Canon imageRUNNER 2206N, imageRUNNER 2206, imageRUNNER 2006N Getting Started

Page 1

Getting Started

Please read "Important Safety Instructions" before operating this product. After you finish reading this guide, store it in a safe place for future reference. The information in this document is subject to change without notice.

canon.com/oip-manual

FT6-2098 (000)

Page 2

Contents

Installation Requirements ................................................................................................. 3

About the Supplied Manuals ...........................................................................................3

Navigating the Menu and Text Input Method ...........................................................4

Turning ON/OFF the Power .............................................................................................. 4

Specifying the Initial Settings .......................................................................................... 5

Choosing the Method to Connect the Machine to the Computer .....................5

Connecting via a LAN (imageRUNNER 2206N/2006N) ........................................... 5

Connecting via a USB Cable .............................................................................................6

Connecting via a Wireless LAN (imageRUNNER 2206N/2006N) .......................... 6

Setting Wireless LAN (imageRUNNER 2206N/2006N) ............................................. 7

Checking That the Wireless LAN Setting is Completed (imageRUNNER

2206N/2006N) ....................................................................................................................... 9

Setting a Paper Size and Type ..........................................................................................9

Perform Useful Tasks .........................................................................................................10

Clearing Paper Jams ..........................................................................................................11

Replacing Toner Cartridge ..............................................................................................12

Appendix ...............................................................................................................................14

Page 3

Installation Requirements

About the Supplied Manuals

imageRUNNER 2206N/2006N

100 mm or more

1,022.9 mm

* Feeder (Optional)

imageRUNNER 2206

100 mm or more

533 mm

1,285 mm

①

Getting Started (This manual):

Read this manual  rst. This manual describes the basic machine settings, operations, and cautions. Be sure to read this manual before using the machine.

②

MF Driver Installation Guide (Visit the website):

You can access canon.com/oip-manual to read the MF Driver

③

User’s Guide (Visit the website):

Installation Guide that describes software installation.

You can access canon.com/oip-manual to read the User’s Guide that describes all functions of this machine.

1,022.9 mm

1,285 mm

533 mm

Page 4

Navigating the Menu and Text Input Method

imageRUNNER 2206N/2006N

The control panel shown here is for the imageRUNNER 2206N. The available keys vary depending on the model.

Canon-1

A/a/12

<A/a/12>Back

◄►

imageRUNNER 2206

Apply

<Apply>

Current Date/Time Settings

01/08 2014 10:00 AM

(0:00-12:59)

Apply

Numeric keys

Clear

Deleting characters

Delete with . Pressing and holding deletes all characters.

Entry mode: <A> Entry mode: <a> Entry mode: <12>

@ . - _ / 1

ABC abc 2

DEF def 3

GHI ghi 4

JKL jkl 5

MNO mno 6

PQRS pqrs 7

TUV tuv 8

WXYZ wxyz 9

(Not available) 0

(space) - . * # ! “ , ; : ^ ` _ = / | ‘ ? $ @ % & + \ ˜ ( )

[ ] { } < >

(Not available)

Turning ON/OFF the Power

Back <Apply>

◄►

Navigating the Menu

Item selection

Tap an item to select it. Press

to return to the previous

screen.

Setting con rmation

Tap the item. However, when <Apply> appears, tap <Apply>.

Text Input Method (imageRUNNER 2206N/2006N)

Changing entry mode

Tap <A/a/12> to change the entry mode. You can also press

to change the entry mode.

Entry mode Available text

<A> Uppercase alphabetic letters and symbols

<a> Lowercase alphabetic letters and symbols

<12> Numbers

Entering text, symbols, and numbers

Enter with the numeric keys or

Moving the cursor (Entering a space)

Tap <◄> or <►> to move the cursor. To enter a space, move the cursor to the end of the text, and tap <►>.

OFF

• Make sure that the power plug is  rmly inserted into the

power outlet.

• Do not connect the USB cable at this time. Connect it when installing software.

Page 5

Specifying the Initial Settings

Follow the instructions on the screen to perform the following:

• Set the language

• Set the country and region

• Set the time zone

• Set the date and time

• Register the Purchase Information

• Set the Remote UI Access PIN*

• Set the Wireless LAN Connecting*

* imageRUNNER 2206N/2006N only

For details on navigating the menu and how to input the numbers, see “Navigating the Menu and Text Input Method” ( P.4). Setting the Remote UI Access PIN is recommended when using Remote UI to prevent unauthorized access by a third party. The Remote UI uses a Web browser to operate the machine, check the status, and specify settings, enabling you to manage the machine while remaining at your desk. For information on using the Remote UI, see the User’s Guide.

Choosing the Method to Connect the Machine to the Computer

• Connecting via a LAN

(imageRUNNER 2206N/2006N)

You can connect the machine to the computer through a wired LAN router. Use a LAN cable to connect the machine to the router.

• Connecting via a Wireless LAN

(imageRUNNER 2206N/2006N)

You can connect the machine to the computer through a wireless router*. Since it is connected to wireless, no LAN cables are needed.

* A wireless router (access point), which supports IEEE802.11b/g/n,

is required.

Connect the computer to the router by cable or wirelessly.

If you do not sure whether your router is wireless or wired:

See the instruction manual provided with your network device, or contact the manufacturer.

• Direct Connection

Connect a mobile device to the machine wirelessly and directly without routing through a wireless LAN router (or access point).

User’s Guide “Connecting Directly (Access Point Mode)”

Connecting via a LAN (imageRUNNER 2206N/2006N)

Checking Before the Setup

Internet

Router

Connect the computer to the router by cable or wirelessly.

Make sure that there are ports available on the router to connect

the machine and the computer.

Have a Category 5 or higher twisted pair LAN cable ready.

• Connecting via a USB cable

You can connect the machine to the computer using a USB cable.

IMPORTANT

A USB cable is not included in this package. Please obtain a suitable cable for your computer. Make sure that the USB cable you use has the following mark.

LAN cable

Are the computer and the router properly connected using a LAN cable?

For more information, see the instruction manual for the network device you are using, or contact the networking device manufacturer.

Have the network settings on the computer been completed?

If the computer is not properly con gured, you may not use the wired LAN connection even after completing the following settings.

NOTE

• When you connect to a network environment that is not security protected, your personal information could be disclosed to third parties. Please use caution.

• If you connect through a LAN in the o ce, contact your network administrator.

Page 6

Setting Up the LAN Connection

Connect the LAN cable.

The IP address will be automatically con gured in 2 minutes. If you want to set the IP address manually, see the following items.

User’s Guide “Setting IP Addresses”

Install the drivers on your computer using the

provided CD-ROM/DVD-ROM.

See “Installing the software” (P.9).

NOTE

The scanner driver cannot be installed if the machine and your computer are connected in an IPv6 environment.

Proceed to “Setting a Paper Size and Type” (P.9).

Connecting via a USB Cable

Connect the USB cable after installing the drivers.

Install the drivers on your computer using the

provided CD-ROM/DVD-ROM.

See “Installing the software” (P.9).

Connect the USB cable.

Connecting via a Wireless LAN (imageRUNNER 2206N/2006N)

Checking Before the Setup

Wireless LAN Router

Internet

Is the computer connected to the router (access point) correctly by a LAN cable or wireless LAN?

For more information, see the instruction manual for the network device you are using, or contact the networking device manufacturer.

Have the network settings on the computer been completed?

If the computer is not properly con gured, you may not use the wireless LAN connection even after completing the following settings.

NOTE

• You cannot connect both the wired LAN and wireless LAN at the same time. In addition, the machine is set to the “Wired LAN” by default.

• When you connect to a network environment that is not security protected, your personal information could be disclosed to third parties. Please use caution.

• If you connect through a LAN in the o ce, contact your network administrator.

Switching the Connection Method to Wireless LAN

Tap <Menu> in the <Home> Screen.

Proceed to “Setting a Paper Size and Type” (P.9).

Tap <Network Settings>.

If a screen for entering a System Manager ID and PIN is displayed, enter the System Manager ID and PIN, tap <Apply>, and press .

Tap <Select Wired/Wireless LAN>.

Tap <Wireless LAN>.

Select LAN Wired LAN

Wireless LAN

Page 7

Checking the Router

Select the connection method to the wireless LAN. Select from the following two methods depending on the router (access point) that you are using.

There is a button.

This machine supports WPS (Wi-Fi Protected Setup). You can easily set up if your router (access point) has a button, and if the router.

If you are not sure whether or not your router supports WPS, please

see the manual included in the product, or contact the product manufacturer.

mark is on the

Setting Wireless LAN (imageRUNNER 2206N/2006N)

Push Button Mode

Tap <Menu> in the <Home> Screen.

Tap <Network Settings>.

If a screen for entering a System Manager ID and PIN is displayed, enter the System Manager ID and PIN, tap <Apply>, and press .

Tap <Wireless LAN Settings>.

Read the message that is displayed, and tap <OK>.

There is no button.

If there is no button on your router (access point), you may manually select SSID and complete the settings. In this case, you need to remember SSID and network key of your router (access point).

See “Checking That the Wireless LAN Setting is Completed (imageRUNNER 2206N/2006N)” (P.9) to learn how to  nd out your SSID and network key.

To set up with WPS PIN code method, or setup manually:

User’s Guide “Connecting to a Wireless LAN”

Tap <WPS Push Button Mode>.

Wireless LAN Settings SSID Settings WPS Push Button Mode WPS PIN Code Mode Power Save Mode Wireless LAN Information

Tap <Yes>.

Press and hold* the button until the lamp lights or

blinks.

You should press the WPS button within 2 minutes after you tap <Yes> in step 6.

* The time that you should hold the button may vary depending

on the router you are using.

Wait approximately 2 minutes after the connection.

IP address is set during this period of time.

When an error message appears:

Tap <Close> to close the screen, retry the settings. If the access point cannot be detected even after retrying, see the following.

User’s Guide “When an Error Message Appears”

When checking the network connection:

You can check if the machine is properly connected to the network using a computer that connected to a network.

User’s Guide “Viewing Network Settings”

To set IP address manually:

User’s Guide “Connecting to a Wireless LAN”

Page 8

Setting the Access Point Manually

Check SSID or Network Key for a Wireless LAN

Router/Access Point.

• Check the label on the Wireless LAN router.

Write down the name of SSID and network key

displayed in step 1. When multiple access points are displayed, write all SSIDs that are displayed.

Enter the network key that you have written

down.

Enter the network key using the numeric keys, and tap <Apply>.

WEP Key (5-26 Characters)

XXXXXXXX

ApplyA/a/12

SSID

It is sometimes written as name of network, or name of access point. If there are multiple SSIDs, please write down all.

Network Key

It is sometimes written as PIN, WEP key, WPA/WPA2 passphrase, PSK or preshared key.

Tap <Menu> in the <Home> Screen.

Tap <Network Settings>.

If a screen for entering a System Manager ID and PIN is displayed, enter the System Manager ID and PIN, tap <Apply>, and press .

Tap <Wireless LAN Settings>.

Read the message that is displayed, and tap <OK>.

Tap <Yes>.

After the <Connected.> screen is displayed, wait

until the Wi-Fi indicator stops blinking and turns on.

Wait approximately 2 minutes after the

connection.

IP address is set during this period of time.

When an error message appears:

Tap <Close> to close the screen, check whether or not the network key is correct, and then retry the settings.

If the access point cannot be detected even after retrying, see the following.

User’s Guide “When an Error Message Appears”

To set IP address manually:

User’s Guide “Connecting to a Wireless LAN”

Tap <SSID Settings>.

Tap <Select Access Point>.

SSID Settings

Select Access Point

Enter Manually

Select a wireless LAN router.

If multiple matched SSIDs are displayed, select the ID that is listed  rst (the one with the strongest signal).

Page 9

Checking That the Wireless LAN Setting is Completed (imageRUNNER 2206N/2006N)

Press .

Tap <Network Information>.

Tap <IPv4>.

Tap <IP Address>.

Take note of the IP address.

IP Address XXX.XXX.XXX.XXX

Tap <Close>.

Setting a Paper Size and Type

Follow the instructions on the screen to set the paper size and type.

Paper Settings Multi-Purpose Tray Drawer 1 Drawer 2 Select Frequently Used Pape...

Installing the software

• The procedure described here is only applicable when your computer runs on the Windows OS. For more details on the software installation procedure, see the driver’s manual.

• For the installation when your computer runs on the macOS, see the driver’s manual.

• Your machine may not come with the driver for the macOS, depending on the time of purchase. New drivers are uploaded to the Canon website, and you can download and use the latest one.

Press .

Start a web browser from a computer, enter

“http://<IP address of the machine>/” in the address  eld, and then press [Enter] on your keyboard.

Check that the screen of the Remote UI is displayed.

Connection is completed if the screen is displayed.

When the screen is not displayed correctly:

User’s Guide “Common Problems”

If the screen is not displayed properly, re-insert the CD-ROM/DVD-ROM or search for “D:\MInst.exe” on the Windows platform (This description assumes that “D:” is the CD-ROM/DVD-ROM drive name).

Page 10

Perform Useful Tasks

A variety of functions are available. An overview of some useful functions is provided below.

Copy

Enlarged/Reduced Copies

You can enlarge or reduce standard size documents to copy on standard size paper or specify the copy ratio in percentage.

2-Sided Copying**

You can copy 1-sided documents on both sides of paper.

Collating

You can sort copies into sets arranged in page order.

Reduced Layout

You can reduce multiple documents to copy them onto one sheet.

2 on 1 4 on 1

Copying ID Card

You can make a copy of a 2-sided card onto one side of paper.

Enlarged/Reduced Printing

2-Sided Printing**

Reduced Layout

You can reduce multiple documents to print them onto one sheet.

Network Settings*

This machine comes equipped with a network interface that you can construct a network environment easily. You can print a document, and use the network scan from all computers which are connected with the machine. The machine supports to increase work e ciency as a shared machine in the o ce.

Scan

Saving the Documents Using the Control Panel of the Machine

Documents

Data

Saving the Documents Using Operations from a Computer

• Scanning with the MF Scan Utility

• Scanning from an Application

• Scanning with the WIA Driver

Data

E-mailing Scanned Documents*

You can send scanned documents to your e-mail application.

Documents

2 on 1 4 on 1

Booklet Printing**

Poster Printing

Watermark Printing

Combining and Printing Multiple Documents

Selecting a “Pro le”

Documents Data E-mail

Sending Scanned Documents to a File Server*

You can send scanned documents to a  le server.

Documents Data File server

Remote UI*

You can understand the condition of the machine from the computers on the network. You can access the machine and manage jobs or specify various settings via network.

* imageRUNNER 2206N/2006N Only

** The optional Duplex Unit is required for imageRUNNER

2206N/2006N.

Page 11

Clearing Paper Jams

If the following screen appears, a paper jam has occurred in the feeder or inside the machine. Follow the procedure displayed on the screen to remove the jammed document or paper. This manual indicates only areas where paper jams occur. For details on the procedures, see the User’s Guide.

Output Area

Feeder (DADF-AY)* Paper Drawer 1

Paper jammed.

Press [Next] to display the steps.

Previous Next

Duplex Unit-C**

Multi-Purpose Tray Fixing assembly Cassette Feeding Module-AD***

* The optional Feeder is required for imageRUNNER 2206N/2006N.

** The optional Duplex Unit is required for imageRUNNER 2206N/2006N.

*** The optional Cassette Feeding Module is required for imageRUNNER 2206N/2006N.

Page 12

Replacing Toner Cartridge

Toner cartridges are consumables. When the toner becomes nearly empty or has run out completely in the middle of a job run, a message appears on the screen, or the following problems may occur. Take the appropriate action accordingly.

When a Message Appears

When the toner becomes nearly empty or has run out in the middle of a job run, a message appears on the screen.

Message

When the message is

displayed on the screen

The toner cartridge needs to be replaced soon.

The toner cartridge has reached the end of its lifetime.

Description and solutions

Make sure that you have a replacement toner cartridge ready. We recommend checking the level of remaining toner before printing high-volume documents.

User’s Guide “Replacing the Toner Cartridge”

Replace the toner cartridge.

User’s Guide ”Replacing the Toner Cartridge”

If Printouts are Poor in Quality

If your printouts begin to show any of the characteristics below, the toner cartridge is nearly empty. Replace the nearly empty toner cartridge even if no message is displayed.

White streaks appear Partially faded Density is uneven

Toner smudges and splatters

appear Printouts are grayish

Page 13

Memo

Page 14

Appendix

Important Safety Instructions

This chapter describes important safety instructions for the prevention of injury to users of this machine and others, and damage to property. Read this chapter before using the machine, and follow the instructions to use the machine properly. Do not perform any operations not described in this manual. Canon will not be responsible for any damages resulting from operations not described in this manual, improper use, or repair or changes not performed by Canon or a third party authorized by Canon. Improper operation or use of this machine could result in personal injury and/or damage requiring extensive repair that may not be covered under your Limited Warranty.

WARNING

Indicates a warning concerning operations that may lead to death or injury to persons if not performed correctly. To use the machine safely, always pay attention to these warnings.

CAUTION

Indicates a caution concerning operations that may lead to injury to persons if not performed correctly. To use the machine safely, always pay attention to these cautions.

IMPORTANT

Indicates operational requirements and restrictions. Be sure to read these items carefully to operate the machine correctly and avoid damage to the machine or property.

Installation

To use this machine safely and comfortably, carefully read the following precautions and install the machine in an appropriate location.

WARNING

Do not install in a location that may result in a fire or electrical shock

• A location where the ventilation slots are blocked (too close to walls, beds, sofas, rugs, or similar objects)

• A damp or dusty location

• A location exposed to direct sunlight or outdoors

• A location subject to high temperatures

• A location exposed to open flames

• Near alcohol, paint thinners or other flammable substances

Other warnings

• Do not connect unapproved cables to this machine. Doing so may result in a fire or electrical shock.

• Do not place necklaces and other metal objects or containers filled with liquid on the machine. If foreign substances come in contact with electrical parts inside the machine, it may result in a fire or electrical shock.

• If any foreign substance falls into this machine, unplug the power plug from the AC power outlet and contact your local authorized Canon dealer.

CAUTION

Do not install in the following locations

The machine may drop or fall, resulting in injury.

• An unstable location

• A location exposed to vibrations

IMPORTANT

Do not install in the following locations

Doing so may result in damage to the machine.

• A location subject to temperature and humidity extremes, whether low or high

• A location subject to dramatic changes in temperature or humidity

• A location near equipment that generates magnetic or electromagnetic waves

• A laboratory or location where chemical reactions occur

• A location exposed to corrosive or toxic gases

• A location that may warp from the weight of the machine or where the machine is liable to sink (a carpet, etc.)

Avoid poorly ventilated locations

This machine generates a slight amount of ozone and other emissions during normal use. These emissions are not harmful to health. However, they may be noticeable during extended use or long production runs in poorly ventilated rooms. To maintain a comfortable working environment, it is recommended that the room where the machine operates be appropriately ventilated. Also avoid locations where people would be exposed to emissions from the machine.

Do not install in a location where condensation occurs

Water droplets (condensation) may form inside the machine when the room where the machine is installed is heated rapidly, and when the machine is moved from a cool or dry location to a hot or humid location. Using the machine under these conditions may result in paper jams, poor print quality, or damage to the machine. Let the machine adjust to the ambient temperature and humidity for at least 2 hours before use.

Avoid installing the machine near computers or other precision electronic equipment.

Electrical interference and vibrations generated by the machine while printing can adversely affect the operation of such equipment.

Avoid installing the machine near televisions, radios, or similar electronic equipment.

The machine might interfere with sound and picture signal reception. Insert the power plug into a dedicated power outlet, and maintain as much space as possible between the machine and other electronic equipment.

In altitudes of above sea level 3,000 m or higher

Machines with a hard disk may not operate properly when used at high altitudes of about 3,000 meters above sea level, or higher.

When using wireless LAN

• Install the machine at a distance of 50 meters or less from the wireless LAN router.

• As far as possible, install in a location where communication is not blocked by intervening objects. The signal may be degraded when passing through walls or floors.

• Keep the machine as far as possible from digital cordless phones, microwave ovens, or other equipment that emits radio waves.

• Do not use near medical equipment. Radio waves emitted from this machine may interfere with medical equipment, which may result in malfunctions and accidents.

If the operating noise concerns you

Depending on the use environment and operating mode, if the operating noise is of concern, it is recommended that the machine be installed in a place other than the office.

Moving the Machine

If you intend to move the machine, even to a location on the same floor of your building, contact your local authorized Canon dealer beforehand. Do not attempt to move the machine yourself.

Power Supply

WARNING

• Use only a power supply that meets the specified voltage requirements. Failure to do so may result in a fire or electrical shock.

• The machine must be connected to a socket-outlet with grounding connection by the provided power cord.

• Do not use power cords other than the one provided, as this may result in a fire or electrical shock.

• The provided power cord is intended for use with this machine. Do not connect the power cord to other devices.

• Do not modify, pull, forcibly bend, or perform any other act that may damage the power cord. Do not place heavy objects on the power cord. Damaging the power cord may result in a fire or electrical shock.

• Do not plug in or unplug the power plug with wet hands, as this may result in an electrical shock.

• Do not use extension cords or multi-plug power strips with the machine. Doing so may result in a fire or electrical shock.

• Do not wrap the power cord or tie it in a knot, as this may result in a fire or electrical shock.

• Insert the power plug completely into the AC power outlet. Failure to do so may result in a fire or electrical shock.

• Remove the power plug completely from the AC power outlet during a thunder storm. Failure to do so may result in a fire, electrical shock, or damage to the machine.

• Make sure that the power supply for the machine is safe, and has a steady voltage.

• Keep the power cord away from a heat source; failure to do this may cause the power cord coating to melt, resulting in a fire or electrical shock.

Avoid the following situations:

If excessive stress is applied to the connection part of the power cord, it may damage the power cord or the wires inside the machine may disconnect. This could result in a fire.

–Connecting and disconnecting the power

cord frequently.

–Tripping over the power cord. –The power cord is bent near the connection

part, and continuous stress is being applied to the power outlet or the connection part.

–Applying excessive force on the power plug.

CAUTION

• Install this machine near the power outlet and leave sufficient space around the power plug so that it can be unplugged easily in an emergency.

IMPORTANT

When connecting power

• Do not connect the power cord to an uninterruptible power source. Doing so may result in malfunction of or damage to the machine at power failure.

Page 15

• If you plug this machine into an AC power outlet with multiple sockets, do not use the remaining sockets to connect other devices.

• Do not connect the power cord to the auxiliary AC power outlet on a computer.

Other precautions

• Electrical noise may cause this machine to malfunction or lose data.

Handling

WARNING

• Immediately unplug the power plug from the AC power outlet and contact an authorized Canon dealer if the machine makes an unusual noise, emits an unusual smell, or emits smoke or excessive heat. Continued use may result in a fire or electrical shock.

• Do not disassemble or modify this machine. There are high-voltage and high-temperature components inside the machine. Disassembly or modification may result in a fire or electrical shock.

• Place the machine where children will not come in contact with the power cord and other cables or gears and electrical parts inside the machine. Failure to do so may result in unexpected accidents.

• Do not use flammable sprays near this machine. If flammable substances come into contact with electrical parts inside this machine, it may result in a fire or electrical shock.

• When moving this machine, be sure to turn OFF the power of this machine, and then unplug the power plug and interface cables. Failure to do so may damage the power cord or interface cables, resulting in a fire or electrical shock.

• When plugging or unplugging a USB cable when the power plug is plugged into an AC power outlet, do not touch the metal part of the connector, as this may result in an electrical shock.

If you are using a cardiac pacemaker

This machine generates a low level magnetic flux and ultrasonic waves. If you use a cardiac pacemaker and feel abnormalities, please move away from this machine and consult your physician immediately.

CAUTION

• Do not place heavy objects on this machine as they may fall, resulting in injury.

• For safety, unplug the power plug if the machine will not be used for a long period of time.

• Use caution when opening and closing covers to avoid injury to your hands.

• Keep hands and clothing away from the rollers in the output area. If the rollers catch your hands or clothing, this may result in personal injury.

• The inside of the machine and the output slot are very hot during and immediately after use. Avoid contact with these areas to prevent burns. Also, printed paper may be hot immediately after being output, so use caution when handling it. Failure to do so may result in burns.

Feeder or platen glass cover

• Do not press down hard on the feeder or the platen glass cover when using the platen glass to make copies of thick books. Doing so may damage the platen glass and result in personal injury.

• Close the feeder or the platen glass cover gently to avoid catching your hands, as this may result in personal injury.

• Be careful not to put your hands or fingers into the feeder or the platen glass cover. Otherwise, you may be injured.

Paper drawer

• Do not insert your hand into the machine while the paper drawer is removed, as this may result in personal injury.

Energy Saver key

Laser Safety

This product is confirmed as a Class 1 laser product in IEC60825-1:2014 and EN60825-1:2014. CLASS 1 LASER PRODUCT LASER KLASSE 1 APPAREIL À LASER DE CLASSE 1 APPARECCHIO LASER DI CLASSE 1 PRODUCTO LÁSER DE CLASE 1 APARELHO A LASER DE CLASSE 1 LUOKAN 1 LASER-TUOTE LASERPRODUKT KLASS 1 The laser beam can be harmful to human bodies. Since radiation emitted inside the product is completely confined within protective housings and external covers, the laser beam cannot escape from the machine during any phase of user operation. Read the following remarks and instructions for safety.

Laser Safety Caution

(Energy Saver) for safety when the

• Press machine will not be used for a long period of time, such as overnight. Also, turn OFF the main power switch, and disconnect the power cord for safety when the machine will not be used for an extended period of time, such as during consecutive holidays.

• Never open covers other than those instructed in the manuals for this machine.

• If the laser beam should escape and enter your eyes, exposure may cause damage to your eyes.

• Use of controls, adjustments, or performance of procedures other than those specified in this manual may result in hazardous radiation exposure.

Fixing Unit

When removing jammed paper or when inspecting the inside of the machine, do not expose yourself to the heat emitted from the fixing unit and its surroundings for a prolonged period of time. Doing so may result in low temperature burns, even though you did not touch the fixing unit and its surroundings directly.

IMPORTANT

• Follow the instructions on the caution label attached to this machine.

• Do not subject the machine to strong shocks or vibration.

• Do not forcibly open and close doors, covers, and other parts. Doing so may result in damage to the machine.

• Do not turn the main power switch OFF or open the covers while the machine is in operation. This may result in paper jams.

• Use a modular cable that is shorter than 3 meters.

• Use a USB cable that is shorter than 3 meters.

Safety-Related Symbols

Power switch: “ON” position

Power switch: “OFF” position

Power switch: “STAND-BY” position

Push-push switch “ON” “OFF”

Protective earthing terminal

Dangerous voltage inside. Do not open covers other than instructed.

CAUTION: Hot surface. Do not touch.

Class II equipment

Moving parts: Keep body parts away from moving parts

CAUTION: An electrical shock may occur. Remove all the power plugs from the power outlet.

There are sharp edges. Keep body parts away from sharp edges.

[NOTE]

Some of symbols shown above may not be affixed depending on the product.

Page 16

Appendix

Maintenance and Inspections

Clean this machine periodically. If dust accumulates, the machine may not operate properly. When cleaning, be sure to observe the following. If a problem occurs during operation, see “Troubleshooting” in the User’s Guide. If the problem cannot be resolved or you feel the machine requires an inspection, see “When a Problem Cannot Be Solved” in the User’s Guide.

WARNING

• Before cleaning, turn OFF the power and unplug the power plug from the AC power outlet. Failure to do so may result in a fire or electrical shock.

• Unplug the power plug periodically and clean with a dry cloth to remove dust and grime. Accumulated dust may absorb humidity in the air and may result in a fire if it comes into contact with electricity.

• Use a damp, well wrung-out cloth to clean the machine. Dampen cleaning cloths with water only. Do not use alcohol, benzine, paint thinner, or other flammable substances. Do not use tissue paper or paper towels. If these substances come into contact with electrical parts inside the machine, they may generate static electricity or result in a fire or electrical shock.

• Check the power cord and plug periodically for damage. Check the machine for rust, dents, scratches, cracks, or excessive heat generation. Use of poorly-maintained equipment may result in a fire or electrical shock.

CAUTION

• The inside of the machine has hightemperature and high-voltage components. Touching these components may result in burns. Do not touch any part of the machine that is not indicated in the manual.

• When loading paper or removing jammed paper, be careful not to cut your hands with the edges of the paper.

Consumables

WARNING

• Do not throw toner cartridges into open flame, or do not store them or printing/copy paper in a place exposed to open flame. This may cause them to ignite, resulting in burns or fire.

• If you accidentally spill or scatter toner, carefully gather the toner particles together or wipe them up with a soft, damp cloth in a way that prevents inhalation. Never use a vacuum cleaner that does not have safeguards against dust explosions to clean up spilled toner. Doing so may cause a malfunction in the vacuum cleaner, or result in a dust explosion due to static discharge.

CAUTION

• Keep toner and other consumables out of the reach of small children. If these items are ingested, consult a physician immediately.

• If toner touches your clothes or skin, wash it away with water immediately. Do not use warm water, as this may cause toner to fix, resulting in a permanent stain.

• Do not dismantle the toner cartridge, as doing so may cause toner to fly out and enter your eyes or mouth. If toner gets into your eyes or mouth, wash them immediately with cold water and immediately consult a physician.

• If toner escapes from the toner cartridge, make sure not to ingest the toner or allow it to directly touch your skin. If your skin still feels irritated after washing it, or you ingest toner, consult a physician immediately.

IMPORTANT

• Store toner cartridges in a cool location, away from direct sunlight.

Notice

Product Name

Safety regulations require the product’s name to be registered. In some regions where this product is sold, the following name(s) in parentheses ( ) may be registered instead.

imageRUNNER 2206N/2006N (F193302) imageRUNNER 2206 (F193200)

EMC requirements of EC Directive

This equipment conforms with the essential EMC requirements of EC Directive. We declare that this product conforms with the EMC requirements of EC Directive at nominal mains input 230 V, 50 Hz although the rated input of the product is 220 to 240 V, 50/60 Hz. Use of shielded cable is necessary to comply with the technical EMC requirements of EC Directive.

India E-Waste Rule

You can see the information about proper handling equipment after use in the latest User’s Guide (HTML manual) from the Canon website (canon.com/oip-manual).

Wireless LAN Regulatory Information

imageRUNNER 2206N/2006N includes approved Wireless LAN Module (Model name: Type1KA).

Regulatory information for users in Singapore

Complies with

IMDA Standards

DB00671

Legal Limitations on the Usage of Your Product and the Use of Images

Using your product to scan, print or otherwise reproduce certain documents, and the use of such images as scanned, printed or otherwise reproduced by your product, may be prohibited by law and may result in criminal and/or civil liability. A non-exhaustive list of these documents is set forth below. This list is intended to be a guide only. If you are uncertain about the legality of using your product to scan, print or otherwise reproduce any particular document, and/or of the use of the images scanned, printed or otherwise reproduced, you should consult in advance with your legal advisor for guidance.

• Paper Money

• Travelers Checks

• Money Orders

• Food Stamps

• Certificates of Deposit

• Passports

• Postage Stamps (canceled or uncanceled)

• Immigration Papers

• Identifying Badges or Insignias

• Internal Revenue Stamps (canceled or uncanceled)

• Selective Service or Draft Papers

• Bonds or Other Certificates of Indebtedness

• Checks or Drafts Issued by Governmental Agencies

• Stock Certificates

• Motor Vehicle Licenses and Certificates of Title

• Copyrighted Works/Works of Art without Permission of Copyright Owner

Disclaimers

• The information in this document is subject to change without notice.

• CANON INC. MAKES NO WARRANTY OF ANY KIND WITH REGARD TO THIS MATERIAL, EITHER EXPRESS OR IMPLIED, EXCEPT AS PROVIDED HEREIN, INCLUDING WITHOUT LIMITATION, THEREOF, WARRANTIES AS TO MARKETABILITY, MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE OF USE, OR NONINFRINGEMENT. CANON INC. SHALL NOT BE LIABLE FOR ANY DIRECT, INCIDENTAL, OR CONSEQUENTIAL DAMAGES OF ANY NATURE, OR LOSSES OR EXPENSES RESULTING FROM THE USE OF THIS MATERIAL.

About This Manual

Keys and Buttons Used in This Manual

The following symbols and key names are a few examples of how keys to be pressed are expressed in this manual.

• Operation panel keys: [Key icon] Example:

• Display: <Specify destination.>

• Buttons and items on the computer display: [Preferences]

Illustrations

Illustrations used in this manual are those displayed when the imageRUNNER 2206N has the following optional equipment attached to it:

• Cassette Feeding Module-AD

• Feeder (DADF-AY)

Trademarks

Mac is a trademark of Apple Inc. Microsoft, Windows, Windows Vista, Windows Server, Internet Explorer, Excel, and PowerPoint are either registered trademarks or trademarks of Microsoft Corporation in the United States and/ or other countries. Other product and company names herein may be the trademarks of their respective owners.

Third Party Software

This Canon product (the “PRODUCT”) includes third-party software modules. Use and distribution of these software modules, including any updates of such software modules (collectively, the “SOFTWARE”) are subject to license conditions (1) through (9) below. (1) You agree that you will comply with any

applicable export control laws, restrictions or regulations of the countries involved in the event that this PRODUCT including the SOFTWARE is shipped, transferred or exported into any country.

(2) Rights holders of the SOFTWARE retain in all

respects the title, ownership and intellectual property rights in and to the SOFTWARE. Except as expressly provided herein, no license or right, expressed or implied, is hereby conveyed or granted by rights holders of the SOFTWARE to you for any intellectual property of rights holders of the SOFTWARE.

(3) You may use the SOFTWARE solely for use

with the PRODUCT.

(4) You may not assign, sublicense, market,

distribute, or transfer the SOFTWARE to any third party without prior written consent of rights holders of the SOFTWARE.

Page 17

(5) Notwithstanding the foregoing, you may

transfer the SOFTWARE only when (a) you assign all of your rights to the PRODUCT and all rights and obligations under the license conditions to transferee and (b) such transferee agrees to be bound by all these conditions.

(6) You may not decompile, reverse engineer,

disassemble or otherwise reduce the code of the SOFTWARE to human readable form.

(7) You may not modify, adapt, translate, rent,

lease or loan the SOFTWARE or create derivative works based on the SOFTWARE.

(8) You are not entitled to remove or make

separate copies of the SOFTWARE from the PRODUCT.

(9) The human-readable portion (the source

code) of the SOFTWARE is not licensed to you.

Notwithstanding (1) through (9) above, the PRODUCT includes third-party software modules accompanying the other license conditions, and these software modules are subject to the other license conditions. Please refer to the other license conditions of third-party software modules described in Appendix of Manual for the corresponding the PRODUCT. This Manual is available at http://canon. com/oip-manual.

By using the PRODUCT, you shall be deemed to have agreed to all applicable license conditions. If you do not agree to these license conditions, please contact your service representative.

V_180517

Page 18

Memo

Page 19

Memo

Page 20

CANON INC.

30-2, Shimomaruko 3-chome, Ohta-ku, Tokyo 146-8501, Japan

CANON U.S.A., INC.

One Canon Park, Melville, NY 11747, U.S.A.

CANON CANADA INC.

8000 Mississauga Road Brampton ON L6Y 5Z7, Canada

CANON EUROPA N.V.

Bovenkerkerweg 59, 1185 XB Amstelveen, The Netherlands (See http://www.canon-europe.com/ for details on your regional dealer)

CANON AUSTRALIA PTY LTD

Building A, The Park Estate, 5 Talavera Road, Macquarie Park, NSW 2113, Australia

CANON CHINA CO. LTD.

2F Jinbao Building No.89, Jinbao Street, Dongcheng District, Beijing 100005, China

CANON SINGAPORE PTE LTD

1 Fusionopolis Place, #15-10, Galaxis, Singapore 138522
