Bush BRC90DFBLK, BRC90DFSS Instruction manual

Instruction manual

Freestanding Cookers
BRC90DFBLK
BRC90DFSS

If you require any technical guidance or find that your product is not operating as intended, a simple solution can often be found in the Troubleshooting section of these instructions,

You’ll soon be enjoying your new Freestanding Cooker

It all begins here, with your instructions. Don’t worry,
there’s nothing too technical coming up. Just simple,
step-by-step guidance to get you up and running
quickly. Sound good? Then let’s get started.

Help

We’re here to help you get the most from your Freestanding Cooker. Should you require
any guidance, a simple solution can often be found online at:

www.bush-support.co.uk

If you still require further assistance, call one of our experts on 01759 487838.

and Guidance

or online at www.bush-support.co.uk If you still require further assistance, call one of our experts on 01759 487838

Contents

Safety information

1

Safety information 6

Getting to know your

2

Freestanding Cooker

Ready? Let’s begin 10

Accessories 11

Installing your Freestanding

3

Cooker

Installation requirements 14

Data Label 14

First Use 14

Unpacking 14

Technical Data 14

Connections (electrical, water, gas) 15

Care and Maintenance

5

Cleaning 32

Removing the door 33

Replacing the lamps 33

Maintenance 34

Technical specifications

Energy fiche

Product support

6

Troubleshooting 38

Help and assistance 39

Declaration of conformance to product
standards 40

Disposal 40

Guarantee 41

35

36

Surfaces 15

Installation details 16

Gas Conversion 19

Using your Freestanding

4

Cooker

Controls 22

Using the cooktop burners 22

Using the oven 23

Cooking modes 25

Using the digital clock 26

Practical advice 27

Cooking guides 28

3

1

Safety information

Safety information

Safety information

If you require any technical guidance or find that your product is not operating as intended, a simple solution can often be found in the Troubleshooting section of these instructions,

Important - Please read these instructions fully before

installing or operating

INSTALLATION WARNINGS

IMPORTANT: This product MUST be installed by a

qualied Gas Safe registered installer in accordance
with local regulations. Particular attention should be
given to the ventilation requirements.

IMPORTANT: Prior to Installation ensure that the local
supply conditions (gas type and pressure, electricity
voltage and frequency) are compatible with the
requirements of your cooker.

IMPORTANT: Carefully unpack and examine the
appliance for any damage. If you think there is a
defect, do not use the appliance and contact Bush
Product Support on 01759 487838. Packaging
materials should be collected together and disposed of
immediately as they may be harmful to children.

IMPORTANT: Keep the electrical cable (not supplied)
of your cooker away from the hot areas of your cooker;
do not let the cable touch the appliance. Keep the
cable away from sharp edges and heated surfaces.

IMPORTANT: Ensure that the electric supply cable is

not trapped or damaged during installation.

IMPORTANT: In the event that the cable connecting
your cooker becomes damaged, it must be replaced
by a suitably qualied person. This cable must not be
replaced by an unauthorised person.

IMPORTANT: Protect your cooker against atmospheric
effects. Do not expose your cooker to effects such as
sun, rain, snow etc.

DURING USAGE

IMPORTANT: This appliance can be used by children

aged from 8 years and above and persons with
reduced physical, sensory or mental capabilities or
lack of experience and knowledge if they have been
given supervision or instruction concerning use of the
appliance in a safe way and understand the hazards
involved. Children shall not play with the appliance.
Cleaning and user maintenance shall not be made by
children without supervision.

WARNING: The appliance and its accessible parts

become hot during use. Care should be taken to
avoid touching heating elements. Children less than 8
years of age shall be kept away unless continuously
supervised.

WARNING: Cooking on a hob with fat or oil can
be dangerous and should not be left unattended.

WARNING: NEVER try to extinguish a cooking re
with water. Instead switch off the appliance and cover
ame e.g. with a lid or a re blanket.

CAUTION: Cookers may topple forward if a child
climbs onto the cooker door. Children should be
supervised in the kitchen at all times and this cooker
must be secured to the wall using the xing kit
(included) to prevent accidents.

CAUTION: Do not allow children in the kitchen when
cooking or while cooker parts may still be hot. Many
parts of the cooker will become hot and present a
considerable hazard to children.

IMPORTANT: The materials surrounding the appliance
(cabinets) must be able to withstand a minimum
temperature of 100°C.

IMPORTANT: When using your oven for the first time
your cooker may give off smoke or an unusual odour
from the heating elements and insulation materials.
This is normal for new cookers. To eliminate this odour
run the oven at 250 degrees for 40-60 mins with the
oven empty.

WARNING: Before obtaining access to terminals, all
supply circuits must be disconnected.

6

CAUTION: When the oven is hot never touch the oven
glass by hand or with tools.

CAUTION: Before starting to use your appliance,
ensure curtains, paper or ammable items are kept
away from your appliance. Do not keep ammable
materials inside of or around your cooker.

CAUTION: Take care when closing the oven door that
there is nothing obstructing it from closing as this may
break the glass door.

IMPORTANT: When using the grill the oven door must
be kept closed.

Safety information

Safety information

or online at www.bush-support.co.uk If you still require further assistance, call one of our experts on 01759 487838

Important - Please read these instructions fully before

installing or operating

IMPORTANT: Position pans over the centre of the
burners and turn handles to a safe position where they
can not be knocked or grabbed.

IMPORTANT: Make sure the cooker control knobs are
all in the off position when not in use.

IMPORTANT: If you do not intend to use your cooker
for a long period of time turn off the gas and electric
supply to the cooker.

CAUTION: Using gas cooking appliances results in
the production of heat, moisture and the products of
combustion. Ensure that the room where your cooker
is installed is well ventilated particularly while the
cooker is in use. Keep natural ventilation holes open
or install a mechanical ventilation device (extractor
hood) Prolonged intensive use of your cooker may call
for additional ventilation (by opening a window) or by
increasing the level of mechanical ventilation where
present.

GENERAL SAFETY WARNINGS

IMPORTANT: This appliance has been designed for

non-professional, domestic use only. Do not use this
cooker for commercial use or any other application
e.g. room heating.

WARNING: Danger of re: do not store ammable
items on or near the cooking surfaces or inside the
oven.

IMPORTANT: When the door of the oven is open, do
not hang or lean anything on it. You may unbalance
your appliance or damage the door or door hinges.

IMPORTANT: Do not hang towels, dishcloths or
clothes from the cooker or its handles.

CLEANING AND MAINTENANCE

IMPORTANT: Always turn the appliance off before

operations such as cleaning or maintenance. You
can do this by switching the cooker off using cooker
isolation switch.

IMPORTANT: Do not remove the control knobs to
clean the control panel.

WARNING: Do not use harsh abrasive cleaners or
sharp metal scrapers to clean the oven door glass
since they can scratch the surface, which may result in
shattering of the glass.

TO MAINTAIN THE EFFICIENCY AND SAFETY
OF YOUR APPLIANCE, WE RECOMMEND YOU
ALWAYS USE OUR AUTHORISED SERVICE
AGENTS AND ORIGINAL SPARE PARTS.

FOR ASSISTANCE CALL BUSH PRODUCT
SUPPORT 01759 487838.

IMPORTANT: Do not try to lift or move this cooker by

pulling on the door handle.

WARNING: Ensure that the appliance is switched off
before replacing the lamp to avoid the possibility of
electric shock.

IMPORTANT: Your appliance is produced in
accordance with all applicable local and international

standards and regulations.

IMPORTANT: Maintenance and repair work must
only be performed by authorised service technicians.
Installation and repair work that is carried out by
unauthorised technicians is dangerous and could
invalidate your guarantee.

7

Getting to know your

Freestanding Cooker

2

Getting to know your Freestanding Cooker

You’ll be up and running in no time

Getting to know your Freestanding Cooker

If you require any technical guidance or find that your product is not operating as intended, a simple solution can often be found in the Troubleshooting section of these instructions,

Ready? Let’s begin...

Please read these instructions carefully. They contain
important information which will help you get the best
from your Freestanding Cooker and ensure safe and
correct installation and operation.

If you require any further assistance, our technical
experts are happy to help. For full details, refer to
the product support section at the end of these
instructions.

10

Getting to know your Freestanding Cooker

You’ll be up and running in no time

1

2

3

4

6

7

9

10

11

8

2

5

12

1. Cast iron Trivets

2. Semi-rapid Burner

3. Wok Burner

4. Rapid Burner

5. Auxiliary Burner

13

14

15

9. Wire Shelf

10. Shelf positions

11. Baking tray

12. Oven door

13. Door Seal

6. Burner Control Knobs

7. Timer Controls

8. Oven Controls Knobs

or online at www. h-support.co.uk If you still require further assistance, call one of our experts on 01759 487838

14. Hinge

15.

Levelling feet

Getting to know your Freestanding Cooker

11

Getting to know your Freestanding Cooker

You’ll be up and running in no time

Getting to know your Freestanding Cooker

If you require any technical guidance or find that your product is not operating as intended, a simple solution can often be found in the Troubleshooting section of these instructions,

Accessories

1. Grill pan & handle set

2. Two wire shelves

3. Fixing Assembly

4. LPG Nozzles

5. Levelling Feet

1

Oven & Accessories

The oven is supplied with chrome wire
Shelf Supports and a range of shelf
options as shown below. There are four
shelf positions on the oven.

2

3

4

5

12

Installing your

Freestanding Cooker

3

Installing your Freestanding Cooker

Bringing it all together

Installing your Freestanding Cooker

If you require any technical guidance or find that your product is not operating as intended, a simple solution can often be found in the Troubleshooting section of these instructions,

RISK OF ELECTRIC SHOCK

DO NOT OPEN

CAUTION

CAUTION:

TO REDUCE THE RISK OF ELECTRIC
SHOCK, DO NOT REMOVE COVER
(OR BACK). NO USER-SERVICEABLE
PARTS INSIDE. REFER SERVICING TO
QUALIFIED SERVICE PERSONNEL.

RISK OF ELECTRIC SHOCK

DO NOT OPEN

CAUTION

CAUTION:

TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER (OR BACK).
NO USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE
PERSONNEL.

Installation requirements

THIS COOKER MUST BE INSTALLED
ACCORDING TO BS 6172: 2010 BY A SUITABLY
QUALIFIED GAS SAFE REGISTERED INSTALLER

• IMPORTANT: CONTACT AN
AUTHORISED SERVICE AGENT FOR
INSTALLATION OF YOUR OVEN!

Data Label

The Data Label is located on the rear of the
appliance. A duplicate Data Label is supplied to
adhere in an accessible area next to the appliance.
This appliance is suitable for Natural Gas and
Universal LPG; ensure that the available gas supply
matches the Data Label and the gas type label.

First Use

IMPORTANT: When using your oven for the first
time your cooker may give off smoke and an
unusual odour from the heating elements and
insulation materials. This is normal for new cookers.
To eliminate this odour run the oven at 250 degrees
for 40-60 mins with the oven empty.

Unpacking

Carefully unpack and examine the appliance for
any damage. If you think there is a defect, do not
use the appliance and contact Product Support
on 01759 487838.

Packaging materials should be collected
together and disposed of immediately as they
may be harmful to children.

Levelling feet

The height and level of the appliance can be
adjusted by rotating the feet located underneath
the appliance at each corner. Rotate in a
clockwise direction to decrease the height and
anti clockwise to increase the height. The levelling
feet need to be installed on the bottom of the
cooker in the first instance before cooker can be
adjusted for balancing.

14

Technical Data

Inner dimensions of the oven

Width: 66cm Depth: 35.6cm Height: 43.5cm

Inner Volume of the oven: 103 litres.
Voltage & Frequency

of power supply: 240V – 50Hz

Electrical features:
Oven Light: 2x25W
Spit motor : 4W
Upper heating element: 900W
Bottom heating element: 1800W
Grill heating element: 2300W
Circular heating element: 2x1250W
Motor Ventilator: 2x20W
Cooling fan: 18W

Installing your Freestanding Cooker

Bringing it all together

Installing your Freestanding Cooker

or online at www.bush-support.co.uk If you still require further assistance, call one of our experts on 01759 487838.

Insta

llation of Cooker

Gas

This modern cooker was manufactured with parts and
materials of the highest quality and was designed to
meet your cooking needs. You should read this manual
so that you are able to use the cooker correctly and to
avoid any potential problems with using the cooker.
The following information outlines the required rules
for correct installation and service of your cooker. This
is particularly important for the technician who will
install the appliance.

CONTACT AN AUTHORISED SERVICE AGENT FOR
INSTALLATION OF YOUR OVEN!

VENTILATION REQUIREMENTS

For rooms with a volume of less than 5 m³ - permanent
ventilation of 100 cm² is required see figure 1 and 2 for
an example.

For rooms with a volume of between 5 m³ and 10m³
a permanent ventilation of 50 cm² will be required
unless the room has a door which opens directly to
the outside, in which case no permanent ventilation is
required.

There must be enough natural ventilation to provide
the gas to be used in the environment. The average air
flow must directly come in through ventilation from the
outside.

Emptying of the Burned Gases from Environment

For cooking appliances that operate with gas, burned
gas wastes are exhausted directly to the outside
or through cooker hoods that are connected to a
chimney that opens directly to the outside. If it is not
possible to install a cooker hood, it is required to set
an electric fan on the window or wall that has access
to fresh air. This electric fan must have the capacity to
change the volume of air in the kitchen environment
4-5 times per hour.

For rooms with a volume greater than 10 m³ - no
permanent ventilation is required.

Attention: Regardless of room size, all rooms
containing the appliance must have direct access to
the outside air via an openable window or equivalent.
The room containing the cooker should have an air

supply in accordance with BS 5440: Part 2.

Environment where your appliance will be installed

Your cooker must be set up and used in a place where
it will always have ventilation. While operating, this
appliance needs 2m³/h air per kw input.

15

Installing your Freestanding Cooker

Bringing it all together

Installing your Freestanding Cooker

If you require any technical guidance or find that your product is not operating as intended, a simple solution can often be found in the Troubleshooting section of these instructions,

Gas Connection

IMPORTANT - All Gas installations must be carried
out by a suitably qualified person. For information
on choosing a gas installer contact the ‘Gas Safe
Register’.

www.gassaferegister.co.uk

The appliance can be placed close to other furniture
on condition that the furniture’s height does not
exceed the height of the cooker panel Make sure that
there are no combustible or flammable materials, such
as curtains, in the vicinity of the installation.

There must be at least 2cm of free space between the
back wall and the rear of the appliance to allow for
ventilation and air circulation.

Positioning

The furniture close to the cooker must be
manufactured resistant to temperatures up to 100°C.

If the kitchen furniture are higher than the hob plate
of the cooker, it must be at least 10cm away from the
cooker’s side.

Surrounding furniture, cabinets and extractor fans
should be positioned in accordance with the diagram
shown in figure 3. If fitted, the extractor fan must be at
least 65cm above the hob.

If no fan is fitted the minimum distance between the
hob and any cabinet or other structure must be 70cm.

Adjustment of feet

The height and level of the appliance can be adjusted
by rotating the feet located underneath the appliance
at each corner. Rotate in a clockwise direction to
decrease the height and anti clockwise to increase the
height.

Min 100cm

16

Figure 3

Installing your Freestanding Cooker

Bringing it all together

Installing your Freestanding Cooker

or online at www.bush-support.co.uk If you still require further assistance, call one of our experts on 01759 487838.

Installing your Freestanding Cooker

Bringing it all together

Anti-tilting chain

The cooker is supplied with an anti-tilting chain to prevent the appliance from tilting forward and
causing accidental damage to the gas pipe. Make a hole in the wall behind, at the same height as the
fixing chain. Using the fixing assembly (page 12 fig.3) insert the plug into the hole and then screw in
the hook until it is firmly fixed to the wall. Fix the chain to the hook. You can adjust to the level of the
cooker by inserting the feet provided.

1
2
3
4
5

Safety chain (supplied and mounted to oven)
Stability hook
Chain attachment for the rear of the cooker
Rear of the cooker
Kitchen wall

17

Installing your Freestanding Cooker

Bringing it all together

Installing your Freestanding Cooker

If you require any technical guidance or find that your product is not operating as intended, a simple solution can often be found in the Troubleshooting section of these instructions,

Electrical connection

IMPORTANT: Electrical connections must be carried
out by a suitably qualified person and in accordance
with all relevant local building and installation
regulations.

1. See the rating label at the rear of the product for the
appliance’s load rating.

2. The cooker must be connected to a dedicated

circuit suitably rated for the load of the appliance
(see rating label at rear of appliance) as shown in the
wiring diagrams below. It must be connected via a
suitably rated cable to a double pole isolator cooker
switch also suitably rated for the appliance.

3. The electrical cable should not touch the hot parts

of the appliance. .

The electrical cable (not supplied) should not be
routed through any area that may be aected by
heat from the oven, especially the area directly
behind the oven.

18

Installing your Freestanding Cooker

Bringing it all together

Installing your Freestanding Cooker

or online at www.bush-support.co.uk If you still require further assistance, call one of our experts on 01759 487838.

Gas Conversion (NG to U-LPG)

Parts needed

- Test Point Assembly - ULPG Gas Type label

- Auxiliary Jet 00.53mm - Semi-Rapid Jet 00.68mm

- Wok Jet 01.00mm - Rapid / Fish Jet 00.88mm

Converting to a dierent gas type

CONVERSION TO A DIFFERENT GAS TYPE MUST BE
CARRIED OUT BY A SUITABLY QUALIFIED GAS SAFE
REGISTERED INSTALLER

Changing the jets

1. Remove pan supports, burner heads and caps.

2. Use a size 7 socket wrench to unscrew and remove
the jets, replacing them with those supplied in the
conversion kit. Ensure you use the correct jet for the
corresponding burner.

3. Reassemble the burner heads, caps and pan

supports.

4. Fit the Gas type label supplied in the conversion kit

next to the gas connection point and remove the
existing label.

Setting the minimum level

1. Light one of the burners and turn the tap to

minimum flame.

2. Remove the corresponding control knob.

3. Use a thin blade screwdriver to turn the by-pass
screw located above left of the gas valve shaft as
shown right. Turn the by-pass screw fully clockwise.
The result should be a small, stable flame which is
uniform around the entire burner ring. If not, turn the
by-pass screw anti-clockwise until satisfied with the

flame.

4. Check that the burner does not go out when the tap
is turned quickly from the maximum to the minimum
position.

5. Repeat for each burner.

19

Using your Freestanding Cooker 4

Using your Freestanding Cooker

,

Controls

Digital Automatic Clock

Decrease time
Function
Increase time

Control knob (Cooktop Burners)

Cooking Temperature Selection Knob

Instructions for use (cooktop burners)

The symbols on the control knobs mean the
following:

No gas fl

o

Maximum gas flow or ‘high’ flame and
lighting position

Minimum gas flow or ‘low’ flame

All operating positions must be set between the
maximum and minimum flow settings, and never
between the maximum setting and the closed
position.

Gas Burner Components

A Burner cap
B Burner Head
C Burner Bowl
D Thermocouple (where fitted)
E Electrode

Cooking Mode/Selection Knob

If you require any technical guidance or find that your product is not operating as intended, a simple solution can often be found in the Troubleshooting section of these instructions

22

These parts can be removed for cleaning
periodically. After cleaning, they must be well
dried and correctly replaced. It is important to
check that the burner bowl and cap have been
correctly positioned. Failure to do so can cause
serious problems.

Using your Freestanding Cooker

Getting the most from your appliance

Using your Freestanding Cooker

or online at www.bush-support.co.uk If you still require further assistance, call one of our experts on 01759 487838

To light the cooktop burners

To light the burner, press the control knob fully
down and hold the knob down before rotating
anti clockwise to the High Flame position. The
ignition device is integrated into the control knob
and is automatically activated by pushing down
on the control knob.

After lighting the flame, keep the knob pressed for
about 10 seconds: this time is necessary to heat
up the thermocouple and activate the safety valve,
which would otherwise cut o the gas flow. This
step only applies where flame failure device is
fitted.

In the instance of a power failure, place a lit match
near the burner and proceed as described above.
If the flame does not light after the first attempt,
wait 5 minutes for the gas to dissipate before
attempting to re-light the burner.

Once lit, check that the flame is evenand turn the
control knob to adjust the flame as required. If
the flame is uneven, check that the ‘burner head/
skirt’ and ‘burner cap’ are correctly positioned. To
turn o the flame, turn the control knob clockwise
to the o position (
pots or pans from the burners, always turn o the

flame.

For correct use of the cooktop

For lower gas consumption and better eciency,
use only flat-bottomed pan of dimensions suitable
for the burners, as shown in the table below. Also
as soon as a liquid comes to the boil take care to
turn the flame down to a level that will just keep it
boiling.

symbol) Before removing

The use of pans in excess of the maximum
diameter recommended in the table above can
result in over heating/discoloration of hob surface.
During cooking processes involving fats and
oils, watch your foods carefully because these
substances may catch fire if overheated.

How to use your oven

This multi-function oven combines the
advantages of traditional convection ovens with
modern fan assisted ovens in a single appliance.
It is an extremely versatile appliance that allows
you to choose easily and safely between dierent
cooking modes. The various cooking modes are
selected by means of a cooking mode selection
knob, located on the control panel.

To operate the oven:

- Ensure that manual mode is selected (page 26)

- Turn the cooking mode selection knob to the
desired cooking mode (explanation of cooking
modes on page 25)

- Turn the cooking temperature selection knob
to the desired temperature (cooking guide is on
pages 29) or to ‘MAX’ if grilling.

rst time you use your appliance, we

The fi
recommend that you set the thermostat to the
highest setting, set the cooking mode selection
knob to a cooking mode and leave the oven
on for about half an hour with nothing in it and
the oven door shut. Then, open the oven door
and allow the oven to cool. Any smoke or
odour that may be detected during this initial
use is due to the evaporation of substances
used to protect the oven during storage.

Burner Min. Diameter

Large (rapid 150mm 260mm
Medium (semi-rapid) 130mm 180mm
Small (Auxiliary) 90mm 160mm
Triple Flame (Wok) 210mm 270mm

Max. Di

ameter

23

Using your Freestanding Cooker

If you require any technical guidance or find that your product is not operating as intended, a simple solution can often be found in the Troubleshooting section of these instructions,

Positioning the oven trays & shelves

The Baking Tray, Grill Tray or Oven Shelf can be
located in any of the five height positions in the
oven if your oven does not have Telescopic Shelf
Supports. Oven Shelves cannot be fitted to the
Telescopic Support. Only fit the Baking Tray or Grill
Tray to the Telescopic Support.

When fitting the trays or shelves, ensure they
are fitted between the two wires that are closest
together as shown below. Oven Shelves have
a stop so that they are not fully withdrawn by
accident. To fully remove the Oven Shelves, lift
the front of the shelf slightly and withdraw fully
from the oven. Note that the Grill Tray and Baking
Tray do not have a stop position and can be fully
withdrawn without interruption, so be careful not
to accidentally fully withdraw the trays.

Fit Trays and Shelves between bars as shown
below.

Note: Place the Baking Tray provided on the
bottom shelf position of the oven to prevent any
spillages from dripping onto the bottom of the
oven. Never place anything (including foil and

oven trays) on the bottom of the oven when it
is in operation because this could damage the
enamel. Only place your cookware (dishes, trays,

aluminium foil, etc.) on the Oven Shelves provided
with the appliance.

If supplied, use the chrome wire handle
shown below when removing the trays from
the oven.

Above: Fitting the oven shelf to the chromed
shelf supports

24

Using your Freestanding Cooker

Getting the most from your appliance

Using your Freestanding Cooker

or online at www.bush-support.co.uk If you still require further assistance, call one of our experts on 01759 487838

COOKING MODES

Defrost mode
When set to ‘Defrost’ mode, the fan located at the
back of the oven circulates room temperature air
around the food. This is recommended for the
defrosting of all types of food, but in particular for
delicate types of food which do not require heat,
for example: ice cream cakes, cream or custard
desserts, fruit cakes, etc. By using ‘Defrost’ mode,
the defrosting time is approximately halved. In
the case of meat, fish and bread, it is possible to
accelerate the process by selecting ‘Multi Cooking
mode’ and setting the temperature between ao0c
to 100°c.

Convection mode
When set to Convection mode, the top and
bottom heating elements operate together like
a ‘normal’ conventional oven that you have
probably used before.

Convection mode is best suited for traditional
baking and roasting and you should only use one
shelf at a time, otherwise the heat distribution will
be uneven. You can balance the amount of heat
between the top and the bottom of the dish by
selecting a dierent shelf height. If you want more
heat at the top of the dish place the dish on the
top or second shelf. For more heat at the bottom
of the dish, place the dish on third or fourth shelf.

Baking mode
When set to Baking mode, the fan element
and the fan operate providing a delicate heat
distributed uniformly throughout the oven.

Grill Mode
Select ‘Grill’ mode with cooking mode selection
knob and turn cooking temperature selection
knob to ‘Max’. When set to Grill mode, the top
inner element operates. The extremely high and
direct temperature of the grill make it possible
to brown the surface of meats and roasts while
locking the juices in to keep the tender. Grill
mode can also be used for dishes that require a
temperature on the surface such as beef steaks,
veal, rib, steak, filets, hamburgers, etc.

Grill food with the oven door closed.

Top heat mode

When set to Top heat mode, the top heating
element operates. This mode can be used to
brown food at the end of cooking.

Fan assisted Top Heat mode
Select a ‘Fan Assisted Top’ mode with cooking
mode selection knob and turn cooking
temperature selection knob to the desired
temperature setting. When set to Fan Assisted
Top mode, the top inner element and the fan
operate. This mode increases the circulation of air
throughout the oven, which helps prevent food
from burning on the surface, allowing the heat to
penetrate right into the food. Particularly suitable
for kebabs made with meats and vegetables,
sausages, ribs, lamb chops, chicken, quail, pork
chops, fish steaks, stued cuttlefish etc.

This mode is ideal for baking and cooking delicate
foods on multiple shelves, especially cakes that
need to rise such as cream pus and for certain
tartlets, sweet or savoury biscuits, savoury pus,
swiss rolls and small portions of vegetables, etc.

Delicate cooking mode
When set to Delicate cooking mode, the bottom
element and the fan will operate. This mode is
suitable for pastries, cakes and no dry sweets in
baking tins or moulds that require heat from the
bottom.

25

Using your Freestanding Cooker

If you require any technical guidance or find that your product is not operating as intended, a simple solution can often be found in the Troubleshooting section of these instructions,

Using your Freestanding Cooker

Getting the most from your appliance

Programmable Timer

This model has a digital display, 24hr clock with 3
control buttons. When the power is connected,
the screen displays ‘AUTO’.

Adjusting the digital clock
For first use of cooker, the time must be set by
using the digital timer. The time must be set every
time the cooker has been reset by the mains. To
set the correct time, press the button to
remove 'AUTO' first, then + or - button to
advance forward or backward until the correct
time is displayed.

Manual operation setting

If ‘AUTO’ is flashing, automatic or semi-automatic
program has been set. Press button, ‘AUTO’
will clear from the display and the oven can be
operated manually.

Automatic setting
Automatic setting of the oven allows you to
select the end time, cooking time, temperature
and cooking mode. The oven will switch on,
cook according to the selected cooking mode
and temperature and then switch off
automatically;

As an example:
want it to finish at 14:00

1.
the bar above
45 minutes.

2. Press the function button repeatedly until
the bar above flashes and set the finish time to
14:00.
After the above setting , the current time is
displayed and
indicating that automatic cooking feature of the
oven is set. When the clock displays 13:15, the oven
will start cooking automatically.
While cooking the bar will flash.

Press the function button repeatedly until

If cooking time takes 45 minutes and you

flashes and set the cooking time

the bars above and will flash,

1. Press the function button repeatedly until
the bar above flashes , then press + or – button
to set the time frame for baking.

2. Press the function button repeatedly until
the bar above flashes , then press + or – button
to set the time to switch off.

3. Set cooking temperature and cooking mode
by turning the thermostat and function knob.
After these have been set, the bars above and
will flash, indicating that automatic cooking feature
of the oven is set.

26

Using your Freestanding Cooker

Getting the most from your appliance

Using your Freestanding Cooker

or online at www.bush-support.co.uk If you still require further assistance, call one of our experts on 01759 487838

The oven starts immediately, and ‘AUTO’ will
flash. When the finish time is reached, the oven
automatically stops cooking. The alarm will ring
and ‘AUTO’ will flash, press the
ringing will stop.

When the button is pressed during semi­automatic cooking, the set cooking time is
displayed. If the button is pressed and the time
is set back to ‘O’, the semi-automatic setting will
be cancelled. When button is pressed again,
the oven will revert to the manual mode.

Timer

The digital countdown timer can be set up to 23
hours and 59 minutes maximum.

To set the timer, press the button and then + or

- button until the desired time is displayed. Once
the button is released, the current time and U
is displayed. When the button is pressed the
remaining time is displayed. When the set time is
reached, disappears and the alarm will ring. To
stop the alarm, press the button.

button and the

Note: When cooking is finished, the cooking fan
continues to operate until the oven cools down
and then switches o automatically.

PRACTICAL COOKING ADVICE

The oven oers a wide range of settings which
allow you to cook any type of food in the best
possible way. With time you will learn to make the
best use of this versatile cooking appliance and
the following directions are only a guideline which
may be varied according to your own personal
experience.

Preheating

If the oven needs to be preheated, the ‘Convection’
mode or ‘Baking’ mode should be selected.
These are the most ecient modes, which will
reach the desired temperature as quickly as
possible using the least amount of energy.

Once the food has been placed in the oven, the
desired cooking mode should then be selected.

Note: After pressing the button, timer settings
should be done within 5 seconds.

In case of a power failure, all settings including
the time display will be lost. When the power is
returned, three ‘O’ and ‘AUTO’ will be displayed.

The oven light

Set cooking mode selection knob to symbol
to switch on the oven light/s. The oven light/s stay
on when the oven is operating.

Cooling ventilation

In order to cool down the exterior of the
appliance, this model is equipped with a cooling
fan, which switches on automatically. When the
cooling fan is on, you will notice a flow of air
exiting between the oven door and the control
panel.

Multi shelf cooking

If you want to cook food on several shelves, select
the ‘Baking’ mode as this is the only cooking
mode that allows you to do so.

When cooking delicate foods on more than one
shelf, use the ‘Baking’ mode. This mode allows
you to cook on 3 shelves at the same time. Refer
to the ‘Cooking Guide’ table.

27

Using your Freestanding Cooker

If you require any technical guidance or find that your product is not operating as intended, a simple solution can often be found in the Troubleshooting section of these instructions,

Using the Grill

Baking cakes

This multi-function oven has 2 dierent grilling
modes.

Use the ‘Grill’ mode
place the food on the centre of the grill pan, insert
and fit the grill pan on either the 3rd or 4th shelf
from the bottom. Note: only the central part of the
top heating element operates for grilling.

When using ‘Grill’ mode, we recommend you set
the thermostat to the highest setting. However,
this does not mean you cannot use lower
temperatures, simply adjust the thermostat knob
to the desired temperature.

Use ‘Fan assisted grill’ mode
door shut. This mode is very useful for grilling
foods rapidly, as the distribution of heat by the fan
makes it possible not only to brown the surface,
but also to cook the bottom of the food. It can
also be used for browning foods at the end of the
cooking process, such as adding that gratin finish
to pasta bakes for example.

When using ‘Fan assisted grill’ mode, place the
food on the 2nd or 3rd oven shelf from the
bottom, then place a dripping-pan on the 1st rack
from the bottom to prevent fat and grease from
dripping onto the oven floor. We recommend
you set the thermostat to 200°c, as it is the most
ecient temperature for ‘Fan assisted grill’ mode.
However, this does not mean you cannot use
lower temperatures, simply adjust the thermostat
knob to the desired temperature.

with the oven door ajar,

with the oven

When baking cakes, always place them in a
preheated oven. Make sure you wait until the oven
has been preheated thoroughly (the indicator light
will turn o). To prevent heat loss and the cake
from dropping, do not open the oven door during
baking.

In general...

... if pastry is too dry
Increase the temperature by 10°C and reduce the
cooking time.

... if pastry has dropped
Use less liquid or lower the temperature by 10°C.

... if pastry is too dark on top

Place it on a lower shelf, lower the temperature,
and increase the cooking time.

... if cooked well on the inside but sticky on the
outside

Use less liquid, lower the temperature, and
increase the cooking time.

... if the pastry sticks to the pan
Grease the pan well and sprinkle it with a dusting
of flour or use greaseproof paper.

... if I used multi shelf cooking and one shelf is
more cooked

Use a lower temperature setting next time. It is not
necessary to remove the food from all the racks at
the same time.

Important: for best results and to save energy,
always use the ‘Fan assisted grill’ with the oven
door shut.

28

Using your Freestanding Cooker

Getting the most from your appliance

Using your Freestanding Cooker

or online at www.bush-support.co.uk If you still require further assistance, call one of our experts on 01759 487838

Cooking pizza

For best results when cooking pizza:

• Preheat the oven for at least 10 minutes.

• Use a light aluminium pizza pan, placing it on
the shelf supplied with the oven. Don’t use the
dripping pan since this will extend the cooking
time, making it dicult to get a crispy crust.

• Do not open the oven door frequently while the
pizza is cooking;

• If the pizza has a lot of toppings (three or four),
we recommend you add the mozzarella cheese
on top halfway through the cooking process.

• For best results, only use one shelf at a time,
but if you want to cook on two shelves, use
the 2nd and 4th racks from the bottom with a
temperature of 220°c and swap them halfway
through cooking.

Cooking fish and meat

When cooking white meat, fowl and fish, use a
temperature setting from 180°C to 200°c.

For red meat that you want well done on the
outside while tender and juicy in the inside, it
is best to start with a high temperature setting
(200°C-220°C) for a short time, then turn the oven
down afterwards.

In general, the larger the roast, the lower the
temperature setting. Place the meat on the centre
of the shelf and place the dripping pan beneath it
to catch the fat.

Make sure that the shelf is inserted so that it is
in the centre of the oven. If you would like to
increase the amount of heat from below, use a
lower shelf height. For savoury roasts (especially
duck and wild game), dress the meat with lard or
bacon on the top.

29

Care and maintenance

5

Care and maintenance

Looking after your appliance

Care and maintenance

If you require any technical guidance or find that your product is not operating as intended, a simple solution can often be found in the Troubleshooting section of these instructions,

Cleaning

WARNING! Isolate the power supply to the cooker and
make sure that the oven is cool.

Before cleaning your oven or performing
maintenance, make sure that the cooking mode
selection knob and the cooking temperature
selection knob is set to ‘OFF’. To extend the life
of your oven, it must be cleaned frequently.

The inside of the oven should preferable be
cleaned immediately after use, when it is still
warm (but not hot), with warm water and
soap. The soap should be rinsed away and the
interior dried thoroughly. Avoid using abrasive
detergents, scourers, acidic cleaners such as lime
scale remover, etc, as these could damage the
enamel, and can result in development of rust
and corrosion. If stains are particularly tough to
remove, use cleaners specifically recommended
to clean ovens and follow the instructions
provided with the cleaner. Never use steam

cleaner for cleaning inside the oven.

Burner Caps:

Periodically, the enamelled pan support,
enamelled covers and burner heads must be
washed with warm soapy water, rinsed and dried.
After drying them thoroughly, place them back in
their original positions on the burners

Enamelled Parts:

In order to keep enamelled parts as new, it is
necessary to clean them frequently with mild
warm soapy water and then dry with a cloth. Do
not wash them while hot and never use abrasive
powders or abrasive cleaning materials. Do not
leave anything spilled onto enamelled parts for
long periods of time.

Stainless Steel:

Stainless steel parts must be cleaned frequently
with mildly warm soapy water and a soft sponge
and then dried with a soft cloth. Do not use
abrasive powders or abrasive cleaning materials.
Do not leave anything spilled onto stainless steel
parts for long periods of time.

Do not clean using caustic creams, abrasive
cleaning powders, thick wire wool or hard tools.
Enamelled parts of the oven can be damaged
if excess cleaning liquids are not immediately
removed.

After cleaning the interior parts of the oven with a
soapy cloth, rinse it and then dry thoroughly with
a soft cloth.

Clean the glass surfaces with special glass
cleaning agents.

Never use flammable agents like acid, thinner or
petrol when cleaning your oven.

Do not clean your oven with a steam cleaner.

Do not wash any part of your oven in a

dishwasher.

32

Care and maintenance

Looking after your appliance

Care and maintenance

or online at www.bush-support.co.uk If you still require further assistance, call one of our experts on 01759 487838

How to remove the oven door

You can remove the oven door for better access
to the oven when cleaning. Please see the
instructions below for how to safely remove and
replace the oven door.

Remove and assemble procedure

Remove and assemble procedure

• Open door fully

• Lift up and turn the small levers situated on the
two hinges fully back

• Grip the door on the two external sides; shut
it slowly until door contacts the clips. Then
continue closing door until it is about 10cm from
closing fully.

• Pull the door towards you, pulling it out of its
seat. Door will gently come away from oven.

• To reassemble the door follow the above
procedures backwards.

Please note if door does not come away
from oven easily do not forcefully remove.

Replacing the oven lamps

WARNING: Ensure that the appliance is switched off
before replacing the lamp to avoid the possibility of
electric shock.

Remove the glass cover of the lamp-holder as
shown below.

Remove the lamp and replace with a lamp
resistant to high temperatures (300°C) with the
following characteristics:

- Voltage: 220-240V

- Wattage: 25W

- Type: E 14

Replacement lamps are available from our
Support Team. Replace the glass cover and
reconnect the oven to the mains power supply.

33

Care and maintenance

Looking after your appliance

Care and maintenance

If you require any technical guidance or find that your product is not operating as intended, a simple solution can often be found in the Troubleshooting section of these instructions,

Routine maintenance

Have the condition and eciency of the gas pipe
and the pressure regulator (if installed) checked
periodically. If anomalies are found, do not repair
components but have the faulty component
replaced. To ensure good performance and
safety, the gas regulator taps must be greased
periodically.

Periodic lubrication of the taps and any other
appliance service must only be carried out by
Authorised Personnel.

Abnormal operation

Any of the following are considered to be
abnormal operation and may require servicing:

• Yellow tipping of the burner flame.

• Sooting up of cooking utensils.

• Burners not igniting properly.

• Burners failing to remain alight.

• Burners extinguished by cupboard doors.

• Gas valves, which are dicult to turn.

In case the appliance fails to operate correctly,
contact our Support Team on 01759 487838.

34

Care and maintenance

Looking after your appliance

Technical specification

Model

Power supply

BRC90DFBLK/ BRC90DFSS

220-240V~50-60Hz

Maximum Oven Power (W) 2880-3428

Actual Product Size (W x D x H) mm

900 X 600 X (855-900)

Net Weight (kg) 70

Main Oven Volume (L) 103

Second Oven Volume (L) N/A

Energy rating

We apologise for any inconvenience caused by minor inconstancies within these instructions that may
occur due to product improvements and development

All images and drawings are for illustration purposes only.

A

or online at www. h-support.co.uk If you still require further assistance, call one of our experts on 01759 487838

Care and maintenance

35

Energy fiche

Brand

Model

Type of oven

Mass

Energy Class

Energy consumption (electricity) - conventional

Energy consumption (electricity) - fan forced

kg

kWh/cycle

kWh/cycle

BRC90DFBLK/ BRC90DFSS

Electric

70 (+/-2)

122.1

104.8

A

1.20

1.03

Number of cavities

Heat Source

Volume

This oven complies with EN 60350-1

Energy Saving Tips

Oven

- Cook the meals together, if possible.

- Keep the pre-heating time short.

- Do not elongate cooking time.

- Do not open oven door during cooking period.

Type of hob

Number of gas burners

1

Electric

L

103

Energy Saving Tips

Hob

- Use cookwares having flat base.

- Use cookwares with proper size .

- Use cookwares with lid.

- Minimize the amount of liquid or fat.

- When liquid starts boiling , reduce the setting.

Gas hob

5

36

EE gas burner

EE gas hob

If you require any technical guidance or find that your product is not operating as intended, a simple solution can often be found in the Troubleshooting section of these instructions,

Care and maintenance

Triple Ring Burner: 53.56%
Rapid Burner: 56.72%
Semi-rapid Burner-1: 57.01%
Semi-rapid Burner-2: 58.33%
Auxiliary Burner: N.A.

56.4%

Product support

6

Product support

Help is always at hand

Product support

If you require any technical guidance or find that your product is not operating as intended, a simple solution can often be found in the Troubleshooting section of these instructions,

Troubleshooting

1. If no electrical functions appear to work, check
the cooker isolation switch has not been turned
o also check the fuse in the switch and the
circuit breaker in you consumer unit

2. After replacing the fuse or resetting the circuit

breaker turn on individual parts of your cooker
one at a time to check function

Problem Possible Cause Solution

Only parts of the cooker
work it may be that the ovens

Links may be missing in
the rear connector box

or the grill, do not work

Nothing works (completely
dead)

Power is turned o at
the isolation switch or
the consumer unit

3. DO NOT ATTEMPT TO REPAIR THIS
COOKER YOURSELF. CALL BUSH PRODUCT
SUPPORT ON 01759 487838 OR CONSUL
A GAS SAFE REGISTERED INSTALLER

Refer to the Quick Start
Guide to check the correct
placement of the links
This must be done by a
qualified competent person

Ensure isolation switch is on
Check consumer unit has not
tripped out

T

Poor electrical connection

The hob burners do not
operate correctly

Check if the burner parts
are correctly assembled
(especially after cleaning).

Oven not heating up Oven temperature not set

correctly

Door is not properly
closed

Have the connections
checked by a qualified
electrician

The gas supply pressure may
be too low/high.
For appliances working with
bottled LPG, the LPG cylinder
may be depleted.

Ensure that the correct
temperature has been
selected and the door is
properly closed

38

Product support

or online at www.bush-support.co.uk If you still require further assistance, call one of our experts on 01759 487838

Product support

Help is always at hand

Help and assistance

If y

ou require any technical guidance or find that your Freestanding Cooker is not operating as intended, a simple

solution can often be found in the Troubleshooting section of these instructions or online at

www.bush-support.co.uk

If you still require further assistance, call one of our experts on 01759 487838*. To help give us give you a fast and
efficient service please have the following information ready:

Model Ref.

Serial number

Date of purchase

Local call rates applies*

You can find these on
the rating plate - a small
information panel (usually
a sticker or metal plate) on
the rear of your appliance

This will be shown on
your receipt

Lines open 8am-7pm Monday to Saturday and 10am-4pm Sunday.

*Calls to Bush enquiry lines may attract a charge and set up fee from residential lines depending on your call
providers costs may vary, see www.bt.com/pricing for details.

For Security and training purposes, telephone calls to and from customer service centres maybe recorded and monitored. Calls from
Republic of Ireland will attract international call charges.

plan/tariff. Mobile and other

39

Product support

Help is always at hand

Product support

If you require any technical guidance or find that your product is not operating as intended, a simple solution can often be found in the Troubleshooting section of these instructions,

Declaration of conformance to
product standards

This appliance conforms to all relavant standards
applicable to domestic appliances sold in the UK

Disposal

This appliance/tting is marked
according to the European directive
2012/19/EU on Waste Electrical and

Electronic Equipment (WEEE).
By ensuring this product is disposed of
correctly, you will help prevent potential
negative consequences for the environment
and human health, which could otherwise be
caused by inappropriate waste handling of
this product.

The symbol on the product, or on the
documents accompanying the product, the
crossed out wheelie bin symbol, indicates
that this appliance/tting may not be treated
as household waste. Instead it shall be
handed over to the applicable collection point
for the recycling of electrical and electronic
equipment.

Disposal must be carried out in accordance
with local environmental regulations for waste
disposal.

For more detailed information about
treatment, recovery and recycling of this
product, please contact your local authority,
your household waste disposal service or the
retailer where you purchased the product.

40

Product support

or online at www.bush-support.co.uk If you still require further assistance, call one of our experts on 01759 487838

Call us now and activate your 12 month guarantee

Thank you for choosing Bush. Your new product is guaranteed against faults and
breakdowns for 12 months. Don’t forget to register it with us today so we can provide you
with our best possible after-sales service and useful updates.

www.bushregistration.co.uk

FREEPHONE*

0800 597 8548

Lines are open 8am - 8pm, 365 days a year. *Calls may be recorded and monitored.

Your Bush Guarantee

This product is guaranteed for twelve months from the date of original purchase. Any defect that arises due to
faulty materials or workmanship will be repaired free of charge (or if applicable the product will be replaced or the
purchase price refunded) where possible during this period by the dealer from who your purchased the unit.

The guarantee is subject to the following provisions:

• The guarantee does not cover accidental damage,
misuse, cabinet parts, knobs or consumable items.

• The product must be correctly installed and
operated in accordance with the instructions
contained in the manual.

• It must be used solely for domestic purposes. The
guarantee will be rendered invalid if the product is

re-sold or has been damaged by inexpert repair.

• Specifications are subject to change without notice.

• Bush disclaim any liability for loss or damage arising
from the breakdown of the product.

• This guarantee is in addition to and does not
diminish your statutory or legal rights.

Important Data Protection Information

To find out how we and Domestic & General Insurance Plc use your data please refer to the guarantee
registration material or visit www.bushregistrations.co.uk

Guarantor: Argos Limited - 489 - 499 Avebury Blvd. - Milton Keynes - MK9 2NW

41

Contact:

www.bush-support.co.uk

Helpline: 01759 487838
