Our products are designed to meet the highest
standards of quality, functionality and design. We
hope you enjoy your new Braun Shaver.
Warning
Your Prosonic shaver is provided with a special
cord set, which has an integrated Safety Extra
Low Voltage power supply. Do not exchange or
tamper with any part of it, otherwise there is risk
of electric shock.
Description
1 Foil & cutter cassette
2 Cassette release button
3 Shaver head «lock» switch
4 Pop-out long hair trimmer
5 On/off switch
6 Reset button
7 Shaver display
8 Shaver power socket
9 Special cord set
0 Travel case
STOPSTOP
Charging
The best environmental temperature for charging
is between 5 °C and 35 °C.
• Using the special cord set 9, connect the
shaver to an electrical outlet with the motor
switched off and charge it for at least one hour.
• A full charge provides up to 50 minutes
of cordless shaving time. This may vary
according to your beard growth.
• If the rechargeable battery has run out of
power (discharged), you may also shave by
connecting the shaver to an electrical outlet via
the special cord set.
Shaver display 7
r
r
releaserelea
se
9566
9566
The green charge segment(s) will fl ash when
the shaver is being charged or when in use.
When the battery is fully charged, the charge
segment(s) will light up continuously provided
9565
9565
that the shaver is switched on or connected to
an electrical outlet.
The red low charge/empty segment fl ashes
when the battery capacity has dropped below
20%, provided the shaver is switched on.
The remaining capacity will then be suffi cient
for 2 to 3 shaves.
Shaving
t
t
on
on
off
off
2
2
lock
lock
1
1
trimmer
trimmer
on
on
off
off
lock
lock
lock
lock
lock
lock
Press the on/off switch 5 to operate the shaver:
• The pivoting shaver head and fl oating foils
automatically adjust to every contour of your
face.
• To shave hard to reach areas (e.g. under the
nose) slide the shaver head «lock» switch to
the back position to lock the pivoting head at
an angle.
• To trim sideburns, moustache or beard, slide
the pop-out long hair trimmer upwards.
Tips for the perfect shave
For best shaving results, Braun recommends you
to follow 3 simple steps:
1. Always shave before washing your face.
2. At all times, hold the shaver at right angles
(90°) to your skin.
3. Stretch your skin and shave against the
direction of your beard growth.
Cleaning
This appliance is suitable for cleaning
under running tap water .
Warning: Detach the shaver from the
power supply before cleaning it in water.
20
Regular cleaning ensures better shaving
on
re
le
a
s
e
on
re
le
a
s
e
performance. Rinsing the shaving head under
running water after each shave is an easy and
fast way to keep it clean:
• Switch the shaver on (cordless) and rinse
the shaving head under hot running water.
You may use liquid soap without abrasive
substances. Rinse off all foam and let the
shaver run for a few more seconds.
• Next, switch off the shaver, press the release
button 2 to remove the foil and cutter cassette
1 and let it dry.
• If you regularly clean the shaver under
water, then once a week apply a drop of
light machine oil on top of the foil and cutter
cassette.
Alternatively, you may clean the shaver using the
brush provided:
• Switch off the shaver. Remove the foil and
cutter cassette 1 and tap it out on a fl at
surface. Using the brush, clean the inner area
of the pivoting head. However, do not clean
the foil and cutter cassette with the brush as
this may damage it.
trim
trim
mer
mer
w
w
ashable
ashable
re
re
le
le
a
a
s
s
e
e
washable
washable
er
er
oil
oil
re
re
le
le
a
a
s
s
e
e
washable
washable
click!
click!
trimmer
trimmer
re
re
le
le
a
a
s
s
e
e
washable
washable
re
re
le
le
a
a
s
s
e
e
washable
washable
re
re
le
le
a
a
s
s
e
e
washable
washable
Keeping your shaver in top shape
Replacing the foil and cutter cassette/reset
To maintain 100% shaving performance,
replace the foil and cutter cassette 1, when
the replacement symbol lights up on the shaver
display 7 (after about 18 months) or when
cassette is worn.
The replacement symbol will remind you during
the next 7 shaves to replace the foil and cutter
cassette. Then the shaver will automatically reset
the display.
After you have replaced the foil and cutter
cassette, use a ball-pen to push the reset button
6 for at least 3 seconds to reset the counter.
While doing so, the replacement light blinks and
goes off when the reset is complete. The manual
reset can be done at any time.
21
9000
9000
9000
9000
Series
Series
Series
360°Complete
360°Complete
Series
re
re
le
le
a
a
s
s
e
e
washable
washable
er
er
Environmental notice
This appliance contains rechargeable
batteries. In the interest of protecting the
environment, please do not dispose of the
product in household waste at the end of
its useful life. Disposal can take place at a
Braun Repair Centre or at appropriate
collection points provided in your country.
Subject to change without notice.
This product conforms to the European
Directives EMC 89/336/EEC and Low
Voltage 73/23/EEC.
For electric specifi cations, see printing on the
special cord set.
Guarantee
We grant 1 year guarantee on the product
commencing on the date of purchase. Within
the guarantee period we will eliminate, free of
charge, any defects in the appliance resulting
from faults in materials or workmanship, either
by repairing or replacing the complete appliance
as we may choose.
This guarantee extends to every country where
this appliance is supplied by Braun or its
appointed distributor.
This
guarantee does not cover: damage due
to improper use, normal wear and tear
(e.g. foil & cutter cassette) as well as defects that
have a negligible effect on the value or operation
of the appliance. The guarantee becomes void if
repairs are undertaken by unauthorised persons
and if original Braun parts are not used.
To obtain service within the guarantee period,
hand in or send the complete appliance with
your sales receipt to an authorised Braun
Customer Service Centre.
For UK only:
This guarantee in no way affects your rights
under statutory law.
