Buick Regal 1997 V6 3.8L Workshop Manual

buick :: Buick Regal V6-3.8L VIN K (1997)

> Relays and Modules > Relays and Modules - Accessories and Optional Equipment > Accessory Delay Module > Accessory Delay Relay > Component Information > Locations

Behind RH Side Of I/P

> Relays and Modules > Relays and Modules - Accessories and Optional Equipment > Accessory Delay Module > Accessory Delay Relay > Component Information > Locations > Page 8

Accessory Time Delay (RAP) Relay

> Relays and Modules > Relays and Modules - Accessories and Optional Equipment > Alarm Module, (Vehicle Antitheft) > Component Information > Locations

> Relays and Modules > Relays and Modules - Accessories and Optional Equipment > Alarm Module, (Vehicle Antitheft) > Component Information > Locations > Page 12

Alarm Module: Description and Operation
SYSTEM OPERATION (BUICK)

The PASS-Key II Theft Deterrent system prevents vehicle theft by disabling the starter motor and fuel system. If the Body Control Module (BCM)does not identify the use of the correct ignition key to start the vehicle, the BCM will communicate a message to the Powertrain Control Module(PCM) which will disable the starter relay and fuel delivery to the engine.

When the BCM identifies the use of the correct ignition key (resistor pellet) to start the vehicle, the BCM will then send a "fuel enable" and "starterenable" message to the PCM which will allow the vehicle to start.

Important

If the wrong ignition key is used in an attempt to start the vehicle, a Data Trouble Code (DTC) will be set and the Body Control Module (BCM) willnot send a "fuel enable" or "starter enable" message to the Powertrain Control Module (PCM) for three minutes even if the correct ignition key isused.

> Relays and Modules > Relays and Modules - Accessories and Optional Equipment > Alarm Module, (Vehicle Antitheft) > Component Information > Locations > Page 13

Alarm Module: Service and Repair
BODY CONTROL MODULE (BCM)

Remove or Disconnect

1. Battery ground (negative) cable. 2. Left instrument panel insulator. 3. BCM electrical connectors.4. BCM by pushing the BCM up and moving the bottom of the BCM away from and out of the mounting bracket slot.

1. BCM by pushing the top of the BCM up into the mounting bracket. Then, while holding the BCM up, engage the bottom of the BCM into theInstall or Connect

mounting bracket slot.

2. BCM electrical connectors.3. Left instrument panel insulator.4. Battery ground (negative) cable.

> Relays and Modules > Relays and Modules - Accessories and Optional Equipment > Emergency Contact Module > Component Information > Technical Service Bulletins > OnStar(R) - Analog Only Systems Information

Emergency Contact Module: Technical Service BulletinsOnStar(R) - Analog Only Systems Information

INFORMATION
Bulletin No.: 06-08-64-007A
Date: September 22, 2008

Subject: Information on OnStar(R) Analog-Only Systems

Models
Supercede:

This bulletin is being revised to update the models affected list above. Please discard Corporate Bulletin Number 06-08-46-007 (Section 08 - Body &Accessories).

Vehicles with this equipment will no longer be able to receive OnStar(R) services beginning January 1, 2008. At that time, service will be available onlythrough Dual-Mode (Analog / Digital) equipment. Analog-Only vehicles cannot be upgraded to digital equipment.

Disclaimer

All vehicles equipped with OnStar(R) listed in this bulletin were built with Analog-Only OnStar(R) Hardware. OnStar(R) equipped vehicles withanalog-only equipment were designed to operate only on the analog wireless network and cannot be upgraded for digital network compatibility.

> Relays and Modules > Relays and Modules - Accessories and Optional Equipment > Emergency Contact Module > Component Information > Technical Service Bulletins > OnStar(R) - Analog Only Systems Information >

Page 18

Emergency Contact Module: Technical Service BulletinsOnStar(R) - Aftermarket Device Interference Information

INFORMATION
Bulletin No.: 08-08-46-004
Date: August 14, 2008

Subject: Information on Aftermarket Device Interference with OnStar(R) Diagnostic Services

Models:2009 and Prior GM Passenger Car and Truck (including Saturn)2009 and Prior HUMMER H2, H3 Models2009 and Prior Saab 9-7X
with OnStar(R) (RPO UE1)

This bulletin is being issued to provide dealer service personnel with information regarding aftermarket devices connected to the Diagnostic LinkConnector (DLC) and the impact to OnStar(R) diagnostic probes and Vehicle Diagnostic e-mails.

Certain aftermarket devices, when connected to the Diagnostic Link Connector, such as, but not limited to, Scan Tools, Trip Computers, Fuel EconomyAnalyzers and Insurance Tracking Devices, interfere with OnStar's ability to perform a diagnostic probe when requested (via a blue button call) by asubscriber. These devices also prohibit the ability to gather diagnostic and tire pressure data for a subscriber's scheduled OnStar(R) Vehicle Diagnostic(OVD) e-mail.

These aftermarket devices utilize the Vehicles serial data bus to perform data requests and/or information gathering. When these devices are requestingdata, OnStar(R) is designed not to interfere with any data request being made by these devices as required by OBD II regulations.

The OnStar(R) advisor is unable to definitively detect the presence of these devices and will only be able to inform the caller or requester of theunsuccessful or incomplete probe and may in some cases refer the subscriber/requester to take the vehicle to a dealer for diagnosis of the concern.

When performing a diagnostic check for an unsuccessful or incomplete OnStar(R) diagnostic probe, or for concerns regarding completeness of theOnStar(R) Vehicle Diagnostic (OVD) e-mail, verify that an aftermarket device was not present at the time of the requested probe. Regarding the OVDe-mail, if an aftermarket device is interfering (including a Scan Tool of any type), the e-mail will consistently display a "yellow" indication in diagnosticssection for all vehicle systems except the OnStar(R) System and Tire Pressure data (not available on all vehicles) will not be displayed (i.e. section iscollapsed). Successful diagnostic probes and complete OVD e-mails will resume following the removal or disconnecting of the off-board device.

Disclaimer

> Relays and Modules > Relays and Modules - Accessories and Optional Equipment > Emergency Contact Module > Component Information > Technical Service Bulletins > OnStar(R) - Analog Only Systems Information >

Page 19

Emergency Contact Module: Technical Service BulletinsOnStar - Analog-Only Systems Information

Bulletin No.: 06-08-46-007
Date: December 13, 2006
INFORMATION

Subject:Information on OnStar(R) Analog-Only Systems

Models:1996-2001 GM Passenger Cars and Trucks

Plus:2002 Buick LeSabre, Rendezvous2002-2003 Buick Century, Regal2002-2005 Buick Park Avenue2002 Cadillac Eldorado, Escalade Models2002 Chevrolet Avalanche, Silverado, Suburban, Tahoe, Venture2002 GMC Denali, Denali XL, Jimmy, Sierra, Yukon, Yukon XL2002 Oldsmobile Intrigue, Silhouette2002-2003 Oldsmobile Aurora2002 Pontiac Aztek, Bonneville, Montana2002-2003 Pontiac Grand Prix
with OnStar(R) (RPO UE1)

All vehicles equipped with OnStar(R) listed in this bulletin were built with Analog-Only OnStar(R) Hardware. OnStar(R) equipped vehicles withanalog-only equipment were designed to operate only on the analog wireless network and cannot be upgraded for digital network compatibility.

Vehicles with this equipment will no longer be able to receive OnStar(R) services beginning January 1, 2008. At that time, service will be available onlythrough Dual-Mode (Analog/Digital) equipment. Analog-Only vehicles cannot be upgraded to digital equipment.

Disclaimer

> Relays and Modules > Relays and Modules - Accessories and Optional Equipment > Relay Module > Component Information > Technical Service Bulletins > Customer Interest for Relay Module: > 09-06-03-004D

Relay Module: Customer InterestElectrical - MIL ON/DTC's Set By Various Control Modules
TECHNICAL

09-06-03-004DBulletin No.:

December 08, 2010Date:

Subject:

Intermittent No Crank/No Start, No Module Communication, MIL, Warning Lights, Vehicle Messages or DTCs Set by Various ControlModules - Diagnosing and Repairing Fretting Corrosion (Disconnect Affected Connector and Apply Dielectric Lubricant)

Models:

2011 and Prior GM Passenger Cars and Trucks

Attention:

This repair can be applied to ANY electrical connection including, but not limited to: lighting, body electrical, in-line connections, powertrain controlsensors, etc. DO NOT over apply lubricant to the point where it prevents the full engagement of sealed connectors. A light coating on the terminalsurfaces is sufficient to correct the condition.

Supercede:This bulletin is being revised to update the Attention statement and add the 2011 model year. Please discard Corporate Bulletin Number 09-06-03-004C(Section 06 - Engine/Propulsion System).

Condition

Some customers may comment on any of the following conditions:

- An intermittent no crank/no start

- Intermittent malfunction indicator lamp (MIL) illumination

- Intermittent service lamp illumination

- Intermittent service message(s) being displayed

The technician may determine that he is unable to duplicate the intermittent condition.

Cause

- Vibration

- Thermal cycling

- Poor connection/terminal retention

- Micro motion

- A connector, component or wiring harness not properly secured resulting in movement
On low current signal circuits this condition may cause high resistance, resulting in intermittent connections.
On high current power circuits this condition may cause permanent increases in the resistance and may cause a device to become inoperative.

Representative List of Control Modules and Components

> Relays and Modules > Relays and Modules - Accessories and Optional Equipment > Relay Module > Component Information > Technical Service Bulletins > Customer

Interest for Relay Module: > 09-06-03-004D > Page 25

Regal V6-3.8L VIN K (1997)

This condition may be caused by a buildup of nonconductive insulating oxidized debris known as fretting corrosion, occurring between two electricalcontact surfaces of the connection or connector. This may be caused by any of the following conditions:

The following is only a representative list of control modules and components that may be affected by this connection or connector condition and include every possible module or component for every vehicle. DOESNOT

- Blower Control Module

- Body Control Module (BCM)

- Communication Interface Module (CIM)

- Cooling Fan Control Module

- Electronic Brake Control Module (EBCM)

- Electronic Brake and Traction Control Module (EBTCM)

- Electronic Suspension Control (ESC) Module

- Engine Control Module (ECM)

- Heating, Ventilation and Air Conditioning (HVAC) Control Module

- HVAC Actuator

- Inflatable Restraint Sensing and Diagnostic Module (SDM)

- Any AIR BAG module

- Seatbelt Lap Anchor Pretensioner

- Seatbelt Retractor Pretensioner

- An SIR system connection or connector condition resulting in the following DTCs being set: B0015, B0016, B0019, B0020, B0022, or B0023

- Powertrain Control Module (PCM)

- Remote Control Door Lock Receiver (RCDLR)

- Transmission Control Module (TCM)

Correction

replace the control module, wiring or component for the following conditions: ImportantDO NOT

-

be duplicated. The condition is intermittent and cannot

-

be duplicated. The condition is present and by disconnecting and reconnecting the connector the condition can no longer

Use the following procedure to correct the conditions listed above.

1. Install a scan tool and perform the Diagnostic System Check - Vehicle. Retrieve and record any existing history or current DTCs from all of the

control modules (refer to SI).
If any DTC(s) are set, refer to Diagnostic Trouble Code (DTC) List - Vehicle to identify the connector(s) of the control module/component

which may be causing the condition (refer to SI).

If DTCs are not set, refer to Symptoms - Vehicle to identify the connector(s) of the control module/component which may be causing the

condition (refer to SI).

2. When identified, use the appropriate DTC Diagnostics, Symptoms, Schematics, Component Connector End Views and Component Locator

documents to locate and disconnect the affected harness connector(s) which are causing the condition.

ImportantDO NOT

apply an excessive amount of dielectric lubricant to the connectors as shown, as hydrolock may result when attempting to mate theconnectors. Use ONLY a clean nylon brush that is dedicated to the repair of the conditions in this bulletin.

3. With a one-inch nylon bristle brush, apply dielectric lubricant to both the module/component side and the harness side of the affected connector(s).

4. Reconnect the affected connector(s) and wipe away any excess lubricant that may be present. 5. Attempt to duplicate the condition by using the following information:

> Relays and Modules > Relays and Modules - Accessories and Optional Equipment > Relay Module > Component Information > Technical Service Bulletins > Customer

Interest for Relay Module: > 09-06-03-004D > Page 26

Regal V6-3.8L VIN K (1997)

Note

Fretting corrosion looks like little dark smudges on electrical terminals and appear where the actual electrical contact is being made. In less severecases it may be unable to be seen or identified without the use of a magnifying glass.

- DTC Diagnostic Procedure

- Circuit/System Description

- Conditions for Running the DTC

- Conditions for Setting the DTC

- Diagnostic Aids

- Circuit/System Verification

If the condition cannot be duplicated, the repair is complete. If the condition can be duplicated, then follow the appropriate DTC, Symptom or Circuit/System Testing procedure (refer to SI).

Repair Order Documentation

be documented on the repair order. Failure to do so may result in a chargeback.ImportantThe following information MUST

- Customer vehicle condition.

- Was a Service Lamp or Service Message illuminated? If yes, specify which Service Lamp or Service Message.

- Was a DTC(s) set? If yes, specify which DTC(s) were set.

- After following the procedure contained within this bulletin, could the condition be duplicated?

If the condition duplicated, then document the affected module/component connector name and number on the repair order. was not

-

was

If the condition duplicated after the procedure contained within this bulletin was followed, and additional diagnosis led to the replacement ofa module or component, the SI Document ID Number be written on the repair order. MUST

Parts Information

Alternate Distributor For All of North America
Note

NyoGel(R) 760G Lubricant* is equivalent to GMSPO P/N 12377900, and P/N 10953529 (Canada), specified for use to correct the condition in thisbulletin.

*We believe this source and their products to be reliable. There may be additional manufacturers of such products/materials. General Motors does notendorse, indicate any preference for, or assume any responsibility for the products or material from this firm or for any such items that may be availablefrom other sources.

Warranty Information (excluding Saab Models)

For vehicles repaired under warranty, use the appropriate/closest labor operation depending upon the module/component connection that the dielectriclubricant was applied to:

> Relays and Modules > Relays and Modules - Accessories and Optional Equipment > Relay Module > Component Information > Technical Service Bulletins > Customer

Interest for Relay Module: > 09-06-03-004D > Page 27

Regal V6-3.8L VIN K (1997)

Warranty Information (Saab Models)

For vehicles repaired under warranty, use the appropriate/closest labor operation depending upon the module/component connection that the dielectriclubricant was applied to refer to the table above.

Disclaimer

> Relays and Modules > Relays and Modules - Accessories and Optional Equipment > Relay Module > Component Information > Technical Service Bulletins > All Technical Service Bulletins for Relay Module: > 09-06-03-

004D

Relay Module: All Technical Service BulletinsElectrical - MIL ON/DTC's Set By Various Control Modules
TECHNICAL

09-06-03-004DBulletin No.:

December 08, 2010Date:

Subject:

Intermittent No Crank/No Start, No Module Communication, MIL, Warning Lights, Vehicle Messages or DTCs Set by Various ControlModules - Diagnosing and Repairing Fretting Corrosion (Disconnect Affected Connector and Apply Dielectric Lubricant)

Models:

2011 and Prior GM Passenger Cars and Trucks

Attention:

This repair can be applied to ANY electrical connection including, but not limited to: lighting, body electrical, in-line connections, powertrain controlsensors, etc. DO NOT over apply lubricant to the point where it prevents the full engagement of sealed connectors. A light coating on the terminalsurfaces is sufficient to correct the condition.

Supercede:This bulletin is being revised to update the Attention statement and add the 2011 model year. Please discard Corporate Bulletin Number 09-06-03-004C(Section 06 - Engine/Propulsion System).

Condition

Some customers may comment on any of the following conditions:

- An intermittent no crank/no start

- Intermittent malfunction indicator lamp (MIL) illumination

- Intermittent service lamp illumination

- Intermittent service message(s) being displayed
The technician may determine that he is unable to duplicate the intermittent condition.

Cause

- Vibration

- Thermal cycling

- Poor connection/terminal retention

- Micro motion

- A connector, component or wiring harness not properly secured resulting in movement
On low current signal circuits this condition may cause high resistance, resulting in intermittent connections.
On high current power circuits this condition may cause permanent increases in the resistance and may cause a device to become inoperative.

Representative List of Control Modules and Components

> Relays and Modules > Relays and Modules - Accessories and Optional Equipment > Relay Module > Component Information > Technical Service Bulletins > All Technical

Service Bulletins for Relay Module: > 09-06-03-004D > Page 30

Regal V6-3.8L VIN K (1997)

This condition may be caused by a buildup of nonconductive insulating oxidized debris known as fretting corrosion, occurring between two electricalcontact surfaces of the connection or connector. This may be caused by any of the following conditions:

The following is only a representative list of control modules and components that may be affected by this connection or connector condition and include every possible module or component for every vehicle. DOESNOT

- Blower Control Module

- Body Control Module (BCM)

- Communication Interface Module (CIM)

- Cooling Fan Control Module

- Electronic Brake Control Module (EBCM)

- Electronic Brake and Traction Control Module (EBTCM)

- Electronic Suspension Control (ESC) Module

- Engine Control Module (ECM)

- Heating, Ventilation and Air Conditioning (HVAC) Control Module

- HVAC Actuator

- Inflatable Restraint Sensing and Diagnostic Module (SDM)

- Any AIR BAG module

- Seatbelt Lap Anchor Pretensioner

- Seatbelt Retractor Pretensioner

- An SIR system connection or connector condition resulting in the following DTCs being set: B0015, B0016, B0019, B0020, B0022, or B0023

- Powertrain Control Module (PCM)

- Remote Control Door Lock Receiver (RCDLR)

- Transmission Control Module (TCM)

Correction

replace the control module, wiring or component for the following conditions: ImportantDO NOT

-

be duplicated. The condition is intermittent and cannot

-

be duplicated. The condition is present and by disconnecting and reconnecting the connector the condition can no longer

Use the following procedure to correct the conditions listed above.

1. Install a scan tool and perform the Diagnostic System Check - Vehicle. Retrieve and record any existing history or current DTCs from all of the

control modules (refer to SI).
If any DTC(s) are set, refer to Diagnostic Trouble Code (DTC) List - Vehicle to identify the connector(s) of the control module/component

which may be causing the condition (refer to SI).

If DTCs are not set, refer to Symptoms - Vehicle to identify the connector(s) of the control module/component which may be causing the

condition (refer to SI).

2. When identified, use the appropriate DTC Diagnostics, Symptoms, Schematics, Component Connector End Views and Component Locator

documents to locate and disconnect the affected harness connector(s) which are causing the condition.

ImportantDO NOT

apply an excessive amount of dielectric lubricant to the connectors as shown, as hydrolock may result when attempting to mate theconnectors. Use ONLY a clean nylon brush that is dedicated to the repair of the conditions in this bulletin.

3. With a one-inch nylon bristle brush, apply dielectric lubricant to both the module/component side and the harness side of the affected connector(s).

4. Reconnect the affected connector(s) and wipe away any excess lubricant that may be present. 5. Attempt to duplicate the condition by using the following information:

> Relays and Modules > Relays and Modules - Accessories and Optional Equipment > Relay Module > Component Information > Technical Service Bulletins > All Technical

Service Bulletins for Relay Module: > 09-06-03-004D > Page 31

Regal V6-3.8L VIN K (1997)

Note

Fretting corrosion looks like little dark smudges on electrical terminals and appear where the actual electrical contact is being made. In less severecases it may be unable to be seen or identified without the use of a magnifying glass.

- DTC Diagnostic Procedure

- Circuit/System Description

- Conditions for Running the DTC

- Conditions for Setting the DTC

- Diagnostic Aids

- Circuit/System Verification

If the condition cannot be duplicated, the repair is complete. If the condition can be duplicated, then follow the appropriate DTC, Symptom or Circuit/System Testing procedure (refer to SI).

Repair Order Documentation

be documented on the repair order. Failure to do so may result in a chargeback.ImportantThe following information MUST

- Customer vehicle condition.

- Was a Service Lamp or Service Message illuminated? If yes, specify which Service Lamp or Service Message.

- Was a DTC(s) set? If yes, specify which DTC(s) were set.

- After following the procedure contained within this bulletin, could the condition be duplicated?

If the condition duplicated, then document the affected module/component connector name and number on the repair order. was not

-

was

If the condition duplicated after the procedure contained within this bulletin was followed, and additional diagnosis led to the replacement ofa module or component, the SI Document ID Number be written on the repair order. MUST

Parts Information

Alternate Distributor For All of North America
Note

NyoGel(R) 760G Lubricant* is equivalent to GMSPO P/N 12377900, and P/N 10953529 (Canada), specified for use to correct the condition in thisbulletin.

*We believe this source and their products to be reliable. There may be additional manufacturers of such products/materials. General Motors does notendorse, indicate any preference for, or assume any responsibility for the products or material from this firm or for any such items that may be availablefrom other sources.

Warranty Information (excluding Saab Models)

For vehicles repaired under warranty, use the appropriate/closest labor operation depending upon the module/component connection that the dielectriclubricant was applied to:

> Relays and Modules > Relays and Modules - Accessories and Optional Equipment > Relay Module > Component Information > Technical Service Bulletins > All Technical

Service Bulletins for Relay Module: > 09-06-03-004D > Page 32

Regal V6-3.8L VIN K (1997)

Warranty Information (Saab Models)

For vehicles repaired under warranty, use the appropriate/closest labor operation depending upon the module/component connection that the dielectriclubricant was applied to refer to the table above.

Disclaimer

> Relays and Modules > Relays and Modules - Body and Frame > Power Door Lock Relay > Component Information > Locations

Behind RH Side Of I/P

> Relays and Modules > Relays and Modules - Body and Frame > Power Door Lock Relay > Component Information > Locations > Page 37

Door Lock Relay

> Relays and Modules > Relays and Modules - Body and Frame > Seat Heater Control Module > Component Information > Locations > Driver Seat Heater Control Module

Seat Heater Control Module: LocationsDriver Seat Heater Control Module

Below RH side of driver seat, mounted on seat track

> Relays and Modules > Relays and Modules - Body and Frame > Seat Heater Control Module > Component Information > Locations > Driver Seat Heater Control Module > Page 42

Seat Heater Control Module: LocationsPassenger Seat Heater Control Module

Below RH side of passenger's seat, mounted on seat track

> Relays and Modules > Relays and Modules - Body and Frame > Seat Heater Control Module > Component Information > Locations > Page 43

Passenger Seat Heater Control Module

> Relays and Modules > Relays and Modules - Body and Frame > Sunroof / Moonroof Module > Component Information > Locations

> Relays and Modules > Relays and Modules - Body and Frame > Sunroof / Moonroof Module > Component Information > Locations > Page 47

Sunroof / Moonroof Module: Service and Repair

Sunroof Module

Remove

> Relays and Modules > Relays and Modules - Body and Frame > Sunroof / Moonroof Module > Component Information > Locations > Page 48

Regal V6-3.8L VIN K (1997)

1. Position sunroof in the fully closed position.2. Headliner.3. Electrical connectors from actuator and express module.4. Front drain hoses from sunroof housing.5. Rear drain hoses from sunroof housing.6. Four sunroof module bracket to side rail bolts.7. Six sunroof module to roof bolts.8. One sunroof module at actuator bracket bolt.9. Sunroof module from vehicle through door opening.

Install

1. Sunroof module to vehicle through door opening.2. One sunroof module at actuator bracket bolt.

Tighten bolts to .Tighten 10 N.m (89 lb. in.)

3. Six sunroof module to roof bolts.

Tighten bolts to .Tighten 10 N.m (89 lb. in.)

4. Four sunroof module bracket to side rail bolts.

Tighten bolts to .Tighten 10 N.m (89 lb. in.)

5. Rear drain hoses from sunroof housing.6. Front drain hoses from sunroof housing.7. Electrical connectors to actuator and express module.8. Headliner9. Open and close sunroof to recheck operation.

10. Adjust sunroof as necessary.

> Relays and Modules > Relays and Modules - Body and Frame > Trunk / Liftgate Relay > Component Information > Locations

Behind RH Side Of I/P

> Relays and Modules > Relays and Modules - Body and Frame > Trunk / Liftgate Relay > Component Information > Locations > Page 52

Rear Compartment Lid Release Relay

> Relays and Modules > Relays and Modules - Brakes and Traction Control > ABS Main Relay > Component Information > Locations

Below LH Side Of Steering Column

> Relays and Modules > Relays and Modules - Brakes and Traction Control > ABS Main Relay > Component Information > Locations > Page 57

Electronic Brake Control Relay

> Relays and Modules > Relays and Modules - Brakes and Traction Control > ABS Main Relay > Component Information > Service and Repair > Electronic Brake Control Relay

ABS Main Relay: Service and RepairElectronic Brake Control Relay

Electronic Brake Control Relay

REMOVE OR DISCONNECT

1. Electronic brake control relay from connector.2. Electronic brake control relay fastener.

INSTALL OR CONNECT

1. Electronic brake control relay fastener.2. Electronic brake control relay connector.

> Relays and Modules > Relays and Modules - Brakes and Traction Control > ABS Main Relay > Component Information > Service and Repair > Electronic Brake Control Relay > Page 60

ABS Main Relay: Service and RepairElectrical Connectors

ABS VI Electrical Connectors (Typical)

(ABS/ETS)

Some Antilock Brake System/Enhanced Traction System components are equipped with electrical connectors using a Connector PositionAssurance lock. This feature ensures that when the connectors are installed, they are aligned properly and connected securely.(CPA)

Remove the lock before separating the electrical connectors.
^ Take care not to damage the locking pin during removal.
^ Make sure that the rubber connector seal is in place on the connector before and after connection.
^ Always install the lock after the connection is made.

^Important:

> Relays and Modules > Relays and Modules - Brakes and Traction Control > Electronic Brake Control Module > Component Information > Technical Service Bulletins > Customer Interest for Electronic Brake Control Module:

> Steering/Suspension - Various Noises/Vibration > Steering/Suspension - Various Noises/Vibration

Electronic Brake Control Module: Customer InterestSteering/Suspension - Various Noises/Vibration

BULLETIN NUMBER:00-03-06-001

SECTION:03 - Suspension

DATE:April, 2000

SUBJECT:Correction of Various Front End Noises

MODELS:1997-99 Buick Century/Regal1998-99 Oldsmobile Intrigue1997-99 Pontiac Grand Prix

This bulletin is intended to provide information to help identify and correct various front end noises in 1997-1999 Buick, Pontiac, and Oldsmobilemidsize vehicles. Though many components are shared between these vehicles, specific noise related customer concerns may be present in only a selectgroup of vehicles. This bulletin provides specific information regarding the make and model affected with any known cut off points (VIN # or Date). It isnot intended to contain all possible sources of front end noise, but will identify some of the harder to diagnose items.
The subjects of this bulletin include the following:

- WHINE/WHISTLE or TONE at 32 km/h (20 mph) with slight steering input (Magnasteer (R) only).

- A CLUNK that can be produced when the vehicle's engine is running, but not when it is off.

- A CLUNK that can be produced, both when the engine is running and when it is off.

- A CLUNK/RATTLE/POP heard during low speed maneuvers or while driving down the road.

- A CHIRPING or SQUEAKING sound from the front suspension when hitting sharp bumps.

- SNAPS, POPS and CREAKS from the front struts.

- A VIBRATION or ROUGHNESS in the steering.

CORRECTION

The following sections give information on the source and correction of various noises that may be found in midsize vehicles. Please see the applicableService Manual for the repair procedure in each case.

- Whine/Whistle/Tone at 32 km/h (20 mph) w/Slight Steering Input

- A Clunk Produced When the Engine Is Running, NOT When It's Off

- A Clunk Produced When the Engine Is Running and When It's Off

- A Clunk/Rattle/Pop Heard While Driving or Low Speed Maneuvers

> Relays and Modules > Relays and Modules - Brakes and Traction Control > Electronic Brake Control Module > Component Information > Technical Service Bulletins >

Customer Interest for Electronic Brake Control Module: > Steering/Suspension - Various Noises/Vibration > Steering/Suspension - Various Noises/Vibration > Page 67

Regal V6-3.8L VIN K (1997)

- A Chirping/Squeaking Sound From Front Suspension Hitting Bumps

- Snaps, Pops, and Creaks From the Front Struts

- A Vibration or Roughness In the Steering

WARRANTY INFORMATION
For vehicles repaired under warranty.

Disclaimer

> Relays and Modules > Relays and Modules - Brakes and Traction Control > Electronic Brake Control Module > Component Information > Technical Service Bulletins > Customer Interest for Electronic Brake Control Module:

> Steering/Suspension - Various Noises/Vibration > Steering/Suspension - Various Noises/Vibration > Page 68

Electronic Brake Control Module: Customer InterestWhine/Whistle/Tone at 32 km/h (20 mph) w/Slight Steering Input

WHINE/WHISTLE, OR TONE AT 32 KM/H (20 MPH) WITH SLIGHT STEERING INPUT (MAGNASTEER (R) ONLY) - (1998 BUICK REGALGS, 1998 OLDSMOBILE INTRIGUE)

A whine or whistle may be heard in the passenger compartment of the vehicle. The tone may resemble a test tone and is most noticeable at 32 km/h (20mph) with slight steering inputs. The noise originates in the Magnasteer (R) Variable Assist Steering Gear.

Important:

For the Buick Regal, this condition applies only to a two month production of the GS model. During that time, the Oldsmobile Intrigueintermediate shaft was substituted for the Buick part. Check the concerned vehicle for a multi-splined intermediate shaft in place of the standardDOUBLE-D style shaft. Replace the splined shaft as instructed under "A Clunk that can be produced, both when the engine is running and when it is off"in this bulletin. Replace the shaft regardless of it's date code.

-

To diagnose this condition, disconnect the Magnasteer (R) Variable Assist (MSVA) harness (at the MSVA pigtail) from the steering gear and testdrive the vehicle again. If the noise has disappeared, then the MSVA system is the source.

-

To correct this condition, replace the Electronic Brake and Traction Control Module with a revised module (P/N 9353511). Refer to the LaborTime Guide for applicable operation number and time allowance.

> Relays and Modules > Relays and Modules - Brakes and Traction Control > Electronic Brake Control Module > Component Information > Technical Service Bulletins > Customer Interest for Electronic Brake Control Module:

> Steering/Suspension - Various Noises/Vibration > Steering/Suspension - Various Noises/Vibration > Page 69

Electronic Brake Control Module: Customer InterestA Clunk Produced When the Engine Is Running, NOT When It's Off

A CLUNK THAT CAN BE PRODUCED WHEN THE VEHICLE'S ENGINE IS RUNNING BUT NOT WHEN IT'S OFF (1998 BUICK REGAL GS,1998 OLDSMOBILE INTRIGUE)

This type of noise is likely to be a steering gear condition; specifically too much clearance between the seal on the power piston and the groove that theseal rides in. This excessive clearance lets the piston seal knock inside the groove during turns.

-

With the vehicle stationary and the engine running, turn the steering wheel rapidly back and forth over it's center position. Complete a cycle ofboth directions about once a second. The wheel must be turned this quickly in order to bring about the noise. Next, repeat this rapid turning overcenter with the engine off.

-

If the clunk was present with the engine on, but not when turned off, the rack may be the source. Verify the date of vehicle manufacture. Thiscondition was corrected in production by February 1,1998. If the vehicle is older then this date and has not had a steering rack replacement,replace the rack. If the vehicle is newer than February 1,1998 refer to the applicable Service Manual and follow the normal diagnostic proceduresbefore changing the rack.

> Relays and Modules > Relays and Modules - Brakes and Traction Control > Electronic Brake Control Module > Component Information > Technical Service Bulletins > Customer Interest for Electronic Brake Control Module:

> Steering/Suspension - Various Noises/Vibration > Steering/Suspension - Various Noises/Vibration > Page 70

Electronic Brake Control Module: Customer InterestA Clunk Produced When the Engine Is Running and When It's Off

A CLUNK THAT CAN BE PRODUCED BOTH WHEN THE ENGINE IS RUNNING AND WHEN IT'S OFF (1998 BUICK REGAL, 1998OLDSMOBILE INTRIGUE)

Important:

The above condition applies only to a two month production run of the 1998 Buick Regal. During this period, the splined intermediateshafts were installed in place of the standard DOUBLE-D style shaft. These vehicles were all equipped with the early version of the splined shaft whichis prone to the clunk noise. If a Buick Regal with this condition is encountered, replace the shaft with the DOUBLE-D style that is designated in the GMParts Manual as original equipment.

This type of clunk is likely to be caused by the intermediate shaft. This clunk may be caused by too much clearance between the splined inner and outerparts of the slider joint. The additional clearance allows them to knock against each other during turns.

- The correction is to replace the intermediate shaft with one built since the middle of October, 1998.

-

Check the shaft's date code to assure that it is a good shaft. The code can be recognized by the fact that it's laser-etched, rather than stamped on theend of the shaft. The shaft must have been built on or later than the 280th day of 1998 (example: "252A8"). In this example, the "282" representsthe 282nd day and the final "8" represents 1998.

> Relays and Modules > Relays and Modules - Brakes and Traction Control > Electronic Brake Control Module > Component Information > Technical Service Bulletins > Customer Interest for Electronic Brake Control Module:

> Steering/Suspension - Various Noises/Vibration > Steering/Suspension - Various Noises/Vibration > Page 71

Electronic Brake Control Module: Customer InterestA Clunk/Rattle/Pop Heard While Driving or Low Speed Maneuvers

A CLUNK/RATTLE/POP HEARD DURING LOW SPEED MANEUVERS OR WHILE DRIVING DOWN THE ROAD (1998 OLDSMOBILEINTRIGUE)

This noise in it's various forms is likely to be caused by either under-torqued bolts in the front strut mounts or by an older intermediate shaft. Thefollowing is how to distinguish between the two possible causes:

- Begin diagnosis by verifying the torque of the front strut mounting bolts which may have been under-torqued during assembly.

TIGHTENTighten the front strut mounting bolts to 33 Nm (24 lb ft).

-

If the clunk"rattle remains once the mounting bolts are correctly torqued, the cause may be a second condition with the intermediate shaft. Beforeit can be heard, this condition can be felt as a sharp knocking or tapping feel in the steering wheel. Eventually it will become an audible rattle ortapping. This noise is most obvious at low speed. The rattle or tapping is heard when driving over a series of small bumps, but may change to aclunk or pop with light brake application or acceleration.

- This condition may be caused by an insufficient distribution of lubricant between the mating splines of the slider shaft.

-

The correction is to replace the intermediate shaft with one built since the middle of October, 1998. Check the shaft's date code to assure it is agood shaft. The code can be recognized by the fact that it is laser-etched, rather than stamped on the end of the shaft. The shaft must have beenbuilt on or later than the 280th day of 1995 (example: "282A8"). In this example, the "282" represents the 282nd day and the final "8" represents1998.

Important:

Do not remove the intermediate shaft to examine or perform any operation that will "stroke" the shaft. This movement of the slider joint,past normal in-car positioning, will redistribute the grease on the shaft and temporarily eliminate the condition. The only way to permanently repair thevehicle is to replace the shaft if it is identified as one of the early shafts prone to this condition.

> Relays and Modules > Relays and Modules - Brakes and Traction Control > Electronic Brake Control Module > Component Information > Technical Service Bulletins > Customer Interest for Electronic Brake Control Module:

> Steering/Suspension - Various Noises/Vibration > Steering/Suspension - Various Noises/Vibration > Page 72

Electronic Brake Control Module: Customer InterestA Chirping/Squeaking Sound From Front Suspension Hitting Bumps

A CHIRPING OR SQUEAKING SOUND FROM THE FRONT SUSPENSION WHEN HITTING SHARP BUMPS (1998 OLDSMOBILEINTRIGUE, 1999 PONTIAC GRAND PRIX)
A chirping or squeaking sound may be heard from the front suspension when hitting a sharp bump such as a deep pothole or a speed bump.

-

This condition may be caused by an internal misbuild of the strut. The base valve and deflection disc may allow improper fluid flow (internal tothe strut). The unwanted flow between these two components creates the chirping noise.

- This condition was corrected on all Oldsmobile Intrigues beginning with VIN # XF341675 or vehicles built after January 1, 1999.

- This condition was corrected on the Pontiac Grand Prix after VIN # XF265000.

-

The only correction for this noise is replacement of the strut. Struts can be checked by locating the Julian Date stamped into the strut housingapproximately 1/3rd of the way up from the bottom of the strut and facing inward when installed. Beginning with the third digit, any date afterXX8355 (8=1998 355=day) can be considered good.

> Relays and Modules > Relays and Modules - Brakes and Traction Control > Electronic Brake Control Module > Component Information > Technical Service Bulletins > Customer Interest for Electronic Brake Control Module:

> Steering/Suspension - Various Noises/Vibration > Steering/Suspension - Various Noises/Vibration > Page 73

Electronic Brake Control Module: Customer InterestSnaps, Pops, and Creaks From the Front Struts

SNAPS, POPS, AND CREAKS FROM THE FRONT STRUTS (OLDSMOBILE INTRIGUE, PONTIAC GRAND PRIX)
Snaps or pops from the front struts during low speed turns and braking may be the result of two possible conditions:

-

If the Intrigue in question was built in 1997, the cause of this condition may be due to a strut. Refer to Service Bulletin Number 73-33-O4 foradditional information.

-

The other possible cause is that the jounce bumper inside the top of the dust boot is rubbing on the bump plate or cap. To correct this condition,raise the vehicle and with the wheel hanging, raise each front dust boot. Rub wheel bearing grease or other heavy grease onto the bump plate. If theplate comes off the strut housing when the dust boot is lifted, press it back into place firmly before greasing. This repair is so quick, this optionmay be explored whenever there is a concern about steering or front end noise.

> Relays and Modules > Relays and Modules - Brakes and Traction Control > Electronic Brake Control Module > Component Information > Technical Service Bulletins > Customer Interest for Electronic Brake Control Module:

> Steering/Suspension - Various Noises/Vibration > Steering/Suspension - Various Noises/Vibration > Page 74

Electronic Brake Control Module: Customer InterestA Vibration or Roughness In the Steering

A VIBRATION OR ROUGHNESS IN THE STEERING (BUICK CENTURY/REGAL, OLDSMOBILE INTRIGUE AND PONTIAC GRAND PRIX)

This is a feeling of roughness or lumpiness in the steering. This is a subtle condition that may not be obvious like steering shudder. This condition istypically felt during lane changes at highway speed on smooth pavement. It is never felt when the steering wheel is turned and the vehicle is stationary.

-

This condition is called "tire flutter" because it originates with the tires. it tends to worsen with increased miles on the vehicle and tires. Theseverity of this condition will vary with different types of tires. Any time this type of concern is encountered, test drive the vehicle against anotherIntrigue.

-

If the condition is significantly greater in the customer's car, rotate the tires front to rear. This does not always correct the condition, but it is theonly known correction for this type of concern.

> Relays and Modules > Relays and Modules - Brakes and Traction Control > Electronic Brake Control Module > Component Information > Technical Service Bulletins > Customer Interest for Electronic Brake Control Module:

> 00-03-06-001 > Apr > 00 > Steering/Suspension - Various Noises/Vibration > Steering/Suspension - Various Noises/Vibration

Electronic Brake Control Module: Customer InterestSteering/Suspension - Various Noises/Vibration

BULLETIN NUMBER:00-03-06-001

SECTION:03 - Suspension

DATE:April, 2000

SUBJECT:Correction of Various Front End Noises

MODELS:1997-99 Buick Century/Regal1998-99 Oldsmobile Intrigue1997-99 Pontiac Grand Prix

This bulletin is intended to provide information to help identify and correct various front end noises in 1997-1999 Buick, Pontiac, and Oldsmobilemidsize vehicles. Though many components are shared between these vehicles, specific noise related customer concerns may be present in only a selectgroup of vehicles. This bulletin provides specific information regarding the make and model affected with any known cut off points (VIN # or Date). It isnot intended to contain all possible sources of front end noise, but will identify some of the harder to diagnose items.
The subjects of this bulletin include the following:

- WHINE/WHISTLE or TONE at 32 km/h (20 mph) with slight steering input (Magnasteer (R) only).

- A CLUNK that can be produced when the vehicle's engine is running, but not when it is off.

- A CLUNK that can be produced, both when the engine is running and when it is off.

- A CLUNK/RATTLE/POP heard during low speed maneuvers or while driving down the road.

- A CHIRPING or SQUEAKING sound from the front suspension when hitting sharp bumps.

- SNAPS, POPS and CREAKS from the front struts.

- A VIBRATION or ROUGHNESS in the steering.

CORRECTION

The following sections give information on the source and correction of various noises that may be found in midsize vehicles. Please see the applicableService Manual for the repair procedure in each case.

- Whine/Whistle/Tone at 32 km/h (20 mph) w/Slight Steering Input

- A Clunk Produced When the Engine Is Running, NOT When It's Off

- A Clunk Produced When the Engine Is Running and When It's Off

- A Clunk/Rattle/Pop Heard While Driving or Low Speed Maneuvers

> Relays and Modules > Relays and Modules - Brakes and Traction Control > Electronic Brake Control Module > Component Information > Technical Service Bulletins >

Customer Interest for Electronic Brake Control Module: > 00-03-06-001 > Apr > 00 > Steering/Suspension - Various Noises/Vibration > Steering/Suspension - Various Noises

/Vibration > Page 80

Regal V6-3.8L VIN K (1997)

- A Chirping/Squeaking Sound From Front Suspension Hitting Bumps

- Snaps, Pops, and Creaks From the Front Struts

- A Vibration or Roughness In the Steering

WARRANTY INFORMATION
For vehicles repaired under warranty.

Disclaimer

> Relays and Modules > Relays and Modules - Brakes and Traction Control > Electronic Brake Control Module > Component Information > Technical Service Bulletins > Customer Interest for Electronic Brake Control Module:

> 00-03-06-001> Apr> 00> Steering/Suspension - Various Noises/Vibration > Steering/Suspension - Various Noises/Vibration > Page 81

Electronic Brake Control Module: Customer InterestWhine/Whistle/Tone at 32 km/h (20 mph) w/Slight Steering Input

WHINE/WHISTLE, OR TONE AT 32 KM/H (20 MPH) WITH SLIGHT STEERING INPUT (MAGNASTEER (R) ONLY) - (1998 BUICK REGALGS, 1998 OLDSMOBILE INTRIGUE)

A whine or whistle may be heard in the passenger compartment of the vehicle. The tone may resemble a test tone and is most noticeable at 32 km/h (20mph) with slight steering inputs. The noise originates in the Magnasteer (R) Variable Assist Steering Gear.

Important:

For the Buick Regal, this condition applies only to a two month production of the GS model. During that time, the Oldsmobile Intrigueintermediate shaft was substituted for the Buick part. Check the concerned vehicle for a multi-splined intermediate shaft in place of the standardDOUBLE-D style shaft. Replace the splined shaft as instructed under "A Clunk that can be produced, both when the engine is running and when it is off"in this bulletin. Replace the shaft regardless of it's date code.

-

To diagnose this condition, disconnect the Magnasteer (R) Variable Assist (MSVA) harness (at the MSVA pigtail) from the steering gear and testdrive the vehicle again. If the noise has disappeared, then the MSVA system is the source.

-

To correct this condition, replace the Electronic Brake and Traction Control Module with a revised module (P/N 9353511). Refer to the LaborTime Guide for applicable operation number and time allowance.

> Relays and Modules > Relays and Modules - Brakes and Traction Control > Electronic Brake Control Module > Component Information > Technical Service Bulletins > Customer Interest for Electronic Brake Control Module:

> 00-03-06-001> Apr > 00 > Steering/Suspension - Various Noises/Vibration > Steering/Suspension - Various Noises/Vibration > Page 82

Electronic Brake Control Module: Customer InterestA Clunk Produced When the Engine Is Running, NOT When It's Off

A CLUNK THAT CAN BE PRODUCED WHEN THE VEHICLE'S ENGINE IS RUNNING BUT NOT WHEN IT'S OFF (1998 BUICK REGAL GS,1998 OLDSMOBILE INTRIGUE)

This type of noise is likely to be a steering gear condition; specifically too much clearance between the seal on the power piston and the groove that theseal rides in. This excessive clearance lets the piston seal knock inside the groove during turns.

-

With the vehicle stationary and the engine running, turn the steering wheel rapidly back and forth over it's center position. Complete a cycle ofboth directions about once a second. The wheel must be turned this quickly in order to bring about the noise. Next, repeat this rapid turning overcenter with the engine off.

-

If the clunk was present with the engine on, but not when turned off, the rack may be the source. Verify the date of vehicle manufacture. Thiscondition was corrected in production by February 1,1998. If the vehicle is older then this date and has not had a steering rack replacement,replace the rack. If the vehicle is newer than February 1,1998 refer to the applicable Service Manual and follow the normal diagnostic proceduresbefore changing the rack.

> Relays and Modules > Relays and Modules - Brakes and Traction Control > Electronic Brake Control Module > Component Information > Technical Service Bulletins > Customer Interest for Electronic Brake Control Module:

> 00-03-06-001> Apr > 00 > Steering/Suspension - Various Noises/Vibration > Steering/Suspension - Various Noises/Vibration > Page 83

Electronic Brake Control Module: Customer InterestA Clunk Produced When the Engine Is Running and When It's Off

A CLUNK THAT CAN BE PRODUCED BOTH WHEN THE ENGINE IS RUNNING AND WHEN IT'S OFF (1998 BUICK REGAL, 1998OLDSMOBILE INTRIGUE)

Important:

The above condition applies only to a two month production run of the 1998 Buick Regal. During this period, the splined intermediateshafts were installed in place of the standard DOUBLE-D style shaft. These vehicles were all equipped with the early version of the splined shaft whichis prone to the clunk noise. If a Buick Regal with this condition is encountered, replace the shaft with the DOUBLE-D style that is designated in the GMParts Manual as original equipment.

This type of clunk is likely to be caused by the intermediate shaft. This clunk may be caused by too much clearance between the splined inner and outerparts of the slider joint. The additional clearance allows them to knock against each other during turns.

- The correction is to replace the intermediate shaft with one built since the middle of October, 1998.

-

Check the shaft's date code to assure that it is a good shaft. The code can be recognized by the fact that it's laser-etched, rather than stamped on theend of the shaft. The shaft must have been built on or later than the 280th day of 1998 (example: "252A8"). In this example, the "282" representsthe 282nd day and the final "8" represents 1998.

> Relays and Modules > Relays and Modules - Brakes and Traction Control > Electronic Brake Control Module > Component Information > Technical Service Bulletins > Customer Interest for Electronic Brake Control Module:

> 00-03-06-001> Apr > 00 > Steering/Suspension - Various Noises/Vibration > Steering/Suspension - Various Noises/Vibration > Page 84

Electronic Brake Control Module: Customer InterestA Clunk/Rattle/Pop Heard While Driving or Low Speed Maneuvers

A CLUNK/RATTLE/POP HEARD DURING LOW SPEED MANEUVERS OR WHILE DRIVING DOWN THE ROAD (1998 OLDSMOBILEINTRIGUE)

This noise in it's various forms is likely to be caused by either under-torqued bolts in the front strut mounts or by an older intermediate shaft. Thefollowing is how to distinguish between the two possible causes:

- Begin diagnosis by verifying the torque of the front strut mounting bolts which may have been under-torqued during assembly.

TIGHTENTighten the front strut mounting bolts to 33 Nm (24 lb ft).

-

If the clunk"rattle remains once the mounting bolts are correctly torqued, the cause may be a second condition with the intermediate shaft. Beforeit can be heard, this condition can be felt as a sharp knocking or tapping feel in the steering wheel. Eventually it will become an audible rattle ortapping. This noise is most obvious at low speed. The rattle or tapping is heard when driving over a series of small bumps, but may change to aclunk or pop with light brake application or acceleration.

- This condition may be caused by an insufficient distribution of lubricant between the mating splines of the slider shaft.

-

The correction is to replace the intermediate shaft with one built since the middle of October, 1998. Check the shaft's date code to assure it is agood shaft. The code can be recognized by the fact that it is laser-etched, rather than stamped on the end of the shaft. The shaft must have beenbuilt on or later than the 280th day of 1995 (example: "282A8"). In this example, the "282" represents the 282nd day and the final "8" represents1998.

Important:

Do not remove the intermediate shaft to examine or perform any operation that will "stroke" the shaft. This movement of the slider joint,past normal in-car positioning, will redistribute the grease on the shaft and temporarily eliminate the condition. The only way to permanently repair thevehicle is to replace the shaft if it is identified as one of the early shafts prone to this condition.

> Relays and Modules > Relays and Modules - Brakes and Traction Control > Electronic Brake Control Module > Component Information > Technical Service Bulletins > Customer Interest for Electronic Brake Control Module:

> 00-03-06-001> Apr > 00 > Steering/Suspension - Various Noises/Vibration > Steering/Suspension - Various Noises/Vibration > Page 85

Electronic Brake Control Module: Customer InterestA Chirping/Squeaking Sound From Front Suspension Hitting Bumps

A CHIRPING OR SQUEAKING SOUND FROM THE FRONT SUSPENSION WHEN HITTING SHARP BUMPS (1998 OLDSMOBILEINTRIGUE, 1999 PONTIAC GRAND PRIX)
A chirping or squeaking sound may be heard from the front suspension when hitting a sharp bump such as a deep pothole or a speed bump.

-

This condition may be caused by an internal misbuild of the strut. The base valve and deflection disc may allow improper fluid flow (internal tothe strut). The unwanted flow between these two components creates the chirping noise.

- This condition was corrected on all Oldsmobile Intrigues beginning with VIN # XF341675 or vehicles built after January 1, 1999.

- This condition was corrected on the Pontiac Grand Prix after VIN # XF265000.

-

The only correction for this noise is replacement of the strut. Struts can be checked by locating the Julian Date stamped into the strut housingapproximately 1/3rd of the way up from the bottom of the strut and facing inward when installed. Beginning with the third digit, any date afterXX8355 (8=1998 355=day) can be considered good.

> Relays and Modules > Relays and Modules - Brakes and Traction Control > Electronic Brake Control Module > Component Information > Technical Service Bulletins > Customer Interest for Electronic Brake Control Module:

> 00-03-06-001> Apr > 00 > Steering/Suspension - Various Noises/Vibration > Steering/Suspension - Various Noises/Vibration > Page 86

Electronic Brake Control Module: Customer InterestSnaps, Pops, and Creaks From the Front Struts

SNAPS, POPS, AND CREAKS FROM THE FRONT STRUTS (OLDSMOBILE INTRIGUE, PONTIAC GRAND PRIX)
Snaps or pops from the front struts during low speed turns and braking may be the result of two possible conditions:

-

If the Intrigue in question was built in 1997, the cause of this condition may be due to a strut. Refer to Service Bulletin Number 73-33-O4 foradditional information.

-

The other possible cause is that the jounce bumper inside the top of the dust boot is rubbing on the bump plate or cap. To correct this condition,raise the vehicle and with the wheel hanging, raise each front dust boot. Rub wheel bearing grease or other heavy grease onto the bump plate. If theplate comes off the strut housing when the dust boot is lifted, press it back into place firmly before greasing. This repair is so quick, this optionmay be explored whenever there is a concern about steering or front end noise.

> Relays and Modules > Relays and Modules - Brakes and Traction Control > Electronic Brake Control Module > Component Information > Technical Service Bulletins > Customer Interest for Electronic Brake Control Module:

> 00-03-06-001> Apr > 00 > Steering/Suspension - Various Noises/Vibration > Steering/Suspension - Various Noises/Vibration > Page 87

Electronic Brake Control Module: Customer InterestA Vibration or Roughness In the Steering

A VIBRATION OR ROUGHNESS IN THE STEERING (BUICK CENTURY/REGAL, OLDSMOBILE INTRIGUE AND PONTIAC GRAND PRIX)

This is a feeling of roughness or lumpiness in the steering. This is a subtle condition that may not be obvious like steering shudder. This condition istypically felt during lane changes at highway speed on smooth pavement. It is never felt when the steering wheel is turned and the vehicle is stationary.

-

This condition is called "tire flutter" because it originates with the tires. it tends to worsen with increased miles on the vehicle and tires. Theseverity of this condition will vary with different types of tires. Any time this type of concern is encountered, test drive the vehicle against anotherIntrigue.

-

If the condition is significantly greater in the customer's car, rotate the tires front to rear. This does not always correct the condition, but it is theonly known correction for this type of concern.

> Relays and Modules > Relays and Modules - Brakes and Traction Control > Electronic Brake Control Module > Component Information > Technical Service Bulletins > Customer Interest for Electronic Brake Control Module:

> 00-03-06-001 > Apr > Steering/Suspension - Various Noises/Vibration > Steering/Suspension - Various Noises/Vibration

Electronic Brake Control Module: Customer InterestSteering/Suspension - Various Noises/Vibration

BULLETIN NUMBER:00-03-06-001

SECTION:03 - Suspension

DATE:April, 2000

SUBJECT:Correction of Various Front End Noises

MODELS:1997-99 Buick Century/Regal1998-99 Oldsmobile Intrigue1997-99 Pontiac Grand Prix

This bulletin is intended to provide information to help identify and correct various front end noises in 1997-1999 Buick, Pontiac, and Oldsmobilemidsize vehicles. Though many components are shared between these vehicles, specific noise related customer concerns may be present in only a selectgroup of vehicles. This bulletin provides specific information regarding the make and model affected with any known cut off points (VIN # or Date). It isnot intended to contain all possible sources of front end noise, but will identify some of the harder to diagnose items.
The subjects of this bulletin include the following:

- WHINE/WHISTLE or TONE at 32 km/h (20 mph) with slight steering input (Magnasteer (R) only).

- A CLUNK that can be produced when the vehicle's engine is running, but not when it is off.

- A CLUNK that can be produced, both when the engine is running and when it is off.

- A CLUNK/RATTLE/POP heard during low speed maneuvers or while driving down the road.

- A CHIRPING or SQUEAKING sound from the front suspension when hitting sharp bumps.

- SNAPS, POPS and CREAKS from the front struts.

- A VIBRATION or ROUGHNESS in the steering.

CORRECTION

The following sections give information on the source and correction of various noises that may be found in midsize vehicles. Please see the applicableService Manual for the repair procedure in each case.

- Whine/Whistle/Tone at 32 km/h (20 mph) w/Slight Steering Input

- A Clunk Produced When the Engine Is Running, NOT When It's Off

- A Clunk Produced When the Engine Is Running and When It's Off

- A Clunk/Rattle/Pop Heard While Driving or Low Speed Maneuvers

> Relays and Modules > Relays and Modules - Brakes and Traction Control > Electronic Brake Control Module > Component Information > Technical Service Bulletins >

Customer Interest for Electronic Brake Control Module: > 00-03-06-001 > Apr > Steering/Suspension - Various Noises/Vibration > Steering/Suspension - Various Noises/

Vibration > Page 90

Regal V6-3.8L VIN K (1997)

- A Chirping/Squeaking Sound From Front Suspension Hitting Bumps

- Snaps, Pops, and Creaks From the Front Struts

- A Vibration or Roughness In the Steering

WARRANTY INFORMATION
For vehicles repaired under warranty.

Disclaimer
