Page 1

ACE Canada

Library Reference

ACE Canada 7.80c Revision 1

September 2007

Page 2

Contact information Contact us on the Web at http://www.firstlogic.com/customer

If you find any problem with this documentation, please report it to Business Objects in writing at

Patents Business Objects owns the following U.S. patents, which may cover products that are

[email protected]

offered and sold by Business Objects: 5,555,403, 6,247,008 B1, 6,578,027 B2, 6,490,593 and 6,289,352.

Trademarks Business Objects, the Business Objects logo, Crystal Reports, and Crystal Enterprise

are trademarks or registered trademarks of Business Objects SA or its affiliated companies in the United States and other countries. All other names mentioned herein may be trademarks of their respective owners.

Third-party contributors Business Objects products in this release may contain redistributions of software

licensed from third-party contributors. Some of these individual components may also be available under alternative licenses. A partial listing of third-party contributors that have requested or permitted acknowledgments, as well as required notices, can be found at: http://www.businessobjects.com/thirdparty

ACE Canada Library Reference

Page 3

Preface

Purpose and contents of this manual

This manual is a training aid and reference for programmers working with the ACE Canada Library (CACE). The first chapter explains how to make your application work with the library. Chapters 2, 3, and 4 contain detailed reference pages about each of the function calls.

In writing this manual we have assumed that you already are familiar with the C programming language, your operating system, and with basic concepts of database management, mail processing, and address processing.

Installation To install the ACE Canada Library and postal directories, please follow the

instructions in our System Administrator’s Guide. The ACE Canada Library will be installed in a directory called cacelib.

Sample application program

The ACE Canada Library comes with source code for a simple application program called caddrtst. It is an interactive program (using the standard I/O) for processing individual addresses. While you’re becoming acquainted with ACE, you may find it helpful to refer to the source-code file, caddrtst.c, for examples of ACE calls.

Please note that this program is an example intended for use only as a learning tool. It is not a prototype or product per se. We do not support or authorize any use for commercial purposes, and we disclaim any warranty regarding such use.

Conventions This document adheres to the following documentation conventions:

Convention Description

Bold We use bold type for file names, paths, emphasis, and text that you

should type exactly as shown. For example, “Type

Italics We use italics for emphasis and text for which you should substitute

your own data or values. For example, “Type a name for your file, and the

.txt

Menu commands

extension (

We indicate commands that you choose from menus in the following format: Menu Name > Command Name. For example, “Choose File > New.”

We use this symbol to alert you to important information and potential problems.

We use this symbol to point out special cases that you should know about.

We use this symbol to draw your attention to tips that may be useful to you.

testfile

.txt

).”

cd\dirs

.”

Page 4

Documentation

Other documentation Documentation related to this product .

Your complete ACE documentation set includes the following:

 ACE Canada Library Reference  Quick Reference for Library Products  System Administrator’s Guide  Database Prep

Access the latest documentation

You can access documentation in several places:

 On your computer. Release notes, manuals, and other documents for each

product that you’ve installed are available in the Documentation folder. Choose Start > Programs > Business Objects Applications > Documentation.

 On the Customer Portal. Go to www.firstlogic.com/customer, and then

click the Documentation link to access all the latest documentation. You can view the PDFs online, save them to your computer, or order professionally printed documents that will be delivered to you. To order printed documents, see the following instructions.

ACE Canada Library Reference

Page 5

Chapter 1:

How to set up the ACE Canada library ...................................................... 7

How to install and make executables ...............................................................8

Error handling ..................................................................................................9

Three options for initialization and termination.............................................10

ACE function calls for address processing ....................................................13

Address input and output................................................................................14

Chapter 2:

Functions for basic address processing ..................................................... 17

cace_AAS(), cace_AAS_file().......................................................................18

cace_cfg_open(), cace_cfg_close(), cace_cfg_read() ....................................20

cace_evaluate_ah() .........................................................................................22

cace_findf() ....................................................................................................23

cace_get_cert_expire_date(), cace_get_cert_version() ..................................24

cace_get_component(), cace_get_source() ..................................................25

cace_get_error_info() .....................................................................................26

cace_get_file_date() .......................................................................................27

cace_get_lettermatch(), cace_get_simil().......................................................28

cace_get_line_name().....................................................................................29

cace_get_offset() ............................................................................................30

cace_get_revision() ........................................................................................31

cace_get_stats() ..............................................................................................32

cace_init(), cace_term()................................................................................33

cace_init_addr(), cace_term_addr() .............................................................34

cace_open(), cace_close() ............................................................................35

cace_set_error_rtn() .......................................................................................36

cace_set_file(), cace_get_file() ....................................................................37

cace_set_input_length(), cace_get_input_length().......................................38

cace_set_line(), cace_get_line() ...................................................................39

cace_set_mode(), cace_get_mode() ...............................................................40

cace_set_option(), cace_get_option().............................................................41

Chapter 3:

Suggestion lists............................................................................................. 43

How to handle suggestion lists.......................................................................44

cace_get_sugg()..............................................................................................45

cace_get_sugg_cmpt()....................................................................................47

cace_get_suggno()..........................................................................................48

cace_set_range().............................................................................................49

cace_set_sugg() ..............................................................................................50

How to customize suggestion lists .................................................................51

cace_set_sugg_filter() ....................................................................................53

cace_set_sugg_option(), cace_get_sugg_option() .........................................54

Contents

Page 6

Chapter 4:

How to query the postal directories .......................................................... 55

Introduction to directory queries.................................................................... 56

How to query the Canadian national directory .............................................. 57

cace_clear_query()......................................................................................... 58

cace_get_query()............................................................................................ 59

cace_init_query() ...........................................................................................61

cace_init_show()............................................................................................ 62

cace_set_query() ............................................................................................ 63

cace_show() ................................................................................................... 64

cace_term_show(), cace_term_query().......................................................... 65

How to query the City and FSA directories................................................... 66

cace_ll_clear_query()..................................................................................... 67

cace_ll_get_query() .......................................................................................68

cace_ll_init_query().......................................................................................69

cace_ll_init_show()........................................................................................ 70

cace_ll_set_query()........................................................................................ 71

cace_ll_show()............................................................................................... 72

cace_ll_term_show(), cace_ll_term_query() ................................................. 73

Appendix A:

GeoCoding .................................................................................................... 75

Set up GeoCoding.......................................................................................... 77

Index.............................................................................................................. 79

ACE Canada Library Reference

Page 7

Chapter 1: How to set up the ACE Canada library

This chapter explains how to initialize the ACE Canada library, and how to control the way that ACE Canada processes your addresses. It also describes error handling, initializing and terminating configuration files, as well as function calls for address processing.

Chapter 1: How to set up the ACE Canada library

Page 8

How to install and make executables

Microsoft Windows We provide the ACE Canada Library as a 16 or 32-bit dynamically linked library

(DLL). Versions of the DLL are available for Windows NT/2000/XP/2003 Server.

Install ACE Canada following the instructions in our System Administrator’s Guide. ACE Canada will be installed in \pw\cacelib.

We support a variety of Windows compilers and programming languages, including Microsoft C, Visual C++, and Visual Basic. The compiling instructions below are for the Windows SDK and Microsoft C 8.0. If you use any other language, contact us for instructions.

We provide a make file that you may use as an example. The command to make caddrtst is:

C:\PW\CACELIB> nmake caddrtst.mak

Unix Install ACE Canada following the instructions in our Unix System

Administrator’s Guide. ACE Canada will be installed in .../postware/cacelib.

We compile ACE Canada with the cc(1). Specify the operating system and hardware platform as arguments to your compiler command, as shown in the command line below.

To compile our sample program on a Hewlett-Packard 9000 series, use mk_caddrtst or:

$ cc -DPS_UNIX -DPS_UNIX_HP caddrtst.c -o caddrtst lcace -lmas -llgen -loptec -lgmi

-lliud -lpsthr

ACE Canada Library Reference

Page 9

Error handling

Many ACE functions return the same data that they output. This makes these functions easy to use in printf() statements. However, there may be no error indication other than an empty return.

Some ACE functions return CACE_ERROR when the execution results in an error. Any

Default error handling Some languages do not support function pointers. If you cannot set your own

error handler, ACE will present error messages directly to the end user:

 Most versions will present a printf() message on the standard out.

 Windows DLLs will present a pop-up window (a default MsgBox).

CACE_ERROR return indicates a fatal error.

Setting your own error handler

You may set up a callback (or exit, if you prefer that term) to your own errorhandling function. Call cace_set_error_rtn() with a pointer to your function.

ACE will call your function whenever any ACE function returns

CACE_ERROR.

Your function can then process the error as desired. Your function may call cace_get_error_info() to obtain error information. These functions give you an error-code number, as well as two character strings that provide additional information about the error or status.

The Visual Basic compiler now supports passing function pointers. So if you are using version 5.0 or later, you can create your own error-handling function. Your function must be in a .bas file. Here is an example:

Function ErrorHandler() As Integer Dim errorcode As Integer Dim title As String * CACE_ERR_MAX_MSG_LEN Dim msgbody As String * 1000

cace_get_error_info errorcode, title, msgbody MsgBox msgbody End Function

When you register your error handler with ACE, be sure to use the AddressOf operator. For example:

Call cace_set_error_rtn(AddressOf ErrorHandler)

Chapter 1: How to set up the ACE Canada library

Page 10

Three options for initialization and termination

ACE stores configuration settings, file handles, and input and output data in a structure called the address handle (graphic, page Address input and output). Most ACE functions require the address handle as an input parameter. Most of the work of initializing ACE is about preparing the address handle. ACE offers three ways to initialize and terminate the address handle:

 Full use of configuration files, with minimal API function calls. This

approach is good for fast prototyping and some applications.

 Selective use of configuration files and API function calls. This method was

developed specifically for client/server applications, where some aspects of configuration are set on the client side, by an end user (style options, choice of input fields) and other aspects (pathnames of auxiliary files) need to be set on the server side, by an administrator.

 No use of configuration files; do everything with API function calls. This

approach gives the application engineer maximum flexibility and control, but requires more coding.

The sections below explain the typical function-call sequence for each method. For the moment, we’ll skip over address processing (page ACE function calls for address processing), and focus only on initialization and termination. For simplicity, some optional “get information” calls are ignored. In addition, we’ll say only a little about the optional functions covered in chapters 4 and 5.

Option #1: Full use of configuration files and minimal API function calls

1. Call cace_init() to allocate memory and initialize global data for ACE.

2. Call cace_cfg_open() open the directories and initialize an address handle based on settings in the configuration files. An error in a configuration file will cause this function to return CACE_ERROR, so the error handler will be invoked.

3. Recommended: If you intend to use your own function for handling errors, call cace_set_error_rtn() to set up your function. Inside your function, you may call cace_get_error_info() to retrieve information about errors.

4. Process addresses as explained on page ACE function calls for address processing.

5. Optional: Call cace_AAS() to generate the Address Accuracy Statement.

6. Call cace_cfg_close() to close the ACE auxiliary files and free the address handle.

7. Call cace_term() to free global memory used by ACE.

ACE Canada Library Reference

Page 11

Option #2: Selective use of configuration files and API function calls

1. Call cace_init() to allocate memory and initialize global data used by ACE.

2. Call cace_init_addr() to allocate and initialize an address handle.

3. Recommended: If you intend to use your own function for handling errors,

call cace_set_error_rtn() to set up your function. Inside your function, you may call cace_get_error_info() to retrieve information about errors.

4. Call cace_cfg_read() up to three times, to load settings from three

configuration files. The table below shows the API calls that you can skip if you use each configuration file—or, viewed the other way, the API calls you must make if you are not using a particular configuration file.

Config file API calls

Auxiliary Call

Options By default, ACE standardizes addresses in a style fully conforming

Input_Fields ACE offers a set of about two dozen input fields. These are

cace_set_file

to the SERP testing regulations of Canada Post. You are not required to process your own data in SERP-conforming style. If you wish, you may call of your choosing. SERP rules and the stylistic options are fully explained in the

explained in the will use, call

cace_evaluate_ah

set up.

() to register the pathnames of the auxiliary files.

cace_set_option

ACE User’s Guide

Quick Reference

cace_set_input_length

() to verify that a valid combination of fields is

() as necessary to set stylistic options

. Having selected which fields you

() once per field. Then call

5. Call cace_open() to open the auxiliary files.

Your address handle should now be ready to begin processing addresses.

6. Process addresses as explained on page ACE function calls for address

processing.

7. Optional: Call cace_AAS() to generate the Address Accuracy Statement.

8. Call cace_close() to close the ACE auxiliary files.

9. Call cace_term_addr() to free the address handle.

10. Call cace_term() to free global memory used by ACE.

Chapter 1: How to set up the ACE Canada library

Page 12

Option #3: No use of configuration files; do everything with API function calls.

1. Call cace_init() to allocate memory and initialize global data used by ACE.

2. Call cace_init_addr() to allocate and initialize an address handle.

4. Call cace_set_file() to register the pathnames of the auxiliary files.

5. Call cace_open() to open the auxiliary files.

6. ACE offers a set of about two dozen input fields. These are explained in the Quick Reference. Having selected which fields you will use, call cace_set_input_length() once per field. Then call cace_evaluate_ah() to verify that a valid combination of fields is set up.

7. Optional: By default, ACE standardizes addresses in a style fully conforming to the SERP testing regulations of Canada Post. You are not required to process your own data in SERP-conforming style. If you wish, you may call cace_set_option() as necessary to set stylistic options of your choosing. SERP rules and the stylistic options are fully explained in the ACE User’s Guide.

8. Optional: If you intend to support suggestion lists, you may need to call some of those functions to set up handling and options. See Chapter 4 for details.

Your address handle should now be ready to begin processing addresses.

9. Process addresses as explained on page 13.

10. Optional: Call cace_AAS() to generate the Address Accuracy Statement.

11. Call cace_close() to close the ACE auxiliary files.

12. Call cace_term_addr() to free the address handle.

13. Call cace_term() to free global memory used by ACE.

ACE Canada Library Reference

Page 13

ACE function calls for address processing

Process addresses 1. Loop through the ACE input fields you chose. Call cace_set_line() to pass

input data one field at a time. If you have no input data for a field, pass an empty string.

2. Call cace_findf() to perform address parsing and directory look-up and

retrieval.

3. Check the return status of cace_findf() and proceed as explained in the table

below.

Return value Action

CACE_ABORT Something bad happened. Time to exit.

CACE_FOUND The address was assigned. Go ahead and retrieve the pro-

cessed address data from ACE. Most applications make a combination of calls to

cace_get_component

14.

CACE_

ERROR_E* The address was not assigned. (To find out why not,

check the C standardized the address and populated the output lines and components as best it can. The extent of standardization is very modest, and some components are blank.

ACE_ERROR_CODE

cace_get_line

(). Read more about this on page

() and

component.) ACE has

Go ahead and retrieve the processed address data from ACE. Most applications make a combination of calls to

cace_get_line

about this on page 14.

CACE_USER_CITY CACE_USER_ADDRESS

CACE_INVALID_HANDLE The address handle was invalid. This error might occur in

Invoke your suggestion-list handler. (See Chapter 4 for information about handling suggestion lists.)

debugging but should not occur in a tested, production application.

() and

cace_get_component

(). Read more

Chapter 1: How to set up the ACE Canada library

Page 14

Address input and output

You will pass input address data to ACE by calling cace_set_line() once for each input field to be loaded. Then call cace_findf() to process the address. For output, ACE offers two methods. The diagram on the next page may be helpful.

 Choose cace_get_line() when you want to keep output address data in the

same arrangement of fields as were input.

ACE applies intelligent abbreviation, when necessary, to keep the data within the lengths you specified via cace_set_input_length().

Data is capitalized and standardized according to way you set those stylistic options.

 Choose cace_get_component() when you want the output address broken

down into smaller elements than you input (as shown in diagram). Also you can retrieve additional fields created by ACE, such as the error/status code.

You may retrieve unstandardized or standardized components by setting a flag with your call. To obtain the best setting for this flag, we recommend that you call cace_get_source().

The style of standardized components is partially controlled by the stylistic options. No abbreviation is applied.

If you retrieve a component that is part of something larger, the stylistic option will apply. For example, within CACE_ADDRESS, the abbreviated or spelled-out style of suffix and directional is controlled by those options. The same is true for the place-name conversion of city name within CACE_LASTLINE.

But if your retrieve the suffix, directional, or city name by itself, then the stylistic option does not apply. Instead, you make your stylistic choice by selecting from two or three flavors of components, each with a different symbol. For example, compare CACE_SUFFIX with CACE_APL_SUFFIX.

Line and component symbols are defined in cace.h and explained in our Quick Reference. Line symbols all begin with

CACE_*.

with

CACE_I* and components simply begin

ACE Canada Library Reference

Page 15

Think of the address handle as having four sections or quadrants. When you call cace_set_line(), you are loading one line in the first quadrant (upper left corner of diagram). ACE populates the other three quadrants when you call cace_findf().

StandardizedUnstandardized

cace_set_line()

Lines

Components

cace_get_component( …, CACE_OLD, …)

Input Lines

CACE_ILASTLINE

•

CACE_IADDRESS

•

...

Parsed, Unstandardized Components

CACE_CITY

•

CACE_PROVINCE

•

CACE_POSTAL

•

CACE_PRIM_RANGE

•

CACE_PRIM_NAME

•

CACE_SUFFIX

•

CACE_DIR

•

CACE_UNIT_DESIG

•

CACE_SEC_RANGE

•

...

Standardized Lines

CACE_ILASTLINE

•

CACE_IADDRESS

•

...

Parsed, Standardized Components

CACE_CITY

•

CACE_PROVINCE

•

CACE_POSTAL

•

CACE_PRIM_RANGE

•

CACE_PRIM_NAME

•

CACE_SUFFIX

•

CACE_DIR

•

CACE_UNIT_DESIG

•

CACE_SEC_RANGE

•

...

cace_get_line()

cace_get_component(

…, CACE_NEW, …)

Chapter 1: How to set up the ACE Canada library

Page 16

ACE Canada Library Reference

Page 17

Chapter 2: Functions for basic address processing

This chapter contains reference data about ACE functions for ordinary address processing. Chapters 3 and 4 describe other functions used in more advanced programs.

Chapter 2: Functions for basic address processing

Page 18

cace_AAS(), cace_AAS_file()

Synopsis char* cace_AAS(ten parameters);

CADDR_HANDLE cah; Input: address handle

int ext_ascii; Input: use extended ASCII to draw lines

char* list_processor; Input: company name of list processor char* mailers_address1; char* mailers_address2; Input: mailing company’s name char* mailers_address3; and address char* mailers_address4; char* cpc_number; Input: Canada Post customer number char* list_name; Input: name of list processed char* file_name; Input: name of file processed

int cace_AAS_file(eleven parameters);

CADDR_HANDLE cah; Input: address handle

char* report_file; Input: path and name of output file int ext_ascii; Input: use extended ASCII to draw lines

TRUE FALSE

Description Both functions generate a facsimile of the CPC form, “Statement of Address

Accuracy.” (For background information and a sample, refer to the ACE User’s Guide.) The cace_AAS() function writes the report into a character array. The

cace_AAS_file() function places the report directly into a file (which it creates, opens, writes, and closes).

ASCII

The ext_ascii parameter controls whether ACE will use extended characters to draw smooth lines on the form. If your printer does not support extended The remaining parameters all correspond to blanks on the AAS form.

ACE Canada Library Reference

ASCII, set FAL SE , and ACE will instead use simple lines and dashes.

Page 19

Returns The cace_AAS() function returns a pointer to a character array containing the

form. It is your responsibility to free the memory allocated for this array. If for some reason the form could not be built (perhaps because memory for it could not be allocated), then cace_AAS() returns

NULLP.

The cace_AAS_file() function returns

CACE_ERROR if the file could not be opened and closed, or the report could not

be written. It returns

CACE_INVALID_HANDLE if the input address handle was

CACE_OK if successful. It returns

invalid.

Chapter 2: Functions for basic address processing

Page 20

cace_cfg_open(), cace_cfg_close(), cace_cfg_read()

Synopses int cace_cfg_open(two parameters);

char* pathname; Input: pathname of overall config file

CADDR_HANDLE* cah; Output: address handle

int cace_cfg_close(one parameter);

CADDR_HANDLE* cah; Input: address handle

int cace_cfg_read(three parameters);

CADDR_HANDLE cah; Input: address handle

int config_type; Input: config file type

CACE_CFG_AUXILIARY_FILES

CACE_CFG_INPUT_FIELDS

CACE_CFG_OPTIONS

char* pathname; Input: pathname of overall config file

Description CACE supports four types of configuration files. The “vanilla” configuration files

(table below) may be found in your cacelib subdirectory. You should copy these files before edit them, and use your own filenames.

The configuration files are heavily commented. There is no separate or further documentation for the parameters in these files.

Type of file Original name Description

Overall

Auxiliary

Input_Fields

Options

cace.cfg

caceaux.cfg

caceflds.cfg

caceopts.cfg

Pathnames of the other three configuration files.

Pathnames of the directories, dictionaries, etc.

Selection and lengths of input fields

Style and suggestion-list options.

The cace_cfg_open() function opens the auxiliary files and initializes one address handle based on settings in configuration files. It calls cace_init_addr() and

cace_open(). The cace_cfg_close() function calls cace_term_addr() and cace_close().

The cace_cfg_read() function is an alternative to cace_cfg_open(). It is provided for client/server or other applications where you may need to employ configuration files selectively. For example, in a client/server environment, the Options and Input_Fields files might be set on the client side, by the end user, while the Auxiliary file would be on the server side, and set by an administrator.

The cace_cfg_read() function loads settings into an address handle which you must provide. This means that you must make your own call to cace_init_addr(). Likewise, cace_cfg_read() does not open the auxiliary files, so you must make your own call to cace_open().

Returns Returns CACE_OK if successful; otherwise, CACE_ERROR. An error usually

indicates that something is wrong in one of the configuration files. Returns

CACE_INVALID_HANDLE if the input address handle was invalid.

ACE Canada Library Reference

Page 21

cace_evaluate_ah()

Synopsis int cace_evaluate_ah(one parameter);

CADDR_HANDLE cah; Input: address handle

Description The cace_evaluate_ah() functions checks the input address structure for validity.

You do not have to call cace_evaluate_ah(), but if you do, call it after cace_init_addr().

Returns Returns CACE_OK if the input lines structure is valid for parsing. Returns

CACE_INVALID_HANDLE if the input address handle was invalid. Returns CACE_ERROR if an internal error occurred. The following returns indicate a

problem in the selection of input fields:

Symbol Description

CACE_2MANYLINES Too many fields were set. For example, you would get

this error if you set up 18 or more input lines.

Note:

The discrete, province, and postcode count as one line. The discrete country filed is valid with any combination of input fields.

CACE_BADMLP An invalid combination of input fields was set. For

example, you would get this error if you have not selected any fields for address-line data. Or if you select any of the multiline fields while also selecting the discrete address-line, last-line, or city/state/postalcode fields.

CACE_DUP_LL_FIELDS You have set up too many last-line fields. If you are

using CACE_ILASTLINE, you should not also use the city, province, or postal code fields for input.

CACE_MULTI1 The multiline fields defined don't start with

CACE_ILINE1. If you have three multiline fields, you must use CACE_ILINE1-3, not 4-6, for example.

CACE_MULTI2 The multiline fields are not consecutive. For example,

you would get this error if you set up the multiline fields CACE_ILINE1, CACE_ILINE3, and CACE_ILINE4.

CACE_NO_AL_FIELDS You have not set up any field(s) for address-line data.

CACE_NO_LL_FIELDS You have not set up enough fields for last-line data.

You must set either the last-line field or a combination of city, province, postal code.

ACE Canada Library Reference

Page 23

cace_findf()

Synopsis int cace_findf(one parameter);

CADDR_HANDLE cah; Input: address handle

Description The cace_findf() function searches for the address in the postal databases, assigns

postal codes, and writes the standardized address into the data structure pointed to by the address handle.

Returns The cace_findf() call may return any of the following codes.

Symbol Description

CACE_FOUND The address was assigned. Go ahead and retrieve the processed address data from ACE Can-

ada. Most applications make a combination of calls to

cace_get_component

CACE_USER_ADDRESS The last line was matched, but the address line was not. An address suggestion list was gener-

ated. Invoke your suggestion-list handler. (See Chapter 4 for information about handling suggestion lists.)

CACE_USER_SECONDARY A SECONDARY address suggestion list was generated. Invoke your suggestion-list handler.

(See Chapter 4 for information about handling suggestion lists.)

CACE_USER_CITY The last line was not matched. A last-line suggestion list was generated. Invoke your sugges-

tion-list handler. (See Chapter 4 for information about handling suggestion lists.)

CACE_ERROR_E* The address was not matched and no suggestion list could be generated. ACE has standard-

ized the address and populated the output lines and components as best it can. The extent of standardization is very modest, and some components are blank.

().

cace_get_line

() and

Go ahead and retrieve the processed address data from ACE. Most applications make a combination of calls to page .

Note: To find out why the address was not assigned, check the C nent. Error defines all end with a three-digit error number. The of these numbers and a description of each error condition.

CACE_INVALID_HANDLE The address handle was invalid. This error might occur in debugging but should not occur in a

tested, production application.

CACE_ABORT A fatal error occurred. Something bad happened. Time to exit.

Example

CADDR_HANDLE cah;

ret = cace_findf(cah);

cace_get_line

() and

cace_get_component

(). Read more about this on

ACE_ERROR_CODE

Quick Reference

compo-

presents a list

Chapter 2: Functions for basic address processing

Page 24

cace_get_cert_expire_date(), cace_get_cert_version()

Synopses char *cace_get_cert_expire_date(one parameter);

char *serp_expiry_date; Output: expiration date string

char *cace_get_cert_version(one parameter);

char *serp_version; Output: software version string

Description ACE offers two functions that you can use to retrieve information about our

SERP certification. Both functions return strings.

 Call cace_get_cert_expire_date() to retrieve the date that SERP recognition

will expire, in dd-mmm-yyyy format.

Note: The U.S. ACE program offers a similar function. However, that function

produces the date on which CASS certification was achieved, not when it will expire.

 Call cace_get_cert_version() to retrieve the product name and version

number, as they appear on the SERP recognition. For example: “

ACE CANADA

2.30”

POSTWARE

Returns Both functions return the same buffer pointer that you passed in.

ACE Canada Library Reference

Page 25

cace_get_component(), cace_get_source()

Synopsis char* cace_get_component(four parameters);

CADDR_HANDLE cah; Input: address handle

int component; Input: component name int oldnew_flag; Input: original or standardized address

CACE_OLD CACE_NEW

char* comp_data; Output: retrieved data

int cace_get_source(two parameters);

CADDR_HANDLE cah; Input: address handle

int component; Input: component name

Description You can use cace_get_component() to retrieve from ACE any component from

either the original (input) or the standardized address.

Before calling cace_get_component(), call cace_get_source() for advice. The cace_get_source() function returns the “best” source for the component type passed in. To retrieve any component of the original address, set oldnew_flag to

CACE_OLD; to get a component of the standardized address, use CACE_NEW.

Symbols for component are listed and explained in our Quick Reference.

The receiving buffer should be long enough to contain the longest possible component being retrieved. Instead of a fixed number of characters, you may want to use the also an

CACE_component_LEN definition. These lengths are defined as the

CACE_MAXFLD_LEN constant. For each component, there is

maximum length plus one (for the null terminator).

Returns The cace_get_component() function returns a pointer to a buffer containing the

requested component. If any of the input parameters is invalid, the buffer will be empty. There is no error indication.

CACE_OLD or CACE_NEW. Returns

Example

The cace_get_source() function returns

CACE_INVALID_HANDLE if the input address handle was invalid.

int oldnew_flag; char streetname[CACE_PRIM_NAME_LEN]; oldnew_flag = cace_get_source(cah, CACE_PRIM_NAME); cace_get_component(cah, CACE_PRIM_NAME, &oldnew_flag, streetname);

Chapter 2: Functions for basic address processing

Page 26

cace_get_error_info()

Synopsis int cace_get_error_info(four parameters);

CADDR_HANDLE cah; Input: address handle

int *err_code; Output: error code char *message1; Output: error type message char *message2; Output: specific error message

Description When any ACE function returns CACE_ERROR, you can get information about

the error by calling cace_get_error_info(). This function produces an error code number, as well as two character strings that provide additional information about the error or status. The first string provides a short error description and the second provides additional details. The second string is usually the name of the file that was being processed when the error occurred.

The buffers receiving message1 and message2 should be large enough to contain the descriptive strings. Instead of a fixed number of characters, you may want to use the constant

Returns Returns CACE_INVALID_HANDLE if the input address handle was invalid;

otherwise,

CACE_ERRMSG_LEN.

CACE_OK.

Example

CADDR_HANDLE cah; int err_code; char msg1[CACE_ERRMSG_LEN]; char msg2[CACE_ERRMSG_LEN];

if (cace_open() == CACE_ERROR) { cace_get_error_info(cah, &err_code, msg1, msg2); printf("Error number %d has occurred\n", err_code); printf("%s\n, %s\n", msg1, msg2); exit(err_code);

}

cace_get_file_date()

Synopsis char* cace_get_file_date(three parameters);

CADDR_HANDLE cah; Input: address handle

int

file_ID; Input: file identifier

CACE_DIR_CAN CACE_DIR_CITY CACE_DIR_FSA CACE_DIR_PCI

CACE_DCT_ADDRLN CACE_DCT_LASTLN CACE_DCT_CAP

CACE_DIR_ADDRESS_GEO CACE_DIR_CENTROID_GEO

char* date_string Output: date directory or dictionary was

generated

Description These functions extract a date from the directory and return it as a date_string in

the format mm/yyyy (for example, 06/1998). This is the date that we processed the directory. It is not the file timestamp.

This also returns a creation date of dictionaries. These dates are returned in DDMMM-YYYY format. For example,

You mu st ca ll cace_open() before calling cace_get_file_date(). If the directory has not been opened, the date_string buffer will be blank.

Returns Returns the same pointer to the date_string buffer that you passed in. The

date_string buffer will be empty if either of the input parameters was invalid.

Example

printf("The directory date is %s\n", cace_get_file_date(cah, CACE_DIR_CAN, date_string));

Chapter 2: Functions for basic address processing

Page 28

cace_get_lettermatch(), cace_get_simil()

Synopses int cace_get_lettermatch(two parameters);

CADDR_HANDLE cah; Input: address handle

int component; Input: component name

CACE_PRIM_NAME CACE_CITY

int cace_get_simil(two parameters);

CADDR_HANDLE cah; Input: address handle

int component; Input: component name

CACE_PRIM_NAME

CACE_CITY

Description

If your address data has been drastically abbreviated or truncated, this can occasionally cause a bad match to the postal directories. For example:

Input name: Standardized to:Should be: RIVERCR ST RIVER STRIVERCREST ST MILW RD MILL RDMILWAUKEE RD

If you wish, you can detect such errors by calling cace_get_lettermatch() and/or cace_get_simil(). Run the test after cace_findf() returns, but before writing the standardized address into the database file. When you detect a possibly incorrect standardization, you might set aside the addresses so that it can be processed manually.

Returns The cace_get_lettermatch() function returns TRUE if, and only if, every letter in

the input component also appears in the name CACE assigned. It is not sensitive to the order of letters. If the return is

FALSE, this means that the letters in the

input name do not all appear in the output name.

The cace_get_simil() function returns an integer percentage between 0 and 100. This provides a relative measure of the similarity of the original name to the standardized name. The higher the return value, the greater the before-and-after similarity. It’s up to you to decide what threshold score you will use; we suggest 70 as a starting point. The similarity level takes into account both the characterby-character likeness of the names and their length. Case (upper or lower) does not matter; spaces do.

These functions work only on the primary (street) name and city name fields. If you pass in any other component number, these functions will return

CACE_ERROR. Both functions return CACE_INVALID_HANDLE if the input

address handle was invalid.

ACE Canada Library Reference

Page 29

cace_get_line_name()

Synopsis char* cace_get_line_name(two parameters);

int line_ID; Input: line number

CACE_INAME CACE_IFIRM CACE_IADDRESS CACE_ISUITE CACE_ILASTLINE CACE_ICITY CACE_IPROVINCE CACE_IPOSTAL CACE_ICOUNTRY CACE_ILINE1 - 6 CACE_ILANGUAGE

char* line_name; Output: user-friendly line name

Description Given a line_ID, cace_get_line_name() produces an English, user-friendly field

name suitable for use in your user interface. For example, given the input

CACE_ICITY, you get “City”.

Refer to the ACE User’s Guide for discussion of the ACE input fields. You may retrieve the name of any line, whether or not it was activated through cace_set_input_length().

Returns The cace_get_line_name() function returns the same line_name buffer pointer

that you passed in. The buffer will be empty if the input line_ID was invalid. There is no specific error indication.

Chapter 2: Functions for basic address processing

Page 30

cace_get_offset()

Synopsis int cace_get_offset(four parameters);

CADDR_HANDLE cah; Input: address handle

int component; Input: component name int* row; Output: row number ( int* column; Output: column number (zero-based)

Description The cace_get_offset() function can be used to find the position of an input

component within an input field. The function sets parameters for the row number, and the column offset within that row, where the specified component was located. Columns are numbered from zero. If the requested component was not present in the input, row and column will both be set to 1.

Symbols for component are listed and explained in our Quick Reference.

Returns Returns CACE_OK if the request could be fulfilled (even if the component was

not present in the input address); otherwise, returns

CACE_INVALID_HANDLE if the input CADDR_HANDLE is invalid.

ACE_ILINE1, etc.)

CACE_ERROR. Returns

Example

int row, column; CADDR_HANDLE cah;

cace_get_offset(cah, CACE_PRIM_NAME, &row, &column);

printf("Primary Name found in %d row and %d column\n", row, column);

ACE Canada Library Reference

Page 31

cace_get_revision()

Synopsis int cace_get_revision(one parameter);

char* version_string; string identifying CACE and supporting

library versions

Description The cace_get_revision() function produces a string that identifies the version of

ACE Canada being used. It also identifies the version numbers of the underlying support libraries. For example, here is a typical result:

CACE:7.10cr2 LGEN:3.20 OPTEC:3.20 MAS:610a GMI:4 LIUD:3/10

If you call for technical support, you may be asked for this string.

When allocating the version_string buffer, use our defined length,

CACE_MAX_REVISION_STR_LEN.

Returns Returns CACE_OK if successful; otherwise, CACE_ERROR.

Chapter 2: Functions for basic address processing

Page 32

cace_get_stats()

Synopsis int cace_get_stats(two parameters);

CADDR_HANDLE cah; Input: address handle

int component; Input: component name

Description To find out how an address component was standardized, call the function

cace_get_stats() with the name of the component. For a complete list of component names, refer to our Quick Reference.

Note: The return value from this function does not reflect any capitalization changes. Although returned.

CACE_CASE_CHANGED is defined in cace.h, it is never

Returns Returns one of the integers listed at right. Your

program could tally these returns to generate a statistical report. Returns if the input address handle was invalid.

CACE_INVALID_HANDLE

• CACE_SAME

• CACE_MODIFIED

• CACE_DELETED

• CACE_ADDED

ACE Canada Library Reference

Page 33

cace_init(), cace_term()

Synopses int cace_init(no parameters);

int cace_term(no parameters);

Description The cace_init() function initializes global data used internally by the ACE

system. The cace_init() call must precede any other ACE library calls.

The cace_term() function releases all memory allocated by the ACE system functions.

Returns The cace_init() function returns CACE_OK if ACE was successfully initialized;

otherwise,

CACE_ERROR.

The cace_term() function always returns

Example

cace_init_addr(), cace_term_addr()

Synopses int cace_init_addr(one parameter);

CADDR_HANDLE* cah; Output: address handle

int cace_term_addr(one parameter);

CADDR_HANDLE* cah; Input: address handle

Description The cace_init_addr() function creates and initializes the address object and

returns the address handle. This routine allocates memory. It is your responsibility to call cace_term_addr() when the handle is no longer needed. The cace_term_addr() function frees all dynamic memory allocated to the address object and sets the address handle to null.

Important: When you allocate your CADDR_HANDLE, use our type-define

and initialize it to

The cace_term_addr() function is provided for the sole purpose of releasing memory before exiting an application program that uses CACE. It is not necessary to call cace_term_addr() before re-using an address handle.

NULLP.

Returns Both functions can return CACE_OK or CACE_ERROR. The term function also

CACE_INVALID_HANDLE if the input address handle was invalid.

Example

returns

CADDR_HANDLE cah; ret = cace_init_addr(cah);

/* address processing */ cace_term_addr(&cah);

ACE Canada Library Reference

Page 35

cace_open(), cace_close()

Synopses int cace_open(one parameter);

CADDR_HANDLE cah; Input: address handle

int cace_close(one parameter);

CADDR_HANDLE cah; Input: address handle

Description The cace_open() function opens the postal directories, parsing dictionaries, and

other auxiliary files used by the ACE system.

By default, cace_open() expects to find the auxiliary files in the current directory. If the files are located in another directory, you must call the appropriate cace_set_file() functions before cace_open().

The cace_close() function closes all supporting files opened by cace_open(), and releases all memory allocated by the ACE system. It accepts no parameters.

Returns Both functions can return CACE_OK, CACE_INVALID_HANDLE, or

CACE_ERROR.

cace_set_error_rtn()

Synopsis int cace_set_error_rtn(two parameters);

CADDR_HANDLE cah;Input: address handle

int (*routine)(

Description Your application program should include a function to handle error returns from

ACE. Use cace_set_error_rtn() to give ACE a pointer to your error-handling function. ACE will call your function whenever any ACE function returns

CACE_ERROR.

ACE will pass one parameter to your exit function: the address handle. function should return an integer (we suggest Your function may, in turn, call cace_get_error_info() to retrieve error information from ACE. If you would like to see an example of an error-handling function, examine the source code in caddrtst.c.

Returns Returns CACE_OK if the function was successfully registered, or

CACE_INVALID_HANDLE if the input CADDR_HANDLE was invalid.

CADDR_HANDLE);Input: pointer to handling function

You r

TRUE), which ACE will ignore.

Synopsis for your error handler

Example

int my_error_handler(one parameter);

CADDR_HANDLE cah; Input: address handle

NULL

CADDR_HANDLE cah; int myfunction() { printf("ACE has detected an error"); return (TRUE); } cace_set_error_rtn(cah, myfunction);

1. Note: The address handle passed to your error handler will be NULL. In a future release, when ACE Canada becomes thread-safe, a real address handle will be passed.

ACE Canada Library Reference

Page 37

cace_set_file(), cace_get_file()

Synopses int cace_set_file(three parameters);

CADDR_HANDLE cah; Input: address handle

int

file_ID; Input: file identifier (see table below)

char* pathname; Input: pathname

int cace_get_file(three parameters);

CADDR_HANDLE cah; Input: address handle

file_ID; Input: file identifier (same as above)

int char* pathname; Output: pathname

Description By default, CACE expects to find its auxiliary files in the current directory. If you

store them in another location, you must call cace_set_file(), once per file, to register each pathname with CACE. Make these calls before cace_open().

The pathname string may be a full or relative path. When you allocate space for pathname strings, you may use the CACE define

The table at right shows the file_ID symbols and file

Symbol File name Location

CACE_FRM_AAS

names. The locations shown are where our installation programs

CACE_DCT_ADDRLN

CACE_DCT_CAP

will place the files on your development platform. You might use different locations when you install your application on end-user systems.

As an alternative, you may use the

CACE_AUX_CFG_FIL E

configuration file.

When you call

cace_cfg_open() or cace_cfg_read(),

pathname settings will be registered from the configuration file.

CACE_DCT_LASTLN

CACE_DIR_CITY

CACE_DIR_FSA

CACE_DIR_CAN

CACE_DIR_PCI

CACE_KEYFILE

CANALGLOC

CANCTRLOC

CACE_DIR_ADDRESS_ GEO

CACE_DIR_CENTROID _GEO

PATH _M AX .

caceaas.frm

addrlnca.dct

pwcasca.dct

lastlnca.dct

cancity.dir

canfsa.dir

canada.dir

canpci.dir

cacelib.key

canalg.dir

canctr.dir

canalg.dir

canctr.dir

cacelib

dirs

cacelib

dirs

Returns Both functions return CACE_OK, CACE_INVALID_HANDLE, or

CACE_ERROR.

The set function does not test whether the file actually exists at the specified pathname. That test occurs when you call cace_open().

Chapter 2: Functions for basic address processing

Page 38

cace_set_input_length(), cace_get_input_length()

Synopses int cace_set_input_length(three parameters);

CADDR_HANDLE cah; Input: address handle

int line; Input: input/output field int length; Input: maximum length, for standardization

int cace_get_input_length(three parameters);

CADDR_HANDLE cah; Input: address handle

int line; Input: line number int* length; Output: current length

Description Use cace_set_input_length() to set up one input line.

Call it once for each input line that you plan to use.

Symbols for the line parameter are listed at right. For details, refer to our Quick Reference.

With each call, specify a maximum length for standardization. Do not add one byte for the null terminator. ACE will do that for you.

CACE_INAME CACE_IFIRM CACE_IADDRESS CACE_ISUITE CACE_ILASTLINE CACE_ICITY CACE_IPROVINCE CACE_IPOSTAL CACE_ICOUNTRY CACE_ILINE1-6 CACE_ILANGUAGE

After processing the address, ACE writes into the

CADDR_HANDLE structure a similar set of fields, albeit containing standardized

data. When necessary, ACE will abbreviate data to fit the field length you have set. This is important if you are going to use cace_get_line() to retrieve whole fields.

To find out which input fields are currently being used, you may call cace_get_input_length(). It produces the registered length of one line. Any line with a length of zero is not being used.

Returns The set function can return CACE_OK, CACE_INVALID_HANDLE, or

CACE_ERROR. An error return can be caused by a shortage of available memory,

because this function allocates memory.

The get function returns the field length

if the call was successful; otherwise,

CACE_INVALID_HANDLE or CACE_ERROR.

cace_set_line(), cace_get_line()

Synopses int cace_set_line(three parameters);

CADDR_HANDLE cah; Input: address handle

int line; Input: line number (see Quick Reference) char* line_buffer; Input: raw address data

char* cace_get_line(three parameters);

CADDR_HANDLE cah; Input: address handle

int line; Input: line number char* line_buffer; Output: standardized address data

Description The cace_set_line() function loads an input address component into the address

handle.

The cace_get_line() function retrieves one line from the

CADDR_HANDLE

structure.

Note: ACE does not check the size of the receiving line_buffer. It is your responsibility to provide adequate space for the data you retrieve.

Symbols for the line parameter are explained in our Quick Reference.

Caution: Even if you have no data to load, be sure to clear unused lines by

calling cace_set_line() with the empty string (""). ACE never clears the input lines.

Returns The set function can return CACE_OK, CACE_INVALID_HANDLE, or

CACE_ERROR. The get function returns the same line_buffer pointer that you

passed in. If either of the input parameters was invalid, this buffer will be empty; there is no specific error indication.

Example

char line_buffer [80];

cace_set_line(cah, CACE_IPOSTAL, &line__buffer);

ret = cace_findf(cah);

printf("%d/n", cace_get_line(cah, CACE_ILASTLINE, line_buffer0));

Chapter 2: Functions for basic address processing

Page 40

cace_set_mode(), cace_get_mode()

Synopses int cace_set_mode(three parameters);

CADDR_HANDLE cah; Input: address handle

int

mode_ID; Input: mode identifier (see table below)

int mode; Input: desired mode (TRUE/FALSE)

char* cace_get_mode(three parameters);

CADDR_HANDLE cah; Input: address handle

mode_ID; Input: mode identifier (see table below)

int int* mode; Output: current mode (TRUE/FALSE)

Description When the mode is set, only the original parsed components will be populated.

Standardization is done according to your preference, with the exception of settings that require the use of the directories.

The mode idendtifiers are as follows:

\CACE_MODE_GEO can take values CACE_CENTROID_GEO / CACE_ADDRESS_GEO / CACE_BOTH_GEO / CACE_NONE_GEO. This is used to set the geo information to be assigned at centroid level / address level / 'both' mode / disable geo code assignment

Mode identifier Values Description

CACE_MODE_PARSE_ONLY TRUE Enable Parse-only mode.

FALSE Disable parse-only mode.

CACE_MODE_GEO CACE_ADDRESS_GEO Perform Address-level GeoCoding processing only. Lati-

tude and longitude information on each address is unique to that address. ACE Canada searches the Address-Level GeoCensus directory for this information.

CACE_CENTROID_GEO Perform Centroid-level GeoCoding processing only. Lati-

tude and longitude information on each address is based on a circular area (a centroid circle) in which the address is located. ACE Canada searches the Centroid GeoCensus directory for this information.

CACE_BOTH_GEO Perform Address and Centroid-level GeoCoding process-

ing. ACE Canada first checks to see if the address has Address-Level GeoCensus data, and if it does, ACE Canada returns that information. If it does not, ACE Canada searches the Centroid-Level GeoCensus data and returns that information. ACE Canada does not return both the address-level and the centroid-level information.

CACE_NONE_GEO Do not perform GeoCoding.

Returns The return values are CACE_OK, CACE_INVALID_HANDLE, or

CACE_ERROR.

ACE Canada Library Reference

Page 41

cace_set_option(), cace_get_option()

Synopses int ace_set_option(three parameters);

CADDR_HANDLE cah; Input: address handle

int

option_ID; Input: option identifier (see table)

int setting; Input: option setting (see table)

int ace_get_option(three parameters);

CADDR_HANDLE cah; Input: address handle

int

option_ID; Input: option identifier (see table)

int* setting; Input: option setting (see table)

Description By default, CACE standardizes addresses in a style fully conforming to the SERP

testing regulations of the Canada Post Corporation.

You are not required to process your own data in SERP-conforming style. If you wish, you may call cace_set_option() as necessary to set stylistic options of your choosing.

SERP rules and the stylistic options are fully explained in the ACE User’s Guide.

As an alternative, you may use the

CACE_OPTS_CFG_FILE configuration file.

When you call cace_cfg_open() or cace_cfg_read(), options settings will be registered from the configuration file.

Call cace_get_option() to get the currently registered setting.

Returns Returns CACE_OK, CACE_INVALID_HANDLE, or CACE_ERROR.

Symbol for option_ID Symbols for setting Default setting

CACE_OPT_ALIAS

CACE_OPT_CAPITALIZATION CACE_UPPERCASE

CACE_OPT_DIR_STYLE CACE_OPT_SFX_STYLE

CACE_OPT_DUAL_TYPE CACE_DUAL_POSITION

CACE_OPT_FRENCH_ACCENTS CACE_ACCENT_ALL

CACE_CONVERT_ALIAS CACE_PRESERVE_ALIAS

CACE_MIXEDCASE

CACE_STYLE_OPTIMAL CACE_STYLE_LONG CACE_STYLE_PRESERVE

CACE_DUAL_MAILING CACE_DUAL_STREET

CACE_ACCENT_NONE CACE_ACCENT_IGNORE

CACE_PRESERVE_ALIAS

CACE_UPPERCASE

CACE_STYLE_OPTIMAL

CACE_DUAL_POSITION

CACE_ACCENT_IGNORE

Chapter 2: Functions for basic address processing

Page 42

Symbol for option_ID Symbols for setting Default setting

CACE_OPT_LANGUAGE CACE_BY_EXAMPLE

CACE_FORCE_ENGLISH CACE_FORCE_FRENCH CACE_BY_PROVINCE CACE_BY_FIELD

CACE_OPT_LVR_RULE CACE_OPT_RURAL_RULE

CACE_OPT_MULTI_COMBINE_AL CACE_OPT_MULTI_COMBINE_LL

CACE_OPT_MULTI_SWAP CACE_SWAP_TOP

CACE_OPT_MULTI_UPDATE_PC CACE_UPDATE

CACE_OPT_PC_ONLY TRUE

CACE_OPT_NONPREF_CITY CACE_CONVERT_NONPREF_CITY

CACE_OPT_POBOX_SEARCH TRUE

CACE_OPT_STND_ADDR_LINE CACE_OPT_STND_LAST_LINE CACE_OPT_STND_UNASSIGNED

CACE_OPT_SRANGE CACE_SRANGE_STYLE_DASHED

CACE_OPT_WEIGH_PNAME_OVER_PC TRUE

CACE_OPT_ENGLISH_UNITDES CACE_ENG_DEF_UNITDES_SUITE CACE_ENG_DEF_UNITDES_SUITE

CACE_OPT_FRENCH_UNITDES CACE_FRC_DEF_UNITDES_

TRUE FAL SE

CACE_SWAP_BOTTOM CACE_SWAP_NONE

CACE_DONT_UPDATE CACE_ERASE_THEN_UPDATE

FAL SE

CACE_PRESERVE_NONPREF_CITY

FAL SE

TRUE FAL SE

CACE_SRANGE_STYLE_TRAILING CACE_SRANGE_STYLE_PRESERVE

FAL SE

CACE_ENG_DEF_UNITDES_ APARTMENT

CACE_ENG_DEF_UNITDES_UNIT

BUREAU

CACE_FRC_DEF_UNITDES_ APPARTEMENT

CACE_FRC_DEF_UNITDES_UNITE

CACE_BY_EXAMPLE

TRUE

FALSE

CACE_NONE

CACE_UPDATE

TRUE

CACE_CONVERT_NONPREF_CITY

TRUE

TRUE TRUE FALSE

CACE_SRANGE_STYLE_PRESERVE

FALSE

CACE_FRC_DEF_UNITDES_ BUREAU

ACE Canada Library Reference

Page 43

Chapter 3: Suggestion lists

If Canadian ACE cannot assign an address, it can provide a suggestion at what the address is. This chapter explains what suggestion lists are, and how your application may process them.

Chapter 3: Suggestion lists

Page 44

How to handle suggestion lists

The process is as follows:

1. Call cace_set_sugg_option(cah, enable suggestion lists.

2. Optional: You may want to call cace_set_sugg_option() or cace_set_sugg_filter() to set other options for customized suggestion lists. These options are explained on page How to customize suggestion lists.

3. Call cace_findf() as usual. If address processing results in a suggestion list, cace_findf() exits, returning a special code (CACE_USER_CITY or

CACE_USER_ADDRESS). You detect this return code and step in to process

the suggestion list.

4. Retrieve the list from CACE. First, call cace_get_suggno() to get the number of suggestions available. Then if it’s a city suggestion list, call cace_get_sugg() to retrieve suggestion text. If it’s an address suggestion list, call either cace_get_sugg() or cace_get_sugg_cmpt().

5. Display the suggestion list to the user. The user may choose one suggestion, or reject the list and abandon the assignment. Capture the user’s choice, and pass it to ACE by calling cace_set_sugg(). Pass either a suggestion number or, to indicate rejection, pass -1.

The user might choose an address suggestion that does not match the primary range of the input record. For example, suppose the input address is 3310 Main, and the suggestion list shows Main extends only to the 800 block. The user might decide that the first digit of the input range had been double-typed, and the true range should be 310. So the user selects the address suggestion 300-399 Main. In this event your call to cace_set_sugg() will return You should prompt the user to enter a new range. Then call cace_set_range() to pass the user’s range into CACE.

CACE_SUGG_OPT_GENERATE, TRUE) to

CACE_USER_RANGE_BAD.

6. Call cace_findf() a second time. It attempts assignment based on the chosen suggestion.

Or, if the user has rejected the suggestion list, treat the record as unassigned.

ACE Canada Library Reference

Page 45

cace_get_sugg()

Synopsis int cace_get_sugg(three parameters);

ADDR_HANDLE cah; Input: address handle

int suggestion_number; Input: suggestion number (zero-based) char* suggestion_buffer; Output: suggestion string

Description The cace_get_sugg() function returns one suggestion string at a time. Call it from inside a

loop. The suggestion_number argument may range from zero to the number of suggestions available, minus one.

Make sure that your receiving suggestion_buffer is long enough. Each suggestion is a variable-length string delimited by vertical bars (|). Of course, when you display suggestions to the user, you will probably want to align fields in orderly columns, so your display may be wider than the ACE suggestion string.

Last-line suggestions

Address-line suggestions

Postal address (PO Box, Rural Route, General Delivery)

A last-line suggestion string contains a city name and province abbreviation. They are up to 34 characters long with the

NULL terminator. For example:

OTTAWA|ON

city province

Address suggestions are up to 132 characters long with the NULL. This function also returns secondary information if present. The low- and high-range numbers each occupy ten bytes and are left-padded with spaces. With one space in between, the total is 21 bytes. For example:

Delivery Inst Type

Delivery Inst

Qualifier

Postcode

Address

Type

Odd/Even Indicator

Primary

name

Low

number

Deliver Inst

name

PO BOX | 10 20 | AIRDRIE | STN | MAIN | T4B2K6 | P | B

High

number

Street address

Low

number

Primary

name

Directional

Address

Typ e

304 404 | MAIN | ST | S | T4B3C3 | S | E

High

number

Street Type

Postcode

Chapter 3: Suggestion lists

Odd/Even

Odd/Even Indicator

Indicator

Page 46

Street address with unit information

Low

number

Primary

name

Directional

Address

Type

Low Unit

number

Secondary

name

Unit Odd/Even

Indicator

649 649 | MAIN | ST | N | T4B1Z8 | H | O | 26 33 | BUSINESS BUILDING | H | B

High

number

Street

Type

Postcode

Odd/Even Indicator

High Unit

number

Secondary

Type

Street served by route address

Low

number

Primary

name

Directional

Delivery

Inst Type

Address

Typ e

901 937 | MAIN | ST | SE | SS | 1 | T0J2P0 | SR | O

High

number

Street

Type

Delivery

Inst Name

Postcode

Odd/Even

Indicator

Returns Returns CACE_OK, CACE_INVALID_HANDLE, or CACE_ERROR. Returns

CACE_ERROR if:

 an error occurred while retrieving the suggestion, or

 the input suggestion_number was out of range (for example, greater than the

number of suggestions available.)

cace_get_sugg_cmpt()

Synopsis char* cace_get_sugg_cmpt(four parameters);

CADDR_HANDLE cah; Input: address handle

int sugg_number; Input: suggestion number (zero-based) int component; Input: component to be retrieved; see

cace_get_query(), page 59

char* cmpt_buffer; Input: retrieved component

Description The cace_get_sugg_cmpt() function retrieves one component of one address-line

suggestion. Call it inside a nested loop—the inner loop on component, the outer loop on sugg_number. You can obtain the maximum value of sugg_number by calling cace_get_suggno().

For the component parameter, use the field names of cace_get_query(). Remember, you are retrieving data from the Canadian national directory records, not the components of a processed address. Do not use the field names of cace_get_component().

Returns Returns a pointer to the cmpt_buffer containing the retrieved component. If any of

the input parameters was invalid, this buffer will be empty.

cace_get_suggno()

Synopsis int cace_get_suggno(one parameter);

CADDR_HANDLE cah; Input: address handle

Description Call cace_get_suggno() to determine the number of suggestions on the current

list. You might call it before drawing a suggestion list window to determine how large to make the window.

Returns Returns the number of suggestions in the current suggestion list, or

CACE_INVALID_HANDLE, or CACE_ERROR.

cace_set_range()

Synopses int cace_set_range (three parameters);

CADDR_HANDLE cah; Input: address handle

int range_type; Input: range type

char* range; Input: new range

Description This function comes into play when a user is viewing an address suggestion list. It

is possible that the user will choose a suggestion that does not match the primary or secondary range of the input record. If the ACE user can enter a new, correct range, then ACE can assign the address.

In this situation, ACE Canada needs the user to set a new primary or secondary range that falls within the range of the chosen suggestion. This function provides a way for the user to set a new range.

If your call to cace_set_sugg() returns CACE_USER_PRANGE_BAD, CACE_USER_SRANGE_BAD, or CACE_USER_BOTH_RANGES_BAD, prompt the user to enter a new range. Call cace_set_range() to pass the user’s range into CACE, then call cace_findf().

The range types can be CACE_PRIM_RANGE which updates the primary range, or CACE_SEC_RANGE which updates the secondary range.

Returns Returns the following values:

Value Description

CACE_USER_PRANGE_BAD The primary range is invalid.

CACE_USER_SRANGE_BAD The secondary range is invalid.

Chapter 3: Suggestion lists

Page 50

cace_set_sugg()

Synopsis int cace_set_sugg(three parameters);

CADDR_HANDLE cah; Input: address handle

int sugg_num; Input: suggestion number (zero-based) int sugg_list_type; Input: list type

CACE_USER_ADDRESS CACE_USER_CITY

Description

Call the cace_set_sugg() function to select a particular suggestion line from an array of suggestions produced by cace_findf().

Note: If the suggestion number that you set is negative or greater than the list size, then ACE will assume that the suggestion list was rejected. The address will not be assigned.

Returns Returns CACE_OK, CACE_INVALID_HANDLE, CACE_ERROR,

CACE_USER_PRANGE_BAD, CACE_USER_SRANGE_BAD, CACE_USER_SECONDARY, or CACE_USER_BOTH_RANGES_BAD

Returns CACE_ERROR if the suggestion number was negative or greater than the total number on the list.

Returns

CACE_USER_PRANGE_BAD if the primary range of the input address

does not fall within the range of the chosen address suggestion. See the cace_set_range() page for details on handling this return.

Returns CACE_USER_SRANGE_BAD, if the secondary range is invalid.

Returns CACE_USER_SECONDARY to indicate that secondary address suggestions are available.

Returns

CACE_USER_BOTH_RANGES_BAD, if both the primary and secondary

ranges are invalid.

ACE Canada Library Reference

Page 51

How to customize suggestion lists

ACE offers several options for customizing suggestion lists. These options affect only the style of suggestion lists, not procedures for handling suggestions. You can set these options by calling cace_set_sugg_option() or cace_set_sugg_filter().

If you decide to call the customizing functions, you will probably make those calls during initialization, before the first cace_findf() call. However, you may change suggestion modes at any time. Your new choices will take effect upon the next cace_findf() call.

Consolidate ranges Address suggestions are Canadian national directory records

that ACE has called potential matches for the input address. Normally, each Canadian national directory record is returned as a separate suggestion.

For example, given the input data 114 Main, ACE might produce the suggestions shown at right.

If you want, ACE can consolidate these suggestions. The result is a more compact list that is easier and faster for you to display, and perhaps easier for your end users to grasp. ACE offers two styles of consolidation; they differ in their treatment of primary ranges:

CNSL In the first style, ACE ignores gaps and

overlaps in primary ranges, so consolidation is more aggressive. The above suggestion list would be compressed as shown here.

CNSL2 In the second style, ACE preserves gaps

in primary ranges, but overlapping ranges are consolidated. The above suggestion list would be compressed as shown here.

100 - 199 Main St

111 - 117 Main St

200 - 299 Main St

300 - 300 Main St

100 - 199 Main St E

231 - 233 Main St E

235 - 235 Main St E

100 - 399 Main St

100 - 235 Main St E

100 - 399 Main St

100 - 199 Main St E

231 - 233 Main St

235 - 235 Main St E

Note: When ACE consolidates, it produces only one suggestion for each unique combination of primary name, directional, suffix, and postal code. However, once a user selects a suggestion, normal assignment can proceed.

Chapter 3: Suggestion lists

Page 52

Filter by primary range

Another way to shorten address suggestion lists is to filter them by primary range. This approach is different from simply consolidating ranges. ACE offers two ways to filter suggestions by range:

Range Match: The first approach is just an on/off switch. If you turn it on, ACE returns only those suggestions that

100 - 117 Main St

100 - 199 Main St

match the input primary range.

Range Window: The other approach is a little more liberal. You set a span around the input range—in effect, limiting suggestions to an area a few blocks on either side of the input address.

The example at right shows the suggestions we would get

100 - 199 Main St

111 - 117 Main St

200 - 299 Main St

100 - 199 Main St E

231 - 233 Main St E

235 - 235 Main St E

with window set at 100. Again, the effect is to limit suggestions to one block on either side of the primary range that was input. Notice that the 300 block of Main Street has been dropped.

Adjust simil level A simil score is a number between zero and 100; the higher the number, the

greater the similarity between two strings. ACE uses simil scores when comparing input street names with streets in the Canadian national directory. The same is true when ACE compares an input city name with cities in the City directory.

During the normal assignment process, ACE requires a simil score in the upper 70s to determine a match. A looser standard applies when generating suggestion lists; a simil score of 60 or higher is close enough to earn a directory record a place on the suggestion list.

You can raise or lower the threshold simil score for suggestions lists. If you raise the threshold, expect shorter suggestion lists, and vice versa.

Filter by query You can filter address suggestions more generally. This method may be useful in

situations where you know something more about your addresses than is stored in your records.

The mechanism for creating filters is the same

CACE_QUERY structure that you

can use to query the Canadian national directory (as described in Appendix C). Then you attach the by calling cace_set_sugg_filter(). Not all

CACE_QUERY structure to the suggestion-building process

CACE_QUERY fields are available; see

the cace_set_sugg_filter() page for details.

ACE Canada Library Reference

Page 53

cace_set_sugg_filter()

Synopsis #include <caceshow.h>

int cace_set_sugg_filter(two parameters);

CADDR_HANDLE cah; Input: address handle

from cace_init_addr()

CACE_QUERY_HANDLE caq; Input: query handle

from cace_init_query()

Description To make address suggestion lists more focused, you can filter suggestions. The

mechanism for creating filters is the same query the Canadian national directory.

We suggest that you make the calls listed below before you process addresses. However, you may change your filter setting at any time. Your new filter will take effect upon your next call to cace_findf().

1. Call cace_init_query() to allocate a query handle.

2. Call cace_clear_query() to clear the query handle.

3. Call cace_set_query() to write your criteria into the query handle. Query

fields are listed on the cace_set_query() page (63). Note, you may use only the query fields listed below. Other query fields are invalid for suggestion filtering.

CACE_QUERY structure that is used to

CACEQ_CTYIDX CACEQ_DIRIDX CACEQ_SUFFIX CACEQ_LOWRANGE CACEQ_HIGHRANGE

4. Call cace_set_sugg_filter() to attach the query handle to the suggestion-

building process.

5. During termination, call cace_term_query() to free the query handle.

Returns Returns CACE_OK, CACE_INVALID_HANDLE, or CACE_ERROR.

cace_set_sugg_option(), cace_get_sugg_option()

Synopses int cace_set_sugg_option(two parameters);

CADDR_HANDLE cah; Input: address handle

int

option_ID; Input: option identifier (see table)

int setting; Input: option setting (see table)

int cace_get_sugg_option(two parameters);

CADDR_HANDLE cah; Input: address handle

int

option_ID; Input: option identifier (see table)

int* setting; Input: option setting (see table)

Description The cace_set_sugg_option() function sets the state of suggestion list processing. Your new

setting will take effect upon your next call to cace_findf().

Returns Returns CACE_OK, CACE_INVALID_HANDLE, or CACE_ERROR.

Symbol for option_ID Setting values Description

CACE_SUGG_OPT_GENERATE

CACE_SUGG_OPT_AL_SIZE 1 to ? Maximum number of address-line suggestions.

CACE_SUGG_OPT_LL_SIZE 1 to ? Maximum number of last-line suggestions.

CACE_SUGG_OPT_RANGEMATCH

CACE_SUGG_OPT_RANGEWINDOW 0 to ? A span around the input range, limiting address-line

CACE_SUGG_OPT_AL_SIMIL 0 to 100 Threshold simil score for address suggestions.

CACE_SUGG_OPT_LL_SIMIL 0 to 100 Threshold simil score for last-line suggestions.

CACE_SUGG_OPT_STYLE

TRUE

FAL SE

TRUE

FAL SE

CACE_NORMAL_SUGG

CACE_CNSL_SUGG

CACE_CNSL2_SUGG

TRUE

, CACE generates a suggestion lists when ranking results in a tie condition. If treats the address as unassigned.

TRUE

, CACE returns only those address-line suggestions that match the primary range of the input address.

suggestions to an area a few blocks on either side of the input address.

CACE ignores gaps and overlaps in primary ranges, so consolidation is more aggressive.

CACE preserves gaps in primary ranges, but overlapping ranges are consolidated.

Suggestions are not consolidated.

Note

: To consolidate suggestions, CACE may create temporary work files. They are placed in the user’s current working directory. During initialization, verify that the user has read/write permission in the current directory.

FALSE

, CACE

ACE Canada Library Reference

Page 55

Chapter 4: How to query the postal directories

You can use ACE to extract records from the postal directories. There are many reasons why you might want to do this. For example, when ACE does not assign an address, the reasons why might become clearer if you compare the faulty address with entries in the directories.

This appendix explains how to use ACE to extract records from the directories.

Chapter 4: How to query the postal directories

Page 56

Introduction to directory queries

Overview ACE offers two separate, but similar, sets of functions for directory queries. The

first set is used for querying the Canadian national directory about address-line data. The second set is for querying the City and FSA directories about last-line data.

When you perform queries, two ACE handles are involved: An input query handle, and an output browse handle. There are separate init and term functions for each handle.

Note: ACE matches your query fields to directory records using the same match rules that ACE follows when you process addresses normally.

Address-line queries in the Canadian national directory

Functions cace_init_query()

cace_clear_query() cace_set_query() cace_init_show() cace_show() cace_get_query() cace_term_query() cace_term_show()

Handles CACE_QUERY_HANDLE

CACE_BROWSE_HANDLE

Header file

Sample C source code

Ready-to-run sample program

caceshow.h cllshow.h

cshowtst.c tstllshw.c

cshowtst

cshowtst.exe tstllshw

Last-line queries in the City and FSA directories

cace_ll_init_query() cace_ll_clear_query() cace_ll_set_query() cace_ll_init_show() cace_ll_show() cace_ll_get_query() cace_ll_term_query() cace_ll_term_show()

CACE_LL_QUERY_HANDLE CACE_LL_BROWSE_HANDLE

tstllshw.exe

ACE Canada Library Reference

Page 57

How to query the Canadian national directory

If you’re anxious to begin making address queries, you might compile our cshowtst.c program, or use the Show utility. You also receive a ready-to-run Show executable, cshowtst.

1. Include the header file caceshow.h when you compile your application.

2. Call cace_init(), cace_init_addr(), and cace_set_error_rtn() as usual.

3. Call cace_set_file() to register the pathnames of all of the auxiliary files.

4. Call cace_open() to open the ACE auxiliary files.

5. Call cace_init_query() to allocate a query handle.

6. Call cace_clear_query() to clear the query handle.

7. Call cace_set_query() to write your criteria into the query handle. Query fields are listed on the cace_set_query() reference page.

8. Call cace_init_show() to verify that the query is valid. If the query is valid, cace_init_show() returns a browse handle. This is where retrieved Canadian national records will be written by cace_show().

9. Enter a loop:

• Call cace_show() to perform the query and write the next record into the browse handle. If there is at least one more qualifying record, cace_show() returns

TRUE.

 Call cace_get_query() to retrieve individual fields (one per call) from the

current Canadian national record. Retrieved fields are listed and described on the cace_get_query() reference page.

 Exit the loop when cace_show() returns FAL SE, indicating that no more

records meet the search criteria. To limit the maximum number of records extracted, you might set your own counter.

 When you have finished with the browse handle, call cace_term_show() to

free it.

10. If you want to make additional queries, repeat steps 6 through 9.

11. Call cace_term_query() to free the query handle, and cace_term_addr() to free the address handle.

Chapter 4: How to query the postal directories

Page 58

cace_clear_query()

Synopsis #include <caceshow.h>

int cace_clear_query(one parameter);

CACE_QUERY_HANDLE can_qhandle;from cace_init_query()

Description Call cace_clear_query() between queries against the national directory. This

function clears the query handle data.

If you do not call this function between queries, data may remain in the handle that would corrupt the next query.

Returns Returns CACE_OK if successful. Returns CACE_INVALID_HANDLE if the

input query handle was invalid.

ACE Canada Library Reference

Page 59

cace_get_query()

Synopsis #include <caceshow.h>

int cace_get_query(three parameters);

CACE_BROWSE_HANDLE cace_bhandle;from cace_init_show()

int browse_field; component name char* buffer; pointer to retrieved string

Description The cace_get_query() function retrieves one field from the current record of the

current query. Valid browse_field names are listed on the next page.

You may choose to retrieve any combination of address components, except city and province. Your options are listed on the next page.

Note: ACE does not check the size of the receiving buffer. It is your responsibility to provide adequate space for the data you retrieve.

Returns Returns CACE_OK if successful. Returns CACE_INVALID_HANDLE if the

input browse handle was invalid.

Chapter 4: How to query the postal directories

Page 60

Browse fields for cace_get_query()

Name Description

CACEQ_ODDEVEN An E, O, or B to indicate whether the record covers the

even-numbered side of the street, odd, or both.

CACEQ_LOWRANGE

The range of house, route, or box numbers covered.

CACEQ_HIGHRANGE

CACEQ_PNAME Primary (street) name.

CACEQ_SODDEVEN An E, O, or B to indicate whether the secondary record

covers the even-numbered side of the street, odd, or both.

CACEQ_DIR Directional (N, NE, E, SE, S, SW, and so on).

CACEQ_SFX Street suffix (Ave, St, Rue, and so on).

CACEQ_SNAME The firm or business name for this record.

CACEQ_SLOWRANGE CACEQ_SHIGHRANGE

CACEQ_CTYIDX CACEQ_SCTYIDX

The range of apartment or office suite numbers for an apartment or office building.

The city index number for the primary or secondary record. Each valid city name within a directory area has its own city index number.

CACEQ_PCODE The postal code you want to query.

CACEQ_TYPE CACEQ_STYPE

The type of the primary or secondary record. ACE supports eight types. A secondary records does not have to be the same type as its primary record.

(general delivery)

(street)

(post office box)

(rural service)

(high-rise)

(firm)

(street served by route number)

(building name)

CACEQ_DIRIDX The directory area index number you want to query.

CACEQ_DELINST For delivery-type records, such as post office box, rural

route, or general delivery records, the delivery installation area name for the record. This is usually the city name for most records.

CACEQ_DELTYPE For delivery-type records, such as post office box, rural

route, or general delivery records, the delivery installation type. Some current supported values are Station (STN), Post Office (PO), Letter Carrier Depot (LCD), and Commercial Dealership Outlet (CDO).

CACEQ_DELQUAL For delivery-type records, such as post office box, rural

route, or general delivery records, the name of the delivery installation.

CACEQ_LVR Returns a T if the address is a Large Volume Receiver

and an F if it is not.

ACE Canada Library Reference

Page 61

cace_init_query()

Synopsis #include <caceshow.h>

int cace_init_query(two parameters);

CADDR_HANDLE cah; Input: address handle CACE_QUERY_HANDLE *can_qhandle; Output: query handle

Description Call cace_init_query() to initialize an ACE query handle. You will use this

handle in later calls related to your query.

Returns Returns CACE_OK, CACE_INVALID_HANDLE, or CACE_ERROR.

cace_init_show()

Synopsis #include <caceshow.h>

int cace_init_show(two parameters);

CACE_QUERY_HANDLE can_qhandle; Input: query handle CACE_BROWSE_HANDLE *cace_bhandle; Output: browse handle

Description The cace_init_show() function evaluates your query handle. If the query is valid,

it creates a browse handle. This pointer is used as input to cace_show(), which actually performs the query.

Returns Returns CACE_OK, CACE_INVALID_HANDLE, or CACE_ERROR.

Most of the remaining return values (table below) indicate an error in the query date. Previously, these conditions were reported through a query_status integer. Now they are return values.

Return Description

CACESHOW_INVALID_QUERY The input query was invalid (something was wrong

in one of the query fields).

CACESHOW_NOMEM The browse handle could not be created because

memory was exhausted.

cace_set_query()

Synopsis #include <caceshow.h>

int cace_set_query(three parameters);

CACE_QUERY_HANDLE can_qhandle; from cace_init_query()

int query_field; query field (see table below) char* query_data; data to be matched

Description Call cace_set_query() function to load one component into the query handle.

You may query on any combination of fields listed below.

Returns Returns CACE_OK, CACE_INVALID_HANDLE, or CACE_ERROR.

Postal fields

Name Description

CACEQ_CTYIDX Set the city index to query the directories for.

CACEQ_DIR Set the directional to search for.

CACEQ_DIRIDX Set the directory index to limit the search.

CACEQ_FRENCH_ACCENTS Set either of the strings “Y” or “N”. As an alternative,

you may use the full spelling “YES” or “NO.” Only the first letter of the string is checked for Y or N. The default is No, for no accented characters. If you set Yes, ACE produces accents where available on CACEQ_SNAME, CACEQ_PNAME, and CACEQ_DELINST.

CACEQ_LOWRANGE CACEQ_HIGHRANGE

CACEQ_PCODE Set the postal code to search.

CACEQ_PNAME Set a primary name to search for. You can use wild-

CACEQ_SDR_ONLY Set either of the strings “Y” or “N”.3 Set No for nor-

CACEQ_SFX Set the suffix to search for.

To search for a particular house number, load it into CACEQ_LOWRANGE and set CACEQ_HIGHRANGE empty. To search within a range of house numbers, load the low end into CACEQ_LOWRANGE, and load the high end into CACEQ_HIGHRANGE.

cards.

mal queries. If you set Yes, ACE only retrieves Street Descriptor records (street names).

Chapter 4: How to query the postal directories

Page 64

cace_show()

Synopsis #include <caceshow.h>

int cace_show(two parameters);

CACE_BROWSE_HANDLE can_bhandle; from cace_init_show()

int* show_status; status of current retrieval

Description The cace_show() function retrieves a record from the directory, following search

criteria stored in a

CACE_BROWSE_HANDLE.

The show_status integer indicates the status of the current retrieval.

Symbol for show_status Description

CACESHOW_GOTLINE A line was returned.

CACESHOW_DONE The query is completed (all records matching the search

CACESHOW_ABORT An internal error occurred, or the input browse handle

CACE_QUERY_HANDLE, and storing the result in the

criteria have been retrieved).

was invalid.

Returns Returns TRUE if an additional record was retrieved, or FAL SE if the query is now

complete.

ACE Canada Library Reference

Page 65

cace_term_show(), cace_term_query()

Synopses int cace_term_show(one parameter);

CACE_BROWSE_HANDLE *cace_bhandle; from cace_init_show()

#include <caceshow.h> int cace_term_query(one parameter);

CACE_QUERY_HANDLE *can_qhandle; from

cace_init_query()

Description The cace_term_query() function frees all dynamic memory allocated the query

handle.

The cace_term_show() function frees all dynamic memory allocated for the ACE browse handle.

Returns Returns CACE_OK, CACE_INVALID_HANDLE, or CACE_ERROR.

How to query the City and FSA directories

If you’re anxious to begin making last-line queries, you might compile our tstllshw.c program, or use the Show utility. (With ACE Library you receive a ready-to-run Show executable, tstllshw.)

1. Include the header file cllshow.h when you compile your application.

2. Call cace_init(), cace_init_addr(), and cace_set_error_rtn() as usual.

3. Call cace_set_file() to register the pathnames of all of the auxiliary files.

4. Call cace_open() to open the ACE auxiliary files.

5. Call cace_ll_init_query() to allocate a query handle.

6. Call cace_ll_clear_query() to clear the query handle.

7. Call cace_ll_set_query() to write your criteria into the query handle. Query fields are listed on the cace_ll_set_query() reference page. The only query field that you must set is

8. Call cace_ll_init_show() to verify that the query is valid. If the query is valid, cace_ll_init_show() returns a browse handle. This is where retrieved records will be written by cace_ll_show().

9. Enter a loop:

CACE_LLQ_TYPE.

 Call cace_ll_show() to perform the query and write the next record into the

browse handle. If there is one more qualifying record, cace_ll_show() returns

CACE_LLSHOW_GOTLINE.

 Call cace_ll_get_query() to retrieve individual fields (one per call) from the

current record. Retrieved fields are listed and described on the cace_ll_get_query() page.

 Exit the loop when cace_ll_show() returns FALSE, indicating that no more

records meet the search criteria. To limit the maximum number of records extracted, you might set your own counter.

 When you are finished with the browse handle, call cace_ll_term_show() to

free it.

10. If you want to make additional queries, repeat steps 6 through 9.

11. Call cace_ll_term_query() to free the query handle, and

cace_term_addr() to free the address handle.

ACE Canada Library Reference

Page 67

cace_ll_clear_query()

Synopsis #include <cllshow.h>

int cace_ll_clear_query(one parameter);

CACE_LL_QUERY_HANDLE can_ll_qhandle;from cace_ll_init_query()

Description Call cace_ll_clear_query() between queries against the City and FSA

directories. This function clears the query handle.

If you do not call this function between queries, data might remain in the handle that would corrupt the next query.

Returns Returns CACE_OK if successful. Returns CACE_INVALID_HANDLE if the

input query handle was invalid.

Chapter 4: How to query the postal directories

Page 68

cace_ll_get_query()

Synopsis #include <cllshow.h>

int cace_ll_get_query(three parameters);

CACE_LL_BROWSE_HANDLE can_ll_bhandle;from cace_ll_init_show()

int browse_field; browse field (see below) char* buffer; retrieved string

Description The cace_ll_get_query() function retrieves one field from the current record of

the current query. Browse fields are listed below.

Note: ACE does not check the size of the receiving buffer. It is your responsibility to provide adequate space for the data you retrieve.

Name Description

CACE_LLQ_CTY_ABBR This city has an abbreviation. Returns T or F.

CACE_LLQ_CTY_ABBR13 This is a 13 character city abbreviation. Returns T or F.

CACE_LLQ_CTY_ABBR18 This is an 18 character city abbreviation. Returns T or F.

CACE_LLQ_CTY_VALID This city is valid for mailing. Returns T or F.

CACE_LLQ_CTY_RURAL This city is rural. Returns T or F.

CACE_LLQ_CTY_SOLE_STATION This city is a sole delivery station. Returns T or F.

CACE_LLQ_CTY_FSA_LIMITED This city is limited by FSA. Returns T or F.

CACE_LLQ_CITYNAME City name.

CACE_LLQ_CTYIDX CACE_LLQ_ALTCTYIDX City index into the postal directories.

CACE_LLQ_DIRIDX The directory index.

CACE_LLQ_FSA The three-character FSA (forward sortation area).

CACE_LLQ_LDU The three-character LDU (local delivery unit).

CACE_LLQ_LVR Indicates whether an address is a Large Volume Receiver (com-

parable to a U.S.Unique ZIP Code). Returns T or F.

CACE_LLQ_PROVINCE The two-letter province abbreviation.

Returns Returns CACE_OK if successful. Returns CACE_INVALID_HANDLE if the

input query handle was invalid.

ACE Canada Library Reference

Page 69

cace_ll_init_query()

Synopsis #include <cllshow.h>

int cace_ll_init_query(two parameters);

CADDR_HANDLE cah; Input: address handle CACE_LL_QUERY_HANDLE* can_ll_qhandle; Output: query handle

Description Call cace_ll_init_query() to initialize a ACE last-line query handle. You will use

this handle in later calls related to your query.

Returns Returns CACE_OK, CACE_INVALID_HANDLE, or CACE_ERROR.

cace_ll_init_show()

Synopsis #include <cllshow.h>

int cace_ll_init_show(two parameters);

CACE_LL_QUERY_HANDLE can_ll_qhandle;Input: query handle CACE_LL_BROWSE_HANDLE *can_ll_bhandle;Output: browse handle

Description The cace_ll_init_show() function evaluates the query handle. If the query is

valid, it creates a browse handle. This pointer is used as input to cace_ll_show(), which actually performs the query.

Returns Returns CACE_OK, CACE_INVALID_HANDLE, or CACE_ERROR.

Most of the remaining return values (table below) indicate an error in the query date. Previously, these conditions were reported through a query_status integer. Now they are return values.

Return Description

CACE_LLSHOW_NEED_CITY The input query was invalid; a city name is

needed to complete the query.

CACE_LLSHOW_BAD_PROVINCE The input query was invalid; the providence

field contained an invalid abbreviation.

CACE_LLSHOW_INVALID_QUERY The input query data was invalid, resulting in

no matching records in the directory.

CACE_LLSHOW_NOMEM The browse handle could not be created

because memory was exhausted.

cace_ll_set_query()

Synopsis #include <cllshow.h>

int cace_ll_set_query(three parameters);

CACE_LL_QUERY_HANDLE can_ll_qhandle;from cace_ll_init_query()

int query_field;query field (see below) char* query_data;data to be matched

Description The cace_ll_set_query() function loads one component into the query handle.

Query fields are listed below. The only mandatory query field is

CACE_LLQ_TYPE. You must set that field so that ACE can determine which file

to query.

Returns Returns CACE_OK, CACE_INVALID_HANDLE, or CACE_ERROR.

Fields for setting query options

Name Description

CACE_LLQ_CTYIDX CACE_LLQ_ALTCTYIDX

CACE_LLQ_DIRIDX Set the directory index to limit the search.

CACE_LLQ_FRENCH_ACCENTS For the option value, use the string “Y” or “N”. As

CACE_LLQ_FSA Set the FSA (Forward Sortation Area) to limit the

CACE_LLQ_POSTCODE Confine the query to a particular postcode.

CACE_LLQ_PROVINCE To confine the query to a particular province, set

CACE_LLQ_TYPE Tells ACE what type of query to perform: City,

CACE_LLQ_CITYNAME You must spell the city name correctly in order for

Set the city index to query the directories for.

an alternative, you may use the full spelling “YES” or “NO.” Only the first letter of the string is checked for Y or N. The default is N, for no accented characters. The default is No, for no accented characters. If you set Yes, ACE produces accents where available on CACE_LLQ_CITYNAME.

scope of the search.

its two-letter abbreviation.

FSA, or PCI.

ACE to find it in the directory. Wildcards are supported—for example, VANC* finds Vancouver and Vancouver Airport.

Chapter 4: How to query the postal directories

Page 72

cace_ll_show()

Synopsis #include <cllshow.h>

int cace_ll_show(two parameters);

CACE_LL_BROWSE_HANDLE can_ll_bhandle;from cace_ll_init_show()

int* show_status;status of current retrieval

Description The cace_ll_show() function retrieves one record from the City or FSA directory

and writes to the browse handle.

The show_status integer indicates the status of the current retrieval.

Symbol for show_status Description

CACE_LLSHOW_GOTLINE A line was returned.

CACE_LLSHOW_DONE The query is completed (all records matching the search

criteria have been retrieved).

CACE_LLSHOW_ABORT An internal error occurred, or the input browse handle

was invalid.

Returns Returns TRUE if an additional record was retrieved, or FAL SE if the query is now

complete.

ACE Canada Library Reference

Page 73

cace_ll_term_show(), cace_ll_term_query()

Synopses #include <cllshow.h>

int cace_ll_term_show(one parameter);

CACE_LL_BROWSE_HANDLE *can_ll_bhandle;from cace_ll_init_show()

#include <cllshow.h>

int cace_ll_term_query(one parameter);

CACE_LL_QUERY_HANDLE *can_ll_qhandle;from cace_ll_init_query()

Description The cace_ll_term_show() function frees all dynamic memory allocated for the

ACE last-line browse handle.

The cace_ll_term_query() function frees all dynamic memory allocated the ACE last-line query handle.

Returns Returns CACE_OK, CACE_INVALID_HANDLE, or CACE_ERROR.

ACE Canada forms the basis

GeoCoding options: Centroid and AddressLevel

Get the most from the GeoCoding data

Market analysis You can use mapping applications to analyze market penetration, for instance.

ACE Canada does not draw maps. However, you can use the latitude and longitude assigned by ACE Canada as input to third-party mapping software. Those programs enable you to plot the locations of your customers and filter your database to cover a particular geographic area.

Two GeoCoding options are available:

 Address-Level. Latitude and longitude are based on an individual address.

ACE Canada assigns to the individual dwelling or not at all.

 Centroid. Latitude and longitude are based on the postal code, so precision

of assignment is typically at the block-face level.

You can combine GeoCoding with the functionality of mapping software to view your geo-enhanced information. It will help your organization build its sales and marketing strategies. Here are some of the ways you can use the GeoCoding data, with or without mapping products.

Companies striving to gain a clearer understanding of their markets employ market analysis. This way they can view sales, marketing, and demographic data on maps, charts, and graphs. The result is a more finely targeted marketing program. You will understand both where your customers are and the penetration you have achieved in your chosen markets.

Predictive modeling and target marketing

Media planning For better support of your advertising decisions, you may want to employ media

You can more accurately target your customers for direct response campaigns using geographic selections. Predictive modeling or other analytical techniques allow you to identify the characteristics of your “ideal” customer. This method incorporates demographic information used to enrich your customer database. From this analysis, it is possible to identify the best prospects for mailing or telemarketing programs.

planning. Coupling a visual display of key markets with a view of media outlets can help your organization make more strategic use of your advertising dollars.

Appendix A: GeoCoding

Page 76

Territory management GeoCoding data provides a more accurate market picture for your organization. It

can help you distribute territories and sales quotas more equitably.

Direct sales Using GeoCoding data with market analysis tools and mapping software, you can

track sales leads gathered from marketing activities.

Directory files The following directory files are required for GeoCoding.

Directory File Description

GeoCoding components

canalg.dir

canctr.dir

The address level geo code directory file.

The centroid geo code directory file.

The following GeoCoding components are available for ACE Canada Library and Job. Include these components in your setup when you plan to perform GeoCoding.

Library Length Description

CACE_ADDRESS_GEO_LAT 12 Latitude (degrees north of the equator)

in the format +

12.123456.

CACE_ADDRESS_GEO_LNG 12 Longitude (degrees east of the Green-

wich Meridian) in the format +

12.123456.

CACE_CENTROID_GEO_LAT 12 Latitude (degrees north of the equator)

in the format +

12.123456.

CACE_CENTROID_GEO_LNG 12 Longitude (degrees east of the Green-

wich Meridian) in the format +

12.123456.

CACE_GEO_MATCH 9 Match code indicating the precision of

the latitude and longitude assignment.

Match in Address-level.

Match on Centroid-level

No match on Centroid-level

No match on Address-level

Both options tried, but no match on Address or Centroid-level.

ACE Canada Library Reference

Page 77

Set up GeoCoding

The following functions support GeoCoding.

cace_set_mode() and cace_get_mode()

Call cace_set_mode() and cace_get_mode() with the CACE_MODE_GEO parameter to set and retrieve the GeoCoding mode. Include one of the following values to specify the type of GeoCoding you want to perform.

Mode identifier Values Description

CACE_MODE_GEO CACE_ADDRESS_GEO Perform Address-level GeoCoding processing only.

Latitude and longitude information on each address is unique to that address. ACE Canada searches the Address-Level GeoCensus directory for this information.

CACE_CENTROID_GEO Perform Centroid-level GeoCoding processing only.

Latitude and longitude information on each address is based on a circular area (a centroid circle) in which the address is located. ACE Canada searches the Centroid GeoCensus directory for this information.

CACE_BOTH_GEO Perform Address and Centroid-level GeoCoding pro-

cessing. ACE Canada first checks to see if the address has Address-Level GeoCensus data, and if it does, ACE Canada returns that information. If it does not, ACE Canada searches the Centroid-Level GeoCensus data and returns that information. ACE Canada does not return both the address-level and the centroidlevel information.

CACE_NONE_GEO Do not perform GeoCoding.

cace_set_file() and cace_get_file()

Call cace_set_file() and cace_get_file() with the following values to specify and retrieve the location and filename of the Address-level and Centroid-level GeoCoding directory files.

Symbol File name Location Description

CACE_DIR_ADDRESS_GEO

CACE_DIR_CENTROID_GEO

canalg.dir

canctr.dir

dirs The address-level GeoCoding directory file.

dirs The centroid-level GeoCoding directory file.

cace_get_file_date() Call cace_get_file_date() with the following values to retrieve the file date for the

Address-level and Centroid-level GeoCoding directory files.

Symbol File name Location Description

CACE_DIR_ADDRESS_GEO

CACE_DIR_CENTROID_GEO

canalg.dir

canctr.dir

dirs The address-level GeoCoding directory file.

dirs The centroid-level GeoCoding directory file.

Appendix A: GeoCoding

Page 78

ACE Canada Library Reference

Page 79

Index

address

standardization, 28 Address Accuracy Statement (AAS), 18, 37 address format, 38

cace_get_input_length(), 38 address handles, 34, 38, 39

cace_cfg_open(), 20

cace_get_input_length(), 38 address processing

function call sequence address standardization checks

cace_get_stats(), 32

lettermatch and simil, 28

, 13

cace_AAS(), 18 cace_AAS_file(), 18 cace_browse_ptr structure, 56, 59 cace_cfg_close(), 20 cace_cfg_open(), 20 cace_cfg_read(), 20 cace_clear_query(), 58 cace_close(), 35 cace_findf()

suggestion lists, 51 cace_get_cert_expire_date(), 24 cace_get_cert_version(), 24 cace_get_component(), 25 cace_get_dir_date(), 27 cace_get_error_info(), 9 cace_get_file(), 37 cace_get_input_length(), 38 cace_get_lettermatch(), 28 cace_get_line(), 39 cace_get_mode(), 40 cace_get_option(), 41 cace_get_query(), 59 cace_get_simil(), 28 cace_get_source(), 25 cace_get_stats(), 32 cace_get_sugg_option(), 54 cace_init(), 33 cace_init_addr(), 34 cace_init_query(), 61 cace_init_show(), 62 cace_ll_browse_ptr structure, 56, 68 cace_ll_clear_query(), 67 cace_ll_get_query(), 68 cace_ll_init_query(), 69 cace_ll_init_show(), 70 cace_ll_query_PTR structure, 71 cace_ll_query_ptr structure, 56

cace_ll_set_query(), 71 cace_ll_show(), 72 cace_ll_term_query(), 73 cace_ll_term_show(), 73 cace_open(), 35 cace_query structure, 56 cace_set_error_rtn(), 9 cace_set_file(), 37 cace_set_input_length(), 38 cace_set_line(), 39 cace_set_mode(), 40 cace_set_option(), 41 cace_set_sugg_filter(), 52 cace_set_sugg_option(), 54 cace_set_sugg_rangematch(), 52 cace_set_sugg_rangewindow(), 52 cace_set_sugg_simil(), 52 cace_set_sugg_style(), 51 cace_show(), 64 cace_term(), 33 cace_term_addr(), 34 cace_term_query(), 65 cace_term_show(), 65 caddr_handle structure

cace_cfg_open(), 20

cace_get_input_length(), 38 caddrtst (sample program), 3 can.dir, 35 Canada Post Corporation (CPC)

Address Accuracy Statement canaddr.dct, 35, 37 Canadian national directory retrieval

browse fields

create query structure, 62

get next query, 64

get one field, 59

shutdown, 65 cancase.dct, 35 cancity.dir, 35, 37 canfsa.dir, 35 canlast.dct, 28, 35, 37 city directory, 37

queries, 56 city lettermatch and simil, 28 city name

abbreviations, how to find

last-line query field, 71 compile and link, 8

, 59

, 18, 37

, 71

direct sales, 75 directional, query field, 59 directories

Index

Page 80

get date, 27 get or set pathname, 37

error handling, 9, 36

forward sortation area (FSA)

directory, get pathname

function call sequence

basic address processing

, 37

, 13

output, 25, 39

cace_get_input_length(), 38

postal code directory, 37 primary name

lettermatch and simil, 28

query field, 59 primary range, query field, 59 pwcas.dct, 37

GeoCoding

components description, 76 directory files, 37, 76 mode, 40 setup, 77

, 76

header files, 56

initialization, 33, 34, 35, 38

cace_cfg_open(), 20 cace_get_input_length(), 38

input fields, 38, 39

last-line queries, 56

browse fields, 68 cace_ll_set_query(), 71 create query structure, 70 function calls, 56, 73 header files, 56 query fields, 71 structure pointers, 56

MakeProcInstance(), 9 Microsoft Windows

DLL error handling SDK, 9

, 9

sample program, 3 sequence of function calls

basic address processing shutdown, 33, 34 Software Evaluation and Recognition Program (SERP)

Address Accuracy Statement standardization checks, 28

cace_get_stats(), 32

lettermatch and simil, 28 suffix, query field, 59 suggestion lists, 52

consolidation, 51

filtering, 52

how to customize, 52

, 13

, 18, 37

termination, 33, 34

cace_cfg_close(), 20

cace_ll_term_query(), 73

cace_ll_term_show(), 73

cace_term_query(), 65

cace_term_show(), 65

unit designator, query field, 59 Unix compile and link, 8

Visual Basic, 9

Windows DLL, 8

ACE Canada Library Reference

Business objects ACE CANADA 7.80C User Manual

ACE Canada

Library Reference

Preface

Conventions This document adheres to the following documentation conventions:

Contents

How to install and make executables

Microsoft Windows We provide the ACE Canada Library as a 16 or 32-bit dynamically linked library

Unix Install ACE Canada following the instructions in our Unix System

Error handling

Default error handling Some languages do not support function pointers. If you cannot set your own

Setting your own error handler

Three options for initialization and termination

Option #1: Full use of configuration files and minimal API function calls

Option #2: Selective use of configuration files and API function calls

Option #3: No use of configuration files; do everything with API function calls.

ACE function calls for address processing

Process addresses 1. Loop through the ACE input fields you chose. Call cace_set_line() to pass

Address input and output

cace_AAS(), cace_AAS_file()

Synopsis char* cace_AAS(ten parameters);

Description Both functions generate a facsimile of the CPC form, “Statement of Address

Returns The cace_AAS() function returns a pointer to a character array containing the

cace_cfg_open(), cace_cfg_close(), cace_cfg_read()

Synopses int cace_cfg_open(two parameters);

Description CACE supports four types of configuration files. The “vanilla” configuration files

Returns Returns CACE_OK if successful; otherwise, CACE_ERROR. An error usually

See also After cace_cfg_open(), make cace_get_*() calls to obtain the settings that were

cace_evaluate_ah()

Synopsis int cace_evaluate_ah(one parameter);

Returns Returns CACE_OK if the input lines structure is valid for parsing. Returns

Symbol Description

cace_findf()

Synopsis int cace_findf(one parameter);

Returns The cace_findf() call may return any of the following codes.

Symbol Description

Example

cace_get_cert_expire_date(), cace_get_cert_version()

Synopses char *cace_get_cert_expire_date(one parameter);

Description ACE offers two functions that you can use to retrieve information about our

Returns Both functions return the same buffer pointer that you passed in.

cace_get_component(), cace_get_source()

Synopsis char* cace_get_component(four parameters);

Description You can use cace_get_component() to retrieve from ACE any component from

Returns The cace_get_component() function returns a pointer to a buffer containing the

Example

cace_get_error_info()

Synopsis int cace_get_error_info(four parameters);

Description When any ACE function returns CACE_ERROR, you can get information about

Returns Returns CACE_INVALID_HANDLE if the input address handle was invalid;

Example

See also cace_set_error_rtn()

cace_get_file_date()

Synopsis char* cace_get_file_date(three parameters);

Description These functions extract a date from the directory and return it as a date_string in

Returns Returns the same pointer to the date_string buffer that you passed in. The

Example

cace_get_lettermatch(), cace_get_simil()

Synopses int cace_get_lettermatch(two parameters);

Description

Returns The cace_get_lettermatch() function returns TRUE if, and only if, every letter in

cace_get_line_name()

Synopsis char* cace_get_line_name(two parameters);

Description Given a line_ID, cace_get_line_name() produces an English, user-friendly field

Returns The cace_get_line_name() function returns the same line_name buffer pointer

cace_get_offset()

Synopsis int cace_get_offset(four parameters);

Description The cace_get_offset() function can be used to find the position of an input

Returns Returns CACE_OK if the request could be fulfilled (even if the component was

Example

cace_get_revision()

Synopsis int cace_get_revision(one parameter);

Description The cace_get_revision() function produces a string that identifies the version of

Returns Returns CACE_OK if successful; otherwise, CACE_ERROR.

cace_get_stats()

Synopsis int cace_get_stats(two parameters);

Description To find out how an address component was standardized, call the function

Returns Returns one of the integers listed at right. Your

cace_init(), cace_term()

Synopses int cace_init(no parameters);
