Bradley Smoker MG-EXT User Manual

215-1384 Rev. A; EN 01-819
Page 1 of 4

P.O. Box 309, Menomonee Falls, WI 53052-0309
TEL. 1-800-BRADLEY FAX [phone]
http://www.bradleycorp.com

Installation
Instructions

Table of Contents

Pre-Installation Information ...............2

Installation Instructions ...................3

Cleaning and Maintenance ................4

MG-EXT

Express®Lavatory System
MG-Series Extension

IMPORTANT

Read this entire installation manual to
ensure proper installation.

Wall anchors used must have a minimum
pull-out rating of 300 lbs.

File these instructions with the owner or
maintenance department.

2

Bradley Corporation • 215-1384 Rev. A; EN 01-819

Express®Lavatory System MG-Series Extension
MG-EXT Installation Instructions

Pre-Installation Information

Check Contents

Separate all parts from the packaging and check each part with the drawing below. Make sure all
parts are accounted for before discarding any packaging material. If any parts are missing, do not
attempt to install your Express

®

MG-Series Extension until you obtain the missing parts.

Supplies Required:

• (2 - 8) 1/4”-20 wall anchors (quantity depends on length of the Extension)

Tools Recommended:

• Screwdrivers

• Tools for mounting wall anchors

• Level

• Tablesaw with carbide tip blade for trimming solid-surface material

10” - 22” 0
23” - 40” 1
41” - 58” 2
59” - 76” 3

LENGTH # OF MTG. BRACKETS

(P/N 140-814)
