FX4D
Comfortt Series Fan Coil
Sizes 019 thr u 061
Product Data
AIR HANDLER TECHNOLOGY
AT ITS FINEST
The FX4D fan coils combine the proven technology of Carrier fan
coil units with Puron, the environmentally sound refrigerant.
These fan coils are loaded with popular features. Factory--installed,
refrigerant--specific thermostatic expansion valves (TXV) are
standard with these fan coil designs. The designs feature contoured
condensate pans with rugged, drain connections, ensuring that little
water is left in the unit at the end of the cooling duty cycle. The
lack of standing condensate and corrosion free pans improves IAQ
and product life, features homeowners appreciate.
Standard features include grooved copper tubing and louvered
aluminum fins. The large face areas of the refrigerant coils provide
superior efficiency for high SEER and HSPF performance. Coil
circuiting has also been updated to make the most of all Carrier
heat pumps and air conditioners. Also units come with solid state
fan controls, 1--in (25mm) thick insulation with R--value of 4.2,
multi--speed motors, and fully--wettable coils. Units can
accommodate factory-- and/or field--installed heaters from 3 to 30
kW.
It also should be noted that the unique cabinet design of these fan
coils meet new stringent regulations for cabinet air leakage -- a
requirement of 2% cabinet leakage rate when tested at 1.0 inches of
static pressure.
The FX4D fan coil is the Puron refrigeration design loaded with
popular features. It comes in a pre--painted (taupe metallic)
galvanized steel casing and is shipped with a cleanable, permanent
framed filter, and a factory--supplied power plug. ArmorCoatt
provides a tin plating of the indoor coil’s copper hairpins. This
creates a barrier between the corrosion--causing elements and the
coil. These fan coils utilize the latest in electronic commutation
motor (ECM) technology through the use of high efficiency, X13,
blower motors.
A10009
STANDARD FEATURES
S High efficiency ECM (electronic commutating motor) X--13 motors -- all sizes
S Integrated motor controls have replaced integrated circuit board
S Large, grooved tube, louvered fin coils
S Efficient, quiet, time--tested blower housings and diffusers
S Sturdy, drainable condensate pans
S Cabinet construction features innovations designed to prevent cabinet sweating
S Tested for condensate disposal in much tougher conditions than Air Conditioning and Refrigeration Institute requirements
S Super--thick R--4.2 insulation with vapor barrier
S Pre--painted galvanized steel cabinet (taupe metallic)
S Cabinet design meets stringent regulations for 2% cabinet leakage rate when tested at 1.0 inches static pressure
S Installation--flexible, multipoise units
S Horizontal hanging provisions on cabinet
S No tools required to service filter
S Factory--supplied, cleanable and reusable filter
S Newly improved filter rack area filter door insulation added for improved air seal
S Factory--installed heater packages available (5-- through 15--kW)
S 3-- through 30--kW accessory heaters -- field installed
S Factory--supplied power plug
FX4D
S Easy plug--in provisions for heater installation
S Entry options for high and low voltage wiring hook--up
S Simple, 5--amp blade fuse (and a spare) to protect 40 VA transformer
S Easy coil inspection (removable, snap--in plug on A--coil models)
S Leak--preventing sweat connections
S Modular cabinets available on 037 through 061 sizes.
S Designed for manufactured housing applications.
ADDITIONAL FEATURES
FX4D
S Puron, environmentally sound refrigerant
S Factory--installed Puron refrigerant thermostatic expansion valves (TXV)
S Factory--installed heater packages available
S ArmorCoatt coil protection available
2
MODEL NUMBER NOMENCLATURE
CARRIER FAN COILS
123456789101112
FX4DNB019000
Product Type Heating Size
Fan Coil, Multipoise with Puron 000 = No Heat
005 = 5kW
Electrical 008 = 8 kW
N -- 208/230v, 1 ph, 60 Hz 010 = 10kW
015 = 15kW
Cabinet Style
B -- Modular Coil Coating
F -- Single Piece 0 = Standard
T=ArmorCoatt
Capacity
019 = 18,000
025 = 24,000
031 = 30,000
037 = 36,000
043 = 42,000
049 = 48,000
061 = 60,000
FX4D
the environmentally sound refrigerant
Use of the AHRI Certified
TM Mark indicates a
manufacturer’s
participation in the
program For verification
of certification for individual
products, go to
www.ahridirectory.org.
3
DIMENSIONS
UNIT
FX4DNF019
FX4DNF025
FX4DNF031
FX4DNF037
FX4DNF043
FX4DNF049
FX4DNF061
NOTE:
1. SERIES DESIGNATION IS THE 14TH POSITION
OF UNIT PRODUCT NUMBER
2. ALL DIMENSIONS ARE IN "INCHES" UNLESS NOTED.
ABCDE FGHJ
49 5/8" 17 5/8" 15 3/4" 15 5/8" 15 3/8" 23 1/8" 23 5/8" - 17" X - 122 122
49 5/8" 17 5/8" 15 3/4" 15 5/8" 15 3/8" 23 1/8" 23 5/8" - 17" X - 122 122
53 7/16" 21 1/8" 19 1/4" 19 1/8" 19 3/16" 26 15/16" 27 1/2" - 19" X - 146 146
49 5/8" 21 1/8" 19 1/4" 19 1/8" 15 11/16" 23 7/16" 23 1/8" - - - X 157 157
49 5/8" 21 1/8" 19 1/4" 19 1/8" 15 11/16" 23 7/16" 23 1/8" - - - X 157 157
53 7/16" 24 11/16" 22 3/4" 22 11/16" 19 1/2" 27 1/4" 26 15/16" - - - X 185 185
59 3/16" 24 11/16" 22 3/4" 22 11/16" 25 1/4" 32 15/16" 32 5/8" - - - X 201 201
UNIT CONNECTION SIZES
SUCTION: 018 THRU 025 - 5/8" I.D. SWEAT
030 THRU 037 - 3/4" I.D. SWEAT
042 THRU 061 - 7/8" I.D. SWEAT
LIQUID: 3/8" I.D. SWEAT
CONDENSATE: 3/4" FPT
2 1/8"
CONFIGURATION
SLOPE "A"
10 3/16"
1"
COIL
22 1/16"
SHIPPING WT
(LBS)
NON TIN-COATED
OUTLET AIR
SHIPPING WT
(LBS)
TIN-COATED
NOTE: ALLOW 21" FROM FRONT
FOR SERVICE
7/8"11"
3/4"
FX4D
ALTERNATE
1 7/8"
7/8", 1 3/32"
2" DIA. K.O.'S
FOR HIGH VOLTAGE
POWER WIRING
7/8"DIA. K.O.
FOR LOW VOLTAGE
CONTROL WIRING
ALTERNATE
7/8"DIA. K.O.
FOR LOW VOLTAGE
CONTROL WIRING
7/8",1 3/32",2"DIA. K.O.'S
FOR HIGH VOLTAGE
POWER WIRING
OPPOSITE SIDE
OPTIONAL FIELD CONVERTED
RIGHT SIDE RETURN OPENING
A
(SLOPE COIL UNITS ONLY)
NOTE: MODULAR
UNITS WILL HAVE
A TWO-PIECE
CABINET
1 1/2"
10 7/16"
15/16"
2 5/8"
1 15/16"
TOP VIEW
C
FITTING
PANEL
1"
1 3/8"
J
1 3/16"
B
DISCONNECT OR
CIRCUIT BREAKER
LOCATION
BLOWER, CONTROL,
& ELECTRIC HEATER
ACCESS PANEL
1 3/4"
1 1/4"
19"
OPENING
19 13/16"
RIGHT SIDE VIEW
INLET AIR
COIL ACCESS
PANEL
LIQUID LINE CONNECTION
SUCTION LINE CONNECTION
6 3/16"
10 3/4"
4 11/16"
3 1/16"
9 1/2"
LIQUID LINE
CONNECTION
SUCTION LINE
CONNECTION
E
INLET AIR
LIQUID LINE
CONNECTION
MAX
MODULAR UNITS
2 1/2"
FOR
H
5"
1"
SHOWN WITH "A" COIL DETAILS CONNECTION
LOCATIONS FOR UPFLOW OR HORIZ. APPLICATIONS
OPENING
D
INLET AIR
FRONT VIEW
FILTER ACCESS
PANEL
SLOPE COIL DETAILS
CONNECTION LOCATIONS SHOWN
Fig. 1 -- FX4D -- English
4
FOR UPFLOW OR HORIZ.
LEFT APPLICATIONS
ACCESS PANEL CONFIG. FOR
SLOPE COILS
DOWNFLOW OR HORIZ.
RIGHT APPLICATIONS
AND
"A" COILS
DOWNFLOW APPLICATIONS
A10032
NOTES:
1. CONDENSATE PAN DRAIN CAPS NOT SHOWN FOR CLARITY.
2. ALL DIMENSIONS ARE IN "INCHES" UNLESS NOTED.
AIRFLOW
2 3/16" TYP.
(2 PLACES)*
DIMENSIONS (cont.)
SLOPE COIL
AIRFLOW
7/16" TYP.
(2 PLACES)*
SECONDARY DRAIN
PRIMARY DRAIN
1 13/16"
TYP.
3 1/4"
F
1 1/4"
1" TYP.
(2 PLACES)*
PRIMARY DRAIN
SECONDARY DRAIN
5/16"
TYP.*
7/16" TYP.
(4 PLACES)*
DOWNFLOW
(FIELD CONVERTED)
2 1/8"
F
HORIZ. RIGHT
(FIELD CONVERTED)
G
1 1/4"
1 5/8"
TYP.*
1" TYP.
PRIMARY DRAIN
SECONDARY DRAIN
2 3/16"
(2 PLACES)*
TYP.
1 1/4"
3 1/4"
UPFLOW
(2 PLACES)*
2 7/8"
2 9/16"
FX4D
(AS SHIPPED)
PRIMARY DRAIN
SECONDARY DRAIN
1/2"
7/8"
TYP.*
7/8"
TYP.*
1/2"
TYP.*
HORIZ. LEFT
5"
1 1/4"
1 5/8"
2 7/8"
5/16"
TYP.*
1 13/16"
TYP.*
5/16"
TYP.*
(AS SHIPPED)
* HORIZONTAL MOUNT LOCATIONS - DIMPLES PROVIDED IN TOP PANEL,
AND BACK OF CABINET. IN CABINET BOTTOM. HOLES PROVIDED
F
PRIMARY DRAIN
4 3/4"
3 1/16"
AIRFLOW
7/16" TYP,
(4 PLACES)*
2 3/16" TYP.
(2 PLACES)*
G
1" TYP.
(2 PLACES)*
DOWNFLOW
(FIELD CONVERTED)
7/8"
TYP*
SECONDARY DRAIN
1 13/16"
TYP.
1/2"
TYP*
A-COIL
SECONDARY DRAIN
5/16"
TYP.*
5 7/8"
7 7/8"
PRIMARY DRAIN
1 1/2"
1 3/16"
HORIZ. LEFT
(AS SHIPPED)
(FIELD CONVERTED)
5 7/8"
7 7/8"
PRIMARY DRAIN
SECONDARY DRAIN
1 3/16"
HORIZ. RIGHT
1 13/16"
1 1/2"
TYP*
5/16"
TYP*
TYP.*
TYP.*
1/2"
7/8"
SECONDARY DRAIN
PRIMARY DRAIN
(2 PLACES)*
2 3/16"
TYP.
UPFLOW
(AS SHIPPED)
AIRFLOW
3 1/16"
4 3/4"
7/16" TYP.
(4 PLACES)
1" TYP.
(2 PLACES)
3" 1/8
2 11/16"
A10033
Fig. 2 -- FX4D -- English
5
DIMENSIONS (cont.)
COIL
UNIT
FX4DNF019
FX4DNF025
FX4DNF031
FX4DNF037
FX4DNF043
FX4DNF049
FX4DNF061
NOTE:
1. SERIES DESIGNATION IS THE 14TH POSITION
OF UNIT PRODUCT NUMBER
2. ALL DIMENSIONS ARE IN "MM" UNLESS NOTED.
FX4D
ABCDE FGHJ
1260.5 447.7 400.0 396.9 390.5 587.4 600.1 - 431.8 X - 55.3 55.3
1260.5 447.7 400.0 396.9 390.5 587.4 600.1 - 431.8 X - 55.3 55.3
1357.3 536.6 489.0 485.8 487.4 684.2 698.5 - 482.6 X - 66.2 66.2
1260.5 536.6 489.0 485.8 398.5 595.3 587.4 - - - X 71.2 71.2
1260.5 536.6 489.0 485.8 398.5 595.3 587.4 - - - X 71.2 71.2
1357.3 627.1 577.8 576.3 495.3 692.2 684.2 - - - X 84.1 84.1
1503.4 627.1 577.8 576.3 641.4 836.6 828.7 - - - X 91.2 91.2
UNIT CONNECTION SIZES
SUCTION: 018 THRU 025 - 15.88 I.D. SWEAT
030 THRU 037 - 19.05 I.D. SWEAT
042 THRU 061 - 22.23 I.D. SWEAT
LIQUID: 9.53 I.D. SWEAT
CONDENSATE: 19.0 FPT
54.0
ALTERNATE
22.23 DIA. K.O.
FOR LOW VOLTAGE
CONTROL WIRING
A
22.23, 27.78
50.80 DIA. K.O.'S
FOR HIGH VOLTAGE
POWER WIRING
47.6
49.2
TOP VIEW
22.23 DIA. K.O.
FOR LOW VOLTAGE
CONTROL WIRING
25.4
34.9
30.2
44.4
CONFIGURATION
SLOPE "A"
258.8
25.4
ALTERNATE
22.23, 27.78, 50.80 DIA. K.O.'S
FOR HIGH VOLTAGE
POWER WIRING
OPPOSITE SIDE
OPTIONAL FIELD CONVERTED
RIGHT SIDE RETURN OPENING
(SLOPE COIL UNITS ONLY)
SHIPPING WT
(Kgs)
NON TIN-COATED
NOTE: ALLOW 533.4 FROM FRONT
FOR SERVICE
560.4
OUTLET AIR
482.6
SHIPPING WT
(Kgs)
TIN-COATED
22.2279.4
19.0
NOTE: MODULAR
UNITS WILL HAVE
A TWO-PIECE
CABINET
38.1
J
MAX
FOR
MODULAR UNITS
H
23.8
66.7
265.1
127.0
25.4
SHOWN WITH "A" COIL DETAILS CONNECTION
LOCATIONS FOR UPFLOW OR HORIZ. APPLICATIONS
C
FITTING
PANEL
OPENING
D
INLET AIR
FRONT VIEW
B
DISCONNECT OR
CIRCUIT BREAKER
LOCATION
BLOWER, CONTROL,
& ELECTRIC HEATER
ACCESS PANEL
COIL ACCESS
PANEL
LIQUID LINE CONNECTION
SUCTION LINE CONNECTION
157.2
FILTER ACCESS
PANEL
119.1
77.8
273.0
241.3
SLOPE COIL DETAILS
Fig. 3 -- FX4D -- Metric
31.8
LIQUID LINE
CONNECTION
SUCTION LINE
CONNECTION
CONNECTION LOCATIONS SHOWN
FOR UPFLOW OR HORIZ.
LEFT APPLICATIONS
OPENING
503.2
RIGHT SIDE VIEW
INLET AIR
E
INLET AIR
LIQUID LINE
CONNECTION
ACCESS PANEL CONFIG. FOR
SLOPE COILS
DOWNFLOW OR HORIZ.
RIGHT APPLICATIONS
AND
"A" COILS
DOWNFLOW APPLICATIONS
63.5
A10034
6
NOTES:
1. CONDENSATE PAN DRAIN CAPS NOT SHOWN FOR CLARITY.
2. ALL DIMENSIONS ARE IN "MM" UNLESS NOTED.
82.6
F
31.8
SECONDARY DRAIN
PRIMARY DRAIN
AIRFLOW
DIMENSIONS (cont.)
SLOPE COIL
55.6 TYP.
(2 PLACES)*
G
PRIMARY DRAIN
SECONDARY DRAIN
AIRFLOW
11.1 TYP.
(2 PLACES)*
25.4 TYP.
(2 PLACES)*
73.0
25.4 TYP.
(2 PLACES)*
11.1 TYP.
(4 PLACES)*
DOWNFLOW
(FIELD CONVERTED)
PRIMARY DRAIN
SECONDARY DRAIN
8.0
TYP.*
54.0
F
TYP.*
46.0
HORIZ. RIGHT
(FIELD CONVERTED)
* HORIZONTAL MOUNT LOCATIONS - DIMPLES PROVIDED IN TOP PANEL,
AND BACK OF CABINET. IN CABINET BOTTOM. HOLES PROVIDED
3.45 DIA. HORIZONTAL HANGING HARDWARE TO BE FIELD SUPPLIED.
AIRFLOW
120.6
F
77.8
55.6 TYP.
(2 PLACES)*
G
SECONDARY DRAIN
31.8
82.6
UPFLOW
(2 PLACES)*
55.6
TYP.
(AS SHIPPED)
PRIMARY DRAIN
SECONDARY DRAIN
41.3
12.7
TYP.*
31.8
22.2
TYP.*
22.2
TYP.*
12.7
TYP.*
HORIZ. LEFT
127.0
65.1
FX4D
46.0
TYP.*
31.8
8.0
TYP.*
41.3
73.0
(AS SHIPPED)
A-COIL
22.2
TYP*
12.7
TYP*
PRIMARY DRAIN
SECONDARY DRAIN
38.1
30.2
HORIZ. LEFT
(AS SHIPPED)
149.2
200.0
46.0
TYP*
8.0
TYP*
SECONDARY DRAIN
PRIMARY DRAIN
AIRFLOW
11.1 TYP.
(4 PLACES)
25.4 TYP.
(2 PLACES)
PRIMARY DRAIN
25.4 TYP.
(2 PLACES)*
11.1 TYP,
(4 PLACES)*
DOWNFLOW
(FIELD CONVERTED)
46.0
TYP.
8.0
TYP.*
149.2
200.0
HORIZ. RIGHT
(FIELD CONVERTED)
Fig. 4 -- FX4D -- Metric
PRIMARY DRAIN
SECONDARY DRAIN
30.2
7
79.4
38.1
55.6
TYP.
TYP.*
TYP.*
12.7
22.2
(2 PLACES)*
(AS SHIPPED)
UPFLOW
77.8
120.6
68.3
A10035
FACTORY
ORDERING NO.
FX4DNF0190,T)00 --FX4DNF019005 5
FX4DNF025(0,T)00 --FX4DNF025005 5
FX4DNF031(0,T)00 --FX4DNF031008 8
FX4DNF037(0,T)00 --FX4DNF037010 10
FX4DNF043(0,T)00 --FX4DNF043010 10
FX4DNF049(0,T)00 --FX4DNF049010 10
FX4DNF061(0,T)00 --FX4DNF061010 10
FX4DNF061015 15
FX4DNB031T00 --- 30,000
INSTALLED
HEAT (kW)
FX4D
FX4DNB037T00 --- 36,000
FX4DNB043T00 --- 42,000
FX4DNB049T00 --- 48,000
FX4DNB061T00 --- 60,000
6th digit: B --- Modular cabinet, F --- Single piece cabinet
10th digit: 0 --- Standard copper coil, T --- ArmorCoatt
PHYSICAL DATA
NOMINAL COOLING
CAPACITY (Btuh)
18,000
24,000
30,000
36,000
42,000
48,000
60,000
DIMENSIONS
Height Width Depth
49 5/8--- in
1261mm
49 5/8--- in
1261mm
53 7/16--- in
1357mm
49 5/8--- in
1261mm
49 5/8--- in
1260mm
53 7/16--- in
1357mm
59 3/16--- in
1503mm
53 7/16--- in
1357mm
53 7/16--- in
1357mm
53 7/16--- in
1357mm
53 7/16--- in
1357mm
59 3/16--- in
1503mm
17 5/8--- in
447mm
17 5/8--- in
447mm
21 1/8--- in
536mm
21 1/8--- in
536mm
21 1/8--- in
536mm
24 11/16--- in
627mm
24 11/16--- in
627mm
21 1/8--- in
536mm
21 1/8--- in
536mm
21 1/8--- in
536mm
24 11/16--- in
627mm
24 11/16--- in
627mm
22--- 1/16--- in
560mm
22--- 1/16--- in
560mm
22--- 1/16--- in
560mm
22--- 1/16--- in
560mm
22--- 1/16--- in
560mm
22--- 1/16--- in
560mm
22--- 1/16--- in
560mm
22--- 1/16--- in
560mm
22--- 1/16--- in
560mm
22--- 1/16--- in
560mm
22--- 1/16--- in
560mm
22--- 1/16--- in
560mm
SHIPPING
WEIGHT
122 lb
55 kg
122 lb
55 kg
146 lb
66 kg
157 lb
71 kg
157 lb
71 kg
185 lb
84 kg
201 lb
91 kg
146 lb
66 kg
175 lb
79kg
175 lb
79kg
185 lb
84 kg
201 lb
91 kg
SPECIFICATIONS
MODEL FX4D 019 025 031 037 043 049 061
COIL
Puronr Refrigerant
Metering Device
TXV 2ton 3ton 4ton
Rows/Fins Per In. 3 / 14.5
Face Area (Sq. Ft.) 2.97 3.46 4.45 5.93 7.42
Configuration Slope A
FAN
CFM (Nominal) 600 800 1000 1200 1400 1600 2000
Motor Type (ECM) X --- 1 3 X --- 1 3 X --- 1 3 X --- 1 3 X --- 13 X --- 13 X --- 1 3
Motor Hp 1/3 1/3 1/2 1/2 1/2 3/4 3/4
FILTER
21--- 1/2--- in / 546 mm X 16 --- 3/8--- in / 417 mm 19--- 7/8--- in / 505 mm 23--- 5/16--- in / 585 mm
CABINET CONFIGURATION OPTIONS
1 --- p c 1 --- p c / M o d u l a r
T X V --- f a c t o r y i n s t a l l e d h a r d --- s h u t o f f , b i --- f l o w t y p e f o r h e a t p u m p a p p l i c a t i o n
8
PERFORMANCE DATA
AIRFLOW PERFORMANCE (CFM)
MODEL &
SIZE
FX4D 019
FX4D 025
FX4D 031
FX4D 037
FX4D 043
FX4D 049
FX4D 061
--- Airflow outside 450 cfm/ton.
NOTES:
1. Airflow based upon dry coil at 230v with factory--approved filter and electric heater (2 element heater sizes 018 through 037, 3 element
heater sizes 043 through 061).
2. Airflow at 208 volts is approximately the same as 230 volts because the X--13 motor is a constant torque motor. The torque doesn’t drop
off at the speeds the motor operates.
3. To avoid potential for condensate blowing out of drain pan prior to making drain trap:
Return static pressure must be less than 0.40 in wc.
Horizontal applications of 043 -- 061 sizes must have supply static greater than 0.20 in wc.
4. Airflow above 400 cfm/ton on 049--061 size could result in condensate blowing off coil or splashing out of drain pan.
BLOWER
SPEED
Tap 5 776 745 696 660 609 572
Tap 4 683 644 589 548 494 461
Tap 3 683 644 589 548 494 461
Tap 2 631 563 500 443 409 361
Tap 1 625 524 457 417 367 319
Tap 5 956 920 891 851 816 780
Tap 4 825 795 757 722 674 634
Tap 3 825 795 757 722 674 634
Tap 2 726 695 635 598 543 509
Tap 1 631 563 500 443 409 361
Tap 5 1189 1151 1104 1050 1003 959
Tap 4 1041 998 944 886 837 772
Tap 3 1041 998 944 886 837 772
Tap 2 924 876 817 752 704 660
Tap 1 779 693 628 571 526 476
Tap 5 1363 1332 1294 1253 1207 1157
Tap 4 1237 1206 1160 1121 1070 1013
Tap 3 1237 1206 1160 1121 1070 1013
Tap 2 1095 1058 1007 951 888 824
Tap 1 1014 885 773 673 609 549
Tap 5 1519 1490 1454 1419 1379 1332
Tap 4 1437 1403 1366 1333 1294 1245
Tap 3 1437 1403 1366 1333 1294 1245
Tap 2 1257 1226 1191 1141 1090 1033
Tap 1 1237 1206 1160 1121 1070 1013
Tap 5 1757 1725 1693 1653 1614 1576
Tap 4 1664 1626 1593 1552 1517 1477
Tap 3 1664 1626 1593 1552 1517 1477
Tap 2 1459 1420 1379 1336 1298 1259
Tap 1 1301 1241 1195 1150 1102 1039
Tap 5 2030 1995 1961 1927 1888 1842
Tap 4 1811 1775 1740 1703 1664 1613
Tap 3 1811 1775 1740 1703 1664 1613
Tap 2 1665 1632 1593 1556 1507 1453
Tap 1 1462 1418 1371 1327 1278 1228
0.10 0.20 0.30 0.40 0.50 0.60
FX4D
9
PERFORMANCE DATA (cont.)
GROSS COOLING CAPACITIES (MBH) -- PURONr REFRIGERANT
UNIT
SIZE
FX4D
019
FX4D
025
FX4D
FX4D
031
FX4D
037
FX4D
043
FX4D
049
FX4D
061
See Notes following table.
INDOOR COIL
AIR
CFM EWB TC SHC BF TC SHC BF TC SHC BF TC SHC BF TC SHC BF
72 / 22 36 19 0.00 33 17 0.00 28 15 0.00 24 13 0.00 19 11 0.01
67 / 19 29 19 0.01 26 17 0.01 22 15 0.02 17 13 0.02 12 10 0.02
525
62 / 17 23 19 0.02 20 17 0.02 16 15 0.02 12 12 0.07 10 10 0.24
72 / 22 40 21 0.00 36 19 0.00 32 17 0.00 27 14 0.01 21 12 0.02
67 / 19 33 21 0.02 29 19 0.02 24 17 0.02 19 14 0.02 13 12 0.03
600
62 / 17 26 21 0.02 22 19 0.02 17 17 0.03 13 13 0.08 11 11 0.25
72 / 22 44 23 0.00 40 21 0.00 35 18 0.00 29 16 0.02 23 13 0.02
67 / 19 36 23 0.02 32 21 0.03 26 18 0.03 21 16 0.03 15 13 0.03
675
62 / 17 29 24 0.03 24 21 0.03 19 19 0.04 15 15 0.10 12 12 0.26
72 / 22 48 25 0.00 43 22 0.00 37 19 0.00 31 17 0.02 25 14 0.03
67 / 19 39 25 0.03 34 22 0.03 28 20 0.03 22 17 0.03 16 14 0.04
700
62 / 17 31 25 0.03 26 23 0.03 20 20 0.04 16 16 0.10 13 13 0.26
72 / 22 53 27 0.00 47 24 0.00 41 21 0.01 35 18 0.03 27 15 0.04
67 / 19 43 28 0.04 37 25 0.04 31 22 0.04 25 19 0.04 17 16 0.05
800
62 / 17 34 28 0.04 29 25 0.04 23 22 0.05 18 18 0.12 15 15 0.28
72 / 22 57 30 0.00 51 27 0.00 45 23 0.03 38 20 0.04 30 17 0.05
67 / 19 47 30 0.05 41 27 0.05 34 24 0.05 27 21 0.05 19 17 0.06
900
62 / 17 37 31 0.05 31 28 0.05 25 24 0.06 20 20 0.14 16 16 0.29
72 / 22 59 30 0.00 53 27 0.00 46 24 0.01 38 20 0.02 30 17 0.03
67 / 19 48 31 0.03 42 28 0.03 35 24 0.04 27 21 0.04 19 17 0.04
875
62 / 17 38 31 0.04 32 28 0.04 25 24 0.04 20 20 0.11 16 16 0.27
72 / 22 65 33 0.00 58 30 0.00 51 26 0.02 42 23 0.04 33 19 0.04
67 / 19 53 34 0.04 46 31 0.04 38 27 0.05 30 23 0.05 21 19 0.05
1000
62 / 17 42 35 0.05 35 31 0.05 28 27 0.06 22 22 0.13 18 18 0.29
72 / 22 71 36 0.00 63 33 0.00 55 29 0.03 46 25 0.05 36 20 0.05
67 / 19 58 37 0.05 50 33 0.05 42 29 0.06 33 25 0.06 23 21 0.07
1125
62 / 17 46 38 0.06 38 34 0.06 30 30 0.07 24 24 0.15 20 20 0.30
72 / 22 67 36 0.00 60 32 0.00 52 28 0.00 44 24 0.02 35 20 0.03
67 / 19 54 37 0.03 47 33 0.03 40 29 0.03 31 25 0.03 22 20 0.04
1050
62 / 17 43 37 0.03 36 33 0.03 29 29 0.04 22 22 0.10 18 18 0.26
72 / 22 74 40 0.00 66 36 0.00 58 31 0.01 48 27 0.03 38 22 0.04
67 / 19 60 41 0.04 52 36 0.04 44 32 0.04 35 27 0.04 24 23 0.05
1200
62 / 17 48 41 0.04 40 37 0.04 32 32 0.05 25 25 0.12 21 21 0.28
72 / 22 81 43 0.00 72 39 0.00 63 34 0.03 53 30 0.04 41 25 0.05
67 / 19 66 45 0.05 57 40 0.05 48 35 0.05 38 30 0.05 27 25 0.06
1350
62 / 17 52 46 0.05 44 41 0.05 35 36 0.06 28 28 0.14 23 23 0.29
72 / 22 79 41 0.00 71 37 0.00 62 33 0.02 52 28 0.03 41 23 0.04
67 / 19 64 42 0.04 56 38 0.04 47 33 0.04 37 29 0.04 26 24 0.05
1225
62 / 17 51 43 0.04 43 38 0.04 34 34 0.05 27 27 0.12 22 22 0.28
72 / 22 87 46 0.00 78 41 0.00 68 36 0.03 57 31 0.04 45 26 0.05
67 / 19 71 47 0.05 62 42 0.05 52 37 0.05 41 32 0.05 29 26 0.06
1400
62 / 17 56 48 0.06 47 43 0.06 38 38 0.06 30 30 0.14 25 25 0.29
72 / 22 95 50 0.00 85 45 0.00 74 39 0.04 62 34 0.05 48 28 0.06
67 / 19 77 51 0.06 67 46 0.06 56 40 0.06 44 35 0.07 31 29 0.07
1575
62 / 17 61 52 0.07 51 47 0.07 41 41 0.08 33 33 0.17 27 27 0.31
72 / 22 90 48 0.00 81 43 0.00 71 38 0.00 59 32 0.02 47 27 0.03
67 / 19 73 49 0.03 64 44 0.03 54 38 0.03 42 33 0.03 30 27 0.04
1400
62 / 17 58 49 0.03 49 44 0.03 39 39 0.04 30 30 0.10 25 25 0.26
72 / 22 100 53 0.00 89 48 0.00 78 42 0.01 65 36 0.03 51 30 0.04
67 / 19 81 54 0.04 71 48 0.04 59 43 0.04 47 36 0.04 33 30 0.05
1600
62 / 17 65 55 0.04 54 49 0.04 43 43 0.05 34 34 0.12 28 28 0.28
72 / 22 109 58 0.00 97 52 0.00 85 46 0.03 71 39 0.04 56 33 0.05
67 / 19 89 59 0.05 77 53 0.05 65 47 0.05 51 40 0.05 36 33 0.06
1800
62 / 17 70 60 0.05 59 54 0.05 47 48 0.06 37 37 0.14 31 31 0.29
72 / 22 109 57 0.00 98 51 0.00 86 45 0.00 73 39 0.01 58 32 0.02
67 / 19 89 58 0.02 78 52 0.02 66 46 0.02 52 39 0.03 37 33 0.03
1600
62 / 17 71 59 0.03 60 52 0.03 48 46 0.03 37 37 0.09 31 31 0.24
72 / 22 117 61 0.00 105 55 0.00 92 48 0.01 78 41 0.02 62 35 0.02
67 / 19 95 62 0.03 84 56 0.03 70 49 0.03 56 42 0.03 40 35 0.03
1750
62 / 17 76 63 0.03 64 56 0.03 51 50 0.04 40 40 0.10 33 33 0.25
72 / 22 129 67 0.00 116 60 0.00 102 53 0.02 86 46 0.03 68 38 0.03
67 / 19 105 69 0.04 92 62 0.04 78 54 0.04 62 47 0.04 44 39 0.05
2000
62 / 17 84 70 0.04 71 63 0.04 57 55 0.05 45 45 0.12 37 37 0.27
35 / 2 40 / 4 45 / 7 50 / 10 55 / 13
SATURATED TEMPERATURE LEAVING EVAPORATOR (_F/C)
10
PERFORMANCE DATA (cont)
CFM --- C u b i c F t p e r M i n u t e EWB --- Entering Wet Bulb _F(_C) LWB --- L e a v i n g W e t B u l b _F(_C) TC --- Gross Cooling Capacity 1000 Btuh
SHC --- Gross Sensible Capacity 1000
Btuh
NOTES:
1. Contact manufacturer for cooling capacities at conditions
other than shown in table.
2. Formulas:
Leaving db = entering db --sensible heat cap.
Leaving wb = wb corresponding to enthalpy of air leaving
lwb
lwb=hewb
)
--total capacity (Btuh)
coil (h
h
4.5xCFM
where h
= enthalpy of air entering coil. Direct interpola-
ewb
tion is permissible. Do not extrapolate.
3. SHC is based on 80_F(27_C) db temperature of air enter-
ing coil. Below 80_F(27_C) db, subtract (Correction Fact-
or x CFM) from SHC. Above 80_F(27_C) db, add (Cor-
rectionFactorxCFM)toSHC.
4. Bypass Factor = 0 indicates no psychometric solution. Use
bypass factor of next lower EWB for approximation.
MINIMUM CFM AND MOTOR SPEED SELECTION
FAN COIL SIZES
FX
019 525 525 525 — 600* — — — — —
025 700 700 700 — 700 775* — — — —
031 — 875 875 — 875 875 — 1060* — —
037 — 1050 970 970 970 920 — 1040 — —
043 — — 1225 1225 1225 1225 1225 1225 — —
049 — — 1400 1400 1400 1400 1400 1400 1400 1400
061 — — 1750 1750 1750 1750 1750 1750 1750 1750
* Indicates medium speed (blue). All other motor speeds at low tap.
3 5 8 9 10 15 18 20 24 30
BF --- B y p a s s F a c t o r MBH --- 1000 Btuh
1.09 x CFM
BYPASS
FACTOR
0.10 .098 1.96 2.94 3.92 4.91
0.20 0.87 1.74 2.62 3.49 4.36
0.30 0.76 1.53 2.29 3.05 3.82
Interpolation is permissible.
Correction Factor = 1.09 x (1 --- BF) x (db --- 80)
HEATER kW
SHC CORRECTION FACTOR
ENTERING AIR DRY -- BULB TEMPERAT URE (_F)
79 78 77 76 75 Under 75
81 82 83 84 85 Over 85
ENTERING AIR DRY -- BULB TEMPERAT URE (_C)
26 25 25 24 24 Under 75
27 28 28 29 29 Over 85
Correction Factor
Use
formula
shown
below
FX4D
AIR DELIVERY PERFORMANCE CORRECTION COMPONENT PRESSURE DROP (in wc)
AT INDICATED AIRFLOW (DRY--TO--WET COIL)
FX
SIZE
019 0.034 0.049 0.063 --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --025 0.016 0.027 0.038 0.049 0.059 --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --031 --- --- --- --- --- --- 0.049 0.059 0.070 0.080 --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --037 --- --- --- --- --- --- --- --- --- --- 0.055 0.064 0.073 0.081 --- --- --- --- --- --- --- --- --- --- --- --- --- --043 --- --- --- --- --- --- --- --- --- --- --- --- --- --- 0.049 0.056 0.063 0.070 --- --- --- --- --- --- --- --- --- --049 --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- 0.038 0.043 0.049 0.054 0.059 --- --- --- --061 --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- 0.027 0.031 0.035 0.039 0.043
500 600 700 800 900 1000 1100 1200 1300 1400 1500 1600 1700 1800 1900 2000
CFM
11
PERFORMANCE DATA (cont)
FACTORY--INSTALLED FILTER STATIC PRESSURE DROP (in wc)
UNIT SIZE
FX4D
019, 025 0.012 0.022 0.048 0.072 --- --- --- --- ---
031, 037, 043 --- --- 0.036 0.051 0.07 0.092 0.12 --- ---
049, 061 --- --- --- --- --- 0.073 0.086 0.105 0.13
400 600 800 1000 1200 1400 1600 1800 2000
ELECTRIC HEATER STATIC PRESSURE DROP (in wc)
019 --- 037 043 --- 061
HEATER
ELEMENTS
0 0 +.02 0 0 +.04
1 3, 5 +.01 2 8, 10 +.02
2 8, 10 0 3 9, 15 0
3 9, 15 –.02 4 20 –.02
4 20 –.04 6 18, 24, 30 –.10
The airflow performance data was developed u sing fan coils with 10---kW electric heaters (2 elements) in the 019 through 037 size units and 15 ---kW heaters (3
FX4D
elements) in the 043through 061 size units. For fan coils with heaters of a different number of elements, the externa l available static at a given CFM fr om the
curve may be corrected by adding or subtracting available external static pressure as indicated above.
kW
EXTERNAL STATIC
PRESSURE
CORRECTION
ACCESSORY ELECTRIC HEATERS
HEATER
PAR T NO.
KFCEH0401N03 3 230/1 3 None 018–024 9,400
KFCEH0501N05 5 230/1 5 None 018–060 15,700
KFCEH0801N08 8 230/1 8 None 018–060 25,100
KFCEH0901N10 10 230/1 10 None 018–060 31,400
KFCEH3201F20 20 230/1 5, 20 Fuse} 030–060 62,800
KFCEH1601315 15 230/3 5, 15 None 036–060 47,100
KFCEH2001318 18 230/3 6, 12, 18 None 042–060 56,500
KFCEH3401F24 24 230/3* 8, 16, 24 Fu se 048, 060 78,300
KFCEH3501F30 30 230/3* 10, 20, 30 Fuse 048, 060 94,100
KFCEH2401C05 5 230/1 5 Circuit Breaker 018–060 15,700
KFCEH2501C08 8 230/1 8 Circuit Breaker 018–060 25,100
KFCEH2601C10 10 230/1 10 Circuit Breaker 018–060 31,400
KFCEH3301C20 20 230/1 5, 20 Circuit Breaker 030–060 62,800
KFCEH2901N09 9 230/1{ 3, 9 None 036–060 28,200
KFCEH3001F15 15 230/1 5, 15 Fuse} 024–060 47,100
KFCEH3101C15 15 230/1 5, 15 Circuit Breaker 024–060 47,100
* Field convertible to 1 phase.
{ Field convertible to 3 phase.
} Single point wiring kit required for these heaters in Canada.
** Blower Motor heat not included.
kW @
240V
VOLTS/
PH
STAGES (kW
OPERATING)
CFM
HEATER
ELEMENTS
INTERNAL
CIRCUIT
PROTECTION
KW
FAN COIL SIZE
USED WITH
EXTERNAL STATIC
PRESSURE
CORRECTION
HEATING CAP.**
@ 230V
ESTIMATED SOUND POWER LEVEL (dBA)
UNIT SIZE
FX
019 600 0.25 64.7 60.7 56.7 53.7 51.7 49.7 45.7
025 800 0.25 66.0 62.0 58.0 55.0 53.0 51.0 47.0
031 1000 0.25 67.0 63.0 59.0 56.0 54.0 52.0 48.0
037 1200 0.25 67.8 63.8 59.8 56.8 54.8 52.8 48.8
043 1400 0.25 68.4 64.4 60.4 57.4 55.4 53.4 49.4
049 1600 0.25 69.0 65.0 61.0 58.0 56.0 54.0 50.0
061 2000 0.25 70.0 66.0 62.0 59.0 57.0 55.0 51.0
* Estimated sound power levels have been derived using the method described in the 1987 ASHRAE HVAC Systems & Applications Handbook, Chapter 52,
p. 52.7.
CONDITIONS OCTAVE BAND CENTER FREQUENCY*
CFM
Ext Static
Pressure
63 125 250 500 1000 2000 4000
12
ELECTRICAL DATA FOR UNITS WITH FACTORY--INSTALLED HEAT
FX4DNF
MODEL NO.
019005 1/3 2.8 208/230/1/60 0501N05 18.1/20.0 26.1/28.5 30/30 N/A N/A N/A N/A N/A N/A
025005 1/3 2.8 208/230/1/60 0501N05 18.1/20.0 26.1/28.5 30/30 N/A N/A N/A N/A N/A N/A
031008 1/2 4.1 208/230/1/60 0801N08 28.9/32.0 41.3/45.2 45/50 N/A N/A N/A N/A N/A N/A
037010 1/2 4.1 208/230/1/60 0901N10 36.2/40.0 50.4/55.1 60/60 N/A N/A N/A N/A N/A N/A
043010 1/2 4.1 208/230/1/60 0901N10 36.2/40.0 50.4/55.1 60/60 N/A N/A N/A N/A N/A N/A
049010 3/4 6.0 208/230/1/60 0901N10 36.2/40.0 52.8/57.5 60/60 N/A N/A N/A N/A N/A N/A
061010 3/4 6.0 208/230/1/60 0901N10 36.2/40.0 52.8/57.5 60/60 N/A N/A N/A N/A N/A N/A
061(0,T)015 3/4 6.0 208/230/1/60 1501F15 54.2/59.9 75.3/82.4 80/90 36.2/40.0 52.8/57.5 60/60 18.1/20.0 22.6/25.0 25/25
MCA --- Minimum Circuit Amps
MOCP --- Maximum Overcurrent Protection
MTRHPMTR
FLA
VOLTS/PH/
HZ
HEAT PACK
INSTALLED
MKFCEH
SINGLE CIRCUIT DUAL CIRCUIT
Heater
Amps
MCA MOCP
Htr.
Amps
L1/L2 L1/L2 L1/L2 L3/L4 L3/L4 L3/L4
MCA MOCP
Htr.
Amps
MCA MOCP
ELECTRICAL DATA FOR UNITS WITHOUT ELECTRICAL HEAT
MODEL NO.
FX4DNF019(0,T)00 1/3 2.8 208/230/1/60 3.5 15 14
FX4DNF025(0,T)00 1/3 2.8 208/230/1/60 3.5 15 14
FX4DNF031(0,T)00 1/2 4.1 208/230/1/60 5.1 15 14
FX4DNF037(0,T)00 1/2 4.1 208/230/1/60 5.1 15 14
FX4DNF043(0,T)00 1/2 4.1 208/230/1/60 5.1 15 14
FX4DNF049(0,T)00 3/4 6.0 208/230/1/60 7.5 15 14
FX4DNF061(0,T)00 3/4 6.0 208/230/1/60 7.5 15 14
FX4DNB031T00 1/2 4.1 208/230/1/60 5.1 15 14
FX4DNB037T00 1/2 4.1 208/230/1/60 5.1 15 14
FX4DNB043T00 1/2 4.1 208/230/1/60 5.1 15 14
FX4DNB049T00 3/4 6.0 208/230/1/60 7.5 15 14
FX4DNB061T00 3/4 6.0 208/230/1/60 7.5 15 14
MTR
HP
MTR
FLA
VOLTS/PH/HZ
SINGLE CIRCUIT
MCA
MAXIMUM
OVERCURRENT
PROTECTION
BRANCH CIRCUIT
MIN WIRE SIZE*
AWG
FX4D
* Usecopperwireonly.Use75_C only in this application. When using non ---metallic (NM) sheathed cable, wire size required should be based on that of 60_C
conductors, instead of wire sizes shown in table above per NEC Article 336---26.
NOTE: If branch circuit wire length exceeds 100 ft (30 m), consult NEC 215 --- 2 to determine maximum wire length. Use 2% voltage drop.
FLA --- F u l l L o a d A m p s
13
Dual Circuit
208/230V (Ft)‡
Max Wire Length
Single
Circuit
208/230V (FT)‡
MAX WIRE LENGTH
Dual Circuit
208/230V
Max Fuse/CktBkr Amps
Single
Circuit
AMPS
208/230V
MAX FUSE/CKT BKR
FX4D
Dual Circuit
208/230V
Min Gnd Wire Size
BRANCH CIR CUIT
Single
Circuit
Dual Circuit
208/230V†
Min Wire Size (AWG)
Single
Circuit
Dual Circuit
208/230V*
Min Ampacity
Single
Circuit
Dual Circuit
208/230V
HEATER AMPS
Single
Circuit
208/230V
MIN GND
WIRE SIZE
208/230V†
MIN WIRE SIZE (AWG)
208/230V*
MIN AMPACITY
208/230V
HEATER AMPS
TION
CIRCUIT
PROTEC-
INTERNAL
PHASE
ACCESSORY ELECTRIC HEATER ELECTRICAL DATA
kW
HEATER
PART NO.
5 3.8 1 None 18.1/20.0 — — 26.0/28.4 — — 10/10 — — 10/10 — — 30/30 — — 66/66 — —
5 3.8 1 None 18.1/20.0 — — 31.2/ 33.5 — — 8/8 — — 10/10 — — 35/35 — — 85/88 — —
5 3.8 1 CktBkr 18.1/20.0 — — 26.0/28.4 — — 10/10 — — 10/10 — — 30/30 — — 66/66 — —
240v 208v L1,l2 L3,L4 L1,L2 L3,L4 L1, L2 L3, L4 L1, L2 L3,L4 L1,L2 L3,L4 L1,L2 L3,L4
1
KFCEH0401N03 3 2.3 1 None 10. 9/12.0 — — 15.9/17.3 — — 12/12 — — 12/12 — — 20/20 — — 67/68 — —
5 3.8 1 CktBkr 18.1/20.0 — — 31.2/33.5 — — 8/8 — — 10/ 10 — — 35/35 — — 85/88 — —
2
1
2
KFCEH0801N08 8 6.0 1 None 28.9/32.0 — — 44.7/ 48.5 — — 8/8 — — 10/10 — — 45/50 — — 59/60 — —
KFCEH0501N05
KFCEH0501N05
KFCEH2501C08 8 6.0 1 CktBkr 28.9/32.0 — — 44.7/48.5 — — 8/8 — — 10/ 10 — — 45/50 — — 59/60 — —
KFCEH2401C05
KFCEH2401C05
PHASE
kW
240V 208V L1, L2 L3, L4 L5,L6 L1,L2 L3,L4 L5,L6 L1,L2 L3, L4 L5,L6 L1,L2 L3,L4 L5,L6 L1,L2 L3, L4 L5,L6
24 18. 0 3 Fuse 50.1/55.4 — — 71.2/77.8 — — 4/4 — — 8/8 — — 80/80 — — 94/95 — —
24 18. 0 1 Fuse 86.7/95.5 — — 116.9/ 127.9 — — 1/1 — — 6/6 — — 125/150 — — 115/116 — —
30 22. 5 3 Fuse 62.6/69.2 — — 86.8/95.0 — — 3/3 — — 8/8 — — 90/100 — — 97/98 — —
30 22. 5 1 Fuse 109.0/120.0 — — 144.8/158.5 — — 0/00 — — 6/6 — — 150/175 — — 117/150 — —
1. For fan coil sizes 018---037.
2. For fan coil sizes 042---061.
NO.
HEATER PART
KFCEH2901N09 9 6.8 1 None 32.8/36.0 — — 49.5/ 53.5 — — 8/6 — — 10/10 — — 50/60 — — 54/87 — —
KFCEH0901N10 10 7.5 1 None 36.2/40.0 — — 53.8/ 58.5 — — 6/6 — — 10/10 — — 60/60 — — 78/80 — —
KFCEH2601C10 10 7.5 1 CktBkr 36.2/40.0 — — 53.8/58.5 — — 6/6 — — 10/ 10 — — 60/60 — — 78/80 — —
KFCEH2901N09** 9 6.8 3 None 18.8/20.8 — — 32.0/34. 5 — — 8/8 — — 10/10 — — 35/ 35 — — 83/ 85 — —
KFCEH3101C15 15 11.3 1 Ckt Bkr — 36.2/40.0 18.1/ 20.0 — 53.8/58.5 22.7/25.0 — 6/6 10/ 10 — 10/10 10/10 — 60/60 25/ 25 — 78/80 75/ 76
KFCEH3201F20 20 15.0 1 Fuse 72.3/79.9 36.2/40. 0 36.2/40.0 98.9/108.4 53.8/58.5 45.3/50.0 3/2 6/6 8/ 8 8/ 6 10/ 10 10/10 100/110 60/60 50/50 85/109 78/80 59/59
KFCEH3301C20 20 15.0 1 Ckt Bkr — 36.2/40.0 36.2/ 40.0 — 53.8/58.5 45.3/50.0 — 6/6 8/8 — 10/10 10/10 — 60/60 50/50 — 78/80 59/ 59
KFCEH3401F24††
KFCEH3501F30††
KFCEH3001F15 15 11.3 1 Fuse 54.2/59.9 36.2/40. 0 18.1/20.0 76.3/ 83.4 53.8/ 58.5 22.7/25.0 4/4 6/6 10/10 8/ 8 10/ 10 10/10 80/90 60/60 25/ 25 88/89 78/ 80 75/76
FIELD MULTIPOINT WIRING OF 24--AND 30--kW SINGLE PHASE
KFCEH1601315 15 11.3 3 None 31.3/34.6 — — 47.7/51.8 — — 8/ 6 — — 10/10 — — 50/60 — — 56/90 — —
KFCEH2001318 18 13.5 3 None 37.6/41.5 — — 55.5/60.4 — — 6/ 6 — — 10/8 — — 60/70 — — 76/77 — —
KFCEH3401F24†† 24 18.0 1 28.9/32.0 28.9/32.0 28.9/32.0 44.7/48.5 36.2/40.0 36.2/40.0 8/8 8/8 8/8 10/10 45/50 40/40 40/40 59/60 73/73 73/73
theNationalElectricCode(ANSI/NFPA70).
* Includes blower motor amps of largest fan coil used with heater.
{ Copper wire must be used. If other than uncoated (non --- plated), 75_C ambient, copper wire (solid wire for 10 AWG and smaller, stranded wire for larger than 10 AWG) is used, consult applicable tables of
} Length shown is as measured 1 way along wire path between unit and service panel for a voltage drop not to exceed 2%.
** Field convertible to 3 phase.
KFCEH3501F30†† 30 22.5 1 36.2/40.0 36.2/40.0 36.2/40.0 53.8/58.5 45.3/50.0 45.3/50.0 6/6 8/8 8/8 10/10 60/60 50/50 50/50 78/80 59/59 59/59
{{ Field convertible to 1 phase, single or multiple supply circuit.
3. Sin gle circuit application of F15 and F20 heaters requires single - --point wiring kit accessory.
NOTES:
14
HEATER ELECTRICAL DATA
FACTORY--INSTALLED HEATER OPTIONS*
MODEL 019 025 031 037 043 049 061
FX4DNF 5 5 8 10 10 10 10, 15
* For field - --installed heater/fan coil combinations, see Accessory Electric Heaters.
ELECTRIC HEATER INTERNAL PROTECTION
HEATER kW PHASE
5 1 — 1/60
8 1 — 1/60
9 1/3 — —
10 1 — 1/60
15 1 2/30–2/60 2/60
15 3 — —
18 3 — —
20 1 4/60 2/60
24 1/3 6/60 —
30 1/3 6/60 —
* All circuit breakers are 2 pole.
FUSE
QTY/SIZE
When using units with 20--, 24--, and 30--kW electric heaters, maintain a 1--in. (25 mm) clearance from combustible materials to discharge
plenum and ductwork and maintain a distance of 36 in. (914mm) from the unit. Use an accessory downflow base to maintain proper clearance
on downflow installations. Use flexible connectors between ductwork and unit to prevent transmission of vibration. When electric heater is
installed, use heat resistant material for flexible connector between ductwork and unit at discharge connection. Ductwork passing through
unconditioned space must be insulated and covered with vapor barrier
CKT BKR*
QTY/SIZE
FX4D
ACCESSORIES
ITEM ACCESSORY PART NO.* FAN COIL SIZE USED WITH
1. Disconnect Kit KFADK0201DSC Cooling controls and heaters 3--- through 10--- kW
KFACB0201CFB 019, 025
2. Downflow Base Kit
3. Downflow Conversion Kit
4. Downflow/Horizontal Conversion Gasket Kit KFAHD0101SLP All
5. Horizontal Water Management Kit (25 pack)
6. Single-- -Point Wiring Kit KFASP0101SPK O n l y w i t h 1 5 --- a n d 2 0 --- k W F u s e d H e a t e r s
7. Filter Kit (12 Pack)
8.
9. PVC Cond ensate Trap Kit (50 pack) KFAET0150ETK All
10. Air Cleaner 240--- volt Conversion Kit KEAVC0201240 All
* Factory authorized and listed, field ---installed.
{ KFAHD0101SLP must also be purchased for downflow applications.
} KFAHD0101SLP must also be purchased for downflow or horizontal applications.
Fan Coil Filter Cabinet
(Fan Coil Filter Media)
{
}
KFACB0301CFB 031, 037, 043
KFACB0401CFB 049, 061
KFADC0201SLP Slope Coil Units — 019, 024, 031
KFADC0401ACL A --- Coil Units — 037, 043, 049, 061
KFAHC0125AAA All
KFAFK0112SML NA
KFAFK0212MED 019, 025
KFAFK0312LRG 031 037, 043
KFAFK0412XXL 049, 061
FNCCABCC0014
(FILXXFNC0014)
FNCCABCC0017
(FILXXFNC0017)
FNCCABCC0021
(FILXXFNC0021)
FNCCABCC0024
(FILXXFNC0024)
NA
019, 025
031, 037, 043
049, 061
15
ACCESSORY KITS DESCRIPTION SUGGESTED AND REQUIRED USE
1. Disconnect Kit
The kit is used to disconnect electrical power to the fan coil so service or maintenance may be performed safely.
SUGGESTED USE: Units for 3-- through 10--kW electric resistance heaters and cooling controls.
2. Downflow Base Kit
This kit is designed to provide a 1--in. minimum clearance between unit discharge plenum, ductwork, and combustible materials. It
also provides a gap--free seal with the floor.
REQUIRED USE: This kit must be used whenever fan coils are used in downflow applications.
3. Downflow Conversion Kit
Fan coils are shipped from the factory for upflow or horizontal--left applications. Downflow conversion kits provide proper condensate
water drainage and support for the coil when used in downflow applications. Separate kits are available for slope coils and A--coils.
REQUIRED USE: This kit must be used whenever fan coils are used in downflow applications.
4. Downflow/Horizontal Conversion Gasket Kit
This kit provides the proper gasketing of units when applied in either a downflow or horizontal application.
REQUIRED USE: Fan coils in either downflow or horizontal applications.
5. Horizontal Applications -- Water Management Kit
This kit provides proper installation of fan coils under conditions of high static pressure and high relative humidity.
SUGGESTED USE: All fan coils.
6. Single Point Wiring Kit
FX4D
The single point wiring kit acts as a jumper between L1 and L3 lugs, and between the L2 and L4 lugs. This allows the installer to run
two heavy--gauge, high--voltage wires into the fan coil rather than 4 light--gauge, high--voltage wires.
SUGGESTED USE: Fan coils with 15-- and 20--kW fused heaters only.
7. Filter Kit (12 pack)
The kit consists of 12 fan coil framed filters. These filters collect large dust particles from the return air entering the fan coil and
prevents them from collecting on the coil. This process helps to keep the coil clean, which increases heat transfer and, in turn, the
efficiency of the system.
SUGGESTED USE: To replace filters in fan coils.
REQUIRED USE: All units unless a filter grille is used.
8. Fan Coil Filter Cabinet
This cabinet is mounted to the fan coil on the return air end and designed to slip over the outer fan coil casing. The cabinets are
insulated using the same insulation as production fan coils. They are designed for the removal of particulates from indoor air using
FILXXFNC00(14, 17, 21, 24) media filter cartridges. These fan coil media filter cartridge kits are designed for the removal of particles
from indoor air. The cartridge is installed in the return air duct next to the air handler or further upstream.
SUGGESTED USE: All fan coils.
9. Condensate Drain Trap Kit
This kit consists of 50 PVC condensate traps. Each trap is pre--formed and ready for field installation. This deep trap helps the system
make and hold proper condensate flow even during blower initiation.
SUGGESTED USE: All fan coils.
10. Air Cleaner 240--volt Conversion Kit
The AIRA electronic air cleaner comes ready for 115--v operation.
REQUIRED USE: This kit is required when running 240--volt circuit to air cleaner.
Copyright 2010 Carrier Corp. S 7310 W. Morris St. S Indianapolis, IN 46231 Printed in U.S.A. Edition Date: 09/ 10
Manufacturer reserves the right to change, at any time, specifications and designs without notice and without obligations.
Catalog No: FX4D--- 01PD
Replaces: NEW
16
Loading...
