1
Unit Dimensions
Outdoor Entertainment Measurements
Width 84”
Height 84”
Depth 36”
Weight 700 lbs.
Shipping Weight 750 lbs.
The Outdoor Entertainment Measurements are
provided for backyard planning. If the Guide steps
are followed, there will be little trouble hooking
up a television for HDMI and Power Supply.
Unit Dimensions
The Outdoor Entertainment system is
also available with shelves in place of
the refrigerators.
2
Bracket Installation for HDMI
1. Drill for the Placement of Metal Brackets
Drill and place 2 brackets (if desired) for the back wall placement in the cabinet of a wall-mounted television.
The placement of these brackets and the cabinet space allotted for a at-screen television are shown below.
Bracket Installation for HDMI
The television enclosure is 54” Wide by 27” Tall. Please note
that diagonal screen measurements will not give the true
physical dimensions of the television because the diagonal
measurement does not take into account the television’s
housing. Therefore, the best measurement to use is the actual
height and width of your television (including the base if used).
Life Vessel Pre-delivery Guide
LTR50001199, Rev. A
3
2. Plug in Your TV’s HDMI (TV Cabinet Recess)
This pair of upper wall receptacles
is for connecting your television’s
HDMI and power.
3. Inside Doors Are HDMI and a Covered Outlet
This pair of lower wall receptacles is for
connecting your cable’s/Blu-Ray’s/DVD’s
HDMI and power.
Bracket Installation for HDMI
4. Covered Power Switch and Outlet
This switch/outlet combination
is shown closed (left) and open
(right).
5. Power Switch Turns Recessed Lighting & Power On/Off
4
Warranty
Warranty
Limited Warranty
All Cal Flame entertainment centers are manufactured with the highest quality appliances and are warranted to
be free from defects in material and workmanship at time of delivery.
LMS warrants the entertainment center from deterioration, corrosion, and defects in material and workmanship
for a period of one year from the original date of delivery. Specically warranted are the structural frame,
reproof panels, the base, and electrical wiring and components, including switches and outlets.
LMS warrants for a period of 90 days hardware and components, including, but not limited to: stainless steel
doors, stainless steel drawers, sinks, drop-in cocktail center, ice chest, blender station, food warmer, drop-in
bar center, cutting board and cutting board storage, griddle and griddle storage, Deep Fryer Helper, paper towel
storage, propane tank drawer.
LMS warrants the decorative nishes to be free of defects at time of delivery, including, but not limited to,
stucco, grout, brick, rock, tile, granite, and foot rest.
Extent of Warranty
This limited warranty is only valid on Cal Flame models delivered in the United States or Canada and extends
through the selling dealer to the original purchaser at the original site of installation.
Manufacturer Warranty
The appliance warranty is extended through the manufacturer of the product. These items include, but are not
limited to, refrigerators, umbrellas, accessories, stereos, speakers, televisions, and DVD players.
Many of the items mentioned above are delivered with their own manufacturer’s warranty. For more information,
see their warranties in the owner’s information package that was delivered with your entertainment center.
Warranty Performance
In the event of a malfunction or defect covered under the terms of this warranty, contact either the selling
dealer or a local contractor or service technician. Depending on your needs, this may be a contractor qualied
to repair stone and tile or a service agent licensed to repair gas or electrical appliances.
In the event the consumer is unable to obtain satisfactory customer service from the selling dealer or service
agent, written notication must be given to the LMS Customer Relations Department within 30 days of the
reported failure.
There will be no charge for parts on a covered item. Cost of labor is the responsibility of the owner. Shipping
and handling charges will apply to all warranted replacement parts. The service agent may assess a reasonable
travel or mileage charge per service call. If LMS determines that repair of a covered item is not feasible, LMS
reserves the right to replace the defective merchandise with merchandise equal in value to the original purchase
price. Warranty repair and / or replacement are the sole discretion of LMS and this warranty does not cover
costs therein, including but not limited to: freight, removal, re-installation, etc.
This warrant is non-transferable and may not be extended beyond the above mentioned time frames under any
circumstances, by any of LMS’s representatives.
Life Vessel Pre-delivery Guide
LTR50001199, Rev. A
5
Warranty Limitations
This warranty is void if the entertainment center has been subject to negligence, alteration, misuse, repairs,
dings, dents, scratches, or incorrect and / or prohibited applications, as specied in the owner’s manual. Gas
lines must be installed by a licensed plumber only or local gas company agent. Incorrect electrical installation
by unlicensed electricians, service by non-LMS authorized representatives, acts of God and other cases beyond
the control of LMS are not covered by this warranty. Please refer to the owner’s manual for examples of
exclusions and common acts invalidating this warranty. This limited warranty applies only to entertainment
centers used for personal, family, and outdoor household purposes. This warranty does not apply to labor
charges on entertainment centers, replacement parts and hardware. This limitation is retroactive and applies
to all entertainment centers manufactured from 2000 and hereafter.
Examples of common acts invalidating this warranty include but are not limited to:
• Scratches caused by normal use.
• Damage caused by extreme weather conditions (hot, cold, etc.)
• Damage caused by dirt, sand, and/or water damage.
• Damage caused by salty and humid conditions (especially in beach or seaside communities)
• Damage caused by continued operation of the entertainment center with either known or unknown
problems.
• Damage caused by direct sunlight.
• Damage caused as a result of failure to follow the operating instructions as dened in this owner’s manual.
Warranty
This limited warranty applies only to entertainment centers normally used for personal, family, or household
purposes and specically excludes rental or commercial applications.
Disclaimers
LMS shall not be liable for loss of use of the entertainment centers or other incidental or consequential costs,
expense or damages, which may include, but are not limited to, removal of permanent deck or other custom
xtures or the necessity for crane removal. Any implied warranty shall have duration equal of the applicable
warranty stated above.
Natural stone: Rock, travertine, marble, granite, etc. may be characterized by dry seams, pits, chips, cracks,
and fossils that are often lled with grout during installation. These are normal imperfections and are not
considered defects.
Legal Remedies
This limited warranty gives you specic legal rights. You may have other rights, which may vary from state to
state.
Customer Service
For customer service, contact the authorized selling dealer immediately. If you need additional information or
assistance, please contact the LMS Customer Relations Department at 1462 E. Ninth St., Pomona CA 91766 or
call (800) 225-7727.
See your Cal Flame barbecue dealer for a copy of the applicable warranty, details and any questions you may
have regarding the warranty coverage on your entertainment center.
Don’t forget to register your new product at www.calamebbq.com.
