Cadillac SRX 2015 User's Guide

2015
ConvenienCe/Personalizati o n Gu i d e
Review this guide for an overview of some important features in your Cadillac SRX. Some optional equipment (denoted by ♦) described in
this guide may not be included in your vehicle. More detailed information can be found in your Owner Manual.
INSTRUMENT PANEL
Exterior
Lamps
Turn Signal
Lever
Cruise Control/
Phone/Heated
Steering Wheel♦
Buttons
Instrument
Cluster/Driver
Information
Center
Windshield Wipers/Rear Wiper Lever
Audio Steering
Wheel Controls/
5-Way Controller
CUE
Touch
Screen
Audio
System
Controls
Climate
Controls
Power Mirrors Control
Tilt/Telescope
Steering
Wheel Lever
Adjustable
Pedals
Switch♦
Engine
Start/Stop
Button
Hazard Warning Flashers
Button
Heated/
Ventilated Seat
Buttons♦
2
Electric Parking
Brake
Switch
Shift Lever/ Driver Shift
Lane Departure♦/
Parking Assist♦/
ECO Mode Buttons
StabiliTrak/
Traction
Control
Button
INSTRUMENT CLUSTER
BRAKE
PARK
Symbols
Traction Control Off
Antilock Brake System Warning
StabiliTrak Off
Electric Parking Brake Service Security
StabiliTrak/Traction Control
Lane Departure Warning
Lights On Reminder
Cruise Control
Adaptive Cruise Control
Brake System Warning
High Beam Headlamps
Adaptive Forward Lighting
Airbag Readiness
Engine Oil Pressure Warning
Electric Parking Brake Set
eco Eco Active
Forward Collision Alert
Charging System Warning
Safety Belt Reminder
Engine Coolant Temperature
Check Engine Warning
Low Tire Pressure
Low Fuel Warning
Refer to your Owner Manual to learn about the information being relayed by the lights, gauges and indicators of the instrument cluster.
Optional equipment
3
See In Brief in your Owner Manual.
REMOTE KEYLESS ENTRY TRANSMITTER
Lock
Press to lock all doors.
Unlock
Press to unlock the driver’s door. Press again to unlock all doors.
Note: To change the Remote Keyless Entry settings, go to Remote Lock, Unlock, Start in the Vehicle Settings menu.
Remote Vehicle Start
Use to start the engine from outside the vehicle. See Adaptive Remote Start on page 5.
Vehicle Locator/Panic Alarm
Press and release to locate your vehicle. The exterior lamps ash
and the horn sounds. Press and hold for 3 seconds to activate the alarm. The turn signal
lamps ash and the horn sounds for 30 seconds, or until the
button is pressed again or the vehicle is started.
Liftgate Release
Press twice to unlock the liftgate or open/close the power liftgate.♦
Door Key
Press the button (A) to pull the door key out of the transmitter. If needed, use the key to lock/unlock the driver’s door.
A
KEYLESS ACCESS SYSTEM
The Keyless Access System enables operation of the doors,
ignition and liftgate without removing the Remote Keyless Entry transmitter from your pocket or purse. The transmitter must be
within 3 feet of the door being unlocked or the liftgate.
Keyless Unlocking
With the transmitter within range:
Press the lock button on the driver’s door handle to unlock the
driver’s door; press it again within 5 seconds to unlock all doors.
Press the lock button on
a passenger door han dle to unlock all doors.
Press the touch pad
above the license plate to open the liftgate.
Keyless Locking
With the ignition off, the transmitter removed from the vehicle, and all doors closed:
Press the lock button on any door handle to lock all doors
immediately.
If Passive Locking is turned on, all doors will lock automatically
after a short delay once all doors are closed.
Note: To change the door lock and unlock settings, go to Remote Lock, Unlock, Start in the Vehicle Settings menu.
-
See Keys, Doors and Windows in your Owner Manual.
See Keys, Doors and Windows in your Owner Manual.
4
KEYLESS START
ADAPTIVE REMOTE START
Start
With the vehicle in Park or Neutral,
press the brake pedal and then press the ENGINE START/STOP button to start the engine. The green indicator on the button will illuminate.
Note: The transmitter must be in the vehicle to turn on the ignition. If the transmitter battery is weak, place the transmitter in the depression below the Accessory Power Outlet in the center console lower storage area to enable the engine to start.
Cell phone chargers may interfere with the operation of the Keyless Start System and should not be plugged in when starting or turning off the engine.
Stop/Off
Shift to Park and press the ENGINE START/STOP button to
turn off the engine.
Power will be available for 10 minutes to operate the audio system
until the driver’s door is opened and to operate the windows and
sunroof♦ until any door is opened.
Accessory
With the engine off and the brake pedal NOT depressed, press
the ENGINE START/STOP button to place the ignition system in the Accessory mode. The yellow indicator on the button will illuminate. Press the button again to return to the Off position.
See Driving and Operating in your Owner Manual.
Optional equipment
Starting the Vehicle
1. Press and release the
Lock button on the Remote Keyless
Entry transmitter.
2. Immediately press and hold the
Remote Start button until
the turn signal lamps ash.
When the vehicle starts, the parking lamps will light and remain
on while the engine is running. The engine will continue running
for 10 minutes. Repeat these steps for a 10-minute time exten
sion. Remote start can be extended only once.
3. Before driving, press the brake pedal and then press the
ENGINE START/STOP button to turn on the ignition.
Canceling a Remote Start
Press and hold the Remote Start button until the parking
lamps turn off.
Climate Control Operation
During a remote start, the automatic climate control system
will operate at the same setting as when the vehicle was last turned off.
Heated/Ventilated Seat Operation
The heated/ventilated seats will turn on during a remote start (if
selected in the Vehicle Settings menu) when outside temperatures
warrant. The seat button indicators do not illuminate during a remote start.
Note: To change the heated/ventilated seat settings, go to Remote Lock, Unlock, Start in the Vehicle Settings menu.
See Keys, Doors and Windows in your Owner Manual.
5
-
STEERING WHEEL CONTROLS
Cruise Control
On/Off
(On/Off Adaptive
Cruise Control♦)
SET– Set/Coast
Press down the control
bar to set the speed. If active, press down to decrease speed by
1 mph.
RES+ Resume/Accelerate
Press up the control bar to resume a set speed. If active, press up
to increase speed by 1 mph.
Cancel
Press to cancel cruise control without erasing the set speed.
Follow Distance Gap (Adaptive Cruise Control♦)
Press to select a following gap time setting of Far, Medium,
or Near.
See Driving and Operating in your Owner Manual.
CUE System Voice Recognition
Push to Talk
Press to answer an incoming call or to interact with the OnStar,
Bluetooth or CUE system.
End Call/Mute
Press to end/reject a call or mute the audio system.
5-Way Controller
Left/Right
Press to navigate to the left or right cluster display or to toggle to the next or previous menu option.
Up/Down
Press the control bar up or down to scroll through a menu.
SEL Select
Press to select a highlighted menu item.
See Instruments and Controls in your Owner Manual.
Audio Controls
+
Volume
Press + or – to increase or decrease the volume.
Next/Previous
Press
up or
down to select the next or previous favorite
radio station, track, or le.
See Instruments and Controls in your Owner Manual.
Heated Steering Wheel♦
On/Off
See Instruments and Controls in your Owner Manual.
See Instruments and Controls in your Owner Manual.
