Bosch VGA-IP54K-IC78 Installation Guide

Page 1
IP54 Gasket Kit
VGA-IP54K-IC | VGA-IP54K-IC78
en Installation Guide
Page 2
Page 3
IP54 Gasket Kit Table of Contents | en 3
Table of Contents
1 Important Safety Instructions 4
2 Unpacking 5
3 Using the Gasket Kit 6
3.1 Schematic 6
3.2 Installing the Gasket Kit 7
Bosch Security Systems, Inc. Installation Guide F.01U.218.855 | 2.0 | 2011.07
Page 4
4 en | Important Safety Instructions IP54 Gasket Kit
1 Important Safety Instructions
Read, follow, and retain all of the following safety instructions. Heed all warnings on the unit and in the operating instructions before operation.
1. Clean only with a dry cloth. Do not use liquid cleaners or aerosol cleaners.
2. Use only replacement parts specified by the manufacturer.
3. Install in accordance with the manufacturer's instructions in accordance with applicable local codes. Use only attachments/accessories specified by the manufacturer. Equipment change or modification could void the user's guarantee or authorization agreement.
This Installation Manual is the intellectual property of Bosch Security Systems; protected by copyright. Contact: www.boschsecurity.com
F.01U.218.855 | 2.0 | 2011.07 Installation Guide Bosch Security Systems, Inc.
Page 5
IP54 Gasket Kit Unpacking | en 5
2 Unpacking
This equipment should be unpacked and handled with care. If an item appears to have been damaged in shipment, notify the shipper immediately.
Verify that all the parts listed in the Parts List below are included. If any items are missing, notify your Bosch Security Systems Sales or Customer Service Representative.
The original packing carton is the safest container in which to transport the unit and must be used if returning the unit for service. Save it for possible future use.
This installation should be made by qualified service personnel and conform to the National Electrical Code and applicable local codes.
2.1 Parts List
Verify that all parts listed in the table below are included with the VGA-IP54K Gasket Kit. If any items are missing, notify your Bosch Security Systems Sales or Customer Service Representative. – One (1) White Trim Ring with gasket installed – One (1) Black Trim Ring with gasket installed – One (1) Ceiling Gasket – One (1) Interface Box Gasket (self-stick)
Bosch Security Systems, Inc. Installation Guide F.01U.218.855 | 2.0 | 2011.07
Page 6
6 en | Using the Gasket Kit IP54 Gasket Kit
1 2
3
4
5
3 Using the Gasket Kit
The following instructions are for installing the VGA-IP54K-IC or the VGA-IP54K-IC78 (IP54 Gasket Kit) with a new Bosch In­ceiling AutoDome. If retrofitting the kit to a previously installed AutoDome, the In-ceiling housing and the Interface Box must be removed from the ceiling and the original bubble and trim ring must be removed from the in-ceiling housing before proceeding.
3.1 Schematic
Use the following illustration with the installation instructions that follow:
1 White Trim Ring with gasket installed 5 Ceiling Gasket
2 Black Trim Ring with gasket installed 6 Interface Box
3 Bubble (from original assembly) 7 Interface Box Gasket (self-stick)
4 Inner Ring (from original assembly) 8 Interface Box Lid
F.01U.218.855 | 2.0 | 2011.07 Installation Guide Bosch Security Systems, Inc.
Page 7
IP54 Gasket Kit Using the Gasket Kit | en 7
3.2 Installing the Gasket Kit
Use the following steps to install the VGA-IP54K Gasket Kit.
1. Remove the Bubble from the original Trim Ring
Assembly.
a. Remove the outer set screw from the trim ring and
bubble that shipped with the in-ceiling AutoDome. Set aside the set screw for later use.
b. Turn the original bubble and trim ring over and
remove the four (4) screws from the inner ring with a #1 Phillips screwdriver. Set aside the screws for later use. Remove the bubble (item 3) and the inner ring (item 4) from the trim ring. Set aside the inner ring and the bubble for later use.
c. Discard the original trim ring.
2. Attach the bubble to the new trim ring assembly. a. Choose the white or black trim ring with pre-installed
gasket from the VGA-IP54K kit (item 1 or 2). b. Place the bubble into the IP54 trim ring. c. Place the inner ring from the original assembly (item
4) over the bubble flanges and align the inner ring
lock-screw hole to the hole in the side of the trim ring. d. Secure the trim ring to the inner ring with the set
screw and the four (4) screws set aside earlier, using
a #1 Phillips screwdriver.
3. Install the gasket to the inside of the Interface Box lid. a. Open the lid of the Interface Box (item 8), and remove
it from the Interface Box (item 6).
b. Remove the protective paper from the self-stick
gasket provided in the kit (item 7).
c. Align the adhesive side of the gasket to the inside of
the Interface Box lid, and attach to the Interface Box.
d. Re-attach the lid with the gasket attached to the
Interface Box.
Bosch Security Systems, Inc. Installation Guide F.01U.218.855 | 2.0 | 2011.07
Page 8
8 en | Using the Gasket Kit IP54 Gasket Kit
4. Install the Ceiling Gasket around the In-Ceiling Housing. a. Place the ceiling gasket (item 5) provided in the kit
over the top of the in-ceiling housing.
b. Carefully slide the gasket down over the housing, until
it rests on the flange of the housing.
5. Install the In-ceiling AutoDome. Follow the instructions provided in the installation instruction provided with the AutoDome.
F.01U.218.855 | 2.0 | 2011.07 Installation Guide Bosch Security Systems, Inc.
Page 9
Page 10
Bosch Security Systems, Inc.
850 Greenfield Road Lancaster, PA 17601 U.S.A.
www.boschsecurity.com
© Bosch Security Systems, Inc., 2011
