Braun Tricontrol 4775, 5713 User Manual
4775
n
o
ff
o
n
o
r
e
mm
i
r
t
www.braun.com/register
+
4775
a
w
e
l
b
a
h
s
Tr iTriControlControl
Tr iTriControlControl
Type 5 713
Modèle 5 713
Modelo 5 713
5-713-455/04/XI-05
USA/CDN/MEX
English 4
Français 9
Español 14
Thank you for purchasing a Braun product.
We hope you are completely satisfied with
your new Braun shaver.
If you have any questions, please call:
US residents 1-800-BRAUN-11
1-800-272-8611
Canadian residents 1-800-387-6657
Merci d’avoir fait l’achat d’un produit Braun.
Nous espérons que vous serez pleinement
satisfaite de votre nouveau rasoir Braun.
Si vous avez des questions, veuillez appeler
Braun Canada : 1-800-387-6657
Gracias por haber comprado un producto
Braun.
Esperamos que Ud. quede completamente
satisfecha con su nueva afeitadora Braun.
Si Ud. tiene alguna duda, por favor llame al:
01(800) 508-5800
1
2
3
on • off
F/C4700
washable
3
on
5
6
trimmer
+
4775
on off
washable
4
7
on • off
on
•
off
3
oil
English
IMPORTANT SAFETY
INSTRUCTIONS
When using an electrical appliance, basic precautions should always be
followed, including the following:
Read all instructions before using this appliance.
When disconnected, the hand-held part of this shaving appliance may be
cleaned under water.
DANGER
To reduce the risk of electric shock:
1. Use only in dry condition.
2. Do not submerge in water.
3. Do not reach for an appliance that has fallen into water. Unplug immediately.
4. Do not use while bathing or in a shower.
5. Do not place, store or charge the appliance where it can fall or be pulled into a
tub or sink. Do not place in or drop into water or other liquid.
6. Except when charging, always unplug this appliance from the electrical outlet
immediately after using.
7. Unplug this appliance before cleaning.
8. This appliance is provided with a special cord set with integrated Safety Extra
Low Voltage power supply. Do not exchange or manipulate any part of it.
9. Do not use an extension cord with this appliance.
FOR HOUSEHOLD USE ONLY
4
WARNING
To reduce the risk of burns, fire, electric shock, or injury to persons:
1. Close supervision is necessary when this appliance is used by, on, or near
children or invalids.
2. Use this appliance only for its intended use as described in this manual.
Do not use attachments not recommended by the manufacturer.
3. Never operate this appliance if it has a damaged cord or plug, if it is not
working properly, if it has been dropped or damaged, or if the power supply
has been dropped into water. Return the appliance to a service center for
examination and repair.
4. Keep the cord away from heated surfaces.
5. Never drop or insert any object into any opening.
6. Do not use outdoors or operate where aerosol (spray) products are being
used or where oxygen is being administered.
7. Do not use this appliance with a damaged or broken foil, as serious skin
injuries may occur.
8. Always attach plug to appliance first, then to outlet.
To disconnect, turn all controls to «off», then remove plug from outlet.
SAVE THIS INSTRUCTIONS
5
Description
Shaving
1 Shaver foil
2 Cutter block
3 Release button
4 «on/off» switch
5 Long hair trimmer
6 Dual function light
green: charging
red: low-charge
7 Special cord set
Charging
The best environmental temperature for charging is between 60 °F to 95 °F/15 °C to 35 °C.
• Using the special cord set, connect the
shaver to an electrical outlet with the motor
switched off.
• When charging for the first time, leave the
shaver to charge continuously for 4 hours.
Subsequent charges will take about 1 hour.
• As soon as you start charging the shaver,
the green charging light (6) comes on.
When the batteries are fully charged, the
green light intermittently blinks on and off.
This indicates that the battery maintains its
full capacity.
• Once the shaver is completely charged,
discharge the shaver through normal use.
Then recharge to full capacity.
• A full charge will give up to 40 minutes of
cordless shaving time depending on your
beard growth. However, the maximum
battery capacity will only be reached after
several charging/discharging cycles.
• When the batteries are running low, the
dual function light (6) turns red (provided
the shaver is switched on). The red light
indicates the shaver capacity has dropped
below 20%, which is sufficient for 2 to 3
shaves.
• If the rechargeable batteries are dis-
charged, you can shave without charging
by connecting the shaver to an electrical
outlet via the special cord set.
Press the «on/off» switch (4) to turn the shaver
on.
Trimmer: When the long hair trimmer (5) is
activated, it allows controlled trimming of
moustache or sideburns.
Tips for the perfect shave
• It can take up to 14-21 days for your
beard to adjust to the new shaving
system.
• Shave before washing your face or taking
a shower, as skin tends to swell after
washing.
• The dryer the skin, the closer the shaving
results will be.
• Hold the shaver at right angles (90°) to the
skin. Stretch the skin and shave against
the direction of beard growth.
• To maintain 100% shaving performance,
replace your foil and cutter block every 18
months or when worn.
Cleaning
The hand-held unit shall be detached from
the power supply cord before cleaning. The
shaver shall not be used until it has dried.
Regular cleaning ensures better shaving
performance. Rinsing the shaving head after
each shave under hot running water is an easy
and fast way to keep it clean:
• Switch the shaver on (cordless) and rinse
the shaving head under hot running water.
A natural based soap may also be used
provided it contains no particles or
abrasive substances. Rinse off all foam and
let the shaver run for a few more seconds.
• Next, switch the shaver off and press the
release buttons. Lift the shaver foil off and
pull the cutter block out. Then leave the
disassembled shaving parts to dry.
Alternatively, you may clean the shaver using
the brush provided:
6
