Canon 518 SV User Manual
к
.. H
•s3//i - 9? ^
Canon H]
m z oo M ii i ii
INSTRUCTIONS
English Edition
Power Zoom Button for Telephoto Power Zoom Button for Wide-Angle
Film Type Window
\
, Film Plane Indicator
/ / Slit for Lighting Unit and Filter Cancellation Key
Power Level Indicator
--- Zooming Ring
-----
Focusing Ring
Lens
Cable Release Socket
Wrist Strap
/ Battery Checker
Trigger Grip
Filming Speed Dial,
Manual Zoom Knob
Aperture Control Ring"
Shutter Lock Dial
Trigge
Release Socket for Single Frame
/" /
Battery Chamber Cover Tripod Socket
/ /
■ Footage Counter
Eyepiece Adjustment Ring
• Viewfinder
Rear Cover Lock Button
__ Film Transport
Indicator
- Rear Cover
'Remote Control
Switch Socket
After you have loaded the batteries and adjusted
the eyepiece, follow these simple steps:
1
Insert a Super 8 film cartridge.
Turn the shutter lock dial to "R”.
Set the aperture control ring at "A".
2
Set the filming speed dial at "18".
3
Look through the viewfinder and focus in telephoto.
[uia_4 sirs u 163Z1
page
Manual Aperture Control
Fadings..........................................................................................14
Filters............................................................................................. 15
Close-Up Lenses ..........................................................................15
Converters ....................................................................................16
Shooting with Artificial Light
Unloading of Film Cartridge .......................................................17
Proper Care of the Camera..........................................................18
............................................................
......................................................
14
17
Pull the trigger slightly and check whether the exposure indr
cater is within the proper range.
' Decide the composition of the picture by turning the zoom lens.
Pull the trigger.
Zoom in and zoom out according to your needs.
5
Your Camera Body Number
Date of Purchase
Dealer's Name _________________
ишогомп
Main Features of Your Super 8 Camera
jj Uses Super 8 film cartridge—50% larger picture area.
2 Simple cartridge loading with automatic film speed setting.
Sharp and fast FI.8 S times zoom lens with zooming range of
3
9.5-47.5mm. Extendible to 6.2-31 mm with Wide-Converter or
15.6-78mm with Tele-Converter.
k Automatic through-the-iens exposure control using CdS photo-
*■ cell with servo EE meter.
Single-lens reflex viewing and microprism screen rangefinder for
5
accurate focusing.
0 Powered film drive and zooming.
1 Manually operable aperture for fade-ins and fade-outs.
0 18 fps normal filming speed, 24 fps, and “SLOW MOTION”.
0 Easy-to-hold trigger grip.
