BRAUN 570cc-3 User Manual

Series5

590 cc

570 cc

sta

min

•

off

ive sit

Type 5751

Modèle 5751

Modelo 5751

www.braun.com/register

English	6	Thank you for purchasing a Braun product.
		We hope you are completely satisfied with
Français	14	your new Braun shaver.
		If you have any questions, please call:
Español	21	US residents	1-800-BRAUN-11
			1-800-272-8611
		Canadian residents 1-800-387-6657

Merci d’avoir fait l’achat d’un produit Braun. Nous espérons que vous serez pleinement satisfait de votre nouveau rasoir Braun.

Si vous avez des questions, veuillez appeler Braun Canada au : 1-800-387-6657

Gracias por haber comprado un producto Braun.

Esperamos que quede completamente satisfecho con su nueva afeitadora Braun. Si tiene alguna duda, por favor llame al:

01(800) 508-5800

98927731/I-09 USA / CAN / MEX Printed in Germany

Imprimé en Allemagne Impreso en Alemania

	clea	n
start	clea	ing

washable

min

7
8
9
10
11			e
			iv
12			it
		n	s
	s	n
	e

on • off

590 570

sensiitiive

start clea

start clea	n
	ing

ning

min

new /nouveau

start

min

clea

•

start

clea

ning

			e
			iv
			it
	e	n	s
s	e
s

on • off

full

low

	e
	iv
	t
	i
	s
e	n

washable

90°

nsitive

	min	•••
	min
		b
off	min	•••
s		c
ni	ng	c
start clea	ng
	min

s i t i v e

start clea	n
	ing

min

new / nouveau

old ancien

start clea	n
	ing

min

s i t i v e

English

IMPORTANT SAFETY

INSTRUCTIONS

When using an electrical appliance, basic precautions should always be followed, including the following:

Read all instructions before using this appliance.

When disconnected, the hand-held part of this shaving appliance may be cleaned under water.

DANGER

To reduce the risk of electric shock:

1.Use only in dry condition.

2.Do not submerge in water.

3.Do not reach for an appliance that has fallen into water. Unplug immediately.

4.Do not use while bathing or in a shower.

5.Do not place, store or charge the appliance where it can fall or be pulled into a tub or sink. Do not place in or drop into water or other liquid.

6.Except when charging, always unplug this appliance from the electrical outlet immediately after using.

7.Unplug this appliance before cleaning.

8.This appliance is provided with a special cord set with integrated Safety Extra Low Voltage power supply. Do not exchange or manipulate any part of it.

9.Do not use an extension cord with this appliance.

FOR HOUSEHOLD USE ONLY

WARNING

To reduce the risk of burns, fire, electric shock, or injury to persons:

1.Close supervision is necessary when this appliance is used by, on, or near children or invalids.

2.Use this appliance only for its intended use as described in this manual. Do not use attachments not recommended by the manufacturer.

3.Never operate this appliance if it has a damaged cord or plug, if it is not working properly, if it has been dropped or damaged, or if the power supply has been dropped into water. Return the appliance to a service center for examination and repair.

4.Keep the cord away from heated surfaces.

5.Never drop or insert any object into any opening.

6.Do not use outdoors or operate where aerosol (spray) products are being used or where oxygen is being administered.

7.Do not use this appliance with a damaged or broken foil, as serious skin injuries may occur.

8.Always attach plug to appliance first, then to outlet.

To disconnect, turn all controls to «off», then remove plug from outlet.

9.When plugging to an electrical outlet outside the USA, use a plug adapter to match the outlet’s pin configuration.

10.Caution: The battery used in this device may present a fire or chemical burn hazard if mistreated. Do not disassemble heat above 100 °C (212 °F) or incinerate.

SAVE THESE INSTRUCTIONS

Warning

Your shaving system is provided with a special cord set, which has an integrated Safety Extra Low Voltage power supply. Do not exchange or tamper with any part of it, otherwise there is risk of an electric shock.

To prevent the cleaning fluid from leaking, ensure that the Clean&Renew station is placed on a flat surface. When a cleaning cartridge is installed, do not tip, move suddenly or transport the station in any way as cleaning fluid might spill out of the cartridge. Do not place the station inside a mirror cabinet, nor place it on a polished or lacquered surface.

The cleaning cartridge contains a highly flammable liquid so keep it away from sources of ignition. Do not expose to direct sunlight and cigarette smoking nor store it over a radiator.

Keep it out of reach of children.

Do not refill the cartridge and use only original Braun refill cartridges.

Description

Clean&Renew™ station

1Level indicator

2Lift button for cartridge exchange

3Station-to-shaver contacts

4Start button

5Station power socket

6Cleaning cartridge

Shaver

7Shaver foil

8Cutter block

9Foil release buttons

10Long hair trimmer

11Comfort setting switch «sensitive»

12Shaver-to-station contacts

13On/off switch

14Shaver display

15Cleaning light (yellow)

16Replacement light for shaving parts

17Reset button

18Shaver power socket

19Special cord set

20Case

A Before shaving

Prior to first use, you have to connect the shaver to an electrical outlet using the special cord set (19) or alternatively, proceed as follows:

Installing the Clean&Renew station

•Using the special cord set (19), connect the station power socket (5) to an electrical outlet.

•Press the lift button (2) to open the housing.

•Hold the cleaning cartridge (6) down on a flat, stable surface (e.g. table).

•Carefully remove the lid from the cartridge.

•Slide the cartridge into the base of the station as far as it will go.

•Slowly close the housing by pushing it down until it locks.

Charging the shaver in the Clean&Renew station

Insert the shaver head down into the cleaning station. (The contacts (12) on the back of the shaver will align with the contacts (3) in the cleaning station).

If required, the Clean&Renew station will start charging the shaver now.

A full charge provides up to 45 minutes of cordless shaving time. This may vary according to your beard growth.

The best environmental temperature for charging is between 41 °F to 95 °F / 5 °C to 35 °C. Do not expose the shaver to temperatures higher than 122 °F / 50 °C for extended periods of time.

Shaver display

The shaver display (14) shows the charge status of the battery. During charging or when using the shaver, the respective green

battery segment will blink. When fully charged, all green segments will light up for approximately one hour, provided the shaver sits in the C&R station.

The red low charge segment flashes when the battery is running low. You should be able to finish your shave.

B Shaving

Press the on/off switch (13) to operate the shaver.

Comfort setting switch «sensitive»

Setting the shaver head according to your comfort needs.

The «sensitive» switch (11) provides three options for comfort setting:

1« + » :

The shaver head is in full swing, freely follows the contours of your skin to provide more comfort.

2Middle position:

The shaver head is semi-fixed for more control.

3« – » :

The shaver head is fixed for full control and precise handling in hard to reach areas.

Long hair trimmer

To trim sideburns, moustache or beard, slide the long hair trimmer (10) upwards.

Tips for the perfect shave

For best results, Braun recommends you follow 3 simple steps:

1.Always shave before washing your face.

2.At all times, hold the shaver at right angles (90°) to your skin.

3.Stretch your skin and shave against the direction of your beard growth.

Shaving with the cord

If the shaver has run out of power (discharged), you may also shave with the shaver connected to an electrical outlet via the special cord set.

Cleaning

For best shaving results, we recommend cleaning the shaver in the station after each shave (see «Automatic cleaning»).

All charging and cleaning needs are then automatically taken care of.

Cleaning indicator

Clean your shaver in the Clean&Renew station at the latest when the yellow cleaning light (15) shines constantly after shaving.

If this is not done, the cleaning light will go off after some time and the counter will be reset.

C Automatic cleaning

The Clean&Renew has been developed for cleaning, charging and storing your shaver. After each shave, return the shaver to the Clean&Renew station and proceed as follows:

•Insert the shaver head down into the cleaning station.

•Push down the start button (4). The cleaning process will start (approx. 5 minutes cleaning, 4 hours drying).

•Do not interrupt the cleaning process, as it leaves the shaver wet and not fit for use.

If interruption is needed nonetheless, press the start button (4).

•When cleaning is finished, the yellow cleaning light will go off and the shaver is ready for use.

•A cleaning cartridge should be sufficient for about 30 cleaning cycles. When the level indicator (1) has reached the «min» mark, the remaining fluid in the cartridge is sufficient for about 5 more cycles. Then the
