Braun SYNCRO SYSTEM SMART LOGIC, 7650 User Manual
Type Mod le Modelo
5492
+
5301
Syncro SystemSmart Logic
English 4
Français 15
Español 26
Thank you for purchasing a Braun product.
We hope you are completely satisfied with
your new Braun shaver.
If you have any questions, please call:
US residents 1-800-BRAUN-11
1-800-272-8611
Canadian residents 1-800-387-6657
Merci d’avoir fait l’achat d’un produit Braun.
Nous espérons que vous serez pleinement
satisfaite de votre nouveau rasoir Braun.
Si vous avez des questions, veuillez appeler
Braun Canada : 1-800-387-6657
Gracias por haber comprado un producto
Braun.
Esperamos que Ud. completamente
satisfecha con su nueva afeitadora Braun.
Si Ud. tiene alguna duda,
en México, llame al: 01 (800) 508-5800
Internet
www.braun.com
5-492-449/01/I-03/G2
USA / CDN / MEX
Printed in Germany
Imprimé en Allemagne
Impreso en Alemania
Syncro 7650
Clean &Charge
10
3
4
5
6
8
9
A
1
2
7
Syncro
Syncro
+
-
Syncro
Syncro
B
13
14
15
16
4
17
18
12
7650
11
19
English
IMPORTANT SAFETY
INSTRUCTIONS
When using an electrical appliance, basic precautions should always be
followed, including the following:
Read all instructions before using this appliance.
DANGER
To reduce the risk of electric shock:
1. Do not reach for an appliance that has fallen into water.
Unplug immediately.
2. Do not use while bathing or in a shower.
3. Do not place, store or charge the appliance where it can fall or be pulled
into a tub or sink. Do not place in or drop into water or other liquid.
4. When not using for a longer period of time, unplug this appliance from the
electrical outlet.
5. Unplug this appliance before cleaning.
6. This appliance is provided with a low voltage adapter. Do not exchange or
manipulate any part of it.
FOR HOUSEHOLD USE
SAVE THESE INSTRUCTIONS
4
WARNING
To reduce the risk of burns, fire, electric shock, or injury to persons:
1. Close supervision is necessary when this appliance is used by, on, or near
children.
2. Use this appliance only for its intended use as described in this manual.
Do not use attachments not recommended by the manufacturer.
3. The appliance should never be exposed to temperatures of less than
32 º F / 0 ºC and more than 105 ºF/+40ºC for longer than a few hours.
Keep the appliance and cord dry at all times. Do not handle with wet hands.
Do not store in a damp environment. To avoid damage do not wind the cord
around the appliance. It is important to check the cord for damage periodically particularly at each end where the cord enters the plug.
4. Never operate this appliance if it has a damaged cord or plug, if it is not wor-
king properly, if it has been dropped or damaged, or dropped into water.
Return the appliance to a service center for examination and repair.
5. Keep the cord away from heated surfaces.
6. Never drop or insert any object into any opening.
7. Do not use outdoors or operate where aerosol (spray) products are being
used or where oxygen is being administered.
8. Do not use this appliance with a damaged or broken foil, as serious facial
injuries may occur.
9. Always attach plug to appliance first, then to outlet.
To disconnect, turn all controls to «off», then remove plug from outlet.
5
210
A Shaver
Your Braun Syncro is supplied with a Braun
Clean&Charge (please see section B).
SmartLogic Inside
The «SmartLogic» electronics inside your shaver analyzes your personal shaving patterns, and then adapts
the battery care and cleaning cycles to ensure optimal
performance.
Technical specifications:
•Wattage via low voltage cord: 7 W
• Power supply via mains adapter, input voltage:
100-240 V ~ / 50 or 60 Hz (automatic adaptation)
• Shaver input voltage: 12 V
Description
1 Foil protection cap 7 Charging lights (green)
2 Shaver foil 8 Low charge light (red)
3 Cutter block 9 Pilot light
4 Foil release button 10 Shaver socket
5 Long hair trimmer 11 Power supply cord set
6 Switch
Charging the shaver
7650
• First char
connect the shaver to the mains with the switch in
position «0» and charge it for at least 4 hours (plug
might get warm).
The SmartLogic inside your shaver automatically
monitors the condition of the batteries as well as the
charging/discharging processes and adapts them to
your personal shaving patterns.
ging: Using the power supply cord set,
•From now on, the SmartLogic inside your shaver will
ensure optimal care of the batteries. If, for instance,
it is your habit to never let the batteries get low, the
SmartLogic will recognize this, look for a pause
when you are likely to not use the shaver and completely discharge and then recharge your shaver to
recondition the batteries (every six months at the
most, and only when necessary).
•A full charge will give up to 50 minutes of cordless
shaving time depending on your beard growth.
However, the maximum battery capacity will only be
reached after several charging/discharging cycles.
6
• Best environmental temperature range for charging
0..20 40 60 80 100
21
2
a
u
t
o
m
a
t
i
c
l
o
c
k
2
1
3
1
is 60°F to 95°F / 15 °C to 35 °C.
Indicator lights
The pilot light shows that the shaver is connected to the
mains.
When the rechargeable battery is fully charged, all five
charging lights illuminate (20% per light), provided the
shaver is plugged into the outlet or switched on.
The red low-charge light flashes when the battery
capacity has dropped below 20%, provided the shaver
is switched on. The remaining capacity will then be sufficient for 2 to 3 shaves.
Shaving
Switch positions
0 = Off (switch is locked)
Press and push up the switch to operate the
shaver:
1 = Shaving with the pivoting head
The pivoting cutting system automatically adjusts
to every contour of your face.
2 = Shaving with the pivoting head locked at an angle
(to permit shaving in difficult areas, e.g. under the
nose)
3 = The long hair trimmer is activated (for trimming
sideburns, moustache and beard).
0..20 40 60 80
Shaving with the cord
If the rechargeable battery is discharged, you may also
shave with the shaver connected to the mains via the
power supply cord set.
(If the shaver does not run immediately, charge it with
the switch on position «0» for approx. 1 minute.
7
Tips for the perfect shave
• It can take 14-21 days for your beard to adjust to
the new shaving system.
•We recommend that you shave befor
e washing,
as the skin tends to be slightly swollen after
washing.
• Hold the shaver at right angles (90°) to the skin.
• Stretch your skin and shave against the direction
of beard growth.
• Replace the shaver foil and cutter block every
18 months, or when the parts are worn, to ensure
optimum shaving performance.
Keeping your shaver in top shape
Automated cleaning
The Braun Clean&Charge takes care of all cleaning and
lubrication needs of your shaver. Please refer to the
separate use instructions.
Manual cleaning
For easy cleaning after each shave, switch the shaver
off. Press the release buttons to lift the shaver foil (do
not remove the foil completely). Switch on the shaver
10
10
oil
for approx. 5-10 seconds so that the shaved stubbles
can fall out.
For a thorough cleaning (weekly), remove the shaver foil
and tap it out on a flat surface. Using the brush, clean
the cutter block and the inner area of the pivoting head.
About every four weeks, clean the cutter block with
Braun cleaning agents.
If your skin is very dry and you notice a reduced operation time of the shaver apply a drop of light machine oil
onto the shaver foil.
Replacing the shaving parts
The shaver foil and cutter block are precision parts that,
in time, are subject to wear. Replace your foil and cutter
block every 18 months and get a 25 % better shave.*
(Shaver foil and cutter block: part No. 7000)
(* Overall evaluation from Braun users comparing their
shave with new parts and those used for 18 months.)
8
Accessories
Available at your dealer or Braun Service Centres:
Shaver foil and cutter block
(part No. 7000)
Environmental notice
This appliance is provided with a nickel-hydride
batteries. They do not contain any harmful heavy
metals. Nevertheless, in the interest of recycling raw
materials, please do not dispose of this appliance in the
household waste at the end of its useful life. Disposal
can take place at a Braun Service Center or appropriate
collection sites.
Subject to change without notice.
Syncro
7000
7000
9
B Clean&Charge
Braun Clean&Charge has been developed to automatically clean and charge your shaver. It also serves as a
storage unit. For peak performance of your shaver,
clean it daily in the Clean&Charge.
During the automated cleaning process, the shaver is
switched on and off at intervals to obtain best cleaning
results. Since the specially formulated cleaning fluid
also contains a small amount of oil, the cleaning procedure also fulfills the lubrication needs of your shaver.
Important
• Only use the power supply cord set supplied with
the shaver.
• In order to avoid any leakage of the cleaning fluid,
place the appliance on a flat, stable surface. Be
careful not to tip, move suddenly or transport in any
way if a cleaning cartridge is installed.
• Do not place the appliance in a mirror cabinet, nor
store it over radiators, nor place it on polished or
laquered surfaces. Do not expose to direct sunlight.
• The appliance contains highly flammable
liquid. Keep it away from sources of ignition.
No smoking. Keep out of reach of children.
Do not refill cartridge. Use only original Braun refill
cartridge.
• When cleaning the shaver, its protection cap should
be removed.
Description
12 Lift button for cartridge exchange
13 Release button
14 Contact bow
15 Operation mode selector
16 «clean» light: cleaning process indicator
17 «charge» light: charging process indicator
18 «cartridge» light: cartridge replacement indicator
19 Cleaning cartridge
Technical specifications
• Power consumption:
3 W when cleaning
7 W when charging
• Power supply:
100-240 V ~ /50 or 60 Hz (automatic adaptation)
• Input voltage: 12 V
10
Before using Clean&Charge
2
1
old
new
new
7650
a
u
t
o
m
a
t
i
c
l
o
c
k
3
2
1
0
o
n
/
o
ff
c
le
a
n
c
h
a
r
g
e
c
a
r
t
r
i
d
g
e
7650
a
u
t
o
m
a
t
i
c
l
o
c
k
3
2
10
7650
For the fi
supply cord set directly to the shaver, charge it for
4 hours and shave at least once.
Only then can the shaver be cleaned or recharged in the
Clean&Charge.
If the rechargeable batteries are discharged, select the
combined «clean + charge» program rather than the
«clean» program alone.
Installing the cartridge
Press the lift button (12) to open the housing.
Hold the cartridge down on a flat, stable surface
(e.g. table). Carefully remove the lid from the cartridge.
Slide the cartridge into the base as far as it will go.
Slowly close the housing by pushing it down until it
locks.
Replacing the cartridge
After having pressed the lift button to open the housing,
wait for a few seconds before removing the used cartridge.
Before discarding the used cartridge, make sure to
close the openings using the lid of the new cartridge,
since the used cartridge will contain contaminated
cleaning solution.
rst charge of the shaver, connect the power
Operating your Clean&Charge
• Use the power supply cord set from your shaver and
plug it into the Clean&Charge and then into a main
outlet.
Open the contact bow (13) by pressing the release
button (14). After shaving, switch the shaver off and
place it upside down into the Clean&Charge (without
having released the shaver foil).
• Select the operation mode by toggling with the
mode selector (15):
clean (about 15 min)
clean + charge (about 75 min)
charge (about 60 min)
The corresponding lights will come on.
(With cord shavers, only the «clean» function can be
selected.)
11
Loading...
