CANDY CDNF 3800 E User Manual

INSTRUCTIONS MANUAL

REFRIGERATOR

DOUBLE DOORS

CDNF 3800 E

ENGLISH

Page…1

ITALIAN Pagina…13

FRENCH Page…25

DEUTSCH

Seite…36

SPANISH

Página…48

PORTOGUESE

Página…60

GREEK Σελίδα…72

POLISH Strona…84

CZECH Strana…96

RUMANIAN Pagina…108

HUNGARIAN Oldal…120

SLOVAK Strana…132 CROATIAN

Stranica…144

Please always follow the safety hint listed below:

The unit should be operated in the absence of flammable or explosive fumes. It is prohibited to put the flammable, acid or volatile goods in cabinet.

Please unplug the unit first when you replace the light bulb or repair the refrigerator.

Please unplug the unit immediately if you find any abnormal smell or smoke, and contact your local service center.

Please don’t allow water on the cabinet, or put a vessel full of water on the refrigerator. If the refrigerator is wet, the electrical insulation capability may be weakened.

Hanging or sitting on the door is very dangerous, it may overturn the unit and subvert the goods in (or on) the refrigerator.

SAFETY PRECAUTIONS

ENGLISH

Due to the production’s improvement, the unit you purchased maybe different from below sketch.

1. Freezer shelf

2. Control House freezer

3. Control House refrigerator

4. Shelf

5. Power plug

6. Crisper

7. Freezer door tray

8. Door shelve

9. Bottles door tray

10. Feet

PARTS

The unit should be placed in a ventilated and dry environment. Do not put the unit in direct sunshine, and keep it as far as possible from heat sources.

The unit should be placed on flat and steady ground. Keep the unit level by adjusting the front leg levellers.

Don’t put the unit in cold area.

There should be enough spare space around the unit as shown, to allow proper ventilation.

PLACEMENT

690mm

1284 mm

600m m

965mm

Make sure the unit has been placed properly and all instructions have been observed.

Adjust the control knob to the middle position, and then plug in the unit.

OPERATION CHECK

The temperature in the fresh compartment is between 0~10 C, although this lower temperature can limit the bacteria propagation, it is not suitable for a long period of food storage.

FRESH FOOD STORAGE Do not place hot food directly into the refrigerator. The internal temperature will increase and force the compressor to work harder and will consume more energy.

It is better to put the food in a sealed bag before placing into the refrigerator.

In order to keep vegetables fresh in the crisper, any water should be removed first, otherwise the vegetables may spoil. If you put the vegetables in a bag, they may be stored for a longer period.

FOOD STORAGE

Control knob

It is used to adjust the temperature of different compartment. User can adjust for desired temperature.

User can adjust the temperature of cooling or freezing by turn-control knob located at the back of the cooling zone cabinet. According to the above picture, the highter knob is used for controlling temperature of freezing while the lower one is for cooling. Temperature shall get lower if turning the knobs by clockwise sense while it will get higher if anticlockwise.

ATTENTION:

When the freezer control knob is set at “7”, you can turn the control knob of the fresh food compartment to “4” or even smaller number to avoid too low storage temperature.

FROZEN FOOD STORAGE

The temperature of the freezer is colder than -18C. It is to store food to be kept for a long period.

After buying frozen food, please put it into the freezer compartment as soon as possible.

FOOD STORAGE

Any hot food must be cooled down to room temperature before to put into the freezer.

Please don’t put glass containers filled with liquid into the freezer compartment as the liquid into the freezer compartment as the glass may break.

It is better to pre-sort the foods before putting them into the freezer. Put the same kinds of food together to help to minimize the time of the freezer door opening when you take the food out, and helps to save energy.

The food should not be put too close to the outlet or inlet of the airflow. It may affect the air circulation.

DOOR TRAY

There are some ventilation holes on the bottom of the door tray, please try not to block all of them when you put the food in.

FOOD STORAGE

Cleaning

Always unplug the unit before cleaning. The unit should be cleaned frequently both inside and outside using water and a little neutral detergent . never use boiling water, harsh cleaning agents, acid, alkali or benzene etc.

Water pan cleaning

The water pan is located in the back of cabinet. Its function is to collect and evaporate the defrost water. Usually it doesn’t need special care , but if you find some water overflow or odd smell, it may need to be checked and cleaned . pull out the power cord first . lift the water pan up a little , and then pull it straight out carefully (caution make sure the discharge pipe is not too hot) after cleaning , re-fix the water pan into the original position .Make sure that the pipe is on top of the water pan before you push it into the original position.

Leaving the unit switched off

If the unit will be switched off for a long time ,the plug should be pulled out , then clean the unit thoroughly . Ensure that the door cannot be fully closed (leave a suitable gap), and place the unit in a well-ventilated area to avoid any odor.

MAINTENANCE

Before calling for service , please check the following issues first:

1. WHEN THE REFRIGERATOR DOES NOT WORK

Check if there is a power failure. Check if the power plug is plugged into the power outlet. Check that the fuse has not blown.

2. WHEN THE REFRIGERATOR IS COOLING EXCESSIVELY

The temperature control dial may be set too high. If you place foodstuffs containing a lot of moisture directly under the cool air outlets, they will freeze easily. This does not indicate a malfunction.

3. WHEN THE REFRIGERATOR IS NOT COOLING SUFFICIENTLY

The food may be packed too tightly together which will block the flow of cool air. You may have put something hot or a lot of foodstuffs into the refrigerator . The door may not have been closed properly. The door gaskets may be damaged. The refrigerator may not be ventilated. There may be insufficient clearance between the refrigerator and the surfaces immediately both sides and above. The temperature control dial may not be set properly.

4. WHEN THE DEFROSTING WATER OVERFLOWS INSIDE THE REFRIGERATOR AND ONTO THE FLOOR.

Check that the drain pipe and the drain hose are not clogged. Check that the drain pan is housed properly.

5. WHEN CONDENSATION FORM ON THE OUTSIDE OF THE REFRIGERATOR

Condensation may form on the outside when the humidity is high such as during a wet season. This is the same result as the condensation formed when chilled water is poured into a glass. It does not, therefore, indicate a failure, wipe dry with a dry cloth.

6. WHEN YOU HEAR A SOUND LIKE WATER FLOWING

A sound like water flowing is the refrigerant flowing. It does not Indicate a malfunction.

7. WHEN THE CABINET'S SIDE PANEL HEATS UP

The side panel of the cabinet will heat up when the door is opened or closed frequently, when starting the unit and when the unit operates in summer with high ambient outside temperature, In such case, do not touch the panel, it results from the dissipation of the heat from inside the cabinet, and it does not mean that something is wrong with the refrigerator.

TROUBLE SHOOTING

FOLLOWING PHENOMEN IS NORMAL

• The sound like a rivulet is caused by refrigerant flowing inside of the system pipe.

• While the unit runs, heat is emitted from both sides of the cabinet.

• When the environment is too humid, the edges around door may have a little of

moisture, wipe it with a dry cloth.

Change the light bulb

Before changing the light bulb, please unplug the refrigerator first, then pull down the light cover and change the light bulb according to the picture. Make sure the light bulb is220-240V~/50Hz/10W.

TROUBLE SHOOTING
