BT FREELANCE XD500 User Manual

User

Guide

BT Freelance XD 500

Digital Cordless Telephone Answering Machine

This equipment is not designed for making emergency telephone calls when the

power fails. Alternative arrangements should be made for access to emergency services.

This product is intended for connection to analogue public switched telephone networks

and private switchboards in the United Kingdom.

YOU MUST

SUBSCRIBE TO YOUR

NETWORK PROVIDER’S

CALLER DISPLAY

SERVICE BEFORE

THIS FEATURE WILL WORK.

A QUARTERLY FEE IS PAYABLE

Please open this page for an ‘At a glance’ guide to your Freelance XD 500

Please open this page for a further ‘At a glance’ guide to your Freelance XD 500

At a glance

BT Freelance XD 500 Handset

Redial/Pause button

To redial one of the 5 last numbers called.

Also used to enter a pause in a stored number.

Phonebook button

Use to access the 50 names and numbers stored

in the phonebook.

Del

Vol

Volume button

Use to adjust the handset earpiece speech volume

and handset and base ringer volume.

Also used to access the calls list and scroll through

the directory, redial and calls list.

Delete/Secrecy button

Use to delete digits entered incorrectly and numbers in the Calls list. Also used to mute a call so the caller

cannot hear you talk to someone close by.

Recall button

For use with a switchboard/PBX and

BT Calling Features.

Also used to switch the handset on or off.

1 2

Red light

To indicate that the phone is ringing or in use.

Handset display

Display shows you the name and number you have dialled and status of the handset.

Menu button

Use to access and select the options in the menu.

Talk button

Use to make, receive and end calls.

Keypad

Int

Conference button

Allows you to hold a three-way conversation.

Internal button

To make internal calls between handsets registered to the base and to transfer an external call to an additional handset.

Page

Vol

Del Play

Messages

Stop

SkipSkip

Ans.

Page button

Press to page the handset.

Stop

To stop message playback.

Delete

Deletes recorded messages and memos.

Play

Lets you play and pause your messages.

Volume

Adjust the loudspeaker volume.

Power/In Use light

Flashes when the handset is in use.

Charging light

Comes on to indicate charging when the handset

is on the base.

Answer on/off

Switches the answering machine on and off.

Also allows you to select your outgoing message.

Skip backward

Lets you skip backwards through your messages

and memos.

Also allows you to switch the audible message

alert on or of f.

Allows you to select your Answer and Record

outgoing message.

Skip forward

Lets you skip forward through your messages and memos.

Also allows you to set the answer delay.

Allows you to select your Answer Only outgoing message.

At a glance

BT Freelance XD 500 Base

3 4

Quick guide to the handset display icons

Handset 1

Displays the number of the handset at all times.

Icon Steady Flashing

EXT

External line in use Incoming call

INT

Internal call Internal call from another handset

New call in Calls list

3 way conversation in progress

Battery exhausted

Battery weak

Battery half-full

Battery full

Phonebook

Menu in use

Handset linked to base station Out of range or searching for base station

HANDSET 1

Idle screen

EXT

INT

EXT

INT

Menu Structure

Phonebook Add

Delete

Modify

Setup Base Vol Volume 1.....5

Vol Off

Base Mel Melody 1.....5

Sel Base Base 1.....4

Auto

Del HS PIN? Handset 1.....5

Pin Code PIN? New PIN

Retype

Priority On

Off

Select Base

Handset 1.....5

Dial Mode Tone

Pulse

Recall Recall 1

Recall 2

PABX PBX1 PIN?

PBX2 PIN?

Pause 3 Sec

5 Sec

Default PIN?

Cont......

TAM menu TAM menu

(Flashes on display when in TAM menu.)

This is a handset See page 45 ‘Using the Freelance XD 500 announcement menu. answering machine via the handset’.

Handset Beep Keytone On or Off

Low Batt On or Off

Outrange On or Off

Ring Vol Volume 1.....5

Vol Off

Ear Vol Ear Vol 1.....5

Int Mel Melody 1.....5

Ext Mel Melody 1.....5

Auto Ans On

Off

Name

Language English

Francais

Deutsch

Nederl

Italiano

Espanol

Portuges

Norsk

Dansk

Svenska

Suomi

Important. If you make a mistake you can return to the previous menu

heading by pressing the DEL button. If you press and hold the DEL button at any time you will return to the idle screen. After 30 seconds if no buttons are pressed the handset will automatically return to the idle screen.

At a glance

Handset 1-2 Base 3-4 Display icons 5 Menu structure 6

Introduction 9

Unpacking your

Freelance XD 500 9 For your records 10 Safety information 11

Setting up 13

Plan the location 13

Using the telephone 18

Making and receiving calls 18 Call timer 19 Redial 20 Secrecy 20 Name and number Phonebook 20 Paging handsets 23

Handset settings 24

Base settings 27

BT Caller Display 30

Calls list 31

Setting up and personalising your answering machine 33

Message display on the

base station 34

Answer delay 35 Audible message alert 36 Outgoing messages 36

Using the Freelance XD 500 answering machine via the base unit 42

Call screening 44

Using the Freelance XD 500 answering machine via the handset 45

Memos 48 Call screening/Call intercept 49

Remote access 50

Time saver 51 Operating the answering

machine 52

Using additional handsets and bases 53

Internal calls 55 Transferring calls 55

Help 57

General information 59

Guarantee 59 Technical information 60 Switchboard compatibility 60 Switchboard external line

access code 60

Recall 61

In this guide

Note

In this user guide, we’ve included helpful tips and useful notes. They are shown in a white box like this.

Introduction

Your Freelance XD 500 has been designed for ease of use and made to the high standards set by BT.

This user guide applies to both single and multiple handset systems.

Please read the instructions carefully before use and retain this user guide for future reference.

Unpacking your Freelance XD 500

If anything is missing, please contact your place of purchase immediately.

Freelance XD 500 base station

Freelance XD 500 handset

2 x AAA rechargeable batteries (NiMH)

Power supply for base station(Item code: 005391)

Telephone line cord

One belt clip

In addition:

If you have purchased the Freelance XD 500 Twin.

Freelance XD 500 handset Freelance XD 500 charger 2 x AAA rechargeable batteries Power supply for the charger (Item code: 003313)

If you have purchased the Freelance XD 500 Trio.

2 Freelance XD 500 handsets 2 Freelance XD 500 chargers 4 x AAA rechargeable batteries 2 x power supply for the chargers (Item code: 003313)

If you have purchased the Freelance XD 500 Quad.

3 Freelance XD 500 handsets 3 Freelance XD 500 chargers 6 x AAA rechargeable batteries 3 x power supply for the chargers (Item code: 003313)

Note

If you have purchased one of the multiple handset packs the handsets come pre-registered.

Page

Vol

Ans.

Stop

SkipSkip

Del Play

Messages

Del

Vol

123

456

789

Int

For your records

Date of purchase:

Place of purchase:

Serial number:

(On the underside of the base)

For guarantee purposes proof of purchase is required so please keep your receipt.

Enter your Base station PIN here:

See page 28 for more information.

Safety information

General

Only use the power supply included with the product. Using an unauthorised power supply will invalidate your guarantee and may damage the telephone. The power supply item code for the base station is 005391. The power supply item code for the charger is: 003313 (only available if you have purchased the Freelance XD 500 Twin, Trio or Quad).

For the handset use only approved Nickel Metal Hydride (NiMH) rechargeable batteries. Never use other batteries or conventional alkaline batteries. Recommended batteries should have a power rating of 550mAh 1.2V. Batteries are available from the Freelance XD 500 Helpline on 08706 058 047.

Do not open the handset, base station or charger. This could expose you to high voltages or other risks. Contact the Freelance XD 500 Helpline for all repairs.

Radio signals transmitted between the handset and base may cause interference to hearing aids.

It is recommended that advice from a qualified expert be sought before using this product in the vicinity of emergency/ intensive care medical equipment.

It is recommended that if you have a pacemaker fitted, you check with a medical expert before using this product.

Your product may interfere with other electrical equipment, e.g. TV and radio sets, clock/alarms and computers if placed too close. It is recommended that you place your product at least one metre away from such appliances to minimise any risk of interference.

Never dispose of the batteries in a fire. There is a serious risk of explosion and/or the release of highly toxic chemicals.

Cleaning

Simply clean the handset and base with a damp (not wet) cloth, or an anti-static wipe.

Never use household polish as this will damage the product.

Never use a dry cloth as this may cause a static shock.

Environmental

Do not expose to direct sunlight.

The product may heat up when the batteries are being recharged. This is normal. However, we recommend that you do not place the product on antique/veneered wood to avoid damage.

Do not stand your product on carpets or other surfaces which generate fibres, or place it in locations preventing the free flow of air over its surfaces.

Do not submerge any part of your product in water and do not use it in damp conditions, such as bathrooms.

Do not expose your product to fire, explosive or other hazardous conditions.

There is a slight chance that your phone could be damaged by an electrical storm. We recommend that you unplug the power and telephone line cord for the duration of the storm.

Battery performance

The charge capacity of rechargeable batteries will reduce with time as they wear out, so reducing talk/standby time of the handset. Eventually they will need to be replaced. New batteries can be obtained from the Helpline on 08706 058 047.

After charging your handset for the first time, subsequent charging time for the batteries is approximately 6-8 hours a day. Batteries and case may become warm during charging, this is normal.

Under ideal conditions, the handset batteries should give about 12 hours talktime or 150 hours standby on a single charge. (This does not mean you can unplug the base station or leave it for this length of time without charge.)

Please note, however, that new NiMH batteries do not reach full capacity until they have been in normal use for several days.

Setting up

Follow these steps to set up your Freelance XD 500 ready for use.

Plan the location

Situate your product close enough to the telephone and mains power supply so that the cables will reach.

Make sure it is at least 1 metre away from other electrical products to avoid interference.

Connect the power supply cable

Plug the power supply cable into the power socket on your Freelance XD 500 base. The green Power/In Use light comes on.

Plug the power supply adaptor into the wall socket

Your Freelance XD 500 will announce the default settings of the answering machine. See page 17.

Do not connect the telephone line cord to the phone socket until your handset is fully charged. This will prevent the risk of the phone being answered before the batteries are charged. Answering the phone before the batteries are fully charged may prevent it from reaching its optimum capacity.

Note

The base station must be plugged into the mains power socket at all times.

Warning

Under no circumstances should non-rechargeable batteries be used. Only use the approved batteries. Using unapproved batteries will invalidate your guarantee and may damage the

telephone.

3 Insert the batteries

Insert the two batteries supplied, as indicated on the markings inside the battery compartment and slide the battery compartment shut. The handset display will show HANDSET 1. This means one handset is registered to the base. (If you have purchased the Freelance XD 500 Twin, Trio or Quad the additional handset(s) will show HANDSET 2/3/4.

Charge the handset batteries for at least 16 hours

Before you use your Freelance XD 500 for the first time it is important to have the handset batteries fully charged. Place the handset on the base. You will hear a long beep. The red charging light on the base will come on and the battery. Leave the handset to charge continuously for at least 16 hours to reach full charge.

Note

The charging light will remain lit even when the batteries are fully charged.

Battery levels

Battery low warning

If the handset battery symbol is empty, you will hear a warning beep every 10 seconds, you will need to recharge your handset before you can use it.

Helpline

If you are experiencing difficulty, please call the BT Freelance XD 500 Helpline on

08706 058 047.

Out of range warning

The symbol on your handset display indicates when you are in range of the base station. If the symbol flashes and you hear a warning beep, you are out of range and will need to move closer to the base station.

Signal Strength

The Freelance XD 500 has a range of up to 300 metres outdoors and up to 50 metres indoors. This is in ideal conditions. The range will be reduced when there is no clear line of sight between the base and the handset. Thick stone walls can severely affect the range.

If you have purchased the Freelance XD 500 Twin, Trio or Quad packs insert the batteries into your additional handsets as shown on page 14.

Connect and charge the Freelance XD 500 handsets

Plug the power supply cable with the red connector into the power socket on your Freelance XD 500 charger.

Plug the power supply adaptor into the wall socket.

Place the handset onto the charger. The red charging light will come on. Leave the handset to charge continuously for at least 16 hours to reach full charge.

Connect the telephone line cord to the base

Plug the telephone line cord into the line socket on your base and connect the other end to the telephone line socket on your wall.

You can change the day and time as required.

Press the  button twice on the Freelance XD 500 handset.

Press the 0 button. The prompt will announce,

“To set day and time press

✱

, to hear day and time

press#”.

(Please note that if you press the #button this allows you to check the day and time.)

Press the

✱

button.

The prompt will announce,

“Please enter new day and time after the tone”.

After the tone enter the day, followed by the time using the 24 hour clock.

1 = Sun, 2 = Mon, 3 = Tues, 4 = Wed, 5 = Thur, 6 = Fri, 7 = Sat.

Note

The main menu announcements are automatically announced through the handset earpiece when the  button is pressed twice.

8 To set the day and time

The message counter on the base unit will flash between 0and Cuntil the day and time are set.

The day and time must be set using the Freelance XD 500 handset.

Your Freelance XD 500 automatically adds the day and time to all messages and memos received.

When you first switch the power on, the clock is set to Sunday,

12.01pm

Note

If the day and time is entered incorrectly, the prompt will announce, “Incorrect, please set again”. Enter the correct setting within 15 seconds otherwise the handset will return to standby mode. If the day and time is entered incorrectly three times

the handset will return to standby.

For example:

1 1415 = Sunday 2.15pm.

5 0915 = Thursday

9.15am.

You will then hear your setting confirmed.

Press the DEL button twice to return the handset to standby.

Note

If you have any difﬁculties setting up your Freelance XD 500 please call the Helpline on

08706 058 047.

Del

Please see the table below for your Freelance XD 500 default settings.

Freelance XD 500 Default Settings Table

Feature Default Setting

Day/Time Stamp Sunday 12:01 pm

Answer Delay Your answering machine

will answer after 6 rings

Audible Message Alert Tone OFF

Outgoing Message Answer and Record “Hello

your call cannot be taken at the moment so please leave your message after the tone.”

Answer Mode ON

Base ringer level High

Base loudspeaker volume Level 5

PIN code 0000

Dialling mode Tone

If you wish to personalise your answering machine settings, for example record your own outgoing message etc, please see “Setting up

and personalising your answering machine” beginning on page 33.

The Freelance XD 500 answering

machine will now be switched ON

and set to its default settings and is

now ready for use.

Making and receiving calls

To switch the handset on and off

Press and hold the RECALL/ POWER button to switch the handset off.

To switch the handset on, press and hold the RECALL/ POWER button again.

To make an external call

Press the TALK button. You will hear the dial tone and the display will show the

EXT

symbol.

Enter the number you want.

Preparatory dialling

Enter the number to be dialled.

The number is shown in the display.

(If you make a mistake, press the DEL button to remove the incorrect digit.)

When you have entered the number correctly, press the TALK button to dial the number.

Using the telephone

Del

To end a call

Press the TALK button or place the handset back on the base.

Call timer

Your handset will automatically time the duration of all external calls.

The handset display shows the call duration both during your call and for a few seconds after it is complete.

To receive a call

When the phone rings the display will show

CALL

and

the EXT symbol will flash.

If you have subscribed to a Caller Display Service, the number (and name if stored in the phonebook) will be displayed.

Press the TALK button to answer the call.

If the handset is on the base, simply lift it up and speak.

To adjust the earpiece volume

During a call:

You can adjust the earpiece volume. There are 5 levels to choose from.

Press the UP or DOWN button until you reach the required level.

In idle mode:

Press the  button.

Press the DOWN button until

HANDSET

is displayed.

Press the

 button.

Press the DOWN button until

EAR VOL

is displayed.

Press the  button.

Press the UP or DOWN button until you reach the required level.

Press the

 button to

confirm the selected level.

Press and hold the DEL button to return to the idle screen.

Vol

Del

+ 45 hidden pages
