Cambridge SoundWorks FPS2000 User Manual

FourPointSurround™ FPS2000 Digital

Multimedia Speaker System

Installation and Operating Instructions

© 2000 Cambridge SoundWorks, Inc.

Notice for the USA

FCC Part 15: This equipment has been tested
and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide
reasonable protection against harmful interference
in a residential installation. This equipment
generates, uses, and can radiate radio frequency
energy and, if not installed and used in
accordance with the instructions, may cause
harmful interference to radio communications.
However, this notice is not a guarantee that
interference will not occur in a particular
installation. If this equipment does cause harmful
interference to radio or television reception, which
can be determined by turning the equipment off
and on, the user is encouraged to try one or more
of the following measures:

❑ Reorient or relocate the receiving antenna.
❑ Increase the distance between the

equipment and receiver.

❑ Connect the equipment to an outlet on a

circuit different from that to which the
receiver is connected.

❑ Consult the dealer or an experienced

radio/ TV technician.

CAUTION: To comply with the limits for the Class
B digital device, pursuant to Part 15 of the FCC
Rules, this device must be installed with computer
equipment certified to comply with the Class B
limits.

CAUTION:

This symbol indicates that the marked item may be hot and should not be touched
without taking care.

• To minimize the risk of burns or other injuries to children, position the device
such that hot surfaces are out of their reach.

• To minimize the risk of fire, keep flammable materials like paper and cloth (for
example, curtains) away from the hot surfaces.

Safety & Regulatory Information

The following sections contain notices for various countries:

All cables used to connect the computer and
peripherals must be shielded and grounded.
Operation with non- certified computers or non­shielded cables may result in interference to radio
or television reception.

Any changes or modifications not expressly
approved by the grantee of this device could void
the user’s authority to operate the device.

Modifications

Notice for Canada

This apparatus complies with the Class B limits for
radio interference as specified in the Canadian
Department of Communications Radio Interference
Regulations.

Cet appareil est conforme aux normes de CLASSE
“B” d’interference radio tel que spe’cifie’ par le
Ministère Canadien des Communications dans les
règlements d’interfèrence radio.

Declaration of Conformity

According to the FCC96 208 and ET95- 19

Manufacturer/
Importer’s Name: Creative Labs Inc.

Manufacturer/
Importer’s Address: 1901 McCarthy Boulevard

declares under its sole responsibility that the
product

Trade Name: Creative Labs/

Model Number: CSW1500

has been tested according to the FCC / CISPR22/85
requirement for Class B devices and found
compliant with the following standards:

EMI/ EMC: ANSI C63.4 1992, FCC Part 15
Subpart B

This device complies with part 15 of the FCC Rules.
Operation is subject to the following two
conditions:

1. This device may not cause harmful interference,
and

2. This device must accept any interference
received, including interference that may cause
undesirable operation.

Ce matériel est conforme à la section 15 des régles
FCC. Son fonctionnement est soumis aux deux
conditions suivantes:

1. Le matériel ne peut étre source d’interférences
et

2. Doit accepter toutes les interférences reques, Y
compris celles pouvant provoquer un
fonctionnement indésirable.

Compliance Manager
Creative Labs, Inc.
January 18, 1999

Milpitas, CA. 95035

United States

Tel: [phone]

Cambridge SoundWorks

This product conforms to the following Council

Compliance

Directive:
❑ Directive 89/ 336/ EEC, 92/ 31/ EEC (EMC),

73/23/EEC (LVD)

Any changes or modifications not expressly
approved by the grantee of this device could void
the user’s authority to operate the device.

The serial number for the FPS2000 Digital is
located on the subwoofer. Please write this
number down and keep it in a secure area. This is
for your security.

Modifications

WARNING: To prevent
fire or shock hazard, do
not expose this appliance
to rain or moisture.

Important Notice

i

IMPORTANT SAFETY INSTRUCTIONS

READ INSTRUCTIONS - All safety and oper-

ating instructions should be read before the

FPS2000 Digital

ellite system is operated.

RETAIN INSTRUCTIONS - The safety and

operating instructions should be retained
for future reference.

HEED WARNINGS - All warnings on the

subwoofer and in the operating instruc­tions should be adhered to.

FOLLOW INSTRUCTIONS - All operating

and use instructions should be followed.

CLEANING - Unplug the Power Supply

Adapter from the wall outlet or other power
source before cleaning. Do not use liquid
cleaners or aerosol cleaners. Use a damp
cloth for cleaning.

ATTACHMENTS - Do not use attachments

not recommended by Cambridge
SoundWorks as they may cause hazards.

WATER AND MOISTURE - Do not use the

subwoofer near water—for example, near
a bath tub, wash bowl, kitchen sink, or
laundry tub; in a wet basement; or near a
swimming pool; and the like.

ACCESSORIES - Do not place the

Digital

tripod, bracket, or table. The subwoofer
may fall, causing serious injury to a child
or adult, and serious damage to the prod­uct. Any mounting of the satellites or sub­woofer should follow the manufacturer’s
instructions, and should use a mounting
accessory recommended by Cambridge
SoundWorks.

amplified subwoofer/sat-

FPS2000

system on an unstable cart, stand,

VENTILATION - Slots and openings in the

cabinet are provided for ventilation and to
ensure reliable operation of the subwoofer
and to prevent it from overheating. These
openings must not be blocked or covered.
The openings should never be blocked by
placing the product on a bed, sofa, rug, or
other similar surface. The openings should
not be placed in a built-in installation such
as a bookcase or rack unless proper ven­tilation is provided or Cambridge
SoundWorks’ instructions have been ad­hered to.

HEAT - The subwoofer should be situated

away from heat sources such as radia­tors, heat registers, stoves, and other
products (including amplifiers) that pro­duce heat.

POWER SOURCES - The subwoofer should

be operated only from the type of power
source indicated on the marking label. If
you are not sure of the type of power
supply to your home, consult your product
dealer or local power company. For prod­ucts intended to operate from battery
power, or other sources, refer to the oper­ating instructions.

POLARIZATION - The power supply may be

equipped with a polarized alternating-cur­rent line plug (a plug having one blade
wider than the other). This plug will fit into
the power outlet only one way. This is a
safety feature. If you are unable to insert
the plug fully into the outlet, try reversing
the plug. If the plug should still fail to fit,

contact your electrician to replace your
obsolete outlet. Do not defeat the safety
purpose of the polarized plug.

POWER-CORD PROTECTION - Power sup-

ply cords should be routed so that they are
not likely to be walked on or pinched by
items placed upon or against them, paying
particular attention to cords at plugs, con­venience receptacles, and the point where
they exit from the subwoofer.

LIGHTNING - For added protection for the

FPS2000 Digital

storm, or when it is left unattended and
unused for long periods of time, unplug it
from the wall outlet. This will prevent dam­age to the subwoofer due to lightning and
power-line surges.

OVERLOADING - Do not overload wall out-

lets, extension cords, or integral conve­nience receptacles as this can result in a
risk of fire or electric shock.

OBJECT AND LIQUID ENTRY - Never push

objects of any kind into the subwoofer
through openings as they may touch dan­gerous voltage points or short out parts
that could result in a fire or electric shock.
Never spill liquid of any kind on the speak­ers or the subwoofer.

SERVICING - Do not attempt to service any

part of the
opening or removing covers may expose
you to dangerous voltage or other haz­ards. Refer all servicing to qualified ser­vice personnel.

system during a lightning

FPS2000 Digital

yourself as

DAMAGE REQUIRING SERVICE - Unplug

the power supply from the wall outlet or
other power source and refer servicing to
qualified service personnel under the fol­lowing conditions:
a) When the power supply adapter or plug
is damaged.
b) If liquid has been spilled, or objects
have fallen into the subwoofer.
c) If the subwoofer or power supply adapter
has been exposed to rain or water.
d) If the

FPS2000 Digital

normally by following the operating in­structions; or exhibits a distinct change in
performance.
e) If the product has been dropped or
damaged in any way.

REPLACEMENT PARTS - When replace-

ment parts are required, be sure the ser­vice technician has used replacement
parts specified by Cambridge SoundWorks
or have the same characteristics as the
original parts. Unauthorized substitutions
may result in fire, electric shock, or other
hazards.

SAFETY CHECK - Upon completion of any

service or repairs to the
system, ask the service technician to per­form safety checks to determine that the

FPS2000 Digital

erating condition.

WALL OR CEILING MOUNTING - The

FPS2000 Digital

mounted to a wall or ceiling only as rec­ommended by Cambridge SoundWorks.

does not operate

FPS2000 Digital

system is in proper op-

satellites should be

ii

Contents

FourPointSurround

FPS2000 Digital

Multimedia Speaker System

Introduction ................................................................................................ 1

Inspecting For Damage ................................................................................ 2

Overview ..................................................................................................... 2

Installation Sequence .................................................................................. 2

Speaker Placement ...................................................................................... 3

Speaker Wiring Diagram ............................................................................. 4

Satellite Connections ................................................................................... 5

Attaching The Floor Stands ......................................................................... 6

Power Supply Adapter ................................................................................. 7

Audio Signal Connections ........................................................................... 7

Connection To Sound Blaster Live! Via DIGITAL DIN .................................. 8

Volume Control ............................................................................................ 8

Using The Volume Control ........................................................................... 9

Mounting The Volume Control .................................................................... 9

Adjusting Output Level ............................................................................. 10

Bass Level Control ..................................................................................... 10

Optimizing The Sound Of Your System ..................................................... 11

Mounting The Satellites ............................................................................ 11

Important .................................................................................................. 12

Specifications ............................................................................................ 12

Technical Support ..................................................................................... 12

1-Year Limited Warranty ........................................................................... 13

iii

Introduction

hank you for purchasing

FourPointSurround
FPS2000 Digital

T

by Cambridge SoundWorks.

The FPS2000 Digital is the first
multimedia speaker system to
support DirectSound
Environmental Audio in true
multichannel, digitally transfered
sound. It lets you experience the
full potential of the multichannel
sound encoded in today’s latest
computer software. We think you
will find it adds an exciting new
dimension to computer sound
and gaming.

®

3D and

Cambridge SoundWorks

1-877-YES-HIFI

(1-877-937-4434),
8 AM to Midnight,

Eastern time

1 PM to 4 AM

Greenwich Mean Time

Outside US:

Tel: [phone]

Fax: [phone]

www.cambridgesoundworks.com

or e-mail us at

[e-mail]

1

Inspecting
For Damage

Examine each speaker unit carefully
for signs of shipping damage. If there
is any damage, do not install the
system.

If there is any problem, or if
anything is missing, call the store
where the system was purchased
or refer to the “Technical Support”
section on pages 12-13.

Save the carton and its inserts in
case you need to transport your
FPS2000 Digital system later.

Overview

The four small satellite speakers of the
FPS2000 Digital are magnetically
shielded. They can be placed next to a
computer monitor. The subwoofer/
amplifier is not shielded and should
be placed at least 18 inches away from
a computer monitor.

The subwoofer is designed to sit
on the floor beneath a desk, and
sounds best in this position. The
satellites used for the front left and
right channels should flank the
computer monitor. The satellites
used for the rear left and right
channels can be placed on the
desktop, on floor stands, or

attached to other sites (using screws).

Installation Sequence

1. Read through the instructions
before installing the speakers.
The instructions assume you have
a 4-channel sound card–one that
supports DirectSound
has separate front and rear stereo
minijack outputs. If your sound
card has a single stereo minijack
line output, please read the note
under “Audio Signal
Connections” on page 7.

2. Place the satellites and the sub­woofer at appropriate sites near
your computer. Attach the stands,
if necessary.

®

3D and

3. To help you identify each
satellite’s channel, apply the
appropriate preprinted label to
the rear of each satellite.

4. Connect the four satellites to the
back of the subwoofer enclosure.
Leave all the wires accessible.

5. Connect your sound card
outputs to the subwoofer.

2

6. Connect the Volume Control to
the subwoofer.

7. Connect the power supply
adapter.

8. Listen to the system and adjust
the Bass Level control for
pleasing bass output.

9. You may wish to experiment
with satellite placement briefly
before concealing the connecting
wires and making the
installation more permanent.

Speaker Placement

The Front Satellites

The front left and right satellites
should be placed to the sides of the
monitor. Install the desktop stands
if placing the satellites on the
desktop.

The Rear Satellites

If you are lucky enough to have
side walls close to your listening
position, excellent placement for the
rear left and right satellites is
behind your listening position,
slightly above ear level (use a screw
to hang each satellite, see diagram
A). Do not be concerned if this is
not practical, since any rear satellite

placement behind or to the side of
the listening position will provide
strong directional and surround
effects.

The rear satellites may be
installed on their convenient floor
stands. The stands should be
positioned behind your listening
position and aimed at the listener.
The stands are small enough to be
stowed underneath or alongside a
desk when not in use
(see diagram B).

If none of these locations are
practical, the rear satellites may be
placed in convenient sites alongside
the listener, including sites slightly
forward of the listening location.

The rear satellites do not have to be
at the same height, or at the same
height as the front sat-ellites. Try
the extreme corners of a desk using
the desktop stands (C) or attach the
rear satellites under a desktop or at
the sides of a desk using the hook &
loop fasteners (D).

The Subwoofer

The subwoofer’s optimum position
is on the floor against the wall. The
closer the subwoofer is to a corner,
the stronger the maximum bass
output. Position the subwoofer
so that its connection panel is
facing a wall, shielded from in­advertent contact.

A D

B

C

3

Speaker Wiring Diagram

Subwoofer

Front Left Satellite

Rear Left Satellite

Power Supply Adapter

FRONTREAR

Front Right Satellite

Audio Connection Cables

Rear Right Satellite

Volume Control

Out To
Computer
Sound Card

RF

4

Satellite Connections

Typically, the 3 meter speaker
cables will connect the front
satellites to the subwoofer and the
5 meter cables will connect the
rear satellites to the subwoofer.

A panel of eight self-adhesive
labels is provided to identify each
satellite and the opposite end of
the cable connected to a satellite.

1. Identify the two 3 meter

cables. Most satellites will be
used with their desktop
stands. In this case, thread one
end of a 3 meter cable through
the hole in the desktop stand.
Connect this end to one
satellite, (as shown in diagram
E). If used, carefully insert the
desktop stand’s attachment
arm into the socket in the back
of the satellite, taking up any
slack in the cable as required.

2. Remove the backing from the

small, round “FRONT LEFT”
label and apply it to the back
of the satellite (see diagram E).

3. Remove the backing from the

remaining, longer “FRONT
LEFT” label and wrap it
around the opposite end of the
speaker cable you just
connected.

4. Connect this end of the speaker
cable to the red and black
“FRONT LEFT” speaker
connectors on the subwoofer.

5. Repeat this process for the
Front Right, Rear Right and
Rear Left satellites. Be sure to

use the remaining 3 meter
cable for the other front
speaker.

Diagram E

To connect the speaker wires to the
spring loaded connectors on the
satellite and subwoofer, push back
on a spring-loaded tab to expose the
connection hole. Insert the bare end
of the wire into the exposed hole,
then release the tab to lock the wire
in place.

Connect wires with red bands to
red tab connectors and unmarked
wires to black tab connectors.

Notes: Matching red wires to red
tabs and unmarked wires to black
tabs insures the speakers all play
“in-phase”. “Out of phase”
connections will do no electrical
harm, but the positional audio
sound quality will be greatly
reduced. You can substitute regular
18 gauge speaker wire to create
longer cables, if needed.

E

5

Attaching The Floor Stands

The rear satellites (with their
desktop stands attached) may be
installed in their floor stands.

1. One leg of each floor stand has
a full length slot, with short
notches opposite the slot at
each end. Insert a satellite
cable inside one of these legs

F

by feeding it down the length
of the full length slot. At each
end, feed the cable through the
short notches (see diagram G).

2. Insert the satellite end of the
leg/cable assembly into the
middle socket of the apex joint.
Make sure the satellite cable
exits through the short notch
and not the full length slot
(see diagram F).

G

REAR
RIGHT

3. Insert the two solid legs into
the outside sockets in the
apex joint.

4. Position the two “cut-away”
sections of the desktop stand
over the opening in the top of
the apex joint, as shown in
diagram F. Be sure to align the
face of the stand with the face
of the apex joint. Lower the
stand straight down into the
apex joint.

5. Holding the ends of the apex
joint, push on the front of the
desktop stand until it slips back
into the slot in the apex joint.
Confirm a secure fit.

6. At the base of the rear leg,
gently pull on the satellite
cable to remove any
unnecessary slack in the cable.

7. Insert a rubber plug into the
base of each leg, taking care to
feed the cable out the short
notch in the rear leg (see
diagram H).

H

6

Power Supply Adapter

Confirm that the power switch is
in the “OFF” position. Insert the
power supply’s AC plug into the
appropriate receptacle. Insert the
small DC connector into the
“15V DC IN” receptacle on the
back of the subwoofer
(see diagram I).

FRONTREAR

I

Audio Signal Connections

The FPS2000 Digital comes with a
front/rear audio signal cable.
Connect this cable between your
sound card and the subwoofer
(see diagram J).

1. Insert one of the green
miniplugs into the green
minijack (LINE OUT) on your
sound card.

2. Insert the corresponding black
miniplug into the black
minijack (REAR OUT) on your
sound card.

3. Insert the green miniplug at
the other end of the cable into
the green minijack (FRONT)
on the subwoofer.

4. Insert the black miniplug into
the black minijack (REAR) on
the subwoofer.

Note: If you have a stereo sound
card (one without a rear stereo
minijack line output), connect a
green miniplug cable to the LINE
OUT minijack of your sound card
and the opposite green miniplug
to the FRONT minijack on the
subwoofer. This will cause both
left front and left rear satellites to
play the left stereo channel and
both right satellites to play the
right stereo channel.

SOUNDCARD OUTPUT

(EXAMPLE-SOUND BLASTER LIVE! AUDIO CARD)

REAR

OUT

FRONTREAR

LINE
OUT

J

FPS2000 Digital Subwoofer

7

FRONTREAR

Connection To Sound Blaster Live! Via DIGITAL DIN

If your Sound Blaster Live! sound
card includes a Digital I/O card,
you can take advantage of the
clear, distortion-free audio
available from its Digital DIN
output.

1. Insert one end of the SPDIF cable
into the DIGITAL DIN output jack
on the Sound Blaster Live!
Digital I/O card. The position of
the Digital DIN connector on the
Digital I/O card may be different
from this diagram. The Digital
DIN connector is
the only connector with
a 9-pin configuration.

Digital DIN Connector

2. Insert the other end of the SPDIF
cable into the DIGITAL DIN input
on the subwoofer (see diagram K).

3. Use the following procedure to
configure the Sound Blaster Live!
sound card for four speakers:

• Bring your mouse pointer to the

top of the monitor screen to
display the Creative Launcher.

• Click on AudioHQ.

• Click on the Speaker tab. The

speaker dialog box will appear.

DIGITAL

DIN

DIGITAL I/O CARD

SPDIF CABLE

• On the Configuration tabbed
page, select the “4 Speakers”
option.

• A sofa icon (representing you)
appears in the center of the
Preview box, with four speakers
at the corners of the box.

Note: The FPS2000 Digital will
detect the presence of a plug
connected to the DIGITAL DIN
input and give the DIGITAL DIN
input priority. Any signal present
at the AUDIO input will be
ignored. Be sure to remove the
plug from the DIGITAL DIN input
if you wish to listen to a sound
source through the analog AUDIO
INPUT.

Volume Control

The FPS2000 Digital system
comes with a separate wired
Volume Control, designed to be
positioned close at hand and
affixed with the semipermanent
mounting strip.

Connect the circular plug at the
end of the Volume Control into the
circular Volume Control jack on
the back of the subwoofer (see
diagram L).

K

FPS2000 Digital Subwoofer

FRONTREAR

L

8

C

A

M

B

R

I

D

G

E

S

O

U

N

D

W

O

R

K

S

Using The Volume Control

The Volume Control has a Front/
Rear Balance Control, a Master
Level Control (see diagram M),
and an On/Off power switch.

Use the Master Level Control
whenever you wish to adjust the
speaker output level.

Adjust the Front/Rear Balance
Control to achieve satisfactory
output from all four speakers. It
should not be necessary to adjust
the control more than once while
playing any single game. Different
games may benefit from different
Front/Rear Balance Control
settings.

Software for Creative Labs
sound cards allows you to adjust
the rear speaker output level. The
rear speaker level adjustment is
found within the “Creative
Configurator” in Sound Blaster
PCI64/128 software. Set this

adjustment to its highest setting.

Sound Blaster Live! and Sound
Blaster Live! Value software has

rear speaker level adjustment
within the mixer application. Set
the “FRONT/REAR BALANCE”
slider to its mid-way position.

Other sound card software may
have similar front to rear balance
adjustments. Be sure these
controls are set for sufficient
output in all four channels, then
use the Front/Rear Balance Control
from that point forward.

M

Front/Rear Balance Control

Master Level Control

Mounting The Volume Control

The enclosed mounting strip is
semipermanent—it holds well but
can be peeled off gently. Be sure
that the mounting surface, such as
the computer monitor or your
desktop, is smooth and clean.

Remove protective paper from one

1

side to reveal adhesive.

Press exposed adhesive side firmly

2

against back of Volume Control.

Remove remaining paper strip.

3

Press control firmly against

4

mounting surface
(desktop, keyboard or monitor).

9

Adjusting Output Level

In most instances, the FPS2000
Digital Master Level Control will

be the most convenient way to
adjust the overall playback level. It
responds instantly and doesn’t
require you to pause games or
programs. But there are other
output level controls present in
software to consider.

Versions of Microsoft
and most other operating systems
offer an on-screen sound level
Control, while most game
programs provide yet another one.
For the FPS2000 Digital Master
Level Control to perform at its
best, these “software” level
controls should be set to an
“optimum” position and then left
alone.

Set any software volume
controls to approximately 75% of
their maximum output level. This
should allow the FPS2000 Digital
Master Level Control to achieve
the highest output level desired
when set to its loudest setting.

®

Windows

®

If the FPS2000 Digital’s
maximum output is still not
sufficient at the extreme setting of
its Volume Control, try increasing
one, and only one, of the software
volume controls to increase overall
output.

If you find the optimum output
level of the FPS2000 Digital
system occurs at too low a setting
of its Volume Control, reduce the
setting of one software volume
control (preferably the operating
system’s output level control) to
achieve greater control range.
Note: Some software volume
controls may introduce distortion
when set to their maximum level.
Experiment to achieve the cleanest
sound.

Bass Level Control

The output of the subwoofer can
be adjusted to suit the listener’s
taste. Start with the control in the
12 o’clock position (see diagram
N). After using the system for a
couple of hours, adjust the control
up or down to fine-tune it.

N

FRONTREAR

10

Optimizing The Sound
Of Your System

Have a clear line of sight from your
listening position to the satellites.
This prevents their higher
frequencies from being blocked. It is
not necessary for each satellite to be
aimed directly at the listener.

The relative strength of low-bass
depends on how close the subwoofer
is to intersecting room surfaces. The

most bass output results from the
subwoofer being placed on the floor
in a corner. The least bass output
results with the unit positioned away
from any corners or walls.

Once you have adjusted the Bass
Level Control, leave it in that
position. It should not be used to
compensate for differences in
recordings or games.

Mounting The Satellites

To the wall:

To wall-mount the cubes on
structurally strong surfaces (a wall
stud or wood panelling), screw a
M5 x 25mm screw into the
material. Allow their heads to
protrude about
the keyhole slots on the back of
each cube (see diagram O).

1

/4 inch to fit into

The plastic anchors supplied
will be needed to secure the
screws in most wall surfaces.
If so, drill
wall, then tap the anchors into
the holes until they are flush
with the wall. Then screw the
screws into the anchors until
they protrude about

rubber feet to the back of the
satellite cubes. This assures an
acoustically secure installation.

1

/4 inch holes in the

Be sure to apply the stick-on

O

1

/4 inch.

Keyhole slot mounting

11

Important

Playback Levels

FPS2000 Digital is intended for
individual or small group listening
and will achieve surprisingly high
output levels. However, playing
the system continuously at overly
loud, distorted levels on heavy
bass program material may cause
its internal fuse to blow.

The fuse can be replaced only by
a qualified service representative.
To avoid this inconvenience and a
possible non-warranty repair
charge, reduce the playback
volume when the system shows
obvious signs of stress, i.e. it
sounds “raspy,” “fuzzy,” and/
or “muddy.”

Specifications

FPS2000 Digital’s

Four-channel

Amplifier Specification

Subwoofer: 25 watts RMS.

Satellite: 7 watts RMS per channel.

These specifications apply to a
FPS2000 Digital
15V DC power adapter.

operating from a

s

Technical Support

Inside U.S.A., Canada and Latin America

Creative Labs Inc. Technical Support

If you need technical assistance, call 405-742-6622. Technical support is
available seven days a week from 8:00 am to midnight, Central time.

You can get the latest program and driver updates from Creative Labs’ bulletin

board, 24 hours a day. Call 405-742-6660; use modem settings:

Baud rate: 300 to 14400

(V.32/V.42 bis)
Data bits: 8
Parity: none
Stop bits: 1

You can also send a FAX at 405-742-6633 or write us at:

Technical Support
Creative Labs, Inc.
1523 Cimarron Plaza
Stillwater, OK 74075

To reach Creative Technical support via the Internet, visit our technical support

web site at http://www.creativehelp.com, for troubleshooting help.

For information about this product and other Creative Labs products, visit

Creative Zone at http://www.soundblaster.com. Or, call Customer Service at

800-998-1000

Faxback information is available by calling 405-372-5227

12

Inside Asia

Creative Technology Ltd. Technical Support

31 International Business Park,
Creative Resource, Singapore 609921

Tel: [phone]
Fax: [phone]

Operating hours (Singapore Time)

Mon-Fri: 9am-6pm
Sat-Sun & Public Holidays: Closed

1-Year Limited Warranty

o the original purchaser,
Cambridge SoundWorks, Inc.
will warrant the FPS2000

T

Digital system to be free of
defects in material and
workmanship for a period of one
(1) year from date of purchase.
With respect to defects, Cambridge
SoundWorks will, at its option,
replace the product or repair the
defect in the product with no
charge to the original purchaser
for parts or labor.

This warranty does not extend
to any defect, malfunction or
failure caused by misuse, abuse,
accident, faulty hook-up, defective
associated equipment or use of the
speaker with equipment for which
it is not intended.

This warranty is valid only
when the speaker is returned to
the retailer that sold the FPS2000
Digital to the original purchaser.

This is the sole and expressed
warranty. This warranty is in lieu
of all other warranties, expressed
or implied, of merchantability,
fitness for purpose or otherwise.
In no event shall Cambridge
SoundWorks, Inc. be liable for
incidental or consequential
damages or have any liability with
respect to defects other than the
obligations set forth as stated.

To ensure warranty coverage, it
is incumbent upon the original
purchaser of FPS2000 Digital to
inform the retailer of the defect
within the warranty period. The
only acceptable method of
establishing warranty status is a
copy of the original proof of
purchase indicating customers
name and purchase date.

For advice about your warranty
or any information, call the store
where purchased or refer to the
“Technical Support” section on
pages 12-13.

© 2000 Cambridge SoundWorks, Inc. All rights reserved. Cambridge SoundWorks is a registered trademark, and FourPointSurround is a trademark of Cambridge SoundWorks, Inc., Newton, MA.

Creative and Sound Blaster are registered trademarks of Creative Technology Ltd. All other brands and products are trademarks or registered trademarks of their respective holders. All
specifications are subject to change without prior notice. Actual contents may differ from those pictured.

13

311 Needham Street, Newton, MA 02464

1-877-937-4434 Fax: [phone]

www.cambridgesoundworks.com

or e-mail us at [e-mail]

0420003004 Rev. C
