SOUNDCOMM B40 HEADSET
IMPORTANT SAFETY INSTRUCTIONS
2
|
ENG
Please read and keep all safety and use instructions.
Important Safety Instructions
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with a dry cloth.
7. Only use attachments/accessories specified by the manufacturer.
8. Refer all servicing to qualified personnel. Servicing is required when the apparatus has been damaged in any
way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the
apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.
WARNING/CAUTION
• Do NOT use the headset at a high volume for any extended period.
– To avoid hearing damage, use your headset at a comfortable, moderate volume level.
– Turn the volume down on your device before placing the headset on your ears, then turn the volume up gradually
until you reach a comfortable listening level.
– Focus on your safety and that of others if you use th headset while engaging in any activity requiring your
attention, e.g., while riding a bicycle or walking in or near trac, a construction site or railroad, etc. Remove the
headset or adjust your volume to ensure you can hear surrounding sounds, including alarms and warning signals.
• Do NOT use your headset while driving or at any time the inability to hear surrounding sounds may present a
danger to yourself or others.
• Remove the headset immediately if you experience a warming sensation or loss of audio.
• Do NOT use the headset as an aviation communication headset.
• Do NOT use the headset if they emit any loud unusual noise. If this happens, turn the headset o and contact Bose
customer service.
• Do NOT use mobile phone adapters to connect the headset to airplane seat jacks, as this could result in injury or
property damage due to overheating.
Contains small parts which may be a choking hazard. Not suitable for children under age 3.
This product contains magnetic material. Consult your physician on whether this might aect your
implantable medical device.
• Do NOT expose this product to dripping or splashing, and do not place objects filled with liquids, such as vases, on
or near the product.
• Keep the product away from fire and heat sources. Do NOT place naked flame sources, such as lighted candles, on
or near the product.
• Do not expose products containing batteries to excessive heat (e.g. from storage in direct sunlight, fire or the like).
• Do NOT make unauthorized alterations to this product.
REGULATORY INFORMATION
3
|
ENG
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to
Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment o and on, the user
is encouraged to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit dierent from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Changes or modifications not expressly approved by Bose Corporation could void the user’s authority to operate
this equipment.
This device complies with part 15 of the FCC Rules and with Industry Canada license-exempt RSS standard(s).
Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this
device must accept any interference received, including interference that may cause undesired operation.
This product conforms to all applicable EU directive requirements. The complete declaration of conformity
can be found at: www.Bose.com/compliance
This symbol means the product must not be discarded as household waste, and should be delivered to an
appropriate collection facility for recycling. Proper disposal and recycling helps protect natural resources,
human health and the environment. For more information on disposal and recycling of this product, contact
your local municipality, disposal service, or the shop where you bought this product.
Please complete and retain for your records
The serial and model numbers are located beneath the left side of the headband.
Serial number: ____________________________________________________________________
Model number: ____________________________________________________________________
Please keep your receipt with your owner’s guide. Now is a good time to register your Bose product.
You can easily do this by going to http://global.Bose.com/register
Date of Manufacture: The eighth digit in the serial number indicates the year of manufacture; “8” is 2008 or 2018.
EU Importer: Bose Products B.V., Gorslaan 60, 1441 RG Purmerend, The Netherlands
©2018 Bose Corporation. No part of this work may be reproduced, modified, distributed or otherwise used without
prior written permission.
4
|
ENG
CONTENTS
WHAT’S IN THE CARTON
Contents ............................................................................................................................. 6
HEADSET COMPONENTS
Headset ............................................................................................................................... 7
HOW TO WEAR THE HEADSET
Fit the headset ................................................................................................................. 8
Adjust the headset fit............................................................................................ 8
MICROPHONE
Adjust the microphone ................................................................................................. 9
Move the microphone assembly (dual headset only) ...................................... 10
HOW TO WEAR THE CONTROL MODULE (OPTIONAL)
Use the belt clip ............................................................................................................... 12
Disconnect the belt clip ....................................................................................... 12
Use the belt pack bracket ........................................................................................... 13
Attach the bracket to your radio/belt pack ................................................. 13
Attach the control module to your radio/belt pack.......................................... 14
Connect the control module ...................................................................................... 14
Disconnect the control module ................................................................................. 15
ACOUSTIC NOISE CANCELLATION
Power on ............................................................................................................................ 16
Power o ............................................................................................................................ 16
CONTENTS
5
|
ENG
CONTENTS
BATTERIES
Install the batteries ......................................................................................................... 17
Battery life ................................................................................................................ 17
HEADSET STATUS
Battery Status .................................................................................................................. 18
CARE AND MAINTENANCE
Store the headset ........................................................................................................... 19
Clean the headset ........................................................................................................... 20
Replacement parts and accessories ........................................................................ 21
Replacement Instructions .................................................................................... 21
TECHNICAL INFORMATION
Serial number location .................................................................................................. 23
Limited warranty ............................................................................................................. 23
Headset Specification ................................................................................................... 24
Microphone Specifications .......................................................................................... 24
On head Weight ............................................................................................................. 25
Cable length ..................................................................................................................... 25
Headset variants .............................................................................................................. 25
TROUBLESHOOTING
Try these solutions first ................................................................................................ 26
Other solutions ................................................................................................................ 26
6
|
ENG
WHAT’S IN THE CARTON
CONTENTS
Carry case
AA batteries (2)
Bose SoundComm B40 Headset
(single earcup or dual earcup)
Belt pack bracket Belt clip
NOTE: If any part of the product is damaged, don’t use it. Contact your authorized
Bose dealer or Bose customer service.
Visit: worldwide.Bose.com/Support/B40
7
|
ENG
HEADSET COMPONENTS
HEADSET
Side pad
Control module
Microphone assembly
(boom microphone
and cable)
Clothing clip
4-pin XLRF or 5-pin XLRM connector
Earcup
Ear cushion
Headband
NOTES: Left earcup model pictured.
Dual earcup headset pictured on page 6.
8
|
ENG
HOW TO WEAR THE HEADSET
FIT THE HEADSET
As you put the headset on, adjust each earcup so its cushion is completely over
your ear. You should feel an even, gentle pressure all around each ear.
NOTE: Make sure you wear the headset in the correct orientation. Inside of each
earcup (scrim) is clearly marked with an L (left) or an R (right).
Scrim with L
(left) marking
Adjust the headset fit
If you need to adjust the headband, make sure the headband is evenly centered on top
of your head. The headband should rest gently on your head.
NOTE: For best comfort, make your final adjustments with noise cancellation
powered on in a noisy environment.
9
|
ENG
ADJUST THE MICROPHONE
Microphone placement is important for clear communications.
NOTE: On the dual headset, the microphone assembly comes attached to the left
earcup. To move the microphone to the other earcup, see page 10.
1. Grasp the microphone with your fingers and adjust so it is level with your mouth.
2. Position the microphone so it is 0.25" (6.35 mm) from your lips.
NOTE: The microphone should not be touching your lips.
0.25" (6.35 mm)
CAUTION: The microphone can rotate up to 320°. Do NOT force the microphone
beyond the intended rotation or damage could occur.
MICROPHONE
