Bush Q5S Instruction manual

Instruction manual

Q5S Soundbar

You’ll soon be enjoying your new Soundbar.

It all begins here, with your instructions. Don’t worry, there’s nothing too technical coming up. Just simple, step-by-step guidance to get you up and running quickly. Sound good? Then let’s get started.

Help and Guidance

We’re here to help you get the most from your Soundbar. Should you require any guidance, a simple solution can often be found online at:

www.argos-support.co.uk

If you still require further assistance, call one of our experts on 0345 600 3021 .

If you require any technical guidance or find that your product is not operating as intended, a simple solution can often be found in the Troubleshooting section of these instructions,

Contents

Safety information

Safety information 6

Getting to know your Soundbar

Ready? Let’s begin 8

Accessories 8

Control panel and remote control 9

Making the connections 11

Installing the remote battery 12

Using your Soundbar

Standby mode 14

Switching inputs 14

Adjusting the volume 14

LED status table 14

EQ presets 14

Product support

Troubleshooting 22

Help and assistance 23

Disposal 24

Guarantee 25

Bass enhancement 14

Mute function 14

Voice message feedback 15

Pairing a bluetooth device 15

Bluetooth LED status table 15

Controlling a paired device 15

Bluetooth notes 15

Other information

Wall mounting the soundbar 18

Technical specification 19

Care & maintenance 19

or online at www.argos-support.co.uk If you still require further assistance, call one of our experts on 0345 600 3021 .

This page is left intentionally blank

Safety information

Important - Please read these instructions fully before

installing or operating

Power source

• This symbol means that this unit is double insulated. An earth connection is not required.

• The appliance must be connected to a 100-240 volt 50/60Hz AC supply by means of a three pin socket.

• Unplug this apparatus during lightning storms or when unused for long periods of time - to prevent damage to this product.

• Opening or removing covers may expose you to dangerous voltages or other hazards.

• To prevent risk of fire or electric shock, avoid overloading wall outlets, extension cords, or integral convenience receptacles.

• Use suitable power sources - Plug the product into a suitable power source, as described in the operating instructions or as marked on the product.

• The supply voltage should be the same as that indicated in the technical specifications and the appliance rating plate.

• If the socket outlets in your home are not suitable for the plug supplied with this unit check with a qualified electrician for replacement.

• In order to disconnect the apparatus from the mains completely, switch off the outlet and remove the mains plug completely.

Heat build up

• During use the unit will heat up, this is not a malfunction. If the unit is used continuously at high volume levels, the unit temperature will rise considerably. Do not touch the unit to avoid potential burns.

Colour irregularity on TV screen

Colour irregularities may be seen on certain types of TV.

• If such an irregularity is seen turn off the TV, then turn on again after 15 to 30 minutes.

• If the colour irregularity is still seen place the soundbar unit further away from the TV.

Moisture and water

• Do not use this apparatus near water or moisture.

• Do not use this product near a bathtub, washbowl, kitchen sink, and laundry tub, in a wet basement, near a swimming pool, or anywhere else that water or moisture is present.

Heat sources and ﬂames

• Batteries shall not be exposed to excessive heat such as sun, fire or the like

• To prevent risk of fire or electric shock, avoid overloading wall outlets, extension cords, or integral convenience receptacles.

• Do not bend, stretch or pull the supply cable in order to avoid electric shock.

• When installed, the power socket must be within easy reach.

• Do not install the unit in a confined space. Allow adequate ventilation to prevent heat build-up.

• For indoor use only.

If you require any technical guidance or find that your product is not operating as intended, a simple solution can often be found in the Troubleshooting section of these instructions,

Safety information6

Servicing and repairs

• Refer all servicing to qualified service personnel

• Servicing is required when the apparatus has been damaged in any way: such as liquid has been spilled or objects have fallen into the apparatus; the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.

Getting to know your Soundbar

You’ll be up and running in no time

Ready? Let’s begin...

Please read these instructions carefully. They contain important information which will help you get the best from your Soundbar and ensure safe and correct installation and operation.

If you require any further assistance, our technical experts are happy to help. For full details, refer to the product support section at the end of these instructions.

Accessories

1. Q5S Soundbar

2. Sub woofer

3. Remote control

4. CR2032 battery

5. Digital coaxial audio cable

6. Digital optical cable

7. 3.5mm to 3.5mm audio cable

8. Mains adapter

9. Instruction manual

Q5S Soundbar

Sub woofer Remote control CR2032 battery

Digital coaxial cable

If you require any technical guidance or find that your product is not operating as intended, a simple solution can often be found in the Troubleshooting section of these instructions,

Getting to know your Soundbar

3.5mm to 3.5mm cableDigital Optical cable

Mains adapter

Getting to know your Soundbar

You’ll be up and running in no time

5 5

2 3

7 118

1. STANDBY button: Switch on the Sound bar or

switch to STANDBY mode.

2. VOLUME + / - buttons: Increase or decrease the

output volume.

3. SOURCE touch button: Select an audio source

from AUX, OPTICAL, COAX or BT inputs.

4. STATUS LED: Input mode and standby status.

5. WALL-MOUNT BRACKETS: Use these brackets to

fix the Sound bar to a wall.

6. SUB WOOFER CONNECTION CABLE: Connect to

the soundbar.

7. COAXIAL DIGITAL AUDIO INPUT (RCA): Connect

the digital audio output from a TV, DVD or Blu-ray player.

COAXIAL

OPTICAL

AUX

8. OPTICAL DIGITAL AUDIO INPUT: Connect the

digital audio output from a TV, DVD/ Blu-ray player or games console.

9. AUX AUDIO INPUT (3.5mm): Connect the

analogue audio output from an MP3 player or similar using a 3.5mm audio cable.

10. SUB WOOFER CONNECTION SOCKET: Connect

the sub woofer cable from No 6.

11. MAINS POWER DC INPUT: Connect the supplied

power adapter.

DC IN

SUB

or online at www.argos-support.co.uk If you still require further assistance, call one of our experts on 0345 600 3021 .

Getting to know your Soundbar
