ELECTRIFIED LOCKS,
RELAYS & TIMERS
MAGNETIC LOCKS
CX-94S-12LS
CX-94S-12LS
LIFETIME
WARRANTY
1200 LBS. SURFACE MOUNT GATE LOCK
FEATURES
• 1,200LBS HOLDING FORCE
• COMPATIBLE WITH ALL ACCESS/EGRESS
SYSTEMS
• FIELD SELECTABLE 12/24V DC
OPERATION
DESCRIPTION
Camden CX-94S-12LS gate locks are rugged magnetic locks designed for outdoor
applications. They offer exceptional performance and value with ultra low current
draw, making them the ideal choice for most gating projects.
SPECIFICATIONS
VOLTAGE: 12/24V DC
CURRENT DRAW: 500MA@12V DC
250MA@24V DC
TEMP RANGE: 5F TO 122F (-15C TO 50C)
CONTACT RATING: BOND SENSOR: 1A@30V DC
DIMENSIONS (BODY): 8”H x 2 1/2”W x 1 5/8”D
(203mm x 63mm x 41.5mm)
• CONDUIT FITTING FOR WEATHER
RESISTANT INSTALLATION
• BUILT-IN LOCK SENSOR AND RELAY
• LIFETIME WARRANTY
ORDERING INFORMATION
MODEL DESCRIPTION
CX-94S-12LS 1200 LBS. SURFACE MOUNT GATE LOCK WITH LOCK SENSOR
AND RELAY
5502 Timberlea Blvd. Mississauga, ON Canada L4W 2T7 • Toll Free: 1 877 226-3369 (CAMDEN9)
Tel: (905) 366-3377 • Fax: (905) 366-3378 • E-mail: info@camdencontrols.com • www.camdencontrols.com
MKTG-LIT-SP-94S-12LS
