U
Universal Chassis System
UCS 1000
ser Manual
EdgeAccess Universal Chassis System
CAUTION!
This product may contain a laser diode operating at a wavelength of 1300nm - 1600nm. Use of
optical instruments (e.g., collimating optics) with this product may increase eye hazard. Use of
controls or adjustments, or performing procedures other than those specified herein may result in
hazardous radiation exposure.
Under normal conditions, the radiation levels emitted by this product are under Class 1 limits in 21
CFR Chapter 1, Subchapter J.
ATTENCION!
Cet équipement peut avoir une diode laser émettant à des longueurs d'onde allant de 1300nm à
1600nm. L'utilisation d'instruments optiques (par exemple : un collimateur optique) avec cet
équipement peut s'avèrer dangereuse pour les yeux. Procéder à des contrôles, des ajustements ou toute
procédure autre que celles décrites ci-après peut provoquer une exposition dangereuse à des
radiations.
Sous des conditions normales, le niveau des radiations émises par cet équipement est en dessous des
limites prescrites dans CFR21, chapitre 1, sous chapitre J.
NOTICE!
This device contains static sensitive components. It should be handled only with proper ElectroStatic
Discharge (ESD) grounding procedures.
NOTE!
Cet équipement contient des composants sensibles aux décharges électro-statiques. Il doit absolument
être manipulé en respectant les règles de mise à la terre afin de prévenir de telles décharges.
UCS 1000
i
EdgeAccess Universal Chassis System
NOTICE
Canoga Perkins has prepared this users manual for use by customers and Canoga Perkins personnel as
a guide for the proper installation, operation and/or maintenance of Canoga Perkins equipment. The
drawings, specifications and information contained in this document are the property of Canoga
Perkins and any unauthorized use or disclosure of such drawings, specifications and information is
prohibited.
Canoga Perkins reserves the right to change or update the contents of this manual and to change the
specifications of its products at any time without prior notification. Every effort has been made to
keep the information in this document current and accurate as of the date of publication or revision.
However, no guarantee is given or implied that the document is error free or that is accurate with
regard to any specification.
Canoga Perkins Corporation
20600 Prairie Street
Chatsworth, California 91311-6008
Business Phone: (818) 718-6300
(Monday - Friday 7 a.m. - 5 p.m. Pacific Time)
FAX: (818) 718-6312 (24hrs.)
Web Site: www.canoga.com
Email: fiber@canoga.com
Copyright© 2000 - 2005 Canoga Perkins Corporation
All Rights Reserved
EdgeAccess
Universal Chassis System
Model UCS 1000
User Manual
Product Number 6912200
Rev. F 09/2005
To reference Technical Advisories and Product Release Notes, go to Canoga Perkins'
website: http://www.canoga.com
®
ii
UCS 1000
EdgeAccess Universal Chassis System
Table of Contents
Chapter 1 Introduction ........................................................................................... 1-1
Chapter 2 Installing and Setting Up the Chassis.................................................. 2-1
Chapter 3 Specifications ......................................................................................... 3-1
Physical Specifications....................................................................................................................... 3-1
Regulatory Compliance ...................................................................................................................... 3-2
Appendix A Limited Warranty............................................................................. A-1
List of Figures
Figure 1. Populated UCS 1000 .......................................................................................................... 1-1
Figure 2. Chassis and Signal Ground Options................................................................................... 2-1
Figure 3. Mounting Bracket on Chassis............................................................................................. 2-2
Figure 4. Chassis Backplane and SW1, ID Switch............................................................................ 2-3
Figure 4. DC Power Supply Detail.................................................................................................... 2-4
List of Tables
Table 1. Power Supply(s) and Maximum Number of Modules......................................................... 1-2
Table 2. SW1, Chassis ID Switch...................................................................................................... 2-3
Table 3. Power Supply LEDs ............................................................................................................ 2-5
UCS 1000
iii
EdgeAccess Universal Chassis System
iv
UCS 1000
