Canoga Perkins
2262 T1/E1
Fiber Optic Modem
User Manual
Canoga Perkins 2262 T1/E1 Fiber Optic Modem
NOTICE
Canoga Perkins reserves the right to change or update the contents of this manual
and to change the specifications of its products at any time without prior notification.
Every effort has been made to keep the information in this document current and
accurate as of the date of publication or revision. However, no guarantee is given or
implied that the document is error free or that it is accurate with regard to any specification.
Canoga Perkins has prepared this manual for use by customers and Canoga Perkins
personnel as a guide for the proper installation, operation and/or maintenance of
Canoga Perkins equipment. The drawings, specifications and information contained
in this document are the property of Canoga Perkins and any unauthorized use or
disclosure of such drawings, specifications and information is prohibited.
Canoga Perkins Corporation
20600 Prairie Street
Chatsworth, CA 91311-6008
(818) 718-6300
FAX: (818) 718-6312
Web Site: http://www.canoga.com
email: fiber@canoga.com
Copyright 1996 - 2005 Canoga Perkins
All Rights Reserved
2262 T1/E1 Fiber Optic Modem
User Manual
Part Number 6911360
Rev. H 09/2005
To reference Technical Advisories and Product Release Notes, go to Canoga
Perkins’ website: http://www.canoga.com/cservice.htm
2
2262 T1/E1 Fiber Optic Modem Canoga Perkins
2262 T1/E1 Fiber Optic Modem
3
Canoga Perkins 2262 T1/E1 Fiber Optic Modem
Caution!
This product may contain a laser diode emitter operating at a wavelength of 1300nm 1600nm. Use of optical instruments (for example: collimating optics) with this product
may increase eye hazard. Use of controls or adjustments or performing procedures
other than those specified herein may result in hazardous radiation exposure.
Under normal conditions, the radiation levels emitted by this product are under the
Class 1 limits in 21 CFR Chapter 1, Subchapter J.
ATTENTION!
Cet équipement peut avoir une diode laser émettant à des longueurs d'onde allant de
1300nm à 1600nm. L'utilisation d’instruments optiques (par exemple : un collimateur
optique) avec cet équipement peut s'avèrer dangereuse pour les yeux. Procéder à des
contrôles, des ajustements ou toute procédure autre que celles décrites ci-après peut
provoquer une exposition dangereuse à des radiations.
Sous des conditions normales, le niveau des radiations émises par cet équipement est
en dessous des limites prescrites dans CFR21, chapitre 1, sous chapitre J.
Notice!
This device contains static sensitive components. It should be handled only with
proper Electrostatic Discharge (ESD) grounding procedures.
NOTE!
Cet équipement contient des composants sensibles aux décharges électro-statiques. Il
doit absolument être manipulé en respectant les règles de mise à la terre afin de
prévenir de telles décharges.
4
2262 T1/E1 Fiber Optic Modem Canoga Perkins
Table of Contents
1. Description ...........................................................................7
1.1 2262 Modem ......................................................................... 7
1.2 Applications ........................................................................... 8
2. Installation ...........................................................................9
2.1 Unpacking the Unit ............................................................... 9
2.2 General Installation .............................................................. 9
2.2.1 Manufacturing Settings ......................................................... 9
2.2.2 Fiber Cable ............................................................................ 9
2.2.3 Loss Budget ........................................................................ 10
2.3 Stand Alone Installation ...................................................... 10
2.3.1 AC/DC Power .................................................................... 12
2.3.2 Interface Connectors .......................................................... 13
2.3.3 Alarm Relay Connectors .................................................... 14
2.3.4 E1 Impedance Switch ......................................................... 14
2.3.5 Loopback Switch ................................................................ 14
2.4 Rack Mount Installation .................................................... 14
3. Operation ............................................................................15
3.1 Local Loopback Operation ................................................ 15
3.2 Remote Loopback Operation ............................................ 15
4. Troubleshooting .................................................................17
4.1 Test Accessories ................................................................. 17
4.2 Diagnostic Procedures ........................................................ 17
4.2.1 Power Supply Diagnostic Procedure .................................. 17
4.2.2 Link Diagnostic Procedure ................................................. 18
4.2.3 Loopback Diagnostic Procedure ........................................ 19
5. Technical Specifications ....................................................21
5.1 Physical and Environmental ............................................... 21
5.2 Optical ................................................................................. 22
5.3 T1/E1 Interface ................................................................... 22
5.4 Agency Certification ........................................................... 23
5.5 Connector Pinout ............................................................... 23
5
Canoga Perkins 2262 T1/E1 Fiber Optic Modem
6. 2262 Glossary ....................................................................24
Appendix A - Limited Warranty ............................................26
List of Figures
1-1 Typical 2262 Modem Application with PBX Interconnections . 8
1-2 Typical 2262 Modem Application with T1/E1 and CSU
Interconnections ................................................................... 8
2-1 Rear Panel T1 Configurations ............................................... 11
2-2 Rear Panel E1 Configurations ............................................... 12
2-3 DC Power Connectors ......................................................... 12
2-4 2262 Interface Connectors ................................................... 13
2-5 2201 Rack Chassis .............................................................. 14
3-1 2262 Front Panel ................................................................. 15
3-2 2262 Block Diagram ............................................................ 16
List of Tables
2-A 2262 Loss Budgets .............................................................. 11
6
2262 T1/E1 Fiber Optic Modem Canoga Perkins
1. Description
1.1 2262 Modem
The 2262 T1/E1 Fiber Optic Modem features standard data speeds of 1.544Mbps
(T1) or 2.048Mbps (E1).
Available as a stand alone or rack-mount unit, the 2262 has local and remote
loopback capability for system diagnostic test. A set of alarm relay connectors
(Normally Closed and Normally Open) is provided to indicate optical link and power
status. Input power can be 115 or 230VAC (+/−10%), or an optional -48VDC.
Connectors can be either:
• T1 DA-15/RJ-48C or Terminal Block/RJ-48C
• E1 Terminal Block and BNC
The 2262 has extended distance options. Transmission distances to 40km or more
are realistic when using single mode optics. The 2262 is typically offered for
multimode fiber optic applications at 850nm, but also has the option of 1310nm
single mode.
The 2262 is transparent to the incoming bipolar signal and is fully compatible with
allowed speed variations. It allows the passing of bipolar violations for B8ZS
coding for T1 or w for E1.
7
Canoga Perkins 2262 T1/E1 Fiber Optic Modem
1.2 Applications
Applications for the 2262 are numerous and varied. For example, it can be used for
earth station down links, fiber front ends for T1/E1 multiplexers, PBX interconnects
or linking CAD/CAM displays to controllers (see Figures 1-1 and 1-2).
Figure 1-1.
Typical 2262 Modem
Application with PBX
Interconnections
Figure 1-2.
Typical 2262 Modem
Application with
T1/E1 and CSU
Interconnections
8
2262 T1/E1 Fiber Optic Modem Canoga Perkins
2. Installation
2.1 Unpacking the Unit
Each 2262 modem is factory tested and shipped in protective cartons. After
unpacking the unit and accessories, retain the shipping carton and protective
packing for reuse in the event a need arises for returning it to the factory.
To assure proper operation of the modem, please inspect it and its shipping carton
carefully for damage. If damage is sustained to the unit, file a liability claim immediately with the freight carrier. Canoga Perkins is not liable for damage caused during
shipment.
2.2 General Installation
2.2.1 Manufacturing Settings
The 2262 has the following settings from the factory:
• Switchable AC Power Setting: 230VAC
• Input DC Power Option: -48VDC
• Impedance Option (E1 only): 75Ω (Up position for Rack Mount Card)
• Loopback Switch: OFF
2.2.2 Fiber Cable
The proposed fiber optic cable must provide adequate bandwidth and optical loss
characteristics for the intended modem link. The 2262 is compatible with 8-10/125
single mode and 62.5/125 multimode cables.
The connectors are clearly marked, either transmit (Tx) or receive (Rx), on the back
panel of stand alone units and on the rear of the 2201 Rack Chassis.
For multimode applications, the 2262 is available with ST* connectors. For single
mode applications, the 2262 is available with FC or ST* connectors.
Warning: Do not over tighten FC/PC fiber connections - damage may
occur. Hand tighten only!
*ST is a Trademark of AT&T.
9
