Candy GOV 570C User Manual
INSTRUCTION BOOK
Vented Tumble Dryer
GOV 570C
English
Español
2
13
INDEX
Introduction
Delivery Information
Unpacking the Product
Safety Reminders
Use
Installation
The Laundry
Environmental Issues
Gias Service
Installation
Electrical Requirements
Adjusting the Feet
Ventilation
Installation of the Discharge Hose
Preparing the Load
Clothes Preparation
Sorting the Load
Do Not Tumble Dry
Energy Saving
Controls and Indicators
Selecting the Programme
Door and Filter
Opening the Door
Filter
Filter Care Indicator
Operation
Delay Start Function
Cancelling and Resetting the Programme
Cleaning and Routine Maintenance
Cleaning the Dryer
Technical Specifications
Troubleshooting
Customer Service
Spares
Gias Service
3
3
3
3
3
4
4
4
4
5
5
5
5
6
6
6
7
7
7
8
9
10
10
10
10
10
11
11
11
11
11
12
12
12
12
EN 2
INTRODUCTION
Please read and follow these instructions carefully and operate the machine accordingly. This
booklet provides important guidelines for safe use, installation, maintenance and some useful
advice for best results when using your machine.
Keep all documentation in a safe place for future reference or for any future owners.
Delivery Information
Please check that the following items are
delivered with the appliance:
● Instruction manual
● Guarantee card
● Vent kit and instructions
● Energy label
UNPACKING THE PRODUCT
Remove the machine from
its packaging close to the
f ina l l oca t i on o f t h e
machine.
1- Cut carefully around the
base of the packaging and
up one corner.
Check that no damage has occurred to the
machine during transit. If it has, call for service
by GIAS.
Failure to comply with the above can
compromise the safety of the appliance. You
may be charged for a service call if a problem
with your machine is caused by misuse.
Dispose of the packaging safely. Make
sure it is out of the reach of children,it is a
potential source of danger.
2- Remove the polythene
sleeve and lift the dryer off
the polystyrene base.
SAFETY REMINDERS
Use
● This appliance is not intended for use by persons (including children) with reduced physical,
sensory or mental capabilities,or lack of experience and knowledge, unless they have been given
supervision or instruction concerning use of the appliance by a person responsible for their safety.
● Children should be supervised to ensure that they do not play with the appliance.
● WARNING Misuse of a tumble dryer may create a fire hazard.
●This machine is solely for domestic use, i.e. to dry household textiles and garments.
●This machine should only be used for its intended purpose as described in this manual. Ensure
that the instructions for installation and use are fully understood before operating the appliance.
● Do not touch the appliance when hands or feet are damp or wet.
● Do not lean on the door when loading the machine or use the door to lift or move the machine.
●Do not allow children to play with the machine or its controls.
● WARNING Do not use the product if the fluff filter is not in position or is damaged; fluff could be
ignited.
● WARNING Where the hot surface symbol is located the temperature rise during operation
of the tumble dryer may be in excess of 60 degrees C.
● Remove the plug from the electricity supply. Always remove the plug before cleaning the
appliance.
● Do not continue to use this machine if it appears to be faulty.
● Lint and fluff must not be allowed to collect on the floor around the outside of the machine.
● The drum inside may be very hot. Always allow the dryer to complete the cool down period before
removing the laundry.
EN 3
SAFETY REMINDERS
Installation
● Check that the product has no visible signs of
damage before use. If damaged do not use and
please call GIAS Service.
● Do not use adapters, multiple connectors
and/or extensions.
● Never install the dryer against curtains and be
sure to prevent items from falling or collecting
behind the dryer.
● The appliance must not be installed behind a
lockable door, a sliding door or a door with a
hinge on the opposite side to that of the tumble
dryer.
The Laundry
●Do not dry unwashed items in the tumble dryer.
● WARNING Do not tumble dry fabrics treated
with dry cleaning fluids.
●WARNING Foam rubber materials can, under
certain circumstances, when heated become
ignited by spontaneous combustion. Items
such as foam rubber (latex foam), shower caps,
waterproof textiles, rubber backed articles and
clothes or pillows fitted with foam rubber pads
MUST NOT be dried in the tumble dryer.
● Always refer to the laundry care labels for
directions on suitability for drying.
● Clothes should be spin dried or thoroughly
wrung before they are put into the tumble dryer.
Clothes that are dripping wet should not be put
into the dryer.
● Lighters and matches must not be left in
pockets and NEVER use flammable liquids
near the machine.
● Glass fibre curtains should NEVER be put in
this machine. Skin irritation may occur if other
garments are contaminated with the glass
fibres.
● Items that have been soiled with substances
such as cooking oil, acetone, alcohol, petrol,
kerosene, spot removers, turpentine, waxes
and wax removers should be washed in hot
water with an extra amount of detergent before
being dried in the tumble dryer.
● Fabric softeners, or similar products, should
be used as specified by the fabric softener
instructions.
Environmental Issues
● A l l pac k a g ing m a t e rials u sed a r e
environmentally-friendly and recyclable.
Please help dispose of the packaging via
environmentally-friendly means. Your local
council will be able to give you details of current
means of disposal.
● To ensure safety when disposing of an old
tumble dryer disconnect the mains plug from
the socket, cut the mains power cable and
destroy this together with the plug. To prevent
children shutting themselves in the machine
break the door hinges or the door lock.
European Directive 2002/96/EC
This appliance is marked according
t o t h e E ur op e a n d i r e c tiv e
2002/96/EC on Waste Electrical and
Electronic Equipment (WEEE).
By ensuring this product is disposed of correctly,
you will help prevent potential negative
consequences for the environment and human
health, which could otherwise be caused by
inappropriate waste handling of this product.
The symbol on the product indicates that this
product may not be treated as household waste.
Instead it shall be handed over to the applicable
collection point for the recycling of electrical and
electronic equipment.
For more detailed information about treatment,
recovery and recycling of this product, please
contact your local city office,your household
waste disposal service or the shop where you
purchased the product. Disposal must be
car r ied out in accor d ance with loca l
environmental regulations for waste disposal.
GIAS Service
● To ensure the continued safe and efficient
operation of this appliance we recommend that
any servicing or repairs are only carried out by
an authorised GIAS service engineer.
If the appliance is not running properly or
breaks down, switch it off and disconnect the
plug from the socket. Consult GIAS Service for
possible repair.
EN 4
INSTALLATION
Electrical Requirements
Tumble dryers are supplied to operate at a
voltage of 230V, 50 Hz single phase. Check
that the supply circuit is rated to at least 10A.
● Electricity can be extremely dangerous.
● This appliance must be earthed.
● The socket outlet and the plug on the
appliance must be of the same type.
● Do not use multiple adapters and/or
extension leads.
● The plug should be accessible for
disconnection after the appliance has been
installed.
The wires in the mains lead are coloured in
accordance with the following codes:
Blue NEUTRAL
Brown LIVE
Green and Yellow EARTH
CE Appliance complies with European
Directive 89/336/EEC, 73/23/EEC and
subsequent amendments.
VENTILATION
Adequate ventilation must be provided in the
room where the tumble dryer is located to
prevent gases from appliances burning other
fuels, including open fires, being drawn into the
room during operation of the tumble dryer.
● Exhaust air must not be discharged into a flue
which is used for exhausting fumes from
appliances burning gas or other fuels.
● Check regularly that the air flowing through
the dryer is not restricted.
● Check the fluff filter after use, and clean, if
necessary.
●The inlet and outlets should be kept free from
obstructions. To ensure adequate ventilation
the space between the bottom of the machine
and the floor must not be obstructed. There
should be a gap of at least 12mm between the
machine and any obstructions.
● Prevent items from falling or collecting behind
the dryer as these may obstruct the air inlet and
outlet.
You may be charged for a service call if a
problem with your machine is caused by
incorrect installation.
If the mains cord on this appliance is
damaged, it must be replaced by a special cord
which is ONLY obtainable from the spares
service. It must be installed by a competent
person.
Adjusting the Feet
Once the machine is in
place the feet should
be adjusted to ensure
that the machine is
level.
● NEVER install the dryer up against curtains.
Do not plug the machine in and switch it on
at the mains until the installation is completed.For
your safety, this dryer must be correctly installed.
If there is any doubt about installation, call GIAS
Service for advice.
EN 5
VENTILATION
Installation of the Discharge Hose
It is essential to use a venting hose to carry the hot moist air away from the dryer unless the dryer is
situated in a open space with a good air flowaround it. Recirculation of the moist air will prevent the
efficient operation of the dryer.
The hose is assembled to the machine as shown. The hose may be fitted through a wall or through
an open door or window. The hose is 110mm in diameter and will extend 1.8 meters.
The following guidelines should be followed when installing the
discharge hose.
● Do not use two hoses joined together as the drying performance will
be reduced.
● Do not restrict the flow of air through the hose e.g. by kinking it or fitting
a smaller diameter connector to mount to a wall opening.
● Avoid the hose making U shaped curves as this will restrict the flow of
air and increase the chance that water will collect in the hose.
● Check the hose regularly to remove any build-up of fluff or water that
may have collected in it.
The following diagrams give examples of good and bad installations.
H max
20 inches
(50.80cm)
PREPARING THE LOAD
Before using the tumble dryer for the first time:
● Please read this instruction book thoroughly.
● Remove all items packed inside drum.
● Wipe the inside of the drum and door with a damp cloth to remove any dust which may have
settled in transit.
Clothes Preparation
Make sure that the laundry you are going to dry is suitable for drying in a tumble dryer, as shown by
the care symbols on each item.
Check that all fastenings are closed and that pockets are empty. Turn the articles inside out. Place
clothes loosely in the drum to make sure that they don't get tangled.
EN 6
PREPARING THE LOAD
Maximum Drying Weight
● Cottons Max. 7 kg
● Synthetics Max. 3.5 kg
Do not overload the drum, large items
when wet can exceed the maximum admissible
clothes load (for example: sleeping bags,
duvets).
Sort the Load as Follows
● By care symbols
These can be found on the collar or inside
seam:
Suitable for tumble drying.
. .
Tumble drying at high temperature.
.
Tumble drying at low temperature only.
Do not tumble dry.
If the item does not have a care label it must be
assumed that it is not suitable for tumble
drying.
● By amount and thickness
Whenever the load is bigger than the dryer
capacity, separate clothes according to
thickness (e.g. towels from thin underwear).
● By type of fabric
Do Not Tumble Dry:
Woollens, silk, delicate fabrics, nylon stockings,
delicate embroidery, fabrics with metallic decorations, garments with PVC or leather
trimmings, training shoes, bulky items such as
sleeping bags, etc.
IMPORTANT: Do not dry articles which
have been treated with a dry cleaning fluid or
rubber clothes (danger of fire or explosion).
During the last 15 minutes the load is always
tumbled in cool air.
Energy Saving
Only put into the tumble dryer laundry which
has been thoroughly wrung or spin-dried. The
drier the laundry the shorter the drying time thus
saving electricity.
ALWAYS
● Try to dry the maximum weight of laundry, this
will save time and electricity.
● Check that the filter is clean before every
drying cycle.
NEVER
● Exceed the maximum weight, this will waste
time and electricity.
Cottons/linen: Towels, cotton jersey, bed and
table linen.
Synthetics: Blouses, shirts, overalls, etc.
made of polyester or polyamid, as well as for
cotton/synthetic mixes.
● By drying level
Sort into: iron dry, cupboard dry, etc. For
delicate articles press the button to select
low drying temperature.
● Put dripping wet items into the tumble dryer,
this may damage the appliance.
EN 7
CONTROLS AND INDICATORS
Filter Care
Indicator
Start/Pause
Button
Control Panel and Indicator Lights
Progress
Display
Programme Selector – Select the required
programme
Delay Start button – Allows the user to
delay the start of the drying cycle (see details
of Operation on page 10)
Start/Pause button – Press to
commence the selected drying programme
Acrylics Synthetics button – Press
to reduce the heat level for delicate items,
the indicator above the button will light up. To
change the heat setting the programme must
be reset
Low Heat – Indicator light ON
High Heat – Indicator light OFF
Filter Care indicator – lights when the
filter needs cleaning
Progress display
DRY – When the programme is selected the
DRY indicator will flash, when the programme
starts the DRY indicator will light up.
– Indicator lights when there is a short
time left until completion of the programme. At
this stage of the drying cycle the machine
enters the Cool Down phase.
The length of the Cool Down phase varies
between 10 and 15 minutes depending on the
programme.
END – Indicator lights when the programme
is finished.
Acrylics/Synthetics
Button
Delay Start
Button
SELECTING THE PROGRAMME
Programme
Selector
The Candy Sensor Dry machine gives many
options for drying the laundry to suit all
circumstances.
The table on the next page lists the programmes and the function of each programme.
Note: The sensor may not detect a small load of
small articles. For small loads and separate
items or pre-dried fabrics with low moisture
content, use the timed programmes.
Set the programme between 30 and 75 minutes
depending on the load size and dryness
required, and select high or low heat depending
upon the fabric type.
If the sensor does not detect the item the dryer
will only operate for 10 minutes before going
into cooldown.
If the load is too large or too wet to tumble dry
the dryer will automatically go into cooldown
after approximately 3 hours.
EN 8
Loading...
