English

Our products are designed to meet the highest standards of quality, functionality and
design. Thank you for your trust in Braun’s quality and we hope you enjoy your new
Braun product.

Read these instructions completely, they contain safety information. Keep them
for future reference.

Warning

Your appliance is provided with a special cord set, which has an
integrated Safety Extra Low Voltage power supply. Do not
exchange or tamper with any part of it, otherwise there is risk of an
electric shock. Only use the special cord set provided with your
appliance.

If the appliance is marked

492, you can use it with any

Braun power supply coded 492-XXXX.

This appliance is suitable for cleaning under running water
and use in a bathtub or shower. For safety reasons it can

only be operated cordless.

Detach the shaver from the power supply before using it with
water.

Do not shave with a damaged foil or cord.
This appliance can be used by children aged from 8 years and

above and persons with reduced physical, sensory or mental capa­bilities or lack of experience and knowledge if they have been given
supervision or instruction concerning the safe use of the appliance
and understand the hazards involved. Children shall not play with
the appliance. Cleaning and user maintenance shall not be made
by children unless they are older than 8 years and supervised.

Clean&Charge Station

To prevent the cleaning fluid from leaking, ensure that the
Clean&Charge Station is placed on a flat surface. When a cleaning
cartridge is installed, do not tip, move suddenly or transport the
station in any way as cleaning fluid might spill out of the cartridge.
Do not place the station inside a mirror cabinet, nor place it on a
polished or lacquered surface.

The cleaning cartridge contains a highly flammable liquid so keep
it away from sources of ignition. Do not expose to direct sunlight
and cigarette smoking nor store it over a radiator.

Do not refill the cartridge and use only original Braun refill
cartridges.

Shaver

1 Foil & Cutter cassette
2 Cassette release button
3 MultiHeadLock switch
4 On/off switch
5 Shaver display
5 a Lock symbol (travel lock)
5 b Charging segments
5 c Cleaning indicator
5 d Battery symbol
6 Long hair trimmer
7 Shaver-to-station contacts
8 Release button for long hair trimmer
9 Shaver power socket
10 a Special cord set (design can differ)
10 b Charging stand*
11 Protection cap*
12 Travel case*

* not with all models

First use and charging

Connect the shaver to an electrical outlet by snapping the special cord set (10a) into
the shaver power socket (9) / the charging stand (10b) or for cc models via the
Clean&Charge Station (see Chapter «Clean&Charge Station»).

Basic operating information

• A full charge provides up to 50 minutes of cordless shaving time. This may vary

according to your beard growth and environmental temperature.

• Recommended ambient temperature for charging is 5 °C to 35 °C. The battery may

not charge properly or at all under extreme low or high temperatures.

• Recommended ambient temperature for storage and shaving is 15 °C to 35 °C.

• Do not expose the appliance to temperatures higher than 50 °C for extended periods

of time.

• When the shaver is connected to an electrical outlet, it may take some minutes until

the display illuminates.

15

Charging / low charge

The charge status is shown in the shaver display (5).

• During charging the respective charging segment (5b) will blink.

• When the shaver is fully charged and connected to an electrical outlet, all 3 charging

segments will light up for a few seconds. Then the display turns off.

• The battery symbol (5d) will flash red, when the battery is running low. You should be

able to finish your shave. With switching off the shaver a beep sound reminds of the
low charge status.

Using the shaver

Press the on/off switch (4) to operate the shaver.

Tips for a perfect dry shave

For best results, Braun recommends you to follow 3 simple steps:

1. Always shave before washing your face.

2. At all times, hold the shaver at the right angle (90°) to your skin.

3. Stretch your skin and shave against the direction of your beard growth.

MultiHeadLock switch (head lock)

• To shave hard-to-reach areas (e.g. under the nose) slide the MultiHeadLock switch

(3) down to lock the shaver head.

• The shaver head can be locked in five positions. To change position, move the shaver

head with your thumb and forefinger back or forth. It will automatically click into the
next position.

• For automatic cleaning in the Clean&Charge Station the head lock should be released.

Long hair trimmer

To trim sideburns, moustache or beard press the release button (8) and slide the long
hair trimmer (6) upwards.

Travel lock

• The lock symbol (5a) lights up in the display when the shaver has been locked to

avoid unintended starting of the motor (e.g. for storing it in a suitcase).

• Activation: By pressing the on/off switch (4) for 3 seconds the shaver is locked. This is

confirmed by a beep sound and the lock symbol in the display. Afterwards the display
turns off.

• Deactivation: By pressing the on/off switch for 3 seconds again the shaver is

unlocked.

Manual cleaning of the shaver

Cleaning under running water

• Switch on the shaver (cordless) and rinse the shaver head under hot running

water until all residues have been removed. You may use liquid soap without

abrasive substances. Rinse off all foam and let the shaver run for a few more seconds.

16

• Next, switch off the shaver, press the release button (2) to remove the Foil & Cutter

cassette (1) and let it dry.

• If you regularly clean the shaver under water, then once a week apply a drop of light

machine oil on top of the Foil & Cutter cassette.

The shaver should be cleaned after each foam usage.

Cleaning with a brush

• Switch off the shaver. Remove the Foil & Cutter cassette (1) and tap it out on a flat

surface. Using the brush, clean the inner area of the pivoting head. Do not clean the
cassette with the brush as this may damage it!

Clean&Charge Station (C&C) (not with all models)

The Clean&Charge Station has been developed for cleaning, charging, lubricating,
disinfecting, drying and storing your Braun shaver.

13 Station power socket
14 Lift button for cartridge exchange
15 Station-to-shaver contacts
16 Clean&Charge Station display
16 a Level indicator
16 b Status light
16 c Cleaning program indicators
17 Start button
18 Cleaning cartridge

Installing the C&C

• Remove the protection foil from the C&C display.

• Press the lift button (14) at the rear side of the C&C to lift up the housing.

• Hold the cleaning cartridge (18) down on a flat, stable surface (e.g. table).

• Carefully remove the lid from the cartridge.

• Slide the cartridge from the rear side into the base of the station until it snaps into place.

• Slowly close the housing by pushing it down until it locks.

• Using the special cord set (10a), connect the station power socket (13) to an

electrical outlet.

Using the C&C

Important: The shaver needs to be dry and free from any foam or soap residue!

Insert the shaver in the C&C upside down, with the front showing and released head
lock (3).
The contacts (7) on the back of the shaver need to align with the contacts (15) in the
C&C. Push the shaver in the correct position. A beep sound confirms that the shaver
sits properly in the C&C.
The C&C analyzes the hygiene status. The status is shown by the cleaning program
indicators (16c) in the C&C display (16).

17

Charging the shaver in the C&C

Charging will start automatically when the shaver has been placed in properly.

Cleaning the shaver in the C&C

When the cleaning indicator (5c) lights up in the shaver display, insert the shaver into
the C&C, as described above.

Cleaning programs

short economical cleaning

normal level of cleaning

high intensive cleaning

Start automatic cleaning

Start the cleaning process by pressing the start button (17). If status light (16b) does
not shine (C&C switches to stand-by after ca. 10 minutes), press start button twice.
Otherwise cleaning will not start. For best shaving results, we recommend cleaning

after each shave.

Each cleaning program consists of several cycles, where cleaning fluid is flushed
through the shaver head. Depending on your Clean&Charge Station model and/or
program selected, the cleaning time takes up to 3 minutes. During this time the status
light blinks. Leave the shaver in the station for drying. It takes several hours until
remaining moisture evaporates depending on the climatic conditions.

After completing the cleaning and charging procedure, all indicators turn off.

Removing the shaver from the C&C

Hold the C&C with one hand and tilt the shaver slightly to the front to release it.

Cleaning cartridge / Replacement

When the level indicator (16a) lights up permanently red, the remaining fluid in the
cartridge is sufficient for about 3 more cycles. When the level indicator blinks red, the
cartridge needs to be replaced – about every 4 weeks when used daily.

After having pressed the lift button (14) to open the housing, wait for a few seconds
before removing the used cartridge to avoid any dripping. Before discarding the used
cartridge, make sure to close the openings using the lid of the new cartridge, since the
used cartridge will contain contaminated cleaning solution.

The hygienic cleaning cartridge contains ethanol or isopropanol (specification see
cartridge), which once opened will naturally evaporate slowly. Each cartridge, if not
used daily, should be replaced after approximately 8 weeks to ensure optimal
disinfection. The cleaning cartridge also contains lubricants for the shaving system,

18

which may leave residual marks on the outer foil frame and the cleaning chamber of the
C&C. These marks can be removed easily by wiping gently with a damp cloth.

Accessories

Braun recommends changing your shaver’s Foil & Cutter cassette every 18 months to
maintain your shaver’s maximum performance.
Available at your dealer or Braun Service Centres:

• Foil & Cutter cassette: 52S/52B

• Cleaning Cartridge: CCR

• Braun Shaver cleaner spray

Environmental notice

Product contains batteries and/or recyclable electric waste. For environment
protection do not dispose of in household waste, but for recycling take to electric
waste collection points provided in your country.

The cleaning cartridge can be disposed of with regular household waste.

Subject to change without notice.

For electric specifications, see printing on the special cord set.

Trouble-Shooting

Problem Possible reason Remedy

SHAVER

Shaver does
not charge
completely and
keeps blinking.

Charging does
not start when
connected to
power socket.

Ambient temperature is
out of valid range.

1. Sometimes charging
could start delayed
(e.g. after long
storage).

2. Ambient temperature
is out of valid range.

3. Special cord set is not
plugged in properly.

Recommended ambient temperature for
charging is 5 °C to 35 °C.

1. Wait a few minutes, if charging will
start automatically.

2. Recommended ambient temperature
for charging is 5 °C to 35 °C.

3. Special cord set needs to snap into
place.

19

Unpleasant
smell from the
shaver head.

Battery
performance
dropped
significantly.

Shaving
performance
dropped
significantly.

Shaver head is
damp.

CLEAN&CHARGE STATION

Cleaning does
not start when
pressing the
start button.

Increased
consumption of
cleaning fluid.

1. Shaver head is cleaned
with water.

2. Cleaning cartridge is
in use for more than
8 weeks.

1. Foil and cutter are
worn which requires
more power for each
shave.

2. Shaver head is
regularly cleaned
with water but not
lubricated.

1. Foil and cutter are
worn.

2. Shaving system is
clogged.

1. Drying time after
automatic cleaning
was too short.

2. Drain of the
Clean&Charge Station
is clogged.

1. Shaver is not placed
properly in the
Clean&Charge Station.

2. Cleaning cartridge
contains not enough
cleaning fluid (display
blinks red).

Drain of the Clean&
Charge station is
clogged.

1. When cleaning the shaver head with
water only use hot water and from time
to time some liquid soap (without
abrasive substances). Remove
Foil & Cutter cassette to let it dry.

2. Change cleaning cartridge at least
every 8 weeks.

1. Renew Foil & Cutter cassette.

2. If the shaver is regularly cleaned with
water, apply a drop of light machine oil
on top of the foil once a week for
lubrication.

1. Renew Foil & Cutter cassette.

2. Soak the Foil & Cutter cassette into hot
water with a drop of dish liquid.
Afterwards rinse it properly and tap it
out. Once dry apply a drop of light
machine oil on the foil.

1. Clean directly after shaving to allow
enough time for drying.

2. Clean the drain with a wooden
toothpick.

1. Insert shaver into the Clean&Charge
Station and push it to the rear side of
the station (contacts of the shaver
need to align with contacts in the
station).

2. Insert new cleaning cartridge.
Press start button again.

– Clean the drain with a wooden

toothpick.

– Regularly wipe the tub clean.

20

Guarantee

We grant a 2 year guarantee on the product commencing on the date of purchase.
Within the guarantee period we will eliminate any defects in the appliance resulting from
faults in materials or workmanship, free of charge either by repairing or replacing the
complete appliance at our discretion.
This guarantee extends to every country where this appliance is supplied by Braun or its
appointed distributor.
This guarantee does not cover: damage due to improper use, normal wear or use as
well as defects that have a negligible effect on the value or operation of the appliance.
The guarantee becomes void if repairs are undertaken by unauthorised persons and if
original Braun parts are not used.
To obtain service within the guarantee period, hand in or send the complete appliance
with your sales receipt to an authorised Braun Customer Service Centre (address
information available online at www.service.braun.com).

For UK only:

This guarantee in no way affects your rights under statutory law.

For Australia & New Zealand only:

Warranty
In Australia, our goods come with guarantees that cannot be excluded under
the Australian Consumer Law. You are entitled to a replacement or refund for
a major failure and for compensation for any other reasonably foreseeable loss
or damage. You are also entitled to have the goods repaired or replaced if the
goods fail to be of acceptable quality and the failure does not amount to a major
failure.

The benefits given by this warranty are in addition to other rights and remedies
of the consumer law.

For Claims in Australia please contact:

Procter & Gamble Australia Pty Ltd
1 Innovation Road, Macquarie Park
NSW 2113
Telephone: [phone]
Facsimile: [phone]
Email: [e-mail]

For claims in New Zealand please contact:

Procter & Gamble Distributing New Zealand Limited
c/o Simpson Grierson
88 Shortland Street, Auckland 1010
New Zealand
Telephone: [phone]
Facsimile: [phone]
Email: [e-mail]

21

Our Warranty

This appliance is also covered by a 24 Month Replacement Warranty commencing on
the date of purchase (Our Warranty).

Our Warranty applies in all States and Territories of Australia and in
New Zealand and is in addition to any mandatory statutory obligations imposed
on Procter & Gamble Australia Pty. Ltd., its distributors and its manufacturer.
Our Warranty does not purport to exclude, restrict or modify any such
mandatory statutory obligations.

Our Warranty only covers defects in the appliance resulting from faults in workmanship
or materials. Therefore, if your appliance becomes faulty as a result of faults in
workmanship or materials, it will be exchanged by your retailer, on presentation of proof
of purchase.

Our Warranty only applies to domestic or household use of this appliance
and the warranty will only apply if the correct operating instructions included with this
product have been followed. For any appliance replaced under this warranty,
Our Warranty ends on the expiry of the warranty period that applied to the original
appliance.

Our Warranty does not cover:
A. Damage arising from improper use or operation on incorrect voltages.
B. Breakages to shaver foils, glass jars, etc.
C. Normal wear due to moving parts.
D. Repairs undertaken by unauthorised service personnel or use of non genuine parts.
E. Appliances that are outside the warranty period or are not faulty.

This appliance is not intended for use by young children or infirm persons without
supervision. Young children should be supervised to ensure that they do not play with
the appliance.

If the appliance is powered by a cord extension set or electrical portable outlet device
these should be positioned so they are not subject to splashing or ingress of moisture.

To the extent permitted by the laws of the Commonwealth of Australia and New Zealand
and applicable laws of a State or Territory of Australia, and without affecting any
mandatory statutory obligations imposed by law, Our Warranty is given in exchange for
any other rights you may have against Procter & Gamble Australia Pty. Ltd. or its
distributors or manufacturer, whether at law, in tort (including negligence), in equity or
under statute.

Please retain proof of purchase of this appliance. If you have any questions in relation to
Our Warranty, please call our Consumer Service line (see below for numbers).

If you intend to make a claim please telephone our Customer Service line on the
numbers set out below to obtain information about your claim and any costs associated
with claiming under Our Warranty. You will bear the cost of returning your product to us.

Repairs and service

If you are sending your appliance for repair under Our Warranty, please pack the
appliance adequately and send it to your nearest Service Agent, at your expense.

22

For service or replacement parts refer to the authorised Service Agents listed overleaf.
Local Service Agents may change from time to time – in that event please contact the
Consumer Service free call number below for updated local service agent details.

Australian Consumer Service (free call): 1 800 641 820

New Zealand Consumer Service (free call): 0 800 108 909

Australian & New Zealand Service Agents

VICTORIA & TASMANIA

Statewide Services Pty Ltd trading
as J A Appliances
17-19 Hossack Avenue
Coburg North, VIC 3058
Tel. [phone]
Fax. [phone]
Email: jaappliances@statewideservices.
com.au

QUEENSLAND

Walters Import trading as Brisbane
Appliance Service Centre
449 Beaudesert Road
Moorooka QLD 4105
Tel. [phone]
Fax. [phone]
Email: [e-mail]

WESTERN AUSTRALIA

Mark 1 Appliances
Unit 1, 46 Abernethy Road
Belmont, WA 6104
Tel. [phone]
Fax. [phone]
Email: [e-mail]

NEW SOUTH WALES & ACT

Faulder Appliance Services Pty Ltd
Shop 4,
9 Evans Road,
Rooty Hill, NSW 2766
Tel. [phone]
Fax. [phone]
Email: [e-mail]

SOUTH AUSTRALIA & NT

Adelaide Service Centre
Shop B2,
Parkholme Shopping Centre
319 Oaklands Road, Parkholme
Adelaide, SA 5043
Tel. [phone]
Fax. [phone]
Email: [e-mail]

NEW ZEALAND

Key Service Ltd
7D Echelon Place East Tamaki
Manukau City
Auckland
New Zealand
(PO Box 38569, Howick, Auckland,
New Zealand)
Tel. [phone]
Fax. [phone]
Email: [e-mail]

23
