Brickcom FB-300N User Manual

Hardware User’s Manual

Megapixel Day & Night

Fixed Box Network Camera

Quality Service Group

FB-500A&FB-300N Series

Review History:

Product name:

Network Camera (FB-500A&FB-300N Series)

Release Date:

2012/5

Manual Revision:

V1.2
Web site:

www.brickcom.com

Email:

[e-mail]

[e-mail]

© 2011 Brickcom Corporation. All Rights Reserved

1. Separate User Manual into HW and SW.

2. Merge FB-130Ap/FB-200Ap/FB-300Ap v3/FB-400Ap/FB-500Ap Series into this
User Manual.

3. Merge FB-300Np into this User Manual.

Table of Contents

Before You Use This Product ...................................................................... 0

Regulatory Information ............................................................................. 1

Package Contents ..................................................................................... 0

Fixed Box Network Camera Overview ........................................................... 1

LED Behavior .......................................................................................... 4

Installation ............................................................................................... 6

Hardware Installation ................................................................................................... 6

System Requirements .................................................................................................. 9

Camera Connection .................................................................................................... 10

Before You Use This Product

In many countries, there are laws prohibiting or restricting the use of surveillance devices.
This Network Camera is a high-performance, web-ready camera which can be part of a
flexible surveillance system. It is the user’s responsibility to ensure that the operation of
this camera is legal before installing this unit for its intended use.

Upon opening the product’s package, verify that all the accessories listed on the “Package

Contents” are included. Before installing the Network Camera, read the warnings in the

“Quick Installation Guide” to avoid misuse. When installing the Network Camera,

carefully read and follow the instructions in the “Installation” chapters to avoid damages

due to faulty assembly or installation.

Regulatory Information

Federal Communication Commission Interference Statement

This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates
uses and can radiate radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications. However, there is
no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct the interference by one of the
following measures:

- Reorient or relocate the receiving antenna.

- Increase the separation between the equipment and receiver.

- Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.

- Consult the dealer or an experienced radio/TV technician for help.

FCC Caution: Any changes or modifications not expressly approved by the party responsible
for compliance could void the user’s authority to operate this equipment.

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause undesired operation.

IMPORTANT NOTE :
FCC Radiation Exposure Statement :

This equipment complies with FCC radiation exposure limits set forth for an uncontrolled
environment. This equipment should be installed and operated with minimum distance 20cm
between the radiator & your body.
This transmitter must not be co-located or operating in conjunction with any other antenna or
transmitter.
The availability of some specific channels and/or operational frequency bands are country
dependent and are firmware programmed at the factory to match the intended destination. The
firmware setting is not accessible by the end user.

a. Network Camera

b. CS mount Lens (Optional)

c. Product CD

d. Camera Stand
e. Warranty Card

f. A/V Cable

g. Power Adapter (Optional)

h. Easy Installation Guide

i. Allen Key

j. C Mount Ring

Package Contents

Please check to make sure that the product package contains all the accessories listed
below.

0
