Carrier TSTATCCPDF01-A, TSTATCCPAC01-A, TSTATCCPRH01-B, TSTATCCNAC01-A, TSTATCCNHP01-A Product Data

...

Download

Product Data

BUILDER’S THERMOST A T

* Standard Model (AC, HP)

NON-PROGRAMMABLE THERMOST A T

* Standard Model (AC, HP, 2S)

Thermostats

Thermidistat

The Carrier electronic thermostat product line consists of programmable and non-programmable air conditioner, heat pump, and 2-speed models; a programmable dual fuel model; and a programmable/non-programmable Thermidistat offers builder’s thermostats in both air conditioner and heat pump models. These units feature non-mercury based electronic controls built into a subtle, slim plastic enclosure. They require no battery back-up and the programmable/ non-programmable models are not power stealing.

FEATURES/BENEFITS

BUILDER’S THERMOST A TS

Product Offering —

Non-programmable air conditioner and heat pump models available.

Easy to Use — Rubber push buttons

provide easy changes to heating/ cooling mode operation, fan operation, and desired temperature setting.

Manual Changeover — Allows

manual switches in system operation when both heating and cooling are needed on the same day.

Control. Carrier also

TSTAT

Control

PROGRAMMABLE THERMOST A T AND THERMIDIST A T

* Standard Model (AC, HP, 2S) * Dual Fuel Model (DF) * Thermidistat Control Model (RH)

CONTROL

NON-PROGRAMMABLE THERMOSTATS

Clean Design — Features soft,

responsive buttons and an easy-to-read backlit Liquid Crystal Display (LCD).

Accurate, Reliable Temperature Control

temperature at all times, and desired temperature prompts upon demand.

Auto Changeover — Switches

system operation automatically when both heating and cooling are needed on the same day.

Outdoor T emperatur e Display —

Allows a check of the temperature outside before leaving home. (Optional on all models except nonprogrammable air conditioner.)

Clean Filter Indicator — Tells when

it is time to clean the system’ s ﬁlter.

Perfect Complement — Completes

your Carrier total comfort system needs.

— LCD shows current room

Limited W arranty — Standard

1-year warranty available on all parts.

PROGRAMMABLE THERMOSTATS

Carrier programmable thermostats possess the same features as nonprogrammable thermostats plus:

Comfort and Energy Savings —

Seven day programming, with 4 temperature changes provided per day , means comfort when the family is at home and savings through reduced energy usage when the family is away or asleep.

Easy to Use — Simple instructions

are located inside the thermostat’s door.

Duplicate Programming — Copy

the comfort schedule from one day to the next using the copy previous day function.

Override Capability — Hold

function allows the regular schedule to be bypassed with a temporary setting.

Battery-Free — Non-volatile RAM

chip requires no battery backup. Program is retained in memory so

reprogramming is not required after power loss.

Timeguard — Equipment

protection.

Dual Fuel Model — The dual fuel

thermostat can be used to control a gas furnace and a heat pump. This thermostat eliminates the need for an interface control kit.

THERMIDISTAT

CONTROL

Carrier’s Thermidistat Control can be used to control any equipment application except zoning. It possesses all the features and beneﬁts of Carrier’ s non-programmable and programmable thermostats plus:

Enhanced Comfort — Allows the

homeowner to accurately maintain the desired temperature and humidity settings in the home. By combining the functions of a programmable thermostat and a humidistat, the Thermidistat Control provides temperature control, humidity control, and dehumidiﬁcation.

Humidity Control — The

Thermidistat Control accurately controls

humidity level. It humidiﬁes during heating and dehumidiﬁes during cooling.

Automatic Humidity Adjustment

— When used with the outdoor temperature sensor, the Thermidistat Control automatically adjusts the humidity setting, reducing excess condensation on the windows.

V acation mode — With a single touch

of a button, vacation mode adjusts all comfort levels for optimum ef ﬁcienc y while the home is unoccupied — or restores the settings to normal upon return.

Smart Recovery — Provides

consistent heating and cooling right on time as it gradually adjusts indoor temperatures before a scheduled change.

Non-Programmable Option —

Offers the same popular humidity control beneﬁts to consumers who do not need the added beneﬁts of programming. Nine functional buttons, along with the UP and DOWN b uttons, make it easy to enter the temperature and humidity set points. The LCD is the largest display on the market for a nonprogrammable thermostat.

Model number nomenclature

ELECTRONIC THERMOSTATS

T STAT

THERMOSTAT

CC – CARRIER BRAND

B – BUILDER'S P – PROGRAMMABLE N – NON-PROGRAMMABLE

AC – AIR CONDITIONING HP – HEAT PUMP 2S – TWO SPEED/TWO STAGE DF – DUAL FUEL RH – RELATIVE HUMIDITY (THERMIDISTAT CONTROL)

QUANTITY

–A

A98298

SERIES

As an ENERGY STAR Carrier Corporation has determined that the programmable thermostats and programmable Thermidistat Control meet the ENERGY STAR guidelines for energy efﬁciency.

Partner,

Dimensions

2 3⁄4″

4 1⁄4″

Builder's Thermostat

3⁄4″

1 3⁄8″

⁄2″

5 13⁄16″

Non-Programmable Thermostat

1 3⁄8″

⁄8″

Programmable Thermostat and Thermidistat Control

A98297

Product data information

Physical Characteristics

Builder’s Models:

Dimensions: See drawing Appearance: Plastic, designer white, white rubber push buttons

Non-Programmable/Programmable Models:

Dimensions: See drawing Appearance: Plastic, eggshell color, textured

Electrical Characteristics

Builder’s Models:

Input Volts/Amps: 24vac, 1 VA

Non-Programmable/Programmable Models:

Input Volts/Amps: 24vac, 5 VA

Environmental Requirements:

Operating Temperature/Relative Humidity: 32°F (0°C) to 104°F (40°C)/95% rh non-condensing Storage Temperature/Relative Humidity: –40°F (–40°C) to 134°F (56°C)/95% rh non-condensing

Program Speciﬁcations:

Builder’s Models:

Temperature set point range: 50°F (10°C) to 90°F (32°C) Manual changeover Non-volatile memory Fahrenheit or Celsius selectable Power-stealing option on AC model Selectable fan ON or OFF with auxiliary heating (HP model) Five-minute compressor timeguard Four cycles per hour maximum Auxiliary heat LED on heat pump models

Non-Programmable Models:

Temperature setpoint range: 40°F (4°C) to 90°F (32°C) Separate heat and cool setpoints Auto changeover Clean ﬁlter reminder: installer adjustable Permanent memory

Programmable Models:

Temperature setpoint range: 40°F (4°C) to 90°F (32°C) Separate heat and cool setpoints Auto changeover Clean ﬁlter reminder: installer adjustable Permanent memory Programming days: 7 day Programming periods: 4—Wake, Day, Eve, Sleep Hold function Copy previous day function Humidity display and control (Thermidistat Control only)

Wiring Requirements:

Power: 24vac nominal, 18- to 30-vac, 50/60 Hz Wiring: Standard 18 to 22 gage.

Description

PART NO. DESCRIPTION TSTATCCPAC01-A TSTATCCPHP01-A TSTATCCP2S01-A

TSTATCCPDF01-A*

TSTATCCPRH01-B

PART NO. DESCRIPTION TSTATCCNAC01-A TSTATCCNHP01-A TSTATCCN2S01-A

PROGRAMMABLE ELECTRONIC THERMOSTATS

Thermostat, Auto Changeover, 7-Day Programmable, °F/°C, 1-Stage Heat/1-Stage Cool Thermostat, Auto Changeover, 7-Day Programmable, °F/°C, 2-Stage Heat/1-Stage Cool Thermostat, Auto Changeover, 7-Day Programmable, °F/°C, 2-Stage Heat/2-Stage Cool

in AC Mode, 3-Stage Heat/2-Stage Cool in HP Mode Dual Fuel Thermostat, Must Be Used with Outdoor Temperature Sensor TSTATXXSEN01

(For use in all AC, HP, and 2S applications) Thermidistat Control — Non-Programmable/Programmable Thermostat with Humidity Control

(For use in all Dual Fuel, AC, HP, and 2S applications. Includes Outdoor Air Temperature Sensor.)

NON-PROGRAMMABLE ELECTRONIC THERMOSTATS

Thermostat, Auto Changeover, Non-Programmable, °F/°C, 1-Stage Heat/1-Stage Cool Thermostat, Auto Changeover, Non-Programmable, °F/°C, 2-Stage Heat/1-Stage Cool Thermostat, Auto Changeover, Non-Programmable, °F/°C, 2-Stage Heat/2-Stage Cool

in AC Mode, 3-Stage Heat/2-Stage Cool in HP Mode

BUILDER’S MODELS

PART NO. DESCRIPTION TSTATCCBAC01 TSTATCCBHP01*

* Do not use in zoning heat pump applications.

Thermostat, Air Conditioner, Non-Programmable, 1-Stage Heat/1-Stage Cool, Manual Changeover, °F/°C Thermostat, Heat Pump, Non-Programmable, 2-Stage Heat/1-Stage Cool, Manual Changeover, °F/°C

Thermostat accessories

PART NO. DESCRIPTION TSTATXXSEN01* TSTATXXNBP01† TSTATXXPBP01† TSTATXXCNV10‡

* Outdoor temperature sensor is an accessory for all Carrier electronic thermostats, except the non-programmable air conditioner version and

builder’s thermostats. It allows the temperature at a remote location (outdoors) to be displayed on the thermostat. The outdoor temperature sensor The outdoor temperature sensor is included with the Thermidistat Control.

† Thermostat backplate can be used for programmable and non-programmab le electronic thermostats only . This plate is designed to co ver surround-

ing wall area located behind thermostat.

‡ Thermostat conversion kit is a 24-vac accessory that can turn a 4-wire thermostat application into a 5-wire application. This kit can also be used

to replace a broken thermostat wire, or add an extra wire when needed.

must be

Outdoor Air Temperature Sensor Backplate for Non-Programmable Thermostat Backplate for Programmable Thermostat and Thermidistat Control Thermostat Conversion Kit (4 to 5 Wire) — 10 Pack

used with the dual fuel thermostat.

Thermostat and Thermidistat Control application

NON-PROGRAMMABLE THERMOSTAT USA GE

OUTDOOR UNIT

Air Conditioner Heat Pump

INDOOR UNIT 1-Stage Furnace 2-Stage Furnace Typical Fan Coil FK Series Fan Coil

* Model HP thermostat must be ﬁeld converted to air conditioner operation. † Must use Programmable Dual Fuel Thermostat or Thermidistat Control in this application. ‡ Dual Fuel operation controlled by heat pump when using Model 2S Thermostat.

Non-Programmable Models

The TSTATCCNAC01-A Thermostat provides single-stage, non-programmable heat/cool temperature control for 24-vac heating-cooling systems with auto changeover. Temperature display can be selected to read °F or °C.

The TSTATCCNHP01-A Thermostat provides versatile 2-stage heating and single-stage cooling, non-programmable temperature control for 24-vac heating-cooling systems with auto changeov er . Temperature display can be selected to read °F or °C. Thermostat comes factory set to operate as a heat pump model with second-stage controlling auxiliary electric heat. This model can easily be converted from heat pump operation to air conditioning operation requiring 2 stages of g as or electric heat.

The TSTATCCN2S01-A Thermostat provides versatile multiple stage, non-programmable heat/cool temperature control for 24-vac heating-cooling systems with auto changeover. Temperature display can be selected to read °F or °C. Thermostat is designed for 2-speed compressor bearing units. Thermostat comes factory set to operate as a heat pump model with 2-stage cooling and 3 stages of heat, third-stage controlling auxiliary electric heat. This model can easily be con verted from heat pump operation to air conditioning operation requiring 2 stages of cooling and 2 stages of heating.

1 Speed 2 Speed 1 Speed 2 Speed

Model AC or HP* Model 2S † Model 2S‡ Model AC or HP* Model 2S † Model 2S‡ Model AC or HP* Model 2S Model HP Model 2S Model AC or HP* Model 2S Model HP Model 2S

PROGRAMMABLE THERMOSTAT USA GE

OUTDOOR UNIT

Air Conditioner Heat Pump

INDOOR UNIT 1-Stage Furnace 2-Stage Furnace Typical Fan Coil FK Series Fan Coil

* Model HP thermostat must be ﬁeld converted to AC operation. † For use with special 3-stage electric heat setup. ‡ Dual Fuel operation controlled by heat pump when using Model 2S Thermostat.

1 Speed 2 Speed 1 Speed 2 Speed

Model AC or HP* Model 2S Model DF Model DF or 2S‡ Model AC or HP* Model 2S Model DF Model DF or 2S‡ Model AC or HP* Model 2S Model HP Model 2S Model AC or HP* Model 2S Model HP or 2S† Model 2S

Programmable Models

The TSTATCCPAC01-A Thermostat provides single-stage, 7-day programmable heat/cool temperature control for 24-vac heating-cooling systems with auto changeover. Temperature display can be selected to read °F or °C.

The TSTATCCPHP01-A Thermostat provides versatile 2-stage heating and single-stage cooling, 7-day programmable temperature control for 24-vac heating-cooling systems with auto changeov er . Temperature display can be selected to read °F or °C. Thermostat comes factory set to operate as a heat pump model with second-stage controlling auxiliary electric heat. This model can easily be converted from heat pump operation to air conditioning operation requiring 2 stages of g as or electric heat.

The TSTA TCCP2S01-A Thermostat pro vides versatile multiple stage, 7-day programmable heat/cool temperature control for 24-vac heating-cooling systems with auto changeover. Temperature display can be selected to read °F or °C. Thermostat is designed primarily for 2-speed compressor bearing units. Thermostat comes factory set to operate as a heat pump model with 2-stage cooling and 3-stages of heat, third-stage controlling auxiliary electric heat. This model can also perform smart-staging with FK fan coils (special heaters and setup required) using a single-speed heat pump with 3-stages auxiliary electric heat. In addition, this model can easily be converted from heat pump operation to air conditioning operation requiring 2 stages of cooling and 2 stages of heating (e.g. gas or electric heat).

Programmable Dual Fuel Model

The TSTATCCPDF01-A Thermostat provides single-stage or multiple-stage dual fuel operation, 7-day programmable heat/ cool temperature control for 24-vac systems with auto changeov er. Temperature display can be selected to read °F or °C. The Dual Fuel Thermostat is designed with an adjustable balance point for heat pumps when using a gas furnace for backup or auxiliary heat. Thermostat comes factory set to operate single-speed equipment, but is easily conﬁgured to match multiple stage equipment combinations. This model requires use of the Outdoor Air T emperature Sensor accessory. Using the dual fuel thermostat eliminates the need for an interface control.

THERMIDISTAT CONTROL USAGE

OUTDOOR UNIT

Air Conditioner Heat Pump

INDOOR UNIT 1-Stage Furnace 2-Stage Furnace

Typical Fan Coil

FK Series Fan Coil

* The Thermidistat Control may be used in all applications but must be ﬁeld conﬁgured for speciﬁc application.

1 Speed 2 Speed 1 Speed 2 Speed

Model RH*

Thermidistat Control

The TSTATCCPRH01-B Thermidistat Control provides single-stage or multiple-stage equipment operation, 7-day programmable heat/cool temperature control for 24-vac systems with auto changeover. It controls both humidiﬁcation and dehumidiﬁcation and can be used to control heat pumps, air conditioners, or dual fuel applications. Temperature display can be selected to read °F or °C. The Thermidistat Control is designed primarily as an e xtension of the programmable thermostat line to provide humidify and dehumidify outputs in controlling humidity. It can also be ﬁeld conﬁgured to be nonprogrammable. Humidify outputs connect directly to 24-v humidiﬁers. Dehumidify outputs connect directly to variable-speed furnaces or fan coils that have dehumidiﬁcation capabilities. To achieve full beneﬁts, this model requires use of the Outdoor Air Temperature Sensor accessory, which is included with the Thermidistat Control.

The Thermidistat Control comes packaged with the 40FKA for Comfort Heat.

Operational information

Five-minute compressor timeguard

This timer prevents the compressor from starting unless it has been of f for at least 5 minutes. It can be defeated for 1 c ycle by simultaneously pressing the FAN mode button and INCREASE TEMPERATURE (UP) button.

Fifteen-minute cycle timer

This timer prevents the start of a heating or cooling cycle until at least 15 minutes after the last start of the same cycle. Its function is to assure that equipment is not cycled more than 4 times per hr . This timer is defeated for 1 c ycle when the desired temperature is manually changed. It can also be defeated for 1 cycle by simultaneously pressing the FAN mode button and INCREASE TEMPERATURE button.

Fifteen-minute staging timer

In multistage heating or cooling, this timer prevents an y higher stage from turning on until preceding stage has been on for 15 minutes. This timer is defeated if temperature error is greater than 5°F (usually due to a large change in desired temperature).

Minimum on time

In normal operation, when a stage turns on, it will not turn off for a minimum of 2 minutes (3 minutes on Thermidistat Control model).

Heat/Cool setpoints (desired temperature)

A minimum difference of 3° is enforced between heating and cooling desired temperatures. This is done by allowing 1 setting to “push” the other, to maintain this dif ference. (Thermidistat Control 2° and adjustable.) Builder’s thermostats are controlled by a single set point.

Equipment on indicators (Thermidistat Control)

When cooling equipment is ON, a COOL icon preceded by a small triangle is displayed below the cool setpoint. While cooling equipment turn on is delayed by a staging or cycle timer, the triangle will ﬂash. The same is true for the HEAT icon and its preceding triangle located under the heat setpoint. These 2 triangles are also used to indicate the state of the humidify and dehumidify outputs. See next section.

Humidify/dehumidify output on indicators (Thermidistat Control)

Within humidity select screen (selected by Humidity button and indicated by “hu” or “dhu” on clock display), the triangle under humidity setpoint will be on while humidify output is on. The triangle under dehumidify setpoint will be on while dehumidify output is active (turned off, because this output is reverse logic).

Auto changeover

When auto changeover mode is selected, a change from heat to cool (or vice versa) will not occur until an opposite mode demand has existed for 20 minutes. If setpoint is changed, the 20 minute requirement is deleted. Builder’s thermostats are manual changeover.

Emergency heat mode

When thermostat is controlling a heat pump and emergency heat is selected, all Y signals are locked out, and W becomes energized upon a call for heat.

Smart Recovery (Programmable models)

With Smart Recov ery selected, transition out of setback begins a ﬁxed time period before selected reco very time and gradually adjusts room temperature so that the desired temperature will be achieved at selected recovery time.

Manufacturer reserves the right to discontinue, or change at any time, specifications or designs without notice and without incurring obligations.

Book 1 4 Page 8 Catalog No. 02TS-TA1 Printed in U.S.A. PC 101 Form TSTAT-2PD Tab misc misc

Indianapolis, IN 46231 5-98

•

Replaces: TSTAT-1PD
