BRIGHTSIGN OPS
Preview
OPS COMPATIBLE DIGITAL SIGNAGE MEDIA PLAYER
Part of the HD Series 3 product family, the HO523 is BrightSign’s rst OPS compatible
digital signage media player. The inside edge features a JAE TX25 plug for connecting to
interior display components (video, USB, serial, etc.) The outside edge has industry-standard
connectors, as well as specialized device control and feedback interfaces.
Price: $400
Outside Connectors
• Wi-Fi/Bluetooth module
(optional)
• RJ45 Ethernet (10/100/1000)
• Dual USB 2.0 (type A)
• GPIO (6 pins)
• IR (In/Out)
• 3.5mm Audio Out (analog
& SPDIF digital)
• RS-232 serial (3.5mm jack)
• MicroSD slot
• Service button
• Reset button
Features
• HD class performance; runs BrightSign software or
compatible CMS partners software
• Flexible design: OPS compatible module and enclosure
• Electrical, mechanical, and thermal compatibility with
Intel® OPS speci cation
• Optional on-board Wi-Fi (IEEE 802.11a/b/g/n)
Inside Connectors
• JAE TX25 plug (OPS compatible)
• M.2 interface (for optional WiFi module)
H.265
HEVC
High Efficiency Video Decoding
H.265
BrightBeacon
BrightPlates
TM
TM
FULL HD
1080p60
single decode
BrightWall
Interactive
Mainstream
HTML5
HTML
TM
AutoWall
Live Feeds
Preview
IP Streaming
™
Zones
Geo-Fencing
• H.265/H.264 video decode
Tagging
BrightSign App
Sign Preview
• Video output up to 1080p60
• 10-bit video output (using H.265)
• Hardware accelerated HTML5 support
BrightSign, LLC. 16780 Lark Ave., Suite B, Los Gatos, CA 95032 | USA 408-852-9263 | International +44 1223 298500 | www.brightsign.biz
B-Deploy
IP Streaming Server
Digital
Sound
Remote Snapshot
Mosaic Mode
Page 2
SPECIFICATIONS
MODEL H0523
VIDEO ENGINE DECODER
Single 1080p60 video decoding X
MEDIA FORMATS
Video Codecs: H.265, H.264(MPEG-4, Part 10), MPEG-2, MPEG-1 X
Video Containers: .ts, .mpg, .vob, .mov, .mp4, .m2ts, .wmv X
Images: BMP, JPEG, PNG X
Audio: MP2, MP3, AAC, and WAV (AC3 is passed through) X
HTML5 X (Mainstream)
DISPLAY RESOLUTIONS
1920x1080x24/25/29.92/30/50/59.94/60p, 1920x1080x50/59.94/60i,
1600x1200x60p, 1440x1050x60/75p, 1440x900x60/75p,
1360x768x60p, 1280x1024x60/75p, 1280x960x60p,
1280x800x60p/75p, 1280x768x60p, 1280x720x50/59.94/60p,
1024x768x60p, 800x600x60/75p, 720x576x50p/50i,
720x480x59.94/60p/60i, 640x480x60p
HARDWARE INTERFACES
External micro SD Slot (SDHC and SDXC); SDHC storage up to 32GB
SDXC storage up to 2TB
2 USB High Speed Host Ports (also supports content updates) X (Type A)
Phoenix GPIO Port (6-pin bi-directional) X
3.5mm RS-232 Serial Port X
3.5mm IR In/Out X
3.5mm Audio Out (analog & SPDIF digital) X
HDMI 1.4a Out over JAE connector X
Ethernet X (Gigabit)
M.2 (E) Keyed Wi-Fi/Bluetooth Connector (for the Wi-Fi module) X
Wi-Fi External Antenna Connector (optional) X
Status LEDs Power, Error, Busy,
Reset and Service Buttons X
Real Time Clock X
FEATURES
H.265 Decoding: smaller le sizes and lower bitrates than H.264 X
HTML5: hardware-accelerated engine that plays modular HTML
assets awlessly alongside high-bandwidth video
BrightBeacon
mobile devices & signage (requires: wireless/Bluetooth module)
BrightWall
TM
: 2-way Bluetooth/Beacon communication between
™
: synchronized playback across multiple displays X
X
X
Update
X (Mainstream)
X
MODEL H0523
AutoWall™: embraces the power of HTML5 to create unique
multimedia video walls
Zones: playback multiple content types on a single screen X
Mosaic Mode: simultaneously play a multitude of smaller resolution
videos that add up to the maximum video resolution of the player
IP Streaming: play streaming media X
IP Streaming Server: serve IP streams from local storage X
Interactivity: connect virtually any type of interactive device to a
multitude of interactive ports
Live Feeds: Live Data, Live Text, MRSS, Twitter, Flickr, etc. X
Tagging: BrightSign Network users can assign media and player tags
for highly targeted content distribution
BrightSign App: update signs with an iOS device X
Geo-Fencing: trigger playback based on location (requires USB
dongle)
Sign Preview: preview presentation playback in BrightAuthor X
Remote Snapshot: remotely view a snapshot image of the display’s
playback
TM
BrightPlates
Networking: update, manage and schedule your signage X
B-deploy: A setup feature to deploy many players at once X
Extended Thermal: supports ambient temperatures between 0° & 70° C at
90% max relative humidity, non-condensing
SOFTWARE
Free BrightAuthor Software X
BrightSign Networking Options X
ACCESSORIES
USB Button Pads X
Wireless/Bluetooth Module X
MicroSD Class 10 Cards (various capacities) X
MISCELLANEOUS
Dimensions (W x H x D) 200 x 30 x 122mm or 7.9
Weight
Power 12V-19V DC nominal
Multi-Country Power & Regulatory Approvals
1 year warranty, parts and labor X
: easy template-based sign creation service X
X
X
X (GPIO, USB, serial,
UDP)
X
X
X
X
x 1.2 x 4.8 in
22.9 oz
X
