Candy EVO 1072D User Manual [EN]

RO
EN

Instructiuni de utilizare
User instructions

RO

EN

FELICITÅRI!

Cumparind aceasta masina
de spalat CANDY ati aratat
ca nu acceptati
compromisuri, vreti doar ce
e cel mai bun.

CANDY are placerea sa va
prezinte o noua masina
de spalat, rezultatul multor
ani de cercetari si studii
asupra nevoilor
consumatorilor.Ati ales
calitatea, durabilitatea si
eficienta oferite de aceasta
masina de spalat.

CANDY va ofera o gama
larga de aparate
electrocasnice: masini de
spalat vase,masini de spalat
si uscat rufe, aragaze,
cuptoare cu microunde,
cuptoare traditionale si
hote, frigidere si
congelatoare.
Solicitati de la magazin
catalogul cu gama
completa Candy.

OUR COMPLIMENTS

With the purchase of this
Candy household
appliance, you have shown
that you will not accept
compromises: you want only
the best.

Candy is happy to present
their new washing machine,
the result of years of
research and market
experience through direct
contact with Consumers.
You have chosen the quality,
durability and high
performance that this
washing machine offers.

Candy is also able to offer a
vast range of other
household appliances:
washing machines,
dishwashers, washer-dryers,
cookers, microwave ovens.
Traditional ovens and hobs,
refrigerators and freezers.

Ask your local retailer for the
complete catalogue of
Candy products.

Va rugam sa cititi aceste
instructiuni cu mare atentie
deoarece furnizeaza
informatii importante cu
privire la instalarea, folosirea
si intretinerea masinii Dvs. De
spalat precum si sugestii
pentru a obtine cele mai
bune rezultate la spalare.

Pastrati instructiunile cu grija
pentru a le putea consulta
de cite ori aveti nevoie.

2

Please read this booklet
carefully as it provides
important guide lines for
safe installation, use and
maintenance and some
useful advise for best results
when using your washing
machine.

Keep this booklet in a safe
place for further
consultation.

When contacting Candy
or a Customer Services
Centre always refer to the
Model, No., and G number
(if applicable of the
appliance see panel).

CUPRINS

RO

INDEX

EN

CAPITOLUL

CHAPTER

Felicitari

Informatii generale

Garantie

Masuri de securitate

Caracteristici tehnice

Instalare punerea in functiune

Descrierea comenzilor

Descrierea programelor

Selectionarea programelor

Caseta de detergenti

Produsul

Spalarea

Introduction

General points on delivery

Guarantee

Safety Measures

Technical Data

Setting up and Installation

Control Description

Table of Programmes

Selection

Detergent drawer

The Product

Washing

1

2

3

4

5

6

7

8

9

10

11

Curatarea si intretinerea
aparatului

Anomalii in functionare

Cleaning and routine
maintenance

Faults Search

12

13

3

RO

EN

CAPITOLUL 1

INFORMATII
GENERALE

La cumpararea masinii,
verificati ca urmatoarele
materiale sa insoteasca
masina:

A) INSTRUCTIUNI DE

UTILIZARE IN LIMBA
ROMANA

B) LISTA CU PUNCTELE

SERVICE

C) CERTIFICAT DE

GARANTIE

D) DOPURI

CHAPTER 1

GENERAL POINTS
ON DELIVERY

On delivery, check that the
following are included with
the machine:

A) INSTRUCTION MANUAL

B) CUSTOMER SERVICE

ADDRESSES

C) GUARANTEE

CERTIFICATES

D) CAPS

E) COT RIGID PENTRU

TUBUL DE EVACUARE

F) COMPARTIMENT

PENTRU DETERGENT
LICHID

PASTRATI-LE INTR-UN
LOC SIGUR.

Verificati daca masina are
daune in urma transportului.
In acest caz, contactati
centrul service
autorizat.

4

E) BEND FOR OUTLET TUBE

F) LIQUID DETERGENT OR

LIQUID BLEACH
COMPARTMENT
(CONTAINER)

KEEP THEM IN A SAFE
PLACE

Check that the machine has
not incurred damage during
transport. If this is the case,
contact your nearest Candy
Centre.

AB

C

D

E

F

RO

EN

CAPITOLUL 2

GARANTIE

Masina de spalat este insotita
de un certificat de garantie care
va permite sa va bucurati de
depanare gratuita.

CHAPTER 2

GUARANTEE

The appliance is supplied
with a guarantee certificate
which allows free use of the
Technical Assistance Service.

5

RO

EN

CAPITOLUL 3

MASURI DE
SECURITATE

ATENTIE: PENTRU ORICE
OPERATIE DE CURATARE
SI INTRETINERE A MASINII
DE SPALAT

Se scoate stekerul din

●

priza.

●

Se inchide robinetul de

apa.

● Toate produsele Candy au

impamintare.
Asigurati-va ca priza folosita
are impamantare.

Aparatele sunt realizate
în conformitate cu directivele
europene 73/23/EEC si
89/336/EEC, înlocuite de
2006/95/EC si 2004/108/EC si
modificarile ulterioare.

CHAPTER 3

SAFETY MEASURES

IMPORTANT:
FOR ALL CLEANING
AND MAINTENANCE
WORK

Remove the plug

●

Turn off the water inlet tap.

●

All Candy appliances are

●

earthed. Ensure that the
main electricity circuit is
earthed. Contact a qualified
electrician if this is not the
case.

Appliance complies
with European Directives
73/23/EEC and 89/336/EEC,
replaced by 2006/95/EC and
2004/108/EC, and
subsequent amendments.

Nu se atinge aparatul cu

●

mainile sau picioarele ude.

Nu utilizati aparatul cand

●

sunteti desculti.

● Nu utilizati prelungitoare in

camera de baie.

ATENTIE: IN TIMPUL
SPALARII TEMPERATURA
APEI POATE AJUNGE LA
90°C.

● Inainte de a deschide hubloul
asigurati-va ca nu exista apa in
tambur.

6

Do not touch the

●

appliance with wet or damp
hands or feet.

Do not use the appliance

●

when bare-footed.

Extreme care should be

●

taken if extension leads are
used in bathrooms or shower
rooms. Avoid this where
possible.

WARNING: DURING THE
WASHING CYCLE,THE
WATER CAN REACH A
TEMPERATURE OF 90°C.

●

Before opening the
washing machine door,
ensure that there is no water
in the drum.

RO

● Nu utilizati adaptoare sau
triplustekere

● Acest aparat nu este
destinat pentru a fi utilizat de
catre copii sau de catre
persoane cu dizabilitati, fara
stricta supraveghere a unui
adult responsabil.

Nu permiteti copiilor sa se
joace cu acest aparat.

● Nu trageti de cablu pentru
a scoate aparatul din priza

EN

●

Do not use adaptors or

multiple plugs.

This appliance is not

●

intended for use by persons
(including children) with
reduced physical,sensory or
mental capabilities, or lack of
experience and knowledge,
unless they have been given
supervision or instruction
concerning use of the
appliance by a person
responsible for their safety.

Children should be
supervised to ensure that
they do not play with the
appliance.

● Nu expuneti aparatul la
agenti atmosferici (razele
soarelui, ploaie etc.)

● In cazul in care o mutati,nu
ridicati niciodata de butoane
sau de caseta de
detergent.

● In timpul transportului nu
sprijiniti hubloul de carucior

IMPORTANT!

In cazul in care aparatul se
instaleaza pe o pardoseala
acoperita cu covor sau
mocheta, trebuie avut grija
ca orificiile de ventilatie de la
baza aparatului sa nu fie
acoperite.

● Pentru a ridica masina sunt
necesare 2 persoane
precum in imagine

● In cazul unei defectiuni
si/sau functionari anormale,
aparatul se opreste, se
inchide robinetul de apa si
nu se atinge masina. Pentru o
eventuala reparatie
trebuie sa va adresati unui
centru de asistenta tehnica
Candy solicitind
piese originale pentru orice
inlocuiri. Nerespectarea
indicatiilor sus mentionate
pot compromite securitatea
masinii.

● Daca e necesara
inlocuirea cablului de
alimentare, aceasta se va
face cu un
cablu disponibil la punctul
service.

Do not pull the mains lead

●

or the appliance itself to
remove the plug from the
socket.

Do not leave the

●

appliance exposed to
atmospheric agents (rain, sun
etc.)

In the case of removal,

●

never lift the appliance by
the knobs or detersive
drawer.

During transportation

●

do not lean the door against
the trolley.

Important!

When the appliance
location is on carpet floors,
attention must be paid so as
to ensure that there is no
obstruction to the bottom
vents.

Lift the appliance in pairs

●

as illustrated in the diagram.

In the case of failure

●

and/or incorrect operation,
turn the washing machine
off, close the water inlet tap
and do not tamper with the
appliance. Contact a Candy
Technical Assistance Centre
for any repairs and ask for
original Candy spare parts.
Avoidance of these norms
may compromise the safety
of the appliance.

Should the supply cord

●

(mains cable) be demaged,
this is to be replaced by a
specific cable available from
the after sales service centre.

7

RO

EN

CAPITOLUL 4

85

cm

60 cm

CHAPTER 4

52 cm

85

cm

60 cm

60 cm

CARACTERISTICI TEHNICE

CAPACITATE RUFE USCATE

PUTERE

AMPERAJUL FUZIBILULUI

ROTATII CENTRIFUGA

PRESIUNEA IN INSTALATIA

HIDRAULICA

TENSIUNE

8

TECHNICAL DATA

MAXIMUM WASH

LOAD DRY

POWER INPUT

POWER CURRENT FUSE

AMP

SPIN

r.p.m.

WATER PRESSURE

SUPPLY VOLTAGE

52

cm

kg 9

W

A

MPa

V

7

2150

10

CITITI PE PLACUTA MASINII

SSEEEE RRAATTIINNGG PPLLAATTEE

52

cm

8

2150

10

min. 0,05

max. 0,8

220-240

60

cm

2400

16

RO

EN

CAPITOLUL 5

INSTALARE. PUNERE
IN FUNCTIUNE

Atentie: Masina de spalat se
instaleaza de catre un
instalator profesionist,dar nu
intra in obligatia centrului
service autorizat sa faca
aceasta instalare in termen
de garantie,in regim gratuit.

Atentie: Reteaua dvs.
electrica trebuie sa poata
suporta puterea maxima a
masinii. In caz contrar,
inlocuiti cablurile de
alimentare sau sigurantele
cu unele de amperaj
corespunzator (16A).

Atentie: In cazul sistemelor
proprii de alimentare
cu apa, presiunea apei
trebuie sa fie suficient de
mare pentru a dizolva tot
detergentul din sertarul de
detergent. In caz contrar, se
pot produce blocari ale
sertarului de detergent, sau
ale furtunului dintre cuva
si sertarul de detergent.

Dupa ce ati scos ambalajul,
faceti in felul urmator:

Taiati cu atentie curelele care
leaga cablul de alimentare si
furtunul de evacuare.

Indepartati cele 2 sau 4
suruburi marcate cu A si cele
2 sau 4 distantatoare
marcate cu B.

Acoperiti cele 2 sau 4 gauri
folosind capacele furnizate in
punga cu manuale de
instructiuni.

ATENTIE: NU LASATI
AMBALAJUL LA
INDEMANA COPIILOR,
ACESTA FIIND O
POTENTIALA
SURSA DE PERICOL.

CHAPTER 5

SETTING UP
INSTALLATION

Move the machine near its
permanent position without
the packaging base.

Carefully cut the securing
strap that holds the main
cord and the drain hose.

Remove the 2 or 4 fixing
screws marked (A) and
remove the 2 or 4 spacers
marked (B)

Cover the 2 or 4 holes using
the caps provided in the
instruction booklet pack.

WARNING:
DO NOT LEAVE THE
PACKAGING IN THE
REACH OF CHILDREN
AS IT IS A POTENTIAL
SOURCE OF DANGER.

9

min 50 cm
max 85 cm

+2,6 mt max

max 100 cm

min 4 cm

RO

Aplicati folia suplimentara la
baza ca in figura.

EN

Fix the sheet of corrugated
material on the bottom as
shown in picture.

Conectati tubul de apa la
robinet.

Masina trebuie conectata la
reteaua de apa
folosind exclusiv furtunele din
dotare.Nu folositi furtune vechi,
utilizate.

ATENTIE: NU DESCHIDETI
IN ACEST MOMENT
ROBINETUL.

Asezati masina langa perete si
puneti tubul de evacuare
la marginea cazii,avand grija
ca acesta sa nu fie strangulat
sau indoit.

Este mai bine sa conectati
tubul la o teava de evacuare
fixa care trebuie sa aiba un
diametru mai mare decat
cel al tubului si o inaltime
minima de 50 cm.Daca este
necesar utilizati cotul de plastic
din dotare.

Connect the fill hose
to the tap.

The appliance must be
connected to the water
mains using new hose-sets.
The old hose-sets should not
be reused.

IMPORTANT:
DO NOT TURN THE TAP
ON AT THIS TIME.

Position the washing
machine next to the wall.
Hook the outlet tube to the
edge of the bath tub,
paying attention that there
are no bends or
contractions along the tube.

It is better to connect the
discharge hose to a fixed
outlet of a diameter greater
than that of the outlet tube
and at a height of min. 50
cm. If is necessary to use the
plastic sleeve supplied.

10

A

B

C

RO

Folositi cele patru picioare
ajustabile pentru a aseza
orizontal masina pe podea .

a) Rotiti piulita in sens orar
pentru a debloca surubul
piciorusului.

b) Rotiti piciorusul si coborati-l
sau inaltati-l pentru a obtine o
aderenta perfecta la sol.

c) Blocati piciorusul rotind
piulita in sens invers acelor
de ceasornic pana la capat.

EN

Use the 4 feet to level the
machine with the floor:

a) Turn the nut clockwise to
release the screw adjuster of
the foot.

b) Rotate foot to raise or
lower it until it stands firmly on
the ground.

c) Lock the foot in position
by turning the nut anti­clockwise until it comes up
against the bottom of the
machine.

Asigurati-va ca toate
butoanele sunt in pozitia “OFF”
si hubloul este inchis.

Introduceti stekerul in priza.

ATENTIE:

în cazul în care va fi necesar sa
înlocuiti cablul de alimentare,
conectati firele în conformitate
cu urmatoarele culori/coduri:

ALBASTRU - NUL (N)

MARO - FAZA (L)

GALBEN-VERDE - ÎMPAMANTARE ( )

Daca nu se aprinde, cititi
capitolul referitor la defecte
posibile.

Ensure that the knob is on the
“OFF” position and the load
door is closed

Insert the plug.

ATTENTION:

should it be necessary to
replace the supply cord,
connect the wire in
accordance with the
following colours/codes:

BLUE - NEUTRAL (N)
BROWN - LIVE (L)
YELLOW-GREEN - EARTH ( )

After installation, the
appliance must be
positioned so that the plug is
accessible.

11

RO

EN

CAPITOLUL 6

COMENZI

Manerul usii

P

CHAPTER 6

CONTROLS

Door handle

C

D

HL

A

I EF B

59 Min

14 Min

&

EcoMix

20°

GE

A

60°C

40°C

Buton selectare programe cu
pozitie “OFF”

Buton Pornit/Oprit

Indicator pornire program

Leduri indicatoare butoane

Buton Aquaplus

Buton spalare rece

Buton pornire intarziata

Buton viteza de stoarcere

Afisaj “Digital”

Caseta detergenti

12

Timer knob for wash
programmes with OFF position

Start button

Programme start light

Buttons indicator light

Aquaplus button

Cold wash button

Start Delay button

Spin Speed button

Digital Display

Detergent drawer

B

C
D
E

F
G
H

I

L
P
