Brother MFC-230C, MFC-265C User's Guide

Download

USER’S GUIDE

MFC-230C MFC-265C

Approval Information and Compilation and Publication Notice

THIS EQUIPMENT IS DESIGNED TO WORK WITH A TWO WIRE ANALOGUE PSTN LINE FITTED WITH THE APPROPRIATE CONNECTOR.

APPROVAL INFORMATION

Brother advises that this product may not function correctly in a country other than where it was originally purchased, and does not offer any warranty in the event that this product is used on public telecommunication lines in another country.

Compilation and Publication Notice

Under the supervision of Brother Industries Ltd., this manual has been compiled and published, covering the latest product descriptions and specifications.

The contents of this manual and the specifications of this product are subject to change without notice.

Brother reserves the right to make changes without notice in the specifications and materials contained herein and shall not be responsible for any damages (including consequential) caused by reliance on the materials presented, including but not limited to typographical and other errors relating to the publication.

Use only GENUINE brother supplies

Brother multifunction machines are designed to work ink of a particular specification and work to a level of optimum performance when used with genuine Brother ink cartridges. Brother cannot guarantee this optimum performance if ink or ink cartridges of other specifications are used. Brother does not therefore recommend the use of cartridges other than genuine Brother cartridges with this machine or the refilling of empty cartridges with ink from other sources. If damage is caused to the print head or other parts of this machine as a result of the use of ink or ink cartridges other than genuine Brother products due to the incompatibility or lack of suitability of those products with this machine, any repairs required as a result will not be covered by the warranty.

Section I General

1 General Information 2

Using the documentation ....................................................................................... 2

Symbols and conventions used in the documentation .................................... 2

Accessing the Software User’s Guide ................................................................... 2

Viewing Documentation ...................................................................................2

Control panel overview ..........................................................................................4

2 Loading documents and paper 6

Loading documents ............................................................................................... 6

Using the ADF (MFC-265C only)..................................................................... 6

Using the scanner glass .................................................................................. 7

Scannable area ............................................................................................... 7

Acceptable paper and other media........................................................................8

Recommended media ..................................................................................... 8

Handling and using media ............................................................................... 9

Choosing the right media............................................................................... 10

Loading paper and other media...........................................................................12

Loading envelopes and post cards................................................................ 14

Removing small printouts from the machine ................................................. 15

Printable area ................................................................................................ 16

3 General setup 17

Power Save mode ............................................................................................... 17

Putting your machine in Power Save mode................................................... 17

Bringing your machine out of Power Save mode .......................................... 17

Power Save setting........................................................................................ 17

Mode Timer.......................................................................................................... 18

Paper settings......................................................................................................18

Paper Type .................................................................................................... 18

Paper Size ..................................................................................................... 18

Volume Settings...................................................................................................19

Ring Volume .................................................................................................. 19

Beeper Volume.............................................................................................. 19

Speaker Volume ............................................................................................ 19

LCD display ......................................................................................................... 20

LCD Contrast.................................................................................................20

LCD Language .............................................................................................. 20

Setting the fax logic ............................................................................................. 20

4 Security features 21

TX Lock................................................................................................................21

Setting and changing the TX lock password ................................................. 21

Turning the TX Lock on/off ............................................................................22

Section II Fax

5 Sending a fax 24

Entering Fax mode .............................................................................................. 24

Faxing from the ADF (MFC-265C only) ........................................................24

Faxing from the scanner glass ...................................................................... 24

Faxing Letter size documents from the scanner glass ..................................25

Colour fax transmission .................................................................................25

Cancelling a fax in progress ..........................................................................25

Broadcasting (Monochrome only)........................................................................25

Cancelling a Broadcast in progress ...............................................................26

Additional sending operations.............................................................................. 26

Sending faxes using multiple settings ........................................................... 26

Contrast .........................................................................................................27

Changing fax resolution .................................................................................27

Dual access (Monochrome only) ...................................................................28

Real time transmission ..................................................................................28

Overseas Mode .............................................................................................29

Checking and cancelling waiting jobs............................................................29

Sending a fax manually ................................................................................. 29

Out of Memory message ...............................................................................29

6 Receiving a Fax 30

Receive modes .................................................................................................... 30

Choosing the Receive Mode .........................................................................30

Using receive modes ........................................................................................... 31

Fax only .........................................................................................................31

Fax/Tel........................................................................................................... 31

Manual ........................................................................................................... 31

External TAD .................................................................................................31

Receive mode settings ........................................................................................32

Ring Delay .....................................................................................................32

F/T Ring Time (Fax/Tel mode only)...............................................................32

Fax Detect .....................................................................................................33

Additional receiving operations............................................................................33

Printing a reduced incoming fax ....................................................................33

Receiving faxes into memory ........................................................................ 34

7 Telephone and External devices 35

Voice Operations .................................................................................................35

Tone or pulse................................................................................................. 35

Fax/Tel mode ................................................................................................ 35

Fax/Tel mode in Power Save mode ..............................................................35

Telephone Service...............................................................................................36

Caller ID (Caller IDentification) (not available in certain area)....................... 36

Advantages of Caller ID................................................................................. 36

Setup Method ................................................................................................ 36

How Does the Caller ID Work?...................................................................... 36

If the Caller ID is Stored in Your Machine’s Memory..................................... 37

Connecting an external TAD (telephone answering device)................................38

Connections................................................................................................... 38

Recording an outgoing message (OGM) on an external TAD.......................38

Multi-line connections (PBX) ......................................................................... 39

External and extension telephones...................................................................... 39

Connecting an external or extension telephone ............................................ 39

Operation from extension telephones............................................................ 40

Using a cordless external telephone ............................................................. 40

Using remote codes....................................................................................... 40

8 Dialling and storing numbers 42

How to Dial .......................................................................................................... 42

Manual dialling............................................................................................... 42

Speed Dialling ............................................................................................... 42

Search ........................................................................................................... 42

Fax Redial ..................................................................................................... 43

Storing numbers .................................................................................................. 43

Storing a pause ............................................................................................. 43

Storing Speed Dial numbers.......................................................................... 44

Changing Speed Dial numbers...................................................................... 44

Setting up groups for broadcasting................................................................ 45

Combining Quick Dial numbers ..................................................................... 45

9 Printing Reports 46

Fax reports........................................................................................................... 46

Transmission Verification Report...................................................................46

Fax Journal (activity report) ........................................................................... 46

Reports ................................................................................................................ 47

How to print a report ...................................................................................... 47

Section III Copy

10 Making copies 50

How to copy ......................................................................................................... 50

Entering Copy mode ......................................................................................50

Making a single copy ..................................................................................... 50

iii

Making multiple copies ..................................................................................50

Stop copying ..................................................................................................50

Copy options........................................................................................................51

Changing copy speed and quality ................................................................. 52

Enlarging or reducing the image copied ........................................................ 52

Making N in 1 copies or a poster ...................................................................53

Sorting copies using the ADF (Monochrome only) (MFC-265C only)............54

Adjusting Brightness, Contrast and Colour.................................................... 55

Paper options ................................................................................................56

Section IV Direct Photo Printing

11 Printing photos from a memory card or

USB Flash memory drive 58

PhotoCapture Center™ Operations.....................................................................58

Printing from a memory card or USB Flash memory drive without a PC.......58

Using PhotoCapture Center™ from your computer ....................................... 58

Using a memory card or USB Flash memory drive .......................................58

Memory cards or a USB Flash memory drive folder structure....................... 59

Getting started .....................................................................................................60

How to print from a memory card or USB Flash memory drive ...........................61

Print Index (Thumbnails) ...............................................................................61

Printing Images.............................................................................................. 62

DPOF printing ................................................................................................63

PhotoCapture Center™ print settings..................................................................64

Print speed and quality ..................................................................................64

Paper Options................................................................................................ 64

Adjusting Brightness and Contrast ................................................................ 65

Cropping ........................................................................................................65

Borderless printing......................................................................................... 65

Understanding the Error Messages ..................................................................... 66

12 Printing photos from a camera 67

Printing photos directly from a PictBridge camera ...............................................67

PictBridge requirements ................................................................................67

Setting your digital camera ............................................................................67

Printing Images.............................................................................................. 68

DPOF printing ................................................................................................68

Printing photos directly from a digital camera (without PictBridge)......................69

Printing Images.............................................................................................. 69

Understanding the Error Messages ..................................................................... 70

Section V Software

13 Software features 72

Section VI Appendixes

A Safety and Legal 74

Choosing a location .............................................................................................74

To use the machine safely...................................................................................75

Important safety instructions.......................................................................... 78

IMPORTANT - For your safety ......................................................................79

Legal limitations for copying ................................................................................ 80

Trademarks.......................................................................................................... 81

B Troubleshooting and Routine Maintenance 82

Troubleshooting ................................................................................................... 82

If you are having difficulty with your machine ................................................ 82

Error messages ................................................................................................... 88

Transferring your faxes or Fax Journal report ...............................................91

Document jam (MFC-265C only) .................................................................. 92

Printer jam or paper jam ................................................................................ 92

Dial Tone detection........................................................................................ 94

Telephone line interference ........................................................................... 95

Routine maintenance...........................................................................................95

Replacing the ink cartridges .......................................................................... 95

Cleaning the outside of the machine ............................................................. 97

Cleaning the scanner..................................................................................... 98

Cleaning the machine printer platen.............................................................. 99

Cleaning the Paper Pick-up Roller ................................................................99

Cleaning the print head ............................................................................... 100

Checking the print quality ............................................................................ 100

Checking the print alignment ....................................................................... 102

Checking the ink volume .............................................................................102

Machine Information .......................................................................................... 103

Checking the serial number ......................................................................... 103

Packing and shipping the machine .................................................................... 103

C Menu and Features 106

On-screen programming .................................................................................... 106

Menu table................................................................................................... 106

Memory storage........................................................................................... 106

Menu keys ......................................................................................................... 106

Menu Table........................................................................................................108

Entering Text ..................................................................................................... 115

D Specifications 116

General .............................................................................................................. 116

Print media.........................................................................................................118

Fax.....................................................................................................................119

Copy .................................................................................................................. 121

PhotoCapture Center™ ..................................................................................... 122

PictBridge .......................................................................................................... 123

Scanner ............................................................................................................. 124

Printer ................................................................................................................ 125

Interfaces ........................................................................................................... 126

Computer requirements ..................................................................................... 127

Consumable items ............................................................................................. 128

E Glossary 129

F Index 132

Section I

General I

General Information 2 Loading documents and paper 6 General setup 17 Security features 21

General Information 1

Using the documentation 1

Thank you for buying a Brother machine! Reading the documentation will help you make the most of your machine.

Symbols and conventions used in the documentation 1

The following symbols and conventions are used throughout the documentation.

Bold Bold typeface identifies specific

keys on the machine’s control panel.

Italics Italicized typeface emphasizes

an important point or refers you to a related topic.

Courier New

Text in the Courier New font identifies messages on the LCD of the machine.

Accessing the Software User’s Guide 1

This User’s Guide does not contain all the information about the machine such as how to use Printer, Scanner and PC Fax. When you are ready to learn detailed information about these operations, read the Software User’s Guide that is on the CD-ROM.

Viewing Documentation 1

Viewing Documentation (For Windows

To view the documentation, from the Start menu, point to Brother, MFC-XXXX (where XXXX is your model name) from the programs group, and then choose User’s Guides in HTML format.

If you have not installed the software, you can find the documentation by following the instructions below:

) 1

Warnings tell you what to do to prevent possible personal injury.

Electrical Hazard icons alert you to possible electrical shock.

Cautions specify procedures you must follow or avoid to prevent possible damage to the machine or other objects.

Notes tell you how you should respond to a situation that may arise or give tips about how the operation works with other features.

Improper Setup icons alert you to devices and operations that are not compatible with the machine.

a Turn on your PC. Insert the Brother

CD-ROM into your CD-ROM drive.

b If the model name screen appears, click

your model name.

c If the language screen appears, click

your language. The CD-ROM main menu will appear.

General Information

Note

If this window does not appear, use

Windows program from the root directory of the Brother CD-ROM.

Explorer to run the start.exe

d Click Documentation. e Click the documentation you want to

read.

 HTML documents: Software

User’s Guide in HTML format.

This format is recommended for viewing on your computer.

 PDF documents: User’s Guide for

stand-alone operations, Software User’s Guide in PDF format.

This format is recommended for printing the manuals. Click to go to the Brother Solution Center, where you can view or download the PDF documents. (Internet access and PDF Reader software are required.)

How to find Scanning instructions 1

There are several ways you can scan documents. You can find the instructions as follows:

Software User’s Guide

 Scanning (For Windows

Professional/Windows Vista™)

 ControlCenter3 (For Windows

Professional/Windows Vista™)

2000

XP and Windows

2000

XP and Windows

Viewing Documentation (For Macintosh

a Turn on your Macintosh

Brother CD-ROM into your CD-ROM drive. The following window will appear.

) 1

. Insert the

b Double-click the Documentation icon. c Double-click your language folder. d Double-click the top page file to view the

Software User’s Guide in HTML format.

e Click the documentation you want to

read.

 Software User’s Guide

How to find Scanning instructions 1

There are several ways you can scan documents. You can find the instructions as follows:

Software User’s Guide

 Scanning (For Mac OS

greater)

 ControlCenter2 (For Mac OS

greater)

Presto!

 Instructions for scanning directly from

PageManager® User’s Guide

Presto!

Presto! can be viewed from the Help selection in

the Presto!

PageManager®. The complete

PageManager® User’s Guide

PageManager® application.

X 10.2.4 or

Chapter 1

Control panel overview 1

Note

Most of the illustrations in this User’s Guide show the MFC-265C.

1 Fax keys

 Redial/Pause

Redials the last number called. It also inserts a pause when programming quick dial numbers.

 Hook

This key is used to have a telephone conversation after picking up the external handset during the F/T pseudo-ring.

Also, use this key to gain access to an outside line, or transfer a call to another extension when it is connected to a PBX.

2 Dial Pad

Use these keys to dial telephone and fax numbers and as a keyboard for entering information into the machine.

The # key lets you temporarily switch the dialling mode during a telephone call from Pulse to Tone.

3 Mode keys:

 Fax

Lets you access Fax mode.

 Scan

Lets you access Scan mode.

 Copy

Lets you access Copy mode.

 PhotoCapture

Lets you access PhotoCapture Center™ mode.

4 Fax Resolution

Lets you temporarily change the resolution when sending a fax.

5 Ink Management

Lets you clean the print head, check the print quality, and check the available ink volume.

General Information

6Start keys:

 Colour Start

Lets you start sending faxes or making copies in full colour. Also lets you start a scanning operation (in colour or mono, depending on the scanning setting in the ControlCenter software).

 Mono Start

Lets you start sending faxes or making copies in monochrome. Also lets you start a scanning operation (in colour or mono, depending on the scanning setting in the ControlCenter software).

7 Stop/Exit

Stops an operation or exits from a menu.

8 Menu keys:

 Menu

Lets you access the main menu to program the machine.

 a Speed Dial

Lets you store, look up, and dial numbers in the memory.

 Volume keys

d c

In Fax mode, you can press these keys to adjust the ring volume.

 d

Press to scroll backward to a menu selection.

 a or b

Press to scroll through the menus and options.

 Clear/Back

Press to cancel the current setting.

 OK

Lets you choose a setting.

9 Copy Options

Lets you temporarily change the copy settings when in copy mode.

10 LCD (liquid crystal display)

Displays messages on the screen to help you set up and use your machine.

11 Power Save

Lets you put the machine into Power Save mode.

Loading documents and paper 2

Loading documents 2

You can send a fax, make copies, and scan from the ADF (automatic document feeder) and from the scanner glass.

Using the ADF (MFC-265C only) 2

The ADF can hold up to 10 pages and feeds each sheet individually. Use standard

80 g/m before putting them in the ADF.

Recommended environment 2

Temperature: 20 to 30° C

Humidity: 50% to 70%

Paper:

Document Sizes Supported 2

paper and always fan the pages

80 g/m

How to load documents 2

DO NOT pull on the document while it is feeding.

DO NOT use paper that is curled, wrinkled, folded, ripped, stapled, paper clipped, pasted or taped.

DO NOT use cardboard, newspaper or fabric.

 Make sure documents written with ink are

CAUTION

completely dry.

a Fan the pages well. Make sure you put

the documents face down, top edge first in the ADF until you feel them touch

the feed roller.

b Adjust the paper guides to fit the width of

your documents.

Length: 148 to 355.6 mm

Width: 148to215.9mm

Weight:

64 to 90 g/m

c Unfold the ADF Document Output

Support Flap (1).

DO NOT leave thick documents on the scanner glass. If you do this, the ADF may jam.

CAUTION

Loading documents and paper

Using the scanner glass 2

You can use the scanner glass to fax, copy or scan pages of a book or one page at a time.

Document Sizes Supported 2

Length: Up to 297 mm

Width: Up to 215.9 mm

Weight: Up to 2 kg

How to load documents 2

Note

To use the scanner glass, the ADF must be empty.

a Lift the document cover. b Using the document guidelines on the

left, center the document face down on the scanner glass.

CAUTION

If you are scanning a book or thick document, DO NOT slam the cover or press on it.

Scannable area 2

The scannable area depends on the settings in the application you are using. The figures below show the areas you cannot scan on Letter and A4 paper.

c Close the document cover.

Usage

Fax Letter 3 mm 4 mm

Copy Letter 3 mm 3 mm

Scan Letter 3 mm 3 mm

Document Size

A4 3 mm 1 mm

A4 3 mm 3 mm

A4 3 mm 0 mm

Top (1)

Bottom (2)

Left (3)

Right (4)

Chapter 2

Acceptable paper and other media 2

The print quality can be affected by the type of paper you are using in the machine.

To get the best print quality for the settings you have chosen, always set the Paper Type to match the type of paper you load.

You can use plain paper, inkjet paper (coated paper), glossy paper, transparencies and envelopes.

We recommend testing various paper types before buying large quantities.

For best results, use Brother paper.

 When you print on inkjet paper (coated

paper), transparencies and photo paper, be sure to choose the correct media in the ‘Basic’ tab of the printer driver or in the Paper Type setting of the menu (See Paper Type on page 18).

 When you print on Brother photo paper,

load the instruction sheet included with the photo paper in the paper tray first, and then put the photo paper on the instruction sheet.

Recommended media 2

To get the best print quality, we suggest using Brother paper. (See table below.)

If Brother paper is not available in your country, we recommend testing various papers before purchasing large quantities.

We recommend using ‘3M Transparency Film’ when you print on transparencies.

Brother paper

Paper Type Item

A4 Plain BP60PA

A4 Glossy Photo BP61GLA

A4 Inkjet (Matte) BP60MA

10 x 15 cm Glossy BP61GLP

 When you use transparencies or photo

paper, remove each sheet at once to prevent smudging or paper jams.

 Avoid touching the printed surface of the

paper immediately after printing; the surface may not be completely dry and may stain your fingers.

Loading documents and paper

Handling and using media 2



Store paper in its original packaging, and keep it sealed. Keep the paper flat and away from moisture, direct sunlight and heat.

 The coated side of photo paper is shiny.

Avoid touching the shiny (coated) side. Load photo paper with the shiny side facing down.

 Avoid touching either side of

transparencies because they absorb water and perspiration easily, and this may cause decreased output quality. Transparencies designed for laser printers/copiers may stain your next document. Use only transparencies recommended for inkjet printing.

DO NOT use the following kinds of paper:

Improper Setup

• Damaged, curled, wrinkled, or irregularly shaped paper

Paper capacity of the output paper tray

Up to 50 sheets of 80 g/m2 A4 or 20 lb Letter paper.

 Transparencies or photo paper must be

picked up from the output paper tray one page at a time to avoid smudging.

1 2 mm or longer

• Extremely shiny or highly textured paper

• Paper already printed on by a printer

• Paper that cannot be arranged uniformly when stacked

• Paper made with a short grain

Chapter 2

Choosing the right media 2

Paper type and size for each operation 2

Paper Type Paper Size Usage

Fax Copy Photo

Capture

Cut Sheet Letter 216 × 279 mm (8 1/2 × 11 in.) Yes Yes Yes Yes

A4 210 × 297 mm (8.3 × 11.7 in.) Yes Yes Yes Yes

Legal 216 × 356 mm (8 1/2 × 14 in.) Yes Yes – Yes

Executive 184 × 267 mm (7 1/4 × 10 1/2 in.) – – – Yes

JIS B5 182 × 257 mm (7.2 × 10.1 in.) – – – Yes

A5 148 × 210 mm (5.8 × 8.3 in.) – Yes – Yes

A6 105 × 148 mm (4.1 × 5.8 in.) – – – Yes

Cards Photo 10 × 15 cm (4 × 6 in.) – Yes Yes Yes

Photo 2L 13 × 18 cm (5 × 7 in.) – – Yes Yes

Index Card 127 × 203 mm (5 × 8 in.) – – – Yes

Post Card 1

Post Card 2 (Double)

Envelopes C5

Envelope

DL Envelope

COM-10 105 × 241 mm (4 1/8 × 9 1/2 in.) – – – Yes

Monarch 98 × 191 mm (3 7/8 × 7 1/2 in.) – – – Yes

JE4 Envelope

Transparencies

Letter 216 × 279 mm (8 1/2 × 11 in.) – Yes – Yes

A4 210 × 297 mm (8.3 × 11.7 in.) – Yes – Yes

100 × 148 mm (3.9 × 5.8 in.) – – – Yes

148 × 200 mm (5.8 × 7.9 in.) – – – Yes

162 × 229 mm (6.4 × 9 in.) – – – Yes

110 × 220 mm (4.3 × 8.7 in.) – – – Yes

105 × 235 mm (4.1 × 9.3 in.) – – – Yes

Printer

Loading documents and paper

Paper weight, thickness and capacity 2

Paper Type Weight Thickness

Cut Sheet

Plain Paper

Inkjet Paper

Glossy Paper

Cards Photo Card

Index Card

Post Card

Envelopes

64 to 120 g/m

64 to 200 g/m

(17 to 32 lb)

(17 to 53 lb)

Up to 220 g/m2 (Up to 58 lb)

Up to 240 g/m

Up to 120 g/m

(Up to 64 lb)

(Up to 32 lb)

Up to 200 g/m2 (Up to 53 lb)

75 to 95 g/m

(20 to 25 lb)

0.08 to 0.15 mm (0.003 to 0.006 in.)

0.08 to 0.25 mm (0.003 to 0.01 in.) 20

Up to 0.25 mm (Up to 0.01 in.) 20

Up to 0.28 mm (Up to 0.01 in.) 20

Up to 0.15 mm (Up to 0.006 in.) 30

Up to 0.23 mm (Up to 0.01 in.) 30

Up to 0.52 mm (Up to 0.02 in.) 10

Transparencies – – 10

Up to 50 sheets for Legal size paper 80 g/m2 (20 lb).

Up to 100 sheets of 80 g/m

(20 lb) paper.

No. of sheets

100

Chapter 2

Loading paper and other media 2

a If the paper support flap is open, close it,

and then pull the paper tray completely out of the machine. Lift the output paper tray cover (1).

c Fan the stack of paper well to avoid

paper jams and misfeeds.

Note

Always make sure the paper is not curled.

d Gently put the paper into the paper tray

print side down and top edge first. Check that the paper is flat in the tray.

b Press and slide the paper side

guides (1) and paper length guide (2) to fit the paper size.

Note

When you use Legal size paper, press and hold the universal guide release button as you slide out the front of the paper tray.

Loading documents and paper

e Gently adjust the paper side guides to

the paper with both hands. Make sure the paper side guides touch the sides of the paper.

Note

Be careful that you do not push the paper in too far; it may lift at the back of the tray and cause feed problems.

f Close the output paper tray cover.

h While holding the paper tray in place,

pull out the paper support (1) until it clicks and unfold the paper support flap (2).

Note

Do not use the paper support flap for Legal paper.

g Slowly push the paper tray completely

into the machine.

Chapter 2

Loading envelopes and post cards 2

Loading envelopes 2

 Use envelopes that weigh from 75 to

95 g/m

 Some envelopes need margin settings to

be set in the application. Make sure you do a test print first.

DO NOT use any of the following types of envelope, as they will cause paper feed problems:

• That are of a baggy construction.

• That are embossed (have raised writing

• That have clasps or staples.

• That are pre-printed on the inside.

CAUTION

on them).

How to load envelopes and post cards 2

a Before loading, press the corners and

sides of the envelopes or post cards to make them as flat as possible.

Note

If the envelopes or post cards are ‘double-feeding,’ put one envelope or post card in the paper tray at a time.

Glue 2

Double flap 2

Occasionally you may experience paper feed problems caused by the thickness, size and flap shape of the envelopes you are using.

b Put the envelopes or post cards into the

paper tray with the address side down and the leading edge in first as shown in the illustration. Slide the paper side guides (1) and paper length guide (2) to fit the size of the envelopes or post cards.

If you have problems when printing on envelopes, try the following suggestions:

a Open the envelope flap.

Loading documents and paper

b Make sure the open flap is either to the

side of the envelope or to the back edge of the envelope when printing.

c Adjust the size and margin in your

application.

Removing small printouts from the machine 2

When the machine ejects small paper onto the output paper tray you may not be able to reach it. Make sure printing has finished, and then pull the tray completely out of the machine.

Chapter 2

Printable area 2

The printable area depends on the settings in the application you are using. The figures below show the unprintable areas on cut sheet paper and envelopes. The machine can only print in the shaded areas when the Borderless print feature is available and turned on.

Cut Sheet Paper Envelopes

Top (1) Bottom (2) Left (3) Right (4)

Cut Sheet 3 mm 3 mm 3 mm 3 mm

Envelopes 12 mm 24 mm 3 mm 3 mm

Note

The Borderless feature is not available for envelopes.

General setup 3

Power Save mode 3

When the machine is idle, you can put the machine into Power Save mode by pressing the Power Save key. You can still receive telephone calls in Power Save mode. For further information on receiving faxes in the power save condition, please see the table on page 17. If you want to do other operations, you must take the machine out of Power Save mode.

Note

If you have connected an external telephone or TAD, it is always available.

Putting your machine in Power Save mode 3

a Press and hold down the Power Save

key. The LCD will show Shutting Down. The LCD will stay on for a few seconds before going off.

Bringing your machine out of Power Save mode 3

a Press the Power Save key.

Note

• Even if you have put the machine into Power Save mode, it will periodically clean the print head to preserve print quality.

• If you unplug the AC power cord, no machine operations will be available.

• You can customize Power Save mode so that, apart from automatic head cleaning, no machine operations are available. (See Power Save setting on page 17.)

Power Save setting 3

You can customize the machine's Power Save key. The default mode is Fax Receive:On. Your machine can receive faxes or calls even when the machine is in Power Save mode. If you do not want your machine to receive faxes or calls, turn this setting to Fax Receive:Off. (See Power Save mode on page 17)

a Press Menu, 1, 5. b Press a or b to choose

Fax Receive:On, or Fax Receive:Off.

Press OK.

c Press Stop/Exit.

On/Off setting

Fax Receive:

(factory setting)

Fax Receive: Off

You cannot receive a fax with Mono Start or Colour Start.

You cannot receive a fax automatically if you have set the receive mode to Fax/Tel.

Receive mode

Fax Only

External TAD

Manual

Fax/Tel

— No machine

Available operations

Fax Receive

Fax Detect

operations will be available other than cleaning the print head.

Chapter 3

Mode Timer 3

The machine has four temporary mode keys on the control panel: Fax, Scan, Copy and PhotoCapture. You can change the amount of time the machine takes after the last Scan, Copy or PhotoCapture operation before it returns to Fax mode. If you choose Off, the machine stays in the mode you used last.

a Press Menu, 1, 1. b Press a or b to choose 0 Sec,

30 Secs, 1 Min, 2 Mins, 5 Mins or Off.

Press OK.

c Press Stop/Exit.

Paper settings 3

Paper Type 3

To get the best print quality, set the machine for the type of paper you are using.

a Press Menu, 1, 2. b Press a or b to choose Plain Paper,

Inkjet Paper, Brother Photo, Other Photo or Transparency.

Press OK.

c Press Stop/Exit.

Note

The machine ejects paper with printed surfaces face up onto the paper tray in front of the machine. When you use transparencies or glossy paper, remove each sheet at once to prevent smudging or paper jams.

Paper Size 3

You can use five sizes of paper for printing copies: Letter, Legal, A4, A5, and 10 × 15 cm and three sizes for printing faxes: Letter, Legal and A4. When you change the size of paper you load in the machine, you will need to change the paper size setting at the same time so your machine can fit an incoming fax on the page.

a Press Menu, 1, 3. b Press a or b to choose Letter, Legal,

A4, A5 or 10x15cm. Press OK.

c Press Stop/Exit.

General setup

Volume Settings 3

Ring Volume 3

You can choose a range of ring volume levels, from High to Off.

While in Fax mode , press d or c

to adjust the volume level. The LCD shows the current setting, and each key press will change the volume to the next level. The machine will keep the new setting until you change it.

You can also change the volume through the menu, by following the instructions below:

Setting the Ring Volume from the menu

a Press Menu, 1, 4, 1. b Press a or b to choose Low, Med, High

or Off. Press OK.

c Press Stop/Exit.

Beeper Volume 3

When the beeper is on, the machine will beep when you press a key, make a mistake or after you send or receive a fax.

You can choose a range of volume levels, from High to Off.

a Press Menu, 1, 4, 2. b Press a or b to choose Low, Med, High

or Off. Press OK.

c Press Stop/Exit.

Speaker Volume 3

You can choose a range of speaker volume

levels, from High to Off.

a Press Menu, 1, 4, 3. b Press a or b to choose Low, Med, High

or Off. Press OK.

c Press Stop/Exit

You can also adjust the speaker volume by pressing Hook.

a Press Hook. b Press d or c

This setting will stay until you change it again.

c Press Hook.

Chapter 3

LCD display 3

LCD Contrast 3

You can adjust the LCD contrast for a sharper and more vivid display. If you are having difficulty reading the LCD, try changing the contrast setting.

a Press Menu, 1, 6. b Press a or b to choose Light or Dark.

Press OK.

c Press Stop/Exit.

LCD Language 3

You can change the LCD language.

a Press Menu, 0, 0. b Press a or b to choose English or

Chinese. Press OK.

c Press Stop/Exit.

Setting the fax logic 3

You can change the transmission process when you send or receive the fax manually with an external telephone.

Easy mode:

Call Out Receives Call

Documents

the ADF

No documents in the ADF or Documents on the scanner glass

Advanced mode:

Documents

the ADF

No documents in the ADF or Documents on the scanner glass

Send the faxes by pressing Start.

Send the faxes by pressing

Start

Call Out Receives Call

Send the faxes by pressing

Start

Press Start, and then you can select:

1.Send

2.Receive

—

Receive the faxes by pressing Start

—

Press Start, and then you can select:

1.Send

2.Receive

a Press Menu, 2, 0, 5. b Press a or b to choose Easy Mode or

Advanced Mode. Press OK.

c Press Stop/Exit.

Security features 4

TX Lock 4

TX Lock lets you prevent unauthorized access to the machine.

While TX Lock is On, the following operations are available:

 Receiving faxes

While TX Lock is On, the following operations are NOT available:

 Sending faxes

 Copying

 PC printing

 Scanning

 PhotoCapture

 Operation from Control panel

Note

If you forget the TX Lock password, please call your Brother dealer for service.

Setting and changing the TX lock password 4

Note

If you have already set the password, you will not need to set it again.

Setting up the password 4

a Press Menu, 2, 0, 1. b Enter a 4-digit number for the password.

Press OK.

c When the LCD shows Verify:,

re-enter the password. Press OK.

d Press Stop/Exit.

Changing the TX Lock password 4

a Press Menu, 2, 0, 1.

b Press a or b to choose Set Password.

Press OK.

c Enter a 4-digit number for the current

password. Press OK.

d Enter a 4-digit number for a new

password. Press OK.

e When the LCD shows Verify:,

re-enter the password. Press OK.

f Press Stop/Exit.

Chapter 4

Turning the TX Lock on/off 4

Turning TX Lock on 4

a Press Menu, 2, 0, 1. b Press a or b to choose Set TX Lock.

Press OK.

c Enter the registered 4-digit password.

Press OK. The machine goes offline and the LCD shows TX Lock Mode.

Turning TX Lock off 4

a Press Menu. b Enter the registered 4-digit password.

Press OK. TX lock is automatically turned off.

Note

If you enter the wrong password, the LCD shows Wrong Password and stays offline. The machine will stay in TX Lock mode until the registered password is entered.

Section II

Fax II

Sending a fax 24 Receiving a Fax 30 Telephone and External devices 35 Dialling and storing numbers 42 Printing Reports 46

Sending a fax 5

Entering Fax mode 5

To enter fax mode, press (Fax), and

the key will glow green.

Faxing from the ADF (MFC-265C only) 5

a Make sure you are in Fax mode .

b Put the document face down in the ADF.

(See Loading documents on page 6.)

c Dial the fax number using the dial pad. d Press Mono Start or Colour Start.

The machine starts scanning the document.

Note

• To cancel, press Stop/Exit.

• If you send a black & white fax when the memory is full it will be sent in real time.

Faxing from the scanner glass5

You can use the scanner glass to fax pages of a book one at a time. The documents can be up to letter or A4 size.

You cannot send multiple pages for colour faxes.

a Make sure you are in Fax mode .

b Load your document on the scanner

glass.

c Dial the fax number. d Press Mono Start or Colour Start.

 If you press Mono Start, the

machine starts scanning the first page. Go to step e.

 If you press Colour Start, the

machine starts sending the document.

e Do one of the following:

 To send a single page, press 2 to

choose No (or press Mono Start again).

The machine starts sending the document.

 To send more than one page, press

1 to choose Yes and go to step f.

f Put the next page on the scanner glass.

Press OK. The machine starts scanning the page. (Repeat step e and step f for each additional page.)

Note

(MFC-265C only)

Since you can only scan one page at a time, it is easier to use the ADF if you are sending a multiple page document.

Sending a fax

Faxing Letter size documents from the scanner glass 5

When documents are Letter size, you need to set Scan Size to Letter. If you do not, the side portion of the faxes will be missing.

a Make sure you are in Fax mode .

b Press Menu, 2, 2, 0. c Press a or b to choose Letter.

Press OK.

d Press Stop/Exit.

Colour fax transmission 5

Your machine can send a colour fax to machines that support this feature.

Colour faxes cannot be stored in the memory. When you send a colour fax, the machine will send it in real time (even if Real Time TX is set to Off).

Broadcasting (Monochrome only) 5

Broadcasting is when the same fax message is automatically sent to more than one fax number. You can include Groups, Speed Dial numbers and up to 50 manually dialled numbers in the same broadcast.

After the broadcast is finished, a Broadcast Report will be printed.

a Make sure you are in Fax mode .

b Load your document. c Enter a number. Press OK.

You can use either a Speed Dial, a Group or a manually entered number using the dial pad.

d Repeat c until you have entered all the

fax numbers you wish to broadcast to.

e Press Mono Start.

Cancelling a fax in progress 5

If you want to cancel a fax while the machine is scanning, dialling or sending, press Stop/Exit.

Note

• If you did not use up any of the numbers for Groups, you can ‘broadcast’ faxes to as many as 90 different numbers.

• The available memory will vary depending on the types of jobs in the memory and the number of locations used for broadcasting. If you broadcast to the maximum numbers available, you will not be able to use dual access.

• If the memory is full, press Stop/Exit to stop the job. If more than one page has been scanned, press Mono Start to send the portion that is in the memory.

Chapter 5

Cancelling a Broadcast in progress 5

a Press Menu, 2, 4.

The LCD will show the fax number being dialled.

XXXXXXXX

b Press OK.

The LCD will show the job number:

1.Clear 2.Exit

c Press 1 to clear.

The LCD will then show the Broadcast job number and 1.Clear 2.Exit.

d To cancel the Broadcast, press 1. e Press Stop/Exit.

Additional sending operations 5

Sending faxes using multiple settings 5

When you send a fax you can choose any combination of these settings: resolution, contrast, overseas mode and real time transmission.

a Make sure you are in Fax mode .

b Load your document. c Choose a setting you want to change in

the Setup Send menu (Menu, 2, 2). Press OK.

d Choose the option you want for the

setting. Press OK.

e Do one of the following:

1.Yes 2.No

 Press 1 to change another setting.

 Press 2 when you have finished

choosing your settings.

f Send the fax as normal.

Sending a fax

Contrast 5

If your document is very light or very dark, you may want to change the contrast. For most documents the default setting Auto can be used. It automatically chooses the suitable contrast for your document.

Use Light when sending a light document.

Use Dark when sending a dark document.

a Make sure you are in Fax mode .

b Load your document. c Press Menu, 2, 2, 1. d Press a or b to choose Auto, Light or

Dark. Press OK.

Note

Even if you choose Light or Dark, the machine will send the fax using the Auto setting in any of the following conditions:

• When you send a colour fax.

• When you choose Photo as the Fax Resolution.

To change the default fax resolution 5

a Make sure you are in Fax mode .

b Press Menu, 2, 2, 2. c Press a or b to choose the resolution

you want. Press OK.

Note

You can choose four different resolution settings for monochrome faxes and two for colour.

Monochrome

Standard Suitable for most typed

documents.

Fine Good for small print and

transmits a little slower than Standard resolution.

S.Fine Good for small print or artwork

and transmits slower than Fine resolution.

Photo Use when the document has

varying shades of grey or is a photograph. This has the slowest transmission.

Changing fax resolution 5

The quality of a fax can be improved by changing the fax resolution. Resolution can be changed for the next fax or for all faxes.

To change the fax resolution for the next fax

a Make sure you are in Fax mode .

b Load your document. c Press Fax Resolution then a or b to

choose the resolution. Press OK.

Colour

Standard Suitable for most typed

documents.

Fine Use when the document is a

photograph. The transmission time is slower than Standard resolution.

If you choose S.Fine or Photo and then use the Colour Start key to send a fax, the machine will send the fax using the Fine setting.

Chapter 5

Dual access (Monochrome only) 5

You can dial a number and start scanning the fax into memory—even when the machine is sending from memory, receiving faxes or printing PC data. The LCD shows the new job number and available memory.

The number of pages you can scan into the memory will vary depending on the data that is printed on them.

Note

If the Out of Memory message appears while scanning documents, press Stop/Exit to cancel or Mono Start to send the scanned pages.

Real time transmission 5

When you are sending a fax, the machine will scan the documents into the memory before sending. Then, as soon as the telephone line is free, the machine will start dialling and sending.

If the memory is full or you are sending a colour fax, the machine will send the document in real time (even if Real Time TX is set to Off).

Sometimes, you may want to send an important document immediately, without waiting for memory transmission. You can set

Real Time TX to On for all documents or Next Fax Only for the next fax only.

Sending in real time for all faxes 5

a Make sure you are in Fax mode .

b Press Menu, 2, 2, 3.

3.Real Time TX

Realtime TX:On

c Press a or b to choose On (or Off).

Press OK.

Sending in real time for the next fax only

a Make sure you are in Fax mode .

b Press Menu, 2, 2, 3. c Press a or b to choose

Next Fax Only. Press OK.

d Press a or b to choose Next Fax:Off

or Next Fax:On.

e Press OK.

Note

In real time transmission, the automatic redial feature does not work when using the scanner glass.

Note

In Real Time Transmission, the automatic redial feature does not work when using the scanner glass.

Sending a fax

Overseas Mode 5

If you are having difficulty sending a fax overseas due to possible interference on the telephone line, we recommend that you turn on the Overseas mode. After you send a fax using this feature, the feature will turn itself off.

a Make sure you are in Fax mode .

b Load your document. c Press Menu, 2, 2, 4. d Press a or b to choose On (or Off).

Press OK.

Checking and cancelling waiting jobs 5

You can check which jobs are still waiting in the memory to be sent and cancel a job. (If there are no jobs, the LCD shows No Jobs Waiting.)

a Press Menu, 2, 4.

Any waiting jobs appear on the LCD.

b Do one of the following:

 Press a or b to scroll through the jobs

and choose the job you want to cancel.

Press OK to choose a job, and then press 1 to cancel it.

 Press 2 to exit without cancelling.

c When you have finished, press

Stop/Exit.

Sending a fax manually 5

Manual transmission lets you hear the dialling, ringing and fax-receiving tones while sending a fax.

a Make sure you are in Fax mode .

b Load your document. c Pick up the handset of an external

telephone and listen for a dial tone.

d Dial the fax number you want to call. e When you hear the fax tone, press

Mono Start or Colour Start.

 Press 1 when you choose the Fax

Mode to Advanced Mode and send

the Faxes from the scanner glass. (See Setting the Fax Logic on page page 20.)

f Replace the handset.

Out of Memory message 5

If you get an Out of Memory message while scanning the first page of a fax, press Stop/Exit to cancel the fax.

If you get an Out of Memory message while scanning a subsequent page, you will have the option to press Mono Start to send the pages scanned so far, or to press Stop/Exit to cancel the operation.

Note

If you get an Out of Memory message while faxing and you do not want to delete your stored faxes to clear the memory, you can send the fax in real time. (See Real time transmission on page 28.)

Receiving a Fax 6

Receive modes 6

You must choose a receive mode depending on the external devices and telephone services you have on your line.

Choosing the Receive Mode 6

By default, your machine will automatically receive any faxes that are sent to it. The diagram below will help you choose the correct mode. For more detailed information on the receive modes see Using receive modes on page 31 and Receive mode settings on page 32.

Do you want to use the telephone features of your machine (if available) or an external telephone or external telephone answering device connected on the same line as the machine?

Yes

Are you using the voice message function of an external telephone answering device?

Do you want the machine to answer fax and telephone calls automatically?

To set a receive mode follow the instructions below.

Fax Only

Manual

Fax/Tel

Yes

External TAD

Yes

a Press Menu, 0, 1. b Press a or b to choose Fax Only, Fax/Tel, External TAD or Manual.

Press OK.

c Press Stop/Exit.

The LCD will display the current receive mode.

12/10 11:53 Fax12/10 11:53 Fax

1 Current receive mode

Fax: Fax Only

Receiving a Fax

Using receive modes 6

Some receive modes answer automatically (Fax Only and Fax/Tel). You may want to change the ring delay before using these modes see Ring Delay on page 32.

Fax only 6

Fax only mode will automatically answer every call. If the call is a fax your machine will receive it.

Fax/Tel 6

Fax/Tel mode helps you automatically manage incoming calls, by recognising whether they are fax or voice calls and dealing with them in one of the following ways:

 Faxes will be automatically received.

 Voice calls will start the F/T ring to tell you

to pick up the line. The F/T ring is a fast double ring made by your machine.

Also see F/T Ring Time (Fax/Tel mode

only) on page 32 and Ring Delay on page 32.

External TAD 6

External TAD mode lets an external answering device manage your incoming calls. Incoming calls will be dealt with in one of the following ways:

 Faxes will be automatically received.

 Voice callers can record a message on the

external TAD.

For more information see Connecting an

external TAD (telephone answering device) on page 38.

Manual 6

Manual mode turns off all automatic answering functions.

To receive a fax in manual mode lift the handset of an external telephone or press Tel/R. When you hear fax tones (short repeating beeps), press Mono Start or Colour Start. Press 2 when you select the

Fax Mode to Advanced Mode. (See Setting the fax logic on page 20. ) You can also use

the Fax Detect feature to receive faxes by lifting a handset on the same line as the machine.

Also see Fax Detect on page 33.

Chapter 6

Receive mode settings 6

Ring Delay 6

The Ring Delay sets the number of times the machine rings before it answers in Fax Only or Fax/Tel mode.

(See Operation from extension

telephones on page 40 and Fax Detect on page 33.)

a Press Menu, 2, 1, 1. b Press a or b to choose how many times

the line rings before the machine answers. Press OK. If you choose 00, the line will not ring at all.

c Press Stop/Exit.

F/T Ring Time (Fax/Tel mode only) 6

If you set the Receive Mode to Fax/Tel, you need to decide how long the machine will signal you with its special pseudo/double-ring when you have a voice call. If it's a fax call, the machine receives the fax.

This pseudo/double-ring happens after the initial ringing from the telephone company. Only the machine rings and no other telephones on the same line will ring with the special pseudo/double-ring. However, you can still answer the call on any telephone on the same line as the machine. (See

Operation from extension telephones on page 40.)

a Press Menu, 2, 1, 2. b Press a or b to choose how long the

machine will ring to alert you that you have a voice call (20, 30, 40 or 70 seconds). Press OK.

c Press Stop/Exit.

Note

Even if the caller hangs up during the pseudo/double-ringing, the machine will continue to ring for the set time.

Receiving a Fax

Fax Detect 6

If Fax Detect is On: 6

The machine receives a fax call automatically, even if you answer the call. When you see Receiving on the LCD or when you hear ‘chirps’ through the handset you are using, just replace the handset. Your machine will do the rest.

If Fax Detect is Off: 6

If you are at the machine and answer a fax call by lifting the handset, press Mono Start or Colour Start. Press 2 when you select the

Fax Mode to Advanced Mode. (See Setting the fax logic on page 20. )

If you answered at an extension telephone, press l 5 1. (See Operation from extension telephones on page 40.)

Note

• If this feature is set to On, but your machine does not connect a fax call when you lift an extension or external telephone handset, press the Remote Activation Code l 5 1. At the machine, press Mono Start or Colour Start.

• If you send faxes from a computer on the same telephone line and the machine intercepts them, set Fax Detect to Off.

a Press Menu, 2, 1, 3.

Additional receiving operations 6

Printing a reduced incoming fax 6

If you choose On, the machine automatically reduces each page of an incoming fax to fit on one page of A4, Letter or Legal size paper.

The machine calculates the reduction ratio by using the page size of the fax and your Paper Size setting (Menu, 1, 3).

a Make sure you are in Fax mode .

b Press Menu, 2, 1, 5.

5.Auto Reduction

c Press a or b to choose On or Off.

Press OK.

d Press Stop/Exit.

b Press a or b to choose On (or Off).

Press OK.

c Press Stop/Exit.

Chapter 6

Receiving faxes into memory 6

As soon as the paper tray becomes empty during fax reception, the screen will display No Paper Fed, asking you to put paper in the paper tray. (See Loading paper and other media on page 12.) If you are unable to put paper in the paper tray the following will happen:

If Memory Receive is On: 6

The machine will carry on receiving the fax, with the remaining pages being stored in memory, if enough memory is available. Further incoming faxes will also be stored into memory until the memory is full. When the memory is full the machine will stop automatically answering calls. To print the faxes, put fresh paper in the tray.

If Memory Receive is Off: 6

The machine will carry on receiving the fax, with the remaining pages being stored in memory, if enough memory is available. The machine will then stop automatically answering calls until fresh paper is put in the paper tray. To print the last fax you received, put fresh paper in the tray.

a Make sure you are in Fax mode. b Press Menu, 2, 1, 6. c Press a or b to choose On or Off. Press

OK.

d Press Stop/Exit.

Telephone and External devices 7

Voice Operations 7

Tone or pulse 7

If you are using an external telephone and have a pulse dialling service, but need to send tone signals (for example, for telephone banking), follow the instructions below. If you have Touch Tone service, you will not need this feature to send tone signals.

a Lift the handset of the external

telephone.

b Press # on the control panel of your

machine. Any digits dialled after this will send tone signals. When you hang up, the machine will return to the pulse dialling service.

Fax/Tel mode 7

When the machine is in Fax/Tel mode, it will use the F/T Ring Time (pseudo/double-ringing) to alert you to pick up a voice call.

If you are at an external telephone, lift the handset of the external telephone, and then press Hook to answer.

Fax/Tel mode in Power Save mode 7

When the machine is in Power Save mode you can receive faxes if the Power Save setting is Fax Receive:On. (See Power Save setting on page 17.)

Fax/Tel mode does not work in power save mode. The machine will not answer telephone or fax calls and will keep ringing. If you are at an external or extension telephone, lift the handset and talk. If you hear fax tones, hold the handset until Fax Detect activates your machine. If the other party says they want to send you a fax, activate the machine by pressing l 51.

If you are at an extension telephone, you'll need to lift the handset during the F/T Ring Time and then press #51 between the pseudo/double-rings. If no one is on the line, or if someone wants to send you a fax, send the call back to the machine by pressing l 51.

Chapter 7

Telephone Service 7

Features like Voice Mail, Call Waiting, RingMaster, answering services, alarm systems or other custom features on one phone line may create problems with the operation of your machine.

Your fax machine lets you use the caller ID subscriber service offered by certain telephone companies.

Caller ID (Caller IDentification) (not available in certain area) 7

Caller ID is a telephone service that allows the subscriber to see a display of the caller's phone number as the telephone rings. It is a fast way to screen your calls. You can respond quickly to calls you missed, because caller IDs are received and stored in your fax machine memory. Besides the standard Caller ID feature, you can also select a single caller's phone number and call back.

Note

• To get the Caller ID service, you have to apply for it at your local telephone company.

• FSK and DTMF are the two modes for displaying your calls. The default mode of this machine is FSK. Please ask your local telephone company for whether your mode is FSK or DTMF. If your local telephone company uses DTMF mode, please switch your mode as follows. Contact your local telephone company or Brother dealer in the case that the feature does not work normally. Caller ID feature is not available in the following situation:

1 You have not applied for it at your local

telephone company.

2 The fax machine is connected to an

internal switchboard or other switch device.

3 Due to the switchboard problems or line

problems of local telephone companies, the feature may not work in some areas.

Advantages of Caller ID 7

For Business 7

All businesses profit from a quicker response to customer calls.

For Home 7

Residential customers can protect themselves from unwanted calls by checking the displayed name and number.

Setup Method 7

a Press Menu, 2, 0, 3.

3.Caller ID Type

b Press a or b to choose FSK or DTMF.

Press OK.

FSK

DTMF

c Press Stop/Exit.

How Does the Caller ID Work?7

The Caller ID Appears on the Display When Your Telephone Rings

As your telephone rings, the display shows you the caller’s phone number or name. And it will also show you the caller’s name, if the name has been stored as speed dial or one touch dial in your machine. Once you pick up the handset, the caller’s ID disappears.

Telephone and External devices

Note

•If ID Unknown appears on the display, it means that the call came from outside your caller ID service area or a public phone.

•If ID Withheld appears on the display, it means the caller intentionally blocked the transmission of his/her ID.

• If no caller ID was transmitted to your fax machine, PICK UP PHONE will remain on the display.

If the Caller ID is Stored in Your Machine’s Memory

The machine can store a maximum of the last 30 incoming caller IDs in the memory, along with the time and date of reception, The 31st call will cause the oldest ID to be erased.

The Caller ID information stored in the memory can be used for the following.

 Calling back by choosing one Caller ID

from the memory

You can scroll to choose one Caller ID to call back.

Viewing Caller ID List

Caller ID memory stores information for up to thirty calls; when the thirty-first call comes in, information about the first call is erased. You can scroll through Caller ID information to review those calls made to your machine.

a Press Menu, 2, 0, 4. b Press a or b to choose Display # and

press OK. If the name was not received, it will not be displayed.

c Press a or b to scroll through the Caller

ID memory to select the Caller ID you want to view and press OK. The next screen shows the caller’s telephone number and the date and time of the call.

d Press Stop/Exit.

Printing Caller ID List

a Press Menu, 2, 0, 4. b Press a or b to choose Print Report

and press OK.



Printing the Caller ID List.

You can review calls you received by checking the Caller IDs in memory. This report will list the Date, Time, Phone Number (Caller ID), and type of Call (Comment).

Note

• Before using Caller ID service, please

select a number larger than 02 when you set the Ring Delay. (See Ring Delay on page 32. )

• If not all of the telephone numbers can

be shown as normal, there may be some problems with the IP phone line or with the telephone companies.

c Press Mono Start or Colour Start. d Press Stop/Exit.

Chapter 7

Connecting an external TAD (telephone answering device)

You may choose to connect an external answering device. However, when you have an external TAD on the same telephone line as the machine, the TAD answers all calls and the machine ‘listens’ for fax calling (CNG) tones. If it hears them, the machine takes over the call and receives the fax. If it does not hear CNG tones, the machine lets the TAD continue playing your outgoing message so your caller can leave you a voice message.

The TAD must answer within four rings (the recommended setting is two rings). The machine cannot hear CNG tones until the TAD has answered the call, and with four rings there are only 8 to 10 seconds of CNG tones left for the fax ‘handshake’. Make sure you carefully follow the instructions in this guide for recording your outgoing message. We do not recommend using the toll saver feature on your external answering machine if it exceeds five rings.

DO NOT connect a TAD elsewhere on the same

telephone line.

Improper Setup

Connections 7

The external TAD must be connected as shown in the previous illustration.

a Set your external TAD to one or two

rings. (The machine's Ring Delay setting does not apply.)

b Record the outgoing message on your

external TAD.

c Set the TAD to answer calls. d Set the Receive Mode to

External TAD. (See Choosing the Receive Mode on page 30.)

Recording an outgoing message (OGM) on an external TAD 7

Note

If you do not receive all your faxes, cut the Ring Delay setting on your external TAD.

EXT.LINE

LINE

EXT.

1TAD

When the TAD answers a call, the LCD shows Telephone.

Timing is important in recording this message. The message sets up the ways to handle both manual and automatic fax reception.

a Record 5 seconds of silence at the

beginning of your message. (This allows your machine time to listen for the fax CNG tones of automatic transmissions before they stop.)

b Limit your speaking to 20 seconds.

Telephone and External devices

Note

We recommend beginning your OGM with an initial 5-second silence because the machine cannot hear fax tones over a resonant or loud voice. You may try omitting this pause, but if your machine has trouble receiving, then you must re-record the OGM to include it.

Multi-line connections (PBX) 7

We suggest you ask the company who installed your PBX to connect your machine. If you have a multi line system we suggest you ask the installer to connect the unit to the last line on the system. This prevents the machine being activated each time the system receives telephone calls. If all incoming calls will be answered by a switchboard operator we recommend that you set the Receive Mode to Manual.

We cannot guarantee that your machine will operate properly under all circumstances when connected to a PBX. Any difficulties with sending or receiving faxes should be reported first to the company who handles your PBX.

External and extension telephones

Connecting an external or extension telephone 7

You can connect a separate telephone as shown in the diagram below.

LINE

EXT.

1 Extension telephone

2 External telephone

When you are using an external telephone, the LCD shows Telephone.

EXT.

Note

Make sure the Telephone Line Type is set to PBX.

Chapter 7

Operation from extension telephones 7

If you answer a fax call on an extension or an external telephone plugged into the correct socket on the machine, you can make your machine take the call by using the Remote Activation Code. When you press the Remote Activation Code l 51, the machine starts to receive the fax.

If the machine answers a voice call and pseudo/double-rings for you to take over, use the Remote Deactivation Code #51 to take the call at an extension telephone. (See F/T Ring Time (Fax/Tel mode only) on page 32.)

If you answer a call and no one is on the line:

You should assume that you're receiving a manual fax.

Press l 51 and wait for the chirp or until the LCD shows Receiving, and then hang up.

Note

You can also use the Fax Detect feature to make your machine automatically take the call. (See Fax Detect on page 33. )

Using a cordless external telephone 7

Once the base unit of the cordless telephone has been connected to the same telephone line as the machine (see External and extension telephones on page 39), it is easier to answer calls during the Ring Delay if you carry the cordless handset around with you.

If you let the machine answer first, you will have to go to the machine so you can press Hook to send the call to the cordless handset.

Using remote codes 7

Remote Activation Code 7

If you answer a fax call on an extension or external telephone, you can tell your machine to receive it by dialling the Remote Activation Code l 51. Wait for the chirping sounds then replace the handset. See Fax Detect on page 33. Your caller will have to press Start to send the fax.

Remote Deactivation Code 7

If you receive a voice call and the machine is in F/T mode, it will start to sound the F/T (double) ring after the initial ring delay. If you pick up the call on an extension telephone you can turn the F/T ring off by pressing #51 (make sure you press this between the rings).

Changing the remote codes 7

If you want to use Remote Activation, you have to turn on the remote codes. The preset Remote Activation Code is l 51. The preset Remote Deactivation Code is #51. If you want to, you can replace them with your own codes.

a Press Menu, 2, 1, 4.

1.Setup Receive

4.Remote Codes

b Press a or b to choose On (or Off).

Press OK.

c Enter the new Remote Activation Code.

Press OK.

Telephone and External devices

d Enter the new Remote Deactivation

Code. Press OK.

e Press Stop/Exit.

Note

• If you are always disconnected when accessing your external TAD remotely, try changing the Remote Activation Code and Remote Deactivation Code to another three-digit code using the numbers 0-9, l, #.

• Remote Codes might not work with some telephone systems.

Dialling and storing numbers 8

How to Dial 8

Manual dialling 8

Press all of the digits of the fax number.

Speed Dialling 8

a Press Speed Dial.

Search 8

You can search for names you have stored in the Speed-Dial memories.

Press Speed Dial. Press OK and the navigation keys to search numerically, or use the dial pad to search alphabetically.

b Press OK and the # (hash) key, and

then the two digit Speed Dial number.

Note

If the LCD shows Not Registered when you enter a Speed Dial number, a number has not been stored at this location.

1 To search numerically.

2 To search alphabetically, you can use the

dial pad to enter the first letter of the name you are looking for.

Dialling and storing numbers

Fax Redial 8

If you are sending a fax manually and the line is busy, press Redial/Pause, and then press Mono Start or Colour Start to try again. If you want to make a second call to the last number dialled, you can save time by pressing Redial/Pause and Mono Start or

Colour Start.

Redial/Pause only works if you dialled from

the control panel.

If you are sending a fax automatically and the line is busy, the machine will automatically redial up to three times at five minute intervals.

Note

In Real Time Transmission the automatic redial feature does not work when using the scanner glass.

Storing numbers 8

You can set up your machine to do the following types of easy dialling: Speed Dial and Groups for broadcasting faxes. When you dial a Quick Dial number, the LCD shows the name, if you stored it, or the number.

Note

If you lose electrical power, the Quick Dial numbers that are in the memory will not be lost.

Storing a pause 8

Press

Redial/Pause

between numbers. If you are dialling overseas, you can press needed to increase the length of the pause.

to put a 3.5-second pause

Redial/Pause

as many times as

Chapter 8

Storing Speed Dial numbers 8

You can store up to 40 2-digit Speed Dial locations with a name. When you dial you will only have to press a few keys (For example:

Speed Dial, OK, #, the two-digit number, and Mono Start or Colour Start).

a Press Speed Dial and a or b to choose

Set Speed Dial. Press OK.

b Use the dial pad to enter a 2-digit

Speed Dial location number (01-40). Press OK.

c Enter the fax or telephone number

(up to 20 digits). Press OK.

d Do one of the following:

 Enter the name (up to 16 characters)

using the dial pad.

Press OK. (To help you enter letters, see Entering Text on page 115.)

 To store the number without a name,

press OK.

e Do one of the following:

Changing Speed Dial numbers 8

If you try to store a Speed Dial number where a number has already been stored, the LCD will show the name or number that has been stored there, and will ask you to do one of the following:

 Press 1 to change the stored number.

#05:MIKE

1.Change 2.Exit

 Press 2 to exit without making a change.

If you chose 1, you will be able to change the stored number and name, or enter a new one. Follow the instructions below:

a Enter a new number. Press OK. b Enter a new name. Press OK.

 To change a character, use d or c to

position the cursor under the character you want to change, then press Clear/Back. Re-enter the character.

 To finish the setting, press Stop/Exit.

 To store another Speed Dial

number, go to step b.

 To finish the setting, press

Stop/Exit.

Dialling and storing numbers

Setting up groups for broadcasting 8

If you regularly want to send the same fax message to many fax numbers you can set up a Group. Groups are stored on a Speed Dial number. Each group uses up a Speed Dial location. You can then send the fax message to all the numbers stored in a group just by entering a Speed Dial number, and then pressing Mono Start.

Before you can add numbers to a Group, you need to store them as Speed Dial numbers. You can have up to six small Groups, or you can assign up to 39 numbers to one large Group.

a Press Speed Dial and a or b to choose

Setup Groups. Press OK.

b Use the dial pad to enter the two-digit

Speed Dial number where you want to store the Group. Press OK.

c Use the dial pad to enter a Group

number (1 to 6). Press OK.

Setup Group:G0_

f Use the dial pad to enter a name for the

Group. Press OK.

Note

You can easily print a list of all your Speed Dial numbers. Numbers that are part of a group will be marked in the GROUP column. (See How to print a report on page 47.)

Combining Quick Dial numbers 8

You can combine more than one Quick Dial number when you dial. This feature may be useful if you need to dial an access code for a cheaper rate long distance carrier.

For example, you might have stored ‘555’ on Speed Dial #03 and ‘7000 ’ on Speed Dial #02. You can use them both to dial ‘555-7000’ if you press the following keys:

Speed Dial, OK, #03, Speed Dial, #02, and Start.

Numbers can be added manually by entering them on the dial pad:

Speed Dial, OK, #03, 7, 0, 0, 1 (on the dial pad), and Start.

d To add Speed Dial numbers follow the

instructions below: For example, for Speed Dial numbers 05 and 09. Press Speed Dial, 05, Speed Dial, 09. The LCD shows: #05#09.

G01:#05#09

e Press OK when you have finished

adding numbers.

This would dial ‘555–7001’. You can also add a pause by pressing the Redial/Pause key.

Printing Reports 9

Fax reports 9

You need to set up the Transmission Verification Report and Journal Period using the Menu key.

Transmission Verification Report 9

You can use the Transmission Report as proof that you sent a fax. This report lists the time and date of transmission and whether the transmission was successful (OK). If you choose On or On+Image, the report will print for every fax you send.

If you send a lot of faxes to the same place, you may need more than the job numbers to know which faxes you must send again. Choosing On+Image or Off+Image will print a section of the fax's first page on the report to help you remember.

When the Verification Report is turned Off or Off+Image, the Report will only print if there is a transmission error, with ERROR in the RESULT column.

a Press Menu, 2, 3, 1. b Press a or b to choose Off+Image, On,

On+Image or Off. Press OK.

c Press Stop/Exit.

Fax Journal (activity report) 9

You can set the machine to print a journal at specific intervals (every 50 faxes, 6, 12 or 24 hours, 2 or 7 days). If you set the interval to Off, you can still print the report Reports on page 47. The default setting is Every 50 Faxes.

a Press Menu, 2, 3, 2. b Press a or b to choose an interval.

Press OK. (If you choose 7 days, the LCD will ask you to choose the first day for the 7-day countdown.)

 6, 12, 24 hours, 2 or 7 days

The machine will print the report at the chosen time and then erase all jobs from its memory. If the machine's memory becomes full with 200 jobs before the time you chose has passed, the machine will print the Journal early and then erase all jobs from the memory. If you want an extra report before it is due to print, you can print it without erasing the jobs from the memory.

 Every 50 Faxes

The machine will print the Journal when the machine has stored 50 jobs.

c Enter the time to start printing in 24-hour

format. Press OK. (For example: enter 19:45 for 7:45 PM.)

d Press Stop/Exit.

Reports 9

The following reports are available:

1.XMIT Verify

Prints a Transmission Verification Report for your last transmission.

2.Help List

A help list about how to quickly program your machine.

3.Quick Dial

Lists names and numbers stored in the Speed Dial memory, in numerical order.

4.Fax Journal

Lists information about the last incoming and outgoing faxes. (TX: Transmit.) (RX: Receive.)

5.User Settings

Lists your settings.

Printing Reports

How to print a report 9

a Press Menu, 5. b Do one of the following:

 Press a or b to choose the report you

want. Press OK.

 Enter the number of the report you

want to print. For example, press 2 to print the help list.

c Press Mono Start. d Press Stop/Exit.

Chapter 9

Section III

Copy III

Making copies 50

Making copies 10

How to copy 10

Entering Copy mode 10

Press (Copy) to enter Copy mode. The

default setting is Fax. You can change the number of seconds or minutes that the machine stays in Copy mode. (Mode Timer on page 18.)

The LCD shows the default copy setting:

Making multiple copies 10

You can make up to 99 copies.

a Make sure you are in Copy mode .

b Load your document.

(See Loading documents on page 6.)

c Use the dial pad to enter the number of

copies (up to 99).

d Press Mono Start or Colour Start.

Note

(MFC-265C only)

To sort your copies, press the

Copy Options key. (See Sorting copies using the ADF (Monochrome only) (MFC-265C only) on page 54.)

Stop copying 10

123

1 Copy Ratio

2Quality

3 No of Copies

Making a single copy 10

a Make sure you are in Copy mode .

b Load your document.

(See Loading documents on page 6.)

c Press Mono Start or Colour Start.

To stop copying, press Stop/Exit.

Making copies

Copy options 10

When you want to quickly change the copy settings temporarily for the next copy, use the Copy Options key.

The machine returns to its default settings 1 minute after it finishes copying, or if the mode timer returns the machine to Fax mode. For more information see Mode Timer on page 18.

Press Menu

selection

Press Quality Normal

Enlarge /Reduce

Paper Type

Paper Size

Brightness

Stack/Sort

Page Layout

No. of Copies

Options

Fast

Best

50%/69%/78%/ 83%/93%/97%/ 100%/104%/ 142%/186%/ 198%/200%/

Custom(25-400%)

Plain Paper

Inkjet Paper

Brother Photo

Other Photo

Transparency

Letter

Legal

10(W) x 15(H)cm

- nnonn +55

Stack

Sort

Off(1 in 1)

2in1(P)

2in1(L)

4in1(P)

4in1(L)

Poster(3 x 3)

No. of Copies: 01

(01 - 99)

Page

Note

You can save the copy settings you use most often by setting them as default. You can find instructions on how to do this in the section for each feature.

Chapter 10

Changing copy speed and quality 10

You can choose from a range of quality settings. The default setting is Normal.

To temporarily change the quality setting, follow the instruction below:

Press

Normal Normal is the

recommended mode for ordinary print outs. This produces good copy quality with good copy speed.

Fast Fast copy speed

and lowest ink consumption. Use to save time printing documents to be proof-read, large documents or many copies.

Best Use best mode to

copy precise images such as photographs. This provides the highest resolution and the slowest speed.

a Make sure you are in Copy mode .

b Load your document. c Use the dial pad to enter the number of

copies (up to 99).

d Press Copy Options and a or b to

choose Quality. Press OK.

To change the default setting, follow the instruction below:

a Press Menu, 3, 1.

1.Quality

b Press a or b to choose Normal, Best or

Fast quality. Press OK.

c Press Stop/Exit.

Enlarging or reducing the image copied 10

You can choose the following enlargement or reduction ratios:

Custom(25-400%) allows you to enter a ratio from 25% to 400%.

Auto sets the machine to calculate the reduction ratio that best fits the size of paper.

Press

and then a or b to choose

Enlarge/Reduce

To enlarge or reduce the next copy follow the instruction below:

Custom(25-400%)

200%

198% 10x15cmiA4

186%10x15cmiLTR

142% A5iA4

104% EXEiLTR

100%

97% LTRiA4

93% A4iLTR

83% LGLiA4

78% LGLiLTR

69% A4iA5

50%

e Press a or b to choose Normal, Best or

Fast quality. Press OK.

f Press Mono Start or Colour Start.

a Make sure you are in Copy mode .

b Load your document. c Use the dial pad to enter the number of

copies (up to 99).

Making copies

d Press Copy Options and a or b to

choose Enlarge/Reduce. Press OK.

e Do one of the following:

 Press a or b to choose the

enlargement or reduction ratio you want. Press OK.

 Press a or b to choose

Custom(25-400%). Press OK. Use the dial pad to enter an enlargement or reduction ratio from 25% to 400%. (For example, press 5 3 to enter 53%.) Press OK.

f Press Mono Start or Colour Start.

Note

Page Layout Options are not available with Enlarge/Reduce.

Making N in 1 copies or a poster 10

The N in 1 copy feature can help you save paper by letting you copy two or four pages onto one printed page.

You can also produce a poster. When you use the poster feature your machine divides your document into sections, then enlarges the sections so you can assemble them into a poster. If you want to print a poster, use the scanner glass.

Important 10

 Please make sure paper size is set to

Letter, Legal or A4.

 You cannot use the Enlarge/Reduce

setting with the N in 1 and Poster features.

 N in 1 colour copies are not available.

 (P) means Portrait and (L) means

Landscape.

a Make sure you are in Copy mode .

b Load your document. c Use the dial pad to enter the number of

copies (up to 99).

d Press Copy Options and a or b to

choose Page Layout. Press OK.

e Press a or b to choose Off(1 in 1),

2in1(P), 2in1(L), 4in1(P), 4in1(L) or Poster(3 x 3).

Press OK.

f Press Mono Start to scan the

document. You can also press Colour Start if you are using Poster layout. If you are making a poster or placed the document in the ADF, the machine scans the pages and starts printing.

If you are using the scanner glass, go to g.

g After the machine scans the page, press

1 to scan the next page.

Next Page?

1.Yes 2.No

h Put the next document on the scanner

glass. Press OK. Repeat g and h for each page of the layout.

Set Next Page

Then Press OK

i After all the pages have been scanned,

press 2 to finish.

 You can only make one poster copy at a

time.

Chapter 10

Place your document face down in the direction shown below:

 2 in 1 (P)

 2 in 1 (L)

 4 in 1 (P)

 4 in 1 (L)

 Poster (3x3)

You can make a poster size copy of a photograph.

Sorting copies using the ADF (Monochrome only) (MFC-265C only) 10

You can sort multiple copies. Pages will be sorted in the order 1 2 3, 1 2 3, 1 2 3, and so on.

a Make sure you are in Copy mode .

b Load your document. c Use the dial pad to enter the number of

copies (up to 99).

d Press Copy Options and a or b to

choose Stack/Sort. Press OK.

e Press a or b to choose Sort.

Press OK.

f Press Mono Start.

Note

Page Layout Options are not available with Stack/Sort.

Making copies

Adjusting Brightness, Contrast and Colour 10

Brightness 10

To temporarily change the brightness setting, follow the instructions below:

a Make sure you are in Copy mode .

b Load your document. c Use the dial pad to enter the number of

copies (up to 99).

d Press Copy Options and a or b to

choose Brightness. Press OK.

-nnonn+

e Press a or b to make a lighter or darker

copy. Press OK.

f Press Mono Start or Colour Start.

To change the default setting follow the instructions below:

Colour saturation 10

a Press Menu, 3, 4.

4.Color Adjust

b Press a or b to choose 1.Red, 2.Green

or 3.Blue. Press OK.

c Press a or b to change the colour

saturation. Press OK.

d Do one of the followings:

 Return to b to choose the next

colour.

 Press Stop/Exit.

a Press Menu, 3, 2. b Press a or b to make a lighter or darker

copy. Press OK.

c Press Stop/Exit.

Contrast 10

Adjust the contrast to help an image look sharper and more vivid.

a Press Menu, 3, 3.

3.Contrast

b Press a or b to change the contrast.

Press OK.

c Press Stop/Exit.

Chapter 10

Paper options 10

Paper type 10

If you are copying on special paper, set the machine for the type of paper you are using to get the best print quality.

a Make sure you are in Copy mode .

b Load your document. c Use the dial pad to enter the number of

copies (up to 99).

d Press Copy Options and a or b to

choose Paper Type. Press OK.

e Press a or b to choose the type of paper

you are using (Plain Paper,

Inkjet Paper, Brother Photo, Other Photo or Transparency).

Press OK.

f Press Mono Start or Colour Start.

Note

To change the default paper type setting see Paper Type on page 18.

Paper size 10

If copying on paper other than A4 size, you will need to change the paper size setting. You can copy on Letter, Legal, A4, A5 or Photo [10cm (W) × 15cm (H)] paper.

a Make sure you are in Copy mode .

b Load your document. c Use the dial pad to enter the number of

copies (up to 99).

d Press Copy Options and a or b to

choose Paper Size. Press OK.

e Press a or b to choose the size of paper

you are using Letter, Legal, A4, A5 or 10(W) x 15(H)cm. Press OK.

f Press Mono Start or Colour Start.

Note

To change the default paper size setting see Paper Size on page 18.

Section IV

Direct Photo Printing

Printing photos from a memory card or USB Flash memory drive

Printing photos from a camera 67

Printing photos from a memory

card or USB Flash memory drive

Note

The MFC-230C only supports a USB Flash memory drive.

PhotoCapture Center™ Operations

Printing from a memory card or USB Flash memory drive without a PC 11

Even if your machine is not connected to your computer, you can print photos directly from digital camera media or USB Flash Memory drive. (See How to print from a memory card or USB Flash memory drive on page 61.)

Using PhotoCapture Center™ from your computer 11

Using a memory card or USB Flash memory drive 11

Your Brother machine has media drives (slots) for use with popular digital camera

media: CompactFlash Memory Stick Pro™, SecureDigital,

MultiMediaCard™, xD-Picture Card™ and a USB Flash memory drive.

CompactFlash

SecureDigital

MultiMediaCard™

22 mm or less

, Memory Stick®,

Memory Stick Pro™

xD-Picture Card™

Memory Stick

You can access a memory card or USB Flash memory drive that is inserted in front of the machine from your PC.

(See PhotoCapture Center™ for Windows or Remote Setup & PhotoCapture Center™

for Macintosh on the CD-ROM.)

in the Software User's Guide

11 mm or less

USB Flash memory

drive

 miniSD™ can be used with a miniSD™

adapter.

 Memory Stick Duo™ can be used with a

Memory Stick Duo™ adapter.

 Memory Stick Pro Duo™ can be used with

a Memory Stick Pro Duo™ adapter.

 Adapters are not included with the

machine. Contact a third party supplier for adapters.

The PhotoCapture Center™ feature lets you print digital photos from your digital camera at high resolution to get photo quality printing.

Printing photos from a memory card or USB Flash memory drive

Memory cards or a USB Flash memory drive folder structure11

Your machine is designed to be compatible with modern digital camera image files and memory cards; however, please read the points below to avoid errors:

 The image file extension must be .JPG

(Other image file extensions like .JPEG, .TIF, .GIF and so on will not be recognized).

 PhotoCapture Center™ printing must be

performed separately from PhotoCapture Center™ operations using the PC. (Simultaneous operation is not available.)

 IBM Microdrive™ is not compatible with

the machine.

 The machine can read up to 999 files on a

memory card or USB Flash memory drive.

 CompactFlash

 This product supports xD-Picture Card™

Type M / Type H.

 The DPOF file on the memory cards must

be in a valid format. (See DPOF printing on page 63.)

Type II is not supported.

Please be aware of the following:

 When printing the INDEX or IMAGE, the

PhotoCapture Center™ will print all the valid images, even if one or more images have been corrupted. The corrupted image will not be printed.

 (memory card users)

Your machine is designed to read memory cards that have been formatted by a digital camera.

When a digital camera formats a memory card it creates a special folder into which it copies image data. If you need to modify the image data stored on a memory card with your PC, we recommend that you do not modify the folder structure created by the digital camera. When saving new or modified image files to the memory card we also recommend you use the same folder your digital camera uses. If the data is not saved to the same folder, the machine may not be able to read the file or print the image.

 (USB Flash memory drive users)

This machine supports USB Flash memory drives that have been formatted

by Windows

Chapter 11

Getting started 11

Firmly put a memory card or USB Flash memory drive into the correct slot.

1 2 3 4

1 USB Flash memory drive

2 CompactFlash

3 SecureDigital, MultiMediaCard™

4 Memory Stick

5 xD-Picture Card™

CAUTION

The USB direct interface supports only a USB Flash memory drive, a PictBridge compatible camera, or a digital camera that uses the USB mass storage standard. Any other USB devices are not supported.

, Memory Stick Pro™

The PhotoCapture key indications

 PhotoCapture light is on, the memory

card or USB Flash memory drive is properly inserted.

 PhotoCapture light is off, the memory

card or USB Flash memory drive is not properly inserted.

 PhotoCapture light is blinking, the

memory card or USB Flash memory drive is being read or written to.

CAUTION

DO NOT unplug the power cord or remove the memory card or USB Flash memory drive from the media drive (slot) or USB direct interface while the machine is reading or writing to the memory card or USB Flash memory drive (the

PhotoCapture key is blinking). You will lose your data or damage the card.

The machine can only read one device at a time so do not put more than one device in the slot.

Printing photos from a memory card or USB Flash memory drive

How to print from a memory card or USB Flash memory drive

Before printing a photo you must first print a thumbnail index to choose the number of the photo you want to print. Follow the instructions below to start printing directly from your memory card or USB Flash memory drive:

a Make sure you have put the memory

card or USB Flash memory drive in the correct slot. The LCD will show the following message:

C.Flash Active

Press PhotoCa...

b Press PhotoCapture. For DPOF

printing, see DPOF printing on page 63.

c Press a or b to choose Print Index.

Press OK.

Print Index (Thumbnails) 11

The PhotoCapture Center™ assigns

numbers for images (such as No.1, No.2, No.3, and so on).

The PhotoCapture Center™ does not recognize any other numbers or file names that your digital camera or PC has used to identify the pictures. You can print a thumbnail page (Index page with 5 images per line). This will show all the pictures on the memory card or USB Flash memory drive.

d Press Colour Start to start printing the

index sheet. Make a note of the image number you want to print. See Print Index (Thumbnails) on page 61.

e Press a or b to choose Print Images

and then press OK. See Printing Images on page 62.

f Enter the image number and press OK. g Press Colour Start to start printing.

Note

• Only file names that are 8 characters or less will be printed correctly on the index sheet.

• File names cannot be printed correctly if they are Chinese. However it does not affect any functions.

a Make sure you have put the memory

card or USB Flash memory drive in the correct slot.

Press (PhotoCapture).

b Press a or b to choose Print Index.

Press OK.

c Press a or b to choose the type of paper

you are using, Plain Paper,

Inkjet Paper, Brother Photo or Other Photo.

Press OK.

Chapter 11

d Press a or b to choose the paper size

you are using, Letter or A4. Press OK.

e Press Colour Start to print.

Printing Images 11

Before you can print an individual image, you have to know the image number.

a Make sure you have put the memory

card or USB Flash memory drive in the correct slot.

b Print the index first. (See Print Index

(Thumbnails) on page 61.)

Press (PhotoCapture).

c Press a or b to choose Print Images.

Press OK.

Note

If your memory card or USB Flash memory drive contains valid DPOF information, the LCD will show

DPOF Print:Yes. See DPOF printing on page 63.

d Enter the image number that you want to

print from the thumbnail index. Press OK.

No.:1,3,6

Note

• Multiple numbers can be entered by using the OK key to separate numbers. For example 1, OK, 3, OK, 6 would print images 1,3 and 6. The # key can be used to print a range of numbers, for example 1, #, 5 would print all images from 1 to 5.

• You can enter up to 12 characters (including commas) for the image numbers you want to print.

e After you have chosen the images you

want to print, press OK to choose your settings. If you have already chosen your settings, press Colour Start.

Printing photos from a memory card or USB Flash memory drive

f Press a or b to choose the type of paper

you are using, Plain Paper,

Inkjet Paper, Brother Photo or Other Photo.

Press OK.

g Press a or b to choose the paper size

you are using, Letter, A4, 10x15cm or 13x18cm.

 If you choose Letter or A4, go to h.

 If you choose another size, go to i.

 If you have finished choosing

settings, press Colour Start.

h Press a or b to choose the print size

(10 x 8cm, 13x9cm, 15 x 10cm, 18 x 13cm or 20 x 15cm). Press OK.

i Do one of the following:

 To choose the number of copies go

to j.

 If you have finished choosing

settings, press Colour Start.

j Enter the number of copies you want.

Press OK.

DPOF printing 11

DPOF stands for Digital Print Order Format.

Major digital camera manufacturers (Canon Inc., Eastman Kodak Company. Fuji Photo Film Co. Ltd., Matsushita Electric Industrial Co. Ltd. and Sony Corporation) created this standard to make it easier to print images from a digital camera.

If your digital camera supports DPOF printing, you will be able to choose on the digital camera display the images and number of copies you want to print.

When the memory card (CompactFlash

Memory Stick SecureDigital, MultiMediaCard™ or xD-Picture Card™) with DPOF information is put into your machine, you can print the chosen image easily.

To print directly from a memory card with DPOF information on it follow the instructions below:

, Memory Stick Pro™,

a Firmly insert the memory cards into the

correct slot.

C.Flash Active

k Press Colour Start to print.

The printing positions when using A4 are shown below.

10 x 8cm

18 x 13cm520 x 15cm

13 x 9cm

15 x 10cm

Press (PhotoCapture).

b Press a or b to choose Print Images.

Press OK.

c If there is a DPOF file on the card, the

LCD will show:

DPOF Print:Yes

d Press a or b to choose

DPOF Print:Yes. Press OK.

e Press a or b to choose the type of paper

you are using, Plain Paper,

Inkjet Paper, Brother Photo or Other Photo.

Press OK.

Chapter 11

f Press a or b to choose the paper size

you are using, Letter, A4, 10x15cm or 13x18cm.

 If you chose Letter or A4, go to g.

 If you chose another size, go to h.

g Press a or b to choose the print size

(10 x 8cm, 13x9cm, 15 x 10cm, 18 x 13cm or 20 x 15cm). Press OK.

h Press Colour Start to print.

PhotoCapture Center™ print settings

These settings will remain until you change them again.

Print speed and quality 11

a Press Menu, 4, 1. b Press a or b to choose Normal or

Photo. Press OK.

c Press Stop/Exit.

Paper Options 11

Paper Type 11

a Press Menu, 4, 2.

b Press a or b to choose Plain Paper,

Inkjet Paper, Brother Photo or Other Photo.

Press OK.

c Press Stop/Exit.

Paper Size 11

a Press Menu, 4, 3. b Press a or b to choose the paper size

you are using, Letter, A4, 10x15cm or 13x18cm.

Press OK.

c Press Stop/Exit.

Printing photos from a memory card or USB Flash memory drive

Print Size 11

This setting is available only when you choose Letter or A4 in the paper size setting.

a Press Menu, 4, 4. b Press a or b to choose the print size you

are using, 10 x 8cm, 13 x 9cm, 15 x 10cm, 18 x 13cm or 20 x 15cm.

Press OK.

c Press Stop/Exit.

Adjusting Brightness and Contrast 11

Brightness 11

a Press Menu, 4, 5. b Press a or b to make a lighter or darker

print. Press OK.

Cropping 11

If your photo is too long or wide to fit the available space on your chosen layout, part of the image will be automatically cropped.

The default setting is On. If you want to print the whole image, turn this setting to Off.

a Press Menu, 4, 7. b Press a or b to choose Off (or On).

Press OK.

c Press Stop/Exit.

Cropping:On

Cropping:Off 11

c Press Stop/Exit.

Contrast 11

You can choose the contrast setting. More contrast will make an image look sharper and more vivid.

a Press Menu, 4, 6. b Press a or b to increase or decrease the

contrast. Press OK.

c Press Stop/Exit.

Borderless printing 11

This feature expands the printable area to the edges of the paper. Printing time will be slightly slower.

a Press Menu, 4, 8. b Press a or b to choose Off (or On).

Press OK.

c Press Stop/Exit.

Chapter 11

Understanding the Error Messages

Once you are familiar with the types of errors that can occur while you are using PhotoCapture Center™, you can easily identify and troubleshoot any problems.

 Hub is Unusable

This message will appear if a Hub or USB Flash memory drive with a Hub has been put into the USB direct interface.

 Media Error

This message will appear if you put in a memory card that is either bad or not formatted, or when there is a problem with the media drive. To clear this error, take out the memory card.

 No File

This message will appear if you try to access a memory card or USB Flash memory drive in the drive (slot) that does not contain a .JPG file.

 Out of Memory

This message will appear if you are working with images that are too large for the machine's memory.

 Unusable Device

This message will appear if a USB device or USB Flash memory drive that is not supported has been connected to the USB direct interface. (For more information, visit us at http://solutions.brother.com This message will also appear if you connect a broken device to the USB direct interface.

Printing photos from a camera 12

Printing photos directly from a PictBridge camera 12

Your Brother machine supports the PictBridge standard, allowing you to connect to and print photos directly from any PictBridge compatible digital camera.

If your camera is using the USB Mass Storage standard, you can also print photos from a digital camera without PictBridge. See

Printing photos directly from a digital camera (without PictBridge) on page 69.

PictBridge requirements 12

To avoid errors, remember the following points:

 The machine and the digital camera must

be connected using a suitable USB cable.

 The image file extension must be .JPG

(Other image file extensions like .JPEG, .TIF, .GIF and so on will not be recognized).

 PhotoCapture Center™ operations are

not available when using the PictBridge feature.

Setting your digital camera 12

Make sure your camera is in PictBridge mode. Some of the settings listed below may not be available for your PictBridge compatible digital camera.

Depending on your camera some of these settings may not be available.

Camera Menu Selections

Paper Size 10×15cm, Printer Settings

Paper Type Plain Paper,

Layout Borderless: On,

DPOF setting

Print Quality Normal, Fine,

See DPOF printing on page 68 for more details.

If your camera is set to use the Printer Settings (Default setting), the machine will print your photo using the following settings.

Settings Options

Paper Size 10×15cm

Paper Type Glossy Paper

Layout Borderless: On

Print Quality Fine

 When your camera does not have any

menu selections, this setting is also used.

 The names and availability of each setting

depends on the specification of your camera.

Please refer to the documentation supplied with your camera for more detailed information on changing PictBridge settings.

Options

(Default setting)

Glossy Paper, Inkjet Paper, Printer Settings (Default

setting)

Borderless: Off, Printer Settings (Default

setting)

Printer Settings (Default

setting)

Chapter 12

Printing Images 12

Note

Remove any memory cards or USB Flash memory drive from the machine before connecting a digital camera.

a Make sure that your camera is turned

off. Connect your camera to the USB direct interface (1) on the machine using the USB cable.

DPOF printing 12

DPOF stands for Digital Print Order Format.

Major digital camera manufacturers (Canon Inc., Eastman Kodak Company, Fuji Photo Film Co. Ltd., Matsushita Electric Industrial Co. Ltd. and Sony Corporation) created this standard to make it easier to print images from a digital camera.

If your digital camera supports DPOF printing, you will be able to choose on the digital camera display the images and number of copies you want to print.

1 USB direct interface

b Turn on the camera.

When the machine has recognized the camera, the LCD shows the following message:

Camera Connected

c Choose the photo you want to print

following the instructions from your camera. When the machine starts printing a photo, the LCD will show Printing.

To prevent damage to your machine, do not connect any device other than a digital camera or USB Flash memory drive to the USB direct interface.

WARNING

Printing photos from a camera

Printing photos directly from a digital camera (without PictBridge)

If your camera supports the USB Mass Storage standard, you can connect your camera in storage mode. This enables you to print photos from your camera.

If you would like to print photos in PictBridge mode, see Printing photos directly from a PictBridge camera on page 67.

Note

The name, availability and operation differ among digital cameras. Please refer to the documentation supplied with your camera for detailed information, such as how to switch from PictBridge mode to USB mass storage mode.

Printing Images 12

Note

Remove any memory cards or USB Flash

memory drive from the machine before connecting a digital camera.

a Make sure that your camera is turned

off. Connect your camera to the USB direct interface (1) on the machine using the USB cable.

1 USB direct interface

b Turn on the camera. c Follow the steps in Printing

Images on page 62.

To prevent damage to your machine, do not connect any device other than a digital camera or USB Flash memory drive to the USB direct interface.

WARNING

Chapter 12

Understanding the Error Messages 12

Once you are familiar with the types of errors that can occur while you are printing from a camera, you can easily identify and troubleshoot any problems.

 Out of Memory

This message will appear if you are working with images that are too large for the machine's memory.

 Unusable Device

This message will appear if you connect a camera which is not in PictBridge mode nor using the USB Mass Storage standard. This message can also appear if you connect a broken device to the USB direct interface.

For more detailed solutions see Error messages on page 88.

Section V

Software V

Software features 72

Software features 13

The CD-ROM includes the Software User’s Guide for features available when connected to a computer (for example, printing and scanning). The guide has easy to use links that, when clicked, will take you directly to a particular section.

You can find information on these features:

 Printing

 Scanning

 ControlCenter3 (for Windows

 ControlCenter2 (for Macintosh

 Faxing from your computer

 PhotoCapture Center™

How to read the HTML User’s Guide

This is a quick reference to use the HTML User’s Guide.

(For Windows

)

Note

If you have not installed the software, see Viewing Documentation on page 2.

a From the Start menu, point to Brother,

MFC-XXXX (where XXXX is your model

number) from the programs group, then click User’s Guides in HTML format.

c Click the heading you would like to read

from the list at the left of the window.

(For Macintosh®)

a Make sure your Macintosh

on. Insert the Brother CD-ROM into your CD-ROM drive.

is turned

b Double-click the Documentation icon. c Double-click your language folder, and

then double-click the top page file.

d Click SOFTWARE USER’S GUIDE in

the top menu, and then click the heading you would like to read from the list at the left of the window.

b Click SOFTWARE USER’S GUIDE

from the top menu.

Section VI

Appendixes VI

Safety and Legal 74 Troubleshooting and Routine Maintenance 82 Menu and Features 106 Specifications 116 Glossary 129

Safety and Legal A

Choosing a location A

Put your machine on a flat, stable surface that is free of vibration and shocks, such as a desk. Put the machine near a telephone socket and a standard, grounded electrical socket. Choose a location where the temperature remains between 10° C and 35° C.

CAUTION

• Avoid placing your machine in a high-traffic area.

• Avoid placing your machine on a carpet.

• DO NOT put the machine near heaters, air conditioners, refrigerators, medical equipment, chemicals or water.

• DO NOT expose the machine to direct sunlight, excessive heat, moisture, or dust.

• DO NOT connect your machine to electrical sockets controlled by wall switches or automatic timers.

• Disruption of power can wipe out information in the machine's memory.

• Do not connect your machine to electrical sockets on the same circuit as large appliances or other equipment that might disrupt the power supply.

• Avoid interference sources, such as speakers or the base units of non-Brother cordless telephones.

Safety and Legal

To use the machine safely A

Please keep these instructions for later reference and read them before attempting any maintenance.

WARNING

There are high voltage electrodes inside the machine. Before you clean the inside of the machine, make sure you have unplugged the telephone line cord first and then the power cord from the electrical socket. Doing this will prevent an electrical shock.

DO NOT handle the plug with wet hands. Doing this might cause an electrical shock.

DO NOT pull in the middle of the AC power cord. Doing this might cause an electrical shock.

DO NOT put your hands on the edge of the machine under the document cover or the scanner cover. Doing this may cause injury.

DO NOT put your hands on the edge of the paper tray under the output paper tray cover. Doing this may cause injury.

DO NOT touch the paper feed roller. Doing this may cause injury.

DO NOT touch the area shaded in the illustration. Doing this may cause injury.

Safety and Legal

When moving the machine you must lift it from the base, by placing a hand at each side of the unit as shown in the illustration. DO NOT carry the machine by holding the scanner cover.

DO NOT use flammable substances or any type of spray to clean the inside or outside of the machine. Doing this may cause a fire or electrical shock.

If the machine becomes hot, releases smoke, or generates any strong smells, immediately turn off the power switch and unplug the machine from the electrical socket. Call your Brother dealer or Brother Customer Service.

If metal objects, water or other liquids get inside the machine, immediately turn off the power switch and unplug the machine from the electrical socket. Call your Brother dealer or Brother Customer Service.

WARNING

• Use caution when installing or modifying telephone lines. Never touch telephone wires or terminals that are not insulated unless the telephone line has been unplugged at the wall socket. Never install telephone wiring during a lightning storm. Never install a telephone wall socket in a wet location.

• This product must be installed near an electrical socket that is easily accessible. In case of an emergency, you must unplug the power cord from the electrical socket to shut off the power completely.

• Always make sure the plug is fully inserted.

WARNING

IMPORTANT SAFETY INSTRUCTIONS

When using your telephone equipment, basic safety precautions should always be followed to reduce the risk of fire, electric shock and injury to people, including the following:

1 DO NOT use this product near water, for example, near a bath tub, wash bowl, kitchen sink

or washing machine, in a wet basement or near a swimming pool.

2 Avoid using this product during an electrical storm. There may be a remote risk of electric

shock from lightning.

3 DO NOT use this product to report a gas leak in the vicinity of the leak.

Important safety instructions A

1 Read all of these instructions.

2 Save them for later reference.

3 Follow all warnings and instructions marked on the product.

4 Unplug this product from the wall socket before cleaning the inside of the machine. DO NOT

use liquid or aerosol cleaners. Use a damp cloth for cleaning.

5 DO NOT use this product near water.

6 DO NOT place this product on an unstable cart, stand, or table. The product may fall, causing

serious damage to the product.

7 Slots and openings in the casing and the back or bottom are provided for ventilation. To ensure

reliable operation of the product and to protect it from overheating, these openings must not be blocked or covered. The openings should never be blocked by placing the product on a bed, sofa, rug, or other similar surface. This product should never be placed near or over a radiator or heater. This product should never be placed in a built-in installation unless adequate ventilation is provided.

8 This product should be operated from the type of power source indicated on the label. If you

are not sure of the type of power available, call your dealer or local power company.

Safety and Legal

9 Use only the power cord supplied with this machine.

10 This product is equipped with a 3-wire grounded plug, a plug having a third (grounded) pin.

This plug will only fit into a grounded power outlet. This is a safety feature. If you are unable to insert the plug into the outlet, call your electrician to replace your obsolete outlet. DO NOT defeat the purpose of the grounded plug.

11 DO NOT allow anything to rest on the power cord. DO NOT place this product where people

can walk on the cord.

12 DO NOT place anything in front of the machine that will block received faxes. DO NOT place

anything in the path of received faxes.

13 Wait until pages have exited the machine before picking them up.

14 Unplug this product from the power socket and refer all servicing to Brother Authorized Service

Personnel under the following conditions:

 When the power cord is damaged or frayed.

 If liquid has been spilled into the product.

 If the product has been exposed to rain or water.

 If the product does not operate normally when the operating instructions are followed,

adjust only those controls that are covered by the operating instructions. Incorrect adjustment of other controls may result in damage and will often require extensive work by a qualified technician to restore the product to normal operation.

 If the product has been dropped or the casing has been damaged.

 If the product exhibits a distinct change in performance, indicating a need for service.

15 To protect your product against power surges, we recommend the use of a power protection

device (Surge Protector).

16 To reduce the risk of fire, electric shock and injury to people, note the following:



Do not use this product near appliances that use water, a swimming pool, or in a wet basement.

 Do not use the machine during an electrical storm (there is the remote possibility of an

electrical shock) or to report a gas leak in the vicinity of the leak.

IMPORTANT - For your safety A

To ensure safe operation, the supplied three-pin plug must be inserted only into a standard three-pin electrical socket that is effectively grounded through the normal household wiring.

The fact that the equipment operates satisfactorily does not imply that the power is grounded and that the installation is completely safe. For your safety, if in any doubt about the effective grounding of the power, consult a qualified electrician.

Legal limitations for copying A

It is an offence to make reproductions of certain items or documents with the intent to commit fraud. This memorandum is intended to be a guide rather than a complete list.We suggest you check with relevant legal authorities if in doubt about a particular item or document.

The following are examples of documents which should not be copied:

 Money

 Bonds or other certificates of indebtedness

 Certificates of Deposit

 Armed Forces Service or Draft papers.

 Passports

 Postage Stamps (cancelled or uncancelled)

 Immigration Papers

 Welfare documents

 Cheques or Drafts drawn by Governmental Agencies

 Identification Documents, badges or insignias

 Licences and Certificates of Title to motor vehicles

Copyrighted works cannot be copied. Sections of a copyrighted work can be copied for ‘fair dealing’. Multiple copies would indicate improper use.

Works of art should be considered the equivalent of copyrighted works.

Licenses and Certificates of Title to motor vehicles may not be copied under certain state/provincial laws.

Safety and Legal

Trademarks A

The Brother logo is a registered trademark of Brother Industries, Ltd.

Brother is a registered trademark of Brother Industries, Ltd.

Multi-Function Link is a registered trademark of Brother International Corporation.

Microsoft and Windows are registered trademarks of Microsoft Corporation in the U.S. and other countries.

Windows Vista is either a registered trademark or trademark of Microsoft Corporation in the United States and/or other countries.

Macintosh and TrueType are registered trademarks of Apple Inc.

Presto! PageManager is a registered trademark of NewSoft Technology Corporation.

Microdrive is a trademark of International Business Machine Corporation.

CompactFlash is a registered trademark of SanDisk Corporation.

Memory Stick is a registered trademark of Sony Corporation.

SanDisk is a licensee of the SD and miniSD trademarks.

MultiMediaCard is a trademark of Infineon Technologies and licensed to the MultiMediaCard Association.

xD-Picture Card is a trademark of Fujifilm Co. Ltd., Toshiba Corporation and Olympus Optical Co. Ltd.

PictBridge is a trademark.

Memory Stick Pro, Memory Stick Pro Duo, Memory Stick Duo and MagicGate are trademarks of Sony Corporation.

FaceFilter Studio is a trademark of Reallusion, Inc.

Each company whose software title is mentioned in this manual has a Software License Agreement specific to its proprietary programs.

All other brand and product names mentioned in this User's Guide and the Software User's Guide are registered trademarks of their respective companies.

Troubleshooting and Routine

Maintenance

Troubleshooting B

If you think there is a problem with your machine, check the chart below and follow the troubleshooting tips.

Most problems can be easily resolved by yourself. If you need additional help, the Brother Solutions Center offers the latest FAQs and troubleshooting tips. Visit us at http://solutions.brother.com

If you are having difficulty with your machine B

Printing

Difficulty Suggestions

No printout Check the interface cable connection on both the machine and your computer.

Poor print quality Check the print quality. (See Checking the print quality on page 100.)

White horizontal lines appear in text or graphics.

The machine prints blank pages. Clean the print head. (See Cleaning the print head on page 100.)

Characters and lines are stacked. Check the printing alignment. (See Checking the print alignment on page 102.)

(See the Quick Setup Guide.)

Make sure the machine is plugged in and not in Power Save mode.

One or more ink cartridges are empty. (See Replacing the ink cartridges on page 95.)

Check to see if the LCD is showing an error message. (See Error messages on page 88.)

Check that the correct printer driver has been installed and chosen.

Make sure the machine is online. Click Start and then Printers and Faxes. Right-click and choose ‘Brother MFC-XXXX (where XXXX is your model name)’, and make sure that ‘Use Printer Offline’ is unchecked.

Make sure that the Printer Driver or Paper Type setting in the menu matches the type of paper you are using. (See Printing in the Software User's Guide on the CD-ROM and Paper Type on page 18.)

Make sure that your ink cartridges are fresh. The following may cause ink to clog:

 The expiration date written on the cartridge package has passed. (Cartridges

stay usable for up to two years if kept in their original packaging.)

 The ink cartridge was in your machine over six months.

 The ink cartridge may not have been stored properly before use.

Try using the recommended types of paper. (See Acceptable paper and other media on page 8.)

The recommended environment for your machine is between 20° C to 33° C.

Clean the print head. (See Cleaning the print head on page 100.)

Try using the recommended types of paper. (See Acceptable paper and other media on page 8.)

Troubleshooting and Routine Maintenance

Printing (continued)

Difficulty Suggestions

Printed text or images are skewed. Make sure the paper is loaded properly in the paper tray and the paper side guide

Smudged stain at the top center of the printed page.

Printing appears dirty or ink seems to run.

Stains appear on the reverse side or at the bottom of the page.

The machine prints dense lines on the page.

The printouts are wrinkled. In the printer driver Basic tab, click Settings, and uncheck Bi-Directional

Cannot perform ‘2 in 1

’ or ‘4 in 1 ’

printing.

Print speed is too slow. Try changing the printer driver setting. The highest resolution needs longer data

Colour Enhancement is not working properly.

Machine feeds multiple pages Make sure the paper is loaded properly in the paper tray. (See Loading paper and

Printed pages are not stacked neatly.

Printed pages refeed and cause a paper jam.

Machine does not print from Paint Brush.

Machine does not print from Adobe Illustrator.

The machine cannot print full pages of a document.

Out of Memory message occurs.

is adjusted correctly. (See Loading paper and other media on page 12.)

Make sure the Jam Clear Cover is set properly.

Make sure the paper is not too thick or curled. (See Acceptable paper and other media on page 8.)

Make sure you are using the recommended types of paper. (See Acceptable paper and other media on page 8.) Don't handle the paper until the ink is dry.

Make sure the printer platen is not dirty with ink. (See Cleaning the machine printer platen on page 99.)

Make sure you are using the paper support flap. (See Loading paper and other media on page 12.)

Check Reverse Order in the Basic tab of the printer driver.

Printing.

Check that the paper size setting in the application and in the printer driver are the same.

processing, sending and printing time. Try the other quality settings in the printer driver Basic tab. Also, click the Settings, and make sure you uncheck Colour Enhancement.

Turn the borderless feature off. Borderless printing is slower than normal printing.

(See Printing for Windows

or Printing and Faxing for Macintosh® in the Software

User's Guide on the CD-ROM.)

If the image data is not full colour in your application (such as 256 colour), Colour Enhancement will not work. Use at least 24 bit colour data with the Colour Enhancement feature.

other media on page 12.)

Check that more than two types of paper are not loaded in the paper tray at any one time.

Make sure you are using the paper support flap. (See Loading paper and other media on page 12.)

Make sure you pull out the paper support until it clicks and unfold the paper support flap.

Try setting the Display setting to ‘256 colours.’

Try to reduce the print resolution. (See Printing for Windows

Faxing for Macintosh

in the Software User's Guide on the CD-ROM.)

Reduce the printing resolution. (See Printing for Windows

for Macintosh

in the Software User's Guide on the CD-ROM.)

or Printing and

or Printing and Faxing

Reduce the complexity of your document and try again. Reduce the graphic quality or the number of font sizes within your application software.

Printing Received Faxes

Difficulty Suggestions

Condensed print and white streaks across the page or the top and bottom of sentences are cut off.

Vertical black lines when receiving. The sender's scanner may be dirty. Ask the sender to make a copy to see if the

Received colour fax prints only in black and white.

Left and Right margins are cut off or a single page is printed on two pages.

You probably had a bad connection, with static or interference on the telephone line. Ask the other party to send the fax again.

problem is with the sending machine. Try receiving from another fax machine.

Replace the colour ink cartridges that are empty or nearly empty, and then ask the other person to send the colour fax again. (See Replacing the ink cartridges on page 95.)

Turn on Auto Reduction. (See Printing a reduced incoming fax on page 33.)

Telephone Line or Connections

Difficulty Suggestions

Dialling does not work. (No dial tone)

The machine does not answer when called.

Check that the machine is plugged in and switched on.

Check the line cord connection.

Change the Tone/Pulse setting. (See Quick Setup Guide.)

Lift the external telephone’s handset, (or the machine’s handset or cordless handset if available), and then dial the number to send a manual fax. Wait to hear fax receiving tones before pressing Mono Start or Colour Start.

Make sure the machine is in the correct receiving mode for your setup. (See Receive modes on page 30.) Check for a dial tone. If possible, call your machine to hear it answer. If there is still no answer, check the telephone line cord connection. If there is no ringing when you call your machine, ask your telephone company to check the line.

Receiving Faxes

Difficulty Suggestions

Cannot receive a fax Make sure the machine is in the correct receiving mode for your setup. (See

Receive modes on page 30.)

If you often have interference on the telephone line, try changing the menu setting of Compatibility to Basic. (See Telephone line interference on page 95.)

If you connect your machine to PBX or ISDN, set the menu setting of Telephone Line Type to your telephone type.

Sending Faxes

Difficulty Suggestions

Cannot send a fax

Make sure that the Fax key is illuminated. (See Entering Fax

mode on page 24.)

Ask the other party to check that the receiving machine has paper.

Print the Transmission Verification Report and check for an error. (See Reports on page 47.)

Troubleshooting and Routine Maintenance

Sending Faxes (continued)

Difficulty Suggestions

Transmission Verification Report says ‘Result:NG’ or ‘Result:ERROR’.

Poor fax send quality. Try changing your resolution to Fine or S.Fine. Make a copy to check your

Vertical black lines when sending.

(MFC-265C only)

There is probably temporary noise or static on the line. Try sending the fax again. If you send a PC FAX message and get ‘Result:ERROR’ on the Transmission Verification Report, your machine may be out of memory. If the problem continues, ask the telephone company to check your telephone line.

If you often get transmission errors due to possible interference on the telephone line, try changing the menu setting of Compatibility to Basic. (See Telephone line interference on page 95.)

If you connect your machine to PBX or ISDN, set the menu setting of Telephone Line Type to your telephone type.

machine's scanner operation. If the copy quality is not good, clean the scanner. (See Cleaning the scanner on page 98.)

If the copy you made shows the same problem, clean the scanner. (See Cleaning the scanner on page 98.)

Handling Incoming Calls

Difficulty Suggestions

The machine ‘Hears’ a voice as a CNG Tone.

Sending a Fax Call to the machine. If you answered at the machine, press Mono Start and hang up at once. If you

Custom features on a single line. If you have Call Waiting, Call Waiting/Caller ID, an alarm system or any other

If Fax Detect is set to on, your machine is more sensitive to sounds. It may mistakenly interpret certain voices or music on the line as a fax machine calling and respond with fax receiving tones. Deactivate the machine by pressing

Stop/Exit. Try avoiding this problem by turning Fax Detect to off. (See Fax Detect on page 33. )

answered on an external or extension telephone, press your Remote Activation Code (default setting is l51). When your machine answers, hang up.

custom feature on a single telephone line with your machine, it may create a problem sending or receiving faxes.

For example: If you subscribe to Call Waiting or some other custom service and its signal comes through the line while your machine is sending or receiving a fax, the signal can temporarily interrupt or disrupt the faxes. Brother's ECM feature should help overcome this problem. This condition is related to the telephone system industry and is common to all devices that send and receive information on a single, shared line with custom features. If avoiding a slight interruption is crucial to your business, a separate telephone line with no custom features is recommended.

Menu Setting Difficulties

Difficulty Suggestions

The machine beeps when you try to access the Setup Receive menu.

If the Fax key is not illuminated, press it to turn on Fax mode. The Setup

Receive setting is available only when the machine is in Fax mode.

Copying Difficulties

Difficulty Suggestions

Cannot make a copy

Vertical streaks appear on copies If you see vertical streaks on copies, clean the scanner. (See Cleaning the

Poor copy results when using the ADF (MFC-265C only)

Vertical black line appears in copies (MFC-265C only)

Make sure that the Copy key is illuminated. (See Entering Copy

mode on page 50.)

scanner on page 98.)

Try using the scanner glass. (See Using the scanner glass on page 7.)

Black vertical lines on copies are typically caused by dirt or correction fluid on the glass strip. Clean the glass strip. (See Cleaning the scanner on page 98.)

Scanning Difficulties

Difficulty Suggestions

TWAIN/WIA errors appear when starting to scan.

Poor scanning results when using the ADF. (MFC-265C only)

Make sure the Brother TWAIN/WIA driver is chosen as the primary source. In

Presto ! Select to choose the Brother TWAIN/WIA driver.

Try using the scanner glass. (See Using the scanner glass on page 7.)

PageManager® with OCR , click File, Scan or Get Photo and click

Software Difficulties

Difficulty Suggestions

Cannot install software or print Run the Repair MFL-Pro Suite program on the CD-ROM. This program will repair

‘Device Busy’ Make sure the machine is not showing an error message on the LCD.

Cannot print images from FaceFilter Studio.

and reinstall the software.

To use FaceFilter Studio, you must install the FaceFilter Studio application from the CD-ROM supplied with your machine. To install FaceFilter Studio see the Quick Setup Guide.

Also, before you start FaceFilter Studio for the first time, you must make sure your Brother machine is turned On and connected to your computer. This will allow you to access all the functions of FaceFilter Studio.

PhotoCapture Center™ Difficulties

Difficulty Suggestions

Removable Disk does not work properly.

Cannot access Removable Disk from Desktop icon.

1 Have you installed the Windows

1) Unplug the USB cable.

2) Install the Windows

 Install MFL-Pro Suite from the CD-ROM. (See the Quick Setup

 Download the latest service pack from the Microsoft Web site.

3) Wait about 1 minute after you restart the PC, and then connect the USB cable.

2 Take out the memory card or USB Flash memory drive and put it back in

again.

3 If you have tried ‘Eject’ from within Windows

USB Flash memory drive before you continue.

4 If an error message appears when you try to eject the memory card or USB

Flash memory drive, it means the card is being accessed. Wait a while and then try again.

5 If all of the above do not work, turn off your PC and machine, and then turn

them on again. (You will have to unplug the power cord of the machine to turn it off.)

Make sure that you have correctly inserted the memory card or USB Flash memory drive.

Guide.)

Troubleshooting and Routine Maintenance

2000 update? If not, do the following:

2000 update using one of the following methods.

, take out the memory card or

Error messages B

As with any sophisticated office product, errors may occur. If this happens, your machine identifies the error and shows an error message. The most common error messages are shown below.

You can correct most errors by yourself. If you need more help, the Brother Solutions Center offers the latest FAQs and troubleshooting tips.

Visit us at http://solutions.brother.com

Error Message Cause Action

Clean UnableXXThe machine has a mechanical

problem.

—OR—

A foreign objects such as a clip or ripped paper is in the machine.

Comm.Error Poor telephone line quality caused

a communication error.

Cover is Open The scanner cover is not closed

completely.

The ink cartridge cover is not completely closed.

Data Remaining

Disconnected The other person or other person's

Document Jam The document was not inserted or

High Temperature

Hub is Unusable.

Print data is left in the machine's memory.

Print data is left in the machine's memory. The USB cable was unplugged while the computer was sending the data to the machine.

fax machine stopped the call.

fed properly, or the document scanned from the ADF was too long.

The print head is too warm. Allow the machine to cool down.

A Hub or USB Flash memory drive with Hub has been connected to the USB direct interface.

Open the scanner cover and remove any foreign objects inside the machine. If the error message continues, see Transferring your faxes or Fax Journal report on page 91 before disconnecting the machine so you will not lose any important messages. Then, disconnect the machine from the power for several minutes and then reconnect it.

Try sending the fax again or try connecting the machine to another telephone line. If the problem continues, call the telephone company and ask them to check your telephone line.

Lift the scanner cover and then close it again.

Firmly close the ink cartridge cover until it clicks.

Re-start printing from your computer.

Press Stop/Exit. The machine will cancel the job and clear it from the memory. Try to print again.

Try to send or receive again.

See Using the ADF (MFC-265C only) on page 6.

See Document jam (MFC-265C only) on page 92.

A Hub or USB Flash memory drive with Hub are not supported. Unplug the device from the USB direct interface.

Troubleshooting and Routine Maintenance

Error Message Cause Action

Init Unable XX

Ink Empty Black

Ink Empty Yellow

Ink Empty Cyan

Ink Empty Magent

Low Temperature

Media Error The memory card is either

Near Empty Black

Near Empty Yellw

Near Empty Cyan

Near Empty Mgent

No Caller ID There is no incoming call history.

No Cartridge An ink cartridge is not installed

No File The memory card or USB Flash

The machine has a mechanical problem.

—OR—

A foreign object such as a clip or ripped paper is in the machine.

The indicated ink cartridge is empty. The machine will stop all print operations. While memory is available, black and white faxes will be stored in the memory. If a sending machine has a colour fax, the machine's that the fax be sent as black and white. If the sending machine has the ability to convert it, the colour fax will be stored in the memory as a black and white fax.

The print head is too cold. Allow the machine to warm up.

corrupted, improperly formatted, or there is a problem with the memory card.

The indicated ink cartridge is running out of ink. If a sending machine has a colour fax, the machine's that the fax be sent as black and white. If the sending machine has the ability to convert it, the colour fax will be received into memory as a black and white fax.

You have not received any calls, you have not activated the Caller ID feature on your machine, or you have not subscribed to the Caller ID service from your telephone company.

properly.

memory drive in the media drive does not contain a .JPG file.

‘handshake’ will ask

Replace the empty ink cartridges. (See Replacing the ink cartridges on page 95.)

Put the card firmly into the slot again to make sure it is in the correct position. If the error remains, check the media drive (slot) of the machine by putting in another memory card that you know is working.

Order a new ink cartridge.

If you want to use the Caller ID feature call your telephone company.

Take out the ink cartridge and put it in again seating it properly. (See Replacing the ink cartridges on page 95.)

Put the correct memory card or USB Flash memory drive into the slot again.

Error Message Cause Action

No Paper Fed The machine is out of paper or

paper is not properly loaded in the paper tray.

Do one of the following:

 Refill the paper in the paper tray, and then

press Mono Start or Colour Start.

 Remove the paper and load it again and then

press Mono Start or Colour Start.

The paper is jammed in the

See Printer jam or paper jam on page 92.

machine.

No Response/Busy

The number you dialed does not

Verify the number and try again.

answer or is busy.

Not Registered

You tried to access a Speed Dial number that is not programmed.

Set up the Speed Dial number. (See Storing Speed Dial numbers on page 44.)

Out of Memory The machine's memory is full. Fax sending or copy operation in progress

Press Stop/Exit and wait until the other operations in progress finish and then try again.

Printing operation in progress

Reduce print resolution. (For details, see Printing

for Windows® or Printing and Faxing for

Macintosh

in the Software User's Guide on the

CD-ROM.)

Paper Jam Paper is jammed in the machine. Remove the Jam Clear Cover (at the back of the

machine) and pull out the jammed paper. See Printer jam or paper jam on page 92.

Print UnableXXThe machine has a mechanical

problem.

—OR—

A foreign object such as a clip or ripped paper is in the machine.

Scan UnableXXThe machine has a mechanical

problem.

—OR—

A foreign object such as a clip or ripped paper is in the machine.

Unusable Device

A broken device has been connected to the USB direct interface.

Unplug the device from the USB direct interface, then press Power Save to turn the machine off and then on again.

Troubleshooting and Routine Maintenance

Error Message Cause Action

Unusable Device Please Disconnect USB Device.

Wrong Paper Size

A USB device or USB Flash memory drive that is not supported has been connected to the USB direct interface.

(For more information, visit us at http://solutions.brother.com

Paper is not the correct size. Load the correct size of paper (Letter, Legal or

Unplug the device from the USB direct interface.

A4), and then press Mono Start or Colour Start.

Transferring your faxes or Fax Journal report B

If the LCD shows:

Clean Unable XX Init Unable XX Print Unable XX Scan Unable XX

We recommend transferring your faxes to another fax machine. (See Transferring faxes to another fax machine on page 91.)

You can also transfer the Fax Journal report to see if there are any faxes you need to transfer. (See Transferring faxes to another fax machine on page 91.)

Note

If there is an error message on the machine's LCD, after the faxes have been transferred, disconnect the machine from the power source for several minutes, and then reconnect it.

Transferring faxes to another fax machine

If you have not set up your Station ID, you cannot enter fax transfer mode. (See Setting your Station ID in the Quick Setup Guide.)

a Press Menu, 9, 0, 1. b Do one of the following:

 If the LCD shows No Data, there

are no faxes left in the machine's memory.

Press Stop/Exit.

 If the LCD shows Enter Fax No.,

enter the fax number to which faxes will be forwarded.

c Press Mono Start.

Transferring the Fax Journal report to another fax machine

If you have not set up your Station ID, you cannot enter fax transfer mode. (See Setting your Station ID in the Quick Setup Guide.)

a Press Menu 9, 0, 2. b Enter the fax number to which the Fax

Journal report will be forwarded.

c Press Mono Start.

Document jam (MFC-265C only) B

Document is jammed inside the ADF unit

Documents can jam in the ADF unit if they are not inserted or fed properly, or if they are too long. Follow the steps below to clear a document jam.

Document is jammed in the top of the ADF unit

a Take out any paper from the ADF that is

not jammed.

b Open the ADF cover. c Pull the jammed document up and to the

left.

a Take out any paper from the ADF that is

not jammed.

b Lift the document cover. c Pull the jammed document out to the

left.

d Close the document cover. e Press Stop/Exit.

Printer jam or paper jam B

d Close the ADF cover. e Press Stop/Exit.

Note

To avoid future document jams close the ADF cover properly by pushing it gently in the middle.

Take out the jammed paper depending on where it is jammed in the machine. Open and close the scanner cover to clear the error.

a Pull the paper tray (1) out of the

machine.

Brother MFC-230C, MFC-265C User's Guide

Specifications and Main Features

Frequently Asked Questions

User Manual

Approval Information and Compilation and Publication Notice

APPROVAL INFORMATION

Compilation and Publication Notice

Table of Contents

General Information 1

Using the documentation 1

Symbols and conventions used in the documentation 1

Accessing the Software User’s Guide 1

Viewing Documentation 1

How to find Scanning instructions 1

How to find Scanning instructions 1

Control panel overview 1

Loading documents and paper 2

Loading documents 2

Using the ADF (MFC-265C only) 2

Recommended environment 2

Document Sizes Supported 2

How to load documents 2

Using the scanner glass 2

Document Sizes Supported 2

How to load documents 2

Scannable area 2

Acceptable paper and other media 2

Recommended media 2

Handling and using media 2

Paper capacity of the output paper tray

Choosing the right media 2

Paper type and size for each operation 2

Paper weight, thickness and capacity 2

Loading paper and other media 2

Loading envelopes and post cards 2

Loading envelopes 2

Removing small printouts from the machine 2

Printable area 2

General setup 3

Power Save mode 3

Putting your machine in Power Save mode 3

Bringing your machine out of Power Save mode 3

• You can customize Power Save mode so that, apart from automatic head cleaning, no machine operations are available. (See Power Save setting on page 17.)

Mode Timer 3

Paper settings 3

Paper Type 3

Paper Size 3

Volume Settings 3

Ring Volume 3

Setting the Ring Volume from the menu

Beeper Volume 3

Speaker Volume 3

LCD display 3

LCD Contrast 3

LCD Language 3

Setting the fax logic 3

Security features 4

TX Lock 4

Setting and changing the TX lock password 4

Setting up the password 4

Changing the TX Lock password 4

Turning the TX Lock on/off 4

Turning TX Lock on 4

Turning TX Lock off 4

Sending a fax 5

Entering Fax mode 5

Faxing from the ADF (MFC-265C only) 5

Faxing from the scanner glass5

Faxing Letter size documents from the scanner glass 5

Colour fax transmission 5

Broadcasting (Monochrome only) 5

Cancelling a fax in progress 5

Cancelling a Broadcast in progress 5

Additional sending operations 5

Sending faxes using multiple settings 5

Contrast 5

To change the default fax resolution 5

Changing fax resolution 5

To change the fax resolution for the next fax

Dual access (Monochrome only) 5
