Bruno CRE-2110 Operator's Manual

REV. 08-16-2010

CRE-2110

ELECTRA-RIDE™ III

STAIRWAY ELEVATOR

Operator’s Manual

Retail Customers

Please contact your Bruno dealer with any questions or service concerns, using the contact information shown below: (Dealer: Place contact information below.)

Dealer Name: Address: Telephone No.:

Dealer Name: Gamburd Inc. Address: 12405 Montague St. Los Angeles, CA 91331 Telephone No.: (888) 902-2237

2

PRODUCT REGISTRATION FORM

Bruno is pleased to provide you with this mobility-enhancing product.

The Product Registration Form is shipped in a plastic bag with this manual. It is very

important that you ll out and return this

form at your earliest convenience so that we may complete the warranty registration process for your unit.

The serial number is found on labels afxed to the manual, as well as on the unit itself.

Serial and model numbers must be provided

when ling a warranty claim, requesting service

or ordering parts. We encourage you to keep this information readily available at all times.

Please Note: The warranty for the CRE-2110

Stairway Elevator is rendered null and void if the unit is installed by anyone other than an authorized Bruno dealer.

Best wishes from the Bruno Team.

Product Registration Form

Please print in

CAPITAL

letters.

*First Name ______________________________________________________ M.I._____

*Last Name _______________________________________________________________

*Street Address ________________________________________________ Apt. No._____

*City _____________________________________________ *State/Province _________

*Zip/Postal Code ___________________________________________________________

Email Address _____________________________________________________________

Telephone No. _____________________________________________________________

Date of Purchase (mm/dd/yy) _________________________________________________

Model No._________________

*Serial No._________________

Please be assured that Bruno does not share or sell the information you provide.

Please rate your satisfaction with your Bruno dealer:

excellent good average poor

Please rate your satisfaction with your Bruno product:

excellent good average poor

Bruno reserves the right to use information indicated on this form in its online, video, audio and printed

materials. Names will be abbreviated to ensure the privacy and anonymity of the individual.

Online registration available at http://www.bruno.com/warranty.html

P/N PROD REG STD

Rev. 04-01-07

* = required ﬁ eld

SAMPLE

3

Table of Contents

Regulatory Information and Specications . . . . . . . . . . . . . 4

Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-6

Parts of the CRE-2110 . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Circuit Breaker . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Seating . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-21

Standard Swivel Seat . . . . . . . . . . . . . . . . . . . . 10-11

Power Swivel Seat. . . . . . . . . . . . . . . . . . . . . . . . . . 12

Optional Mid-Park Position. . . . . . . . . . . . . . . 13-14

Power Footrest . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Folding Rail . . . . . . . . . . . . . . . . . . . . . . . . . . . 16-17

Optional Power Folding Rail . . . . . . . . . . . . . . 18-21

Diagnostic Codes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

Charging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

Battery Charger. . . . . . . . . . . . . . . . . . . . . . . . . . . . 24-25

Maintenance/Transmitter Battery Replacement . . . . . . . . . 26

Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27-28

Vacation and Long-Term Storage . . . . . . . . . . . . . . . . . . . 29

Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30-31

4

FCC REGULATIONS

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This

equipment generates, uses, and can radiate radio frequency energy, and if not installed

and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a

particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the

user is encouraged to try to correct the interference by one or more of the of the following measures:

• Reorient or relocate receiving antenna.

• Increase separation between equipment and receiver.

• Consult your dealer.

SPECIFICATIONS

Weight Capacity: 400 lbs. (181 kg) Control: constant pressure (armrest and two remotes) Maximum Incline: 45 degrees Seat Swivel: 0, 60 and 90 degrees at top Power Supply: 24VDC battery charger powered by 120V outlet

5

FOR YOUR SAFETY

• Read and understand the operating instructions, and all safety precautions prior to using the CRE-2110.

• Be sure stairs are clear of objects before operating the stairway elevator.

• Always be aware of the surface onto which you are stepping as you get on and off the

stairway elevator.

• Avoid carrying items with you on the stairway elevator which could hinder movement of the elevator up and down the stairs.

• Do not wear LOOSE clothing that could interfere with elevator movement.

• Fasten your positioning belt before operating the stairway elevator.

• Make sure the seat is locked in the correct riding position.

• Be certain the seat swivel is locked in place before attempting to get on or off the

stairway elevator.

• NON-AMBULATORY USERS: Bruno recommends carrying a cellular or cordless telephone or an emergency communication device when riding the stairway elevator while alone in the house.

6

FOR YOUR SAFETY

Each stairway elevator is designed to travel down the stairway at a slightly slower speed

than is the case when travelling UP.

The footrest is equipped with obstruction sensors which stop the carriage if an obstacle is

encountered on the stairs.

If this should occur, press the opposite side of the UP/DOWN rocker control switch (on

the armrest) to run the carriage in the opposite direction. Clear the obstacle from the stairway or rail then resume travel in the desired direction.

Your CRE-2110 is battery powered and will continue to operate for some time during a power outage. The length of operation will depend on the battery condition, the length of the stairs and the weight of the rider.

Only in the event of a prolonged power outage (more than one hour) will it be necessary to turn the power off (circuit breaker switch on the carriage) and unplug the charger from the wall outlet to conserve battery charge.

The power swivel seat option is equipped with current overload sensing to prevent further seat swivel if a jam is detected.

The power footrest option is equipped with current overload sensing that will cause the footrest to return to its last position if a jam is detected.

7

CRE-2110

armrest

positioning belt

UP-DOWN

rocker switch

swivel release handle

footrest lever

obstruction sensors

8

CIRCUIT BREAKER

The CRE-2110 includes an ON/OFF switch with a built-in circuit breaker.

The circuit breaker protects the battery, controller and motor circuits in the stairway elevator carriage.

It is unlikely that this circuit breaker will trip during normal use. However, if the elevator becomes inoperative, check the circuit breaker as a rst troubleshooting step. Reset it, if necessary.

Possible causes of circuit breaker tripping:

• foreign object jamming the rail or gear

rack;

• exceeding the rated weight capacity of the stairway elevator.

ON/OFF switch

with built-in

circuit breaker

9

The CRE-2110 seat assembly (with standard armrests) is designed to swivel a total of 135 degrees.

It locks in the center (home) position, and in positions 60 and 90 degrees to the up side and 45 degrees to the down side.

Lift up on the swivel release lever located under the seat (either side) to swivel the seat to a convenient position for transferring into or out of the seat.

Once you release the swivel lever, the seat will lock in the closest of the four positions indicated above.

The seat also ips up to facilitate storage.

SEATING

swivel release handle

10

OPERATION

The CRE-2110 includes a “soft-start” feature which prevents the unit from moving abruptly the instant the

UP/DOWN switch is pressed.

Press and hold the switch for a moment to begin the gentle acceleration of the stairway elevator to operating speed.

STANDARD SWIVEL SEAT

1. Position yourself in the seat.

2. Fasten the positioning belt.

3. Raise and hold the seat swivel lever.

4. Rotate the seat so that you are at right angles to the rail (with your back to the stairway wall).

5. Release the seat swivel lever to secure the seat in that position.

A safety switch prevents operation of the CRE-2110 unless the seat is locked in position at right angles to the rail (the “riding” position).

6. Position both feet securely on the footrest and place your arms on the armrest cushions.

7. Press and hold the rocker switch (located on the front edge of one of the armrests) to

travel UP / DOWN the rail.

Depressing and holding the rocker switch will cause the carriage to move until the carriage stops automatically at the upper or lower end of the stair rail, or until the switch is released.

11

OPERATION

8. Once you have reached the top or bottom landing, release the rocker switch.

9. Raise and hold the seat swivel lever as you rotate to the position for transferring from the seat.

10. Release the seat swivel lever and allow the seat to lock in this position.

11. Unbuckle the positioning belt and carefully exit the seat.

Two (2) remote call / send transmitters enable you to move the carriage to or from either end of the stair rail.

12

OPERATION

POWER SWIVEL SEAT

1. Position yourself in the seat.

2. Fasten the positioning belt.

3. Position both feet securely on the footrest and

place your arms on the armrest cushions.

4. Press and hold the rocker switch (located

on the front edge of one of the armrests) to

travel UP / DOWN the rail.

5. Once you have reached the top or bottom

landing, release the rocker switch.

6. To rotate the seat at the top landing, press

the rocker switch again on the same side.

7. Release the rocker switch when you have fully

rotated out.

8. Unbuckle the positioning belt and carefully exit

the seat.

13

OPERATION

Optional Mid-Park Position

The mid-park is available as an option. This feature will let you park and charge the unit at a position between the two ends of the rail. This allows for more room at the top and bottom of the stairs.

1. Push either the seat rocker switch or the remote call/send to move the stairway elevator up or down the rail.

NOTE: The seat will always stop and beep

once when it reaches the mid-park position.

2. To resume travel to the end of the rail (top or bottom), release the switch (or remote button).

3. Press again and hold until the unit arrives at the top or bottom of the rail.

NOTE: The seat will again stop and beep once

to indicate end of travel.

14

OPERATION

Optional Mid-Park Position

POWER SWIVEL SEAT

NOTES:

1. You may use the remote call/send transmitters

to return the rotated power seat back to the ride position.

2. If the unit stops unexpectedly while traveling,

check for obstructions or excessive loading. You

will only be able to run the unit in the opposite direction until the overload is cleared.

15

OPERATION

POWER FOOTREST

If your unit is equipped with an optional power

footrest, follow the operating instructions indicated below.

1. Raise the seat to raise the footrest to its stored

position.

2. Lower the seat to lower the footrest to the ride

position.

NOTES:

• Do not try to manually raise or lower the footrest.

Always raise/lower the footrest by raising/lowering the seat. Failure to follow this instruction could damage the unit.

• If a jam occurs while raising or lowering the footrest,

the footrest will attempt to return to its last position. This will produce a sequence error.

To restore normal footrest operation:

▫ Clear the jam.

▫ Move the seat up and down until the footrest moves

again.

▫ If normal footrest operation is not restored, contact

a Bruno Service Representative.

16

DIAGNOSTIC CODES (UNDER SEAT)

A2 Seat in UP Position (Seat Fold Switch Closed)

A3 Seat Out of Riding Position (Swivel Limit Open)

A6 Seat Jammed (Actuator Stalled)

A7 Footrest Jammed (Actuator Stalled)

C1 Charging

C2 Off Charge

C3 Off Charge and Not Parked

C4 Parked and Charger Not Detected

C5 Battery Voltage Critical

C6 Battery Voltage Low

L1 Seat Safety Switch Open

L2 Up Limit Switch Open

L3 Down Limit Switch Open

L6 Mid-Rail Park Active L8 Soft Stop Switch

17

Keep the batteries charged to ensure optimal operation

of your CRE-2110.

The batteries are charging whenever the carriage is parked tightly against the brackets at either end of the rail. Whenever the carriage does not contact the upper or lower charge bracket, the batteries will slowly discharge.

Failure to keep the batteries charged, or allowing them

to fully discharge, will signicantly shorten the life of the

batteries.

Therefore, when the stairway elevator is not in use, park the carriage at either end of the rail, making sure it touches the charge bracket contacts.

The yellow LED light on the upper and lower charge brackets glows when the carriage is correctly parked against the contacts.

If your application prevents parking the carriage at one or

the other end of the stairs (for example, a door at the top of

the stairs), ALWAYS use the call/send transmitter to move the carriage to the end of the rail where the carriage can

contact the charge bracket. Using the transmitter, call it

back to the other end of the stairs when needed.

CHARGING

LED

glowing LED = charging

18

BATTERY CHARGER LED’S

charging

power on

ready

RED YELLOW GREEN STATUS

ON ON (< 1 sec.)

OFF

OFF charger not connected to

battery

ON (<5 sec.) ON ON

ON (<5 sec.) OFF OFF

ON (<5 sec.) BLINK (5 sec.) OFF

battery disconnect situation detected; 5-second delay until yellow and green LED’s completely off

ON ON OFF charger delivering maximum

current (2.2A)

ON ON OFF charger at maximum voltage;

current continues to drop

ON OFF ON batteries fully charged;

yellow LED occasionally turns off

ON BLINKS

ALTERNATELY

BLINKS

ALTERNATELY

low voltage indication

BLINKS

ALTERNATELY

BLINKS

ALTERNATELY

OFF battery defective or

heavily sulfated

ON OFF FAST BLINK partially open circuit; bad

contact or battery sulfation

19

BATTERY CHARGER FUSE REPLACEMENT

If the charger is subject to a power line

surge, the AC input fuse may blow. Refer to the illustration to the left for fuse location.

To replace fuse:

1. Turn OFF the battery charger power switch.

2. Remove power cord from wall outlet.

3. Twist the fuseholder cap and pull out to

remove the fuse.

4. Replace with the same size and type fuse: (Bussmann GMD-2A or equivalent)

2A, Slo-Blow, 5 x 20mm.

fuse

charger power switch

20

MAINTENANCE

Your CRE-2110 is designed to provide many years of reliable

service with minimal maintenance.

For best service life:

• Keep the rail channel clean and free of debris.

• Always park the carriage at one end of the rail so that the

batteries charge when the elevator is not in use.

• Keep the battery charger plugged into a live outlet at all

times.

• At least once a year, have the elevator examined, cleaned and lubricated by a qualied, authorized Bruno service

technician.

TRANSMITTER BATTERY REPLACEMENT

• Detach the transmitter from the wall.

• From the back of the transmitter, remove the battery access

cover.

• Remove the old battery and replace with a new one. One 9V battery required. Change batteries annually.

• Put the access cover back on the transmitter.

• Reposition the transmitter on the wall.

back of transmitter with battery access

cover removed

9V battery

21

TROUBLESHOOTING

Your CRE-2110 is not operating correctly. What should you do?

Before calling your Bruno dealer, refer to the solutions listed below. This could save you an unnecessary service call!

• Seat swivel. Is the seat locked in the riding position?

• Footrest. Is there an obstruction on the stairway that the footrest is contacting?

• Carriage safety panels. Is there an obstruction on the stairway that the carriage

safety panels are contacting?

• Main circuit breaker (or fuse) panel of residence. Has a breaker tripped or a fuse blown?

• Battery charger. A discharged battery will cause the carriage to move more slowly

until the voltage drops to the point where the controller will shut off. If this should occur, pause for a moment, then run the carriage down until the unit contacts the upper or lower charge bracket.

Partially charged batteries will run the carriage down, but not up.

Continued on next page.

22

• Battery charger (continued). Conrm that the charger is plugged into a live outlet

and wait for the batteries to charge.

Is the charger plugged into a functional outlet? Do not

use outlets which are controlled by a wall switch.

Is the red power light on?

• Visual check. Do you notice anything about your elevator that is different or out of

place?

If your CRE-2110 continues to function improperly or not at all after completing the

preceding checklist, contact an authorized Bruno dealer to perform all required service,

repair and maintenance operations.

TROUBLESHOOTING (CONTINUED)

23

VACATION AND LONG-TERM STORAGE

If the CRE-2110 will remain unused for an

extended period of time, turn off the circuit

breaker, then unplug the battery charger from the wall outlet.

NOTE: The batteries may require recharging

before normal use if the stairway elevator remained unused for an extended period of time.

To recharge, simply turn on the circuit breaker, reconnect the charger to the wall outlet and wait until the charger LED’s indicate that the batteries are fully recharged.

FIVE YEAR MAJOR COMPONENTS WARRANTY

TWO YEAR LIMITED WARRANTY

for

Bruno Stairlifts

Bruno Independent Living Aids, Inc. (“Bruno”), warrants to the original purchaser of a Bruno Stairlift that the Bruno Stairlift is free from defects in material and workmanship for a period

of two years from date of purchase. In addition, Bruno warrants that the motor, gear box and rail (the “Major Components”) will be free from defects in materials and workmanship for a period of ve years from the date of purchase.

The exclusive remedy for a defect in a Bruno Stairlift shall be the repair or replacement, at the option of Bruno, of the defective part or component. After the rst 30 days of this war-

ranty, only parts and components are covered. This warranty does not cover labor and other services after the initial 30 days. If repair or replacement of a Bruno Stairlift is not commercially practical or cannot be timely made, Bruno may elect to refund the purchase price of the Bruno Stairlift instead of repairing or replacing the Bruno Stairlift.

IN NO EVENT SHALL BRUNO BE RESPONSIBLE FOR INDIRECT, INCIDENTAL OR CONSEQUENTIAL DAMAGES, WHETHER SUCH DAMAGES ARISE FROM CLAIMS BASED ON CONTRACT, WARRANTY, TORT (INCLUDING NEGLIGENCE), STRICT LIABILITY OR PRODUCT LIABILITY. Some states do not allow the exclusion or

limitation of incidental or consequential damages, so the above limitation or exclusion may

not apply to you.

ALL IMPLIED WARRANTIES, INCLUDING ANY WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE, ARE LIMITED IN THEIR DURATION TO THE LENGTH OF THE WARRANTY STATED ABOVE FOR THE AFFECTED COMPONENT. Some states do not allow limitations on how long an implied warranty lasts

so the above limitation may not apply to you.

To obtain warranty service, you must follow these procedures:

1. Obtain return authorization by calling your local Bruno dealer;

2. Return the Bruno Stairlift, freight prepaid, to the address provided by your

Bruno dealer or Bruno with proof of purchase indicating the date purchased.

Bruno will pay for shipping back to the purchaser within the continental United States and

Canada if a defect in material or workmanship is discovered. Return freight and repair charges will be the responsibility of the purchaser if the problem is not covered by warranty.

This warranty does not cover damage or failure caused by misuse, abuse, accidents, physical damage, modications not made by Bruno, damage in shipment, or repairs undertaken by anyone other than Bruno factory employees or authorized distributors. The “original purchaser” of a Bruno Stairlift that is leased or rented shall be the person or entity acting as the lessee or rental provider.

This warranty gives you specic legal rights, and you may also have other rights which vary from state to state. Bruno specically does not authorize any person to extend the time or

scope of this warranty.

For further information regarding this limited warranty, please contact Bruno by calling 1-800-882-8183 or writing to Bruno at the following address:

Bruno Independent Living Aids, Inc.® Attention: Service Department

1780 Executive Drive, Post Ofce Box 84 Oconomowoc, WI 53066 USA

P/N 2110-O

Bruno Independent Living Aids, Inc

®

1780 Executive Drive, P.O. Box 84, Oconomowoc, WI 53066 www.bruno.com

262-567-4990 • FAX: 262-953-5501

©2009 Bruno Independent Living Aids, Inc.® All illustrations and specifications in this brochure are based on the latest product information available at the time of publication. Bruno Independent Living Aids, Inc®. reserves the right to make changes at any time without notice. Manual Back Cover 7/09-2.

Turning Automotive Seating

Straight & Custom

Curved-Rail Stairlifts

Over 25 Different

Vehicle Lift Solutions

Vertical Platform Lift

First in Performance. Built to Last!

Bruno CRE-2110 Operator's Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
