Candy CMG 25D CW, CMG 25D CB, CMG 25D CS User Manual

CMG 25D CW
CMG 25D CS CMG 25D CB
MICROWAVE OVENS
FORNI A MICROONDE
MANUALE DI ISTRUZIONI
HORNOS MICROONDAS
MANUAL DE INSTRUCCIONES
GB
IT
ES
GB
Microwave Oven
INSTRUCTION MANUAL
MODEL:
Read these instructions carefully before using your microwave oven, and keep it carefully.
If you follow the instructions, your oven will provide you with many years of good service.
SAVE THESE INSTRUCTIONS CAREFULLY
CMG 25D CW
CMG 25D CS CMG 25D CB
1
GB
CLOCK/PRE-SET
DEFROST BY WEIGHT
DEFROST BY TIME
MICRO/GRILL/COMBI
AUTO MENU
STOP/CLEAR/CHILD LOCK
START/EXPRESS
TIME/WEIGHT
2
GB
PRECAUTIONS TO AVOID POSSIBLE EXPOSURE TO EXCESSIVE MICROWAVE ENERGY
(a) Do not attempt to operate this oven with the door open since this can
result in harmful exposure to microwave energy. It is important not to
break or tamper with the safety interlocks.
(b) Do not place any object between the oven front face and the door or allow
soil or cleaner residue to accumulate on sealing surfaces.
(c) WARNING: If the door or door seals are damaged, the oven must not
be operated until it has been repaired by a competent person.
ADDENDUM
If the apparatus is not maintained in a good state of cleanliness, its surface could
be degraded and affect the lifespan of the apparatus and lead to a dangerous
situation.
Specifications
Model:
Rated Voltage:
Rated Input Power(Microwave):
Rated Output Power(Microwave):
Rated Input Power(Grill): Oven Capacity: Turntable Diameter: External Dimensions(LxWxH): Net Weight:
CMG 25D CW/ CMG 25D CS / CMG 25D CB
230V~50Hz
1450W
900 W
1000W
25L
315mm
511 x395x 284 mm
Approx.16.1 kg
3
GB
4
IMPORTANT SAFETY INSTRUCTIONS
WARNING
To reduce the risk of fire, electric shock, injury to persons or exposure to excessive microwave oven energy when using your appliance, follow basic precautions, including the following:
1. Warning: Liquids and other foods must
not be heated in sealed containers since
they are liable to explode.
2. Warning: It is hazardous for anyone other than a competent person to remove a cover which gives protection against exposure to microwave energy.
3. Warning: Only allow children to use the oven without supervision when adequate instructions have been given so that the child is able to use the oven in a safe way and understand the hazards of improper use.
4. Warning: When the appliance is operated in the combination mode, children should only use the oven under adult supervision due to the temperatures generated. (only for grill series)
5. Only use utensils suitable for use in microwave ovens.
6. The oven should be cleaned regularly and any food deposits should be removed.
7. Read and follow the specific:"PRECAU­ TIONS TO AVOID POSSIBLE EXPOSURE TO EXCESSIVE MICROWAVE ENERGY".
8. When heating food in plastic or paper containers, keep an eye on the oven due to the possibility of ignition.
9. If smoke is observed, switch off or unplug the appliance and keep the door closed in order to stifle any flames.
10. Do not overcook food.
11. Do not use the oven cavity for storage purposes. Do not store items, such as bread, cookies, etc. inside the oven.
12. Remove wire twist-ties and metal handles from paper or plastic containers/bags before placing them in the oven.
13. Install or locate this oven only in accordance with the installation instructions provided.
14. Eggs in the shell and whole hard-boiled eggs should not be heated in microwave ovens since they may explode, even after microwave heating has ended.
15. Use this appliance only for its intended uses as described in manual. Do not use corrosive chemicals or vapors in this appliance. This oven is especially designed to heat. It is not designed for industrial or laboratory use.
16. If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified persons in order to avoid a hazard.
17. Do not store or use this appliance outdoors.
18. Do not use this oven near water, in a wet basement or near a swimming pool.
19. The temperature of accessible surfaces may be high when the appliance is operating. Keep cord away from heated surface, and do not cover any events on the oven.
20. Do not let cord hang over edge of table or counter.
21. Failure to maintain the oven in a clean condition could lead to deterioration of the surface that could adversely affect the life of the appliance and possibly result in a hazardous situation.
22. The contents of feeding bottles and baby food jars shall be stirred or shaken and the temperature checked before consumption, in order to avoid burns.
23. Microwave heating of beverages can result in delayed eruptive boiling, therefore take care when handling the container.
GB
5
24. This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge,unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.
25. Children should be supervised to ensure that they do not play with the appliance.
26.The microwave oven shall not be placed in a cabinet unless it has been tested in a cabinet.
27.Appliances are not intended to be operated by means of an external timer or separate remote-control system.
The rear surface of appliance shall be placed against a wall.
28.
To Reduce the Risk of Injury to Persons Grounding Installation
DANGER
Electric Shock Hazard Touching some of the internal components can cause serious personal injury or death. Do not disassemble this appliance.
WARNING
Electric Shock Hazard Improper use of the grounding can result in electric shock. Do not plug into an outlet until appliance is properly installed and grounded.
CLEANING
Be sure to disconnect the oven from the power supply.
1. Clean the inside of the oven after using with a slightly damp cloth.
2. Clean the accessories in the usual way
in soapy water.
3. The door frame and seal and
neighbouring parts must be cleaned carefully with a damp cloth when they are dirty.
This appliance must be grounded. In the event of an electrical short circuit, grounding reduces the risk of electric shock by providing an escape wire for the electric current. This appliance is equipped with a cord having a grounding wire with a grounding plug. The plug must be plugged into an outlet that is properly installed and grounded.
Consult a qualified electrician or serviceman if the grounding instructions are not completely understood or if doubt exists as to whether the appliance is properly grounded. If it is necessary to use an extension cord , use only a 3-wire extension cord that has a 2-pronged plug with a grounding slot & 2 grounding plates. A 2-slot receptacle, with a grounding prong or grounding terminal(s), will accept the plug of the appliance.
1. A short power-supply cord is provided to reduce the risks resulting from becoming entangled in or tripping over a longer cord.
2. If a long cord set or extension cord is used:
1)The marked electrical rating of the cord set or extension cord should be at least as great as the electrical rating of the appliance.
2)The extension cord must be a grounding­ type 3-wire cord.
3)The long cord should be arranged so that it will not drape over the counter top or tabletop where it can be pulled on by children or tripped over unintentionally
.
GB
6
UTENSILS
CAUTION
Personal Injury Hazard
It is hazardous for anyone other than a compentent person to carry out any service or repair operation that involves the removal of a cover which gives protection against exposure to microwave energy.
See the instructions on "Materials you can use in microwave oven or to be avoided in microwave oven." There may be certain non-metallic utensils that are not safe to use for microwaving. If in doubt, you can test the utensil in question following the procedure below.
Utensil Test:
1. Fill a microwave-safe container with 1 cup of cold water (250ml) along with the utensil in question.
2. Cook on maximum power for 1 minute.
3. Carefully feel the utensil. If the empty utensil is warm, do not use it for microwave cooking.
4. Do not exceed 1 minute cooking time.
Materials you can use in microwave oven
Utensils Remarks
Aluminum foil Shielding only. Small smooth pieces can be used to cover thin parts of
meat or poultry to prevent overcooking. Arcing can occur if foil is too close to oven walls. The foil should be at least 1 inch (2.5cm) away from oven walls.
Browning dish
Dinnerware
Glass jars
Glassware
Oven cooking bags
Paper plates and cups
Paper towels
Parchment paper
Plastic
Plastic wrap
Thermometers Microwave-safe only (meat and candy thermometers). Wax paper Use as a cover to prevent splattering and retain moisture.
Follow manufacturer’s instructions. The bottom of browning dish must be at least 3/16 inch (5mm) above the turntable. Incorrect usage may cause the turntable to break.
Microwave-safe only. Follow manufacturer's instructions. Do not use cracked or chipped dishes.
Always remove lid. Use only to heat food until just warm. Most glass jars are not heat resistant and may break.
Heat-resistant oven glassware only. Make sure there is no metallic trim. Do not use cracked or chipped dishes.
Follow manufacturer’s instructions. Do not close with metal tie. Make slits to allow steam to escape.
Use for short–term cooking/warming only. Do not leave oven unattended while cooking.
Use to cover food for reheating and absorbing fat. Use with supervision for a short-term cooking only.
Use as a cover to prevent splattering or a wrap for steaming.
Microwave-safe only. Follow the manufacturer’s instructions. Should be labeled "Microwave Safe". Some plastic containers soften, as the food inside gets hot. "Boiling bags" and tightly closed plastic bags should be slit, pierced or vented as directed by package.
Microwave-safe only. Use to cover food during cooking to retain moisture. Do not allow plastic wrap to touch food.
GB
7
Materials to be avoided in microwave oven
Utensils Remarks
Aluminum tray Food carton with metal handle Metal or metal­trimmed utensils
Metal twist ties Paper bags Plastic foam
Wood
May cause arcing. Transfer food into microwave-safe dish. May cause arcing. Transfer food into microwave-safe dish.
Metal shields the food from microwave energy. Metal trim may cause arcing. May cause arcing and could cause a fire in the oven. May cause a fire in the oven.
Plastic foam may melt or contaminate the liquid inside when exposed to high temperature.
Wood will dry out when used in the microwave oven and may split or crack.
SETTING UP YOUR OVEN
Names of Oven Parts and Accessories
Remove the oven and all materials from the carton and oven cavity. Your oven comes with the following accessories: Glass tray 1 Turntable ring assembly 1 Instruction Manual 1
F
A
E
G
Warning: Do not use grill rack in microwave mode! Always take it out when using the microwave!
Shut off oven power if the door is opened during operation.
Grill Rack( Only for Grill series )
CB
D
A) Control panel B) Turntable shaft C) Turntable ring assembly D) Glass tray E) Observation window F) Door assembly G) Safety interlock system
Turntable Installation
8
Hub (underside)
Glass tray
Turntable shaft
Turntable ring assembly
a. Never place the tray should never be restricted. b. Both always be used during cooking. c. All food and containers of food are always placed on the
glass tray
d. If breaks, contact your nearest authorized service center.
Countertop Installation
Remove all packing material and accessories. Examine the oven for any damage such as dents or broken door. Do not install if oven is damaged.
GB
glass tray
glass tray
glass tray
and
for cooking.
or
turntable ring assembly
Cabinet: Remove any protective film found on the microwave oven cabinet surface.
Do not remove the light brown Mica cover that is attached to the oven cavity to protect the magnetron.
upside down. The glass
turntable ring assembly
cracks or
must
Installation
Select a level surface that provide
1.
enough open space for the intake and/or outlet vents.
12 inch(30cm)
3.0 inch(7.5cm)
3.0 inch(7.5cm)
A minimum clearance of 3.0 inches (7.5cm) is required between the oven and any adjacent walls. One side must be open. (1) Leave a minimum clearance of 12
inches (30cm) above the oven. (2) Do not remove the legs from the bottom of the oven.
OPEN
(3) Blocking the intake and/or outlet openings
can damage the oven. (4) Place the oven as far away from radios and TV as possible. Operation of microwave oven may cause interference to your radio or TV reception.
2. Plug your oven into a standard household outlet. Be sure the voltage and the frequency is the same as the voltage and the frequency on the rating label.
WARNING: Do not install oven over a range cooktop or other heat-producing appliance. If installed near or over a heat source, the oven could be damaged and the warranty would be void.
The accessible surface may be hot during operation.
GB
9
OPERATION INSTRUCTION
This microwave oven uses modern electronic control to adjust cooking parameters to meet your needs better for cooking.
1.Clock Setting
When the microwave oven is electrified,the oven will display "0:00", buzzer will ring once.
1) Press " ", the hour figures will flah.
2) Turn " " to adjust the hour figures, the input time should be within 0--23.
3) Press " ", the minute figures will flash.
4) Turn " " to adjust the minute figures, the input time should be within 0--59.
5) Press " " to finish clock setting. ":" will flash. Note: 1) If the clock is not set, it would not function when powered.
2) During the process of clock setting, if you press " " or no operation in one minute, the oven will exit the setting.
2. Microwave Cooking
Press " "several times to select the function you want. Turn " " to adjust the cooking time. Press " " to start cooking.
Example: If you want to use 80% power to cook for 20 minutes, you can operate the oven as the following steps.
1) Press " " once, the LED will display "P100", " " indicator will be lighted.
2) Press " " once again to choose 80% power, the LED will display "P80".
3) Turn " " to adjust the cooking time until the oven display"20:00"
(The maximum cooking time is 95 minutes.)
4) Press " " to start cooking, ":" will light and the " " indicator will flash (Buzzer will sound five times after finishing). NOTE: the step quantities for the adjustment time of the coding switch are as follow: 0---1 min : 5 seconds 1---5 min : 10 seconds 5---10 min : 30 seconds
Microwave Power Chart
Press
Microwave Power
Once Twice Thrice 4 times 5 times
80% 50% 30% 10%100%
10---30 min : 1 minute 30---95 min : 5 minutes
GB
10
3. Grill Cooking
1) Press the " " key six times , "G " displays and grill function is selected.
2) Turn " " to adjust the cooking time. The maximum cooking time is 95 minutes.
3) Press the " " key to start cooking. The" " will flash, ":" will be lighted.
Note: If half the grill time passes, the oven pause and beep twice. This is normal. You can just press" " to continue cooking. But in order to have a better effect ofgrilling food,you should turn the food over, close the door, and then press " " to continue cooking. If there is no operation in 1 minute, the oven will continue working and beep once.
4. Combination Cooking
1) Press the " " key for times, " C-1 " or "C-2" display and combination function is selected. " " and " " will light.
2) Turn " " to adjust the cooking time. (The maximum cooking time is 95 minutes.)
3) Press " " key to start cooking. The cooking indicators will flash and ":" will light.
Note: Combination instructions
Instructions
1
2
LED Display
Microwave Power
55%
36%
Grill Power
45%
64%
5. Speedy Cooking
When the oven is in the waiting states, press " " key to start cooking
with full microwave power for 30 seconds. The cooking time will add 30 seconds by every press on " " key,and the maximum setting time is 95 minutes.
Note: Be invalidation under other program during cooking.
6. Defrost by Weight
1) Press " " pad once,the LED will display "dEF1".
2) Turn " " to select the weight of food.At the same time, "g" will light. The weight should be 100-2000g.
3) Press " " key to start defrosting. " " and " " indicators will flash and "g" indicator will go out.
GB
11
7. Defrost By Time
1) Press " " key once, the LED will display "dEF2".
2) Turn " " to select the cooking time. At the same time, " " and " " will be lighted. The time setting is from 00:05 to 95:00.
The default power level is P30. It is not adjustable.
3) Press " " key to start defrosting. " " and " " indicators will flash .
8. Auto Menu
1). In waiting states, press " " to choose the menu you need.
"A-1","A-2"...."A-8" will display in order.
2). Turn " " to select the weight or portion of the menu.
3) Press " " to start cooking. When cooking finish, buzzer will sound five times. If the clock has been set before, the current time will be displayed, otherwise, 0:00 will be displayed.
For example: to cook the pasta of 150g.
1) Press " " for three times, "A-3" displays and pasta menu is selected. " " and " " indicator will light.
2). Turn " " to select the weight of the menu. Stop turning when "150" displays.
3) Press " " to start cooking.
When cooking finish, buzzer will sound five times. Then turn back to waiting states.
9.Multi-Stage Cooking
Two stages of cooking can be maximumly set. If one stages is defrosting, it will be put in the first stage automatically. The buzzer will ring once after each stage and the next stage will begin. Note: Auto menu cannot be set as one of the multi-stage.
Example: if you want to defrost the food of 500g + 80% microwave power for 5 minutes. The steps are as following:
1) Press " ", "dEF1" displays;
2) Turn " " to adjust the weight of the food. Stop turning when "500" displays;
3) Press" " twice to choose 80% microwave power;
4) Turn " " to adjust the cooking time of 5 minutes;
5) Press " " to start cooking. Note: When the first stage finish, buzzer sounds once then the second stage
begins. back to the waiting
When all of them finish, buzzer sounds five times and the unit turn
states.
GB
12
10. Pre-set Function
1) Set the clock first. (Consult the instruction of clock setting.)
2) Input the cooking program. Two stages can be set at most. Defrosting
should not be set here.
3) Press " ". The current clock is displayed. The hour figure flash;
4) Turn " " to adjust the hour figures, the input time should be within
0--23.
5) Press " ", the minute figures will flash.
6) Turn " " to adjust the minute figures, the input time should
be within 0--59.
7) Press " " to finish setting. ":" will light, buzzer will
ring twice when the time arrives, then cooking will start automatically. Note: 1) Clock must be set first. Otherwise,pre-set function will not work.
2) If the pre-set program has been set without the cooking program,
the whole setting will be used as an alarm clock. That means when
pre-set time arrives, buzzer will sound five times only.
11. Inquiring Function
(1) In cooking state, press " ", the current microwave power will be displayed for 3 seconds. (2) In pre-set state, press " " to inquire the time for delay start cooking. The pre-set time will flash for 3 seconds, then the oven will turn back to the clock display. (3) During cooking state, press " " to check the current time. It will be displayed
for 3 seconds.
12. Lock-out Function for Children
Lock: In waiting state, press " " for 3 seconds, there will be a long "beep" denoting entering into the children-lock state and LED will display " " and "
Lock quitting: In locked state, press " " for 3 seconds, there will be a long "beep" denoting that the lock is released, and LED will turn back to the clock stae, "
" will light.
" will go out.
GB
13
13. Protection of Fan
When the microwave or combination cooking works over 5 minutes, it stops working at the last 15 seconds, only fan runs.
14. Protection Function of Magnetron Control Pipe
When the unit runs for 30 minutes with high power level, it will adjust to 80% microwave power to protect the magnetron control pipe. This function works under multi-stage and other states.
15. Automatic Going Out Function
When the door is kept open for 10 minutes, the oven light will be off. Press any key after opening the door, time will count down again. The oven lamp will light.
16. Specification
(1) The buzzer will sound once when turning the knob at the beginning; (2) " " must be pressed to continue cooking if the door is opened during cooking; (3) Once the cooking programme has been set , " " is not pressed
in 1 minute. The current time will be displayed. The setting will be cancelled.
(4) The buzzer sounds once by efficient press, inefficient press will be no responce.
Auto menu Chart
14
GB
Menu
A-1
AUTO REHEAT
A-2
VEGETABLE
A-3
PASTA
A-4
MEAT
A-5
PIZZA
A-6
POTATO
A-7
FISH
A-8
SOUP
Weight(g)
150
250
350
400
150
350
500
50(with water 450g)
100(with water 800g)
150(with water 1200g)
150
300
450
600
1(About 80g)
2(About 160g)
3(About 250g)
1(About 220 10g)
2(About 440 10g)
3(About 660 10g)
+
+
+
150
250
350
400
450
500
750
1000
Display
150
250
350
400
150
350
500
50
100
150
150
300
450
600
1
2
3
1
2
3
150
250
350
400
450
500
750
1000
Trouble shooting
15
GB
It is forbidden to run the unit without any food inside. It is very dangerous.
CUSTOMER ASSISTANCE SERVICE If you cannot identify the cause of the operating anomaly: switch off the appliance (do not subject it to rought treatment) and contact the Assistance Service. PRODUCT SERIAL NUMBER. Where can I find it? It is important that you to inform the Assistance Service of your product code and its serial number (a 16 character code which begins with the number 3); this can be found on the guarantee certificate or on the data plate located on the appliance. It will help to avoid wasted journerys to technicians, thereby (and most significantly) saving the corresponding callout charges.
GB
16
applicable collection point for the recycling of electrical and electronic equipment Disposal must be carried out in accordance with local environmental regulations for waste disposal. For more detailed information about treatment, recovery and recycling of this product, please contact your local city office, your household waste disposal service
or the shop where you purchased the product
This appliance is marked according to the European directive 2002/96/EC on Waste Electrical and Electronic Equipment (WEEE). By ensuring this product is disposed of correctly, you will help prevent potential negative consequences for the environment and human health, which could otherwise be caused by inappropriate waste handling of this product. The symbol on the product indicates that this product may not be treated as household waste. Instead it shall be handed over to the
.
GB
17
Cooking Guide
MICROWAVES
Microwave energy actually penetrates food, attracted and absorbed by its water, fat and sugar content. The microwaves cause the molecules in the food to move rapidly. The rapid movement of these molecules creates friction and the resulting heat cooks the food.
COOKING
Cookware for microwave cooking:
Cookware must allow microwave energy to pass through it for maximum efficiency. Microwaves can penetrate through ceramic, glass, porcelain and plastic as well as paper and wood, but they are reflected by metal, such as stainless steel, aluminium and copper. So food must never be cooked in metal containers.
Foods suitable for microwave cooking:
Many kinds of food are suitable for microwave cooking, including fresh or frozen vegetables, fruit, pasta, rice, grains, beans, fish, and meat. Sauces, custard, soups, steamed puddings, preserves, and chutneys can also be cooked in a microwave oven. Generally speaking, microwave cooking is ideal for any food that would normally be prepared on a hob.
Covering during cooking
To cover the food during cooking is very important, as the evaporated water rises as steam and contributes to cooking process. Food can be covered in different ways: e.g. with a ceramic plate, plastic cover or microwave suitable cling film.
Standing times
After cooking is over food the standing time is important to allow the temperature to even out within the food.
GB
18
Cooking Guide
Cooking Guide for frozen vegetables
Use a suitable glass pyrex bowl with lid. Cook covered for the minimum time - see table. Continue cooking to get the result you prefer. Stir twice during cooking and once after cooking. Add salt, herbs or butter after cooking. Cover during standing time..
Food Portion Power
Spinach
Broccoli
Peas Green Beans
Mixed Vegetables (carrots/peas/ corn)
Mixed Vegetables (Chinese style)
150g P80 5-6 2-3
300g P80 8-9 2-3
300g P80 7-8 2-3 300g P80 7½-8½ 2-3
300g P80 7-8 2-3
300g P80 7½-8½ 2-3
Time
(min. )
Standing
Time (min. )
Instructions
Add 15 ml (1 tablespoon) cold water.
Add30ml(2tbsp.)cold water.
Add15ml(1tbsp.)cold water.
Add30ml(2tbsp.)cold water.
Add15ml(1tbsp.)cold water.
Add15ml(1tbsp.)cold water.
GB
19
Cooking Guide
Cooking Guide for fresh vegetables
Use a suitable glass pyrex bowl with lid. Add 30-45 ml cold water (2-3 tbsp.) for every 250 g unless another water quantity is recommended - see table. Cook covered for the minimum time - see table. Continue cooking to get the result you prefer. Stir once during and once after cooking. Add salt, herbs or butter after cooking. Cover during a standing time of 3 minutes.
Hint: Cut the fresh vegetables into even sized pieces. The smaller they
All fresh vegetables should be cooked using full microwave power (P100).
Food
Broccoli Brussels
Sprouts Carrots
Cauliflower
Courgettes
Egg Plants Leeks
Mushrooms
Onions Pepper
Potatoes
Turnip Cabbage
are cut, the quicker they will cook.
Portion
250g 500g
250g 5-5½ 3 250g 3½-4 3 250g
500g
250g 3-3½ 3
250g 2½-3 3 250g 3-3½ 3
125g 250g
250g 4-4½ 3 250g 3½-4 3 250g
500g
250g
Time
(min. )
3½-4
4-4½
6½-7½
1-1½ 2-2½
4½-5
6-7
3-4 6-7
Standing
Time (min. )
3
3
3
3
3
Prepare even sized florets. Arrange the stems to the centre.
Add 60-75 ml (5-6 tbsp.) water. Cut carrots into even sized slices.
Prepare even sized florets. Cut big florets into halves. Arrange stems to the centre.
Cut courgettes into slices. Add 30 ml (2 tbsp.) water or a knob of butter. Cook until just tender.
Cut egg plants into small slices and sprinkle with 1 tablespoon lemon juice.
Cut leeks into thick slices. Prepare small whole or sliced
mushrooms. Do not add any water. Sprinkle with lemon juice. Spice with salt and pepper. Drain before serving.
Cut onions into slices or halves. Add only 15 ml (1 tbsp.) water.
Cut pepper into small slices. Weigh the peeled potatoes and cut
them into similar sized halves or quarters.
Cut turnip cabbage into small cubes.
Instructions
GB
20
Cooking Guide
Cooking Guide for rice and pasta
Rice: Use a large glass pyrex bowl with lid - rice doubles in volume during
Pasta: Usea large glass pyrex bowl. Add boiling water, a pinch of salt and
Food Portion Power
White Rice (parboiled)
Brown Rice (parboiled)
Mixed Rice (rice + wild rice)
Mixed Corn (rice + grain)
Pasta
cooking. Cook covered. After the cooking time is over, stir before standing time and salt or add herbs and butter. Remark: the rice may not have absorbed all water after the cooking time is finished.
stir well. Cook uncovered. Stir occasionally during and after cooking. Cover during standing time and drain thoroughly afterwards.
Time
(min. )
250g
P100
375g 250g
P100
375g
250g P100 16-17 5
250g P100 17-18 5 250g P100 10-11 5
15-16 17½-
18½
20-21 22-23
Standing
Time (min. )
5
5
Instructions
Add 500 ml cold water. Add 750 ml cold water.
Add 500 ml cold water. Add 750 ml cold water.
Add 500 ml cold water.
Add 400 ml cold water. Add 1000 ml hot water.
REHEATING
Your microwave oven will reheat food in a fraction of the time that conventional ovens hobs normally take. Use the power levels and reheating times in the following chart as a guide. The times in the chart consider liquids with a room temperature of about +18 to +20°C or a chilled food with a temperature of about +5 to +7°C.
Arranging and covering
Avoid reheating large items such as joint of meat - they tend to overcook and dry out before the centre is piping hot. Reheating small pieces will be more successful.
Power levels and stirring
Some foods can be reheated using maximum powerwhile others should be reheated using lower power.
Check the tables for guidance. In general, it is better to reheat food using a lower power level, if the food is delicate, in large quantities, or if it is likely to heat up very quickly (mince pies, for example). Stir well or turn food over during reheating for best results. When possible, stir again before serving.
GB
21
Cooking Guide
Take particular care when heating liquids and baby foods. To prevent eruptive boiling of liquids and possible scalding , stir before, during and after heating. Keep them in the microwave oven during standing time. We recommend putting a plastic spoon or glass stick into the liquids. Avoid overheating (and therefore spoiling) the food. It is preferable to underestimate cooking time and add extra heating time, if necessary.
Heating and standing times
When reheating food for the first time, it is helpful to make a note of the time taken - for future reference. Always make sure that the reheated food is piping hot throughout. Allow food to stand for a short time after reheating - to let the temperature even out. The recommended standing time after reheating is 2-4 minutes, unless another time is recommended in the chart.. Take particular care when heating liquids and baby food. See also the chapter with the safety precautions.
REHEATING LIQUIDS
Always allow a standing time of at least 20 seconds after the oven has been switched off to allow the temperature to even out. Stir during heating, if necessary, and ALWAYS stir after heating. To prevent eruptive boiling and possible scalding, you should put a spoon or glass stick into the beverages and stir before, during and after heating.
REHEATING BABY FOOD
BABY FOOD:
Empty into a deep ceramic plate. Cover with plastic lid. Stir well after reheating! Let stand for 2-3 minutes before serving. Stir again and check the temperature. Recommended serving temperature: between 30-40°C.
BABY MILK:
Pour milk into a sterilised glass bottle. Reheat uncovered. Never heat a baby’s bottle with teat on, as the bottle may explode if overheated. Shake well before standing time and again before serving ! Always carefully check the temperature of baby milk or food before giving it to the baby. Recommended serving temperature: ca. 37°C.
REMARK:
Baby food particularly needs to be checked carefully before serving to prevent burns. Use the power levels and times in the next table as a guide lines for reheating.
GB
22
Cooking Guide
Reheating Liquids and Food
Use the power levels and times in this table as a guide lines for reheating.
Standing
Food Portion Power
150 ml
Drinks (coffee,milk, tea, water with room temperature)
Soup (chilled)
Stew (chilled)
Pasta with sauce (chilled)
Filled pasta with sauce (chilled)
Plated Meal (chilled)
(1cup) 300 ml
(2cups)
450 ml
(3cups)
600 ml
(4cups)
250g 350g 450g 550g
350g P80
350g P80 3½-4½ 3
350g P80
350g 450g 550g
P100
P100
P80
Time
(min. )
1-1½
1½-2
2½-3
3-3½
2-2½ 2½-3 3-3½ 3½-4
4½-5½ 2-3
4-5 3
4½-5½
5-6
5½-6½
Time
(min. )
1-2
2-3
Instructions
Pour into a c eramic cup and reheat uncovered. Place 1 cupinthecentre,2 opposite of each other and 3 or 4 in a circle. Stir carefully before and after standing time, be careful while taking them out of oven.
Pour into a deep ceramic plate or deep ceramic bowl. Cover with plastic lid. Stir well after reheating. Stir again before serving.
Put stew in a deep ceramic plate. Cover with plastic lid.Stir occasionally during reheating and again before standing and serving.
Put pasta (e.g. spaghetti or egg noodles) on a flat ceramic plate. Cover with microwave cling film. Stir before serving.
Put filled pasta (e.g. ravioli, tortellini) in a deep ceramic plate. Cover with plastic lid. Stir occasionally during reheating and again before standing and serving.
Plate a meal of 2-3 chilled components on a ceramic
3
dish. Cover with microwave cling-film.
GB
23
Cooking Guide
Reheating Baby Food and Milk
Use the power levels and times in this table as guide lines for reheating.
Food Portion Power Time
Baby food (vegetables + meat)
Baby porridge (grain + milk + fruit)
Baby milk
190g P80 30sec. 2-3
190g P80 20sec. 2-3
100ml
P30
200ml
30-40
sec.
1min.
to
1min.
10 sec.
Standing
Time
(min. )
2-3
Instructions
Empty into ceramic deep plate. Cook covered. Stir after cooking time. Stand for 2-3 minutes. Before serving, stir well and check the tem- perature carefully.
Empty into ceramic deep plate. Cook covered. Stir after cooking time. Stand for 2-3 minutes. Before serving, stir well and check the tem- perature carefully.
Stir or shake well and pour into a sterilised glass bottle. Place into the centre of turntable. Cook uncovered. Shake well and stand for at least 3 minutes. Before serving, shake well and check the tempera- ture carefully.
GB
24
Cooking Guide
RILL
G
The grill-heating element is located underneath the ceiling of the cavity. It operates while the door is closed and the turntable is rotating. The turntable’s rotation makes the food brown more evenly. Preheating the grill for 4 minutes will make the food brown more quickly.
Cookware for grilling:
Should be flameproof and may include metal. Do not use any type of plastic cookware, as it can melt.
Food suitable for grilling:
Chops, sausages, steaks, hamburgers, bacon and gammon rashers, thin fish portions, sandwiches and all kinds of toast with toppings.
IMPORTANT REMARK:
Please remember that food must be placed on the high rack, unless another instruction is recommended.
MICROWAVE + GRILL
This cooking mode combines the radiant heat that is coming from the grill with the speed of microwave cooking. It operates only while the door is closed and the turntable is rotating. Due to the rotation of the turntable, the food browns evenly.
Cookware for cooking with microwave + grill
Please use cookware that microwaves can pass through. Cookware should be flameproof. Do not use metal cookware with combination mode. Do not use any type of plastic cookware, as it can melt.
Food suitable for microwave + grill cooking:
Food suitable for combination mode cooking include all kinds of cooked food which need reheating and browning (e.g. baked pasta), as well as foods which require a short cooking time to brown the top of the food. Also, this mode can be used for thick food portions that benefit from a browned and crispy top (e.g. chicken pieces, turning them over half way through cooking). Please refer to the grill table for further details.
The food must be turned over, if it is to be browned on both sides.
GB
25
Cooking Guide
Grill Guide for fresh food
Preheat the grill with the grill-function for 4 minutes.
Use the power levels and times in this table as guide lines for grilling.
Fresh Food Portion Power
Toast Slices
Bread Rolls (already baked)
Grilled Tomatoes
Tomato­Cheese Toast
Toast Hawaii (pineapple, ham,cheese slices)
Baked Potatoes
Gratin Potatoes/ vegetables (chilled)
Chicken Pieces
Roast Chicken
4pcs
(each25g
2-4
pieces
200g
(2pcs)
400g
(4pcs)
4pcs
(300g)
2pcs
(300g)
4pcs
(600g)
250g 500g
500g C1
450g
(2pcs)
650g
(2-3pcs)
850g
(4pcs)
900g
1100g
Grill
only
)
Grill
only
C2
C2 4-5 -
C1
C1
C2
C1 10-12
1. Side
3½-4½ 3-4
2½-3½ 1½-2½
3½-4½
3½-4½
4½-5½ 6½-7½
2. Side Time (min)
5-6
6-7
9-11 -
7-8
9-10
11-12
12-14
Time (min)
Putthe toast slices side by side on the rack.
Put bread rolls first with the bottomsideupinacircle directly on the turntable.
Cut tomatoes into halves. Put some cheese on top. Arrange
-
in a circle in a flat glass pyrex dish. Place it on the rack.
Toast the breas slices first. Put the toast with topping on the rack. Stand for 2-3 minutes.
Toast the bread slices first. Put the toast with topping on the rack. Put 2 toasts opposite
­directly on the rack. Stand for
2-3 minutes. Cut potatoes into halves. Put
theminacircleontherackwith
­the cut side to the grill.
Putthefreshgratinintoasmall glass Grill pyrex dish. Put the dish on the rack. After cooking stand for 2-3 minutes.
Brush chicken pieces with oil
7-8
and spices. Put them in a circle with the bones to the middle. Put one chicken piece not into
8-9
thecentreofthe rack. Standfor 2-3 minutes.
9-10
Brush chicken with oil and spices. Put chicken first breast side down, second side breast
9-11
side up directly on turntable.
11-13
Stand for 5 minutes after grilling.
Instructions
Cooking Guide
26
Grill Guide for fresh food
Fresh Food Portion Power
Lamb Chops (medium)
Pork Steaks
Roast Fish
Baked Apples
400g
(4pcs)
250 g
(2pcs)
500 g
(4pcs)
450g 650g
2 apple
(ca.400g)
4 apples
(ca.800g)
Grill only
MW +
Grill
C2
C2
GB
1. Side Time (min)
10-12 8-9
10-12
C2
6-7
8-10
6-7 7-8
6-7
2. Side Time
(min)
(Grill only)
Instructions
Brush the lamb chopswith oil and spices. Lay them in a circle on the rack.After grilling stand for 2-3 minutes.
Brush the pork steakswith oil and spices. Lay them in a circle on the rack. After
5-6
grilling stand for 2-3 minutes.
7-8
Brush skin of whole fish with oil and herbs and spices. Put
7-8
fish side by side (head to tail)
8-9
on rack. Core the apples and fill them
with raisins and jam. Put some almond slices on top.
-
Put apples on a flat glass pyrex dish. Place the dish directly on the turntable.
GB
27
Cooking Guide
Grill Guide for frozen food
Use the power levels and times in this table as guide lines for grilling.
Fresh Food Portion Power
Bread Rolls (each ca. 50 g)
Baguettes/ Garlic Bread
Gratin (vegetables or potatoes)
Pasta (Cannelloni, Macaroni, Lasagne)
Fish Gratin 400g C1
2pcs 4pcs
200-250g
(1pc)
400g C1
400g C1 14-16 -
MW+
Grill
MW+
Grill
1. Side
2. Side
Time
(min)
C2
1½-2 2½-3
C1
3½-4
13-15 -
16-18 -
Time
(min)
Instructions
Arrange rolls in a circle with the bottom side up
Grill
directly on the turntable.
only
Grill the second side of
2-3
the rolls up to the crisp
2-3
you prefer. Stand for 2-5 minutes.
Put frozen baguette diagonally on baking
Grill
paper on the rack. After
only
grilling stand for 2-3
2-3
minutes. Put frozen gratin into a
small glass pyrex dish. Put the dish on the rack. After cooking stand for 2­3 minutes.
Put frozen pasta into a small flat rectangular glass pyrex dish. Put the dish directly on the turntable. After cooking stand for 2-3 minutes.
Put frozen fish gratin into a small flat rectangular glass pyrex dish. Put the dish directly on the turntable. After cooking stand for 2-3 minutes.
GB
28
Using the CrustyPlate
Your CANDY microwave oven has a crusty plate as an additional accessory.
This crusty plate allows you to brown food not only on the top with the grill, but also the bottom of the food turns crispy and brown due to the high temperature of the crusty plate.
Several items which you can prepare on the crusty plate can be found in the chart (see next page).
The crusty plate can also be used for bacon, eggs, sausages, etc.
1. Place the crusty plate directly on the turntable and preheat itwithhighestMicrowave-Grill-Combination[600W+Grill]by following the times and instructions in the chart.
Always use oven gloves to take out the crusty plate, as
it is becomming very hot.
2. Brush the plate with oil if you are cooking food, such as bacon and eggs, in order to brown the food nicely.
Please note that the crusty plate has a teflon layer
which is not scratch-resis tant. Do not use any sharp objects like a knife to cut on the crusty plate.
Use plastic accessories to avoid scratches on the
surface of the crusty plate or remove the food from the plate before cutting
3. Place the food on the crusty plate.
Do not place any objects on the crusty plate that are
not heat-resistant; e.g. plastic bowels.
Never place the crusty plate in the oven without
turntable.
4. Place the crusty plate on the metal rack(or turntable) in the microwave.
5. Select the appropriate cooking time and power. Refer to the table on the next page.
GB
Using the CrustyPlate
How to clean the Crusty Plate
Clean the crusty plate with warm water and detergent and rinse off with clean water.
Do not use a scrubbing brush or a hard sponge otherwise the top layer will be damaged.
Please Note
The crusty plate is not dishwasher-safe.
29
Loading...
+ 73 hidden pages
