1INTRODUCTION
This reference manual describes the console commands for the SmartCell 6A000 and SmartCell ZX-250 ATM
switches. The two switches share a common console interface and are referred to in this manual as the SmartCell
6A000/ZX-250.
Audience and Scope
The manual is intended for network administrators and o thers responsible for maintaining the SmartCell
6A000/ZX-250. You do not need to read the manual f rom start to fini sh. You can use it to study the console commands
you use.
Definitions
The manual is organized alphabetically by switch attribute.
•The definition of a switch attribute is a function that manipulates the switch in a specific way. For
example, buselan.
•The definition of an operator is the active verb that makes the switch attribute perform a specific
task. For example, show.
•The definition of a command is the combination of an operator plus a switch attribute. For exam ple,
show buselan.
Content
•Chapter 2, "SmartCell 6A0 00/ZX-250 Command s," gives definitio ns, descriptions, and examples of
all available commands on the SmartCell 6A000 and SmartCell ZX-250 switches.
•Chapter 3, “Boot Load Commands” gives definitions, descriptions, and examples of the low-level
boot load commands.
•Appendix A, "Acronyms," spells out t he ATM acronyms used in thi s manual as wel l as tho se found
in the SmartCell 6A000 User Guide, SmartCell ZX-250 User Guide, and SmartCell ZX
Administrator Installation Guide.
•Appendix B, “Cause Codes,” describes the codes that appear in some console messages.
•Appendix C, "Technical Support," gives instructions for contacting Cabletron by telephone, fax,
electronic mail, and the World Wide Web.
SmartCell 6A000/ZX-250 Reference Manual 1-1
Introduction
Sections
Read "Switch Attribute" for an example and definition of the various sections under each switch attribute as well as a
description of how the manual is organized.
Each section begins with a switch attribute heading (for example, "PVCByID"). Then come the details of relevant
operators, parameters, and commands.
Most sections have two parameter tables—one for input and another for output. The tables contain the parameter
names, descriptions, and definitions of their values, field sizes, and defaults.
The section ends with examples copied from the switch console for each console command for that switch attribute.
Conventions
The SmartCell 6A000/ZX-250 Reference Manual uses the following conventions to convey instructions and
information:
•Information you enter (console commands an d input parameters) is shown in bold Courier 10 font
and requires a space between operator and switch attribute.
•Input and output parameters are shown in [Square Brackets].
•Input definitions are shown in <anglebrackets>, as joined text and not case sensitive.
•Filter flags </s> (summary) or </d> (detail) are available with certain show commands and apply to
different information viewing levels. Filter flags require a space between them and the full
command. For example, show client /d. The/s option is the same as the standard default option. You
can find more details at the relevant switch attribute sections. See the following examples:
switch_prompt # show client
ClientNumber(ALL) :
Client Type IP Address Server Type Server Conn Status
==============================================================================
1 LANE 90.1.1.186 LECS Established Operational
3 IP/ATM 90.1.1.124 Local Established Operational
switch_prompt #
switch_prompt # show client /s
ClientNumber(ALL) :
Client Type IP Address Server Type Server Conn Status
==============================================================================
1 LANE 90.1.1.186 LECS Established Operational
3 IP/ATM 90.1.1.124 Local Established Operational
switch_prompt #
switch_prompt # show client /d
ClientNumber(ALL) :
LANE Client 1
==============================================================================
Client State : Operational
Client Address : 39:00:00:00:00:00:00:00:00:00:14:15:00:00:20:D4:14:15:00:00
LAN Name : elan1
LECS Addr Source : ILMI
LECS Address : 39:00:00:00:00:00:00:00:00:00:14:15:00:00:20:D4:14:15:00:01
LES Address : 39:00:00:00:00:00:00:00:00:00:14:15:00:00:20:D4:14:15:00:02
LAN Type : 802.3
MTU : 1516
IP Address : 90.1.1.186
1-2 SmartCell 6A000/ZX-250 Reference Manual
Introduction
IP NetMask : 255.255.255.0
IP/ATM Client 3
==============================================================================
Client State : Operational
Client Address : 39:00:00:00:00:00:00:00:00:00:14:15:00:00:00:5A:01:01:7C:00
Server : is local
Server Connection : Established
MTU : 9180
IP Address : 90.1.1.124
Abbreviations
Pay close attention to how switch attributes appear in each section heading. Switch attributes are not case sensitive. If
the heading states B USStat, you must t ype
See the following example:
switch_prompt # show busstats
Command busstats not Valid for Action show
Type Help <command> for help
switch_prompt #
busstat and not busstats, because the switch will not recognize the latter .
switch_prompt # show busstat
ELANNumber(ALL) :
BUS ELANs
============================================================================
ELAN ELAN000 Statistics
Out Octets : 0
Out Unicast : 0
switch_prompt #
You can, ho wever, abbreviate the switch attribute to the extent that it is unique. For example, instead of typing show
porttrafficcongestion, you can just type show portt. The same can be done with operators. Instead of typing modify,
you can type mod. You should type at least three characters for any operator. For example,
switch_prompt # mod portm
PortNumber(ALL) :
PortMode(SONET) :
switch_prompt #
See "Switch Attribute" for an explanation of how the sections are organized.
SmartCell 6A000/ZX-250 Reference Manual 1-3
Introduction
Help Options
If you want information on a specific command, type ? or help before typing the command and you will g et a brief
description of the command and all its input parameters. If you want information about a specific input parameter while
executing a command, type
parameter. For example,
switch_prompt # ? add lecselan
Create/Add ELAN for LECS(LECSELAN)
============================================================================
ELANNumber ELAN Number in the range 0-127
ELANName ELAN Name ( max. length 32 characters)
LESAddress ATM Address for the LES
ELANType 802.3 : Ethernet or 802.5 : TokenRing
MTU Maximum Frame Size - 1516(def for 802.3), 4544(def for 802.5), 9234
TLVSet TLV Set Number in the range 1-65535
switch_prompt #
switch_prompt # add lecselan
ELANNumber(0) : ?
ELAN Number in the range 0-127
ELANName(ELAN000) : ?
ELAN Name ( max. length 32 characters)
LESAddress(39:00:00:00:00:00:00:00:00:00:14:15:00:00:20:D4:14:15:00:02): ?
ATM Address for the LES
ELANType(802.3) : ?
802.3 : Ethernet or 802.5 : TokenRing
MTU(1516) : ?
Maximum Frame Size - 1516(def for 802.3), 4544(def for 802.5), 9234
TLVSet() : ?
TLV Set Number in the range 1-65535
LECSELAN 0 already exists
switch_prompt #
? or help after it appears on the console and it will give you details relating to that
Other Reference Options
You will fin d a lis t of acron yms, details about technical support, and an index at the back of this manual. The index
contains page references for all switch attribute sections, command parameters, op erators, comman d descriptions and
command examples. There is also a table of commands at the end of this chapter. It lists all switch attributes by their
operator.
See the SmartCell 6A000 User Guide and SmartCell ZX-250 User Guide for details on how to use the switch. Th e user
guides contain information about switch configuration, maintenance, and SNMP (simple network management
protocol), as well as an overview of switch capabilities.
1-4 SmartCell 6A000/ZX-250 Reference Manual
Introduction
Switch Attribute
This section—immediately below the headin g—gives a brief descripti on of what the switch attri bute does. A detailed
description of each command is available under "Descriptions."
SERVERSVC
XX
"X" under any of these headings indicates the switch attribute is applicable to that software type.
Parameters
Operators make the switch attribute work. Operators pertaining to each switch attribute are listed immediately below
the "Operators" heading. The command is the switch attribute combined with the operator. A list of possible switch
operators follows. You can use an alias when a word in parentheses appears. However, only the operators not in
parentheses are used in this manual.
Table 1-1 List of Operators
OperatorAction
add (create)Adds new object
activateActivates an existing but deactivated object
backupBacks up switch configuration
clearClears (initializes to 0) properties of an object
disableLowers privilege level
deactivateDeactivates an existing object
delete (remove)Deletes existing object
enableRaises privilege level
exitExits from console
flushFlushes all entries
historyShows past console commands
modify (set)Sets properties of an existing object
SmartCell 6A000/ZX-250 Reference Manual 1-5
Introduction
(
)
Table 1-1 List of Operators
Continued
OperatorAction
passwdChanges passwords
rebootReboots the switch
restartRestarts LANE and IP-ATM clients
restoreRestores switch configuration
setupSets up switch
show (display)Shows properties of an object
OPERATORACTION
shutdownShuts down switch
startStarts server
stopSto ps server
updateUpgrades firmware
Operators
Table 1-2 Operator Table Explanation
ParameterDescriptionValue/Field SizeDefault
[Input or Output Field]
(</d>)
What the switch puts on your screen (either as inpu t
or output) relating to the console command you are
executing. The [InputParameter] is an entry you
Unit of measurement/
Maximum field size
for input entry.
need to complete if you do not accept the default.
The [OutputParameter ] shows in for mation f rom th e
switch. Requires no input. This example is available
only within the detailed information table.
Parameters appear in the parameter tables in the same order and spelling as the switch shows them.
Option
offered by
the switch.
Most switch attribute descriptions show two tables —Input Parameter and Output Parameter. If the parameter has
already been described in the input parameter table, no reference to it appears in the output parameter table. The output
parameter table contains only parameters that have not been described in the input parameter table or that are written
very differently on output despite having the same meaning.
1-6 SmartCell 6A000/ZX-250 Reference Manual
Introduction
Only one parameter table in a switch attribute section means either that switch attribute uses only input parameters or
that the output parameters are identical to the input parameters. The heading of the table indicates which is the case. If
the table heading says Input Parameter or Output Parameter, only input or output parameters apply to this switch
attribute. However , if the table headi ng says Par ameter, the table contains both input and output parameters, and their
field names and definitions are identical.
Some output parameters show either (</d>) or (</s>) to indicate that a filter flag is available and that parameter is
available only when you type either /d (detailed information) or /s (summarized information) after the command. If
you do not type these command extensions, the parameters do not appear. Further explanations are given at relevant
sections. See "SVC" for an example.
The following table gives details about several of the most common parameters in this ma nual; a shorter description
of these parameters appears at the relevant sections within the manual:
Table 1-3 Parameter Table Explanation
ParameterDescriptionValue/Field SizeDefault
[PortNumber]Port number on the switch. Port
numbers can be any of the physical
ports on the local switch. Specifying
"ALL" causes all related values for the
ports to be affected by the command.
Port B4 is the CPU port. The
SmartCell 6A00 0/ZX-250 reser ve
this port for use by the CPU for local
servers and clients. Therefore, B4
port is usually not listed. Only ALL,
ALL or A1
A1-A4, B1-B3, C1-C4, and D1-D4
are listed.
[ATM Address] ATM address assigned to the port,
client, or server according to ATM
Forum specifications.
13-20 bytes. Hex-based,
dot-decimal format separated by
colons/
usually no default
59 characters
[ClientNumber] Number of the client. Each client on
the switch must have a unique client
0 through 127/
Up to 3 characters
ALL
number. Client numbers are shared
between LAN emulation (LANE)
clients and IP/ATM (IP over ATM)
clients.
With [Index Number], [PortNumber ], [Client Numb er], and other paramet ers that default to "ALL", unless you specify
a number at that input field, the switch gives ALL information pertaining to that parameter field.
SmartCell 6A000/ZX-250 Reference Manual 1-7
Descriptions
Table 1-4 Description Table Explanation
OperatorParameters/PermissionsDescription
Introduction
console
command
[InputParameter] <whatyoutype>
(Privilege level this console command
allows:)
Administrator or All
This section provides detailed descriptions of the command
(operator and switch attribute) and discusses what the
command does and how and when it is used. Other relev ant
information appears here.
The following is an example of a description section. It is located under "BUSELAN." Note the detailed description
of the command following the table.
Changes the behavior of the BUS parameter s for a
specified ELAN. The specified ELAN is then
>
deleted and recreated. If the corresponding
LESELAN exists, then the modified BUSELAN
>
should have the same characteristics as that
existing LESELAN because their parameters need
to match.
Examples
Examples are copied exactly from the switch console to show you what yo u should see. They appear at the end of each
section in the same order as the operators are listed at the start of each section. There is no significance to the order in
which the examples appear, except that show usually appears after the other command exam ples to demonstrate ho w
a command can change a characteristic of the switch. Unless they fit on the current page, examples usually begin at
the top of a page. The location of every command example appears in the index under "Examples".
Examples show how you must enter console commands at the switch prompt (indicated in bold - modify buselan
(console command)). The other bold text (1, 103, pvc, 802.5, 4544) is the input parameters that modify this switch
attribute (BUSELAN). The text in brackets (immediately following the parameter field - for example,
ELANType(802.3)) indicates the current default. See the following examples.
ELAN : elan103
ELAN Number : 103
ELAN Name : elan103
ATM Address :39:00:00:00:00:00:00:00:20:D4:14:15:00:00:20:D4:14:15:66:02
Max Frame Size : 4544
Connection Method : PVC
Distribute VPI/VCI: 0/50
LAN Type : 802.5
Multipoint : YES
switch_prompt #
)Four-character name of the software submodule that
) (summarized) appears next to a parameter to indicate that this parameter appears in
</s>
message buffer.
generated the log and alarm entries.
generated the log entry that created this alarm message.
) indicates parameters that are available only through the
</d>
1, 2, 3, 4.../
n/a
ALL
1, 2, 3, 4...
See Software Modules Table under “LogTrace” .
See Software SubModules Table under
“LogTrace” .
show alarm
SmartCell 6A000/ZX-250 Reference Manual 2-1
Output ParameterDescriptionDefault
Console Commands
[TimeStamp] (</s>)Time (in system up time) when the alarm message entry
was created. The time stamp is in the format
[hrs:mins:secs:msecs].
[Message] (</s>)Numeric code that specifies the message in the log entry
that generated this alarm message. Actual alphanumeric
message is not stored with the alarm because of the
limited space within the flash files.
[SequenceNum] (</d>)Sequence number (within the log message buffer) o f the
log message entry that generated this alarm message
entry.
[NumParameters] (</d>)Number of informational pa rameters within alarm
message entry.
[LogLevel] (</d>)Log debug level of the log message th at caused the alarm
message to be generated.
[Parameter] (</d>)List of parameters displayed by the alarm message.
Fields include parameter number , type, length , and value.
The following parameters are visible only with flush alarm:
n/a
n/a
1, 2, 3, 4...
1, 2, 3, 4...
1, 2, 3, 4...
n/a
[Alarm directory]Name of the directory within the flash file system that
contains the alarm message buffer.
[AlarmConfig file]Name of the file that contains the current configuration of
the alarm message buffer.
[Alarm Filename]Base name of the set of files within the flash file system
where alarm messages are stored. Alarm message file
names are composed of the base name and a numeric
offset.
[Num of alarm files]Number of alarm files (within the flash file system) to be
used for saving alarm messages.
[Starting file number]Offset to starting file for alarm messages in relation to
number of alarm message files stated by [Num of alarm files].
[Num of used files]Number of files currently used within the alarm message
buffer.
ALARM
alarmc.db
zalarm
32
0
0
2-2 SmartCell 6A000/ZX-250 Reference Manual
Console Commands
Output ParameterDescriptionDefault
[Num of logs per file]Number of alarm messages that can be held by each file
within the alarm message buffer.
Descriptions
OperatorParameters/PermissionsDescription
show alarm(/s | /d)
[Index] <index>
Administrator
clear alarm
AdministratorClears the current alarm message and alarm configuration files
Displays alarm messages contained within the alarm message
buffer. Alarm messages are referred to by their index numbe rs.
Index numbers correspond to the order in which an alarm
message is logged into the alarm message buffer.
The amount of information displayed is controlled by
alarmverbose
described on page 9. Alarmverbose has two
,
additional options —/s (summary) and /d (detail) filter flags.
These filter flags control the amount of information displayed
only when alarmverbose is on. When alarmverbose is off,
and
display the same information.
/d
from the buffer for saving or showing alarms. If the alarm
message file is cleared, all currently stored alarm messages are
cleared as well. You must confirm that you wish to clear the
alarm before you can continue to clear the alarm configuration
file. If you respond n to the clear alarm confirmation prompt, it
assumes you have canceled the command. If you respond y, you
will see details of the alarm configuration file. You must
confirm at this prompt also before the command is completed.
Use
add alarmconfig on page 6 to create an alarm message
buffer file again
8
modify
/s
flush alarm
AdministratorFlushes alarms and deletes saved alarm messages from the flash
file system. You must confirm at the prompt before the
command is completed. Use
add alarmconfig on page 6 to
create an alarm message buffer file again.
SmartCell 6A000/ZX-250 Reference Manual 2-3
Console Commands
Examples
(AlarmVerbose is off)
switch_prompt # modify alarmverbose
Mode(On) : off
Setting Alarm Verbose Mode to Off
switch_prompt # show alarm 1 /s
---------------------------------------------------Num Mod SubMod T(h:m:s:ms) Msg
---------------------------------------------------1 HW LINK 000:00:13:886 14910: Port (null) DOWN
switch_prompt # show alarm 1 /d
----------------------------------------------------------------------------------------Num Mod SubMod T(h:m:s:ms) Msg Seq L P P-532387424(TLV) P-532387424(TLV) P-532387424(TLV)
----------------------------------------------------------------------------------------1 HW LINK 000:00:13:886 14910: Port (null) DOWN 1 2 3
switch_prompt # modify alarmverbose
Mode(Off) : on
Setting Alarm Verbose Mode to On
switch_prompt # show alarm 1 /s
---------------------------------- AlarmNumber : 1
Module : HW
SubModule : LINK
TimeStamp : 000:00:13:886
SequenceNum : 1
NumParameters : 3
LogLevel : 2
Parameter : Num Type Len Val
: 0 STR 0 -531130720(0xe05796a0)
: 1 INT 0 2(0x2)
: 2 STR 0 -535494944(0xe014fee0)
Message : [14910] Port (null) DOWN
switch_prompt # show alarm 1 /d
---------------------------------- AlarmNumber : 1
Module : HW
SubModule : LINK
TimeStamp : 000:00:13:886
SequenceNum : 1
NumParameters : 3
LogLevel : 2
Parameter : Num Type Len Val
: 0 STR 0 -531130720(0xe05796a0)
: 1 INT 0 2(0x2)
: 2 STR 0 -535494944(0xe014fee0)
Message : [14910] Port (null) DOWN
switch_prompt #
switch_prompt # clear alarm
Confirm(y/n)?: y
2-4 SmartCell 6A000/ZX-250 Reference Manual
Console Commands
Writing into Alarm Configuration
Alarm directory : ALARM
Alarm Config file : alarmc.db
Alarm Filename : zalarm
Num of alarm files : 32
Starting file number: 0
Num of used files : 18
Num of logs per file: 8
Would you also like to clear this Alarm Configuration file(y/n)?: y
switch_prompt #
switch_prompt # flush alarm
Writing into Alarm Configuration
Alarm directory : ALARM
Alarm Config file : alarmc.db
Alarm Filename : zalarm
Num of alarm files : 32
Starting file number: 0
Num of used files : 18
Num of logs per file: 8
Confirm(y/n)?: y
switch_prompt #
SmartCell 6A000/ZX-250 Reference Manual 2-5
Console Commands
g
AlarmConfi
Use AlarmConfig (alarm configuration) to determine alarm message buffer file configuration.
SERVERSVC
XX
Operators
add, modify, show
Parameters
Input ParameterDescriptionValue/Field SizeDefault
[AlarmNumFiles]Number of alarm files (within the flash file
system) to be used for saving alarm messages.
[StartFileNum]Offset to the starting file for alarm messages in
relation to number of alarm message files
specified by [AlarmNumFiles].
[NumFilesUsed]Number of files currently used within the alarm
message buffer (cannot exceed number of files to
store alarms).
[NumAlarmsPerFile]Number of alarm messages that can be stored per
file within the alarm message buffer. Using a
smaller value results in less file system rewriting
but increases the space wasted per entry, as each
file has fixed overhead.
Output ParameterDescriptionDefault
1, 2, 3, 4.../
1-32
0, 1, 2, 3, 4.../
n/a
0, 1, 2, 3, 4.../
n/a
0, 1, 2, 3, 4.../
n/a
32
0
0
8
[Alarm directory]Name of the directory within the flash file system that contains the alarm
message buffer.
2-6 SmartCell 6A000/ZX-250 Reference Manual
ALARM
Loading...
+ 238 hidden pages
You need points to download manuals.
1 point = 1 manual.
You can buy points or you can get point for every manual you upload.
