SUPER CRUISE™
CONVENIENCE &
PERSONALIZATION GUIDE
2024
cadillac.com
Review this quick reference guide for an overview of the Super Cruise™ driver assistance technology. Some equipment described in this guide may not
be included in your vehicle. Contact your dealer for details on a specific vehicle. All information contained in this guide is based on the latest information
available at the time of printing and is subject to change without notice. More information can be found in your Owner's Manual and at cadillac.com/owners.
Certain restrictions, precautions and safety procedures apply to your vehicle. Please read your Owner’s Manual for complete instructions.
SUPER CRUISE OVERVIEW
Adaptive Cruise
Control Buttons
Due to current supply-chain shortages, certain features shown have
limited or late availability, or are no longer available. See the window
label or your dealer regarding the features on an individual vehicle.
Super Cruise
Button
Steering Wheel
Light Bar
2
Adaptive Cruise
Control Symbol
Driver Attention
Camera
Super Cruise
Symbol
Escalade shown
SUPER CRUISE OPERATION
Super Cruise is a hands-free driver assistance technology
for use on compatible roads. The system steers the vehicle
to maintain lane position or to perform a lane change, under
certain conditions, while also monitoring your attention to
the road. Working with the Adaptive Cruise Control system,
it reduces the need for you to frequently steer, brake or
accelerate under available operating conditions.
When Super Cruise is engaged, the vehicle’s real-time cameras,
sensors, and GPS, used in conjunction with the precision LiDAR
map data, keep the vehicle centered in its lane and traveling
along the lane path while the driver’s hands are removed from
the steering wheel.
Super Cruise can be used while trailering (if properly equipped).
Specific calibrations are designed to account for additional
drag and increased braking distance. Lane Change on Demand
and Automatic Lane Change are not available when trailering.
Always pay attention while driving and when using Super
Cruise. Do not use a handheld device. For compatible roads
and full details, visit cadillac.com/supercruise.
Note: Operation requires an active and eligible Connected Services
plan, working electrical system, cell reception, and GPS signal.
HOW SUPER CRUISE WORKS
Super Cruise driver assistance technology is available only on
compatible roads. The GPS uses real-time corrections and map
data to determine the vehicle’s location while the Lane Sensing
Camera detects the marked lanes on the road to help the
vehicle steer and maintain lane position.
The system works with Adaptive Cruise Control, which detects
vehicles traveling in the same direction in your path and
accelerates or brakes your vehicle to maintain a driver- selected
following distance
gap from a vehicle
detected ahead,
even in stopand-go traffic
conditions.
When engaged,
Super Cruise
indicators and
messages on
the instrument
cluster, along
with the steering
wheel light
bar and voice
CT5-V shown
prompts, provide
feedback on
system status,
while the Driver
Attention Camera
ensures the driver
is paying attention
to the road ahead.
The steering
wheel light bar
intuitively provides
a status of system
operation, including
when the system is
steering and when
you need to manually
LYRIQ shown
steer the vehicle. You can override Super Cruise at any time by
steering, braking or accelerating.
3
Some equipment shown may not be included in your vehicle.
SUPER CRUISE OPERATION ENGAGING SUPER CRUISE
In addition, by monitoring the driver's head position and eye
gaze, the Driver Attention Camera lets you know when you need
to pay more attention to the road ahead. Alerts may prompt
you to pay close attention to the road and steer manually when
needed.
To steer manually, hold the steering wheel firmly with both
hands on the sensing areas, highlighted below, on the
wheel.
In situations in
which the driver
doesn't respond to
the series of Super
Cruise alerts, the
vehicle will come
to a controlled
stop in its lane
and an OnStar
EmergencyCertified Advisor
will be connected
to the vehicle to
provide support.
Super Cruise will
be disabled until
the next ignition
cycle.
It's extremely important that you pay attention to the operation
of the vehicle, even while using Super Cruise. Always be
prepared to take over operation of the vehicle at all times.
See Driving and Operating in your Owner’s Manual.
To use the Super Cruise driver assistance technology,
Adaptive Cruise Control must be On.
1. Press the
Adaptive Cruise
Control button
(A) on the
steering wheel
to turn on the
system. The
symbol (C)
will illuminate
in white on the
Cluster Display.
If the system
is already set,
the will be
green with a
speed shown.
Note: Press and
hold the Cancel
button to switch from
regular Cruise Control
to Adaptive Cruise
Control.
2. When Super
Cruise detects
you are on a
compatible road
and paying sufficient attention, and all other driving
conditions are met (lane markings visible, GPS available,
no system faults, etc.), the
illuminate in white on the Cluster Display.
B
Super Cruise symbol (D) will
A
Escalade shown
A
LYRIQ shown
B
4
ENGAGING SUPER CRUISE
3. When it is safe
to do so, press
the Super
Cruise button
(B) on the
steering wheel
to engage
Super Cruise.
The symbol
(E) and steering
wheel light bar
illuminate in
green when
Super Cruise
is steering the
vehicle.
If Super Cruise
is engaged and
the symbol
and steering
wheel light bar
illuminate in
blue, the driver
is still in control
of steering
and Super Cruise is not steering the vehicle. Position the
vehicle in the center of the lane until the symbol and
light bar turn green.
4. Once Super Cruise controls the steering, and traffic, local
laws, and other conditions permit, and it is safe to do so,
your hands can be taken off the steering wheel. The vehicle
can be steered manually at any time.
C
D
E
When Super Cruise is engaged, the Forward Collision System
will be set to the Alert and Brake setting.
If an Adaptive Cruise Control speed was not previously set,
the current speed will be the cruise set speed used by Super
Cruise.
To disengage Super Cruise, press the Super Cruise
button again, press the brake pedal, or press the Regen on
Demand paddle (LYRIQ model).
SUPER CRUISE AVAILABILITY
Super Cruise is available to be used when:
• Adaptive Cruise Control is On.
• The vehicle is on a compatible road, which generally only
allows high-speed traffic and is separated from opposing
traffic. Super Cruise may be available on non-divided roads
that are mapped, outside of urbanized areas and have a
road speed limit above 45 MPH.
• Camera or radar sensors are not obstructed or damaged.
• Lane markings are clearly visible. Do not use Super Cruise in
poor weather conditions or when visibility is limited.
• Driver attention is detected.
• Teen Driver is not active.
Super Cruise should not be used in complex or uncertain
driving conditions, including: in construction zones; when
approaching an intersection controlled with a traffic light, stop
sign or other traffic control device; on winding or hilly roads; in
tunnels; or in heavy traffic. Always make sure traffic conditions
are safe before using Super Cruise.
See Driving and Operating in your Owner’s Manual.
5
Some equipment shown may not be included in your vehicle.
STEERING WHEEL LIGHT BAR INDICATORS
When the Super Cruise driver assistance technology is not engaged, the light bar will not be visible on the steering wheel and the
Super Cruise symbol on the Cluster Display will be illuminated in white or will not be illuminated. You must steer the vehicle.
When Super Cruise is engaged, the steering wheel light bar and Super Cruise symbol indicate system status.
Solid Green Bar
and Solid Green
Symbol
Flashing Green Bar
and Solid Green
Symbol
Pulsing Blue Bar
and Solid Blue
Symbol
Flashing Red Bar,
Solid Red Symbol,
and Safety Alert
Seat Pulses or
Beeps Sound
Flashing Red Bar,
Solid Red Symbol,
Safety Alert Seat
Pulses or Beeps
Sound, and Voice
Prompt
Super Cruise is active and steering the vehicle. This is the only
time you may remove your hands from the steering wheel.
Super Cruise is active, but the system detects that you need to
pay more attention to the road.
Super Cruise is active, but the system detects that you are
manually steering. To return to Super Cruise steering, position
the vehicle in the center of the lane and hold the steering wheel
steady until the green indicators appear.
You need to take steering control immediately. The system
cannot operate properly under current conditions. Firmly hold
the steering wheel with both hands on the sensing areas of the
wheel. The vehicle will begin to coast until you take steering
control. Super Cruise must be re-engaged to use the system
again.
You need to take steering control immediately. A voice prompt
will tell you to take over steering control. Firmly hold the steering
wheel with both hands on the sensing areas of the wheel. If you
do not take steering control, the vehicle will steer and brake
gradually to a stop. Super Cruise will not be available until the next
ignition cycle and an OnStar Emergency-Certified Advisor will be
notified to provide support for the driver.
6
See Driving and Operating in your Owner’s Manual.
ATTENTION ALERTS
DRIVER ATTENTION CAMERA
When the Super
Cruise driver
assistance
technology is
engaged, the
Driver Attention
Camera, located
on top of the
steering column,
determines if the
driver's attention
is on the road
ahead. Itworks
with infrared lights to track head position and eye gaze to
determine where you are looking.
Note: The Driver Attention Camera does not record or share photos, audio
or video.
1ST ALERT
If the system detects that you may not be paying sufficient
attention to the road ahead, the steering wheel light bar
flashes green to prompt you to return your attention to the
road.
The light bar will stop flashing when the system detects your
attention to the road has resumed.
The Driver Attention Camera needs to see the driver's entire
face clearly. If the steering wheel light bar flashes green
while you are paying sufficient attention, your face may be
obstructed. It may be necessary to adjust the angle of the
steering wheel and your seating position.
2ND ALERT
If the steering wheel light bar flashes green for too long and
the system detects continued inattentiveness to the road
ahead, the steering wheel light bar flashes red to notify you to
look at the road and steer the vehicle manually. Firmly hold the
steering wheel with both hands on the sensing areas of the
wheel.
In addition to the
steering wheel
light bar flashing
red, beeps also
sound or the
Safety Alert Seat
pulses (if selected).
Tochange the
Safety Alert
Seat setting,
go to Settings >
Vehicle >
Collision/
Escalade shown
Detection
Systems >
Alert Type.
The vehicle will not
accelerate while
the light bar is
flashing red. Super
Cruise must be
re-engaged to use
the system again.
CT4 shown
7
Some equipment shown may not be included in your vehicle.
ATTENTION ALERTS
The steering wheel light bar will also flash red when:
• Adaptive Cruise Control is canceled.
• The vehicle is on a tight curve or speed is too fast.
• Lane markings are poor or visibility is limited.
• The compatible road ends.
• The vehicle is approaching an intersection controlled by a
traffic light, stop sign or other traffic control device.
• There is a system fault.
3RD ALERT
If the steering
wheel light bar
flashes red for
too long, a voice
prompt will be
heard. Firmly hold
the steering wheel
with both hands on
the sensing areas
of the wheel to
steer manually.
You should take
over steering immediately; otherwise, the vehicle will slow in
your lane of travel and eventually brake to a stop. Super Cruise
and Adaptive Cruise Control will disengage.
In the event of an unresponsive driver, the vehicle will come
to a controlled stop in its lane, activate the hazard lights, and
contact an OnStar Emergency-Certified Advisor.
See Driving and Operating in your Owner’s Manual.
MESSAGING
Super Cruise driver assistance technology may not be available
or may disengage when active based on several operating
conditions. Use the
wheel to view Cluster Display messages about system
operation.
If the
Super Cruise
symbol does
not appear,
press the
Super Cruise
button to
display a
message
about why
the system is
unavailable.
Immediately after Super Cruise disengagement, press the
message with the reason for disengagement.
Refer to your Owner’s Manual for summaries of all messages.
See Driving and Operating in your Owner’s Manual.
Super Cruise button (within 10 seconds) to display a
Super Cruise
button on the steering
8
CHANGING LANES
MANUALLY CHANGING LANES
The vehicle can be steered manually at any time when the
Super Cruise driver assistance technology is engaged.
1. Verify the next
lane is clear and
conditions are
safe to make a
lane change.
2. Move the
steering wheel
manually by
holding the
steering wheel
with both hands
on the sensing
areas of the wheel. The steering wheel light bar pulsesblue.
3. Steer the vehicle into the desired lane.
4. To allow Super Cruise to resume steering, center the
vehicle in the lane until the light bar turns green.
AUTOMATIC LANE CHANGES
When engaged, Super Cruise can automatically perform a
single lane change under certain conditions if enabled in the
Vehicle Settings. Automatic Lane Change is not available when
trailering.
To enable Super Cruise lane changes, go to Settings >
Vehicle > Collision/Detection Systems > Super Cruise Lane
Change.
The system may automatically perform a lane change to the
left to pass a slower-moving vehicle ahead and a subsequent
lane change to the right to return to the original lane. The
system also may automatically perform a lane change to the
left or right when the current lane is ending ahead or when a
slower moving vehicle is detected in the adjacent ending lane to
provide space for the merging vehicle.
LANE CHANGE ON DEMAND
With Super Cruise engaged, the driver can direct the system
to perform a single lane change using the turn signal. Lane
Change on Demand is not available when trailering.
1. Verify the next
lane is clear and
conditions are
safe to make a
lane change.
2. Activate the
turn signal in
the direction
of the desired
lane change
by briefly
pressing and
releasing the turn signal lever or moving the lever fully up
or down. The turn signals will remain active while Super
Cruise completes the lane change. Super Cruise will steer
the vehicle to perform the lane change if it detects traffic is
clear. A message on the Cluster Display shows the status of
the lane change.
3. Return the turn signal lever to the neutral position after the
lane change if it was moved fully up or down.
To cancel a lane change, return the turn signal lever to the
neutral position, move the lever in the opposite direction of
the lane change, or steer manually at any time.
See Driving and Operating in your Owner’s Manual.
9
Some equipment shown may not be included in your vehicle.
DRIVER ASSISTANCE
INFORMATION
On CT4 and CT5 models, Driver Assistance information can be
viewed on the instrument cluster, if selected.
INFORMATION ZONE OPTIONS
1. Use the or button on the steering wheel 5-way
controller to select the desired menu to show in the
Interactive Information Zone.
2. Use the thumbwheel on the steering wheel 5-way controller
to scroll through the available selections in each menu.
3. Press the thumbwheel to select the menu option.
See Instruments and Controls in your Owner's Manual.
CONNECTED SERVICES
REQUIRED CONNECTED SERVICES PLAN
Super Cruise functionality is enabled by a data connection for
real-time, precise positioning and periodic Super Cruise map
updates. In order to operate Super Cruise, an active and eligible
Connected Services plan is required.
Note: To learn more about Connected Services, press the blue OnStar
button, visit onstar.com, or call 1-888-466-7827.
See OnStar in your Owner’s Manual.
MAP DATABASE
Super Cruise driver assistance technology uses a LiDARscanned map database, which restricts system use to
compatible roads.
Visit cadillac.com/supercruise to view compatible roads near you.
MAP UPDATES
Super Cruise map updates and GPS enhancement data are
automatically downloaded to the vehicle. Super Cruise will
be disabled if updates do not occur and the map reaches 7
months old.
If the map is not updated after 7 months, a message will be
displayed on the Cluster Display indicating that service is
needed. See your Cadillac dealer.
See Driving and Operating in your Owner's Manual.
10
USING SUPER CRUISE
RESPONSIBLY
Super Cruise is a driver assistance technology. Your complete
attention is always required while driving since unexpected
steering or braking may occur if the system does not correctly
detect lanes, vehicles or traffic situations ahead, or if situations
occur that the system cannot detect, including cross-traffic.
Do not use a hand-held device while driving, even with Super
Cruise engaged.
The system is designed to maintain the current lane. You need
to take control to steer around a traffic situation or object,
merge into traffic, make a turn, and exit the road. You must also
stop the vehicle for crossing traffic and at a traffic light, stop
sign or other traffic-control device. The system does not detect
if you are drowsy or focused on safe driving. Always be ready
to take action and take over steering or apply the brakes.
Super Cruise:
• Does not prevent crashes or warn of possible crashes.
• Does not steer to avoid stopped or slow-moving vehicles,
cross-traffic, construction barriers or cones, motorcycles,
children, pedestrians, animals, or other objects on the road.
• Does not steer in response to vehicles or objects next to
your vehicle, including vehicles attempting to enter your
lane.
• Does not respond to traffic lights, stop signs, or other
traffic control devices.
• Does not respond to crossing or oncoming traffic.
• Does not make turns.
• Does not steer to merge onto or to exit roads.
• Does not steer to avoid or steer through construction
zones.
•
Does not function in city driving conditions.
USING SUPER CRUISE
RESPONSIBLY
Some state and local laws may not permit hands-free driving. In
these locations, use Super Cruise by lightly holding the steering
wheel at all times. Always know the rules in your area.
Super Cruise is available on additional roads, including areas
of divided roads that have limited crossings. Under certain
conditions, such as when approaching an intersection, Super
Cruise uses the high-precision map to hand control of the
vehicle back to you. It is important that you always stay
engaged and vigilant at all times while driving.
See Driving and Operating in your Owner’s Manual.
SYSTEM CARE
Super Cruise driver assistance technology operates using
the front and rear radars, front camera, and Surround Vision
cameras. Keep the surfaces of these systems clean for proper
Super Cruise operation.
Clean the lens cover of the Driver Attention Camera on the
steering column with a soft cloth sprayed with glass cleaner as
needed.
Note: We recommend any required service on the Super Cruise system be
performed by an authorized Cadillac dealer.
See Vehicle Care in your Owner’s Manual.
11
OWNER PRIVILEGES™
ROADSIDE ASSISTANCE 1-800-224-1400
TTY Users: 1-888-889-2438
Roadside Assistance provides every Cadillac owner with
the advantage of contacting a Cadillac advisor and, when
appropriate, a Cadillac-trained dealer technician who can
provide on-site services, including towing service, battery jump
starting, lock-out service, fuel delivery and flat tire assistance.
Services are provided for up to 6 years/70,000 miles,
whichever occurs first.
OnStar® Roadside Assistance
If you have a current OnStar Safety & Security plan, press the
blueOnStar button or red Emergency button (for emergencies
only) to get the help you need. An OnStar advisor will use GPS
technology to pinpoint your vehicle location and contact the
nearest service provider.
To learn more about OnStar services, press the blue OnStar
button,call 1-888-466-7827, visit onstar.com or refer to your
Owner’s Manual.
CUSTOMER ASSISTANCE 1-800-333-4223
Cadillac Customer Assistance is available anytime to answer
questions or provide additional information.
We recommend always using ACDelco or GM Genuine Parts.
Some equipment described in this guide may not be included in your vehicle. Contact your dealer for details on a specific
85137426 A
vehicle. All information contained in this guide is based on the latest information available at the time of printing and
is subject to change without notice. Certain restrictions, precautions, and safety procedures apply to your vehicle.
Please read your Owner’s Manual for complete instructions. Copyright 2023 General Motors LLC. All Rights Reserved.
myCADILLAC MOBILE APP
Download the myCadillac app to your compatible smartphone
(ordevice) and, if your vehicle is properly equipped, you can
use your device to start or turn off your vehicle, lock or unlock
your doors, view key diagnostic information, see your parking
location and more.
The app is available on select Apple® and Android™ devices. Service
availability, features and functionality vary by vehicle, device and data
plan. Device data connection required. Visit onstar.com for more details.
Download the mobile app from the App Store or Google Play Store.
CADILLAC ONLINE OWNER CENTER
Create an account at cadillac.com/owners
to access personalized information, including
an online Owner’s Manual and helpful howto videos; track your service history and
warranty status; manage your OnStar and
Connected Services vehicle plans; review
your current Vehicle Diagnostics report
(active service account required) andmore.
12
Loading...
