Calculated Industries 8020 User Manual

LTRA MEASURE

ASTER

PROFESSIONAL GRADE U.S. STANDARD TO METRIC CONVERSION CALCULATOR

Model 8020

Pocket Reference Guide

➡

Insert This

Direction

POCKET REFERENCE GUIDE — 1

The

Ultra Measure Master

calculator simplifies conversions between Metric and Imperial weights and measures. The

Ultra

Measure Master

can convert the following

types of dimensions:

• Linear

• Area

• Volume

• Weight

• Temperature

• Linear Velocity

• Volumetric Velocity (Flow Rates)

• Pressure

• Bending Moment

In addition to the above, the

Ultra Measure

Master

performs dimensional calculations

with ease!

ULTRA MEASURE MASTER

POCKET REFERENCE GUIDE — 2

GETTING STARTED...............................3

Key Definitions.....................................3

Power On and Off ..............................11

Conventions and Units of Measure ...11

Fractional Settings .............................14

Preference Feature............................15

Using Exponential Notation...............17

Setting Flashing Denominator...........18

Basic Math Operations......................19

Memory Operation .............................22

Paperless Tape Feature....................24

USING THE ULTRAMEASURE

MASTER ...............................................26

Entering Dimensions and Units.........26

Linear Conversions............................27

Area Conversions..............................29

Volume Conversions..........................31

Weight Conversions ..........................33

Weight/Volume Conversions.............35

Temperature Conversions .................38

Linear Velocity Conversions ..............39

Volumetric Velocity Conversions .......40

Pressure Conversions.......................42

Bending Moment Conversions .........43

APPENDIX ............................................45

Accuracy/Errors.................................45

Battery Information ...........................46

Specifications.....................................46

REPAIR AND RETURN.........................47

Warranty, Repair and Return

Information .....................................47

WARRANTY..........................................48

TABLE OF CONTENTS

POCKET REFERENCE GUIDE — 3

KEY DEFINITIONS

+ – x Arithmetic operation keys. ÷ =

% Four-function (+, –, x, ÷)

percent key

0 – 9 Keys used for entering and • numbers.

Off Key

— Turns all power

off.

On/Clear Key

— Turns on power. Pressing once clears the display. Pressing twice clears all temporary registers.

Storage Key

— Used to

store values.

Recall Key

— Recalls val-

ues stored in registers.

Convert Key

— Used with dimension keys to convert dimensions, or with other keys to access special functions.

Shift Key

— Used with other keys to access units of measure or other special functions.

GETTING STARTED

POCKET REFERENCE GUIDE — 4

Gallon Key

— Displays and

enters value as gallons.

Fluid Ounces Key

— Displays and enters value as fluid ounces.

Liter Key

— Displays and

enters value as liters.

Milliliter Key

— Displays

and enters value as milliliters.

Ton Key

— Displays and

enters value as tons.

Pounds Key

— Displays

and enters value as pounds.

Dry Ounces Key

— Displays and enters value as dry ounces.

Kilograms Key

— Displays and enters value as kilograms.

Grams Key

— Displays

and enters value as grams.

Square Key

— Defines a

square dimension.

Meters Key

— Displays

and enters value as meters.

Centimeter Key

— Displays and enters value as centimeters.

POCKET REFERENCE GUIDE — 5

Millimeter Key

— Displays and enters value as millimeters.

Kilometer Key

— Displays and enters value as kilometers.

Yards Key

— Displays and

enters value as yards.

Feet Key

— Enters or con-

verts to

feet

as whole or decimal number. Also used with the i and / keys for entering Feet-Inch values (e.g., 6 f 9 i 1 / 2). Repeated presses during conversions toggle between Fractional and Decimal Feet.

Inch Key

— Enters or con-

verts to

inches

. Entry can be whole or decimal number. Also used with the / key for entering fractional inch values (e.g., 9 i 1 / 2). Repeated presses during conversions toggle between Fractional and Decimal Inches.

Fraction Key

— Used to separate the numerator and denominator when entering fractions: 1 / 2

POCKET REFERENCE GUIDE — 6

Miles Key

— Displays and

enters value as miles.

s g

Gallons per Minute (gpm)

— Displays and enters value as gallons per minute.

s F

Fluid Ounces per Second (oz/sec)

— Displays and enters value as fluid ounces per second.

s L

Liters per Second (liters/sec)

— Displays and enters value as liters per second.

s Â

Milliliters per Second (mL/sec)

— Displays and enters value as milliliters per second.

s %

Weight per Volume (wt/vol)

— Displays and enters weight per volume ratio in permanent memory.

s t

Metric Tons (met tons)

— Displays and enters value as metric tons.

s l

Pounds per Square Inch (psi)

— Displays and enters value as pounds per square inch.

POCKET REFERENCE GUIDE — 7

s d

Pounds per Square Foot (psf)

— Displays and enters value as pounds per square foot.

s k

Kilopascals (kPa)

— Displays and enters value as kilopascals.

s G

Megapascals (MPa)

— Displays and enters value as megapascals.

s S

Cubic Volume (Cu)

— Displays and enters a cubic dimension.

s m

Meters per Minute (m/min)

— Displays and enters value as meters per minute.

s c

Meters per Second (m/sec)

— Displays and enters value as meters per second.

s M

Millimeters per Second (mm/sec)

— Displays and enters value as millimeters per second.

s K

Kilometers per Hour (km/h)

— Displays and enters value as kilometers per hour.

POCKET REFERENCE GUIDE — 8

s y

Feet per Minute (ft/min)

— Displays and enters value as feet per minute.

s f

Feet per Second (ft/sec)

— Displays and enters value as feet per second.

s i

Inches per Second (in/sec)

— Displays and enters value as inches per second.

s /

Exponential Notation (EXP)

— Used to enter an

exponential value (i.e., x10y).

s µ

Miles per Hour (mph)

— Displays and enters value as miles per hour.

s 9

Newton-meters (N-m)

— Displays and enters value as newton-meters.

s 8

Foot-Pound (ft-lbs)

— Displays and enters value as foot pounds.

s 7

Inch-Pounds (in-lbs)

— Displays and enters value as inch pounds.

s 6

Acre-Feet (Acre-Ft)

— Displays and enters value as acre-feet.

s 5

Acre

— Displays and

enters value as acres.

POCKET REFERENCE GUIDE — 9

s 4

Hectare

— Displays and

enters value as hectares.

s 3

Fahrenheit (°F)

— Displays and enters value as Fahrenheit.

s 2

Celsius (°C)

— Displays

and enters value as Celsius.

s 1

Board Feet (BdFt)

— Displays and enters value as board feet.

s •

Per Unit Function (Per)

— Allows you to calculate total material cost, if you multiply the total amount of material by the per unit cost of the item.

s –

Change Sign (+/–)

— Toggles the sign of the displayed value.

s ÷

Square Root Function ( )

— Calculates and displays the square root of a number. You will get an error if you try to find the square root of a linear or volume value.

Ç +

Pi Constant (π)

— An inter-

nal constant: 3.141593.

POCKET REFERENCE GUIDE — 10

Ç ®

Memory Clear

— Clears the value in the cumulative memory (s 0) without changing the display.

Ç x

All Clear (AC)

— Clears all values including Memory. Resets all settings to their defaults.

® x

Metric Mode Toggle

— Toggles between Metric mode and Imperial mode.

Note: This mode is not reset when you perform an all clear

Ç x

® =

Paperless Tape Function (Tape)

— Accesses the “Paperless Tape” mode so you can check previous entries.

® /

Preference Setting

— Accesses user defined fractional and exponential settings.

® +

Memory Clear

— Clears all Memory registers (0 – 9) without clearing the display.

ß 0

Cumulative Memory (M+)

— Adds the displayed value to Memory.

POCKET REFERENCE GUIDE — 11

Ç ß 0

Subtract from Cumulative Memory (M–)

— Subtracts the displayed value from Memory.

ß 1 – 9

Memory Storage

— When pressed after the ß key, the 1 through 9 keys will store the displayed value into fixed Memory.

POWER ON AND OFF

Turn the calculator on by pressing the o key. To turn the calculator off, press O.

CONVENTIONS AND UNITS OF MEASURE

CONVENTIONS UNITS OF MEASURE

Linear meters

centimeters millimeters feet inches yards miles kilometers

Area square meters

square yards square miles hectares square centimeters square feet

(Cont’d)

POCKET REFERENCE GUIDE — 12

(Cont’d)

CONVENTIONS UNITS OF MEASURE

Area

(Cont’d)

square kilometers square millimeters square inches acres

Volume cubic meters

cubic yards cubic miles gallons milliliters cubic centimeters cubic feet cubic inches cubic kilometers fluid ounces board feet cubic millimeters acre-feet liters

Temperature Celsius

Fahrenheit

Weight dry ounces

pounds tons grams kilograms metric tons

(Cont’d)

POCKET REFERENCE GUIDE — 13

(Cont’d)

CONVENTIONS UNITS OF MEASURE

Linear Velocity feet per minute

feet per second inches per second meters per minute meters per second millimeters per second miles per hour kilometers per hour

Volumetric fluid ounces per second Velocity gallons per minute

(Flow Rate)

milliliters per second liters per second

Pressure pounds per square inch

pounds per square foot kilopascals megapascals bars

Bending inch-pounds Moment foot-pounds

newton-meters

POCKET REFERENCE GUIDE — 14

FRACTIONAL SETTINGS

When your calculator is in a default condition (battery change or full reset), it is set to round fractional values to the nearest 1/64th of an inch. However, you may program your preference for six different accuracy levels and two different modes (Normal and Fixed), all of which remain in permanent memory until revised or reset.

The fractional level can be revised by using Ç as shown below:

Ç 1 = Fraction Set to 1/16” Ç 2 = Fraction Set to 1/2” Ç 3 = Fraction Set to 1/32” Ç 4 = Fraction Set to 1/4” Ç 6 = Fraction Set to 1/64” Ç 8 = Fraction Set to 1/8”

If there is a value on the display, when one of the functions above is performed the accuracy level will be temporarily revised. If the display is cleared, then the accuracy will be permanently revised.

POCKET REFERENCE GUIDE — 15

PREFERENCE FEATURE

The Ultra Measure Master provides Preference Settings that allow you to set fractional accuracy and display features. The preference settings are displayed using ® /. Repeated presses of / toggle through the different settings while the + and – keys are used for revision. These settings remain set until they are changed or the calculator is reset.

FRACTIONAL ACCURACY SETTINGS

• Fraction Set to 1/64”

(Default)

• Fraction Set to 1/2”

• Fraction Set to 1/4”

• Fraction Set to 1/8”

• Fraction Set to 1/16”

• Fraction Set to 1/32”

FRACTION MODES

• Normal Mode

(Default)

• Fixed Mode

EXPONENT

• On

(Default)

• Off

FLASHING FRACTION

• Off

(Default)

• On

Whenever the fractional setting is other than 1/64 normal mode, a star (★) will appear in the bottom left of the display when the calculator is turned on. This indicates a special fractional setting is stored within.
