EFFICIENT & ECONOMICAL
GAS HOME HEATING +
DOMESTIC HOT WATER
MINUTEMAN® II
BURNHAM MINUTEMAN® II GAS-FIRED
BOILER/WATER HEATER
Space Saving
Combo
Burnham's Minuteman® II
boiler/water heater combines
home heating with domestic hot
water in one space-saving unit.
Because of its small footprint, it
can be easily installed in confined
areas or closets. The Minuteman
II boiler is ideal for all heating
applications ranging from single
homes, multi-family units, to
industrial or commercial applications.
Available in three sizes from
70 to 140 MBH input, the annual
fuel utilization efficiencies are as
high as 83%. The Minuteman II
unit can also provide hot water at
up to 3.3 gallons per minute
intermittent draw.
Direct Vent
Burnham's high efficiency
Minuteman II is an innovation in
boiler design.
An important safety consideration, given today's heavily
insulated and tightly constructed
homes, is that all the Minuteman
II combustion air is taken directly
from outside. Installed this way,
the Minuteman II is a sealed unit
so not only the air for combustion,
but also the products of that
combustion are completely sealed
off from the air in your living
space.
Power Vented
The National Fuel Gas Code has
set specific guidelines requiring
properly lined chimneys for
atmospheric gas boilers and water
heaters. Burnham's Minuteman II
unit delivers both capabilities in a
direct vent unit that avoids the
expense of chimney lining.
So, if you don't have a chimney
or if your old chimney isn't up to
the code, you can install the
Minuteman II and vent directly
outside through the wall.
Perfect in Many
Applications
The Minuteman II boiler/water
heater installs almost anywhere,
making it perfect for whatever
your home heating needs might
be.
New home construction...
provides little space for equipment. That's why the Minuteman
II is designed to provide hot water
and heat in a space similar to that
of a standard water heater.
Electric baseboard
conversions...are growing more
popular due to lower gas prices,
high electric heat costs and
greater gas line accessibility. The
Minuteman II can replace the
electric space heating and the
electric hot water heater with just
one system.
Conversions from centralized
heating…to individual heating
units in multifamily housing.
Provides space heating and
domestic hot water in small
footprint for apartment or
condominium applications.
Direct vent replacements...
where chimneys are not up to
code. Burnham's Minuteman II
delivers capabilities in a direct
vent unit that avoids the expense
of chimney lining by venting
through the wall direct to the
outside.
Quality Engineered Cast
Iron Construction
The rugged cast iron construction of the Minuteman II boiler
makes it dependable, efficient,
and virtually trouble-free. The
cast iron heat
exchanger has
a greater
water content
than those
boilers with
copper tube
heat exchangers. This can extend
the life of the boiler, protect it
against adverse operating conditions, and assure quiet operation.
Made in the USA
Unlike some other boiler/water
heater units, the Burnham
Minuteman II and all its major
components are manufactured in
the U.S.A.
All Burnham section castings,
including those of
the Minuteman II
boiler, are made at
our own in-house
foundry. By producing our castings this way,
Burnham ensures quality and
availability.
2
The Economical
Heating Choice
Burnham's Minuteman® II
boiler is efficient by design. At
the heart of every Minuteman II
is a dependable cast iron heat
exchanger that not only
enhances energy efficiency, but
also improves boiler performance. A draft inducing fan
pulls hot gases through the heat
exchanger at just the right speed
for optimum efficiency. Together,
the heat exchanger and fan
provide for more heat with less
fuel and eliminate heat loss
through the vent. No vent damper
is required.
Dimensions (All Sizes)
& Standard Equipment
STANDARD EQUIPMENT
Section assembly
Deluxe insulated jacket
Tank circulator
High limit
Electronic ignition
100% shut-off combination
Step-opening gas valve
Safety relief valve 30 PSI
Induced draft fan
Differential suction pressure
switch
Vent monitor
Boiler water monitor switch
Transformer/relay
Boiler drain valve
Pressure-temperature gauge
Tank aquastat
AL29-4C vent connector
AL29-4C terminal
Combustion air intake terminal
Ease of Service
The Minuteman II unit is
equipped with split controls: an
operating/high limit control, a
transformer, and a circulator relay.
By using "off-the-shelf" separate
controls instead of a combination
control, Burnham has simplified
control replacement and reduced
replacement costs.
3 DIA
VENT
LEFT SIDE VIEW
12
16
ALTERNATE
DOMESTIC
WATER PIPING
ACCESS (K.O.)
(TYP)
7
4 DIA AIR
INTAKE
RELIEFVALVE PIPING
3
5
16
4
3
3
4
10
(TYP)
5
(TYP)
9
AIR
INTAKE
10
FRONT VIEW L/DOOR
GAS PIPING
9
16
The location of the controls
also makes regular servicing
easier because everything is up
front.
Designed for Safety
The Minuteman II boiler/water
heater's sleek blue jacket gives a
clean appliance look to the
installation, plus it's designed with
safety in mind.
All controls are safely hidden
behind the two front panels. The
top panel is only removable by an
adult-sized person. For added
safety, the middle and bottom
panels on the Minuteman II
combination unit are secured with
screws and cannot be removed
without tools.
1
26
8
9
16
21
C
L
VENT
13
3
16
C
L
C
L
4
3
8
PIPING IN HIDDEN
OUTLINE NOT
FURNISHED
BY MANUFACTURER
GAS PIPING
TOP VIEW
13
9
16
15
3
16
RELIEF VALVE
HOUSE HEATING
SUPPLY
CONNECTION
HOUSE HEATING
RETURN
CONNECTION
RIGHT SIDE VIEW
5
16
54
15
16
17
4
3
FEATURES
A. Air Intake Connection
B. Exhaust Connection
C. Control Center
D. Blower Relay
E. Cast Iron Heat Exchanger (Hidden From View)
F. Ignition Module
G. Gas Valve
H. Aquastat
I. Tank Relay
J. Tank Circulator
K. Drain Valve
L. Domestic Water Heater
M.Sealed Combustion Chamber
N. Temperature/Pressure Gauge
O. Blower
P. High Limit
Q. Differential Pressure Switch
Lifetime Limited
Warranty
Every Minuteman cast iron heat
exchanger is covered by
Burnham's lifetime True Blue
Limited Warranty on water and
ten years on steam heat exchangers.
The additional purchase of
Burnham's Winter Warmth
Assurance plan
extends the True
Blue Warranty
protection of the heat
exchanger to 5 or
10-year blanket
coverage. The
program pays 100%
for parts and labor on qualified
repairs for 5 or 10-years from the
date of installation. See your
Burnham Home Heating Team
member for more information.
One Source for Total
Comfort
With over 125 years of proven
dependability and the broadest
product line, Burnham is the one
company you can rely on for your
complete home heating comfort.
Improve upon your new
boiler’s efficiency with
Burnham’s complete line of
system components including:
radiant heat pipe and accessories
from Burnham Radiant Heating
Company, low profile baseboard,
modern radiators, and electronic
controls. Burnham offers all the
components for a complete home
comfort system along with the
industry’s most comprehensive
technical support team. Now is
the time to make Burnham the
one source for your total hydronic
heating system.
4
www.burnham.com
5
SPECIFICATIONS
MINUTEMAN® II RATINGS
RELIOB
REBMUN
)1(
07-4IIMM
501-4IIMM
501-5IIMM
041-5IIMM
1. If LP gas specify on order. Ratings are the same. (MMII5-105 and MMII5-140 not available for LP gas)
2. Ratings shown are for installations at sea level and elevations up to 2,000 ft. For elevations above 2,000 ft. ratings should be
reduced at the rate of four percent (4%) for each 1,000 ft. above sea level.
3. Net I=B=R ratings shown are based on normal I=B=R piping and pick-up allowance of 1.15. Consult the manufacturer for
installations having unusual piping and pick-up requirements such as intermittent system operation, extensive piping systems,
etc.
4. Maximum equivalent length cannot exceed the sum of the length of straight pipe and the equivalent length of any elbow used
(90° and 45° elbows equal 5 equivalent feet).
5. The direct vent Minuteman II is designed to vent directly through the wall using Burnham's approved vent system, 3" AL294C® stainless steel pipe. Inlet air must be supplied from outdoor using 4" 26 gauge galvanized or similar, through the same wall
as the vent.
6. Working Pressure: 30 PSI
TUPNI
HBM
)2(
07
501
501
041
EOD
GNITAEH
YTICAPAC
HBM
85
48
88
211
R=B=I
TEN
RETAW
GNITAR
HBM
)3(
05
37
77
79
CITSEMOD
RETAWTOH
ESIR°001
TNETTIMRETNI
WARD
MPG
9.2
1.3
1.3
3.3
MUMIXAM
TNEV
HTGNEL
.TF.VIUQE
)5()4(
07
07
07
07
MUMIXAM
RIA
TELNI
HTGNEL
.TF.VIUQE
)5()4(
07
07
07
07
%EUFA
3.38
2.08
3.38
1.08
.XORPPA
GNIPPIHS
THGIEW
).SBL(
703
703
543
543
Form No.PL81401041000E-12/00-20Mp
© 2000 Burnham Corporation - Lancaster, PA
Printed in U.S.A.
www.burnham.com
