Braun 390cc-4 User Manual [es, fr, en]

Series 33
Stapled booklet, 105x148 mm, 40 p (incl. 8 p cover), 2/2c = black + HKS43N
r
e
e
s
r
i
e
e
S
s
S
3
3
+
Type 5411, 5412
390cc-4
Modèles 5411, 5412 Modelo 5411, 5412
www.braun.com
390cc-4 370cc-4 350cc-4
English 6
Français 18
Español 29
Thank you for purchasing a Braun product. We hope you are completely satisfied with your new Braun shaver. If you have any questions, please call: US residents 1-800-BRAUN-11 1-800-272-8611 Canadian residents 1-800-387-6657
Merci d’avoir fait l’achat d’un produit Braun. Nous espérons que vous serez pleinement satisfait de votre nouveau rasoir Braun. Si vous avez des questions, veuillez appeler Braun Canada : 1-800-387-6657
Gracias por haber comprado un producto Braun. Esperamos que quede completamente satisfecho con su nueva afeitadora Braun. Si tiene alguna duda, por favor llame al: En México 01(800) 508-5800
99778043/I-11 USA / CDN / MEX
1
+
3 9 0
c c
­4
S
e
r
i
e
s
3
S
e
r
i
e
s
3
2
3
r
i
e
e
s
r
i
e
e
S
s
S
3
3
4
+
5 6
+
11
7
8
3
9
0
cc-4
390
370 350
9
10
STOP
3
12
+
A
+
90°
B
f ul
l
l o c
k
f
u l l
click!
clic!
oil
h
uile
4
•••
•••
1
2
l oc
k
l ock
C
l o c
k
1
2
new/
nouveau
3
a
4
•••
5
-
+
new/
nouveau
-
+
-
-
+
old / ancien
+
b
•••
c
-
+
5
English
IMPORTANT SAFETY INSTRUCTIONS
When using an electrical appliance, basic precautions should always be followed, including the following:
Read all instructions before using this appliance.
When disconnected, the hand-held part of this shaving appliance may be cleaned under water.
DANGER
To reduce the risk of electric shock:
1. Use only in dry condition.
2. Do not submerge in water.
3. Do not reach for an appliance that has fallen into water. Unplug immediately.
4. Do not use while bathing or in a shower.
5. Do not place, store or charge the appliance where it can fall or be pulled into a tub or sink. Do not place in or drop into water or other liquid.
6. Except when charging, always unplug this appliance from the electrical outlet immediately after using.
7. Unplug this appliance before cleaning.
8. This appliance is provided with a special electric cord set with integrated Safety Extra Low Voltage power supply. Do not exchange or manipulate any part of it.
9. Do not use an extension cord with this appliance.
FOR HOUSEHOLD USE ONLY
6
WARNING
To reduce the risk of burns, fire, electric shock, or injury to persons:
1. Close supervision is necessary when this appliance is used by, on, or near children or invalids.
2. Use this appliance only for its intended use as described in this manual. Do not use attachments not recommended by the manufacturer.
3. Never operate this appliance if it has a damaged cord or plug, if it is not working properly, if it has been dropped or damaged, or if the power supply has been dropped into water. Return the appliance to a service center for examination and repair.
4. Keep the cord away from heated surfaces.
5. Never drop or insert any object into any opening of the appliance.
6. Do not use outdoors or operate where aerosol (spray) products are being used or where oxygen is being administered.
7. Do not use this appliance with a damaged or broken foil, as serious skin injuries may occur.
8. Always attach plug to appliance first, then to outlet. To disconnect, turn all controls to «off», then remove plug from outlet.
9. When plugging to an electrical outlet outside the USA, use a plug adapter to match the outlet’s pin configuration.
SAVE THESE INSTRUCTIONS
7
Description
1 Foil & Cutter cassette 2 Long hair trimmer 3 Precision setting switch (« ») (390cc/370cc only) 4 On/off switch 5 Charging lights (green) 6 Low-charge light (red) 7 Cleaning light (yellow) 8 Replacement light for shaving parts 9 Shaver power socket 10 Special electric cord set 11 Travel pouch (390cc/370cc only) 12 Protective cap (350cc only)
Charging
The best environmental temperature for charging is between 60 °F to 95 °F / 15 °C to 35 °C. Do not expose the shaver to temperatures higher than 122 °F / 50 °C for extended periods of time.
• Using the special electric cord set (10), connect the shaver to an electrical
outlet with the motor switched off.
• When charging for the first time or when the shaver is not used for a few
months, leave the shaver to charge continuously for 4 hours. Subsequent charges will take about 1 hour.
• A full charge provides up to 45 minutes of cordless shaving time depend-
ing on your beard growth.
• Shave without the cord. With normal use the shaver will be charged auto-
matically after every cleaning in the Clean&Renew (see «C Clean&Renew»).
• Maximum battery capacity will only be reached after several charging/
discharging cycles.
• 5-minute quick charge (with the special electric cord set (10)) is sufficient
for a shave.
• If the rechargeable batteries are discharged, you may also shave by
connecting the shaver to an electrical outlet via the special electric cord set.
Charging lights
The green charging lights (5) show the charge status of the batteries. The green charging light blinks when the shaver is being charged or switched on. When the battery is fully charged, all green charging lights shine permanently, provided the shaver is connected to an electrical outlet.
8
Low-charge light
The red low-charge light shines permanently when the battery is running low. You should be able to finish your shave.
A Shaving
Press the on/off switch (4) to operate the shaver (picture). The flexible shaving foils automatically adjust to every contour of your face (picture).
Long hair trimmer
To trim sideburns, moustache or beard, slide the long hair trimmer (2) upwards.
Precision setting switch (« For precise handling in hard to shave areas (e.g. under the nose) slide the switch (3) to the right to position « ». The centre trimmer and one foil will be lowered.
Tips for the perfect shave
For best results, Braun recommends you follow 3 simple steps:
1. Always shave before washing your face.
2. At all times, hold the shaver at right angles (90°) to your skin.
3. Stretch your skin and shave against the direction of your beard growth.
») (390cc/370cc only)
B Keeping your shaver in top shape
Cleaning indicator
Your shaver should be cleaned daily in the Clean&Renew, and certainly when the yellow cleaning light (7) shines constantly after shaving. If this is not done, the yellow light will go out after some time. The shaver’s electronics will then assume it has been cleaned manually and a new calculation of the time when the next cleaning is required will be started. During the cleaning process in the Clean&Renew the yellow light will flash and will go off after approx. 4 hours when cleaning is finished.
Automatic cleaning
Once the shaver is put into the Clean&Renew, it is cleaned automatically (see «C Clean&Renew»). Manual cleaning is recommended only when the Clean&Renew is not available, e. g. when travelling.
9
Manual cleaning
The hand-held unit should be detached from the power supply cord before cleaning. The shaver should not be used until it has dried.
Regular cleaning ensures better shaving performance. Rinsing the shaver head under running water after each shave is an easy and fast way to keep it clean:
• Switch the shaver on (cordless) and rinse the shaver head under hot
running water. You may use liquid soap without abrasive substances. Rinse off all foam and let the shaver run for a few more seconds.
• Next, switch off the shaver, remove the shaver Foil & Cutter cassette (1)
and let it dry.
• If you regularly clean the shaver under water, then once a week apply a
drop of light machine oil onto the long hair trimmer (2) and shaver Foil & Cutter cassette (1).
Alternatively, you may clean the shaver using a brush:
• Switch off the shaver. Remove the shaver Foil & Cutter cassette and tap it
out on a flat surface.
• Using a brush, clean the inner area of the shaver head. However, do not
clean the shaver Foil & Cutter cassette with a brush as this may damage it.
Replacement light for shaving parts
To maintain the appliance performing like new, replace the shaver Foil & Cutter cassette (1), when the replacement light for shaving parts (8) comes on (after about 18 months) or when worn. The replacement light will remind you during the next 7 shaves to replace the foil and cutter cassette. Then the shaver will automatically reset. After you have replaced the Foil & Cutter cassette (1), press the on/off switch (4) for at least 5 seconds to reset the counter. While doing so, the replacement light blinks and goes off when the reset is complete. The manual reset can be done at any time.
Preserving the batteries
In order to maintain the optimum capacity of the rechargeable batteries, the shaver has to be fully discharged (by shaving) every 6 months approximately. Then recharge the shaver to full capacity.
Environmental notice
This appliance contains rechargeable batteries. To protect the environment, do not dispose of the appliance in the household waste at the end of its useful life. Disposal can take place at a Braun Service Center or appropriate collection sites.
10
C Clean&Renew
Braun Clean&Renew has been developed for cleaning, charging and storing your shaver. During the automated cleaning process, the shaver is switched on and off at intervals to obtain best cleaning results. Since the specially formulated cleaning fluid contains a small amount of oil, the cleaning procedure also fulfils the lubrication needs of the shaver.
Important
• Only use the power supply special electric cord set supplied with the shaver.
• In order to avoid any leakage of the cleaning fluid, place the appliance on a
flat, stable surface. Do not tip, move suddenly or transport in any way if a cleaning cartridge is installed.
• Do not place the appliance in a mirror cabinet, nor store it over radiators,
nor place it on polished or lacquered surfaces. Do not expose to direct sunlight.
• The appliance contains flammable liquid. Keep it away from
sources of ignition. No smoking.
• Keep out of reach of children. Do not refill cartridge. Use only
original Braun refill cartridge.
Clean your shaver daily in the Clean&Renew.
Description
1 Start/release button 2 Contact bow 3 Lift button for cartridge exchange 4 Level indicator 5 Cleaning cartridge
Before using Clean&Renew Installing the cartridge
• Press the lift button (3) to open the housing.
• Hold the cartridge down on a flat, stable surface (e.g. table). Carefully
remove the lid from the cartridge. Slide the cartridge into the base as far as it will go.
• Slowly close the housing by pushing it down until it locks.
Replacing the cartridge
After having pressed the lift button (3) to open the housing, wait for a few seconds before removing the used cartridge.
11
Before discarding the used cartridge, make sure to close the openings using the lid of the new cartridge, since the used cartridge will contain contami­nated cleaning solution. The used cartridge can be disposed in the household waste.
Operating your Clean&Renew
• Connect your Clean&Renew with the cord set to the mains electricity
supply. The special socket at the back is adjustable to save space. After each shave, switch the shaver off and put it into the Clean&Renew, upside down and with the front showing.
• Push the start/release button (1) to lock and connect the shaver. The
cleaning process will start. The yellow light on the shaver will flash during the complete process (approx. 2 minutes cleaning, min. 4 hours drying).
• Do not interrupt the cleaning process, as it leaves the shaver wet and not
fit for use. If interruption is needed nonetheless, press the start/release button (1).
• When cleaning is finished, the yellow light will go off and the shaver is
ready for use. To release it, push the start/release button.
• A cleaning cartridge should be sufficient for about 30 cleaning cycles.
When the level indicator (4) has reached the « » mark, the remaining fluid in the cartridge is sufficient for about 5 more cleaning cycles. Then the cartridge should be replaced, when used daily approx. every 4 weeks.
• The hygienic cleaning solution cartridge contains alcohol which, once
opened, will naturally evaporate slowly into the surrounding air. Each cartridge, if not used daily should be replaced after approx. 8 weeks.
• The cleaning cartridge also contains lubricates, which may leave residual
marks on the shaver head after cleaning. However, these marks can be removed easily by wiping gently with a cloth or soft tissue paper.
• Clean the housing from time to time with a damp cloth, especially the
opening where the shaver rests.
Accessories
Available at your dealer or Braun Service Centers:
• Foil & Cutter cassette: 32S/32B
• Cleaning cartridge Clean&Renew: CCR
Subject to change without notice.
For electric specifications, see printing on the special electric cord set.
12
