Candy CS H8A2LE Instruction manual

EN

Please read and follow these instructions
carefully and operate the machine
accordingly. This booklet provides important
guidelin es for safe use, installation,
maintenance and some useful advice for best

results when using your machine.

Keep all documentation in a safe place for
future reference or for any future owners.

Please check that the following items are
delivered with the appliance:

● Instruction manual

● Guarantee card

● Energy label

By placing the mark on this product,
we are confirming compliance to all relevant
European safety, health and environmental
requirements which are applicable in
legislation for this product.

Index

1. SAFETY REMINDERS

2. DRAIN HOSE KIT: FITTING

INSTRUCTIONS

3. PREPARING THE LOAD

4. CLEANING AND ROUTINE
MAINTENANCE

5. WATER CONTAINER

6. DOOR AND FILTER AND CONDENSER

7. CONTROLS AND INDICATORS

8. SELECTING THE PROGRAMME AND
SET THE FUNCTION

9. TROUBLESHOOTING CUSTOMER
SERVICE

Check that no damage has occurred to
the machine during transit. If it has, call for
service by GIAS. Failure to comply with the
above can compromise the safety of the
appliance. You may be charged for a service
call if a problem with your machine is caused
by misuse.

2

1.

SAFETY REMINDS

●

This appliance can be used by
children aged from 8 years and
above and persons with
reduced physical,sensory or
mental capabilities or lack of
experience and knowledge if they
have been given supervision or
instruction concerning use of the
appliance in a safe way and
un der s tan d t he haz a rds
involved.Children shall not play
with the appliance. Cleaning and
user maintenance should not be
made by children without
supervision.Children of less than
3 years should be kept away
unless continuously supervised.

●

WARNING

dryer may create a fire hazard.

This appliances is intended to be

●
used in household and similar

applications such as:

- Staff kitchen areas in shops ,
offices and other working
environments;

- Farm houses

- By clients in hotels, motels and
o t he r r e s i de nt i al t y p e
environments;

- Bed and breakfast type
environments" A different use of
this appliance from house hold
environment or from typical
housekeeping functions,as
commercial use by ex p e rt or
trained users, is excluded even in
the above applications.
If the appliance is used in a
manner inconsistent with this it

Misuse of a tumble

may reduce the life of the
appliance and may void the
manufacturer’s warranty.
Any damage to the appliance
or other damage or loss
arising through use that is not
consistent with domestic or
household use ( even if
located in a domestic or
household environment)
shall not be accepted by the
manufacturer to the fullest
extent permitted by law.

●

This machine should only be
used for its intended purpose
as described in this manual.

Ensure that the instructions
for installation and use are
fully understood before
operating the appliance.

●

Do not touch the appliance
when hands or feet are damp
or wet.
Do not lean on the door when

●

loading the machine or use
the door to lift or move the

machine.

Do not allow children to play

●

with the machine or its
controls.

EN

3

●

WARNING

product if the fluff filter is not in
position or is damaged; fluff

could be ignited.

●

WARNING

surface symbol is located
the temperature rise during

operation of the tumble dryer
may be in excess of 60 degrees
C.

●

Remove the plug from the
electricity supply. Always
remove the plug before cleaning

the appliance.

●

Do not continue to use this
machine if it appears to be faulty.

Lint and fluff must not be

●

allowed to collect on the floor
around the outside of the

machine.

●

The final part of a tumble dryer
cycle occurs without heat (cool

down cycle) to ensure that the
items are left at a temperature
that ensures that the items will
not be damaged.

●

The tumble dryer is not to be
used if industrial chemicals have
been used for cleaning.

●

WARNING:

dryer before the end of the
drying cycle unless all items are
quickly removed and spread out
so that the heat is dissipated.

●

Maximum load drying weight:
see energy label.

Do not use the

Where the hot

Never stop a tumble

Installation

●

Do not use adapters, multiple
connectors and/or extensions.

●

Never install the dryer against
curtains and be sure to prevent
items from falling or collecting
behind the dryer.

●

The appliance must not be
installed behind a lockable door,
a sliding door or a door with a
hinge on the opposite side to
that of the tumble dryer.

Important: During transport
ensure that the dryer is in an
upright position, if it's necessary
you can only flip in the side shown;

CAUTION: If the product is in

different side, wait at least 4 hours
before switching on so that the oil
c a n f l o w b a c k i n t o t h e
compressor. Failure to do this
could result in damage to the
compressor.

4

The Laundry

●

Do not dry unwashed items in
the tumble dryer.

●

WARNING

Do not tumble dry
fabrics treated with dry cleaning
fluids.

●

WARNING

Fo am r u bbe r
materials can, under certain
circumstances, when heated

b e c o m e i g n i t e d b y
spontaneous combustion.
Items such as foam rubber
(latex foam), shower caps,
waterproof textiles, rubber
backed articles and clothes or
pillows fitted with foam rubber
pads MUST NOT be dried in the
tumble dryer.

Always refer to the laundry care

●

labels fo r d ir ections on
suitability for drying.

●

Clothes should be spin dried or
thoroughly wrung before they
are put into the tumble dryer.

●

Clothes that are dripping wet
should not be put into the dryer.

Lighters and matches must not
be left in pockets and NEVER
use flammable liquids near the

machine.

●

Glass fibre curtains should
NEVER be put in this machine.
Skin irritation may occur if other

garments are contaminated
with the glass fibres.

●

Items that have been soiled
with substances such as

cooking oil, acetone, alcohol,

p e t r o l , k e r o s e n e , s p o t
removers, turpentine, waxes
and wax removers should be

washed in hot water with an
extra amount of detergent
before being dried in the
tumble dryer.

●

Fabric softeners, or similar
products, should be used as
specified by the fabric

softener instructions.

Ventilation

●

Adequate ventilation must be
provided in the room where
the tumble dryer is located to
p r e v e n t g a s e s f r o m
appliances burning other
fuels, including open fires,
being drawn into the room
during operation of the
tumble dryer.

●

Installing the rear of the
appliance close to a wall or
vertical surface.
There should be a gap of at

●
least 12 mm between the
m a c h i n e a n d a n y
obstrubtions.The inlet and
outlet should be kept clear of
obst r u c t i o n . To en s u r e
adequate ventilation the
space between the bottom of
the machine and the floor
must not be obstructed.

●

Check regularly that the air
flowing through the dryer is
not restricted.

●

Check frequently the fluff
filter after use, and clean, if
necessary.

●

Prevent items from falling or
collecting behind the dryer as

5

EN

these may obstruct the air inlet
and outlet

●

NEVER install the dryer up
against curtains.

●

In cases where the dryer is
installed on top of a washing
machine, a suitable stacking kit
must be used according to the
follow configuration.

- Stacking kit Mod 35100019:
for minimum washing machine
depth 49 cm

- Stacking kit Mod 35900120:
for minimum washing machine
depth 51 cm

The stacking kit shall be one of
that above, obtainable from our
spare service.
The instructions for installation
and any fixing attachments, are
provided with the staking kit.

Do not install the product in a
low temperature room or in a
room where there is a risk of frost
occurring. At temperature around
freezing point the product may
not be able to operate properly:
there is a risk of damage if the
water is allowed to freeze in the
hydraulic circuit (valves, hoses,
pumps). For a better product
performance the ambient room
temperature must be between
5-35°C. Please note that
operating in cold condition
(between +2 and +5°C) might
simply some water condensation
and water drops on floor.

Air Outlets in the Base

6

Environmental Issues

●

All packaging materials used are
environmentally-friendly and recyclable.
Please help dispose of the packaging via
environmentally-friendly means. Your
local council will be able to give you details
of current means of disposal.

●

To ensure safety when disposing of an old
tumble dryer disconnect the mains plug
from the socket, cut the mains power cable
and destroy this together with the plug. To
prevent children shutting themselves in
the machine break the door hinges or the
door lock.

European Directive 2012/19/EU

This appliance is marked according
to the European directive 2012/19/EU
on Waste Electrical and Electronic
Equipment (WEEE).

WEEE contains both polluting substances
(which can cause negative consequences for
the environment) and basic components (which
can be re-used). It is important to have WEEE
subjected to specific treatments, in order to
remove and dispose properly all pollutants, and
recover and recycle all materials.
Individuals can play an important role in
ensuring that WEEE does not become an
environmental issue; it is essential to follow
some basic rules:

Electrical Requirements

Tumble dryers are supplied to operate at a
voltage of 220-240V, 50 Hz single phase.
Check that the supply circuit is rated to at least
6 A.

Electricity can be extremely dangerous.
This appliance must be earthed.
The socket outlet and the plug on the
appliance must be of the same type.
Do not use multiple adapters and/or
extension leads.

The plug should be accessible for
disconnection after the appliance has
been installed.

C o n t a i ns f lu o r i n at e d
g r e e n h o u s e g a s e s .
Hermetically sealed.

You may be charged for a service
call if a problem with your machine is
caused by incorrect installation.

If the mains cord on this appliance
is damaged, it must be replaced by a
special cord which is ONLY obtainable
from the spares service. It must be
installed by a competent person.

GWP1430

EN

- WEEE should not be treated as household
waste.

- WEEE should be handed over to the relevant
collection points managed by the municipality or
by registered companies. In many countries, for
large WEEE, home collection could be present.

In many countries, when you buy a new
appliance, the old one may be returned to the
retailer who has to collect it free of charge on a
one-to-one basis, as long as the equipment is of
equivalent type and has the same functions as
the supplied equipment.

GIAS Service

●

To ensure the continued safe and efficient
operation of this appliance we recommend
that any servicing or repairs are only carried
out by an authorised GIAS service engineer.

Do not plug the machine in and
switch it on at the mains until the
installation is completed.For your safety,
this dryer must be correctly installed. If
there is any doubt about installation, call
GIAS Service for advice.

Adjusting the Feet

Once the machine is
in place the feet
should be adjusted to
en s u r e t h a t t h e
machine is level.

7

DRAIN HOSE: FITTING

2.

INSTRUCTIONS

To avoid emptying the water container after
each drying cycle, the water can be discharged
directly to a waste water drain pipe (the same
drainage system as household sinks). Water
Bye-Laws prohibit connection to a surface
water drain. The waste water drain pipe should
be located adjacent to the tumble dryer.

The kit consists of:1 hose and 1 tap.

WARNING

tumble dryer plug from the electricity supply
before carrying out any work.

Switch off and remove the

4. Attach the black
hose from the kit,
(using the connector
a n d p i p e c l i p s
supplied), to the hose
re moved from the
bridge connection.

5. Connect the new
drain hose to the waste
Water pipe.

4

5

Fit the Hose as Follows:

1. Flip the machine

slowly to the right
side.

2. The waste water

pipe is situated at the
right-hand side of the
machine (see the
picture). A grey hose
connects to the bridge

at the left hand side of
the machine. Using

pliers, remove the
pipe retaining clip
from the bridge.

1

2

3

3. Pull the hose off the
bridge connection.

6. Once the machine is
in place, check the
bottom to ensure that
the new hose does not

kink when pushing the
tumble d r y e r into
position.

Connect to the mains
electricity supply.

CAUTION:

side, wait at least 4 hours before switching
on so that the oil can flow back into the

compressor. Failure to do this could result
in damage to the compressor.

6

If the product is in different

8

3.

PREPARING THE LOAD

Before using the tumble dryer for the first time:

● Please read this instruction book thoroughly.

● Remove all items packed inside drum.

● Wipe the inside of the drum and door with a

damp cloth to remove any dust which may have

settled in transit.

Clothes Preparation

Make sure that the laundry you are going to
dry is suitable for drying in a tumble dryer, as
shown by the care symbols on each item.
Check that all fastenings are closed and that
pockets are empty. Turn the articles inside out.
Place clothes loosely in the drum to make sure
that they don't get tangled.

Do Not Tumble Dry:

Silk, nylon stockings, delicate embroidery,
fabrics with metallic decorations, garments
with PVC or leather trimmings.

IMPORTANT: Do not dry articles which

have been treated with a dry cleaning fluid or
rubber clothes (danger of fire or explosion).

During the last 15 minutes the load is always
tumbled in cool air.

Energy Saving

Only put into the tumble dryer laundry which has
been thoroughly wrung or spin-dried. The drier
the laundry the shorter the drying time thus
saving electricity.

ALWAYS

● Check that the filter is clean before every
drying cycle.

NEVER

● Put dripping wet items into the tumble dryer,
this may damage the appliance.

Sort the Load as Follows

● By care symbols

These can be found on the collar or inside seam:

Suitable for tumble drying.

. .

Tumble drying at high temperature.

If the item does not have a care label it must
be assumed that it is not suitable for tumble
drying.

● By amount and thickness

Whenever the load is bigger than the dryer
capacity, separate clothes according to
thickness (e.g. towels from thin underwear).

● By type of fabric

Cottons/linen: Towels, cotton jersey, bed
and table linen.
Synthetics: Blouses, shirts, overalls, etc.
made of polyester or polyamid, as well as
for cotton/synthetic mixes.

Do not overload the drum, large items
whe n wet ex ceed th e maxi m um
admissible clothes load (for example:
sleeping bags, duvets).

4.

CLEANING AND ROUTINE

MAINTENANCE

Cleaning the Dryer

● Clean the filter and empty the water
container after every drying cycle.

● Regularly clean the condenser.

● After each period of use, wipe the inside

of the drum and leave the door open for a
while to allow circulation of air to dry it.

● Wipe the outside of the machine and the
door with a soft cloth.

● DO NOT use abrasive pads or cleaning
agents.

● To prevent the door sticking or the build
up of fluff clean the inner door and gasket
with a damp cloth after every drying cycle.

WARNING

load may be very hot.

IMPORTANT Always switch off and
remove the plug from the electricity supply
before cleaning this appliance.

For electrical data refer to the rating
label on the front of the dryer cabinet (with
the door open).

The Drum, door and

EN

.

Tumble drying at low temperature only.

Do not tumble dry.

9

5.

WATER CONTAINER

The water removed from the laundry during
the drying cycle is collected in a container
inside the door of the dryer. When the
container is full the indicator on the
control panel will light, and the container
MUST be emptied. However, we recommend
that the container is emptied after each
drying cycle.

NOTE: Very little water will collect during the
first few cycles of a new machine as an
internal reservoir is filled first.

To remove the container

tank in door drawer

1. Gently pull out the
water container holding
the handle. (A)

When it is full the
water container will
weigh about 6 kg.

2. T i l t t h e w a t e r
container to empty the
water out through the
spout. (B)

A

NOTE: If you have

the option of drainage
near to the dryer you
c a n u s e t h e
di s c h ar g e k i t t o
provide a permanent
drainage for the water
co l l e c t e d i n t he
container of the dryer.
This means that you

don't have to empty
the water container.

1

C

When empty, replace
the water container
back as shown; (C) first

insert the base of the
container into position
as shown (1) then
gentle push the top into
position (2).

3. Press Button to
restart the cycle.

B

10

6.

DOOR AND FILTER

Pull on handle to open the door.
To restart the dryer, close the door and press

Start / Pause button.

WARNING

use the drum and door may be VERY HOT.

Filter

IMPORTANT: To maintain the efficiency of
the dryer check that the fluff filter is clean
before each drying cycle.

When the tumble dryer is in

To Clean the Condenser Filter

1. R e m o v e t h e
kickplate.

2. Turn the two locking
levers anti-clockwise

and pull out the front
cover.

1

EN

1. P u l l t h e f i l te r
upwards.

2. Open filter as shown.

1

3. Gently remove lint
using a soft brush or
your fingertips.

4. Sn a p t h e f i l t e r
together and push
back into place.

2

Filter Care Indicator

Lights when the filter needs cleaning.

If the laundry is not drying check that the filter
is not clogged.

IF YOU CLEAN FILTER UNDER

WATER, REMEMBER TO DRY IT.

WARNING

cycle, before the cool-down cycle has
completed,the handle may be hot. Please use
extreme caution when attempting to empty
the water reservoir during the cycle.

If you open the door mid

3. Gently remove the
filter frame and clean
any dust or fluff with a
cloth from the filter. Do
not use water to clean
the filter.

4. Remove the sponge
gently from its place
and then wash the
sponge by holding it
under a running tap
turning it so to remove
any dust or fluff.

5. Refit the front cover
ensuring it is in the
c o rr e c t w a y ( a s
indicated by the arrow)
and pushed firmly into
place. Lock the two
levers by turning them
clockwise

6. Refit the kickplate.

2

3

4

5

11

7.

CONTROLS AND
INDICATORS

DRY

END

6h

3h

9h

220'

120'

90'

60'

A

D

C

DRY

END

6h

3h

9h

220'

120'

90'

60'

B

3

4

2

A-Programme Selector -

Rotating the knob in both directions it's
possible to select the desired drying
program. To cancel the selections or switch
off the dryer rotate the knob on OFF.

B-Buttons -

1.Start/Pause Button

To start the selected program and/or
suspend it.

2.Time cycle selection

It's possible switch a cycle from automatic to
timed , up to 3 minutes after the start of the
cycle. After this selection to reset the
automatic dying functioning is necessary to
switch off the dryer. In case of incompatibility,
all LEDs flash quickly for 3 times.

3.Drying Selection Button

It allows to set the desired dryness level
editable option up to 5 minutes after the
starting of the cycle:

- Ready to Iron : It leaves the garments

slightly wet to facilitate ironing.

- Dry Hanger : To get garment ready to

be hang

- Dry wardrobe : For laundry that can be

directly stored

-Extra-dry : To get completely dry

garments, ideal for full load.

1

This appliances is equipped with Drying
Manager Function. On automatic cycles,
each level of intermediate drying, prior to the
reaching the selected one, is indicated by
flashing the light indicator corresponding to
the degree of drying reached In case of
incompatibility, all LEDs flash quickly for 3
times.

4.Delay Start Button

To postpone the start of the programm for 3h,
6h, or 9h. Opening of the porthole with
delayed start set, after re-closing the porthole,
press start again to resume the counting.

C- Led

Water tank - It lights up when it's

necessary to empty the condensate water
tank.
Filter cleaning - It lights up when the
cleaning of the filters is requested (the door
and the lower filter.)

These control lights, light up for indicate the
drying phase:

-DRY: It lights up when the drying cycle is
running.

- It light up when the cycle is in the
cooling phase.

-END: It light up when the cycle is done.

D-

SMART TOUCH area - pressing the

START/PAUSE button allows to a previously
downloaded cycle to start whilst the Touch
position is selected on the programme knob
(for downloading cycles from the App see the
relevant section of this user manual).

12

The wool drying cycle of
this machine has been
a p p r o v e d b y T h e
Woolmark Company for
the drying of machine
washable wool products

provided that the products
are washed and dried according to the
instructions on the garment label and those
issues by the manufacturer of this machine.
M1530.

In UK, Eire, Hong Kong and India the
Woolmark trade mark is a Certification trade
mark.

Maximum Drying Weight

Cottons

Synthetics or Delicates

Max.capacity declared
Max.4 Kg

Drying Guide

The standard cycle COTTON DRY ( ) is
the most energy efficient and best suited for
drying normal wet cotton laundry.

The table in last page shows the
approximate time and energy consumption
of the main drying programmes.

Power consumpton of off-mode 0,40 W
Power consumpton of on-mode 0,75 W

Technical Specifications

Drum capacty 115
Maxmum load See energy label
Heght 85 cm
Wdth 60 cm
Depth 60 cm
Energy class See energy label

The real duration of drying cycle
depends by the starting humidity level of
the laundry due to spin speed, type and
amount of load, cleanliness of filters and
ambient temperature.

OPERATION

1. Open the door and load the drum
with laundry. Ensure that garments do
not hinder closure of the door.

2. Gently close the door pushing it
slowly until you hear the door 'click'
shut.

3. Turn the Programme Selector dial to
select the required drying programme
(see Programme Guide).

4. Press the button. The dryer will
start automatically and the indicator
above the button will be continuously
lit.

5. If the door is opened during the
programme to check the laundry, it is
necessary to press to recommence
drying after the door has been closed.

6. W h en t h e c y c l e i s n e a r in g
completion the machine will enter the
cool down phase, the clothes will be
tumbled in cool air allowing the load to
cool down.

7. Following the completion of the
cycle the drum will rotate intermittently
to m i n i mize c r e asing. T h i s will
continue until the machine is switched
OFF or the door is opened.

8.When the programme is complete
the END indicator will light.

Do not open the door during the automatic

programs in order to obtain a proper drying.

EN

Information for Test Laboratory

EN 61121 Programme To Use

-DRY COTTON

-IRON DRY COTTON

-EASY-CARE TEXTILE

- COTTON OR

-COTTON OR WHITES

-DELICATES OR SYNTHETIC

13

8.

SELECTING THE PROGRAMME AND SET THE FUNCTION

PROGRAM

Baby

Rapid 45'

PROGRAM DESCRIPTION

A comfortable solution to dry laundry of mixed fabrics minimazing
folds, delivering the perfect humidity to iron in the easier way.
Before drying it's better to shake off the linens.

Program Eco normative (hang dry) drying. The most efficient
program in energy consumption. Suitable for cottons and linens.

The right cycle to dry cottons, sponges and towels.

To dry all together different kind of fabrics as cotton ,linen,
mix, synthetics.

To dry delicate and synthetic fabrics that need an accurate
and specific treatment.

This specifics cycle has been conceived to dry shirts minimizing
tangles and folds thanks specific movements of the drum. It's
recommended to take out the linens immediately after drying cycle.

A delicate and specific cycle to dry dark or colour cotton or
syntethics garments.

This cycle is perfect for baby clothes, when an high hygiene level
is expected.

Dedicated to dry uniformly fabrics like jeans or denim. It's
recommended flip over the garments before drying.

Dedicated to technical garments for sport and fitness, drying
gently with special care to avoid shrinking and deterioration
of elastic fibers.

Woolen clothes: the program can be used to dry up to 1 kg of
laundry (around 3 jumpers). It is recommended to reverse all
clothes before drying. Timing can change due to dimensions
and thickness of load and to spinning chosen during
washing. At the end of the cycle, clothes are ready to be
worn, but if they are heavier, edges can be a bit wet: it is
suggested to dry them naturally. It is recommended to
unload clothes at the very end of the cycle. Attention: felting
process of wool is irreversible; please dry exclusively clothes
with symbol (symbol "ok tumble"); this program is not
indicated for acrylic clothes.

Prefect to dry quickly up to 2 kg load . It's racommended to
spin at high speed before drying.

CAPACITY

(kg)

2

Full

Full

4

4

2.5

4

4

4

4

1

1

DRYING

TIME
(min)

*

*

*

*

*

*

*

150’

*

*

70’

*

Relax creases

* The real duration of drying cycle depends by the starting humidity level of the laundry due to spin speed, type
and amount of load, cleanliness of filters and ambient temperature.

This is a warm cycle that in only 12 minutes helps to relaxe folds
and creases.

The perfect cycle to remove the bad smells from the linens
smoothing creases.

Customizable setting that interacts with the App on your android smartphone and to download
the cycles (see the dedicated section). The factory sets the default programme Auto-Hygiene,
which will sanitize the machine.

14

2.5

2.5

12’

*

SMART TOUCH

This appliance is equipped with Smart Touch

technology that allows you to interact, via the
App, with smartphones based on Android
operating system and equipped with NFC
(Near Field Communication) function.

● Download on your smartphone the Candy
simply-Fi App.

● Smart Care – -Smart Check-up and a
troubleshooting guide.

● My Statistics – Drying statistics and
tips for a more efficient use of your
machine.

Get all the details of the Smart Touch
functions, browsing the App in DEMO
mode or go to:
www.candysmarttouch.com

EN

The Candy simply-Fi App is available
for devices running both Android
and iOS, both for tablets and for
smartphones. However, you can
interact with the machine and take
advantage of the potential offered by
Smart Touch only with Android
smartphones equipped with NFC
technology, according to following
functional scheme:

Android smartphone
with NFC technology

Android smartphone
without NFC technology

Android Tablet

Apple iPhone
Apple iPad

Interaction with the
machine + contents

Contents only

Contents only
Contents only

Contents only

FUNCTIONS

The main functions available using the App
are:

● Voice Assistant – A guide to help you
choose the ideal cycle with only three voice
inputs (clothes/fabrics, colour, drying level).

HOW TO USE SMART TOUCH

FIRST TIME - Machine registration

Enter the "Settings" menu of your
Android smartphone and activate the
NFC function inside the "Wireless &
Networks" menu.

Depending on the smartphone model
and its Android OS version, the
process of the NFC activation may be
different. Refer to the smartphone
manual for more details.

● Turn the knob to the Smart Touch
position to enable the sensor on the
dashboard.

● Open the App, create the user profile
and register the appliance following the
instructions on the phone display or the

"Quick Guide" attached on the machine.

More information, F.A.Q. and the video
for an easy registration are available
on:
www.candysmarttouch.com/how-to

● Cycles – To download and launch new

drying programmes.

15

NEXT TIME – Regular usage

● Every time you want to manage the
machine through the App, first you have to
enable the Smart Touch mode by turning
the knob to the Smart Touch indicator.

● Make sure you have unlocked your phone
(from stand-by mode) and you have

activated the NFC function; then, follow the
steps mentioned earlier.

If you do not know the position of your NFC
antenna, slightly move the smartphone in a
circular motion over the Smart Touch logo
until the App confirms the connection. In
order for the data transfer to be successful,
it is essential TO KEEP THE SMARTPHONE
ON THE
FEW SECONDS OF THE PROCEDURE; a
message on the device will inform about the
correct outcome of the operation and advise
you when it is possible to move the
smartphone away.

DASHBOARD THE DURING

● If you want to start a dry cycle, load
the laundry and close the door.

● Select the desired function in the App (e.g.:
starting a programme, the Smart Check­ up cycle, update statistics, etc…).

● Follow the instructions on the phone
display, KEEPING IT ON the Smart Touch
logo on the machine dashboard, when
requested to do so by the App.

NOTES:

Place your smartphone so that the NFC
antenna on its back matches the position
of the Smart Touch logo on the appliance
(as illustrated below).

Thick cases or metallic stickers on your
smartphone could affect or prevent the
transmission of data between machine
and telephone. If necessary, remove them.

The replacement of some components of
the smartphone (e.g. back cover, battery,
etc...) with non-original ones, could result
in the NFC antenna removal, preventing
the full use of the App.

The management and the control of the
machine via App is only possible "by
proximity": it is therefore not possible to
perform remote operations (e.g.: from
another room; outside of the house).

WIRELESS PARAMETERS

Parameter

Wireless Standard

Frequency band

Magnetic field limit

With this the Candy Hoover Group Srl,
declares that this appliance marked with
complies with the essential
requirements of the Directive 2014/53/EU.

To receive a copy of the declaration of
c o nfo r m i ty, p lea s e c o nta c t t h e
manufacturer at:

www.candy-group.com

Specifications

ISO/IEC 14443 Type A and NFC Forum Type 4

13,553-13,567 MHz (centre frequency 13,560 MHz)

< 42dBμA/m (at 10 meters)

16

TROUBLESHOOTING

9.

FOR SMART TOUCH MODELS

The Candy simply-Fi app has a Smart Check-up function that allows you to confirm the
functionality and status of the product at any time. To use the Candy simply-Fi APP you will need
an Android smartphone with NFC technology.

More info can be found on the App.

If the display of the machine is showing an error (by a code or blinking LEDs), you should turn on the
App on your Android smartphone, with NFC on, selecting "Read the error" on the "Help on line"

menu place your smart phone against the Smart Touch logo on the control panel. You should now
be able to read the fault directory to solve the issue.

What Might be the Cause of...

Defects you can remedy yourself

Before calling service for technical advice please
run through the following checklist. A charge will
be made if the machine is found to be working or
has been installed incorrectly or used incorrectly.
If the problem persists after completing the
recommended checks, please call Service, they
may be able to assist you over the telephone.

Time display to end could change during
drying cycle. The time to end is continuously
checked during the drying cycle and the time
is adjusted to give the best estimation time.
The displayed time may increase or decrease
during the cycle and this is normal.

Drying time is too long/clothes are not dry
enough…

● Have you selected the correct drying
time/programme?

● Were the clothes too wet? Were the clothes
thoroughly wrung or spindried?

● Does the filter need cleaning?

● Is the dryer overloaded?

The dryer does not operate…

● Is there a working electricity supply to the
dryer? Check using another appliance such as a
table lamp.

● Is the plug properly connected to the mains
supply?

● Is there a power failure?

● Has the fuse blown?

● Is the door fully closed?

● Is the dryer switched on, both at the mains
supply and at the machine?

● Has the drying time or the programme been
selected?

● Has the machine been switched on again after
opening the door?

The dryer is noisy…

● Switch off the dryer and contact GIAS

Service for advice.

The Indicator is on…

● Does the filter need cleaning?

The Indicator is on…

● Does the water container need

emptying?

CUSTOMER SERVICE

Should there still be a problem with your
dr y er a ft e r c om p le t in g al l t h e
recommended checks, please call
service for advice.
They may be able to assist you over the
telephone or arrange for a suitable
appointment for an engineer to call under
the terms of your guarantee. However, a
charge may be made if any of the
following applies to your machine:

● Is found to be in working order.

● Has not been installed in accordance
with the installation instructions.

● Has been used incorrectly.

Spares

Always use genuine spares, available
direct from service.

Service

For service and repairs call your local
service engineer.

The manuf a cturer declin es all
responsibility in the event of any
printing mistakes in this booklet. The
manufacturer also reserves the right
to make appropriate modifications to
its products without changing the
essential characteristics.

EN

17

Energy

Capacity

Time

Whites

Whites

Cotton

Cotton

Whites

Whites

Whites

Cotton

Cotton

Whites

Capacty (kg)
Class

7 8 9 10

A+ A+ A+ A+

Energy kWh 2,54 2,95 3,23 3,80
Tme Mn. 250 280 330 350
Energy kWh 2,35 2,60 2,82 3,35
Tme Mn. 230 250 300 335
Energy kWh 2,02 2,3 2,56 3,05
Tme Mn. 202 225 260 315
Energy kWh 1,11 1,21 1,31 1,70

½

Tme Mn. 113 133 149 159
Energy kWh 1,58 1,83 2,05 2,44
Tme Mn.

Capacty (kg)
Class

Energy kWh
Tme Mn.

160 180 210 230

7 8 9 10

A++ A++ A++ A++

2,24 2,50 2,75 3,10

250 280 330 379

Energy kWh 2,00 2,20 2,40 2,73
Tme Mn.
Energy kWh

230 250 300 336

1,72 1,94 2,18 2,48

Tme Mn. 202 225 260 305
Energy kWh

½

Tme Mn.
Energy kWh

0,98 1,08 1,15 1,18

113 133 149 152

1,35 1,55 1,74 1,98

Tme Mn. 160 180 210 244

40012735
