Bravetti F1011H User Manual

2 L. Deep Fryer
OWNER’S MANUAL
Model F1011H 120V., 60Hz., 1500 Watts
EURO-PRO Operating LLC
Boston, MA, 02465
1 (800) 798-7398 www.euro-pro.com
IMPORTANT SAFETY INSTRUCTIONS
When using electrical appliances, basic safety precautions should always be followed, including the following:
1. Read all instructions for use carefully and look at the illustrations before you start using the appliance.
2. Do not touch hot surfaces, always use handles or knobs.
3. To protect against electrical shock, do not immerse cord and plug of this appliance in water or other liquids.
4. Close supervision is necessary when any appliance is used by or near children.
5. Unplug from outlet when not in use and before cleaning. Allow to cool before putting on or taking off parts and before cleaning the appliance.
6. Do not operate any appliance with a damaged cord or plug, or after the appliance malfunctions, has been dropped or damaged in any manner. Return the appliance to EURO-PRO Operating LLC for examination, repair or adjustment. See warranty.
7. Never plug in before the control panel is installed in the body of the fryer and the heating element is placed in the oil container.
8. Never overfill the fryer with oil. Fill only between the minimum and maximum levels, as indicated inside the oil container.
9. Be sure handle is properly assembled to the basket and locked in place. See detailed assembly instructions.
10. The use of accessory attachments not recommended by the appliance manufacturer may cause injuries.
11. Always insert heating element in the appliance first, then plug into the wall outlet. To disconnect, remove plug from wall outlet then wait for the unit to cool completely before removing the heating element.
12. Extreme caution must be used when moving any appliance containing hot oil or other hot liquids.
13. Do not leave appliance unattended while in use.
14. Do not use outdoors.
15. Do not let cord hang over the edge of the table, counter or touch hot surfaces.
16. Do not place on or near a hot gas or electric burner, or in a heated oven.
17. Do not use appliance for other than intended household use.
GETTING TO KNOW YOUR DEEP FRYER
SPECIAL SAFETY INSTRUCTIONS
A detachable magnetic power cord is
provided to reduce the risk resulting from becoming entangled in or tripping over a longer cord. An extension cord
(or longer detachable cord) is not recommended for use with deep fryers.
Never plug in the unit to an electrical
outlet before the control panel is installed into the body of the fryer with the heating element inside the oil container.
POLARIZED PLUG
WARNING: To reduce the risk of electric shock, this appliance has a
polarized plug (one blade is wider than the other). This plug will fit in a polarized outlet only one way. If the plug does not fit fully in the outlet, reverse the plug. If it still does not fit, contact a qualified electrician to install the proper outlet. Do not modify the plug in any way.
Do not immerse the control panel and
heating element in water.
When opening the lid after frying, lift it
slowly and wait a moment to allow the steam inside to escape before opening fully.
To avoid a circuit overload, do not
operate another high wattage appliance on the same circuit.
SAVE THESE INSTRUCTIONS
FOR HOUSEHOLD USE ONLY
1
Rev. 07/05A
1. Main Unit
2. Oil Container/Reservoir
3. Cover Release Button
4. Removable Cover
5. Filter
6. Viewing Window
7. Frying Basket
8. Frying Basket Handle
Technical Specifications
Voltage: 120V., 60Hz. Power: 1500 Watts
*Illustration may differ from actual product.
2
9. On/Off Button
10. Temperature Control Knob
11. Power “On Light
12. Ready Indicator Light
13. Heating Elements
14. Removable Control Panel
15. “Break Away” Power Cord
OPERATING INSTRUCTIONS
OPERATING INSTRUCTIONS
Before Using Your Deep Fryer
Make sure the deep fryer is unplugged from electrical outlet. Wash the frying basket and oil container in hot, soapy water. Wipe dry thoroughly. Wipe the removable heating control panel and heating elements with a damp, soapy cloth. Wipe dry thoroughly.
Note: Any water left in oil container or on frying basket can cause heated oil to splatter or “pop” during cooking. Special care should be taken to ensure that the oil filter in the removable cover is completely dry, otherwise the filter will not function properly. If not dry, steam may be trapped within the fryer during use and cause serious burns when opened.
Assembling Your Deep Fryer
CAUTION: Never turn on the fryer when the oil pan is empty. Always ensure the fryer is out of the reach of children. Always use fryer on a flat, heat resistant surface.
1. Place oil container inside the base of the deep fryer.
2. Slide the control panel with the heating element downward until it connects with the control panel terminal on the outside of the fryer. The automatic safety switch ensures that the unit will not operate unless the control panel has been inserted correctly into the electric interface on the control panel terminal. ( Fig. 1)
Control
Panel
Fig. 1
Electronic
Interface
WARNING: Never plug in the deep
fryer before filling with oil. Always unplug the appliance when not in use.
3. Pour cooking oil into oil container. Do NOT exceed “MAX” level for cooking oil. (Fig. 2)
Fig. 2
4. Attach the “Break Away” power cord. When attaching the power cord, you will feel a magnetic pull on the cord. (Fig. 3)
Fig. 3
5. Attach the basket handle to the frying basket by pressing inward on the side of the handle to depress the handle shafts. Place the handle shaft into the mating slots inside the fryer basket, make sure the ends are in place and secure. (Fig. 4)
Press here to insert handle shafts into basket
3
Max level
for cooking oil.
Fig. 4
Filling the Oil Container
Never plug in the deep fryer before filling with oil to specified level. Always make sure control panel is securely in place in the body and the heating element is inside the oil in the container before plugging in.
Use blended vegetable oil, pure corn oil
or canola oil. Do not use olive oil, margarine, lard or drippings.
The oil level must always be maintained
between the minimum and the maximum levels marked inside the oil container. Check the oil level before each use. For best results, keep the oil close to the maximum level on the oil container. (Fig. 5)
Never mix different oils and fats
together. Do not mix old and new oil.
Oil level indicator
Fig. 5
Using Solid Fat WARNING: Do Not put solid shorteni ng in
the oil container or the frying basket.
If using solid vegetable shortening, melt
it first in a separate pan and then very carefully pour the melted fat into the oil container.
Previously used solid vegetable shortening
which has curdled and hardened in the oil container should be removed from the oil container and melted in a separate pan before reusing.
Using Your Deep Fryer CAUTION: Never turn on the fryer when
the oil pan is empty. Always ensure the fryer is out of the reach of children. Always use fryer on a flat, heat resistant surface.
1. Place oil container inside base of unit.
2. Slide control panel with heating
elements downward until it connects with the power junction module on the outside of the fryer.
3. Make sure fryer On/Off switch is in the
“Off “ position.
4. Attach the detachable power cord. When attaching the cord - you will feel a magnetic pull on the cord when attaching cord correctly.
5. Pour cooking oil into oil container. Do not exceed max level for cooking oil.
(See instructions on filling the oil
container.)
6. Turn On / Off switch to “On” position. The power “On” light will come on.
7. To set the desired frying temperature, press the temperature control knob and turn the knob to the left to decrease the temperature or to the right to increase. The range of temperature is between 155° F and 385° F.
8. When you have finished setting the temperature, the unit is ready to be used. Close the cover and let the oil reach the set temperature.
9. When the oil in the deep fryer has reached the set temperature, open the cover, place the frying basket onto the oil draining hook, put food into the frying basket and carefully lower the frying basket into the hot oil. Close the cover.
10. When cooking oil reaches desired setting, the temperature ready light will turn on.
Note: The temperature ready light will cycle
off and on during the frying cycle as the unit maintains the selected temperature.
11. When cooking is complete, open the cover carefully to avoid burns caused by escaping steam. Lift the frying basket and hook it onto the oil draining hook to allow the food to drain.
12. Remove the food from the frying basket by:
Lifting the frying basket by its handle and CAREFULLY pouring food onto
a plate covered with paper towels or
into desired serving utensil.
Using tongs to grasp the food from the frying basket and placing into
serving utensil.
13. Repeat procedure for remaining food
to be cooked.
Note: Always replace or remove the frying
basket carefully when cooking. Oil is
very hot and can cause severe injury.
4
OPERATING INSTRUCTIONS
OPERATION INSTRUCTIONS
14. When cooking is completed, press the “”On/Off”” button and remove the plug from the electrical outlet. Allow the oil in the oil container to cool completely for approximately two (2) hours before attempting to remove the oil and clean the deep fryer.
Note: Do not disconnect the deep fryer by pulling on the “Break Away” power cord.
WARNING: Although your deep fryer
has a cool touch exterior, to avoid possible injury or burns, never touch any metal parts on the deep fryer because they may be hot.
IMPORTANT
Do not fill the frying basket with
frozen food when basket is immersed in the hot oil.
Place the food in the frying basket. Do
not drop food into hot cooking oil. Do
not overfill it and never exceed the
maximum quantities. For optimum results and shorter frying time, fry smaller quantities.
The frying basket has a “MAX” line on
it. Do not fill the frying basket with food over this line.
Do not fill the basket higher than the
max line on the basket with frozen food.
Frying Food WARNING: When frying foods, remove
the frying basket from the deep fryer before filling with frozen food because oil will spatter and can cause burns.
WARNING: When frying frozen foods
such as French Fries, you should NOT exceed 1/2 Lb. or less. Clean off any ice from frozen food prior to frying. Failure to do so may cause fryer to overflow when food is placed in oil.
CAUTION: Never plug in the control
panel when it is not assembled to the fryer body. Do not immerse the control panel, power cord or plug in water or any other liquid.
CAUTION: This unit should not be used
to boil water.
Always use the frying basket to fry food.
Always close the cover during frying.
When the oil is pre-heated, ready
indicator light will come on indicating the desired oil temperature has been
reached.
Slowly lower the frying basket into the
hot oil. Lowering the frying basket too quickly can result in the oil overflowing and splashing.
Replace the cover carefully.
It is normal for steam to escape through
the sides of the cover while frying.
Avoid standing too close to the deep
fryer while it is cooking.
WARNING: When opening the cover
after frying, lift up the cover slightly, then wait to allow steam to escape before opening the cover completely. Keep face away from unit to avoid burns caused by escaping steam.
Frying tips
To avoid condensation buildup on the
cover window - rub a little cooking oil on window.
Do not mix different oils or new and old
oil together.
Replace oil regularly. In general, oil
used to fry food with protein, (such as poultry, meat and fish) should not be reused. When oil is used mainly to fry potatoes and is filtered after each use, it can be used up to 8 to 10 times, but do not use the same oil for more than 6 months.
Always replace all oil as soon as it
starts foaming when heated or when color becomes dark or when it has a rancid smell or taste or becomes syrupy.
Make sure that the food to be fried is
dry.
Remove loose ice from frozen food
before frying.
To cook evenly, pieces should be the
same size and thickness.
Thicker pieces will take longer to cook.
Temperature Settings
The following cooking times reflect only the approximate time needed to fry one basket 1/2 full. The exact time may be different depending on actual quantity, personal cooking preferences, size and thickness of pieces, etc. In general, use lower settings for delicate foods (vegetables, fish) and higher settings for frozen foods, French Fries and chicken.
Food Cooking Time Temp.
French Fries 6-9 minutes
Fish Fillets 3-5 minutes
Chicken
Fingers
Chicken
Pieces
Fried Zucchini 3 minutes
Fried
Mushrooms
Onion Rings 3 minutes
Donuts 3-5 minutes
Apple
Beignets
Shrimp 4-6 minutes
6-8 minutes
13-20 minutes
3 minutes
4 minutes
375°F 320°F
350°F
350°F 320°F 320°F 320°F
350°F 350°F 320°F
To Store or Reuse Cooking Oil
Make sure the deep fryer is unplu gged and the oil has cooled (approximately 2 hours) before attempting to clean or store the deep fryer.
The oil does not need to be c hanged after each use. We do not recommend storing and reusing oil that was used for frying high protein foods such as poultry, fish or other meats. When oil is mainly used to fry potatoes and is filtered after each use, it can be used 8 to 10 times. However, do not use the same oil for longer than 6 months.
To filter the oil, first make sure the oil has cooled and then empty the oil from the oil container into a storage container or bottle. (Fig. 6) wash and dry the oil container and basket. To reuse, refill the oil container with the oil, pouring the oil through a wire strainer or paper filter. (Fig. 7)
Fig. 7
Fig. 6
Storing used oil
Filtering used oil
Cleaning Instructions WARNING: Always press the
“On/Off” button to stop the heating element from heating and remove the plug from the wall outlet before cleaning. Allow the deep fryer and the oil to cool completely (approximately 2 hours) before cleaning. Never immerse the control panel, cord, plug or main enclosure in water or any other liquid.
Please read and follow all
instructions in this manual for best results with your deep fryer.
Never immerse the control panel,
cord, plug or main enclosure in water or any other liquid.
Do not place the control panel, cord,
plug or main enclosure in the dishwasher.
Clean the control panel and main
enclosure only with a damp cloth.
The oil container, frying basket and
cover can be washed in the top rack of the dishwasher. To remove the cover, open it and lift it straight up.
Do not use any type of abrasive pad
or steel wool to clean the power cord magnetic socket.
Do not use alcohol or cleaning
solutions to clean deep fryer.
5
6
OPERATION INSTRUCTIONS
Detachable “Break Away” Power Cord
Your deep fryer has been specifically designed with your safety in mind. Your deep fryer has a unique detachable power supply cord. This power supply cord is designed to “break away” from the fryer in the event that the power cord or fryer is inadvertently pulled or tugged. This is intended to prevent the tipping of the appliance and hazardous spillage of hot oil. It is NOT intended to disconnect the fryer during normal use To connect the power cord - note the instructions on the cord plug area - “this side up”. Place cord into opening - you will feel the magnetic pull. Slide cord into slot until it connects. (Fig. 8)
Fig. 8
CAUTION: Do not use the “break -
away” power cord to disconnect the deep fryer. Always disconnect plug from electrical outlet first before removing the power cord.
WARNING: The “break-away” power
cord is only for accidental disconnection of the deep fryer. It is not to be removed during normal operation. If the cord should be disconnected from the unit during operation, the user should
immediately unplug the power cord
from the electrical wall outlet before any attempt to reconnect the magnetic cord back to the deep fryer unit. Do not come in contact with the magnetic connection of the power cord while it is plugged into electrical wall outlet. Injury can occur.
CAUTION: Do not attempt to defeat
the magnetic cord connection by attempting to permanently attach the power cord to the deep fryer.
How To Reset the Deep Fryer
If for some reason the deep fryer stops heating, the reason might be that the safety reset switch has disconnected. To reconnect the deep fryer, follow the instructions below:
Allow the deep fryer to cool completely.
Remove the control panel from the
unit.
Push the thermostat reset button
located on the back of the control panel with the back of a ball point pen. (Fig. 9) The unit will beep to indicate that it has re-set.
Thermostat
Reset Button
Fig. 9
Model F1011H
ONE (1) YEAR LIMITED WARRANTY
EURO-PRO Operating LLC warrants this product to be free from defects in material and workmanship for a period of one (1) year from the date of the original purchase, when utilized for normal household use, subject to the following conditions, exclusions and exceptions. If your appliance fails to operate properly while in use under normal household conditions within the warranty period, return the complete appliance and accessories, freight prepaid. For Customer Service support, call 1 (800) 798-7398 or visit our website www.euro-pro.com.
If the appliance is found to be defective in material or workmanship, EURO-PRO Operating LLC will repair or replace it free of charge. Proof of purchase date and $ 18.95 to cover the cost of return shipping and handling must be included. * Non-durable parts including, without limitation, paper bags, filters, brushes and electrical parts which normally require replacement are specifically excluded from warranty. The liability of EURO-PRO Operating LLC is limited solely to the cost of the repair or replacement of the unit at our option. This warranty does not cover normal wear of parts and does not apply to any unit that has been tampered with or used for commercial purposes. This limited warranty does not cover damage caused by misuse, abuse, negligent handling or damage due to faulty packaging or mishandling in transit. This warranty does not cover damage or defects caused by or resulting from damages from shipping or repairs, service or alterations to the product or any of its parts, which have been performed by a repair person not authorized by EURO-PRO Operating LLC. This warranty is extended to the original purchaser of the unit and excludes all other legal and/or conventional warranties. The responsibility of EURO-PRO Operating LLC if any, is limited to the specific obligations expressly assumed by it under the terms of the limited warranty. In no event is EURO-PRO Operating LLC liable for incidental or consequential damages of any nature whatsoever. Some states do not permit the exclusion or limitation of incidental or consequential damages, so the above may not apply to you. This warranty gives you specific legal rights, and you may also have other rights which vary from state to state or from province to province.
*Important: Carefully pack item to avoid damage in shipping. Be sure to include proof of purchase date and to attach tag to item before packing with your name, complete address and phone number with a note giving purchase information, model number and what you believe is the problem with item. We recommend you insure the package (as damage in shipping is not covered by your warranty). Mark the outside of your package “ATTENTION CUSTOMER SERVICE”. We are constantly striving to improve our product s, therefore the specifications contain ed her ein are subject to change w ithout noti c e.
-----------------------------------------------------------------------------------
OWNERSHIP REGISTRATION CARD
FOR CANADIAN CONSUMERS ONLY
Please fill out and mail the product registration card within ten (10) days of purchase. The registration will enable us to contact you in the unlikely event of a product safety notification. By returning this card you acknowledge to have read and understood the instructions for use, and warnings set forth in the accompanying instructions
EURO-PRO Operating LLC, 4400 Bois Franc, St-Laurent, QC, H4S 1A7
Model F1011H
______________________________________________________________________
Appliance model
______________________________________________________________________
Date purchased Name of store
______________________________________________________________________
Owner' s name
______________________________________________________________________
Address City Prov. Postal Code
.
7
Printed in China
8
Loading...
