Braun 5485+5302 User Manual

5441

Type/Modèle/Modelo 5485

+ 5302

trimmer

off

headlock

5441

Flex Integral System

English 4

Français 15

Español 25

Thank you for purchasing a Braun product. We hope you are completely satisfied with your new Braun product. If you have any questions, please call: US residents 1-800-BRAUN-11

1-800-272-8611

Canadian residents 1-800-387-6657

Merci d’avoir fait l’achat d’un produit Braun. Nous espérons que vous serez pleinement satisfait de votre nouveau produit Braun. Si vous avez des questions, veuillez appeler Braun Canada : 1 800 387 6657

Gracias por haber comprado un producto Braun. Esperamos que Ud. completamente satisfecha con su nuevo producto Braun. Si Ud. tiene alguna duda, por favor llame al 01(800) 508-5800

Internet

www.braun.com

5-485-458/00/I-02/G2 USA / CDN / MEX Printed in Germany Imprimé en Allemagne Impreso en Alemania

The world’s # 1 selling foil shavers

Le rasoir à grille le plus vendu au monde

Fabricante mundial # 1 en la venta de rasuradoras de lámina

Flex integral 5441

Clean &Charge

6 7

13 14

No. 6000

15 16 17 18

lock

off

trimmer

head lock

English

IMPORTANT SAFETY INSTRUCTIONS

When using an electrical appliance, basic precautions should always be followed, including the following:

Read all instructions before using this appliance.

DANGER

To reduce the risk of electric shock:

1. Do not reach for an appliance that has fallen into water. Unplug immediately.

2. Do not use while bathing or in a shower.

3. Do not place, store or charge the appliance where it can fall or be pulled into a tub or sink. Do not place in or drop into water or other liquid.

4. When not using for a longer period of time, unplug this appliance from the electrical outlet.

5. Unplug this appliance before cleaning.

6. This appliance is provided with a low voltage adapter. Do not exchange or manipulate any part of it.

FOR HOUSEHOLD USE SAVE THESE INSTRUCTIONS

WARNING

To reduce the risk of burns, ﬁre, electric shock, or injury to persons:

1. Close supervision is necessary when this appliance is used by, on, or near children.

2. Use this appliance only for its intended use as described in this manual. Do not use attachments not recommended by the manufacturer.

3. The appliance should never be exposed to temperatures of less than 32 ºF / 0 ºC and more than 105 ºF/+40ºC for longer than a few hours. Keep the appliance and cord dry at all times. Do not handle with wet hands. Do not store in a damp environment. To avoid damage do not wind the cord around the appliance. It is important to check the cord for damage periodically particularly at each end where the cord enters the plug.

4. Never operate this appliance if it has a damaged cord or plug, if it is not working properly, if it has been dropped or damaged, or dropped into water. Return the appliance to a service center for examination and repair.

5. Keep the cord away from heated surfaces.

6. Never drop or insert any object into any opening.

7. Do not use outdoors or operate where aerosol (spray) products are being used or where oxygen is being administered.

8. Do not use this appliance with a damaged or broken foil, as serious facial injuries may occur.

9. Always attach plug to appliance ﬁrst, then to outlet. To disconnect, turn all controls to «off», then remove plug from outlet.

A Shaver

Your Braun Flex Integral is supplied with a Braun Clean&Charge (please see section B).

Technical speciﬁcations

•Wattage via cord set: 7 W

• Automatic power supply: (100-240 V~/50 or 60 Hz)

• Shaver input voltage: 12 V

Description

1 Foil protection cap 2 Shaver foil 3 Cutter block 4 Foil release button 5 Pop-out long hair trimmer 6 Switch lock 7 Switch for locking the pivoting head («head lock»)

and for activating the pop-out long hair trimmer

(«trimmer») 8 On/off switch 9 Charging light 10 Shaver socket 11 Power supply cord set

Charging the shaver

charging: Using the power supply cord set,

7570

off

• First

connect the shaver to the mains with the switch

on position «off» and charge it for at least 4 hours

(plug might get warm).

• Once the shaver is completely charged, shave with-

out the cord until fully discharged. Then recharge to

full capacity again (subsequent charges will take

about 1 hour).

•A full charge will give up to 50 minutes of cordless

shaving time depending on your beard growth.

However, the maximum battery capacity will only be

reached after several charging/discharging cycles.

• Best environmental temperature range for charging

is 60 °F to 95 °F / 15°C to 35 °C.

• The charging light shows that the shaver is being

charged. When the rechargeable batteries are fully

charged, the charging light goes off.

If later on, the charging light comes on again, this

indicates that the shaver is being recharged to

maintain its full capacity.

Shaving

Switch lock

The shaver is delivered with the switch lock activated (position «lock»). Push the switch lock up before you shave for the ﬁrst time. To avoid accidentally switching the shaver on, e.g. when travelling, push the switch lock to position «lock».

Switch positions

off

Shaving with the pivoting head. The pivot-

head lock

trimmer

Shaving with the cord

If the rechargeable batteries are discharged, you may also shave with the shaver connected to the mains via the power supply cord set. (If the shaver does not run immediately, charge it with the switch on position «off» for approx. 1 minute.)

ing cutting system automatically adjusts to every contour of your face.

Shaving with the pivoting head locked (to permit shaving in difﬁcult areas, e.g. under the nose)

The long hair trimmer is activated (for trimming sideburns, moustache and beard).

lock

off on

off

trim

head lock

trimmer

head lock

Tips for the perfect shave

• It can take 14-21 days for your beard to adjust to the new shaving system.

•We recommend that you shave befor

e washing, as the skin tends to be slightly swollen after washing.

• Hold the shaver at right angles (90°) to the skin.

• Stretch your skin and shave against the direction of beard growth.

• Replace the shaver foil and cutter block every 18 months, or when the parts are worn, to ensure optimum shaving performance.

Keeping your shaver in top shape

Automated cleaning

The Braun Clean&Charge automatically takes care of all cleaning and lubrication needs of your shaver. Please refer to section B.

Manual cleaning

For easy manual cleaning after each shave, switch the shaver off. Press the release button, take off the shaver foil and gently tap it out on a ﬂat surface. Using the brush, clean the cutter block and the inner area of the pivoting head. About every four weeks, clean the cutter block with Braun cleaning agents.

If your skin is very dry and you notice a reduced operation time of the shaver, apply a drop of light machine oil onto the shaver foil.

oil

Do not rinse the shaver in or under water.

Replacing the shaving parts

The shaver foil and cutter block are precision parts that, in time, are subject to wear. Replace your foil and cutter block every 18 months and get a 25 % better shave.* (Shaver foil and cutter block: part no. 6000)

(* Overall evaluation from Braun users comparing their shave with new parts and those used for 18 months.)

Preserving the cell unit

6000

Flex Integral

In order to maintain the optimum capacity of the rechargeable batteries, the shaver has to be fully discharged (by shaving) every 6 months approximately. Then recharge the shaver to full capacity again. This reconditions the rechargeable batteries.

Accessories

Available at your dealer or Braun Service Centers:

Shaver foil and cutter block

(part no. 6000)

Environmental notice

This appliance is provided with a nickel-hydride batteries. They do not contain any harmful heavy metals.

Nevertheless, in the interest of recycling raw materials, please do not dispose of this appliance in the household waste at the end of its useful life. Disposal can take place at a Braun Service Center or appropriate collection sites.

Subject to change without notice.

B Clean&Charge

Braun Clean&Charge has been developed for cleaning, charging and storing your shaver. Clean your shaver daily in the Clean&Charge.

During the automated cleaning process, the shaver is switched on and off at intervals to obtain best cleaning results. Since the specially formulated cleaning ﬂuid contains a small amount of oil, the cleaning procedure also fulﬁlls the lubrication needs of the shaver.

Important

• Only use the power supply cord set supplied with the shaver.

• In order to avoid any leakage of the cleaning ﬂuid, place the appliance on a ﬂat, stable surface. Do not tip, move suddenly or transport in any way if a cleaning cartridge is installed.

• Do not place the appliance in a mirror cabinet, nor store it over radiators, nor place it on polished or laquered surfaces. Do not expose to direct sunlight.

• The appliance contains highly ﬂammable liquid. Keep it away from sources of ignition. No smoking. Keep out of reach of children. Do not reﬁll cartridge. Use only original Braun reﬁll cartridge.

• When cleaning the shaver, its protection cap should be removed.

Description

12 Lift button for cartridge exchange 13 Contact bow 14 Release button 15 Operation mode selector 16 «clean» light: cleaning process indicator 17 «charge» light: charging process indicator 18 «cartridge» light: cartridge replacement indicator 19 Cleaning cartridge

Technical speciﬁcations

• Power consumption:

•3 W when cleaning

•7 W when charging

• Power supply: 100-240 V ~ / 50 or 60 Hz (automatic adaptation)

• Input voltage: 12 V

Before using Clean&Charge

First charge:

For the ﬁ supply cord set directly to the shaver, charge it for 4 hours and shave at least once. Only then can the shaver be cleaned or recharged in the Clean&Charge.

If the rechargeable batteries are discharged, select the combined «clean» + «charge» programme rather than the «clean» programme alone.

Installing the cartridge

Press the lift button (12) to open the housing.

Hold the cartridge down on a ﬂat, stable surface (e.g. table). Carefully remove the lid from the cartridge. Slide the cartridge into the base as far as it will go.

Slowly close the housing by pushing it down until it locks.

Replacing the cartridge

After having pressed the lift button to open the housing, wait for a few seconds before removing the used cartridge.

Before discarding the used cartridge, make sure to close the openings using the lid of the new cartridge, since the used cartridge will contain contaminated cleaning solution.

rst charge of the shaver, connect the power

Operating your Clean&Charge

• Use the power supply cord set from your shaver and plug it into the Clean&Charge and then into a main outlet. Open the contact bow (13) by pressing the release button (14). After shaving, switch the shaver off and place it upside down into the Clean&Charge. The pivoting head must not be locked (switch «head lock» position down)

5441

new

7570

old

• Select the operation mode by toggling with the mode selector (15): clean (about 15 min) clean + charge (about 75 min) charge (about 60 min)

The corresponding lights will come on.

5441

clean

charge
