PLEASE READ
INSTRUCTIONS
Blink™ Stroller
User Guide
Table of Contents
Warnings ............................................2
Features ............................................3
Assembly ...........................................4
Operating Instructions
Unfold ................................................5
Fold ..................................................6
Parking Brakes .........................................7
Swivel Wheels ..........................................7
Backrest ..............................................8
Canopy ...............................................9
Harness & Securing Child ...............................10
Releasing Harness .....................................11
Care and Maintenance ................................12
Warranty ...........................................13
This product and its components are subject to change without notice.
© 2009 Britax Child Safety, Inc. All rights reserved.
P343200_R5:03/09
Printed in China
WARNINGS
Canopy
Chassis Lock Lever
(on upper right side
diagonal support)
Visor
5-Point
Harness
Seat Pad
Leg Rest
Front Swivel
Wheel
Footrest
Front Swivel
Lock Lever
Carry Strap Foam Grip
Handles
Canopy
Locks
Recline Adjuster
Frame Release
Pedal
(Small pedal on back-
right of frame)
Rear Brake
Basket
Leg Rest Release Levers
Storage
Pouch
Date of Manufacture
Frame Lock
Pedal
• Never leave child unattended.
• Read and understand these instructions before using this product. To ensure proper
use, store this user guide in a convenient place so it can be consulted often. Failure
to follow all warnings and instructions could result in serious injury or death.
• Avoid serious injury from falling or sliding out of the stroller. Always buckle the
harness when a child is in the stroller.
• Do not use stroller with an infant. Child must be approximately 6 months or older.
• Do not use stroller with a child who weighs more than 55 lbs (24.9 kg).
• Do not overload basket. Maximum weight in basket is 5 lbs (2.3 kg). Overloading the
basket may cause the stroller to become unstable and tip over.
• Do not overload storage pouch. Maximum weight in pouch is 1 lb. (.45 kg).
Overloading the pouch may cause the stroller to become unstable and tip over.
• Always make certain that the stroller is fully unfolded and locked before use.
• Assembly of this stroller must be performed only by an adult.
• Do not hang or place items on the stroller handle or frame. They may cause the
stroller to become unstable and tip over.
• Children must always be restrained to prevent standing or falling out of stroller.
• Do not allow children to climb on or play with the stroller.
• Never use stroller on stairs or escalators.
• To avoid entrapment or pinching, do not fold or unfold stroller when child is in or
around stroller.
• Stroller is intended for walking speed only. Do not use while jogging, skating, etc.
• Never use the stroller with more than one child at a time.
• Always set the parking brake when stroller is not moving.
• Only use accessories and replacement parts approved by Britax Child Safety, Inc.
Features
2
NOTE: Actual product may vary from photographs
3
Assembly
Operating Instructions
Initial Assembly
Locate both dual front wheels 1
and canopy
Attach front wheels to stroller 2
frame
Unfold stroller as instructed on 3
page 5
Unfold
Squeeze frame while 1
releasing chassis lock
Lift handle upward and apart to 2
unfold stroller
Press two attachment clips onto each side of stroller frame, placing 4
clips above and below where fabric overlaps frame
Attach hook and loop fasteners around seat back5
4
Step on frame lock pedal to 3
lock stroller chassis
IMPORTANT - Make sure frame is
locked before use
Adjust leg rest into desired 4
position by pressing release
levers as shown
5
Operating Instructions
Fold Parking Brakes
Operating Instructions
Collapse canopy (pg 9) and 1
release primary frame lock by
pulling up on the carry strap
or lifting the frame lock pedal
Fold forward and downward 3
until completely collapsed
6
Using right foot on secondary 2
release, step on frame release
pedal while pressing inward
slightly on handles and fold
stroller forward
Chassis lock should engage 4
automatically
To set parking brake, pressing
down just one brake lever will
activate both rear brakes
NOTE: Verify that brakes are fully
engaged by attempting to move stroller
forward and backward
Swivel Wheels
To unlock swivel wheels, press
swivel lock lever down on each of
the front sets of wheels
To release parking brake, lift lever
until released
To lock swivel wheels, turn wheels
forward, then lift swivel lock lever up
until engaged
Note - Helpful on uneven terrain
7
Operating Instructions
Operating Instructions
Backrest
To lower backrest, press release
button on recline adjuster and slide
adjuster away from backrest
Press backrest down to reclined
position
To raise backrest, press release
button on backrest recline adjuster
and slide toward backrest while
holding backrest adjustment strap
Canopy
To Open Canopy, pull canopy forward, then engage both canopy locks (found
on either side of the canopy) by pressing down - Pull out visor if desired
To Collapse Canopy, release
each canopy lock by pressing up
at center and push canopy back
8
9
Operating Instructions
Harness Adjustment & Securing Child
Operating Instructions
Set brake and position harness around child1
Loosen or tighten harness by sliding each of the five adjusters to desired 2
position
Insert each clip into adjacent 3
sides of the buckle
10
Shoulder height may need to be adjusted1
With buckle released, disconnect shoulder and waist straps by 2
squeezing clips on both sides
Pull shoulder strap completely through seat back and thread it back 3
through the slot nearest the shoulder height of the child
Releasing Harness
ALWAYS1 set parking brake
Reconnect shoulder strap to 4
waist strap before securing
child
before removing child
Unfasten buckle by squeezing 2
clip on each side
11
Care and Maintenance
Warranty
Parking Brake
• Periodically check that the parking brake works properly and locks both
wheels securely.
• Clean out any dirt or debris that may prevent the brake from engaging.
Frame
• Wipe the frame with a damp cloth and mild soap. Use a clean, dry cloth
or towel to wipe away excess water and soap.
Fabric
• Wipe the fabric surface with cold water and mild soap.
Cleaning Plastic Parts:
• Wipe with a damp cloth and mild soap. Use a clean, dry cloth or towel
to wipe away excess water and soap.
Maintenance
If Stroller Gets Wet:
• Dry stroller with a clean cloth or towel to prevent corrosion.
• Do not fold stroller when wet or damp. Always make sure that the stroller
is dry before storing.
Plastic Parts
• Do not use abrasives, solvents, strong detergents, or household
cleaners. These products can scratch, discolor, and weaken plastic or
cause corrosion on metal surfaces.
Storage
• Store away from extreme heat to prevent damage to plastic parts.
• Cover stroller to prevent dust build-up and exposure to sunlight.
• Do not stack other items on top of stroller.
Registration
In case of recall, we can reach you only if we have your name and address.
Send in the completed registration card or register online to be on our
recall list.
This product is distributed by Britax Child Safety, Inc. Britax Child Safety, Inc. (“Britax”)
warrants this product to the original retail purchaser as follows:
Limited One-Year Warranty
This product is warranted against defective materials or workmanship for one year
from the date of original purchase. Proof of purchase is required. Your exclusive
remedy for this warranty is that Britax will, at its option, provide repair or replacement
components to the original purchaser for this product or refund the original purchase
price of the product. Britax reserves the right to discontinue or change fabrics, parts,
models or products, or to make substitutions. Labor and shipping costs for returns
are not included.
To make a claim under this Warranty, you must contact Britax Customer Services
Department at 1-888-4BRITAX or write to 13501 South Ridge Drive, Charlotte, NC
28273. Proof of purchase is required.
PLEASE COMPLETE AND MAIL THE REGISTRATION CARD WITHIN 30 DAYS OF
PURCHASE, OR REGISTER ONLINE AT WWW.BRITAXUSA.COM/REGISTRATION.
Warranty Limitations
This warranty does not include damages which arise from negligence, misuse, salt
corrosion, or use not in accordance with the user guide.
The use of non-Britax accessories is not approved by Britax. The use of unapproved
accessories could cause this product to become damaged or dangerous. Their use
automatically voids the Britax warranty.
Limitations of Damages
The warranty and remedies as set forth above are exclusive and in lieu of all others,
oral or written, express or implied. In no event will Britax or the retailer selling this
product be liable for any damages, including incidental or consequential damages,
arising out of the use or inability to use this product.
Limitations of Warranties and Other Warranty Terms and State Law Rights
Any implied warranties, including implied warranties of merchantability and fitness for
a particular purpose, shall be limited to the duration and terms of the express written
warranty. Some states do not allow limitations on how long an implied warranty lasts
or the exclusion or limitation of incidental or consequential damages, so the above
limitations may not apply to you. This warranty gives you specific legal rights, and
you may have other rights, which vary from state to state. Neither Britax, nor the
retailer selling this product, authorizes any person to create for it any other warranty,
obligation, or liability in connection with this product.
12
www.BritaxUSA.com/registration
13
MADE IN CHINA
Britax Child Safety, Inc.
13501 South Ridge Drive
Charlotte, NC 28273
USA
A Britax Childcare Group Limited
company
Tel 1.888.427.4829
www.BritaxUSA.com
