Boss Audio BV6VIS Owner Manual
CONTENTS
BV6VIS User’s Manual - Contents
U S E R ’ S M A N U A L
2 General precautions
2 Safety precautions
3 Installation precautions
3 Operating precautions
4 Features
4 What is included?
5 Monitor controls and features
6 Remote control
7 System wiring
8 Monitor installation
10 Removing the monitor
10 Remote control battery
replacement
11 Troubleshooting
12 Specifications
Congratulations on your purchase
of a Video Monitor.
It has been designed, engineered
and manufactured to bring you the
highest level of performance and
quality, and will afford you years of
viewing pleasure.
Thank you for making your
choice for car video entertainment!
page
BV6VIS
6" Visor-Mount TFT Monitor
BV6VIS User’s Manual - page 2
General precautions
Safety precautions
Please read this manual completely
and carefully prior to attempting to
install your new mobile video
equipment. Installed correctly, your
equipment will provide you with
years of enjoyable and safe usage.
Installation of this equipment in any
portion of a vehicle which impairs or
distracts the driver is improper and
dangerous.
assumes no liability
whatsoever for failure to follow the
proper installation of this product.
Please keep this manual in a safe place
for future reference.
• Do not operate this equipment while
driving – safe driving should always
be your highest priority.
• Do not mount this monitor on the
sun visor in front of the driver.
In some states and countries, the
viewing of images on a screeen inside
a vehicle is illegal, even by people other
than the driver. Be sure that the
installation and operation of this system
is in compliance with local rules and
regulations.
SHOCK HAZARD! Do not open the case
of this product. There are dangerous
voltages present within the unit. There are
no user-serviceable parts within the unit.
• Do not open or attempt to repair this
unit yourself. Dangerous high voltages
are present which may result in electric
shock. Refer any repairs to a qualified
service technician.
• Do not attempt to repair a damaged,
broken or faulty power cord. Replace
it with a new one immediately.
• To avoid risk of electronic shock or
damage to the monitor, do not permit
any of this equipment to become damp
or wet from water or drinks. If this does
occur, immediately unplug the power
cord and send the monitor to your
local dealer or service center as soon
as possible.
• if there is smoke or any peculiar odor
present during useor if there is damage
to any of the component enclosures,
immediately unplug the power cord
and send the monitor to your local
dealer or service center as soon as
possible .
BV^VI User’s Manual - page 3
Operating precautions
Turn the unit off when it is not in use.
Avoid dropping any metal objects or
inflammable items into the monitor
ventilation slots.
Do not place objects on or suspend
objects from the power cord, as this
may damage the cord.
Installation precautions
Choose a mounting location in your
vehicle where the unit will not distract
or otherwise interfere with the driver’s
ability to control the vehicle.
Do not install components in areas
which are susceptible to rain, moisture,
direct sunlight, extreme heat or cold,
excessive dust, dirt or humidity.
If installation requires drilling holes or
other modifications to the vehicle,
consult with your nearest dealer or
professional car audio installer.
Use only the installation parts and
hardware provided with the unit to
ensure proper installation. Using other
parts can cause malfunction and
possible damage to your video
monitor.
Use only a power source with 12 Volts
DC (negative ground).
Before final installation, temporarily
connect the wiring according to the
diagram near the end of this manual,
check it to ensure that it has been
connected properly, and test the unit
to make sure it is working correctly.
After the monitor is installed, do not
arbitrarily pull it down or strike it. This
may loosen the mounting screws and
cause it to fall down.
BV6VIS User’s Manual - page 4
Features What is included?
Your new video monitor features the
following:
• TFT Active Matrix LCD display
• On-screen menu system
• Audio/video input controls
• Wireless remote control
When first unpacking your new flipdown monitor, please check first that
the package contains all of the items
below. If something is missing, contact
the store where you purchased the
player.
• LCD monitor
• Monitor shround
• Wireless remote control with
batteries
• RCA/mini-headphone auxiliary
AV input Y cable
• Power/AV cable
• Monitor removal key
• Mounting screws
