BT Freestyle 1025 User Manual

Combined Cordless Telephone & Digital Answering Machine
User Guide
This equipment is not designed for making emergency telephone calls when the power fails. Alternative arrangements should be made for access to emergency services.
Freestyle 1025
Key features
Digital answer machine
Control of the answer machine through the handset
You can use the handset to operate all the functions of the answer machine, including message playback and recording a new outgoing message.
Additional handsets
Up to 3 additional handsets can be added to your Freestyle 1025.
10-number Quickdial memory
Store up to 10 of your most frequently dialled or most important numbers in the memory and dial them by pressing just 2 buttons.
Call screening through the handset
When the answer machine is switched on, you can use the handset to listen to the caller leaving a message.
Either cut in to take the call in person or let your Freestyle 1025 continue recording the message.
3 ringer melodies
You can use your handset to hear and choose between three different ringer melodies for your Freestyle 1025.
200-metre range*
Your Freestyle 1025 gives you extra freedom around the home with a handset range of up to 200 metres from the base.
*In ideal conditions.
8-channel auto-frequency (31-39Mhz)
8 channels and a new frequency range of signals between the handset and base greatly reduce the chance of any interference from another phone.
Please open this page for an ‘at a glance’ guide to your Freestyle 1025.
Please open this page for a ‘further at a glance’ guide to your Freestyle 1025.
At a glance
Talk
Press to get a dialling tone or
answer a call when the handset is
off the base, and to end a call.
See page 8
Volume
Adjusts the handset ringer volume
and earpiece speech volume.
See page 11
Recall is for use with some BT
Select Services and when connected
to a switchboard.
See page 12
Quickdial
Allows you to store and dial up to 10
numbers in the memory.
See page 9
1471
Press to hear the date, time and
number (if available), of your last
caller.
See page 12
Secrecy
When pressed, it stops the caller
hearing you.
See page 9
Battery-charging contacts
Place the handset face down on the
base to charge the batteries.
Aerial
Does not extend.
See page 5
In Use / Battery Low
Comes on when the handset is in use or, if the handset is on standby, to indicate the battery needs recharging.
See page 6
R
Volume
1
2
S
k
i
p
G
H
I
4
5
Q
P
R
S
8
7
Channel
P
l
a
y
D
A
E
B
F
C
3
D
S
e
k
i
l
p
e
K
J
L
t
e
M
N
O
6
U
T
X
W
V
Y
Z
9
0
Quickdial
Secrecy Screen
R
1471
Redial
n
e
M
u
Channel
Press to change the channel if there is interference on your call. Your Freestyle 1025 will automatically seek the clearest channel.
See page 9
Keypad
Redial
Redials the last number called.
See page 8
Also used to insert a pause when dialling a number or storing a number in the Quickdial memory.
See page 13
Screen/Menu
Allows you to access the answer machine menu.
See page 21
Also allows you to hear a caller leaving a message through your handset. You can then choose to take the call or not.
See page 23
1
Volume
Page
Vol u me
8
Skip
Skip
Answer on off
Play
Pause
Delete
Charging
Messages
In use
Stop
Freestyle 1025
Adjusts the loudspeaker volume.
See page 17
Page
Press to page the handset.
See page 13
Skip
Lets you skip backward and forward through your memos and messages.
See page 18
Base unit aerial
Extend fully for best reception.
See page 7
Delete
Deletes recorded messages and memos.
See pages 18/19
Also allows you to adjust the answer
delay settings see page 19, and to
turn the message alert on and off,
see page 20.
Answer On/Off
Switches the answering machine
on and off.
Battery-charging contacts
See page 15
Stop
To adjust the base station ringer volume.
See page 11
Stop messages being played.
See page 16
LEDs
CHARGING – comes on when the
handset battery is being charged.
IN USE
– comes on when the line
is in use.
Play/Pause
Lets you play – and pause playback – of your messages.
See page 18
In this guide
At a glance 1 Introduction 4 Setting up 5 Using your Freestyle 1025
telephone 8
Making and receiving calls 8 Using the Quickdial to store and
dial numbers 9 Call return (1471) 12 Call waiting 12
Using your Freestyle 1025 answering machine 14
Message display on the base station 14 Setting up your answer machine 15 Incoming messages 17 Using your answering machine from
the base station 18 Answer delay 19 Message alert 20 Using your answering machine from
the cordless handset 20 Security code 23 Call screening 23 Memos 24
Freestyle 90/130/1025/1200 Additional handsets 27
Registering your handset 27 Basic use of additional Freestyle
handsets 29 Transferring calls between handsets 29
Help 30 Technical information 34 Maintenance 36 Wall mounting 38 Wall-mounting template 39 Index 40
Remote access 25
Control your answering machine from another phone using a TouchTone keypad 25
Operating the answering machine 26
TM
3
Introduction
R
Q u
i c k
d i a
l
S e c
r e c
y
S c r
e e n
1 4
7 1
R e
d ia
l
V o l
u m
e
C h
a n n
e l
1
2
3
4
5
6
7
8
9
0
W
X
Y
Z
T
U
V
P
Q
R
S
G
H
I
J
K
L
M
N
O
D
E
F
A
B
C
D
e
l
e
t
e
P
l
a
y
S
k
i
p
S
k
i
p
M
e
n
u
Volume
8
Skip
Skip
Answer on off
Play
Pause
Delete
Charging
Messages
In use
Stop
Freestyle 1025
Your Freestyle 1025 is designed for ease of use and made to the high standards set by BT
Thank you for making the right choice. You can expect your Freestyle 1025 to provide many years of quality service. Please read the instructions carefully before use and keep this user guide for future reference.
For your records
Date of purchase:
Place of purchase:
Serial number:
(on the underside of the base unit)
Purchase price:
For warranty purposes, proof of purchase is required, so please keep your receipt.
Emergency calls
The emergency services can be contacted in the UK by dialling
999 or 112.
Unpacking your Freestyle 1025
Check that your Freestyle 1025 is complete. When you unpack you should have:
• Freestyle 1025 handset including rechargeable battery
• Freestyle 1025 base unit with answering machine
• Mains power lead with attached 13 amp adaptor plug
• Wall-mounting bracket, 2 screws and wall plugs for wall mounting
As the Freestyle 1025 is a mains-powered cordless telephone, in certain situations you may not be able to make an emergency call:
• If there is severe radio interference.
If you have problems with your phone, call the
Freestyle 1025 Helpline Service on 0845 769 7146.
Customer Helpline
• If the handset batteries fail.
• If there is a power cut.
4
Setting up
Follow these steps to get your Freestyle 1025 ready for use
1 Handset aerial
Your Freestyle 1025 uses a compact aerial which does not pull out.
2 Check your telephone socket
Plug the mains adaptor cord into the
3
back of the base unit
To prevent the cable being pulled out by accident, route it through the channel on the underside of the base.
12V AC
PHONE LINE
Electrical storm warning
During periods of electrical storm, you are
advised to disconnect your apparatus because
damage may occur.
SETTING UP
If you do not have a modern-style telephone socket, call Freefone 0800 800 150 and ask for a BT engineer to come and fit the correct socket.
This is a chargeable service.
If a fault occurs during the 12-month warranty
period and it is due to accidental or wilful damage
(including lightning and electrical damage),
BT will not replace or repair free of charge.
5
Plug the 3 pin adaptor into the
4
mains power socket and switch on
The
CHARGING light remains on until the
handset is removed from the base unit.
SETTING UP
Your Freestyle 1025 begins the set-up procedure which takes a few seconds. – The message counter flashes. – The pre-set outgoing message is ready to use. – The answer delay is set to 6 rings. – The answering machine is switched to ON. – The loudspeaker volume is set to level 5
(from a range of 0-H).
– The machine announces the answer delay
setting: “Calls will be answered after 6 rings”.
Mains power adaptor
The Freestyle 1025 must only be used with the
adaptor supplied.
Using any other adaptor will invalidate the approval
given to this apparatus.
Charge the handset battery for at
5
least 24 hours
When you first use your Freestyle 1025, the rechargeable batteries in the handset need charging for 24 hours.
When fully charged and in good condition,
the handset batteries will provide up to 7 hours
continuous talk time or 72 hours standby.
If the batteries are running low, the
BATT LOW
In Use
If you are making a call and the batteries
are running low, the handset will beep every
10-15 seconds and you have about 2 minutes
before the call is cut off.
Place the handset on the base unit to recharge.
light will flash.
Battery
Low
Battery Care
Batteries cannot be overcharged. However, leaving
the handset on the base unit all the time can deteriorate rechargeable batteries. To get the longest possible life from your batteries, take the handset off
the base for a few hours each day.
Place the handset on the base unit face down, ensuring the contacts are touching.
The
CHARGING light on the base unit comes ON.
After the handset has been charged for 24 hours, your phone is ready for use.
As a rule, placing the handset on the base unit overnight will keep the batteries fully charged for all normal use.
6
Plug your Freestyle 1025 into the
6
phone socket
Fully extend the telescopic aerial
7
on the base unit
For the best reception
Try to avoid putting the telescopic aerial near other
electrical appliances, fluorescent lights and large metallic objects such as cookers, radiators and garage doors as these may cause interference and reduce the
quality of your calls.
To plan the location of the
8
base unit
Your Freestyle 1025 works by sending and receiving radio signals between the base unit and the handset.
The strength of the signal depends on where you site the base unit and how the aerial is deployed.
The higher the base unit is located, the better. An upstairs room is ideal. The following points should be considered:
• It should be within easy reach of a mains socket and a telephone socket. A new-style telephone socket is needed for this product. If you do not have one, call us on Freefone 0800 800 150.
• Tr y to avoid locations near metallic obstructions or electrical appliances, such as TV sets, fridges, computers, fluorescent lights, radiators, metal pipes and metal window frames.
• The Freestyle 1025 can be wall-mounted by using the bracket and screws supplied; see pages 38-39.
Your Freestyle 1025 is now ready for use
SETTING UP
7
Using your Freestyle1025 telephone
USING YOUR PHONE
Making and receiving calls
The handset range is up to 200 metres from the base unit in ideal conditions. If you start to go out of range while using the phone, you will hear warning beeps. If you do not come back in range, your call will be cut off.
To make a call
Press buttons in order shown
Lift the handset off the base.
Press the
IN USE light comes on. The base unit
light comes on. Listen for dial tone.
Dial the number.
To end a call
TALK button. The handset
To receive a call
When the phone rings:
If your handset is on the base unit, simply pick it up to answer the call.
Or
If your handset is off the base, press the
TALK button to answer the call.
To redial the last number
You can redial a number of up to 32 digits long.
Redial
Press the dialling tone.
Press the number you called is redialled.
TALK button. You hear the
REDIAL button. The last
Press the TALK button.
Or
Replace the handset on the base.
8
To ensure the best sound quality
Channel
0 9
Quickdial
Using the Quickdial to store and dial numbers
Your Freestyle 1025 automatically scans available radio channels between the handset and base for the best quality signal. However, if you hear noise or interference during your call:
Press the
CHANNEL button.
Your Freestyle 1025 will select a new channel for you.
If you go out of range
Your Freestyle 1025 has a range of 200 metres in ideal conditions.
However, if you go out of range during a call, you will hear a series of beeps, Move closer to the base to re-establish the signal.
Using the Secrecy button
You can prevent your caller from hearing you while you talk to someone else close by.
Secrecy
Press and release the The
IN USE light flashes and you will
hear an audible tone every 8 seconds.
To return to your caller, press and release the
SECRECY button.
SECRECY button.
Your Freestyle 1025 handset can store up to 10 separate phone numbers, each up to 20 digits long. You can then dial each number by pressing just 2 buttons.
To store a number in the memory
Press the QUICKDIAL button. You hear a beep and the handset will flash.
Press one of the
0-9 buttons to set the
location code under which your phone number will be stored.
DIAL Dial the number you want to store.
Quickdial
Press the
QUICKDIAL button. You hear
a confirmation beep. The number is stored.
Repeat these steps for any other numbers you want to store, using a
0 9
different
0-9 location code for each one.
Storing a number in the memory automatically overwrites any previous number stored under the same location code.
Stored numbers can include those for switchboard and network services that use the
and #buttons as well as
the PAUSE and RECALL functions.
IN USE light
USING YOUR PHONE
9
To dial a stored number
0 9
Quickdial
Quickdial
0 9
Quickdial
Quickdial
Press buttons in order shown
Press the
Press the
Press the
TALK button.
QUICKDIAL button.
0-9 location code under
which the number you want is stored. The number is dialled automatically.
To store an engaged number in the memory
On the back of your handset is a label for you to record the names of the contacts stored under the quickdial memory buttons.
e
s
t
d
N
n
a
o
H
.
1 2 3 4 5 6 7 8 9 0
No
USING YOUR PHONE
If you ring a number that was engaged you can put it in the Quickdial memory.
Press
QUICKDIAL you hear a beep.
0 9
Redial
Quickdial
Store memory location
Press
REDIAL.
Press
QUICKDIAL.
0-9.
The number is now stored in the memory.
Did you know?
You can mix manual and memory dialling as
required. For example, you can dial the area code
0181 380 from the memory and then complete the
number manually.
To store a number of more than 20 digits
Quickdial
0 9
DIAL Dial the first 20 digits.
DIAL Dial the remaining digits.
Quickdial
Press the QUICKDIAL button.
Press one of the
0-9 buttons to set the
location code under which your phone number will be stored.
Press the
QUICKDIAL button. You hear
a confirmation beep. The number is stored.
Press the
Press a different
QUICKDIAL button again.
0-9 button to select a
second location code under which to store the remaining digits.
Press the
QUICKDIAL button. You hear
a confirmation beep. The rest of the number is stored.
10
To dial a stored number of more
Volume
Volume
Quickdial
Quickdial
Vol um e
Quickdial
Quickdial
Volume
than 20 digits
To adjust the handset ringer melody
Press the TALK button.
0 9
Press the first number begins dialling automatically.
QUICKDIAL button, then the
0-9 location code number. The
When the first part of the number has
0 9
been dialled, press the button again, then the second 0-9
QUICKDIAL
location code number. The rest of the number is dialled.
To adjust the incoming speech volume
During a conversation you can adjust the volume of the incoming caller.
Press the
VOLUME button to increase
or decrease the speech volume.
To adjust the handset ringer volume
Press and release the QUICKDIAL button.
1 3
Press and release the
Press either the select the melody required – you will
VOLUME button.
1, 2 or 3 button to
hear the melody selected when pressed.
Press the
QUICKDIAL button to confirm
the setting. You will hear a confirmation beep.
NOTE
The
VOLUME
3 seconds or the Freestyle 1025 will return to standby.
To adjust the base station ringer volume
Your Freestyle 1025 has a volume range of
button must be pressed within
0-H (0 = Off, H = High).
USING YOUR PHONE
When the handset is not in use you can adjust the ringer volume.
Press the
VOLUME button to increase
or decrease the handset ringer volume. The Freestyle 1025 has 3 settings: High, Low and Off.
To set the volume to Off, press and hold the
VOLUME button until you hear
a confirmation beep.
Stop
Vol um e
Press the
STOP button for 1 second.
You hear a confirmation beep. Display shows current level.
Press
VOL
Press
VOL – to decrease the volume.
to increase the volume.
+
As you press, a beep sounds at the level you are selecting.
11
Call return (1471
1471
)
This service lets you easily find who called your number last.
To use the 1471 feature
If an incoming call arrives while you are already engaged on a telephone call, you will hear a soft beep every 5 seconds (this beep is not audible to the person you are speaking to).
Instead of the engaged tone, the second caller will hear an announcement to hold on as you are aware that there is a second call.
USING YOUR PHONE
Press the
TALK button and wait for a
dialling tone.
Press the
1471 button. You hear the
number of your last caller announced and the time they called. If a call is made and the caller withholds their number, the time of the call is still stored but not the number.
Press the
TALK button again – or replace
the handset on the base – to return to standby.
NOTE
To withhold your own number.
Dial 141 before you dial the number you want.
You will need to do this even if you are ex-directory.
Call Waiting
NOTE
Call Waiting service requires set-up by BT or
your service provider and connection to a digital
exchange.
To use Call Waiting
You can answer the second call, without disconnecting your first caller, by
R
pressing the will be put on hold.
When you have spoken to the second caller you can return to the first caller
R
by pressing the switch back and forth between the 2 calls without disconnecting either if you wish.
If you wish to disconnect the first call, press the the first caller.
The handset will then ring. Press the
TALK button again and continue with
the second caller.
The second caller will only be charged for their call from the moment you answer and not while they are waiting for your initial contact.
R button. The first caller
R button again. You can
TALK button after speaking to
12
Redial
R
To switch from pulse to tone dialling
Page
Quickdial
To insert a pause
If you are connected to a pulse dialling exchange, you can still use services such as phone banking that require tone dialling.
KEYPAD
Call the telephone number you require in pulse mode as usual.
When you have been connected, press the
button on the keypad to set
your telephone to tone dialling for the duration of the call.
When you hang up, your Freestyle 1025 will automatically switch back to pulse dialling.
To page the handset
If you misplace the handset, you can use
PAGE to find it again.
Page
Press the The handset will beep. The on the base flashes.
Stop the handset beeping by pressing the
or
the note: pressing the off the line, you will then need to put the handset back onto the base unit.)
PAGE button on the base.
PAGE button again
TALK button on the handset. (Please
IN USE light
TALK button will cut
With some switchboards, after dialling the access code you may have to wait for a moment while the switchboard picks up an outside line. If so, press the
REDIAL button to insert a 2.5 second
pause before keying in the telephone number.
To use the recall button
This button signals either time break recall or earth recall depending on the setting of the dialling mode. If you are connected to a PBX (Private Branch Exchange), contact your PBX supplier for further information.
To set the dialling mode
Press the QUICKDIAL button during standby mode.
1
P
l
a
y
A
B
C
2
Quickdial
Press the
Press
1 for Tone dialling.
Press
2 for Pulse dialling.
Press the the setting (you will hear a confirmation tone). If no instruction is received during this process within 8 seconds, there will be a beep and the process will be cancelled before returning to standby mode.
button.
QUICKDIAL button to finish
USING YOUR PHONE
13
Using the Freestyle1025 answering machine
ANSWERING MACHINE
About your Freestyle 1025 answering machine
Your Freestyle 1025 can digitally record up to 14 minutes of messages, with each incoming message lasting a maximum of 3 minutes.
Your Freestyle 1025 answering machine can operate from the base unit and also directly from your handset. When you set up your answering machine, some of the features, such as recording your outgoing message, must be set up via the handset.
The outgoing message is the message a caller first hears when the answer machine picks up their call. The Freestyle 1025 has a pre-recorded outgoing message which is “Hello, your call
cannot be taken at the moment, so please leave your message after the tone”. If you wish, you can
record your own outgoing message to replace the pre-recorded message (see page 15).
Message display on the base station
Messages
Delete
8
In use
The message display on your base station lets you know the status of your Freestyle 1025 answering machine.
Display Definition
(Blank) Power off.
Power on – answer off mode.
0-9 Answer-on mode, 0-59 messages.
P (flashing) Message paused.
r (flashing)
Message recording (memo, outgoing message or incoming message).
Charging
14
A (flashing) Remote access in progress.
F (flashing) Memory full.
t or 2 to 9 Setting or reading answer delay.
E (flashing) Error.
8-0 Counting down.
C
-0 (flashing) Day/Time needs to be set.
Setting up your answer machine
Answer on off
Screen
M
e
n
u
9
W
X
Y
Z
To switch the answering machine on/off
Your Freestyle 1025 has a recording capacity of 14 minutes. Any outgoing message you record can be up to 30 seconds long.
Pick up the handset.
Press the Answer on/off button.
If you hear ‘Answer off ’ the answering machine is switched off. Display flashes between a dash and the number of messages saved in the memory, or display shows a single dash if there are no messages.
Press again to hear“Answer on”. Your Freestyle 1025 will now answer an incoming call and record any messages. Display shows the number of messages held in the recording memory.
To record your outgoing message via the handset
The Freestyle 1025 has a pre-recorded outgoing message which is “Hello, your
call cannot be taken at the moment, so please leave your message after the tone”.
Press the
Press the
SCREEN/MENU button.
9 button. The machine
announces: “Please speak after the tone, to end recording press
Once the
button has been pressed,
#
”.
#
your outgoing message will be played back.
To check your outgoing message
You can play back your outgoing message at any time.
Pick up the handset.
n
e
u
M
Screen
Press the
U
T
V
Press the
8
message is played back.
SCREEN/MENU button.
8 button. Your outgoing
ANSWERING MACHINE
You can record your own outgoing message to replace the pre-recorded message. If you record your own message, the pre-recorded message is automatically removed and stored in the memory, in case you wish to reinstate it.
15
To delete your outgoing message
8
T
U
V
Screen
M
e
n
u
5
J
K
L
D
e
l
e
t
e
Stop
To set the day and time
ANSWERING MACHINE
You can delete your outgoing message and return to your Freestyle 1025’s pre-recorded outgoing message.
Press the
Press the
SCREEN/MENU button.
8 button.
“Your outgoing message is…”
While the message is playing, press the
5 button.
Your Freestyle 1025 will beep and play its pre-recorded outgoing message.
“Hello, your call cannot be taken at the moment, so please leave your message after the tone.”
Your own message has now been replaced by the Freestyle 1025’s original pre-recorded message.
You can stop any function at any time and return to the last ‘Answer On’ or ‘Answer Off’ setting by pressing the
STOP button on the base unit.
NOTE
Press the SCREEN/MENU button at any time to
return to Standby mode.
n
e
u
M
Screen
KEYPAD
NOTE
You only have 8 seconds to set up your
Day and Time otherwise the Freestyle 1025
will return to the standby mode.
Your Freestyle 1025 automatically adds the day and time to all messages and memos.
When you switch on your Freestyle 1025 for the first time, the clock is set to Saturday 12:01. You can change the day and time as required. The display will show C until the clock has been set.
To set the day and time for each incoming message left on the Freestyle 1025 answer machine:
Press the
Press the announces “To set day and time press
To hear the day and time, press
Press the announces “Please enter new day and time after the tone”.
Enter the day, followed by time (using the 24 hour clock).
1 = Sun, 2 = Mon, 3 = Tues, 4 = Wed, 5 = Thur, 6 = Fri, 7 = Sat.
For example:
1 1415 = Sunday 2.15pm
or
5 0915 = Thursday 9.15am
SCREEN/MENU button.
button. The machine
button. The machine
”.
.
#
16
To adjust the loudspeaker volume
Vol um e
Your Freestyle 1025 has a volume range of 0-H. The pre-set level is 5.
3 minutes is the maximum time allowed for each incoming message. If the maximum message length is reached – or if the memory becomes full – the caller hears the message “Thank you for calling” and your Freestyle 1025 hangs up.
Press
VOL + to increase the volume.
When you reach the maximum volume, the LED display shows H.
Vol um e
Press
VOL – to decrease the volume.
When you reach the minimum volume, the LED display shows 0.
If you adjust the volume when the answering machine is not being used, a beep sounds at the level you are selecting. When the volume is at its highest or lowest setting, you hear 2 beeps.
Incoming messages
Your Freestyle 1025 will automatically record an incoming message when it is connected to your phone socket and is set to ‘Answer on’.
While a message is being recorded, the display flashes r. It will stop recording if the caller stops speaking for longer than 7 seconds.
When a message has been received, the LED display counts up by one.
Your Freestyle 1025 will also hang up if you press the
STOP button.
If there is less than 40 seconds of recording memory left, the caller will hear the announcement “Please complete your call within 10 seconds” after the outgoing message is played.
Your Freestyle 1025 can hold a maximum of 59 incoming messages or up to a total of 14 minutes of recording.
When more than 9 messages are stored on the answering machine the LED display shows 9 flashing.
When the recording memory is full, the display alternates between the number of messages and F.
If the answering machine is switched on, and the memory is full, incoming callers will hear the pre-set message “Hello, your call cannot be taken
at the moment and you cannot leave a message, so please call later”. If the caller is still on the line after 8 seconds, they hear the message “Thank your for calling” and your Freestyle 1025 hangs up.
ANSWERING MACHINE
Your Freestyle 1025 automatically adds the day and time of recording to the end of each message.
NOTE
If a call comes in while you are playing back a
message or memo, the playback stops and the machine
is ready to take the call.
17
Using your answering machine
Play
Pause
Skip
Skip
from the base station
To skip forward and backward through messages at the base
During playback:
ANSWERING MACHINE
To play back a message at the base
You can play back your messages at the answering machine:
Press the
PLAY button.
You hear the announcement “You have (n) messages” and your messages are
played back, starting with the first message received.
At the start of each message, the number of the message is announced. At the end, you hear the day and time of recording.
Press the STOP button at any time during playback
to stop messages playing.
To pause a message at the base
Play
Pause
While listening to the message, press the
PLAY button. Your Freestyle 1025
will beep every 10 seconds during pause.
Press the
SKIP button and the next
message is played. If you press and hold this button the current message will be played back at 1
1
/2 times the speed.
Press once to return to the start of the current message. Press twice to return to the start of the previous message.
To delete an individual message at the base
During playback:
Delete
Press the
To delete the message being played. You hear the announcement “Message deleted”.
The message is not deleted yet, but at the end of playback when there is an 8-second countdown. Let the countdown reach 0 and all the selected messages are deleted and the remaining messages are saved.
DELETE button.
18
Display shows P.
Play
Pause
Press the
PLAY button again to resume
playback.
If playback is not resumed within 60 seconds, the
machine automatically resets to ‘Answer on/off ’ mode.
To delete all messages at the base
Stop
Skip
Skip
To check the answer delay setting at the base station
When all messages have been played back you hear the announcement “End of messages” and the LED display counts down from 8-0.
Delete
During the 8-0 countdown press
DELETE.
At the end of the countdown you hear the confirmation announcement “All messages deleted”.
To cancel deletion from the base
Cancel deletion by pressing the STOP button during the 8-0 countdown. All messages will be saved including any marked for deletion.
Answer delay
Answer delay sets the number of times your Freestyle 1025 will ring before answering a call. The original setting is for your machine to answer after 6 rings. You can change this setting between 2-9 rings or Time Saver.
Press buttons in order shown
Press the
SKIP > button.
Your Freestyle 1025 will announce the current setting. “Calls will be answered after 6 rings”.
To change the answer delay setting
Skip
Press and hold the SKIP > button until the current setting is announced “6”. Keep holding the
SKIP > button and
your Freestyle 1025 will announce the answer delay options: 7, 8, 9 “Time
Saver, 2, 3, 4, 5”.
When you hear the setting you want, release the
SKIP > button. Your
Freestyle 1025 will then announce the new setting e.g. “Answer delay, Time saver” and return to ‘Answer on/off ’ mode.
ANSWERING MACHINE
NOTE
If you set your 1025 Answer Delay to Time Saver
this means that when you call in from another phone
(remote access), if any messages have been recorded
your Freestyle 1025 will answer after only 2 rings.
If there are no messages, it will answer after 6 rings,
thereby allowing you the option of hanging up before
your Freestyle 1025 answers. In using Time Saver,
you can avoid the cost of a call.
19
Message alert
Skip
When new messages have been received, your Freestyle 1025 will beep every 10 seconds. The volume of the beep is at the volume you have set for the loudspeaker.
To switch the message alert on or off
When the answering machine is in its idle state:
Using your answering machine from the cordless handset
You can use your Freestyle 1025 for a variety of functions: to listen to your messages; delete, skip forward or backward; and record a memo or new outgoing message. You can also use it to screen an incoming call.
ANSWERING MACHINE
Press the
SKIP button to confirm the
current setting.
Press and hold to change the setting.
The machine announces, “Message alert off/on” as appropriate.
Volume
1
S
k
G
H
I
4
Q
P
R
S
7
Channel
P
l
a
y
D
A
E
B
F
C
2
3
D
S
e
k
i
l
p
e
i
t
p
e
M
N
K
J
L
O
6
5
U
T
X
W
V
Y
Z
9
8
0
Quickdial
Secrecy Screen
1471
Redial
R
M
n
e
u
20
To use the Freestyle 1025 answer machine from
Screen
M
e
n
u
2
A
B
C
P
l
a
y
5
J
K
L
D
e
l
e
t
e
the handset, use the table below which shows which buttons to press for each function.
Press the
SCREEN/MENU button then:
The voice prompt will guide you through each function.
To play your messages from the handset
When the Freestyle 1025 is in Standby mode:
n
e
u
M
Screen
Press the
SCREEN/MENU button to
access the menu facility.
Press
1 To hear main menu.
2 To play all messages.
3 To play new messages.
4 Skip back during messages.
5 To delete during messages.
6 To skip forward during messages.
7 To record a new memo.
8 To play the outgoing message.
9 To record a new outgoing message.
0 To set a new security code.
To set Day and Time.
Press the
2 button.
The message will then be played back followed by the day and time of the call.
If you have 2 or more messages, they are played back in the order in which they were received.
When all your messages have been played back, your Freestyle 1025 announces: “End of messages”.
To hear main menu, press
1
To delete all messages, press Your Freestyle 1025 will return to standby mode after 8 seconds.
ANSWERING MACHINE
1.
5.
NOTE
To return the handset to standby at any time,
press the SCREEN/MENU button.
21
To skip forward or backward
Screen
M
e
n
u
Screen
M
e
n
u
2
A
B
C
P
l
a
y
5
J
K
L
D
e
l
e
t
e
6
M
N
O
S
k
i
p
4
G
H
I
S
k
i
p
2
A
B
C
P
l
a
y
through messages at the handset
When playing back messages, you can skip forward to the next message or backward to the start of the current or previous message.
Press the main menu.
Press the are being played back.
SCREEN/MENU button to hear
2 button, while the messages
To delete individual messages at the handset
Press the SCREEN/MENU button.
P
l
a
y
A
B
C
Press the
2
When the message you wish to delete is playing, press the
Skip through your messages to make any further deletions.
2 button.
5 button.
ANSWERING MACHINE
Press the
6 button to start playing the
next message.
If you skip beyond the last message, your Freestyle announces “End of messages”.
S
k
i
p
G
H
Press the
I
4
current message.
Press the
4 button once to replay the
4 button twice to go to the
start of the previous message.
To delete all messages at the handset
Press the 1 button to hear main menu.
1
Press the
Following playback of messages, your Freestyle 1025 will announce: “End of messages”.
D
e
l
e
t
e
K
J
L
Press the
5
messages.
Your Freestyle 1025 will announce: “All messages deleted”.
After 8 seconds your Freestyle 1025 will return to ‘Answer On/Of f’ mode.
2 button to hear your message.
5 button to delete all
22
Screen
M
e
n
u
0
Security code
Screen
M
e
n
u
Call screening
Your Freestyle 1025 has a security PIN code which must be entered when remotely accessing the answering machine. This ensures your messages are private and can be accessed only by the users who know the security code. Your Freestyle 1025 answering machine has a preset security code of 000.
To set the security PIN code
A new security code can only be set via the handset.
n
e
M
Screen
Press the
Press the
To set a new security PIN code press
Press the
Enter a 3-digit code after you hear the beep. Your Freestyle 1025 announces the new security PIN code.
u
Press the return your Freestyle 1025 to standby.
Or
The Freestyle 1025 will return to standby automatically after 8 seconds.
SCREEN/MENU button.
0 button.
button to hear security code.
#
SCREEN/MENU button to
You can let your answer machine pick up a call, even if you are in. This allows you to identify the caller and decide whether to take the call.
Make sure that the volume is set to an audible level (see page 17).
Allow the incoming call to be answered by your Freestyle 1025 as normal. You will hear the caller begin to leave a message.
To screen a call from the base unit
Press buttons in order shown
If the handset is resting on the base unit and you decide to take the call, lift the
.
handset and speak to the caller.
Recording will stop automatically.
To screen a call via the handset
When your Freestyle 1025 starts to record an incoming message, the light flashes.
Press the You can hear the caller on the handset.
Or
SCREEN/MENU button.
ANSWERING MACHINE
IN USE
To interrupt recording and talk to your caller, press the
TALK button.
23
Memos
Screen
M
e
n
u
7
P
Q
R
S
A personal memo can be recorded on your Freestyle 1025 and left as a message for another user. Memos can be of any length, up to the maximum recording capacity (3 minutes), but you should keep them short to allow time for recording incoming messages. Memos can only be recorded by using the handset.
To record a memo
Press the SCREEN/MENU button.
NOTE
To play or record your outgoing message,
please refer to page 15.
ANSWERING MACHINE
Press the
7 button. The Freestyle 1025
announces: “Please speak after the tone”.
Your Freestyle 1025 display shows: ‘r’
Press the
button to end recording.
#
When you have completed your memo, your Freestyle 1025 announces: “To hear main menu, press 1”.
Your memo is now stored and can be played back later. Memos are stored in the same way as incoming messages, and the message counter on the base unit will increase by 1.
NOTE
To play back, delete or skip forward or backward
through memos, follow the instructions for playing
back messages (pages 21 to 22).
24
Remote access
Control your answering machine from another phone using a TouchToneTMkeypad
You can turn your Freestyle 1025 answering machine on and off and listen to your messages from any TouchTone your privacy, messages can only be accessed by entering a 3-digit security code.
The code is pre-set to 000 and can be changed.
To change your security PIN code, please refer to page 23.
TM
telephone. To protect
To check for messages
Dial your phone number and wait.
When you hear your outgoing message, press the will hear “Please enter your security code”.
CODE Key in all 3 digits of your security code.
Once you have correctly entered your security code, if you have no messages you will hear “You have no messages,
to hear main menu press 1.”
You now have 8 seconds to enter any other instructions before your Freestyle 1025 hangs up.
If you have messages you will hear
“You have X new messages”.
button on your phone. You
REMOTE ACCESS
Your Freestyle 1025 will then play your messages.
NOTE
If you enter your security PIN code incorrectly, after
the second attempt, your Freestyle 1025 will announce:
“Thank you for calling” and will then hang up.
25
Operating the answering machine
When you have accessed your answering machine, you can operate using the keypad numbers on the phone you are using.
The main menu
The main menu lets you operate a range of answering machine functions. Simply follow the instructions as announced:
REMOTE ACCESS
“To play all messages, press
“To play new messages, press
“To skip back during messages, press
“To delete during messages, press
2
3
4
5
“To skip forward during messages, press
“To play outgoing message, press
8
“To record a new outgoing message, press
“To set answer on or off, press
“To hear main menu, press
0
1
6
9
26
Freestyle 90/130/1025/1200
Quickdial
Channel
Additional Handsets
You can buy and use up to 3 Freestyle additional handsets with your Freestyle 1025 to extend your phone system, without needing to install extension sockets for each new phone.
To erase a registration code
Press and release the QUICKDIAL button.
Each additional handset is supplied with its own charger and user instructions, but the following information will tell you how to register and use an additional handset with your Freestyle 1025.
Registering your handset
You must register your Freestyle additional handset before it can be used with your Freestyle base unit. Make sure that each additional handset is registered with a different number (2, 3 or 4) so it can be identified from other additional handsets. See page 28.
NOTE
The following erasing and re-registering procedure
can be used for either re-registering an original
handset or registering an additional handset. If you
wish to re-register please follow the instruction
adjacent, using your original handset where it refers
to additional handset.
Quickdial
Press and release the
Press the
Press and release the
You will hear a confirmation beep, the old registration code is now erased and you can re-register your additional handset following the procedure below.
button four times.
CHANNEL button.
QUICKDIAL button.
To register an additional handset
Place the handset you wish to register on the base unit and then remove it.
Page
Press and hold the base unit for 5 seconds.
As soon as the flash, release the the additional handset on the base unit.
IN USE light begins to
PAGE button and place
ADDITIONAL HANDSETS
PAGE button
Your additional handset is registered automatically and you will hear a long confirmation beep and the will stop flashing.
IN USE light
27
NOTE
Quickdial
Quickdial
Secrecy
Your additional handset must be placed on the base
unit within 5 seconds of the IN USE light flashing.
To set a handset identity number
Press the QUICKDIAL button.
Press the
SECRECY button.
To re-register an additional handset
KEYPAD
Before re-registering, the old registration code must first be erased. If necessary you can re-register your additional handset by simply following the above procedures.
Enter the identification number (2-4) using the keypad.
When you have entered the number, press the
QUICKDIAL button.
You will hear a beep confirming that the new number has been stored.
NOTE
Check that your additional handset is registered
correctly by pressing the TALK button and listening
for a dial tone. If you do not hear a dial tone your
additional handset is either out of range of the base
unit or it has not been registered properly, or the base
unit line cord is not plugged in.
ADDITIONAL HANDSETS
Make a note of the identification number by writing
it on the handset’s directory label.
To set the handset number
Each additional handset must be assigned an identity number (2, 3 or 4). Your Freestyle 1025 handset is already numbered as HANDSET1. Additional handsets can then be numbered as they are added.
NOTE
NOTE
Your Freestyle additional handset is pre-set
to handset number 2.
28
Basic use of Freestyle additional handsets
NOTE
Like all cordless phones, the Freestyle
additional handset must be charged for 24 hours
before initial use.
NOTE
If you do not hear a dialling tone after pressing the
TALK button, wait a few seconds. On a few exchanges,
there may be a delay.
To end a call
Basic operation of additional handsets is the same as that of your Freestyle 1025 handset.
NOTE
You cannot control the answering machine from
the 90/130/1025/1200 additional handset, and it
does not have the call screening facility.
The handset range is up to 200 metres from the base unit in ideal conditions. If you start to go out of range while using the phone, you will hear warning beeps. If you do not come back in range, your call will be disconnected.
To make a call
Lift the handset off the charger.
Press the comes on and the handset buttons illuminate.
Listen for the dialling tone.
TALK button. The IN USE light
Press the TALK button or replace the handset.
Transferring calls between handsets
While on a call (ie. in talk mode):
Secrecy
KEYPAD
Press the
SECRECY button.
Enter the number of the handset you want to transfer the call to. The specified handset will ring.
To answer the call, press the
TALK button.
NOTE
If the call is not answered, it is returned to the original handset after 30 seconds. The original
handset will ring to let you know if this has
happened. To avoid having to wait 30 seconds
for the call to be returned, you can press the
TALK button to cancel the transfer of the call.
ADDITIONAL HANDSETS
KEYPAD
Dial the number you want.
29
Help
If you have any problems using your Freestyle 1025, this section will give you the most common, easy-to-follow solutions.
Telephone problems Possible cause Solution
HELP
• No dialling tone.
• Telephone will not dial out.
• Telephone cannot receive calls.
• Beeps six times and drops calls.
• You have dialling tone but the telephone will not dial out.
Telephone not connected to telephone line.
Mains disconnected.
Power cut.
Handset battery pack is discharged.
Handset is not registered to base unit.
You may be trying to use tone dialling on a pulse dialling exchange.
Replace handset on base unit for 10 seconds and try again. If this does not work, disconnect the handset battery from the handset for 10 minutes. Also disconnect the mains power.
Then reconnect the base unit to the mains, then replace the handset on the base unit for 10 seconds and try again.
Plug the telephone into the telephone line.
Wait until the power is restored.
Place the handset on the base unit and recharge it for 24 hours, ensuring the charging light is on.
Re-register the handset. Refer to page 27 to first erase registration and then re-register the handset.
Set the mode to P-E (pulse dialling).
30
• Handset does not ring.
• No
IN USE light on handset.
You are connected to a PBX and are not dialling the access code.
Handset battery pack is discharged. Place the handset on the base unit and
Use the PBX access code.
recharge it for 24 hours.
Telephone problems Possible cause Solution
• Handset does not ring, but IN USE light show on handset.
• Base unit does not ring but lights show on base unit.
• Base unit rings too loudly / softly.
• Neither base or handset ring, but lights show on base and handset.
The handset ringer may be set to its
Increase the handset ringer volume.
minimum setting.
Telephone is not connected to the telephone line.
The base ringer is set to off.
Line fault or faulty socket.
Plug the telephone into the telephone socket.
Set the base ringer settings to a higher volume.
Try the telephone on another socket or another line. If the telephone works, contact BT or your telephone network operator for repairs to the line or socket.
Base unit setting is too High or Low. Set the ringer setting accordingly.
The ringer volumes on both the handset and base unit could be set to
Increase the ringer volume on the base unit and handset.
minimum.
Check the REN (see page 34). If you connect too many telephones or
If the REN exceeds 4, disconnect one
or more telephones or devices. devices to your line, they may not all operate correctly.
HELP
• Callers are faint.
• Interference.
• Buzzing.
• Whooshing.
• Echoing.
• Tinniness.
If your telephone is connected to an extension socket, it may have been connected incorrectly.
The base unit telescopic aerial is not extended as high as possible.
You are moving out of range.
Radio channel interference.
Radio channel interference.
The base unit or the handset are too close to electrical equipment or metal obstructions.
Check with your telephone engineer
that the extension socket has been
installed correctly.
Extend the base unit telescopic aerial
as far as possible.
Move closer to the base unit.
Press the
CHANNEL button on the
handset, to select a clearer channel.
Press the
CHANNEL button on the
handset, to select a clearer channel.
Relocate the base unit or move
around with the handset until
reception improves.
31
Telephone problems Possible cause Solution
HELP
• No Quickdial store.
• No number stored on 1471.
• Call appears to have been cut off after pressing the
SECRECY button.
BATT LOW light on the handset is flashing.
• No CHARGING light on the base unit.
You may be trying to store the number with the
IN USE light on.
Stored number may have inadvertently been over written.
Ensure that the before storing the number.
Press the QUICKDIAL button, press the relevant Select Services button, then press the
IN USE light is off
QUICKDIAL button
again. This will reset the button.
You may have pressed a number key on the handset after pressing the
SECRECY button. The current handset
will try to transfer the call to another
Wait 30 seconds; the call will return to the current handset. Or press the
TALK button and the call will return
immediately.
handset.
The handset needs recharging. Replace the handset on the base unit,
ensuring that the base unit is plugged
Dirty contacts on base unit or handset.
in and that the
Clean the contacts with a dry cloth. Heavy soiling can be removed with a
CHARGING light is on.
pencil eraser.
32
Answering Machine problems Possible cause Solution
• General problems.
• Will not record incoming messages.
• Will not answer calls.
• No call screening from the base unit.
• Cannot hear messages when played.
• When accessing your machine remotely, your security PIN code does not work.
None of the answering machine functions will operate while the telephone is in use.
The answering machine is switched off.
The answering machine is full.
The volume is set too low. Press and release the end of the
Incorrect security PIN code entered. Re-set your security PIN code.
Ensure that the telephone is not in use before operating the answering machine.
Switch the answering machine on manually or by remote control.
Delete some or all of your messages manually or by remote control, to make room for new messages.
volume control with the larger symbol until the unit is loud enough.
See page 23.
HELP
33
Technical information
TECHNICAL INFORMATION
Approval for use
Your Freestyle 1025 is tested and approved for connection to public networks, provided it is used in accordance with the guidelines in this user guide.
You may connect it:
• To direct exchange lines.
• To extensions with new plug and socket
arrangements provided with these direct exchange lines.
• To compatible switchboards.
You may NOT connect it:
• To shared service (party) lines.
• As an extension to a payphone.
This phone is designed for UK use only. Using it abroad may violate local radio laws.
The base unit is intended for use when powered from the 9V AC mains adaptor supplied, which conforms to EN60950. Any other usage will invalidate the approval given to this apparatus if, as a result, it ceases to comply with EN60950.
Environment
Your Freestyle 1025 should be kept free of dust, moisture, high temperature and vibration, and should not be exposed to direct sunlight. Do not stand it on carpets or other surfaces which generate fibres, or place it in locations which prevent the free flow of air over its surfaces.
WARNING
The apparatus is only designed to be operated in
a normal office or domestic environment where
the relative humidity does not exceed 60%. It should
not be used in bathrooms or near water.
How many phones can you have?
All items of telephone equipment have a Ringer Equivalence Number (REN), which is used to calculate the number of items which may be connected to any one telephone line. Your Freestyle 1025 has a REN of 1. A total REN of 4 is allowed. If the total REN of 4 is exceeded, the telephones may not ring. With different telephone types there is no guarantee of ringing, even when the REN is less than 4.
Connecting to a switchboard
Your Freestyle 1025 may be connected to compatible switchboards. If in doubt, your switchboard supplier or maintainer should be able to offer help. Advice on connection to BT switching systems can be obtained by dialling BT on 152.
If you do not have a compatible switchboard, it cannot be guaranteed that your Freestyle 1025 will operate correctly under all possible conditions of connection.
34
Call security
Your Freestyle 1025 has its own digital security code that prevents other cordless phone owners from using your phone line. This ensures that you are charged only for calls using your phone. However, all approved cordless phones use radio signals to communicate between the base unit and cordless handset units. It is therefore possible that your conversations could be overheard by other people, on their cordless phones, or on radios that use the same radio frequencies.
Transmission frequencies of available channels:
Channels Base Unit Tx Handset Tx
Freq./MHz Freq./MHz
1 31.0375 39.9375
2 31.0625 39.9625
3 31.0875 39.9875
4 31.1125 40.0125
5 31.1375 40.0375
6 31.1625 40.0625
As this problem applies equally to all similar cordless phones currently available in the UK, call privacy cannot be guaranteed. However, the security coding prevents unauthorised use of your line.
In the unlikely event of your Freestyle 1025 picking up conversations from other cordless phones being used nearby, tr y changing channels using the
CHANNEL button on the
handset.
Transmission frequencies
This cordless telephone has been designed to operate on radio frequencies which have been assigned to the exclusive use of cordless telephones. As the use of cordless telephones becomes more widespread, the quality of service obtained from this apparatus may lessen.
7 31.1875 40.0875
8 31.2125 40.1125
TECHNICAL INFORMATION
Safety advice
Don’t use your Freestyle 1025 in the open air during thunderstorms. Unplug it from the telephone line and the mains socket when there are storms in your area.
Don’t use your Freestyle 1025 outdoors in the rain, or handle it with wet hands.
Don’t install the base unit near a sink, bath or shower. Electrical appliances can cause serious injury if used when you are wet or standing in water.
Don’t install the base unit where the various leads can be tripped over or walked on. This may cause injury, or damage to the leads and your Freestyle 1025.
In the event of a power failure
In the event of a mains power failure you will not be able to make or receive calls from your Freestyle 1025. Alternative arrangements should be made for access to emergency services.
35
Maintenance
Installing a handset battery pack and recharging
Replacing the handset on the base unit to recharge overnight should keep the Freestyle 1025 operative for normal use. In time, the handset battery pack will no longer hold a sufficient charge and should be replaced.
To change the handset battery pack
The handset battery compartment is located at the back of the handset at the lower end.
MAINTENANCE
• Firmly hold the handset in both hands with the back towards you and the bottom end away from you.
• To remove the batter y compar tment cover, push the depression inward and away from you with both thumbs.
• Undo the plastic belt securing the battery pack.
• Remove the old battery pack by unplugging the small white plug that connects it to the handset.
• Insert the small white plug of the new battery pack. (If you look at the shape of the plug and socket, you will see that it can only be inserted one way).
• Place the battery pack in the recess, secure it with the plastic belt and refit the compartment cover.
• Replace the handset on the base unit and charge for a full 24 hours.
• The battery pack must be recycled or disposed of properly.
36
• Do not burn or puncture as it could release toxic material which may cause injury.
Spare parts for your Freestyle 1025 are available
from your BT shop or supplier.
Care of rechargeable battery pack
• When you first install the Freestyle 1025, or replace the battery pack, the handset must be fully charged for 24 hours before use.
• To maintain optimum charge and battery condition, the handset should be allowed to fully discharge about every 4 months.
• Dispose of Ni-Cad battery packs safely. Do not puncture or burn them. They contain toxic materials which could cause injury.
General cleaning
Clean the cabinet of the handset and the base with a soft cloth slightly dampened with a mild solution of water and detergent. Charging contacts should be cleaned with a dry cloth, or for heavy soiling a pencil eraser can be used.
• Do not clean with a wet cloth.
• Do not clean with abrasive materials or solvents as these may damage the unit.
• Do not spray aerosol cleaners onto the base or handset.
Extended periods of non-use
It is recommended that you:
• Disconnect the base unit from both mains supply and telephone line.
• Remove the battery pack from the handset.
• When reconnecting, check that the charging light on the base unit is on. Recharge the handset battery for 24 hours.
Guarantee
If you own your Freestyle 1025 under BT’s guarantee
BT guarantees the product for one year provided that:
The goods have only been used for their intended purpose and have not been subjected to misuse, or been wilfully or accidentally damaged.
The goods have not been tampered with or repaired by anyone other than BT, its staff or agents. If a fault does occur in this product, and you bought the unit yourself, provided that you return it to the place of purchase and produce your receipt, it will either be repaired or replaced free of charge. The terms and conditions of this guarantee do not affect your statutory rights.
If you own your Freestyle 1025 outside the guarantee period
If your Freestyle 1025 needs repair after the guarantee period has ended, it must be repaired so as to remain compliant with the approval requirements for connection to the telephone network. We recommend that you call BT on Freefone 0800 800 150 or visit your nearest BT shop and you will be informed of our recommended repair agents.
MAINTENANCE
37
Wall mounting
Your Freestyle 1025 can be wall-mounted by using the bracket provided.
1
Drill 2 holes for the screws and insert the wall-plugs provided (if required).
You can use the bracket as a template to mark where the screws should go into the wall.
Please refer to page 39, wall-mounting template.
Before you wall-mount your Freestyle 1025, check that:
• the wall can support the weight of the base
• the position you choose leaves enough
WALL MOUNTING
• the position leaves enough space for the
For the best operating conditions, try to place the base unit away from large metal objects and other electrical appliances.
unit and handset;
space so that the base unit (which is larger than the bracket) is clear of any obstruction on the wall, such as a shelf or cupboard. Room should be left so that the handset can be placed on charge without touching any obstructions;
aerial to be extended when wall-mounted.
WALL PLUG
WALL
2
Drive the screws into the wall, leaving about
SCREW
102 mm
4mm free on which to mount the bracket and base unit.
3
Make sure that the power supply and the telephone cables are connected to the base unit, then fit the cables into the channels on the bottom of the base unit.
4
Clip the bracket onto the base unit as shown on the next page.
5
Attach the bracket and base unit by hooking them over the screws protruding from the wall.
38
Wall-mounting template
102 mm
2
SQUEEZE INWARD
WALL MOUNTING
1
36
39
Index
INDEX
Additional handsets
basic use 29 end a call 29 erase 27 handset number 28 identity number 28 make a call 29 re-register 28 register 27 transfer a call 29
Aerial
base unit 7 handset 5
Answer delay 19
changing 19 checking 19
Answering machine -
call screening 23 day and time 16 delete cancel 19 delete message 18 delete all messages 19 go back to pre-set outgoing message 16 message display on base station 14 on/off 15 outgoing message – change 14 outgoing message – check 15 outgoing message – delete 16 outgoing message – pause 18 outgoing message – play 18 outgoing message – pre-record 16 record via the handset 15 skip message 18 volume (base station) 17
Battery
care of handset battery 6, 36-37 charging handset battery 6
Calls
ending 8 making 8 range 9 receiving 8 redialling 8 secrecy 9 sound quality 9
Call screening 23
at the base 23
at the handset 23 Call waiting 12 Channel 9, 35 Charging handset battery 6 Cleaning 37
Day and time 16
Dialling mode 13 Display - answer machine 14 Display messages 14
Emergency calls 4 Guarantee 37 Help 30
Helpline 4
Incoming messages 17 Location 7 Mains adaptor 5
Maintenance 36 Making a call 8 Memory full 14 Memos 24
recording 24
40
Message alert 20 Message display 14 Messages – incoming 17
pause 18 playback 18 skip forward/backwards 18
On/off – answering machine 25 Pause 13, 18
Phone socket 7 Power adaptor 6 Power failure 35 Power socket 6
Quickdial 9
dial 10-11 page 13 pause 13 store 9, 10
Quickdial reference label 10
Range 9
Recall 13 Remote access 25
operate your answer machine 26 check your messages via the handset 25
REN (Ringer Equivalence Number) 34
Safety advice 35
Secrecy 9 Security PIN code 23 Sound quality 9 Store a number in the memory 9 Switchboards 13, 34
Technical information 34
Telephone socket 5 Transmission frequencies 35
Volume 11
base station 11 handset ringer melody 11 incoming messages 11 handset ringer 11
Wall-mounting 38
Wall mounting template 39
1471 feature 12
INDEX
41
Offices in Europe, North America, Japan and Asia Pacific.
The telecommunications services described in this publication are subject to availability and may be modified from time to time. Services and equipment are provided subject to British Telecommunications plc’s respective standard conditions of contract. Nothing in this publication forms any part of any contract.
© British Telecommunications plc 1999. Registered Office: 81 Newgate Street, London EC1A 7AJ. Registered in England No. 1800000. Designed by: The Art & Design Par tnership Limited. Printed in China by: Suncorp Technologies Freestyle 1025 Issue 1 (10/99) 2.
Printed on paper which meets international environmental standards
CE compliant to 89/336/EEC (EMC Directive) & 73/23/EEC (Low Voltage Directive)
APPROVED for connection to
telecommunication systems specified in
the instructions for use subject to the
conditions set out in them
610235
Loading...
