Braun 5730 User Manual

cruZer

Stapled booklet, 105x148 mm, 36 p (incl. 8 p cover), 2/2c = black + cyan

Type/Modèle/Modelo 5730

www.braun.com

cruZer

face

English 6

Français 17

Español 26

Thank you for purchasing a Braun product. We hope you are completely satisfied with your new Braun shaver. If you have any questions, please call: US residents 1-800-BRAUN-11 1-800-272-8611 Canadian residents 1-800-387-6657

Merci d’avoir fait l’achat d’un produit Braun. Nous espérons que vous serez pleinement satisfait de votre nouveau rasoir Braun. Si vous avez des questions, veuillez appeler Braun Canada : 1-800-387-6657

Gracias por haber comprado un producto Braun. Esperamos que esté completamente satisfecho con su nueva rasuradora Braun. Si tiene preguntas, puede llamar al: 01(800) 508-5800

99746286/XI-10 USA/CDN/MEX

90°

180°

huile

English

IMPORTANT SAFETY INSTRUCTIONS

When using an electrical appliance, basic precautions should always be followed, including the following:

Read all instructions before using this appliance.

When disconnected, the hand-held part of this shaving appliance may be used in a bath or shower.

DANGER

To reduce the risk of electric shock:

1. The charger unit is not for immersion in water or for use in shower.

2. Do not reach for a charger that has fallen into water. Unplug immediately.

3. Do not place, store or charge the appliance where it can fall or be pulled into a tub or sink. Do not place in or drop into water or other liquid.

4. Except when charging, always unplug this appliance from the electrical outlet immediately after using.

5. Do not use an extension cord with this appliance.

6. This appliance is provided with a special electric cord set with integrated Safety Extra Low Voltage power supply. Do not exchange or manipulate any part of it.

FOR HOUSEHOLD USE ONLY

WARNING

To reduce the risk of burns, fire, electric shock, or injury to persons:

1. Close supervision is necessary when this appliance is used by,

on, or near children or invalids.

2. Use this appliance only for its intended use as described in this

manual.

Do not use attachments not recommended by the manufacturer.

3. Never operate this appliance if it has a damaged cord or plug,

if it is not working properly, if it has been dropped or damaged, or if the power supply has been dropped into water. Return the appliance to a service center for examination and repair.

4. Keep the cord away from heated surfaces.

5. Never drop or insert any object into any opening of this

appliance.

6. Do not use outdoors or operate where aerosol (spray) products

are being used or where oxygen is being administered.

7. Do not use this appliance with a damaged or broken shaving

system, as serious skin injuries may occur.

8. Always attach plug to appliance first, then to outlet.

To disconnect, turn all controls to «off», then remove plug from

outlet.

9. When plugging to an electrical outlet outside the USA, use a

plug adapter to match the outlet’s pin configuration.

10. Oil bottle

Keep out of reach of children. Do not swallow. Dispose of

properly when empty.

SAVE THESE INSTRUCTIONS

Our products are designed to meet the highest standards of quality, functionality and design. We hope you entirely enjoy your new Braun shaver.

Caution

For safety reasons this appliance can only be operated cordless. For usage in other body areas, please make sure that the skin is stretched. For hygienic reasons, do not share this appliance with other persons.

Description

1 3-day beard comb & protective cap 2 Shaver foil 3 Cutter block 4 Twistable trimmer 4a Wide trimmer (28 mm) 4b Narrow trimmer (14 mm) 5 Charging light 6 On/off switch 7 Adjustable comb 8 Beard length selector 9 Special cord set 10 Precision comb 11 Charging stand

Charging

• The best environmental temperature for charging is between 60 °F to

95 °F / 15 °C to 35 °C. Do not expose the shaver to temperatures higher than 122 °F / 50 °C for extended periods of time.

• Using the special cord set, connect the shaver to an electrical outlet with

the motor switched off.

• When charging for the first time or when the shaver is not used for a few

months, leave the shaver to charge continuously for 4 hours.

• The charging light (5) shows that the appliance is being charged. When the

battery is fully charged, the charging light turns off. Intermittent blinking after a while indicates that the battery maintains its full capacity. This can also happen short term when charging after the battery was completely discharged.

• A full charge provides 30 minutes of cordless shaving time depending on

your beard growth.

• Once the shaver is completely charged, discharge the shaver through

normal use. Then recharge to full capacity. Subsequent charges will take about 1 hour.

• Maximum battery capacity will only be reached after several charging/

discharging cycles.

• 5-minute quick charge is sufficient for a shave.

Shaving

First, remove the adjustable comb (7): Using your thumbs, press against the side clips of the adjustable comb so that they swing off in the direction of the arrows (a). Activate the on/off switch (6). The floating foil frame automatically adapts to your skin surface for a close, smooth shave.

For best results:

• Always shave before washing your face.

• At all times, hold the shaver at right angles (90°) to the skin (b).

• Stretch the skin and shave against the direction of beard growth.

• For pre-shaving after a few days of not having shaved, use the wide

trimmer (4a) to pre-cut long hairs. For a close, smooth shave, finish with the foil.

• To maintain the appliance performing like new, replace your foil and cutter

block at least every 18 months or when worn.

Style

Using the twistable trimmer

The wide trimmer (4a) evenly cuts and trims large areas (c). It is ideal for shaping sideburns, moustaches and partial short beards. The wide trimmer is provided with safety rips and a gliding strip that helps prevent skin irritation and for easy gliding. Press the blue stripes to push up the twistable trimmer (4). While stretching the skin, guide the wide trimmer against the direction of hair growth. The narrow trimmer (4b) precisely defines lines and edges (d), being ideal for precise contouring. To use the narrow trimmer, push up the twistable trimmer and turn it 180°. Frequent use of the twistable trimmer will reduce the battery capacity.

Trim

Using the trimming attachments (1), (7) and (10)

Place the respective trimming attachment onto the shaver foil (2) or on the twistable trimmer (4) and press it against the shaver housing until it snaps into place with a click (e).

3-day beard comb & protective cap (1): This attachment is perfectly suited for creating a stubble look and maintaining it.

• Place the attachment onto the foil (2) and push up the twistable trimmer (4).

Turn on the shaver and use the appliance as shown in the illustration (e). The attachment ensures an optimum usage angle.

Adjustable comb (7): This attachment is ideal for beard trimming and keeping it at a constant length.

• Place the attachment onto the shaver foil (2) and set desired beard length.

Press beard length selector (8) and slide it up (f) (possible length settings from top to bottom: 1.2 mm / 2.8 mm / 4.4 mm / 6 mm). Push up the twistable trimmer (4).

• Press the on/off switch and trim against hair growth by guiding the

transparent comb part over the skin (f).

Precision comb (10): This attachment is ideal for trimming eyebrows (ca. 3 mm).

• It is recommended to place the 3-day beard comb & protection cap (1)

onto the shaving foil (2) (e) when using the precision comb.

• Place the attachment onto the extended narrow trimmer (4b) (g).

• Turn on the shaver and trim against hair growth (g).

Cleaning

Regular cleaning ensures better shaving performance. Rinsing the shaving head after each shave under running water is an easy and fast way to keep it clean:

• Switch the shaver on (cordless) and rinse the shaving head under hot

running water (h). You may use liquid soap without abrasive substances. Rinse off all foam and let the shaver run for a few more seconds.

• Next, switch off the shaver, remove the shaver foil and the cutter block.

Then leave the disassembled shaving parts to dry.

• If you regularly clean the shaver under water, then once a week apply a

drop of light machine oil onto the trimmers (4a, 4b) and shaver foil (i).

Alternatively, you may clean the shaver using the brush provided (j):

• Switch off the shaver. Remove the shaver foil.

• Using the brush, clean the cutter block and the inner area of the shaver

head. However, do not clean the shaver foil with the brush as this may damage the foil.

Keeping your shaver in top shape

Replacing the shaving parts

To maintain the appliance performing like new, replace your foil and cutter block at least every 18 months or when worn. Change both parts at the same time for a closer shave with less skin irritation. (Shaver foil and cutter block: 10B)

Preserving the batteries

In order to maintain the optimum capacity of the rechargeable batteries, the shaver has to be fully discharged (by shaving) every 6 months approximately. Then recharge the shaver to full capacity.

Environmental notice

This product contains rechargeable batteries. In the interest of protecting the environment, please do not dispose of the product in the household waste at the end of its useful life. Disposal can take place at a Braun Service Center or at appropriate collection points provided in your country.

Subject to change without notice.

For electric specifications, see printing on the special cord set.
