Agile Plus
User Instructions
32 pgs2.9 Mb0

Britax Agile Plus, Steelcraft Agile Plus User Instructions

4 Wheel Travel System Stroller
SUITABLE FOR USE WITH THE STEELCRAFT INFANT CARRIER
(SOLD SEPARATELY)
IMPORTANT: KEEP THIS BOOKLET IN A SAFE
PLACE FOR FUTURE REFERENCE.
Serial No. SH908
2
Warnings................................................................................................. 3
Parts List ................................................................................................ .6
Assembled Stroller Parts List....................................................................7
01. To Open Stroller .................................................................................8
02. To Assemble And Remove The Front Swivel Wheels ........................8
03. To Fit And Remove The Rear Wheels ................................................9
04. To Use The Swivel Wheels ................................................................9
05. To Attach And Use The Canopy ......................................................10
06. To Attach And Use The Child Tray ..................................................13
07. To Adjust The Backrest.....................................................................14
08. To Use The Brakes...........................................................................15
09. To Adjust The Footrest.....................................................................15
10. To Adjust The Pivot Handle...............................................................16
11. To Secure Your Child In The Harness...............................................16
12. To Use The Teether Strap.................................................................20
13. To Fit The Rain Cover.......................................................................20
14. To Use The Stroller...........................................................................21
15. To Fold The Stroller...........................................................................22
16. To Fit The Reversible Seat................................................................24
17. To Fit The Bootcover....................................................................... 24
18. Install The Infant Carrier (Sold Separately)......................................25
19. To Release The Infant Carrier...........................................................29
Care and Maintenance .........................................................................31
CONTENTS PAGE
3
WARNINGS
• RETAIN FOR FUTURE REFERENCE.
• READ ALL INSTRUCTIONS CAREFULLY BEFORE ASSEMBLY AND
USE OF THIS STROLLER. ALWAYS FOLLOW THE INSTRUCTIONS.
• THE CORRECT USE AND MAINTENANCE OF THIS PRODUCT IS ESSENTIAL.
• FOLLOW THE MANUFACTURERS INSTRUCTIONS.
• DO NOT LEAVE CHILDREN UNATTENDED.
• SECURE THE CHILD IN THE HARNESS AT ALL TIMES.
• DO NOT CARRY EXTRA CHILDREN OR BAGS ON THIS STROLLER.
• MAKE SURE CHILDREN ARE CLEAR OF ANY MOVING PARTS IF YOU
ADJUST THE STROLLER.
• USE THE HARNESS AT ALL TIMES.
• WHEN NOT IN USE DISCONNECT SHOULDER STRAPS FROM THE
WAIST STRAPS AND BUCKLE TO PREVENT STRANGULATION.
• CHECK THAT ALL SAFETY LOCKS ARE ENGAGED BEFORE PLACING A CHILD IN THE STROLLER.
• ENSURE YOUR CHILD IS SECURED WITH A CORRECTLY ADJUSTED SAFETY HARNESS.
• USE THE TETHER STRAP TO PREVENT THE STROLLER FROM ROLLING AWAY.
• NEVER LET GO OF THE STROLLER WHEN PARKED ON AN INCLINE BECAUSE IT MAY SLIDE OR TIP OVER. ALWAYS PARK ON A FLAT SURFACE.
• REMOVE THE CHILD FROM THE STROLLER BEFORE GOING UP OR DOWN STAIRS OR ESCALATORS.
WARNINGS: TO AVOID INJURY OR DEATH: ALWAYS APPLY THE BRAKES WHENEVER THE STROLLER STATIONARY.
4
WARNINGS
• Do not allow children to stand on the seat.
• Do not hang bags or goods from the handle as this could cause the
stroller to tip over.
• To prevent the risk of the stroller catching fire, do not park it near an exposed heat source such as a radiator, an open fire or a barbecue, etc.
• Do not run while using this product.
• Always lock swivel wheels when on rough surfaces as this will help
eliminate wheel wobble.
• Always raise the leg support (where fitted) to its highest position when transporting a baby. This will reduce the risk of the baby falling out through the front of the stroller.
• It is unsafe to use accessories other than those tested and approved by Britax. For maximum safety only use accessories designed for this stroller.
• Do not place more than 4kg in the basket, or 1kg in any Canopy pocket (if supplied) or 1kg in the parent organiser (if supplied).
• The maximum weight of the child using this product is not to exceed 22kg for the stroller or 9kg for the Infant Carrier.
FOR WARNINGS ON ACCESSORIES - REFER TO THEIR INDIVIDUAL SECTIONS IN THIS BOOK. THE MAXIMUM WEIGHT VARIES FOR EACH ACCESSORY.
WARNING
5
• The upright positions are not suitable for use with children less than six months old. The lowest recline position should be used to transport babies, and the backrest can be adjusted to a more upright position as the child grows older and is able to support its head without assistance.
• The sun is very strong. DO NOT LEAVE YOUR CHILD EXPOSED TO THE SUN. The canopy or hood on this product will not give your child total protection from the harmful rays of the sun.
• The footrest is not designed to carry excess weight. DO NOT ALLOW CHILDREN TO STAND OR SIT ON THE FOOTREST. IT WILL DISENGAGE.
WARNINGS
IMPORTANT
SAFETY WARNINGS
WARNING
6
PARTS LIST
A 1 x Stroller Frame, Seat & Basket B 1 x Canopy C 2 x Rear Wheels D 2 x Front Wheels
A
C
E F
B
D
G H I
Accessories
E 2 x Infant Carrier Adaptors F Child Tray G Seat Insert H Bootcover I Raincover
7
ASSEMBLED STROLLER - PART LIST
Adjustable Handle
Canopy
Front canopy tube
Upper seat
Lower seat
Child Centre Tray
Leg rest
Front Wheel
release button
Front Wheel
swivel lock
Tether Strap
Shoulder Pads
Harness
Sure Lock release button
Rear leg tube
Front leg tube
Basket
Canopy window
Canopy window cover
8
A Release the storage latch (1) located on the rear leg. Open the frame as
shown by the arrows (2) until you hear a ‘click’ which indicates the frame is fully opened and locked. Push down on the stroller handle to confirm that frame is locked
A To assemble the front swivel wheel assembly,take each swivel wheel and
insert and push it into the wheel moulding until you hear a ‘click’ which indicates the wheel is locked in. Check the wheel assembly is fully locked by pulling against it.
B To remove the front swivel wheels, locate and press in the red button on the
top of the wheel moulding.
01. TO OPEN STROLLER
02. TO ASSEMBLE AND REMOVE THE FRONT SWIVEL WHEELS
1
2
2
A
A
A
B
Storage latch
2
9
A To fit the rear wheels, insert each wheel axle into the moulding and push in
until locked. You should hear a ‘click’ which indicates the wheel has locked in. Pull on the wheel to make sure it is engaged. Repeat the process if not locked in.
B To remove the wheels, pull the metal latch downwards on the underneath of
the brake moulding to release the wheel, and then pull the wheel off.
A Press the swivel lock down to lock the swivel wheels.
Push the swivel wheel lock up to allow the wheels to swivel.
Note: Always lock the swivel wheels when using the stroller on rough surfaces as it will minimise wheel wobble.
03. TO FIT AND REMOVE THE REAR WHEELS
04. TO USE THE SWIVEL WHEELS
A B
Metal Latch
10
A1 To attach the canopy, insert the canopy mouldings into the frame mouldings
until they connect together. The back flap of the canopy can be attached to the main canopy with the zipper attachment.
A2 Attach the snaps located on the straps on the sides of the canopy to the top
of the handle tubes, then fold the strap up under the canopy back flap and secure strap with hook and loop to the underneath of the canopy.
05. TO ATTACH AND USE THE CANOPY
A
