Bryant 594D User Manual

ELECTRIC AIR CONDITIONER

Model 594D Energy-Efﬁcient Air Conditioners incorporate innovative technology to provide quiet, reliab le summer cooling performance. Built into these units are the features most desired by homeowners today, including SEER ratings of up to 12.0 when used with components as designated by manufacturer . All models are listed with UL, c-UL, ARI, CEC, and CSA-EEV.

AVAILABLE OPTIONS

ELECTRICAL RANGE —All units are offered in 208/230-volts,

single phase.

HEAVY DUTY INLET GRILLE —The DuraGuard™ coil pro-

tector, made of a coated steel wire grid with vertical 3/8 in. spacing, is designed to help protect the coil from inclement weather, vandalism, and incidental damage. It provides protection while not restricting airﬂow and maintaining ease of coil inspection and cleaning.

Model 594D (60 Hz)

Sizes 018 thru 060

WIDE RANGE OF SIZES —Availab le in 7 nominal sizes from 018

through 060 to meet the needs for residential and light commercial applications.

WEA THER-PR OTECTIVE CABINET —Steel is galvanized, then

coated with a layer of zinc phosphate to which a coat of modiﬁed polyester powder coating is applied and baked on. This provides each unit with a hard, smooth ﬁnish that will last for many years.

All screws on cabinet exterior are ceramic coated for a long-lasting, rust-resistant, quality appearance.

TOTALLY ENCLOSED FAN MOTOR —Means greater reliability

under rain conditions and dependable performance for many years. The permanent-split capacitor type motor was designed for optimum efﬁciency. Then, under extreme conditions, the motor was tested and qualiﬁed to help ensure the greatest reliability.

UNIT DESIGN —Copper tube, enhanced aluminum ﬁn coil is

designed for optimum heat transf er . Vertical air discharge carries sound and hot condenser air up and away from adjacent patio areas and foliage. Heat pump style base pan f or easy remo val of water, dirt, and leaves.

APPLICATION VERSATILITY —The 594D can be combined

with a wide variety of evaporator coils and blower packages to provide quiet, dependable comfort. Unit can be installed on a roof or at ground level on a slab.

EXTERNAL SERVICE VALVES —Both service valves are brass,

back seating type with sweat connections. Valves are externally located so refrigerant tube connections can be made quickly and easily. Each valve has a service port for ease of checking operating refrigerant pressures.

EASY SERVICEABILITY —One panel provides access to elec-

trical controls and compressor. Removal of wire dome grille gives access to fan motor, while removal of top gives access to coil.

COMPRESSOR PROTECTION —Each model is protected with

internal temperature- and current-sensitive overloads. An internal pressure relief valve provides high-pressure protection to the refrigerant system.

AEROQUIET FAN SYSTEM —Allows air to move through the

unit more easily which lowers sound lev els and impro ves overall efﬁciency.

SCROLL COMPRESSOR —All units feature the scroll compres-

sor. This compressor is signiﬁcantly more efﬁcient than conventional compressors. Due to the simplicity of its design, it offers improved reliability. Each compressor is mounted on rubber isolators for additional sound reduction. Continuous operation is approved down to 55°F (12.8°C) in the cooling mode. (See cooling performance tables.)

LIMITED WARRANTY —Standard 1-year warranty on all parts,

with an additional 9-year warranty on the compressor.

Form No. PDS 594D.18.7

DIA

/8-IN.

DIA KNOCKOUT (ALL SIZES)

/8-IN.

DIA KNOCKOUT

/8-IN.

PANEL

ACCESS

A97001

PAD DIMENSIONSABCDEFGHKLMN

MINIMUM MOUNTING

"



FIELD POWER SUPPLY CONN

(042 THRU 060 SIZES ONLY)

AND 1

HOLE WITH 1

DIA LIQUID

DIA VAPOR

LINE CONN



/8-IN.

LINE CONN

/16

DIA HOLE

/8-IN.

FIELD CONTROL

SUPPLY CONN



/16

AIR DISCHARGE

DIA TIEDOWN KNOCKOUTS

/8-IN.

(2) PLACES IN BASEPAN

clearance to service end of unit, 48 in. above unit, 6 in. on one side, 12 in. on remaining side,

/16

UNIT DIMENSIONS

DIMENSIONS (IN.)

and 24 in. between units for proper airflow.

Minimum outdoor operating ambient in cooling mode is 55°F (unless low-ambient control is used) max 125°F.2.

Series designation is the 14th position of the unit model number.3.

1. Allow 30 in.

Center of gravity .4.

AIR IN

NOTES:

AIR DISCHARGE

AIR IN

—2—

AIR IN

AIR DISCHARGE

SIZE SERIES

UNIT

018 E 23-13/16 22-1/2 26-3/16 4-1/8 7-1/8 13-13/16 18-3/8 5/8 12 14-5/8 10 2-3/8 20 x 27

024 E 27-13/16 22-1/2 26-3/16 4-1/8 7-1/8 15-15/16 22-3/8 5/8 12 14-5/8 11 2-3/8 20 x 27

030 E 27-13/16 22-1/2 26-3/16 4-1/8 7-1/8 15-15/16 22-3/8 3/4 12 14-5/8 11 2-3/8 20 X 27

036 E 27-13/16 30 33 5-1/16 9-11/16 15-15/16 22-3/8 3/4 16-1/4 20-3/8 11 2-15/16 26 X 32

042 E 33-13/16 30 33 5-1/16 9-11/16 21-15/16 28-3/8 7/8 16-1/4 20-3/8 13-1/2 2-15/16 26 X 32

048 E, F 33-13/16 30 33 5-1/16 9-11/16 21-15/16 28-3/8 7/8 16-3/4 20-3/8 13-1/2 2-15/16 26 x 32

060 E 39-13/16 30 33 5-1/16 9-11/16 27-15/16 34-3/8 7/8 16-3/4 20-3/8 15 2-15/16 26 x 32

RECOMMENDED TUBE DIAMETERS

LIQUID TUBE DIAMETER (IN.) VAPOR TUBE DIAMETER (IN.)

UNIT SIZE

018, 024 030, 036 3/4 7/8 042, 048 7/8 1-1/8

0 to 50 Ft

Tube Length Long-Line Applications*

3/8 3/8

0 to 50 Ft

Tube Length

Long-Line Applications*

5/8 3/4

(Maximum Diameter)

060 1-1/8 1-1/8

* For tube sets between 50 and 175 ft, consult Residential Split System Long-Line Application Guideline.

CHECK-FLO-RATER®

UNIT SIZE-SERIES

018, E 55 024, E 59 030, E 67 036, E 73 042, E 78 048, E,F 84 060, E 93

* Piston listed is for any approved non-capillary tube coil combination.

Piston is shipped with outdoor unit and must be installed in an approved indoor coil.

PISTON*

IDENTIFICATION NO.

UNIT SIZE

SOUND

LEVEL (dBA)

SOUND POWER (dBA)

OCTAVE BAND CENTER FREQUENCY (Hz)

125 250 500 1000 2000 4000 8000

018 72 54.5 63.0 65.5 66.0 63.5 59.0 51.5 024 74 51.5 61.0 62.5 65.5 62.0 58.5 52.5 030 74 57.0 64.0 67.0 69.0 64.0 60.0 52.5 036 76 59.0 66.0 67.0 69.5 66.5 62.5 56.0 042 76 58.0 65.0 67.5 69.0 65.5 61.0 54.0 048 78 60.0 64.0 68.5 68.5 67.5 64.5 59.5 060 78 61.5 64.5 69.0 70.0 68.0 66.0 60.5

CERTIFICATION APPLIES ONLY

REGISTERED QUALITY SYSTEM

WHEN THE COMPLETE SYSTEM

IS LISTED WITH ARI

—3—

SPECIFICATIONS

UNIT SIZE - SERIES

OPERA TING WT (Lb) 138 143 146 200

018-E 024-E 030-E 036-E

ELECTRICAL

Unit Volts—Hertz—Phase 208/230—60—1 208/230—60—1 208/230—60—1 208/230—60—1 Operating V oltage Range* 187—253 187—253 187—253 187—253 Compressor— Rated Load Amps 8.9 11.4 13.7 16.0

Locked Rotor Amps 41.0 56.0 72.5 88.0 Condenser Fan Motor—Full Load Amps 0.5 0.5 0.8 1.1 Min Unit Ampacity for Wire Sizing 11.6 14.8 17.9 21.1 Min Wire Size (60°C Copper) AWG† 14 14 14 12 Min Wire Size (75°C Copper) AWG† 14 14 14 12 Max Wire Length (60°C) (Ft)‡ 61 53 56 66 Max Wire Length (75°C) (Ft)‡ 58 50 53 63 Max Branch Circuit Fuse Size** 20 20 25 30

COMPRESSOR AND REFRIGERANT

Compressor—Manufacturer & Type Copeland Scroll Temperature & Current Protection Internal Line Break Refrigerant—R-22 Amount (Lb) 4.00 4.25 4.50 5.53

CONDENSER COIL AND FAN

Coil Face Area (Sq Ft) 7.27 8.8 12.0 Fins per In.—Rows—Circuits 20—1—1 25—1—2 Fan Motor—HP, Type, & RPM 1/12 PSC & 1100 1/10 PSC & 1100 1/5 PSC & 825 Volts—Hertz—Phase 208/230—60—1 Condenser Airﬂow (CFM) 1700 2000 3000

OPTIONAL EQUIPMENT

Support Feet Kit KSASF0101AAA Coastal Filter KAACF0601SML KAACF0201MED Time-Delay Relay KAATD0101TDR Cycle Protector KSACY0101AAA Crankcase Heater KAACH1201AAA Start Assist—Capacitor/Relay Type KSAHS1501AAA Start Assist—PTC Type KAACS0201PTC TXV Kit (RPB) KAATX0201RPB KAATX0301RPB KAATX0401RPB KAATX0501RPB TXV Kits (Hard Shutoff) KSATX0601HSO Low-Pressure Switch KAALP0101LPS High-Pressure Switch KSAHI0101HPS Filter Drier P502-8083S (RCD) Evaporator Freeze Thermostat†† KAAFT0101AAA Liquid-Line Solenoid Valve KAALS0101LLS Winter Start Control†† KAAWS0101AAA Low-Ambient Kit KSALA0201R22 Low-Ambient Controller P251-0083 (RCD) MotorMaster® Control‡‡ 32LT660004 (RCD) Ball Bearing Fan Motor HC34GE232 (RCD) HC38GE231 (RCD) Thermostat, Auto Changeover,

Non-Programmable, °F/°C, 1-Stage Heat, 1-Stage Cool TSTATBBNAC01-B

Thermostat, Auto Changeover,

7-Day Programmable, °F/°C, 1-Stage Heat, 1-Stage Cool TSTATBBPAC01-B

Builder’s Thermostat, Manual

Changeover, Non-Programmable, °F/°C, 1-Stage Heat, 1-Stage Cool TSTATBBBAC01-B

Thermidistat™ Control—Programmable/

Non-Programmable Thermostat with

Humidity Control TSTATBBPRH01-B Outdoor Air Temperature Sensor TSTATXXSEN01-B Backplate for Non-Programmable

Thermostat TSTATXXNBP01 Backplate for Builder’s Thermostat TSTATXXBBP01 Backplate for Programmable Thermostat TSTATXXPBP01 Thermostat Conversion Kit (4 to 5 wire)

— 10 Pack TSTATXXCNV10

See notes on page 5.

—4—

SPECIFICATIONS Continued

UNIT SIZE - SERIES

OPERA TING WT (Lb) 213 247 287

042-E 048-E/F 060-E

ELECTRICAL

Unit Volts—Hertz—Phase 208/230—60—1 208/230—60—1 208/230—60—1 Operating V oltage Range* 187—253 187—253 187—253 Compressor— Rated Load Amps 20.0 23.7/21.3 28.8

Locked Rotor Amps 104.0 129.0/137.0 169.0 Condenser Fan Motor—Full Load Amps 1.1 1.4 1.4 Min Unit Ampacity for Wire Sizing 26.1 31.0/28.0 37.4 Min Wire Size (60°C Copper) AWG† 10 8/10 8 Min Wire Size (75°C Copper) AWG† 10 10 8 Max Wire Length (60°C) (Ft)‡ 96 71 104 Max Wire Length (75°C) (Ft)‡ 91 68 99 Max Branch Circuit Fuse Size** 40 50/40 60

COMPRESSOR AND REFRIGERANT

Compressor—Manufacturer & Type Copeland Scroll Temperature & Current Protection Internal Line Break Refrigerant—R-22 Amount (Lb) 6.68 6.34 9.25

CONDENSER COIL AND FAN

Coil Face Area (Sq Ft) 15.2 18.3 Fins per In.—Rows—Circuits 25—1—3 25—1—4 Fan Motor—HP, Type, & RPM 1/5 PSC & 825 1/4 PSC & 1100 Volts—Hertz—Phase 208/230—60—1 Condenser Airﬂow (CFM) 3000 3300

OPTIONAL EQUIPMENT

Support Feet Kit KSASF0101AAA Coastal Filter KAACF0201MED Time-Delay Relay KAATD0101TDR Cycle Protector KSACY0101AAA Standard Crankcase Heater KAACH1201AAA Start Assist—Capacitor/Relay Type KSAHS1501AAA KSAHS1601AAA Start Assist—PTC Type KAACS0201PTC TXV Kit (RPB) KAATX0501RPB KAATX0601RPB KAATX0701RPB TXV Kits (Hard Shutoff) KSATX0601HSO KSATX0701HSO Low-Pressure Switch KAALP0101LPS High-Pressure Switch KSAHI0101HPS Filter Drier P502-8163S (RCD) Evaporator Freeze Thermostat†† KAAFT0101AAA Liquid-Line Solenoid Valve KAALS0101LLS Winter Start Control†† KAAWS0101AAA Low-Ambient Kit KSALA0201R22 Low-Ambient Controller P251-0083 (RCD) MotorMaster® Control‡‡ 32LT660004 (RCD) Ball Bearing Fan Motor HC38GE231 (RCD) HC40GE232 (RCD) Thermostat, Auto Changeover,

Non-Programmable, °F/°C, 1-Stage Heat, 1-Stage Cool TSTATBBNAC01-B

Thermostat, Auto Changeover,

7-Day Programmable, °F/°C, 1-Stage Heat, 1-Stage Cool TSTATBBPAC01-B

Builder’s Thermostat, Manual

Changeover, Non-Programmable, °F/°C, 1-Stage Heat, 1-Stage Cool TSTATBBBAC01-B

Thermidistat™ Control—Programmable/

Non-Programmable Thermostat with

Humidity Control TSTATBBPRH01-B Outdoor Air Temperature Sensor TSTATXXSEN01-B Backplate for Non-Programmable

Thermostat TSTATXXNBP01 Backplate for Builder’s Thermostat TSTATXXBBP01 Backplate for Programmable Thermostat TSTATXXPBP01 Thermostat Conversion Kit (4 to 5 wire)

— 10 Pack TSTATXXCNV10 * Permissible limits of the voltage range at which the unit will operate satisfactorily. Operation outside these limits may result in unit failure.

Copper wire must be used from service disconnect to unit.

† If wire is applied at ambient greater than 30°C (86°F), consult Table 310-16 of the NEC (ANSI/NFPA 70).

The ampacity of nonmetallic-sheathed cable (NM), trade name ROMEX, shall be that of 60°C (140°F) conductors, per the NEC (ANSI/NFPA 70) Article 336-26.

‡ Length shown is as measured 1 way along wire path between unit and service panel for a voltage drop not to exceed 2 percent.

All motors/compressors contain internal overload protection.

** Time-delay fuse. †† Use with Low-Ambient Controller. ‡‡ Fan motor with ball bearings required.

—5—

ACCESSORY USAGE GUIDELINE

REQUIRED FOR

LOW-AMBIENT

ACCESSORY

Crankcase Heater Yes Yes No

Evaporator Freeze Thermostat Yes No No

Winter Start Control

Accumulator No No No

Compressor Start Assist

Capacitor and Relay

Low-Ambient Controller

MotorMaster® Control

Liquid-Line Solenoid Valve

Ball Bearing Fan Motor Yes No No

Wind Bafﬂe See Low-Ambient Instructions No No Coastal Filter No No Yes Support Feet Recommended No Recommended

Hard Shutoff TXV

APPLICATIONS

(Below 55°F)

†

Yes

Yes Yes No

Yes N o No

* For tubing line sets between 50 and 175 ft, refer to Residential Split System Long-Line Application Guideline.

† Only when low-pressure switch is used.

REQUIRED FOR

LONG-LINE

APPLICATIONS*

(Over 50 Ft)

No No

See Long-Line

Application

Guideline

REQUIRED FOR

SEA COAST APPLICATIONS (Within 2 Miles)

ACCESSORY DESCRIPTION AND USAGE (Listed Alphabetically)

1. Ball Bearing Fan Motor

A fan motor with ball bearings which permits speed reduction while maintaining bearing lubrication.

SUGGESTED USE: Required on all units where Low-Ambient Controller (full modulation feature) or MotorMaster® Control has been added.

2. Coastal Filter

A mesh screen inserted under the top cover and inside the base pan to protect the condenser coil from corrosive atmosphere without restricting airﬂow.

SUGGESTED USE: In geographic areas where salt damage could occur.

3. Compressor Start Assist—Capacitor/Relay Type

Start capacitor and start relay gives “hard” boost to compressor motor at each start-up.

SUGGESTED USE: Installations where interconnecting tube length exceeds 50 ft.

4. Compressor Start Assist—PTC Type

Solid state electrical device which gives a ‘‘soft’’ boost to compressor motor at each start-up.

SUGGESTED USE: Installations with marginal power supply.

5. Crankcase Heater

An electric resistance heater which mounts to the base of the compressor to keep the lubricant warm during off cycles. Improves compressor lubrication on restart and minimizes chance of refrigerant slugging. May or may not include a thermostat control.

SUGGESTED USE: When interconnecting tube length exceeds 50 ft.

6. Cycle Protector

Solid state timing device which prevents compressor rapid recycling. Control provides an approximate 5-minute delay after power to the compressor has been interrupted for any reason, including normal room thermostat cycling.

SUGGESTED USE: Installations in areas where power interruptions are frequent.

7. Evaporator Freeze Thermostat

An SPST temperature actuated switch which stops unit operation when evaporator reaches freeze-up conditions.

SUGGESTED USE: All units where Winter Start Control has been added. Use with Low-Ambient Controller.

8. Filter Drier

A device for removing contaminants from refrigerant circulating in an air conditioner: 1 direction ﬂow.

SUGGESTED USE: All split-system air conditioners.

9. High-Pressure Switch

Auto reset SPST switch activ ated by refrigerant pressure on high side of refrigerant circuit. Cycles compressor off if refrigerant pressure rises to 400 ± 10 psig and resets at 298 ± 20 psig. Provides protection against compressor damage due to loss of outdoor airﬂow. To prevent rapid compressor recycling, Cycle Protector can be used with this switch.

SUGGESTED USE: Installations exposed to very ‘‘dirty’’ outdoor air.

10. Liquid-Line Solenoid Valve (LSV)

An electrically operated shutoff valve to be installed at the outdoor or indoor unit (depending on tubing conﬁguration) which stops and starts refrigerant liquid ﬂow in response to compressor operation. Maintains a column of refrigerant liquid ready for action at next compressor operation cycle.

Note: Compressor Start Assist—Capacitor/Relay Type must also be used. Do not use with hard shutoff TXV.

SUGGESTED USE: For improved system performance in air conditioners for certain combinations of indoor and outdoor units. Refer to ARI Unitary Directory.

In areas with high pollution levels.

Installations where outdoor design temperature exceeds 105°F (40.6°C). Replacement installations with hard shutoff expansion valve on indoor coil. Installations where Liquid-Line Solenoid Valve has been added.

Replacement installations with rapid pressure balance (RPB) expansion valve on indoor coil.

When unit will be operated below 55°F (12.8°C) outdoor air temperature. Use with Low-Ambient Controller. All commercial installations.

Where user is likely to “play” with the room thermostat. All commercial installations. Installations where interconnecting tube length exceeds 50 ft. High-rise applications.

Installations where condenser inlet air temperature exceeds 125°F (51.7°C).

In certain long-line applications. Refer to Residential Split System Long-Line Application Guideline.

—6—

ACCESSORY DESCRIPTION AND USAGE (Listed Alphabetically) Continued

11. Low-Ambient Controller

Head pressure controller is a cycle control device activated b y a temper ature sensor mounted on a header tube of the outdoor coil. It is designed to cycle the outdoor fan motor in order to maintain condensing temperature within normal operating limits (appro ximately 100°F high and 60°F low). The control will maintain working head pressure at low-ambient temperatures down to 0°F when properly installed.

SUGGESTED USE: Cooling operation at outdoor temperatures below 55°F (12.8°C).

12. Low-Pressure Switch

Auto reset SPST switch activ ated by refrigerant pressure on low side of refrigerant circuit. Cycles compressor off if refrigerant pressure drops to about 27 psig. Prevents indoor coil freeze-up due to loss of indoor airﬂow. Provides protection against compressor damage due to loss of refrigerant charge. To prevent rapid compressor recycling, Cycle Protector can be used with this switch.

SUGGESTED USE: Where indoor coil is exposed to ‘‘dirty’’ air.

13. MotorMaster® Control

A fan speed control device activated by a temperature sensor. Designed to control condenser fan motor speed in response to the saturated, condensing temperature during operation in cooling mode only. For outdoor temperatures down to –20°F, it maintains condensing temperature at 100°F ± 10°F.

SUGGESTED USE: Cooling operation at outdoor temperatures below 55°F.

14. Outdoor Air Temperature Sensor

A device that allows the temperature at a remote location (outdoors) to be displayed at the thermostat.

SUGGESTED USE: All corporate programmable thermostats.

15. Support Feet

Four stick-on plastic feet which raise the unit 4 in. above the mounting pad. This allows sand, dirt, and other debris to be ﬂushed from the unit base, minimizing corrosion.

SUGGESTED USE: Coastal installations.

16. Thermostatic Expansion Valve (TXV)

A modulating ﬂow control valve which meters refrigerant liquid ﬂow r ate into the evaporator in response to the superheat of the refrigerant gas leaving the evaporator. Kit includes valve, adapter tubes, and external equalizer tube. Both hard shutoff and RPB type valves are available.

SUGGESTED USE: For improved system performance in cooling mode for certain combinations of indoor and outdoor units. Refer to ARI Unitary Directory.

17. Time-Delay Relay

An SPST delay relay which brieﬂy continues operation of the indoor blower motor to provide additional cooling after the compressor cycles off.

SUGGESTED USE: For improved efﬁciency ratings for certain combinations of indoor and outdoor units. Refer to ARI Unitary Directory.

18. Winter Start Control

An SPST delay relay which bypasses the lo w-pressure switch f or approximately 3 min utes to permit start-up for cooling operation under low-load conditions.

SUGGESTED USE: All air conditioners where Low-Ambient Controller has been added.

All commercial installations.

Windy areas or where debris is normally circulating. Rooftop installations.

Required for use on all zoning systems.

—7—

UNIT

SIZE-SERIES

018-E

024-E

030-E

See notes on page 11.

COMBINATION RATINGS

SEER

FACTORY

INDOOR

MODEL

CK5A/CK5BA024* 17,600 NONE 10.50 11.00 11.00 10.60

CC5A/CD5AA018 17,200 NONE 10.50 11.00 11.00 10.45 CC5A/CD5AA024 17,600 NONE 10.50 11.00 11.00 10.60

CC5A/CD5AW024 17,600 NONE 10.50 11.00 11.00 10.60

CE3AA024 17,600 NONE 10.50 11.00 11.00 10.60 CK3BA024 17,600 NONE 10.50 11.00 11.00 10.60

CK5A/CK5BA018 17,200 NONE 10.50 11.00 11.00 10.45

CK5A/CK5BW024 17,600 NONE 10.50 11.00 11.00 10.60 F(A,B)4AN(F,C)018 16,800 TDR 11.00 — 11.00 10.40 F(A,B)4AN(F,C)024 17,600 TDR 11.00 — 11.00 10.75

FC4BNF024 17,600 TDR&TXV 11.00 — — 10.60 FF1(B,C,D)NA018 17,000 TDR 10.50 — 11.00 10.70 FF1(B,C,D)NA024 17,600 TDR 10.50 — 11.00 10.65

FG3AAA024 17,000 NONE 10.50 11.00 11.00 10.45

FK4CNF001 18,000 TDR&TXV 12.50 — — 12.05

FK4CNF002 18,000 TDR&TXV 12.50 — — 12.10

CC5A/CD5AA018 17,000 TDR 12.50 — 12.50 11.40 CC5A/CD5AA024 17,600 TDR 13.00 — 13.00 11.80 CK5A/CK5BA018 17,000 TDR 12.50 — 12.50 11.40 CK5A/CK5BA024 17,600 TDR 13.00 — 13.00 11.80

CC5A/CD5AW024 17,600 TDR 13.00 — 13.00 11.60 CK5A/CK5BW024 17,600 TDR 13.00 — 13.00 11.60

CC5A/CD5AW024 17,600 TDR 13.00 — 13.00 11.70

CK5A/CK5AW024 17,600 TDR 13.00 — 13.00 11.70

CC5A/CD5AA030* 23,000 NONE 10.80 11.00 11.00 9.80

CC5A/CD5AA024 23,000 NONE 10.80 11.00 11.00 9.70 CC5A/CD5AW024 23,000 NONE 10.80 11.00 11.00 9.70 CC5A/CD5AW030 23,200 NONE 10.80 11.00 11.00 9.80

CE3AA024 23,000 NONE 10.80 11.00 11.00 9.80 CE3AA030 23,200 NONE 11.00 11.30 11.30 9.80 CF5AA024 23,000 NONE 10.80 11.00 11.00 9.80 CK3BA024 23,000 NONE 10.80 11.00 11.00 9.70

CK3BA030 23,000 NONE 10.80 11.00 11.00 9.80 CK5A/CK5BA024 23,000 NONE 10.80 11.00 11.00 9.70 CK5A/CK5BA030 23,000 NONE 10.80 11.00 11.00 9.80

CK5A/CK5BW024 23,000 NONE 10.80 11.00 11.00 9.70

CK5A/CK5BW030 23,200 NONE 10.80 11.00 11.00 9.80 F(A,B)4AN(F,C)024 23,000 TDR 11.00 — 11.00 9.80 F(A,B)4AN(F,C)030 23,400 TDR 11.40 — 11.40 10.00

FC4BNF024 23,000 TDR & TXV 11.00 — — 9.80

FC4BNF030 23,400 TDR & TXV 11.40 — — 10.00 FF1(B,C,D))NA024 23,000 TDR 11.00 — 11.00 9.70 FF1(B,C,D))NA030 23,400 TDR 11.30 — 11.30 9.90

FG3AAA024 22,600 NONE 10.50 11.00 11.00 9.60

FK4CNF001 24,000 TDR & TXV 12.50 — — 10.95

FK4CNF002 24,200 TDR & TXV 12.70 — — 11.05

FK4CNF003 24,400 TDR & TXV 13.00 — — 11.30

CC5A/CD5AA030 23,200 TDR 12.00 — 12.00 10.75

CE3AA030 23,200 TDR 12.00 — 12.00 10.85

CK5A/CK5BA030 23,200 TDR 12.00 — 12.00 10.75

CC5A/CD5AA030 23,200 TDR 12.00 — 12.00 10.70

CK5A/CBA5030 23,200 TDR 12.00 — 12.00 10.70

CC5A/CD5AA030 23,200 TDR 12.00 — 12.00 10.70 CK5A/CK5BA030 23,200 TDR 12.00 — 12.00 10.70

CC5A/CD5AA036* 29,000 NONE 10.80 11.00 11.00 9.60

CC5A/CD5AA030 28,200 NONE 10.40 10.60 10.60 9.30

CC5A/CD5AW030 28,200 NONE 10.40 10.60 10.60 9.30

CD5AW036 29,000 NONE 10.80 11.00 11.00 9.60

CE3AA030 28,400 NONE 10.50 10.80 10.80 9.40 CE3AA036 28,800 NONE 10.60 11.00 11.00 9.50 CF5AA036 29,000 NONE 10.60 11.00 11.00 9.55 CK3BA030 28,200 NONE 10.40 10.60 10.60 9.30

CK3BA036 29,000 NONE 10.80 11.00 11.00 9.60 CK5A/CK5BA030 28,200 NONE 10.40 10.60 10.60 9.30 CK5A/CK5BA036 29,000 NONE 10.80 11.00 11.00 9.60

CK5A/CK5BW030 28,200 NONE 10.50 10.60 10.60 9.30

CK5A/CK5BW036 29,000 NONE 10.80 11.00 11.00 9.60 F(A,B)4AN(F,C)030 28,200 TDR 11.00 — 11.00 9.45 F(A,B)4AN(F,C)036 28,600 TDR 10.80 — 10.80 9.35

TOT. CAP.

BTUH

COILS + 333(B,J)AV036060 VARIABLE SPEED FURNACE

COILS + 355MAV042060 VARIABLE SPEED FURNACE

COILS + 355MAV042080 VARIABLE SPEED FURNACE

COILS + 333(B,J)AV036060 VARIABLE SPEED FURNACE

COILS + 355MAV042040 VARIABLE SPEED FURNACE

COILS + 355MAV042060 VARIABLE SPEED FURNACE

COILS + 355MAV042080 VARIABLE SPEED FURNACE

SUPPLIED

ENHANCE-

MENT

STANDARD

RATING

BRYANT GAS FURNACE OR

ACCESSORY

TDR†

ACCESSORY

TXV‡

EERA

—8—

UNIT

SIZE-SERIES

030-E

036-E

See notes on page 11.

COMBINATION RATINGS Continued

SEER

FACTORY

INDOOR

MODEL

FC4BNF030 28,200 TDR & TXV 11.00 — — 9.45 FC4BNF036 28,600 TDR & TXV 10.80 — — 9.35

FF1(B,C,D)NA030 28,400 TDR 11.00 — 11.00 9.40

FG3AAA036 28,600 NONE 10.50 10.80 10.80 9.40 FK4CNF001 29,200 TDR & TXV 11.50 — — 10.05 FK4CNF002 29,400 TDR & TXV 11.80 — — 10.10 FK4CNF003 29,600 TDR & TXV 12.00 — — 10.55

CC5A/CD5AA036 29,400 TDR 12.20 — 12.20 10.45

CE3AA036 29,000 TDR 12.00 — 12.00 10.30

CK5A/CK5BA036 29,400 TDR 12.00 — 12.00 10.45

CC5A/CD5AA036 29,400 TDR 12.20 — 12.20 10.45

CE3AA036 29,000 TDR 12.00 — 12.00 10.30

CK5A/CK5BA036 29,400 TDR 12.00 — 12.00 10.45

CC5A/CD5AA036 29,400 TDR 12.00 — 12.00 10.40 CK5A/CK5BA036 29,400 TDR 11.80 — 11.80 10.40

CC5A/CD5A036 29,400 TDR 12.00 — 12.00 10.40

CK5A/CK5BA036 29,400 TDR 11.80 — 11.80 10.40

CC5A/CD5AA036 29,400 TDR 12.00 — 12.00 10.40 CK5A/CK5BA036 29,400 TDR 12.00 — 12.00 10.40

CC5A/CD5AA042* 35,000 NONE 11.00 11.20 11.20 10.15

CC5A/CD5AA036 35,000 NONE 11.00 11.20 11.20 10.15

CC5A/CD5AW042 34,800 NONE 11.00 11.20 11.20 10.05

CD5AW036 35,000 NONE 11.00 11.20 11.20 10.15

CE3AA036 34,400 NONE 10.80 11.00 11.00 10.05 CE3AA042 35,000 NONE 11.00 11.20 11.20 10.20 CF5AA036 35,000 NONE 11.00 11.20 11.20 10.10 CK3BA036 35,000 NONE 11.00 11.20 11.20 10.15

CK3BA042 35,000 NONE 11.00 11.20 11.20 10.15 CK5A/CK5BA036 35,000 NONE 11.00 11.20 11.20 10.15 CK5A/CK5BA042 35,000 NONE 11.00 11.20 11.20 10.15

CK5A/CK5BW036 35,000 NONE 11.00 11.20 11.20 10.15 CK5A/CK5BW042 34,800 NONE 11.00 11.20 11.20 10.05

F(A,B)4AN(F,B,C))042 35,000 TDR 11.20 — 11.20 10.10

F(A,B)4AN(F,C)036 34,400 TDR 11.00 — 11.00 9.80

FC4BNB054 36,600 TDR & TXV 12.00 — — 10.80 FC4BNF036 34,400 TDR & TXV 11.00 — — 9.80

FC4BN(F,B)042 35,000 TDR & TXV 11.20 — — 10.10

FC4BNF038 36,000 TDR & TXV 11.50 — — 9.80 FG3AAA036 34,200 NONE 10.80 11.00 11.00 9.95 FK4CNB006 36,200 TDR & TXV 13.00 — — 10.65 FK4CNF001 34,600 TDR & TXV 11.50 — — 10.35 FK4CNF002 34,800 TDR & TXV 11.50 — — 10.35 FK4CNF003 35,000 TDR & TXV 12.00 — — 10.95 FK4CNF005 36,000 TDR & TXV 12.50 — — 11.40

CC5A/CD5AA042 34,600 TDR 12.00 — 12.00 10.75

CE3AA042 34,600 TDR 12.00 — 12.00 10.75 CK5A/CK5BA036 35,000 TDR 12.00 — 12.00 10.75

CC5A/CD5AA042 34,600 TDR 12.00 — 12.00 10.75

CE3AA042 34,600 TDR 12.00 — 12.00 10.75 CK5A/CK5BA042 35,000 TDR 12.00 — 12.00 10.75

CC5A/CD5AA042 34,600 TDR 12.00 — 12.00 10.75

CE3AA042 34,600 TDR 12.00 — 12.00 10.75 CK5A/CK5BA042 35,000 TDR 12.00 — 12.00 10.75

CC5A/CD5AA042 34,600 TDR 12.00 — 12.00 10.75

CE3AA042 34,600 TDR 12.00 — 12.00 10.75 CK5A/CK5BA042 35,000 TDR 12.00 — 12.00 10.75

CC5A/CD5AA042 34,600 TDR 12.00 — 12.00 10.75 CK5A/CK5BA042 35,000 TDR 12.00 — 12.00 10.75

CC5A/CD5AA042 34,600 TDR 12.00 — 12.00 10.75 CK5A/CK5BA042 34,600 TDR 12.00 — 12.00 10.75

CC5A/CD5AA042 34,600 TDR 12.00 — 12.00 10.75 CK5A/CK5BA042 35,000 TDR 12.00 — 12.00 10.75

CC5A/CD5AA042 34,600 TDR 12.00 — 12.00 10.75 CK5A/CK5BA042 34,600 TDR 12.00 — 12.00 10.75

TOT. CAP.

BTUH

COILS + 333(B,J)AV036060 VARIABLE SPEED FURNACE

COILS + 333(B,J)AV048080 VARIABLE SPEED FURNACE

COILS + 355MAV042040 VARIABLE SPEED FURNACE

COILS + 355MAV042060 VARIABLE SPEED FURNACE

COILS + 355MAV042080 VARIABLE SPEED FURNACE

COILS + 333(B,J)AV036060 VARIABLE SPEED FURNACE

COILS + 333(B,J)AV048080 VARIABLE SPEED FURNACE

COILS + 333(B,J)AV060100 VARIABLE SPEED FURNACE

COILS + 333(B,J)AV060120 VARIABLE SPEED FURNACE

COILS + 355MAV042040 VARIABLE SPEED FURNACE

COILS + 355MAV042060 VARIABLE SPEED FURNACE

COILS + 355MAV042080 VARIABLE SPEED FURNACE

COILS + 355MAV060100 VARIABLE SPEED FURNACE

SUPPLIED ENHANCE-

MENT

STANDARD

RATING

—9—

BRYANT GAS FURNACE OR

ACCESSORY

TDR†

ACCESSORY

TXV‡

EERA

UNIT

SIZE-SERIES

042-E

048-E/F

See notes on page 11.

COMBINATION RATINGS Continued

SEER

FACTORY

INDOOR

MODEL

CD5AA048* 41,000 NONE 11.00 11.50 11.50 10.25 CC5A/CD5AA042 41,000 NONE 11.00 11.50 11.50 10.25 CC5A/CD5AC048 40,500 NONE 11.00 11.50 11.50 10.15

CC5A/CD5AW042 40,500 NONE 11.00 11.50 11.50 10.15 CC5A/CD5AW048 41,000 NONE 11.00 11.50 11.50 10.25

CE3AA042 41,000 NONE 11.00 11.50 11.50 10.30 CE3AA048 41,500 NONE 11.00 11.50 11.50 10.35 CF5AA048 41,500 NONE 11.00 11.50 11.50 10.30 CK3BA042 41,000 NONE 11.00 11.50 11.50 10.25

CK3BA048 41,000 NONE 11.00 11.50 11.50 10.25 CK5A/CK5BA042 41,000 NONE 11.00 11.50 11.50 10.25 CK5A/CK5BA048 41,000 NONE 11.00 11.50 11.50 10.25

CK5A/CK5BW042 40,500 NONE 11.00 11.50 11.50 10.15

CK5A/CK5BW048 41,000 NONE 11.00 11.50 11.50 10.25 F(A,B)4AN(F,B,C)042 41,000 TDR 11.20 — 11.20 10.10 F(A,B)4AN(F,B,C)048 41,500 TDR 11.50 — 11.50 10.30

FC4BNB054 42,500 TDR & TXV 12.50 — — 10.95 FC4BN(F,B)042 41,000 TDR & TXV 11.20 — — 10.10 FC4BN(F,B)048 41,500 TDR & TXV 11.50 — — 10.30

FG3AAA048 41,000 NONE 11.00 11.50 11.50 10.25

FK4CNB006 42,500 TDR & TXV 13.00 — — 11.65

FK4CNF003 41,000 TDR & TXV 12.00 — — 10.85

FK4CNF005 42,000 TDR & TXV 12.50 — — 11.30

CD5AA048 41,000 TDR 12.50 — 12.50 11.10 CE3AA048 41,000 TDR 12.50 — 12.50 11.05

CK5A/CK5BA048 41,000 TDR 12.50 — 12.50 11.10

CD5AA048 41,000 TDR 12.50 — 12.50 11.10 CE3AA048 41,000 TDR 12.50 — 12.50 11.05

CK5A/CK5BA048 41,000 TDR 12.50 — 12.50 11.10

CD5AA048 41,000 TDR 12.50 — 12.50 11.10 CE3AA048 41,000 TDR 12.50 — 12.50 11.05

CK5A/CK5BA048 41,000 TDR 12.50 — 12.50 11.10

CD5AA048 41,000 TDR 12.50 — 12.50 11.15

CK5A/CK5BA048 41,000 TDR 12.00 — 12.00 11.15

CD5AA048 41,000 TDR 12.50 — 12.50 11.15

CK5A/CK5BA048 41,000 TDR 12.50 — 12.50 11.15

*CC5A/CD5AA060 46,800 NONE 10.60 11.00 11.00 9.65

CC5A/CD5AC048 45,000 NONE 10.50 10.80 10.80 9.50 CC5A/CD5AW048 46,000 NONE 10.50 11.00 11.00 9.60 CC5A/CD5AW060 48,000 NONE 10.80 11.20 11.20 9.85

CD5AA048 46,500 NONE 10.50 11.00 11.00 9.60 CE3AA048 46,500 NONE 10.70 11.00 11.00 9.70 CE3AA060 48,000 NONE 11.00 11.20 11.20 9.95 CF5AA048 46,500 NONE 10.70 11.10 11.10 9.70 CK3BA048 46,500 NONE 10.50 11.00 11.00 9.65

CK3BA060 46,800 NONE 10.60 11.00 11.00 9.85 CK5A/CK5BA048 46,500 NONE 10.50 11.00 11.00 9.65 CK5A/CK5BA060 46,800 NONE 10.60 11.00 11.00 9.85 CK5A/CK5BN048 45,000 NONE 10.50 11.00 11.00 9.65 CK5A/CK5BN060 47,000 NONE 10.50 11.00 11.00 10.05 CK5A/CK5BT048 46,500 NONE 10.50 11.00 11.00 9.65 CK5A/CK5BT060 46,800 NONE 10.60 11.00 11.00 9.85

CK5A/CK5BW048 46,500 NONE 10.50 11.00 11.00 9.65

CK5A/CK5BX060 48,000 NONE 10.80 11.20 11.20 10.05

F(A,B)4AN(F,B,C)048 46,500 TDR 11.00 — 11.00 9.60 F(A,B)4AN(F,B,C)060 48,000 TDR 11.00 — 11.00 9.70

FB4ANB070 48,000 TDR 11.50 — 11.50 10.00 FC4BN(F,B)048 47,000 TDR & TXV 11.00 — — 9.60 FC4BN(F,B)060 48,000 TDR & TXV 11.00 — — 9.70

FC4BNB054 48,000 TDR & TXV 11.50 — — 10.05

FC4BNB070 48,000 TDR & TXV 11.00 — — 10.00

FG3AAA048 46,000 NONE 10.50 10.80 10.80 9.60

FG3AAA060 47,500 NONE 10.70 11.00 11.00 9.80

FK4CNB006 48,500 TDR 12.50 — — 10.85

FK4CNF005 48,000 TDR 12.20 — — 10.55

CC5A/CD5AC048 45,000 TDR 11.00 — 11.00 9.65

CD5AA048 46,000 TDR 11.00 — 11.00 9.75 CK3BA048 46,000 TDR 11.00 — 11.00 9.80

CK5A/CK5BA048 46,000 TDR 11.00 — 11.00 9.80

CC5A/CD5AA060 47,000 TDR 11.50 — 11.50 10.25 CC5A/CD5AW048 46,000 TDR 11.20 — 11.20 10.10 CC5A/CD5AW060 47,000 TDR 12.00 — 12.00 10.55

CK3BA060 47,000 TDR 11.50 — 11.50 10.45

CK5A/CK5BA060 47,000 TDR 11.50 — 11.50 10.45 CK5A/CK5BW048 46,000 TDR 11.20 — 11.20 10.20

CK5A/CK5BX060 47,000 TDR 12.00 — 12.00 10.70

TOT. CAP.

BTUH

COILS + 333(B,J)AV048080 VARIABLE SPEED FURNACE

COILS + 333(B,J)AV060100 VARIABLE SPEED FURNACE

COILS + 333(B,J)AV060120 VARIABLE SPEED FURNACE

COILS + 355MAV042080 VARIABLE SPEED FURNACE

COILS + 355MAV060100 VARIABLE SPEED FURNACE

COILS + 333(B,J)AV048080 VARIABLE SPEED FURNACE

COILS + 333(B,J)AV060100 VARIABLE SPEED FURNACE

SUPPLIED

ENHANCE-

MENT

STANDARD

RATING

—10—

BRYANT GAS

FURNACE OR

ACCESSORY

TDR†

ACCESSORY

TXV‡

EERA

COMBINATION RATINGS Continued

SEER

FACTORY

UNIT

SIZE-SERIES

048-E/F

060-E

* Tested Combination

† In most cases, only 1 method should be used to achieve TDR function. Using more than 1 method in a system may cause degradation in performance. Use

either the accessory Time-Delay Rela y KAATD0101TDR or a furnace equipped with TDR. All Bryant furnaces are equipped with TDR e xcept f or the 394HAD .

‡ Based on computer simulation. TXV must be hard shutoff type.

NOTES: 1. Ratings are net values reﬂecting the effects of circulating fan motor heat. Supplemental electric heat is not included.

2. Tested outdoor/indoor combinations have been tested in accordance with DOE test procedures for central air conditioners. Ratings for other combinations are determined under DOE computer simulation procedures.

3. Determine actual CFM values obtainable for your system by referring to fan performance data in fan coil or furnace coil literature.

4. Minimum outdoor operating ambient in cooling mode is 55°F (12.8°C), maximum 125°F (51.7°C).

INDOOR

MODEL

CC5A/CD5AA060 46,500 TDR 11.50 — 11.50 10.15 CC5A/CD5AW048 46,000 TDR 11.20 — 11.20 10.05 CC5A/CD5AW060 47,000 TDR 12.00 — 12.00 10.45

CK3BA060 46,500 TDR 11.50 — 11.50 10.35

CK5A/CK5BA060 46,500 TDR 11.50 — 11.50 10.35 CK5A/CK5BW048 46,000 TDR 11.20 — 11.20 10.10

CK5A/CK5BX060 47,000 TDR 12.00 — 12.00 10.60

CD5AA048 46,000 TDR 11.00 — 11.00 9.70 CK3BA048 46,000 TDR 11.00 — 11.00 9.75

CK5A/CK5BA048 46,000 TDR 11.00 — 11.00 9.75

CC5A/CD5AA060 46,000 TDR 11.00 — 11.00 9.70 CC5A/CD5AW060 47,000 TDR 11.20 — 11.20 9.95

CD5AA048 46,000 TDR 11.00 — 11.00 9.60

CK3BA048 46,000 TDR 11.00 — 11.00 9.70 CK5A/CK5BA060 46,500 TDR 11.00 — 11.00 9.90 CK5A/CK5BX060 47,000 TDR 11.20 — 11.20 10.15 CK5A/CK5BA048 46,000 TDR 11.00 — 11.00 9.70

CC5A/CD5AA060 46,000 TDR 11.20 — 11.20 9.95 CC5A/CD5AC048 45,000 TDR 11.00 — 11.00 9.70

CC5A/CD5AW060 47,000 TDR 11.80 — 11.80 10.20

CD5AA048 46,000 TDR 11.00 — 11.00 9.90

CK3BA048 46,000 TDR 11.00 — 11.00 9.95

CK3BA060 46,500 TDR 11.20 — 11.20 10.15 CK5A/CK5BA048 46,000 TDR 11.00 — 11.00 9.95 CK5A/CK5BA060 46,000 TDR 11.20 — 11.20 10.40 CK5A/CK5BX060 47,000 TDR 11.80 — 11.80 10.40

CC5A/CD5AA060 46,000 TDR 11.20 — 11.20 9.95

CC5A/CD5AW048 46,000 TDR 11.20 — 11.20 9.90 CC5A/CD5AW060 47,000 TDR 11.80 — 11.80 10.25

CK3BA060 46,500 TDR 11.20 — 11.20 10.20 CK5A/CK5BA060 46,000 TDR 11.20 — 11.20 10.20

CK5A/CK5BW048 46,000 TDR 11.20 — 11.20 9.95

CK5A/CK5BX060 47,000 TDR 11.80 — 11.80 10.45

CC5A/CD5AW060* 56,500 NONE 10.80 11.00 11.00 9.70

CC5A/CD5AA060 54,500 NONE 10.60 10.80 10.80 9.55

CE3AA060 56,500 NONE 10.80 11.00 11.00 9.80 CK5A/CK5BA060 54,500 NONE 10.60 10.80 10.80 9.55 CK5A/CK5BX060 56,500 NONE 10.80 11.00 11.00 9.70

F(A,B)4AN(F,B,C)060 57,000 TDR 10.80 — 10.80 9.40

FB4ANB070 57,500 TDR 11.00 — 11.00 9.80 FC4BNB070 57,500 TDR & TXV 11.00 — — 9.80

FC4BN(F,B)060 57,000 TDR & TXV 10.80 — — 9.40

FG3AAA060 56,000 NONE 10.80 11.00 11.00 9.65 FK4CNB006 57,500 TDR & TXV 12.00 — — 10.30

CC5A/CD5AW060 56,500 TDR 11.80 — 11.80 10.30 CK5A/CK5BW060 56,500 TDR 11.80 — 11.80 10.30

TOT. CAP.

BTUH

COILS + 333(B,J)AV060120 VARIABLE SPEED FURNACE

COILS + 355MAV042080 VARIABLE SPEED FURNACE

COILS + 355MAV060080 VARIABLE SPEED FURNACE

COILS + 355MAV060100 VARIABLE SPEED FURNACE

COILS + 355MAV060120 VARIABLE SPEED FURNACE

COILS + 333(B,J)AV060100 VARIABLE SPEED FURNACE

SUPPLIED ENHANCE-

MENT

STANDARD

RATING

BRYANT GAS FURNACE OR

ACCESSORY

TDR†

ACCESSORY

TXV‡

EERA

—11—

DETAILED COOLING CAPACITIES*

EVAPORATOR

AIR

CFM EWB

85 95 105 115 125

Capacity

MBtuh†

Total

System

Kw**

Capacity

MBtuh†

594D018-E Outdoor Section With CK5A/CK5BA024 Indoor Section

72 19.6 9.74 1.48 18.9 9.46 1.66 18.1 9.17 1.85 17.4 8.90 2.00 16.6 8.60 2.33

525

600

675

See notes on page 18.

67 18.0 12.4 1.46 17.3 12.1 1.63 16.6 11.8 1.82 15.9 11.5 2.00 15.1 11.2 2.28 62 16.5 14.9 1.44 15.9 14.6 1.61 15.2 14.3 1.80 14.5 13.9 2.00 13.8 13.5 2.25 57 15.9 15.9 1.43 15.4 15.4 1.60 14.8 14.8 1.79 14.2 14.2 2.00 13.6 13.6 2.26

72 19.9 10.1 1.51 19.2 9.86 1.69 18.4 9.57 1.88 17.6 9.30 2.10 16.7 9.01 2.36 67 18.3 13.1 1.49 17.6 12.8 1.66 16.9 12.5 1.86 16.1 12.2 2.00 15.3 11.9 2.30 62 16.8 15.9 1.46 16.2 15.6 1.65 15.5 15.2 1.84 14.8 14.7 2.00 14.1 14.1 2.28 57 16.4 16.4 1.46 15.9 15.9 1.64 15.3 15.3 1.83 14.7 14.7 2.00 14.1 14.1 2.29

72 20.1 10.5 1.54 19.3 10.2 1.72 18.6 9.98 1.92 17.7 9.68 2.10 16.9 9.38 2.38 67 18.6 13.8 1.52 17.9 13.5 1.70 17.1 13.2 1.89 16.3 12.9 2.10 15.4 12.6 2.33 62 17.1 16.7 1.51 16.4 16.3 1.68 15.8 15.8 1.87 15.1 15.1 2.00 14.4 14.4 2.31 57 16.9 16.9 1.49 16.4 16.4 1.68 15.8 15.8 1.87 15.1 15.1 2.00 14.5 14.5 2.32

Multipliers for Determining the Performance With Other Indoor Sections

Indoor

Section Size

CC5A/CD5AA 018 0.98 1.00 FK4CNF 001 1.02 0.91

024 1.00 1.00 002 1.02 0.91

CC5A/CD5AW 024 1.00 1.00

CE3AA 024 1.00 1.00 CC5A/CD5AA 018 0.97 0.90 CK3BA 024 1.00 1.00 024 1.00 0.90

CK5A/CK5BA 018 0.98 1.00 CK5A/CK5BA 018 0.97 0.90

024 1.00 1.00 024 1.00 0.90

CK5A/CK5BW 024 1.00 1.00

F(A,B)4AN(F,C) 018 0.95 0.98 CC5A/CD5AW 024 1.00 0.93

024 1.00 0.99 CK5A/CK5BW 024 1.00 0.93

FC4BNF 024 1.00 1.01

FF1(B,C,D)NA 018 0.97 0.96 CC5A/CD5AW 024 1.00 0.92

024 1.00 1.00 CK5A/CK5AW 024 1.00 0.92

FG3AAA 024 0.97 1.00 — — —

Capacity Power Capacity Power

Cooling

CONDENSER ENTERING AIR TEMPERATURES °F

Total

System

Kw**

Capacity

MBtuh†

Indoor

Section Size

COILS + 333(B,J)AV036060 VARIABLE SPEED FURNACE

COILS + 355MAV042060 VARIABLE SPEED FURNACE

COILS + 355MAV042080 VARIABLE SPEED FURNACE

Total

System

Kw**

Capacity

MBtuh†

Total

System

Kw**

Capacity

MBtuh†

Cooling

Total

System

Kw**Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡

—12—

DETAILED COOLING CAPACITIES* Continued

EVAPORATOR

AIR

CFM EWB

85 95 105 115 125

Capacity

MBtuh†

Total

System

Kw**

Capacity

MBtuh†

594D024-E Outdoor Section With CC5A/CD5AA030 Indoor Section

72 25.7 12.8 2.11 24.7 12.4 2.34 23.7 12.1 2.59 22.7 11.7 2.8 21.6 11.3 3.17

700

800

900

See notes on page 18.

67 23.6 16.3 2.08 22.7 15.9 2.30 21.8 15.5 2.55 20.8 15.2 2.8 19.8 14.8 3.13 62 21.6 19.7 2.06 20.8 19.3 2.27 19.9 18.8 2.52 19.0 18.4 2.7 18.1 17.8 3.10 57 20.8 20.8 2.05 20.1 20.1 2.25 19.4 19.4 2.49 18.7 18.7 2.7 17.9 17.9 3.07

72 26.0 13.3 2.15 25.0 12.9 2.38 24.0 12.6 2.63 22.9 12.2 2.9 21.8 11.8 3.21 67 23.9 17.3 2.13 23.0 16.9 2.35 22.0 16.5 2.59 21.0 16.1 2.8 20.0 15.7 3.17 62 22.0 20.9 2.10 21.1 20.4 2.32 20.2 19.9 2.56 19.3 19.3 2.8 18.5 18.5 3.14 57 21.5 21.5 2.09 20.8 20.8 2.31 20.1 20.1 2.56 19.3 19.3 2.8 18.5 18.5 3.14

72 26.3 13.8 2.19 25.3 13.5 2.42 24.2 13.1 2.67 23.1 12.7 2.9 21.9 12.3 3.25 67 24.2 18.2 2.17 23.2 17.8 2.39 22.2 17.4 2.63 21.2 17.0 2.9 20.1 16.6 3.21 62 22.3 22.0 2.14 21.4 21.4 2.36 20.6 20.6 2.60 19.8 19.8 2.8 19.0 19.0 3.18 57 22.1 22.1 2.14 21.5 21.5 2.37 20.6 20.6 2.60 19.8 19.8 2.8 19.0 19.0 3.18

Multipliers for Determining the Performance With Other Indoor Sections

Indoor

Section Size

CC5A/CD5AA 024 1.00 1.00 FG3AAA 024 0.98 1.00

030 1.00 1.00 FK4CNF 001 1.04 0.94

CC5A/CD5AW 024 1.00 1.00 002 1.05 0.94

030 1.01 1.00 003 1.06 0.91

CE3AA 024 1.00 1.00

030 1.01 1.00 CC5A/CD5AA 030 1.01 0.92

CF5AA 024 1.00 1.00 CE3AA 030 1.01 0.92 CG5AA 024 1.00 1.00 CK5A/CK5BA 030 1.01 0.92 CK3BA 024 1.00 1.00

030 1.00 1.00 CC5A/CD5AA 030 1.01 0.94

CK5A/CK5BA 024 1.00 1.00 CK5A/CK5BA 030 1.01 0.94

030 1.00 1.00

CK5A/CK5BW 024 1.00 1.00 CC5A/CD5AA 030 1.01 0.94

F(A,B)4AN(F,C) 024 1.00 1.00 CK5A/CK5BA 030 1.01 0.94

030 1.02 0.99

FC4BNF 024 1.00 1.00 CC5A/CD5AA 030 1.01 0.94

030 1.02 0.99 CK5A/CK5BA 030 1.01 0.94

FF1(B,C,D)NA 024 1.00 1.01 — — —

030 1.02 1.01

Capacity Power Capacity Power

Cooling

CONDENSER ENTERING AIR TEMPERATURES °F

Total

System

Kw**

Capacity

MBtuh†

Indoor

Section Size

COILS + 333(B,J)AV036060 VARIABLE SPEED FURNACE

COILS + 355MAV042040 VARIABLE SPEED FURNACE

COILS + 355MAV042060 VARIABLE SPEED FURNACE

COILS + 355MAV042080 VARIABLE SPEED FURNACE

Total

System

Kw**

Capacity

MBtuh†

Total

System

Kw**

Capacity

MBtuh†

Cooling

Total

System

Kw**Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡

—13—

DETAILED COOLING CAPACITIES* Continued

EVAPORATOR

AIR

CFM EWB

85 95 105 115 125

Capacity

MBtuh†

Total

System

Kw**

Capacity

MBtuh†

594D030-E Outdoor Section With CC5A/CD5AA036 Indoor Section

72 32.5 16.1 2.58 31.2 15.6 2.97 29.8 15.1 3.42 28.3 14.5 3.9 26.3 13.8 5.04

875

1000

1125

See notes on page 18.

67 29.7 20.4 2.59 28.5 19.9 2.99 27.2 19.3 3.43 25.7 18.7 3.9 23.6 17.9 5.11 62 27.1 24.5 2.62 26.0 24.0 3.01 24.8 23.3 3.46 23.4 22.6 4.0 21.4 21.4 5.01 57 26.1 26.1 2.64 25.1 25.1 3.04 24.1 24.1 3.47 23.0 23.0 4.0 21.4 21.4 5.03

72 33.0 16.8 2.61 31.7 16.3 3.00 30.2 15.8 3.44 28.7 15.2 4.0 26.7 14.5 5.04 67 30.2 21.6 2.62 29.0 21.1 3.02 27.6 20.6 3.46 26.1 20.0 4.0 24.0 19.1 5.12 62 27.7 26.1 2.64 26.5 25.5 3.04 25.3 24.8 3.48 23.9 23.8 4.1 22.1 22.1 5.12 57 27.0 27.0 2.66 26.1 26.1 3.06 25.0 25.0 3.50 23.8 23.8 4.0 22.2 22.2 5.07

72 33.4 17.4 2.64 32.0 17.0 3.03 30.6 16.5 3.52 29.0 15.9 4.0 27.0 15.2 5.07 67 30.6 22.8 2.66 29.4 22.3 3.05 28.0 21.7 3.54 26.4 21.1 4.1 24.3 20.3 5.15 62 28.2 27.6 2.67 27.0 26.8 3.07 25.8 25.8 3.56 24.5 24.5 4.1 22.6 22.6 5.34 57 27.9 27.9 2.68 26.9 26.9 3.08 25.8 25.8 3.58 24.6 24.6 4.1 22.8 22.8 5.18

Multipliers for Determining the Performance With Other Indoor Sections

Indoor

Section Size

CC5A/CD5AA 030 0.97 1.00 FK4CNF 001 1.01 0.96

036 1.00 1.00 002 1.01 0.96

CC5A/CD5AW 030 0.97 1.00 003 1.02 0.92

CD5AW 036 1.00 1.00

CE3AA 030 0.98 1.00 CC5A/CD5AA 036 1.01 0.92

036 0.99 1.00 CE3AA 036 1.00 0.93 CF5AA 036 1.00 1.00 CK5A/CK5BA 036 1.01 0.93 CK3BA 030 0.97 1.00

036 1.00 1.00 CC5A/CD5AA 036 1.01 0.92

CK5A/CK5BA 030 0.97 1.00 CE3AA 036 1.00 0.93

036 1.00 1.00 CK5A/CK5BA 036 1.01 0.92

CK5A/CK5BW 030 0.97 1.00

036 1.00 1.00 CC5A/CD5AA 036 1.01 0.94

F(A,B)4AN(F,C) 030 0.97 0.99 CK5A/CK5BA 036 1.01 0.94

036 0.99 1.01

FC4BNF 030 0.97 0.99 CC5A/CD5AA 036 1.01 0.94

036 0.99 1.01 CK5A/CK5BA 036 1.01 0.96

FF1(B,C,D)NA 030 0.98 1.00

FG3AAA 036 0.99 1.00 CC5A/CD5AA 036 1.01 0.94

— — — CK5A/CK5BA 036 1.01 0.94

Capacity Power Capacity Power

Cooling

CONDENSER ENTERING AIR TEMPERATURES °F

Total

System

Kw**

Capacity

MBtuh†

Indoor

Section Size

COILS + 333(B,J)AV036060 VARIABLE SPEED FURNACE

COILS + 333(B,J)AV048080 VARIABLE SPEED FURNACE

COILS + 355MAV042040 VARIABLE SPEED FURNACE

COILS + 355MAV042060 VARIABLE SPEED FURNACE

COILS + 355MAV042080 VARIABLE SPEED FURNACE

Total

System

Kw**

Capacity

MBtuh†

Total

System

Kw**

Capacity

MBtuh†

Cooling

Total

System

Kw**Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡

—14—

DETAILED COOLING CAPACITIES* Continued

EVAPORATOR

AIR

CFM EWB

85 95 105 115 125

Capacity

MBtuh†

Total

System

Kw**

Capacity

MBtuh†

594D036-E Outdoor Section With CC5A/CD5AA042 Indoor Section

72 39.1 19.4 3.13 37.5 18.8 3.47 35.9 18.3 3.84 34.3 17.7 4.2 32.6 17.7 4.69

1050

1200

1350

F(A,B)4AN(F,B,C) 042 1.00 1.01 CC5A/CD5AA 042 0.99 0.93

See notes on page 18.

67 35.9 24.7 3.10 34.5 24.1 3.44 33.0 23.5 3.81 31.4 22.9 4.2 29.8 22.2 4.64 62 32.9 29.8 3.08 31.6 29.2 3.42 30.2 28.5 3.79 28.8 27.7 4.1 27.3 26.9 4.61 57 31.6 31.6 3.08 30.6 30.6 3.41 29.5 29.5 3.78 28.4 28.4 4.1 27.1 27.1 4.57

72 39.6 20.2 3.19 38.1 19.7 3.53 36.4 19.1 3.91 34.7 18.5 4.3 32.9 17.9 4.75 67 36.5 26.2 3.16 35.0 25.6 3.50 33.5 25.0 3.87 31.8 24.4 4.2 30.2 23.7 4.70 62 33.5 31.8 3.14 32.2 31.0 3.48 30.8 30.2 3.84 29.4 29.3 4.2 28.0 28.0 4.66 57 32.8 32.8 3.14 31.7 31.7 3.48 30.5 30.5 3.85 29.3 29.3 4.2 27.9 27.9 4.64

72 40.0 21.0 3.25 38.4 20.5 3.59 36.7 19.9 3.96 34.9 19.3 4.3 33.1 18.6 4.80 67 36.9 27.6 3.22 35.3 27.0 3.56 33.8 26.4 3.93 32.1 25.8 4.3 30.4 25.1 4.76 62 34.0 33.4 3.20 32.7 32.5 3.53 31.3 31.3 3.90 30.1 30.1 4.3 28.7 28.7 4.73 57 33.7 33.7 3.20 32.6 32.6 3.54 31.3 31.3 3.91 30.1 30.1 4.3 28.6 28.6 4.71

Multipliers for Determining the Performance With Other Indoor Sections

Indoor

Section Size

CC5A/CD5AA 036 1.00 1.00 CE3AA 042 0.99 0.95

042 1.00 1.00 CK5A/CK5BA 042 0.99 0.94

CC5A/CD5AW 042 0.99 1.00

CD5AW 036 1.00 1.00 CC5A/CD5AA 042 0.99 0.94 CE3AA 036 0.98 1.00 CE3AA 042 0.99 0.95

042 1.00 1.00 CK5A/CK5BA 042 0.99 0.94

CF5AA 036 1.00 1.00 CG5AA 036 1.00 1.00 CC5A/CD5AA 042 0.99 0.94 CK3BA 036 1.00 1.00 CE3AA 042 0.99 0.95

042 1.00 1.00 CK5A/CK5BA 042 0.99 0.94

CK5A/CK5BA 036 1.00 1.00

042 1.00 1.00 CC5A/CD5AA 042 0.99 0.94

CK5A/CK5BW 036 1.00 1.00 CE3AA 042 0.99 0.95

042 0.99 1.00 CK5A/CK5BA 042 0.99 0.94

F(A,B)4AN(F,C) 036 0.98 1.02

FC4BN(F,B) 042 1.00 1.01 CK5A/CK5BA 042 0.99 0.93

FC4BNB 054 1.05 1.00 FC4BNF 036 0.98 1.02 CC5A/CD5AA 042 0.99 0.93 FG3AAA 036 0.98 1.00 CK5A/CK5BA 042 0.99 0.93 FK4CNB 006 1.03 0.93 FK4CNF 001 0.99 0.98 CC5A/CD5AA 042 0.99 0.93

002 0.99 0.98 CK5A/CK5BA 042 0.99 0.93 003 1.00 0.93 005 1.03 0.94 CC5A/CD5AA 042 0.99 0.93

COILS + 333(B,J)AV036060 VARIABLE SPEED FURNACE CK5A/CK5BA 042 0.99 0.93

CC5A/CD5AA 042 0.99 0.94 — — —

Capacity Power Capacity Power

Cooling

CONDENSER ENTERING AIR TEMPERATURES °F

Total

System

Kw**

Capacity

MBtuh†

Indoor

Section Size

COILS + 333(B,J)AV048080 VARIABLE SPEED FURNACE

COILS + 333(B,J)AV060100 VARIABLE SPEED FURNACE

COILS + 333(B,J)AV060120 VARIABLE SPEED FURNACE

COILS + 355MAV042040 VARIABLE SPEED FURNACE

COILS + 355MAV042060 VARIABLE SPEED FURNACE

COILS + 355MAV042080 VARIABLE SPEED FURNACE

COILS + 355MAV060100 VARIABLE SPEED FURNACE

Total

System

Kw**

Capacity

MBtuh†

Total

System

Kw**

Capacity

MBtuh†

Cooling

Total

System

Kw**Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡

—15—

DETAILED COOLING CAPACITIES* Continued

EVAPORATOR

AIR

CFM EWB

85 95 105 115 125

Capacity

MBtuh†

Total

System

Kw**

Capacity

MBtuh†

594D042-E Outdoor Section With CC5A/CD5AA048 Indoor Section

72 45.8 22.5 3.61 44.0 21.9 3.99 42.3 21.2 4.42‘ 40.4 20.5 4.9 38.5 19.8 5.44

1225

1400

1575

F(A,B)4AN(F,B,C) 042 1.00 1.01

See notes on page 18.

67 42.0 28.4 3.57 40.4 27.8 3.95 38.7 27.1 4.38 37.1 26.4 4.8 35.3 25.7 5.40 62 38.4 34.2 3.54 36.9 33.5 3.91 35.4 32.7 4.34 33.8 32.0 4.8 32.3 31.1 5.36 57 36.6 36.6 3.53 35.4 35.4 3.91 34.2 34.2 4.33 33.0 33.0 4.8 31.8 31.8 5.36

72 46.5 23.4 3.68 44.7 22.7 4.06 42.8 22.1 4.49 40.9 21.4 4.9 38.9 20.7 5.51 67 42.7 30.0 3.64 41.0 29.3 4.02 39.3 28.7 4.45 37.5 27.9 4.9 35.7 27.2 5.46 62 39.1 36.4 3.61 37.5 35.5 3.98 35.9 34.7 4.41 34.4 33.8 4.8 32.8 32.7 5.42 57 37.9 37.9 3.60 36.6 36.6 3.98 35.4 35.4 4.41 34.1 34.1 4.8 32.7 32.7 5.43

72 47.0 24.3 3.75 45.1 23.6 4.13 43.2 22.9 4.56 41.3 22.2 5.0 39.2 21.5 5.57 67 43.2 31.6 3.71 41.5 30.9 4.09 39.7 30.2 4.51 37.9 29.5 4.9 36.1 28.8 5.53 62 39.6 38.3 3.68 38.1 38.3 4.05 36.5 36.3 4.48 35.0 35.0 4.9 33.6 33.6 5.49 57 39.0 39.0 3.67 37.7 37.7 4.05 36.4 36.4 4.48 35.0 35.0 4.9 33.6 33.6 5.50

Multipliers for Determining the Performance With Other Indoor Sections

Indoor

Section Size

CC5A/CD5AA 042 1.00 1.00 FK4CNF 003 1.00 0.95 CC5A/CD5AC 048 0.99 1.00 005 1.02 0.96 CC5A/CD5AW 042 0.99 1.00

048 1.00 1.00 CD5AA 048 1.00 0.93 CD5AA 048 1.00 1.00 CE3AA 048 1.00 0.94 CE3AA 042 1.00 1.00 CK5A/CK5BA 048 1.00 0.93

048 1.01 1.00 CF5AA 048 1.01 1.00 CD5AA 048 1.00 0.93 CK3BA 042 1.00 1.00 CE3AA 048 1.00 0.94

048 1.00 1.00 CK5A/CK5BA 048 1.00 0.93

CK5A/CK5BA 042 1.00 1.00

048 1.00 1.00 CD5AA 048 1.00 0.93

CK5A/CK5BW 042 0.99 1.00 CE3AA 048 1.00 0.94

048 1.00 1.00 CK5A/CK5BA 048 1.00 0.93

048 1.01 1.02 CD5A/CD5BA 048 1.00 0.92

FC4BN(F,B) 042 1.00 1.01 CK5A/CK5BA 048 1.00 0.92

048 1.01 1.02

FC4BNB 054 1.04 1.00 CD5AA 048 1.00 0.92 FG3AAA 048 1.00 1.00 CK5A/CK5BA 048 1.00 0.92 FK4CNB 006 1.04 0.94 — — —

Capacity Power Capacity Power

Cooling

CONDENSER ENTERING AIR TEMPERATURES °F

Total

System

Kw**

Capacity

MBtuh†

Indoor

Section Size

COILS + 333(B,J)AV048080 VARIABLE SPEED FURNACE

COILS + 333(B,J)AV060100 VARIABLE SPEED FURNACE

COILS + 333(B,J)AV060120 VARIABLE SPEED FURNACE

COILS + 355MAV042080 VARIABLE SPEED FURNACE

COILS + 355MAV060100 VARIABLE SPEED FURNACE

Total

System

Kw**

Capacity

MBtuh†

Total

System

Kw**

Capacity

MBtuh†

Cooling

Total

System

Kw**Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡

—16—

DETAILED COOLING CAPACITIES* Continued

EVAPORATOR

AIR

CFM EWB

85 95 105 115 125

Capacity

MBtuh†

Total

System

Kw**

Capacity

MBtuh†

594D048-E, F Outdoor Section With CC5A/CD5AA060 Indoor Section

72 52.3 25.6 4.37 50.2 24.8 4.90 47.9 24.0 5.48 45.6 23.1 6.11 43.1 22.2 6.78

1500

1700

1800

F(A,B)4AN(F,B,C) 048 0.99 1.02 CK5A/CK5BA 060 0.99 0.98

See notes on page 18.

67 48.3 32.5 4.35 46.3 31.7 4.87 44.2 30.8 5.45 42.1 29.9 6.08 39.8 29.0 6.73 62 44.4 39.2 4.34 42.5 38.3 4.86 40.6 37.3 5.43 38.5 36.2 6.05 36.5 35.1 6.70 57 42.0 42.0 4.29 40.5 40.5 4.81 39.0 39.0 5.38 37.4 37.4 5.99 35.7 35.7 6.64

72 53.1 26.6 4.45 50.8 25.8 4.97 48.5 24.9 5.55 46.1 24.1 6.19 43.5 23.1 6.86 67 49.1 34.2 4.42 47.0 33.4 4.95 44.8 32.5 5.52 42.5 31.6 6.15 40.2 30.6 6.81 62 45.1 41.5 4.41 43.2 40.5 4.93 41.2 39.4 5.50 39.1 38.2 6.12 37.1 36.8 6.78 57 43.4 43.4 4.37 41.8 41.8 4.89 40.2 40.2 5.46 38.5 38.5 6.08 36.8 36.8 6.73

72 53.4 27.0 4.49 51.1 26.2 5.01 48.7 25.4 5.59 46.3 24.5 6.22 43.7 23.6 6.90 67 49.3 35.0 4.46 47.3 34.2 4.98 45.1 33.3 5.56 42.8 32.4 6.19 40.4 31.4 6.85 62 45.4 42.5 4.44 43.5 41.5 4.97 41.5 40.3 5.54 39.4 39.0 6.16 37.4 37.4 6.82 57 44.0 44.0 4.41 42.4 42.4 4.93 40.8 40.8 5.50 39.1 39.1 6.12 37.3 37.3 6.78

Multipliers for Determining the Performance With Other Indoor Sections

Indoor

Section Size

CC5A/CD5AA 060 1.00 1.00 CK5A/CK5BX 060 1.00 0.94

CC5A/CD5AC 048 0.96 0.99

CC5A/CD5AW 048 0.98 1.00 CC5A/CD5AA 060 0.99 0.95

060 1.03 1.00 CC5A/CD5AW 048 0.98 0.95 CD5AA 048 0.99 1.00 060 1.00 0.95 CE3AA 048 0.99 1.00 CK3BA 060 0.99 0.95

060 1.03 1.00 CK5A/CK5BA 060 0.99 0.95 CF5AA 048 0.99 0.99 CK5A/CK5BW 048 0.98 0.95 CK3BA 048 0.99 1.00 CK5A/CK5BX 060 1.00 0.95

060 1.00 1.00

CK5A/CK5BA 048 0.99 1.00 CD5AA 048 0.98 0.97

060 1.00 1.00 CK3BA 048 0.98 0.97

CK5A/CK5BN 048 0.96 0.98 CK5A/CK5BA 048 0.98 0.97

060 1.00 1.00

CK5A/CK5BT 048 0.99 1.00 CC5A/CD5AA 060 0.98 0.98

060 1.00 1.00 CC5A/CD5AW 060 1.00 0.98

CK5A/CK5BW 048 0.99 1.00 CD5AA 048 0.98 0.98

CK5A/CK5BX 060 1.03 1.00 CK3BA 048 0.98 0.98

060 1.03 1.03 CK5A/CK5BX 060 1.00 0.98

FB4ANB 070 1.03 1.02 CK5ACK5BA 048 0.98 0.98

FC4BN(F,B) 048 1.00 1.02

060 1.03 1.03 CC5A/CD5AA 060 0.98 0.96

FC4BNB 070 1.03 1.02 CC5A/CD5AC 048 0.96 0.97 FG3AAA 048 0.98 1.00 CC5A/CD5AW 060 1.00 0.96

060 1.01 1.00 CD5AA 048 0.98 0.96

FK4CNB 006 1.04 0.94 CK3BA 048 0.98 0.96 FK4CNF 005 1.03 0.95 060 0.99 0.96

COILS + 333(B,J)AV048080 VARIABLE SPEED FURNACE CK5A/CK5BA 048 0.98 0.96

CC5A/CD5AC 048 0.96 0.97 CK5A/CK5BA 060 0.98 0.96

CD5AA 048 0.98 0.97 CK5A/CK5BX 060 1.00 0.96 CK3BA 048 0.98 0.97

CK5A/CK5BA 048 0.98 0.97 CC5A/CD5AA 060 0.98 0.96

COILS + 333(B,J)AV060100 VARIABLE SPEED FURNACE CC5A/CD5AW 048 0.98 0.96

CC5A/CD5AA 060 1.00 0.94 060 1.00 0.96

CC5A/CD5AW 048 0.98 0.94 CK3BA 060 0.99 0.96

060 1.00 0.94 CK5A/CK5BA 060 0.98 0.96 CK3BA 060 1.00 0.94 CK5A/CK5BW 048 0.98 0.96

CK5A/CK5BA 060 1.00 0.94 CK5A/CK5BX 060 1.00 0.96

CK5A/CK5BW 048 0.98 0.94 — — —

Capacity Power Capacity Power

Cooling

CONDENSER ENTERING AIR TEMPERATURES °F

Total

System

Kw**

Capacity

MBtuh†

Indoor

Section Size

COILS + 333(B,J)AV060120 VARIABLE SPEED FURNACE

COILS + 355MAV042080 VARIABLE SPEED FURNACE

COILS + 355MAV060080 VARIABLE SPEED FURNACE

COILS + 355MAV060100 VARIABLE SPEED FURNACE

COILS + 355MAV060120 VARIABLE SPEED FURNACE

Total

System

Kw**

Capacity

MBtuh†

Total

System

Kw**

Capacity

MBtuh†

Cooling

Total

System

Kw**Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡

—17—

DETAILED COOLING CAPACITIES* Continued

EVAPORATOR

AIR

CFM EWB

85 95 105 115 125

Capacity

MBtuh†

Total

System

Kw**

Capacity

MBtuh†

594D060-E Outdoor Section With CC5A/CD5AW060 Indoor Section

72 63.4 31.4 5.42 61.0 30.4 5.88 58.2 29.4 6.35 54.9 28.2 6.7 50.9 26.8 7.13

1750

2000

2250

F(A,B)4AN(F,B,C) 060 1.01 1.04 CC5A/CD5AW 060 1.00 0.94

* Detailed cooling capacities are based on indoor and outdoor unit at the same elevation per ARI Standard 210/240-94. If additional tubing length and/or indoor

† Total and sensible capacities are net capacities. Blower motor heat has been subtracted. ‡ Sensible capacities shown are based on 80°F (27°C) entering air at the indoor coil. For sensible capacities at other than 80°F (27°C), deduct 835 Btuh

** Unit kw is total of indoor and outdoor unit kilowatts.

67 57.8 39.6 5.36 55.4 38.6 5.79 52.5 37.5 6.21 49.0 36.1 6.5 44.8 34.4 6.76 62 52.4 47.6 5.28 49.9 46.4 5.68 46.9 44.8 6.02 43.4 42.8 6.2 39.7 39.7 6.37 57 50.2 50.2 5.20 48.2 48.2 5.59 45.9 45.9 5.93 43.2 43.2 6.2 40.1 40.1 6.37

72 64.7 32.8 5.44 62.1 31.8 5.91 59.3 30.8 6.38 56.0 29.7 6.8 52.1 28.3 7.22 67 59.0 42.0 5.38 56.5 41.0 5.82 53.6 39.9 6.26 50.2 38.5 6.6 46.1 37.0 6.89 62 53.6 50.7 5.31 51.1 49.4 5.72 48.3 47.6 6.10 45.1 45.1 6.3 41.9 41.9 6.59 57 52.2 52.2 5.24 50.3 50.3 5.65 48.0 48.0 6.03 45.4 45.4 6.3 42.3 42.3 6.57

72 65.7 34.1 5.34 62.9 33.1 5.93 60.1 32.1 6.42 56.9 31.0 6.8 53.0 29.7 7.30 67 60.0 44.4 5.28 57.4 43.3 5.86 54.5 42.2 6.30 51.2 40.9 6.7 47.0 39.3 7.00 62 54.6 53.4 5.34 52.2 51.8 5.77 49.6 49.6 6.17 46.9 46.9 6.5 43.7 43.7 6.76 57 54.0 54.0 5.27 52.0 52.0 5.69 49.8 49.8 6.10 47.2 47.2 6.4 44.0 44.0 6.74

Multipliers for Determining the Performance With Other Indoor Sections

Indoor

Section Size

CC5A/CD5AA 060 0.96 0.98 FC4BNB 070 1.02 1.02 CC5A/CD5AW 060 1.00 1.00 FC4BN(F,B) 060 1.01 1.04

CE3AA 060 1.00 1.00 FG3AAA 060 0.99 1.00 CK5A/CK5BA 060 0.96 0.98 FK4CNB 006 1.02 0.97 CK5A/CK5BX 060 1.00 1.00

FB4ANB 070 1.02 1.02 CK5A/CK5BW 060 1.00 0.94

unit is located above outdoor unit, a slight variation in capacity may occur.

(245 kw) per 1000 CFM (480 L/S) of indoor coil air for each degree below 80°F (27°C), or add 835 Btuh (245 kw) per 1000 CFM (480 L/S) of indoor coil air per degree above 80°F (27°C). When the required data falls between the published data, interpolation may be performed.

Capacity Power Capacity Power

Cooling

CONDENSER ENTERING AIR TEMPERATURES °F

Total

System

Kw**

Capacity

MBtuh†

Indoor

Section Size

COILS + 333(B,J)AV060100 VARIABLE SPEED FURNACE

Total

System

Kw**

Capacity

MBtuh†

Total

System

Kw**

Capacity

MBtuh†

Cooling

Total

System

Kw**Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡

—18—

SST

°F

See notes on page 20.

CONDENSER ONLY RATINGS*

CONDENSER ENTERING AIR TEMPERATURES °F

55 65 75 85 95 105 115

594D018-E

TCG SDT 77.1 86.9 96.8 107.0 116.00 126.0 136.0

KW 0.809 0.930 1.07 1.22 1.38 1.55 1.74

TCG SDT 78.3 88.0 97.8 108.0 117. 127.0 137.0

KW 0.824 0.944 1.08 1.23 1.40 1.57 1.77

TCG SDT 79.8 89.4 99.2 109.0 119.0 128.0 138.0

KW 0.841 0.962 1.10 1.25 1.42 1.60 1.79

TCG SDT 81.6 91.0 101.0 110.0 120.0 130.0 139.0

KW 0.863 0.983 1.12 1.27 1.44 1.62 1.82

TCG SDT 83.5 92.8 102.0 112.0 122.0 131.0 141.0

KW 0.887 1.01 1.15 1.30 1.47 1.65 1.85

TCG SDT 85.5 94.7 104.0 114.0 123.0 133.0 142.0

KW 0.914 1.03 1.17 1.33 1.50 1.68 1.89

16.9 16.2 15.4 14.6 13.8 12.9 12.0

18.6 17.8 16.9 16.1 15.2 14.3 13.4

20.3 19.4 18.6 17.7 16.7 15.8 14.8

22.1 21.2 20.3 19.3 18.3 17.3 16.3

24.0 23.1 22.1 21.1 20.0 19.0 17.8

26.1 25.1 24.0 22.9 21.8 20.7 19.5

594D024-E

TCG 22.1 21.1 20.1 19.0 17.8 16.8 15.8 SDT 81.1 90.3 99.6 109.0 119.0 128.0 138.0

KW 1.25 1.40 1.57 1.75 1.96 2.18 2.44

TCG 24.2 23.2 22.1 21.0 19.8 18.6 17.5 SDT 83.1 92.3 102.0 111.0 120.0 130.0 139.0

KW 1.26 1.42 1.59 1.78 1.99 2.21 2.47

TCG 26.4 25.4 24.3 23.1 21.8 20.6 19.3 SDT 85.3 94.4 104.0 113.0 122.0 131.0 141.0

KW 1.28 1.44 1.62 1.81 2.02 2.25 2.51

TCG 28.6 27.7 26.5 25.3 24.0 22.6 21.3 SDT 87.6 96.6 106.0 115.0 124.0 133.0 143.0

KW 1.29 1.46 1.64 1.84 2.05 2.29 2.55

TCG 31.0 30.1 28.9 27.6 26.3 24.8 23.4 SDT 90.0 99.0 108.0 117.0 126.0 135.0 145.0

KW 1.30 1.48 1.66 1.87 2.09 2.33 2.60

TCG 33.5 32.5 31.4 30.0 28.6 27.1 25.6 SDT 92.7 101.0 110.0 120.0 129.0 138.0 147.0

KW 1.32 1.49 1.69 1.90 2.13 2.38 2.65

594D030-E

TCG 28.3 27.0 25.7 24.2 22.8 21.2 19.7 SDT 80.4 90.3 100.0 110.0 120.0 130.0 140.0

KW 1.47 1.72 1.99 2.30 2.63 2.99 3.34

TCG 31.0 29.6 28.2 26.7 25.1 23.5 21.8 SDT 82.0 91.9 102.0 112.0 122.0 132.0 142.0

KW 1.46 1.71 1.99 2.30 2.64 3.00 3.39

TCG 33.9 32.4 30.9 29.3 27.6 25.9 24.1 SDT 83.8 93.6 104.0 113.0 123.0 133.0 144.0

KW 1.45 1.70 1.99 2.30 2.65 3.02 3.42

TCG 36.9 35.3 33.7 32.0 30.2 28.4 26.5 SDT 85.7 95.5 105.0 115.0 125.0 135.0 145.0

KW 1.44 1.70 1.98 2.30 2.66 3.04 3.45

TCG 40.1 38.4 36.7 34.9 33.0 31.0 29.0 SDT 87.8 97.4 107.0 117.0 127.0 137.0 147.0

KW 1.43 1.69 1.98 2.31 2.66 3.05 3.47

TCG 43.5 41.7 39.8 37.9 35.9 33.8 31.7 SDT 90.0 99.7 109.0 119.0 129.0 139.0 149.0

KW 1.43 1.69 1.98 2.31 2.67 3.07 3.50

594D036-E

TCG 33.8 32.3 30.7 29.1 27.4 25.7 23.9 SDT 77.3 87.0 96.9 107.0 117.0 126.0 136.0

KW 1.87 2.11 2.37 2.66 2.98 3.32 3.68

TCG 37.0 35.4 33.8 32.0 30.3 28.4 26.6 SDT 78.6 88.3 98.1 108.0 118.0 128.0 137.0

KW 1.89 2.12 2.39 2.68 3.00 3.35 3.72

TCG 40.5 38.8 37.0 35.2 33.3 31.3 29.4 SDT 80.3 89.8 99.5 109.0 119.0 129.0 139.0

KW 1.91 2.14 2.41 2.70 3.03 3.39 3.76

TCG 44.1 42.3 40.5 38.5 36.5 34.4 32.3 SDT 82.1 91.5 101.0 111.0 121.0 130.0 140.0

KW 1.93 2.17 2.44 2.73 3.06 3.42 3.81

TCG 48.0 46.1 44.1 42.0 39.9 37.7 35.4 SDT 84.0 93.3 103.0 112.0 122.0 132.0 142.0

KW 1.96 2.20 2.47 2.76 3.10 3.46 3.86

TCG 52.1 50.0 47.9 45.7 43.4 41.1 38.6 SDT 86.1 95.3 105.0 114.0 124.0 133.0 143.0

KW 1.99 2.23 2.50 2.80 3.14 3.50 3.91

—19—

CONDENSER ONLY RATINGS* Continued

SST

°F

55 65 75 85 95 105 115

CONDENSER ENTERING AIR TEMPERATURES °F

594D042-E

TCG 39.4 37.6 35.7 33.9 32.0 30.2 28.4 SDT 77.0 86.9 96.8 107.0 117.0 127.0 137.0

KW 2.17 2.43 2.72 3.04 3.40 3.81 4.26

TCG 43.3 41.4 39.4 37.4 35.4 33.4 31.4 SDT 78.5 88.2 98.0 108.0 118.0 128.0 138.0

KW 2.19 2.45 2.74 3.07 3.43 3.84 4.30

TCG 47.5 45.4 43.3 41.1 39.0 36.8 34.6 SDT 80.0 89.7 99.5 109.0 119.0 129.0 139.0

KW 2.21 2.48 2.77 3.10 3.47 3.88 4.34

TCG 51.8 49.6 47.4 45.1 42.7 40.4 38.1 SDT 81.7 91.4 101.0 111.0 121.0 131.0 141.0

KW 2.24 2.51 2.80 3.14 3.51 3.92 4.39

TCG 56.4 54.1 51.7 49.2 46.7 44.2 41.7 SDT 83.6 93.2 103.0 113.0 122.0 132.0 142.0

KW 2.27 2.54 2.84 3.18 3.55 3.97 4.44

TCG 61.2 58.8 56.2 53.6 51.0 48.3 45.6 SDT 85.6 95.1 105.0 114.0 124.0 134.0 144.0

KW 2.31 2.58 2.88 3.22 3.60 4.03 4.50

594D048-E, F

TCG 46.0 43.8 41.6 39.3 36.9 34.4 32.0 SDT 80.1 89.8 99.6 109.0 119.0 129.0 139.0

KW 2.46 2.82 3.22 3.65 4.13 4.64 5.17

TCG 50.4 48.1 45.7 43.2 40.7 38.1 35.5 SDT 81.9 91.6 101.0 111.0 121.0 131.0 140.0

KW 2.49 2.85 3.25 3.69 4.18 4.71 5.25

TCG 55.1 52.6 50.1 47.4 44.7 41.9 39.1 SDT 83.9 93.4 103.0 113.0 123.0 132.0 142.0

KW 2.52 2.88 3.29 3.74 4.23 4.77 5.34

TCG 60.0 57.4 54.7 51.9 49.0 46.0 43.0 SDT 86.0 95.5 105.0 115.0 124.0 134.0 144.0

KW 2.55 2.92 3.33 3.79 4.29 4.84 5.43

TCG 65.2 62.4 59.6 56.6 53.5 50.3 47.1 SDT 88.3 97.7 107.0 117.0 126.0 136.0 146.0

KW 2.59 2.96 3.38 3.84 4.35 4.91 5.51

TCG 70.7 67.7 64.6 61.5 58.2 54.8 51.3 SDT 90.7 100.0 109.0 119.0 128.0 138.0 148.0

KW 2.64 3.01 3.43 3.90 4.42 4.98 5.60

594D060-E

* ARI listing applies only to systems shown in Performance Data table.

KW — Total Power (Kw) SDT — Saturated Temperature Leaving Compressor (°F) SST — Saturated Temperature Entering Compressor (°F) TCG — Gross Cooling Capacity (1000 Btuh)

TCG 55.1 52.7 50.1 47.4 44.8 42.2 39.5 SDT 80.2 89.9 99.7 109.0 119.0 129.0 139.0

KW 3.06 3.44 3.86 4.34 4.87 5.46 6.07

TCG 60.3 57.7 55.0 52.1 49.2 46.4 43.5 SDT 82.1 91.8 101.0 111.0 121.0 131.0 141.0

KW 3.10 3.49 3.92 4.40 4.93 5.53 6.17

TCG 65.7 63.0 60.1 57.1 54.0 50.9 47.8 SDT 84.1 93.7 103.0 113.0 123.0 133.0 143.0

KW 3.16 3.55 3.99 4.47 5.01 5.61 6.27

TCG 71.4 68.6 65.6 62.3 59.0 55.6 52.3 SDT 86.3 95.9 105.0 115.0 125.0 135.0 144.0

KW 3.21 3.62 4.06 4.55 5.09 5.69 6.36

TCG 77.4 74.5 71.3 67.8 64.3 60.6 57.0 SDT 88.6 98.1 108.0 117.0 127.0 136.0 146.0

KW 3.28 3.69 4.14 4.64 5.19 5.79 6.46

TCG 83.8 80.7 77.3 73.7 69.9 66.0 62.0 SDT 91.1 101.0 110.0 120.0 129.0 139.0 148.0

KW 3.35 3.77 4.23 4.74 5.29 5.90 6.58

—20—

SYSTEM DESIGN SUMMARY

1. Intended for outdoor installation with free air inlet and outlet. Outdoor fan external static pressure available is less than 0.01 in. wc.

2. Minimum outdoor operating air temperature without low-ambient operation accessory is 55°F (12.8°C).

3. Maximum outdoor operating air temperature is 125°F (51.7°C).

4. For reliable operation, unit should be level in all horizontal planes.

5. Maximum elevation of indoor coil above or below base of outdoor unit is: Indoor coil above = 50 ft. Indoor coil below = 150 ft.

6. For interconnecting refrigerant tube lengths greater than 50 ft, consult Residential Split System Long-Line Application Guidelines available from equipment distributor.

7. Crankcase heater required when interconnecting refrigerant tube length exceeds 50 ft.

8. Not more than 3 ft of refrigerant tube should be buried in the ground. If necessary to bury tubes under a sidewalk, provide a minimum 6-in. vertical rise to the valve connections at the unit. For buried lines longer than 3 ft, consult your local distributor.

9. Use only copper wire for electric connection at unit. Aluminum and clad aluminum are not acceptable for the type of connector provided.

10. Mix-matches of indoor coil capacity more than 1 size larger than outdoor unit capacity may result in inadequate indoor comfort.

11. Do not apply capillary tube indoor coils to these units.

—21—

MATCHED SYSTEM

A98599

—22—

—23—

GUIDE SPECIFICATIONS

Air-Cooled, Split-System

Air Conditioner

594D

1-1/2 to 5 Tons Nominal

GENERAL

System Description

Outdoor-mounted, air-cooled, split-system air conditioner unit suitable for ground or rooftop installation. Unit consists of a hermetic compressor, an air-cooled coil, propeller-type condenser fan, and a control box. Unit will discharge supply air upward as shown on contract drawings. Unit will be used in a refrigeration circuit to match up to a packaged fan coil or coil unit.

Quality Assurance

Unit will be rated in accordance with the latest edition of ARI Standard 210.

Unit will be certiﬁed for capacity , efﬁciency , and listed in the latest ARI directory.

Unit construction will comply with latest edition of ANSI/ ASHRAE and with NEC.

Unit will be constructed in accordance with UL standards and will carry the UL label of approval. Unit will ha v e c-UL appro v al.

Unit cabinet will be capable of withstanding Federal Test Method Standard No. 141 (Method 6061) 500-hr salt spray test.

Air-cooled condenser coils will be leak tested at 150 psig and pressure tested at 300 psig.

Unit constructed in ISO 9001 approved facility.

Delivery, Storage, and Handling

Unit will be shipped as single package only and is stored and handled per unit manufacturer’s recommendations.

Warranty (for inclusion by specifying engineer)

U.S. and Canada only.

PRODUCTS

Equipment

Factory assembled, single piece, air-cooled air conditioner unit. Contained within the unit enclosure will be all factory wiring, piping, controls, compressor, refrigerant charge (R22), and special features required prior to ﬁeld start-up.

Unit Cabinet Unit cabinet will be constructed of galvanized steel, bonderized,

and coated with a powder coat paint. F

ans

Condenser fan will be direct-drive propeller type, discharging air upward.

Condenser fan motors will be totally enclosed, 1-phase type with class B insulation and permanently lubricated bearings.

Shafts will be corrosion resistant. Fan blades will be statically and dynamically balanced. Condenser fan openings will be equipped with steel wire safety

guards. Compressor Compressor will be hermetically sealed. Compressor will be mounted on rubber vibration isolators. Condenser Coil Condenser coil will be air cooled. Coil will be constructed of aluminum ﬁns mechanically bonded

to copper tubes which are then cleaned, dehydrated, and sealed.

Refr

igeration Components

Refrigeration circuit components will include liquid-line shutoff valve with sweat connections, suction line shutoff valves with sweat connections, system charge of R22 (R-410A) refrigerant, and compressor oil.

Operating Characteristics

The capacity of the unit will meet or exceed _____ Btuh at a suction temperature of _____ °F. The power consumption at full load will not exceed _____ kw.

Combination of the unit and the evaporator or fan coil unit will have a total net cooling capacity of _____ Btuh or greater at conditions of _____ CFM entering air temperature at the evaporator at _____ °F wet b ulb and _____ °F dry bulb , and air entering the unit at _____ °F.

The system will have an SEER of _____ Btuh/watt or greater at DOE conditions.

Electrical Requirements

Nominal unit electrical characteristics will be _____ v, single phase, 60 hertz. The unit will be capable of satisfactory operation within voltage limits of _____ v to _____ v.

Unit electrical power will be single point connection. Control circuit will be 24v.

Special Features

Refer to section of this literature identifying accessories and descriptions for speciﬁc features and available enhancements.

SPECIFICATIONS SUBJECT TO CHANGE WITHOUT NOTICE

UNIT MUST BE INSTALLED IN ACCORDANCE

WITH INSTALLATION INSTRUCTIONS

Cancels: PDS 594D.18.6

—24—

Bryant 594D User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
