Page 1
INTREPID
10 x 42 Binocular
Page 2
3
2
HD
TM
Objective Lens
Ocular Lens
IPD
The eyecups on a Intrepid HD binocular twist up and down
so any viewer can see the full field and enjoy comfortable
viewing—with or without eyeglasses.
When not using eyeglasses or sunglasses,
keep the eyecups fully extended. For
the best viewing when viewing through
eyeglasses, twist eyecups down.
Adjust the interpupillAry distAnce
The interpupillary distance (IPD) is the distance between the
centers of the left and right eye pupils. Match the IPD of your
eyes to that of the binocular so that you see a single image that
is free of shading.
Basic OperatiOn
Adjust the eyecups
Rotate the binocular barrels inward or
outward to line your eyes up with ocular
lenses.
Distance between the centers of the
ocular lenses.
Twist-up Eyecup
Strap
Attachment
Center Focus
Locking
Diopter
Page 3
5
4
HD
TM
properly focus the binoculAr
For the best views, follow this two-step
process to properly adjust the center
focus and diopter. Choose an object
that is about 20 yards away from you
and stay in the same spot until you have
adjusted the binocular for your eyes.
1. Adjust the center focus—start by closing your right eye
or covering the right objective lens with your hand. Focus
your left eye on the object and
adjust the center focus wheel until
the image is in focus. Leave the
center focus in this position as you
adjust the diopter.
2. Adjust the diopter—start by
closing your left eye or covering the left objective lens
with your hand. Lift the diopter ring to unlock and, looking
through your right eye, adjust the diopter so that the
object is in focus. Make note of this
diopter setting in case you need to
set it again. Push the diopter ring
down to lock—from this point on,
you will only need to use the center
focus wheel.
The Intrepid HD comes with a rainguard for the ocular lenses
and tethered objective lens covers. Use these covers to
protect the lenses whenever you are not viewing.
lens covers
The protective case of the Intrepid HD provides safe storage
between viewing sessions. The carry strap is already attached
to the case.
cArry cAse
accessOries
Attach the padded neckstrap to the Intrepid HD in three
simple steps. Begin with the right barrel of the binocular and
repeat the process for the left barrel.
neckstrAp
1. Push a few inches
of the strap through the
strap attachment on the
binocular.
3. Adjust the overall length,
then pull tight until strap
secured within the buckle.
2. Hold the buckle and thread
the end of the strap through
the buckle.
Note: If using another type of strap, never attach metal o-rings directly onto the strap
attachment.
Adjust Diopter Setting
Page 4
7
6
HD
TM
Caution: Binoculars are not intended for looking
at the sun, or any other intense light source. Such
viewing could damage the retina and cornea of your
eyes—even to the point of causing blindness.
Lens care
Maintain the optical brilliance of the Intrepid HD binocular
by keeping lens surfaces free of dirt, oils, and dust.
protect lenses while out in the field
Make use of the provided eyepiece and objective lens covers
to protect the lenses when not viewing. Then, store the
Intrepid HD in its carry case between viewing sessions.
keep lenses cleAn
In order to enjoy the best views through your Intrepid HD
binocular, take time to regularly clean the exterior lenses:
1. Remove any dust or grit from lenses before wiping. Use
a can of pressurized air, soft camel hair brush, or an acrylic
optical brush.
2. Clear lenses of smudges, fingerprints, or eyelash oil. Fog
the lenses with your own breath, then use a non-abrasive lens
cloth to clean the lenses. Alternately, use a lens cleaning fluid
and optical paper to clean lenses.
Never use facial tissue, heavy cotton, or flannel
clothing on lenses—these materials can scratch the
surface of a lens.
the Vip Warranty
We build optics based on our commitment to your
absolute satisfaction. That’s why our products are
unconditionally guaranteed and we make this Very
Important Promise to you—a Very Important Person.
Rest assured that in the event your Intrepid HD binocular
becomes damaged or defective, we will repair or replace
the binocular at no charge to you. Call us at 800-4260048 for prompt, professional, and friendly service.
2120 West Greenview Drive
Middleton, WI 53562
service@vortexoptics.com
Visit vortexoptics.com for more information. Canadian
customers may visit vortexcanada.net for customer service
information.
The VIP Warranty does not cover loss, theft,
deliberate damage or cosmetic damage that does not
hinder the performance of the product.
Page 5
RZR-2100-12-A
©Vortex Optics USA
INTREPID
10 x 42 Binocular
BIN_INT-101-2/16
