LCA-2 LP

ILLUSTRATED PARTS CATALOG

Designs, materials, weights, speciﬁcations, and dimensions for equipment or replacement parts

BUNN-O-MATIC CORPORATION

are subject to change without notice.

POST OFFICE BOX 3227

SPRINGFIELD, ILLINOIS 62708-3227

PHONE: (217) 529-6601 FAX: (217) 529-6644

BUNN-O-MATIC COMMERCIAL PRODUCT WARRANTY

Bunn-O-Matic Corp. (“BUNN”) warrants equipment manufactured by it as follows:

1) All equipment other than as speciﬁed below: 2 years parts and 1 year labor.

2) Electronic circuit and/or control boards: parts and labor for 3 years.

3) Compressors on refrigeration equipment: 5 years parts and 1 year labor.

4) Grinding burrs on coffee grinding equipment to grind coffee to meet original factory screen sieve analysis: parts and labor for 3 years or 30,000 pounds of coffee, whichever comes ﬁrst.

These warranty periods run from the date of installation. BUNN warrants that the equipment manufactured by it will be commercially free of defects in material and workmanship existing at the time of manufacture and appearing within the applicable warranty period. This warranty does not apply to any equipment, component or part that was not manufactured by BUNN or that, in BUNN’s judgment, has been affected by misuse, neglect, alteration, improper installation or operation, improper maintenance or repair, damage or casualty. This warranty is conditioned on the Buyer 1) giving BUNN prompt notice of any claim to be made under this warranty by telephone at (217) 529-6601 or by writing to Post Ofﬁce Box 3227, Springﬁeld, Illinois 62708-3227; 2) if requested by BUNN, shipping the defective equipment prepaid to an authorized BUNN service location; and 3) receiving prior authorization from BUNN that the defective equipment is under warranty.

THE FOREGOING WARRANTY IS EXCLUSIVE AND IS IN LIEU OF ANY OTHER WARRANTY, WRITTEN OR ORAL, EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, ANY IMPLIED WARRANTY OF EITHER MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. The agents, dealers or employees of BUNN

are not authorized to make modiﬁcations to this warranty or to make additional warranties that are binding on BUNN. Accordingly, statements by such individuals, whether oral or written, do not constitute warranties and should not be relied upon.

If BUNN determines in its sole discretion that the equipment does not conform to the warranty, BUNN, at its exclusive option while the equipment is under warranty, shall either 1) provide at no charge replacement parts and/or labor (during the applicable parts and labor warranty periods speciﬁed above) to repair the defective components, provided that this repair is done by a BUNN Authorized Service Representative; or 2) shall replace the equipment or refund the purchase price for the equipment.

THE BUYER’S REMEDY AGAINST BUNN FOR THE BREACH OF ANY OBLIGATION ARISING OUT OF THE SALE OF THIS EQUIPMENT, WHETHER DERIVED FROM WARRANTY OR OTHERWISE, SHALL BE LIMITED, AT BUNN’S SOLE OPTION AS SPECIFIED HEREIN, TO REPAIR, REPLACEMENT OR REFUND.

In no event shall BUNN be liable for any other damage or loss, including, but not limited to, lost proﬁts, lost sales, loss of use of equipment, claims of Buyer’s customers, cost of capital, cost of down time, cost of substitute equipment, facilities or services, or any other special, incidental or consequential damages.

BUNN, LCA-2 LP and BUNNLink are either trademarks or registered trademarks of Bunn-O-Matic Corporation.

2

38790 033006

TABLE OF CONTENTS

Cabinet Assembly ...............................................................................................................................................8

Dispense Valve and Mixing Chamber ................................................................................................................16

Door Assembly ...................................................................................................................................................6

Electrical Components ......................................................................................................................................18

Housing, Panels & Drip Tray ...............................................................................................................................4

Numerical Index ................................................................................................................................................20

Pump Assembly ................................................................................................................................................10

Tank Assembly ..................................................................................................................................................14

Water Inlet & Tank Drain ...................................................................................................................................12

3

38790 033006

15

HOUSING, PANELS AND DRIP TRAY

16 17 18

19

LCA-2 LP

20

30

13

12

11

10 3 4

6

5

7 8 19

21

16

2

22

23

1

26

29

28

27

1

24 25

P3418-1

4

38790 033006

HOUSING, PANELS AND DRIP TRAY

ITEM PART NO. QTY. DESCRIPTION

1 38774.1000 1 Housing w/Decals (Includes items 2-5)

2 00824.0000* 1 Decal, Ground Screw

3 00986.0002 1 Decal, Warning - Electrical

4 00656.0000 1 Decal, Comply to Plumbing Code

5 - - - - - - - - 1 Machine Data Plate (Not serviced)

6 36398.0000 1 Plug, BunnLink Access

7 01526.0001 4 Washer

8 26528.0000 4 Leg

9 03996.0000 4 Pad, Non-skid

10 36941.0000 1 Bracket, Lower Tank Mount

01315.0005 2 Screw, Truss Head BLK #8-32 x .38”

11 34118.0001 1 Bracket, Upper Tank Mount

01315.0005 2 Screw, Truss Head BLK #8-32 x .38”

12 38777.0001 1 Panel, Left Side

01315.0005 7 Screw, Truss Head BLK #8-32 x .38”

13 37578.0001 1 Hinge Bracket, Upper

01315.0005 3 Screw, Truss Head BLK #8-32 x .38”

14 37716.0001 1 Hinge Bracket, Lower

01315.0005 3 Screw, Truss Head BLK #8-32 x .38”

15 36945.1000 1 Top Cover w/Decals, Rear (Includes items 16 & 17)

01315.0005 2 Screw, Truss Head BLK #8-32 x .38”

16 37881.0000 2 Decal, No Serviceable Parts

17 25151.0000 1 Shield, Insulator

18 36938.0001 1 Top Cover, Front

01315.0005 4 Screw, Truss Head BLK #8-32 x .38”

19 36944.0000 1 Bracket

01315.0005 1 Screw, Truss Head BLK #8-32 x .38”

20 36939.1001 1 Panel w/Decals, Access (Includes items 16 & 21)

01315.0005 4 Screw, Truss Head BLK #8-32 x .38”

21 37921.0002 1 Electrical Schematic 120V

22 34472.0000 1 Lock Assembly

23 38778.0001 1 Panel, Right Side

01315.0005 10 Screw, Truss Head BLK #8-32 x .38”

24 37709.0000 1 Bracket, Drip Tray Adjustment

25 21436.0000 2 Catch, Magnetic

26 37710.0000 1 Bracket, Drip Tray Mounting

01311.0000 2 Screw, Truss Head #8-32 x .25”

27 37846.1000 1 Drip Tray

28 38185.1000 1 Cover Assy, Drip Tray (Includes item 29)

29 38047.1000 1 Cup Locator Ring

30 29504.0004 1 Screw, Shoulder #8-32 x .38” Lkg

5

* Indicates the part number listed is for reference only. See DESCRIPTION for possible service replacement.

38790 033006
