Candy CSOV8DF Instruction manual

EN

!

2

Thank you for choosing this product.
We are proud to offer the ideal product for
you and the best complete range of home
appliances for your daily routine.

Please read and follow these
instructions carefully and operate the
machine accordingly. This booklet provides
important guidelines for safe use,
installation, maintenance and some useful
advice for best results when using your
machine. Keep all documentation in a safe
place for future reference or for any future
owners.

Please check that the following items are
delivered with the appliance:

• Instruction manual

• Guarantee card

• Energy label

Check that no damage has occurred to the
machine during transit. If it as, call for
service by Customer Service Centre.
Failure to comply with the above can
compromise the safety of the appliance.
You may be charged for a service call if a
problem with your machine is caused by
misuse or by incorrect installation.
To contact the Service, ensure that you
have the unique 16-character code
available, also called the "serial number".
This code is a unique code for your
product, printed on the sticker that can be
found inside the door opening.

WEEE contains both polluting substances (which
can cause negative consequences for the
environment) and basic components (which can
be re-used). It is important to have WEEE
subjected to specific treatments, in order to
remove and dispose properly all pollutants, and
recover and recycle all materials. Individuals can
play an important role in ensuring that WEEE
does not become an environmental issue; it is
essential to follow some basic rules:

! WEEE should not be treated as household

waste;

! WEEE should be handed over to the relevant

collection points managed by the municipality or
by registered companies. In many countries, for
large WEEE, home collection could be present.

In many countries, when you buy a new
appliance, the old one may be returned to the
retailer who has to collect it free of charge on a
one-to-one basis, as long as the equipment is of
equivalent type and has the same functions as
the supplied equipment.

1. GENERAL SAFETY RULES

2. VENTILATION

3. DOOR AND FILTERS

4. PRACTICAL HINTS

5. REMOTE CONTROL (WI-FI)

6. QUICK USER GUIDE

7. CONTROLS AND PROGRAMMES

8.

TROUBLESHOOTING AND WARRANTY

This appliance is marked according to
the European directive 2012/19/EU
on Waste Electrical and Electronic
Equipment (WEEE).

Contents

Environmental conditions

!

EN

3

1. GENERAL SAFETY
RULES

! This appliance is intended to

be used in household and
similar applications such as:

- Staff kitchen areas in shops, offices
and other working environments;

- Farm houses;

- By clients in hotels, motels and
other residential type environments;

- Bed and breakfast type environments.

A different use of this appliance
from household environment
or from typical housekeeping
functions, as commercial use by
expert or trained users, is excluded
even in the above applications. If
the appliance is used in a manner
inconsistent with this it may reduce
the life of the appliance and may
void the manufacturer’s warranty.
Any damage to the appliance or
other damage or loss arising
through use that is not consistent
with domestic or household use
(even if located in a domestic or
household environment) shall not
be accepted by the manufacturer to
the fullest extent permitted by law.

! This appliance can be used by

children aged from 8 years and
above and persons with reduced
physical, sensory or mental
capabilities or lack of experience
and knowledge if they have been
given supervision or instruction
concerning use of the appliance

in a safe way and understand the
hazards involved.
Children shall not play with the
appliance. Cleaning and user
maintenance shall not be made
by children without supervision.

! Children should be supervised

to ensure that they do not play
with the appliance.

! Children of less than 3 years

should be kept away unless
continuously supervised.

! This machine is solely for

domestic use, i.e. to dry
household textiles and garments.

! Ensure that the instructions for

installation and use are fully
understood before operating
the appliance.

! Do not touch the appliance

when hands or feet are damp
or wet.

! Do not lean on the door when

loading the machine or use the
door to lift or move the machine.

WARNING

Misuse of a tumble dryer may
create a fire hazard.

!

4

! Do not continue to use this

machine if it appears to be faulty.

! The tumble dryer is not to be

used if industrial chemicals
have been used for cleaning.

!

Lint and fluff must not be allowed
to collect on the floor around the
outside of the machine.

! Always remove the plug before

cleaning the appliance.

! The drum inside may be very

hot. Always allow the dryer to
complete the cool down period
before removing the laundry.

! The final part of a tumble dryer

cycle occurs without heat (cool
down cycle) to ensure that the
items are left at a temperature
that ensures that the items will
not be damaged.

! Do not install the product in a

low temperature room or in a
room where there is a risk of
frost occurring. At temperature
around freezing point the
product may not be able to
operate properly: there is a risk
of damage if the water is
allowed to freeze in the
hydraulic circuit (valves, hoses,
pumps). For a better product
performance the ambient room
temperature must be between
5-35°C. Please note that
operating in cold condition
(between +2 and +5°C) might
simply some water condensation
and water drops on floor.

WARNING

Do not use the product if the
fluff filter is not in position or
is damaged; fluff could be
ignited.

WARNING

Where the hot surface
symbol is located the

temperature rise during
operation of the tumble
dryer may be in excess of 60
degrees C.

WARNING

Never stop a tumble dryer
before the end of the drying
cycle unless all items are
quickly removed and spread
out so that the heat is
dissipated.

Installation

!

EN

5

! In cases where the dryer is

installed on top of a washing
machine, a suitable stacking kit
must be used according to the
configuration of your appliance:

−

Stacking kit "standard size":
for washing machine with
minimum depth of 44 cm;

− Stacking kit "slim size": for

washing machine with
minimum depth of 40 cm.

− Universal stacking kit with

sliding: for washing machine
with minimum depth of
47 cm.

The stacking kit shall be
obtainable from service. The
instructions for installation and
any fixing attachments, are
provided with the stacking kit.

! NEVER install the dryer up

near curtains.

! The appliance must not be

installed behind a lockable
door, a sliding door or a door
with a hinge on the opposite
side to that of the tumble dryer.

! For your safety, the appliance

must be correctly installed. If
there is any doubt about installation,
call Service for advice.

! Once the machine is in place

the feet should be adjusted to
ensure that the machine is
level.

! The technical details (supply

voltage and power input) are
indicated on the product rating
plate.

! Make sure that the electrical

system is earthed, complies
with all applicable law and that
the (electricity) socket is
compatible with the plug of the
appliance. Otherwise, seek
qualified professional assistance.

Electrical connections and
safety instructions

WARNING

The appliance must not be
supplied through an external
switching device, such as a
timer, or connected to a circuit
that is regularly switched on
and off by a utility.

!

6

! Do not use adapters, multiple

connectors and/or extensions.

! The plug should be accessible

for disconnection after the
appliance has been installed.

! Do not plug the machine in and

switch it on at the mains until
the installation is completed.

! If the supply cord is damaged,

it must be replaced

by the

manufacturer, its service

agent
or similarly qualified persons in
order to avoid a hazard.

! Adequate ventilation must be

provided in the room where the
tumble dryer is located to
prevent gases from appliances
burning other fuels, including
open fires, being drawn into
the room during operation of
the tumble dryer.

! Install the rear of the appliance

close to a wall or vertical surface.

! There should be a gap of at

least 12 mm between the
machine and any obstrubtions.
The inlet and outlet air should
be kept clear of obstruction.

! Make sure carpets or rugs

do not obstruct the base or any
of the ventilation openings.

! Prevent items from falling or

collecting behind the dryer as
these may obstruct the air inlet
and outlet.

! Exhaust air must not be

discharged into a flue which is
used for exhausting fumes
from appliances burning gas or
other fuels.

! Check regularly that the air

flowing around the dryer is not
restricted, avoiding accumulation
of dust and lint.

! Check frequently the fluff filter

after use, and clean, if necessary.

* Air inlet.
**Air outlet.

! Always refer to the laundry

care labels for directions on
suitability for drying.

Ventilation

The Laundry

!

EN

7

! Fabric softeners, or similar

products, should be used as
specified by the fabric softener
instructions.

! Do not dry unwashed items in

the tumble dryer.

! Clothes should be spin dried or

thoroughly wrung before they
are put into the tumble dryer.

! Clothes that are dripping wet

should not be put into the dryer.

! Glass fibre curtains should

NEVER be put in this machine.
Skin irritation may occur if

other

garments are contaminated

with

the glass fibres.

! Items that have been soiled

with substances such as cooking
oil, acetone, alcohol, petrol,
kerosene, spot removers,
turpentine, waxes and wax
removers should be washed in
hot water with an extra amount
of detergent before being dried
in the tumble dryer.

!

Remove all objects from pockets
such as lighters and matches.

! Lighters and matches must not

be left in pockets and NEVER
use flammable liquids near the
machine.

! Maximum load drying weight:

see energy label.

!

To consult the product technical
specification please refer to the
manufacturer website.

WARNING

Foam rubber materials can

,
under certain circumstances,
when heated become ignited
by spontaneous combustion.
Items such as foam rubber
(latex foam), shower caps,
waterproof textiles, rubber
backed articles and clothes
or pillows fitted with foam
rubber pads MUST NOT be
dried in the tumble dryer.

WARNING

Do not tumble dry fabrics
treated with dry cleaning fluids.

!

8

2. VENTILATION

! It is essential to use a venting hose to

carry the hot moist air away from the
dryer unless the dryer is situated in an
open space with a good air flow around it.

! Recirculation of the moist air will prevent

the efficient operation of the dryer.

! The hose is assembled to the machine as

shown.

! The hose may be fitted through a wall or

through an open door or window. The
hose is 110 mm in diameter and will
extend 1,8 meters.

The following guidelines should be followed
when installing the discharge hose.

1

! Do not use two hoses joined together as

the drying performance will be reduced.

! Do not restrict the flow of air through the

hose e.g. by kinking it or fitting a smaller
diameter connector to mount to a wall
opening.

! Avoid the hose making U shaped curves

as this will restrict the flow of air and
increase the chance that water will collect
in the hose.

! Check the hose regularly to remove any

build-up of fluff or water that may have
collected in it.

The following diagrams give examples of
good and bad installations.

2 3

4 5

H max
20 inches
(50.80 cm)

Installation of the discharge hose
