BUSH
Model: FSAT+500 Cat No: 226/7470
LET’S GET
STARTED
YOUR USER GUIDE
WELCOME TO FREESAT
We are so pleased you bought this 500GB Bush Freesat+ HD recorder.
Now you can enjoy:
• Quality state-of-the-art satellite TV receiver
• Over 200 of your favourite channels
• Picture perfect High Definition (selected channels)
• BBC iPlayer, ITV Player
• Pause, Record and Rewind at the touch of a button
• Easy plug and play set up
• Expert customer support - visit Freesat.co.uk or call 0333 321 3200
Not included:
• Monthly subscriptions (It’s free)
• Lengthy contracts (It’s free forever)
• Baffling, complicated technology (It’s simple)
IMPORTANT - Please read these instructions fully before installing or using.
These instructions contain important information which will help you get the best from your appliance and ensure safe and correct installation, use and maintenance.
For any help concerning set up and use of your Digital Set Top Box please call the Freesat Helpline: 0333 321 3200
2
Manufactured under license from Dolby Laboratories. Dolby and the double-D symbol are trademarks of Dolby Laboratories.
Safety Information
IMPORTANT - Please read these instructions fully before installation
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with a dry cloth.
7. Do not block any ventilation openings; install in accordance with the instructions.
8. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat.
9. Do not defeat the safety purpose of the polarized plug. If the provided plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet.
10. Protect the power cord from being walked on or pinched, particularly at the plugs, convenience receptacles, and the point where they exit from the apparatus.
11. Only use attachments/accessories specified by the manufacturer.
12. Unplug this apparatus during lightning storms or when unused for long periods of time.
13. Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way, such as the power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.
14. Mains plug is used as the disconnect device; the disconnect device shall remain readily operable.
15. The ventilation should not be impeded by covering the ventilation openings with items, such as newspapers, table-cloth, curtains,etc.
16. No naked flame sources, such as lighted candles, should be placed on the apparatus.
17. Attention should be drawn to the environmental aspects of battery disposal.
18. The use of apparatus in moderate climate.
19. The apparatus shall not be exposed to dripping or splashing and objects filled with liquids, such as vases, shall not be placed on the apparatus.
WARNING: To reduce the risk of fire or electric shock, do not expose this apparatus to rain or moisture.
WARNING: The batteries shall not be exposed to excessive heat such as sunshine, fire or the like.
This symbol indicates that dangerous voltages constituting a risk of electric
shock are present within this unit.
This symbol indicates that there are important operating and maintenance
instructions in the literature accompanying this unit.
This symbol indicates that this product incorporates double insulation between hazardous mains voltage and user accessible parts. When servicing use only identical replacement parts.
CAUTION: Under the influence of electrostatic phenomenon, the product may
malfunction and require the user to reset the power.
This marking indicates that this product should not be disposed with other household waste throughout the EU. To prevent possible harm to the environment or human health from uncontrolled waste disposal, recycle it responsibly to promote the sustainable reuse of material resources. To return your used device, please use the return and collection systems or contact the retailer where the product was purchased. They can take this product for environmentally safe recycling.
Do not throw batteries in the bin or on a fire. Make sure that you dispose of batteries safely at a local recycling centre. You can also recycle batteries at many supermarkets.
3
ELECTRICAL SAFETY
Your receiver is supplied with an external 100V - 240V AC, 50Hz power supply that connects by 12V DC plug to the receiver and by UK mains plug adapter to the mains. Always connect the 12V DC plug to the receiver before connecting the mains plug.
If the mains plug breaks or becomes damaged, do not use it. Do not cut or open the adapter, as this will expose you to dangerous high voltages present inside. The adapter is non-serviceable and does not have any replaceable parts inside. If the power supply is damaged, it must be replaced by the manufacturer, its service agent, or suitably qualified persons in order to avoid a hazard.
To reduce the risk of electric shock, do not remove screws from the receiver or open it as it contains no user- serviceable parts. Please leave all maintenance work to qualified personnel.
4
CONTENTS
1
2
3
In The Box 7
Your receiver 8 Remote control 10
Preparation 12
The satellite dish 12 Connecting your receiver 12 Switching on 14 Tuning in 14
Everyday Use 17
Turning on the receiver 17 Changing channels 17 Changing the volume 18 Browsing bar 18 Subtitles and Audio Description (AD) 19 Using the channel list 20 Regional channels 20 Using the programme guide 21 Interactive TV services 23 Pausing live TV 23 Recording a programme 25 Using the library 26 Playing a recorded programme 28
4
Advanced Use 29
The lock PIN 29 Display mode 30 TV/DTV 30 Changing the channel list 30 Using the favourite channel lists 31 Manual timer recording 31 Using the menu system 32
Setup menu 33 General menu section 33
- Subtitles 33
- Subtitle language 33
- Auto standby 33
- HDCP 33 Picture menu section 34
- Screen type 34
- Display mode 34
- HDMI resolution 34
- Scart mode 34 Sound menu section 35
- Audio language 35
- Audio description 35
- Dolby digital 35
- Lip-sync delay 35
continued...
5
1
CONTENTS
4
Advanced Use (continued...)
Record menu section 35
- Default rec mode 36
- Add to start of rec 36
- Add to end of rec 36
- Live pause length 36
- Skip forwards time 36
- Skip backwards time 36
- Auto disk management 37
- Format hard disk drive 37 System menu section 37
- Freesat installation 37
- Add non-Freesat channels 37
- Network confi guration 37
- Parental guidance 37
- Hide adult channels 38
- Lock online content 38
- Change parental pin 38
- Software update via oad 38
- Software update via usb 38
- Check for software update 38
- Restore factory default 38 Information menu 38
5
6
On Demand TV 39
Setting up for On Demand TV 39 Watching On Demand TV 40
Non-Freesat Channels 41
Tuning in non-Freesat channels 41 Watching non-Freesat channels 42 Pausing and recording non-Freesat channels 43
Appendix A Troubleshooting 44 Appendix B Specifi cations 46
6
In The Box
In your Bush Freesat+ receiver pack you should fi nd the following items:
1
HDMI cable to connect to
an HD-ready TV
Quick Start Guide
Main User Guide
Power supply
Bush Freesat+ receiver
Batteries for the
remote control
Remote control
7
YOUR RECEIVER
Front
POWER Switch the receiver on and off
DOWN Switches to the previous channel
UP Switches to the next channel
ON Blue light indicates the receiver is on
STANDBY Red light indicates the receiver is in standby
SIGNAL Green light indicates valid signal
8
Rear
L and R AUDIO Stereo audio output for connection to an analogue audio system
LNB IN 1, LNB IN 2 Two inputs for connection to the satellite dish
TV SCART Output for connection to a non-HD television
VCR SCART Output/input for connection to video recorder or DVD recorder
S/PDIF Optical audio output for connection to a digital audio system
DC 12v Connection for the power supply unit
HDMI Output for connection to an HD-ready television
USB Socket for upgrading the receiver’s software
ETHERNET Network socket for connecting to the Internet
9
REMOTE CONTROL
Power - switches the receiver on and off.
Use the remote control within a maximum distance from the front of the receiver of 5m and within an angle of 60°. Ensure there is a clear line of sight between the remote control and the receiver. The operating distance may vary depending on the brightness of the room.
Mute - silences the receiver’s sound.
0, 1 … 9 - enter channel numbers, numeric values in the set-up menus or a jump point in playback. Also enters your postcode during the installation process.
Turns the volume up and down.
Switches to the next or previous channel. Moves one page up or down in the channel list and programme guide.
Exits a menu and returns to normal TV viewing.
Red, green, yellow, blue –Chooses options
within menus.
Displays the programme guide.
10
Displays channel and programme information.
Up, down, left, right - move the highlight bar in menus and in the programme guide, and allow you to browse the channels and programmes.
Selects the highlighted option in a menu.
Displays the list of programmes already recorded and set to
be recorded.
Exits a menu and returns to the previous menu.
Winds backwards or forwards through a recording being
played. Moves through the programme guide in 2 hour steps.
Records the selected programme.
Displays the main menu screen.
Selects favourite channels sequentially whilst watching TV
and adds favourite channels to the channel list.
Displays the channel list.
Switches between available screen display modes.
Switches back to the last channel watched.
Stops playback of a recorded programme. Returns to live TV
from paused live TV.
Pauses live TV. Starts and stops playback of a recorded
programme or paused live TV.
Jumps backwards or forwards through a recording being played. Moves through the programme guide in 24 hour steps.
Switches the TV SCART output between Freesat and the
TV’s tuner.
Displays the available audio menu used to change between
different soundtracks ( such as languages and audio description ).
Displays the subtitles menu used to select subtitles.
Displays interactive and digital text services (where available).
11
Preparation
DC 13V
CONNECTING YOUR RECEIVER
This section explains how to set up your Bush receiver to receive Freesat channels.
2
THE SATELLITE DISH
To receive Freesat, you must connect your receiver to an appropriate satellite dish, fixed in position and accurately pointed at the 28.2° East satellite position.
For safety reasons and to provide reliable reception, we strongly recommend that you have your dish installed by a professional. You may be able to use a satellite dish already installed at your home. If you have any questions about the dish, please consult your installer.
12
Place your receiver on a firm, level surface close to the television, a mains electricity socket, and the cables from the dish. (See page 3 – Safety.)
LNB IN 2
LNB IN 1
300mA max
300mA max
TV SCART VCR SCART ETHERNET USB HDMI
R
AUDIO
3A
OPTICAL
L
S/PDIF
RISK OF ELECTRIC SHOCK
DO NOT OPEN
Connect the two cables (or one double cable) from your dish to the LNB IN 1 and LNB IN 2 sockets at the back of the receiver (if the dish cables are fitted with a wall socket inside your home, you will need connecting cables, which you can get from your installer). It does not matter which of the two cables from the dish is connected to which LNB IN socket.
HINT: Each “F-connector” used for the satellite dish cable
connections has a central wire that is inserted into the hole in the LNB IN socket while the collar is screwed onto the socket. When screwing on the collar, make sure that the central wire goes into the socket hole and is not bent to one side.
Turn off your television at its mains socket and connect the HDMI
HINT: If your television has no HDMI socket, then it must
be connected to the receiver by SCART cable, and you will not be able to watch Freesat channels in High Definition.
cable supplied between the HDMI socket at the back of your receiver and an HDMI socket on your television. There may be more than one HDMI socket on your television. If you are not sure which to use, check the television’s manual.
Connect the +12VDC connector to the 3A DC 12Vconnector at the back of the receiver.Then connect the Power Supply Unit (unit with 3 pin mains plug) toan available mains socket that is turned off.
You may have other equipment, such as a DVD recorder or surround sound system, to connect to the receiver.
A video recorder or DVD recorder may be connected to your receiver to make permanent archive recordings of Freesat programmes. You will need to connect a SCART cable between the VCR SCART socket on the back of the receiver and a SCART socket on the video
or DVD recorder. Check the recorder’s manual for guidance.
You can listen to the sound from your Bush receiver through a stereo or surround sound system. For digital sound, connect an optical lead from the sound system’s S/PDIF socket to the one on the receiver. For analogue sound, connect a suitable lead between the receiver’s L and R AUDIO sockets and the L and R audio inputs on the sound system.
To watch On Demand TV services including BBC iPlayer and ITV Player, the receiver must be connected to your internet router or hub using an ethernet cable (not supplied). Plug one end of the ethernet cable into the ETHERNET socket at the back of the receiver, and the other into your hub or router. Make sure the connections are fully pushed in - you’ll hear a click as they lock into place. Consult your router or hub’s documentation for further guidance.
If your receiver is not located near your hub or router, you could use HomePlug powerline adapters to extend your home network using the ring main of your house. Another option is to use a Wireless Ethernet Bridge to bridge the Ethernet socket of the Bush receiver to wi-fi, enabling it to connect wirelessly to your home network. For more information, please consult with your installer or retailer. If you require support for these devices, you will need to contact the manufacturer. The receiver does not support USB Wi-Fi dongles.
13
SWITCHING ON
HINT: If you do not see this screen on your television, see
‘Troubleshooting’ on page 44.
Remove the battery compartment cover from the back of the remote control by lifting the cover catch. Insert the two AAA batteries supplied, as shown on the inside of the compartment. Replace the compartment cover.
Cover catch
Turn on your television at its mains socket, then if necessary bring it out of standby and choose the HDMI input (see your television’s manual for guidance). Switch on the mains socket that the receiver is connected to.
14
After a few seconds, the receiver’s fi rst Freesat installation screen will appear on the television screen:
TUNING IN
When the fi rst installation screen is displayed, use the or buttons to select between 16:9 Widescreen or the squarer 4:3 Traditional as the screen format of your television. Then press the button or the button to highlight the HDMI Resolution selection box, and use the or buttons to select the correct resolution for your television. You should set the HDMI resolution to the highest that your television can display (see your television’s manual). If in doubt, set the resolution to 720p.
HINT: Enter your postcode with the number buttons by
pressing the correct button on the remote a number of times to produce the required letter (printed on each button), or number, in the same way as ‘texting’ with a mobile phone. For example, for an ‘S’, you would press the button four times. If you make a mistake, the button deletes the last character entered.
Press or to highlight the “Next” box and then press to display the next installation screen. If after doing this you lose the picture on your screen press
to return to the first installation
screen using the default resolution of 720p (supported by all HDTVs).
The signal check screen shows the strength and quality of the Freesat signal received from your satellite dish. The signal lock is successful if both LNB inputs are receiving a valid signal. If the second input is not receiving a valid signal, you will be able to proceed with installation but recording functions of the receiver will not work correctly and a warning message will display. If the first input is not receiving a valid signal, the signal lock will fail and you will not be able to proceed. Check the satellite dish connections at the back of the receiver (switch the receiver off and reconnect the cables if necessary). If the connections are OK, consult your retailer or installer.
When the signal lock shows “Successful”, you can continue to tune in the receiver. Press
to proceed.
Enter your postcode using the number buttons on the remote control. You do not need to enter a space. Press the entered your postcode, and then press
button when you have
again to proceed.
15
