DISHWASHER

32000219 CD222AS

Service Manual

395

299

208

208a

200

217

225

209

117

296

127

272

122

313

126

295b

287

297

295a

333

495

IELS2521

32000219 CD222AS 0530 (18/07/2005)

Ricambio Part No. Piece

Ref. Descrizione - Description - Beschreibung - Descripcion

4a Right basket guide 41017657 0718 (02/05/2007)

4b Left basket guide 41017656 0718 (02/05/2007)

8a Foot 41001349

12 Spring 91408705

14 Button 91601285

16 Timer knob 41011633

21 Control panel assy 41016793

27 Closure regulator 91800770

28 Catch 41014449

29 Screw 41005335

36 Work table 91670501 0635 (29/08/2006) 36 Work table 41020020 0635 (29/08/2006)

44 Door lock 41008620

E-Teil Pieza

Inizio Beginning Debut Begin Inicio

Fine Ending Fin End Fin

45 Lower protection 91600125

54a Innerdoor lower gasket 91620003

55 Front gasket 41010838 0718 (02/05/2007) 55 Front gasket 41019164 0718 (02/05/2007)

56 Special screw 92419530

58 L/H gasket holder 91617514 0718 (02/05/2007)

59 Cornet f.gasket 92605757 0630 (24/07/2006)

60 Upper gasket holder 91617530 0630 (24/07/2006) 60 Upper gasket holder 41019290 0630 (24/07/2006) 0718 (02/05/2007)

66 R/H gasket holder 91617522 0718 (02/05/2007)

69 Insulating panel 91600504

79 Rear foot 92685734

84 L/H hinge holder 41007154

84a R/H hinge holder 41007153

85a R/H hinge 41007189

85b L/H hinge 41007190

92 Innerdoor 41010279

92a Innerdoor screw 91401201

93 Door 91800208

32000219 CD222AS 0530 (18/07/2005)

Ricambio Part No. Piece

Ref. Descrizione - Description - Beschreibung - Descripcion

100 Electrodistributor 41010202

103 Gasket 49004681

117 Nozzle 92694801

122 Gasket 91620012

126 Seal gasket 91620014

127 Metal ring 91600586

133 Clip 92470012

134 Electrovalve 41009561

135 Gasket 41015227

138 Drain hose 91670102

138a Drain house elbow 92689587

138b Hoseb clamp 91600328

E-Teil Pieza

Inizio Beginning Debut Begin Inicio

Fine Ending Fin End Fin

141 Seal gasket 92485226

142b Safety fill hose 92968155

148a Outer heater assy 41006831

150 Door micro switch 41009693

151a Electronic module 41016991 0615 (14/04/2006) 151a Electronic module 41016751 0615 (14/04/2006)

152f Switch as.(unipol.switch) 91201694

153 Level switch 41016499

155e LED 41011650

157 Wiring harness 41014671 0615 (14/04/2006) 157 Wiring harness 41017979 0615 (14/04/2006)

157e 6 Way connecton 41016761

157i 4 Way connecton 41011680

161 Drain pump 91200173

161a Drain pump scroll 91600290

164 Anti jamming filter radio 91200489

171 Motor pump 41014580 0608 (22/02/2006) 171 Motor pump 41010872 0608 (22/02/2006) 0613 (27/03/2006) 171 Motor pump 41014580 0613 (27/03/2006)

172 Clip 91408000

173 Hose 41015226

32000219 CD222AS 0530 (18/07/2005)

Ricambio Part No. Piece

Ref. Descrizione - Description - Beschreibung - Descripcion

177 Motor Schoch absorber 92131762

200 Drawer grasket 91406300

204a Upper spray arm 41009782

204b Lower spray arm 41009781

205 Spray arms tube 41006828

208 Filter 41005927

208a Microfilter 41014367

209 Filter plate 91800738

217 Filter bacin. 91670113

218 OR seal gasket 91406302

225a Thermostat Gasket 92445626

241 Lower basket wheel 91601039

E-Teil Pieza

Inizio Beginning Debut Begin Inicio

Fine Ending Fin End Fin

243 Lower basket 92992478

244 Upper basket 41009336

244a Plates holder 41008446

245 Basket wheel pin 92608637

246 Basket wheel upper. 92655596

249a R/H front-L/H rear cups basket 41000749

249b L/H front-R/H rear cups basket 41000750

250 Wheel stopper 91619627

251 Runner 91800137

257 Cutlery basket 92965912

269e Trasparent front plate strip 41011126

272 Clip 92470244

275 Level hose 49003248

280 Clip 92470202

283a Hub 41009859

284 Tub assy 41006826 0630 (24/07/2006)

287m NTC probe 92743616

290 Bearing for spray arm 91405300

295a Water softener 91200504 0615 (14/04/2006)

32000219 CD222AS 0530 (18/07/2005)

Ricambio Part No. Piece

Ref. Descrizione - Description - Beschreibung - Descripcion

295a Water softener 41017403 0615 (14/04/2006)

295b Water softener OR seal gasket 91941698

296 Water softener stopper 91670172

297 Hose 91620010

299 Water softener capacitor 41010398

305 Spring 92483809

311 Sleeve 91602981

311a Sleeve 41010216

314 Slider 91600272

315 Spring 92484021

316 Center square 91600271

318 Upper ramp tube 41009353

321a Deviator 41009202

E-Teil Pieza

Inizio Beginning Debut Begin Inicio

Fine Ending Fin End Fin

321b Deviator valve 91600267

321c Deviator valve holder 41009257

321d Non return valve 91941700

322 Seal 91406301

323 Seal 41009258

330 Subseq.runner ass.support 91670988

332 Botton cover 41005802

362 Wheel support reinforc. 91602344

364 Upper basket stopper 91601047

377 Center square 91621961

395 Air break ring nut 91600575

402 Harness protection 41006833

408a R/H later.panel 41007175 0712 (22/03/2007) 408a R/H later.panel 41023367 0712 (22/03/2007)

408b L/H later.panel 41007176 0712 (22/03/2007) 408b L/H later.panel 41023368 0712 (22/03/2007)

474 Safety switch 41009092 0549 (01/12/2005) 474 Safety switch 41018697 0549 (01/12/2005)

474a Gasket safety switch 41009096

491 Main cable 91200194

32000219 CD222AS 0530 (18/07/2005)

Ricambio Part No. Piece

Ref. Descrizione - Description - Beschreibung - Descripcion

492 Socle 41007218

493 Upper cover 91800072 0630 (24/07/2006) 493 Upper cover 41017653 0630 (24/07/2006)

498 Hose 41009563

508d 8 way selector 41009640

618c Unipolar NA+P.A. switch 90489683

797 Hook 92734912

798 Clutch body 91601427

799 Clutching band 92895838

827 Right foot door brachet 41001350

828 Left foot door bracket 41001351

830 Handle 41008550

834 Screw 92418151

E-Teil Pieza

Inizio Beginning Debut Begin Inicio

Fine Ending Fin End Fin

839 Clip 92470277

999 Wiring diagram 41015527 0615 (14/04/2006) 999 Wiring diagram 41019215 0615 (14/04/2006)
